This specification is available in the following formats: single page HTML, multipage HTML, full specification. This is revision 1.4803.
Copyright © 2011 W3C® (MIT, ERCIM, Keio), All Rights Reserved. W3C liability, trademark and document use rules apply.
The bulk of the text of this specification is also available in the WHATWG Web Applications 1.0 specification, under a license that permits reuse of the specification text.
This is a strict subset of the HTML5 specification that omits user-agent (UA) implementation details. It is targeted toward Web authors and others who are not UA implementors and who want a view of the HTML specification that focuses more precisely on details relevant to using the HTML language to create Web documents and Web applications. Because this document does not provide implementation conformance criteria, UA implementors should not rely on it, but should instead refer to the full specification.
This specification defines the 5th major revision of the core language of the World Wide Web: the Hypertext Markup Language (HTML). In this version, new features are introduced to help Web application authors, new elements are introduced based on research into prevailing authoring practices, and special attention has been given to defining clear conformance criteria for user agents in an effort to improve interoperability.
This section describes the status of this document at the time of its publication. Other documents may supersede this document. A list of current W3C publications and the most recently formally published revision of this technical report can be found in the W3C technical reports index at http://www.w3.org/TR/.
If you wish to make comments regarding this document in a manner that is tracked by the W3C, please submit them via using our public bug database. If you do not have an account then you can enter feedback using this form:
If you cannot do this then you can also e-mail feedback to public-html-comments@w3.org (subscribe, archives), and arrangements will be made to transpose the comments to our public bug database. Alternatively, you can e-mail feedback to whatwg@whatwg.org (subscribe, archives). The editor guarantees that all substantive feedback sent to this list will receive a reply. However, such feedback is not considered formal feedback for the W3C process. All feedback is welcome.
The working groups maintains a list of all bug reports that the editor has not yet tried to address and a list of issues for which the chairs have not yet declared a decision. The editor also maintains a list of all e-mails that he has not yet tried to address. These bugs, issues, and e-mails apply to multiple HTML-related specifications, not just this one.
Implementors should be aware that this specification is not stable. Implementors who are not taking part in the discussions are likely to find the specification changing out from under them in incompatible ways. Vendors interested in implementing this specification before it eventually reaches the Candidate Recommendation stage should join the aforementioned mailing lists and take part in the discussions.
The publication of this document by the W3C as a W3C Working Draft does not imply that all of the participants in the W3C HTML working group endorse the contents of the specification. Indeed, for any section of the specification, one can usually find many members of the working group or of the W3C as a whole who object strongly to the current text, the existence of the section at all, or the idea that the working group should even spend time discussing the concept of that section.
The latest stable version of the editor's draft of this specification is always available on the W3C CVS server and in the WHATWG Subversion repository. The latest editor's working copy (which may contain unfinished text in the process of being prepared) contains the latest draft text of this specification (amongst others). For more details, please see the WHATWG FAQ.
There are various ways to follow the change history for the HTML specifications:
svn checkout http://svn.whatwg.org/webapps/
The W3C HTML Working Group is the W3C working group responsible for this specification's progress along the W3C Recommendation track. This specification is the 05 April 2011 Working Draft.
Work on this specification is also done at the WHATWG. The W3C HTML working group actively pursues convergence with the WHATWG, as required by the W3C HTML working group charter.
This document was produced by a group operating under the 5 February 2004 W3C Patent Policy. W3C maintains a public list of any patent disclosures made in connection with the deliverables of the group; that page also includes instructions for disclosing a patent. An individual who has actual knowledge of a patent which the individual believes contains Essential Claim(s) must disclose the information in accordance with section 6 of the W3C Patent Policy.
a
elementem
elementstrong
elementsmall
elements
elementcite
elementq
elementdfn
elementabbr
elementtime
elementcode
elementvar
elementsamp
elementkbd
elementsub
and sup
elementsi
elementb
elementmark
elementruby
elementrt
elementrp
elementbdi
elementbdo
elementspan
elementbr
elementwbr
elementimg
element
iframe
elementembed
elementobject
elementparam
elementvideo
elementaudio
elementsource
elementtrack
elementcanvas
elementmap
elementarea
elementform
elementfieldset
elementlegend
elementlabel
elementinput
element
type
attribute
input
element attributes
autocomplete
attributedirname
attributelist
attributereadonly
attributesize
attributerequired
attributemultiple
attributemaxlength
attributepattern
attributemin
and max
attributesstep
attributeplaceholder
attributeinput
element APIsbutton
elementselect
elementdatalist
elementoptgroup
elementoption
elementtextarea
elementkeygen
elementoutput
elementprogress
elementmeter
elementa
and area
elementsalternate
"author
"bookmark
"external
"help
"icon
"license
"nofollow
"noreferrer
"pingback
"prefetch
"search
"sidebar
"stylesheet
"tag
"This section is non-normative.
The World Wide Web's markup language has always been HTML. HTML was primarily designed as a language for semantically describing scientific documents, although its general design and adaptations over the years have enabled it to be used to describe a number of other types of documents.
The main area that has not been adequately addressed by HTML is a vague subject referred to as Web Applications. This specification attempts to rectify this, while at the same time updating the HTML specifications to address issues raised in the past few years.
This section is non-normative.
This specification is intended for authors of documents and scripts that use the features defined in this specification.
This document is probably not suited to readers who do not already have at least a passing familiarity with Web technologies, as in places it sacrifices clarity for precision, and brevity for completeness. More approachable tutorials and authoring guides can provide a gentler introduction to the topic.
In particular, familiarity with the basics of DOM Core and DOM Events is necessary for a complete understanding of some of the more technical parts of this specification. An understanding of Web IDL, HTTP, XML, Unicode, character encodings, JavaScript, and CSS will also be helpful in places but is not essential.
This section is non-normative.
This specification is limited to providing a semantic-level markup language and associated semantic-level scripting APIs for authoring accessible pages on the Web ranging from static documents to dynamic applications.
The scope of this specification does not include providing mechanisms for media-specific customization of presentation (although default rendering rules for Web browsers are included at the end of this specification, and several mechanisms for hooking into CSS are provided as part of the language).
The scope of this specification is not to describe an entire operating system. In particular, hardware configuration software, image manipulation tools, and applications that users would be expected to use with high-end workstations on a daily basis are out of scope. In terms of applications, this specification is targeted specifically at applications that would be expected to be used by users on an occasional basis, or regularly but from disparate locations, with low CPU requirements. For instance online purchasing systems, searching systems, games (especially multiplayer online games), public telephone books or address books, communications software (e-mail clients, instant messaging clients, discussion software), document editing software, etc.
This section is non-normative.
For its first five years (1990-1995), HTML went through a number of revisions and experienced a number of extensions, primarily hosted first at CERN, and then at the IETF.
With the creation of the W3C, HTML's development changed venue again. A first abortive attempt at extending HTML in 1995 known as HTML 3.0 then made way to a more pragmatic approach known as HTML 3.2, which was completed in 1997. HTML4 followed, reaching completion in 1998.
At this time, the W3C membership decided to stop evolving HTML and instead begin work on an XML-based equivalent, called XHTML. This effort started with a reformulation of HTML4 in XML, known as XHTML 1.0, which added no new features except the new serialization, and which was completed in 2000. After XHTML 1.0, the W3C's focus turned to making it easier for other working groups to extend XHTML, under the banner of XHTML Modularization. In parallel with this, the W3C also worked on a new language that was not compatible with the earlier HTML and XHTML languages, calling it XHTML2.
Around the time that HTML's evolution was stopped in 1998, parts of the API for HTML developed by browser vendors were specified and published under the name DOM Level 1 (in 1998) and DOM Level 2 Core and DOM Level 2 HTML (starting in 2000 and culminating in 2003). These efforts then petered out, with some DOM Level 3 specifications published in 2004 but the working group being closed before all the Level 3 drafts were completed.
In 2003, the publication of XForms, a technology which was positioned as the next generation of Web forms, sparked a renewed interest in evolving HTML itself, rather than finding replacements for it. This interest was borne from the realization that XML's deployment as a Web technology was limited to entirely new technologies (like RSS and later Atom), rather than as a replacement for existing deployed technologies (like HTML).
A proof of concept to show that it was possible to extend HTML4's forms to provide many of the features that XForms 1.0 introduced, without requiring browsers to implement rendering engines that were incompatible with existing HTML Web pages, was the first result of this renewed interest. At this early stage, while the draft was already publicly available, and input was already being solicited from all sources, the specification was only under Opera Software's copyright.
The idea that HTML's evolution should be reopened was tested at a W3C workshop in 2004, where some of the principles that underlie the HTML5 work (described below), as well as the aforementioned early draft proposal covering just forms-related features, were presented to the W3C jointly by Mozilla and Opera. The proposal was rejected on the grounds that the proposal conflicted with the previously chosen direction for the Web's evolution; the W3C staff and membership voted to continue developing XML-based replacements instead.
Shortly thereafter, Apple, Mozilla, and Opera jointly announced their intent to continue working on the effort under the umbrella of a new venue called the WHATWG. A public mailing list was created, and the draft was moved to the WHATWG site. The copyright was subsequently amended to be jointly owned by all three vendors, and to allow reuse of the specification.
The WHATWG was based on several core principles, in particular that technologies need to be backwards compatible, that specifications and implementations need to match even if this means changing the specification rather than the implementations, and that specifications need to be detailed enough that implementations can achieve complete interoperability without reverse-engineering each other.
The latter requirement in particular required that the scope of the HTML5 specification include what had previously been specified in three separate documents: HTML4, XHTML1, and DOM2 HTML. It also meant including significantly more detail than had previously been considered the norm.
In 2006, the W3C indicated an interest to participate in the development of HTML5 after all, and in 2007 formed a working group chartered to work with the WHATWG on the development of the HTML5 specification. Apple, Mozilla, and Opera allowed the W3C to publish the specification under the W3C copyright, while keeping a version with the less restrictive license on the WHATWG site.
Since then, both groups have been working together.
The HTML specification published by the WHATWG is not identical to this specification. The main differences are that the WHATWG version includes features not included in this W3C version: some features have been omitted as they are considered part of future revisions of HTML, not HTML5; and other features are omitted because at the W3C they are published as separate specifications. There are also some minor differences. For an exact list of differences, please see the WHATWG specification.
A separate document has been published by the W3C HTML working group to document the differences between this specification and the language described in the HTML4 specification. [HTMLDIFF]
This section is non-normative.
It must be admitted that many aspects of HTML appear at first glance to be nonsensical and inconsistent.
HTML, its supporting DOM APIs, as well as many of its supporting technologies, have been developed over a period of several decades by a wide array of people with different priorities who, in many cases, did not know of each other's existence.
Features have thus arisen from many sources, and have not always been designed in especially consistent ways. Furthermore, because of the unique characteristics of the Web, implementation bugs have often become de-facto, and now de-jure, standards, as content is often unintentionally written in ways that rely on them before they can be fixed.
Despite all this, efforts have been made to adhere to certain design goals. These are described in the next few subsections.
This section is non-normative.
To avoid exposing Web authors to the complexities of multithreading, the HTML and DOM APIs are designed such that no script can ever detect the simultaneous execution of other scripts. Even with workers, the intent is that the behavior of implementations can be thought of as completely serializing the execution of all scripts in all browsing contexts.
The navigator.yieldForStorageUpdates()
method, in this model, is equivalent to allowing other scripts to
run while the calling script is blocked.
This section is non-normative.
This specification interacts with and relies on a wide variety of other specifications. In certain circumstances, unfortunately, conflicting needs have led to this specification violating the requirements of these other specifications. Whenever this has occurred, the transgressions have each been noted as a "willful violation", and the reason for the violation has been noted.
This section is non-normative.
This specification defines an abstract language for describing documents and applications, and some APIs for interacting with in-memory representations of resources that use this language.
The in-memory representation is known as "DOM HTML", or "the DOM" for short. This specification defines version 5 of DOM HTML, known as "DOM5 HTML".
There are various concrete syntaxes that can be used to transmit resources that use this abstract language, two of which are defined in this specification.
The first such concrete syntax is the HTML syntax. This is the
format suggested for most authors. It is compatible with most legacy
Web browsers. If a document is transmitted with an HTML MIME
type, such as text/html
, then it will be
processed as an HTML document by Web browsers.
This specification defines version 5 of the HTML syntax, known as
"HTML5".
The second concrete syntax is the XHTML syntax, which is an
application of XML. When a document is transmitted with an XML
MIME type, such as application/xhtml+xml
, then
it is treated as an XML document by Web browsers, to be parsed by an
XML processor. Authors are reminded that the processing for XML and
HTML differs; in particular, even minor syntax errors will prevent a
document labeled as XML from being rendered fully, whereas they
would be ignored in the HTML syntax.
This specification defines version 5 of the XHTML syntax, known as
"XHTML5".
The DOM, the HTML syntax, and XML cannot all represent the same
content. For example, namespaces cannot be represented using the
HTML syntax, but they are supported in the DOM and in XML.
Similarly, documents that use the noscript
feature can
be represented using the HTML syntax, but cannot be represented with
the DOM or in XML. Comments that contain the string "-->
" can only be represented in the DOM, not in
the HTML and XML syntaxes.
This section is non-normative.
This specification is divided into the following major sections:
There are also some appendices, defining rendering rules for Web browsers and listing obsolete features and IANA considerations.
This specification should be read like all other specifications. First, it should be read cover-to-cover, multiple times. Then, it should be read backwards at least once. Then it should be read by picking random sections from the contents list and following all the cross-references.
This is a definition, requirement, or explanation.
This is a note.
This is an example.
This is an open issue.
This is a warning.
interface Example { // this is an IDL definition };
method
( [ optionalArgument ] )This is a note to authors describing the usage of an interface.
/* this is a CSS fragment */
The defining instance of a term is marked up like this. Uses of that term are marked up like this or like this.
The defining instance of an element, attribute, or API is marked
up like this
. References to
that element, attribute, or API are marked up like this
.
Other code fragments are marked up like
this
.
Variables are marked up like this.
This section is non-normative.
A basic HTML document looks like this:
<!DOCTYPE html> <html> <head> <title>Sample page</title> </head> <body> <h1>Sample page</h1> <p>This is a <a href="demo.html">simple</a> sample.</p> <!-- this is a comment --> </body> </html>
HTML documents consist of a tree of elements and text. Each
element is denoted in the source by a start tag, such as "<body>
", and an end
tag, such as "</body>
". (Certain
start tags and end tags can in certain cases be omitted and are implied by other
tags.)
Tags have to be nested such that elements are all completely within each other, without overlapping:
<p>This is <em>very <strong>wrong</em>!</strong></p>
<p>This <em>is <strong>correct</strong>.</em></p>
This specification defines a set of elements that can be used in HTML, along with rules about the ways in which the elements can be nested.
Elements can have attributes, which control how the elements
work. In the example below, there is a hyperlink,
formed using the a
element and its href
attribute:
<a href="demo.html">simple</a>
Attributes are placed
inside the start tag, and consist of a name and a value, separated by an "=
" character. The attribute value can remain unquoted if it doesn't contain spaces or any of
"
'
`
=
<
or >
. Otherwise, it has to be quoted using
either single or double quotes. The value, along with the "=
" character, can be omitted altogether if the value
is the empty string.
<!-- empty attributes --> <input name=address disabled> <input name=address disabled=""> <!-- attributes with a value --> <input name=address maxlength=200> <input name=address maxlength='200'> <input name=address maxlength="200">
HTML user agents (e.g. Web browsers) then parse this markup, turning it into a DOM (Document Object Model) tree. A DOM tree is an in-memory representation of a document.
DOM trees contain several kinds of nodes, in particular a DOCTYPE node, elements, text nodes, and comment nodes.
The markup snippet at the top of this section would be turned into the following DOM tree:
html
html
The root element of this tree is the
html
element, which is the element always found at the
root of HTML documents. It contains two elements, head
and body
, as well as a text node between them.
There are many more text nodes in the DOM tree than one would
initially expect, because the source contains a number of spaces
(represented here by "␣") and line breaks ("⏎") that
all end up as text nodes in the DOM. However, for historical reasons
not all of the spaces and line breaks in the original markup appear
in the DOM. In particular, all the whitespace before
head
start tag ends up being dropped silently, and all
the whitespace after the body
end tag ends up placed at
the end of the body
.
The head
element contains a title
element, which itself contains a text node with the text "Sample
page". Similarly, the body
element contains an
h1
element, a p
element, and a
comment.
This DOM tree can be manipulated from scripts in the
page. Scripts (typically in JavaScript) are small programs that can
be embedded using the script
element or using
event handler content attributes. For example, here is
a form with a script that sets the value of the form's
output
element to say "Hello World":
<form name="main"> Result: <output name="result"></output> <script> document.forms.main.elements.result.value = 'Hello World'; </script> </form>
Each element in the DOM tree is represented by an object, and
these objects have APIs so that they can be manipulated. For
instance, a link (e.g. the a
element in the tree above)
can have its "href
"
attribute changed in several ways:
var a = document.links[0]; // obtain the first link in the document a.href = 'sample.html'; // change the destination URL of the link a.protocol = 'https'; // change just the scheme part of the URL a.setAttribute('href', 'http://example.com/'); // change the content attribute directly
Since DOM trees are used as the way to represent HTML documents when they are processed and presented by implementations (especially interactive implementations like Web browsers), this specification is mostly phrased in terms of DOM trees, instead of the markup described above.
HTML documents represent a media-independent description of interactive content. HTML documents might be rendered to a screen, or through a speech synthesizer, or on a braille display. To influence exactly how such rendering takes place, authors can use a styling language such as CSS.
In the following example, the page has been made yellow-on-blue using CSS.
<!DOCTYPE html> <html> <head> <title>Sample styled page</title> <style> body { background: navy; color: yellow; } </style> </head> <body> <h1>Sample styled page</h1> <p>This page is just a demo.</p> </body> </html>
For more details on how to use HTML, authors are encouraged to consult tutorials and guides. Some of the examples included in this specification might also be of use, but the novice author is cautioned that this specification, by necessity, defines the language with a level of detail that might be difficult to understand at first.
This section is non-normative.
Unlike previous versions of the HTML specification, this specification defines in some detail the required processing for invalid documents as well as valid documents.
However, even though the processing of invalid content is in most cases well-defined, conformance requirements for documents are still important: in practice, interoperability (the situation in which all implementations process particular content in a reliable and identical or equivalent way) is not the only goal of document conformance requirements. This section details some of the more common reasons for still distinguishing between a conforming document and one with errors.
This section is non-normative.
The majority of presentational features from previous versions of HTML are no longer allowed. Presentational markup in general has been found to have a number of problems:
While it is possible to use presentational markup in a way that provides users of assistive technologies (ATs) with an acceptable experience (e.g. using ARIA), doing so is significantly more difficult than doing so when using semantically-appropriate markup. Furthermore, even using such techniques doesn't help make pages accessible for non-AT non-graphical users, such as users of text-mode browsers.
Using media-independent markup, on the other hand, provides an easy way for documents to be authored in such a way that they work for more users (e.g. text browsers).
It is significantly easier to maintain a site written in such a
way that the markup is style-independent. For example, changing
the color of a site that uses <font color="">
throughout requires changes across the entire site, whereas a
similar change to a site based on CSS can be done by changing a
single file.
Presentational markup tends to be much more redundant, and thus results in larger document sizes.
For those reasons, presentational markup has been removed from HTML in this version. This change should not come as a surprise; HTML4 deprecated presentational markup many years ago and provided a mode (HTML4 Transitional) to help authors move away from presentational markup; later, XHTML 1.1 went further and obsoleted those features altogether.
The only remaining presentational markup features in HTML are the
style
attribute and the
style
element. Use of the style
attribute is somewhat discouraged in
production environments, but it can be useful for rapid prototyping
(where its rules can be directly moved into a separate style sheet
later) and for providing specific styles in unusual cases where a
separate style sheet would be inconvenient. Similarly, the
style
element can be useful in syndication or for
page-specific styles, but in general an external style sheet is
likely to be more convenient when the styles apply to multiple
pages.
It is also worth noting that some elements that were previously
presentational have been redefined in this specification to be
media-independent: b
, i
, hr
,
s
, and small
.
This section is non-normative.
The syntax of HTML is constrained to avoid a wide variety of problems.
Certain invalid syntax constructs, when parsed, result in DOM trees that are highly unintuitive.
To allow user agents to be used in controlled environments without having to implement the more bizarre and convoluted error handling rules, user agents are permitted to fail whenever encountering a parse error.
Some error-handling behavior, such as the behavior for the
<table><hr>...
example mentioned
above, are incompatible with streaming user agents (user agents
that process HTML files in one pass, without storing state). To
avoid interoperability problems with such user agents, any syntax
resulting in such behavior is considered invalid.
When a user agent based on XML is connected to an HTML parser, it is possible that certain invariants that XML enforces, such as comments never containing two consecutive hyphens, will be violated by an HTML file. Handling this can require that the parser coerce the HTML DOM into an XML-compatible infoset. Most syntax constructs that require such handling are considered invalid.
Certain syntax constructs can result in disproportionally poor performance. To discourage the use of such constructs, they are typically made non-conforming.
For example, the following markup results in poor performance,
since all the unclosed i
elements have to be
reconstructed in each paragraph, resulting in progressively more
elements in each paragraph:
<p><i>He dreamt. <p><i>He dreamt that he ate breakfast. <p><i>Then lunch. <p><i>And finally dinner.
The resulting DOM for this fragment would be:
There are syntax constructs that, for historical reasons, are relatively fragile. To help reduce the number of users who accidentally run into such problems, they are made non-conforming.
For example, the parsing of certain named character references in attributes happens even with the closing semicolon being omitted. It is safe to include an ampersand followed by letters that do not form a named character reference, but if the letters are changed to a string that does form a named character reference, they will be interpreted as that character instead.
In this fragment, the attribute's value is "?bill&ted
":
<a href="?bill&ted">Bill and Ted</a>
In the following fragment, however, the attribute's value is
actually "?art©
",
not the intended "?art©
":
<a href="?art©">Art and Copy</a>
To avoid this problem, all named character references are required to end with a semicolon, and uses of named character references without a semicolon are flagged as errors.
Thus, the correct way to express the above cases is as follows:
<a href="?bill&ted">Bill and Ted</a> <!-- &ted is ok, since it's not a named character reference -->
<a href="?art&copy">Art and Copy</a> <!-- the & has to be escaped, since © is a named character reference -->
Certain syntax constructs are known to cause especially subtle or serious problems in legacy user agents, and are therefore marked as non-conforming to help authors avoid them.
For example, this is why the U+0060 GRAVE ACCENT character (`) is not allowed in unquoted attributes. In certain legacy user agents, it is sometimes treated as a quote character.
Another example of this is the DOCTYPE, which is required to trigger no-quirks mode, because the behavior of legacy user agents in quirks mode is often largely undocumented.
Certain restrictions exist purely to avoid known security problems.
For example, the restriction on using UTF-7 exists purely to avoid authors falling prey to a known cross-site-scripting attack using UTF-7.
Markup where the author's intent is very unclear is often made non-conforming. Correcting these errors early makes later maintenance easier.
When a user makes a simple typo, it is helpful if the error can be caught early, as this can save the author a lot of debugging time. This specification therefore usually considers it an error to use element names, attribute names, and so forth, that do not match the names defined in this specification.
For example, if the author typed <capton>
instead of <caption>
, this would be flagged as an
error and the author could correct the typo immediately.
In order to allow the language syntax to be extended in the future, certain otherwise harmless features are disallowed.
For example, "attributes" in end tags are ignored currently, but they are invalid, in case a future change to the language makes use of that syntax feature without conflicting with already-deployed (and valid!) content.
Some authors find it helpful to be in the practice of always quoting all attributes and always including all optional tags, preferring the consistency derived from such custom over the minor benefits of terseness afforded by making use of the flexibility of the HTML syntax. To aid such authors, conformance checkers can provide modes of operation wherein such conventions are enforced.
This section is non-normative.
Beyond the syntax of the language, this specification also places restrictions on how elements and attributes can be specified. These restrictions are present for similar reasons:
To avoid misuse of elements with defined meanings, content models are defined that restrict how elements can be nested when such nestings would be of dubious value.
For example, this specification disallows
nesting a section
element inside a kbd
element, since it is highly unlikely for an author to indicate
that an entire section should be keyed in.
Similarly, to draw the author's attention to mistakes in the use of elements, clear contradictions in the semantics expressed are also considered conformance errors.
In the fragments below, for example, the semantics are nonsensical: a row cannot simultaneously be a cell, nor can a radio button be a progress bar.
<tr role="cell">
<input type=radio role=progressbar>
Another example is the restrictions on the
content models of the ul
element, which only allows
li
element children. Lists by definition consist just
of zero or more list items, so if a ul
element
contains something other than an li
element, it's not
clear what was meant.
Certain elements have default styles or behaviors that make certain combinations likely to lead to confusion. Where these have equivalent alternatives without this problem, the confusing combinations are disallowed.
For example, div
elements are
rendered as block boxes, and span
elements as inline
boxes. Putting a block box in an inline box is unnecessarily
confusing; since either nesting just div
elements, or
nesting just span
elements, or nesting
span
elements inside div
elements all
serve the same purpose as nesting a div
element in a
span
element, but only the latter involves a block
box in an inline box, the latter combination is disallowed.
Another example would be the way
interactive content cannot be nested. For example, a
button
element cannot contain a textarea
element. This is because the default behavior of such nesting
interactive elements would be highly confusing to users. Instead
of nesting these elements, they can be placed side by side.
Sometimes, something is disallowed because allowing it would likely cause author confusion.
For example, setting the disabled
attribute to the value
"false
" is disallowed, because despite the
appearance of meaning that the element is enabled, it in fact
means that the element is disabled (what matters for
implementations is the presence of the attribute, not its
value).
Some conformance errors simplify the language that authors need to learn.
For example, the area
element's
shape
attribute, despite
accepting both circ
and circle
values in
practice as synonyms, disallows the use of the circ
value, so as to
simplify tutorials and other learning aids. There would be no
benefit to allowing both, but it would cause extra confusion when
teaching the language.
Certain elements are parsed in somewhat eccentric ways (typically for historical reasons), and their content model restrictions are intended to avoid exposing the author to these issues.
For example, a form
element isn't allowed inside
phrasing content, because when parsed as HTML, a
form
element's start tag will imply a p
element's end tag. Thus, the following markup results in two
paragraphs, not one:
<p>Welcome. <form><label>Name:</label> <input></form>
It is parsed exactly like the following:
<p>Welcome. </p><form><label>Name:</label> <input></form>
Some errors are intended to help prevent script problems that would be hard to debug.
This is why, for instance, it is non-conforming
to have two id
attributes with the
same value. Duplicate IDs lead to the wrong element being
selected, with sometimes disastrous effects whose cause is hard to
determine.
Some constructs are disallowed because historically they have been the cause of a lot of wasted authoring time, and by encouraging authors to avoid making them, authors can save time in future efforts.
For example, a script
element's
src
attribute causes the
element's contents to be ignored. However, this isn't obvious,
especially if the element's contents appear to be executable
script — which can lead to authors spending a lot of time
trying to debug the inline script without realizing that it is not
executing. To reduce this problem, this specification makes it
non-conforming to have executable script in a script
element when the src
attribute is present. This means that authors who are validating
their documents are less likely to waste time with this kind of
mistake.
Some authors like to write files that can be interpreted as both XML and HTML with similar results. Though this practice is discouraged in general due to the myriad of subtle complications involved (especially when involving scripting, styling, or any kind of automated serialization), this specification has a few restrictions intended to at least somewhat mitigate the difficulties. This makes it easier for authors to use this as a transitionary step when migrating between HTML and XHTML.
For example, there are somewhat complicated
rules surrounding the lang
and
xml:lang
attributes intended
to keep the two synchronized.
Another example would be the restrictions on
the values of xmlns
attributes in the HTML
serialization, which are intended to ensure that elements in
conforming documents end up in the same namespaces whether
processed as HTML or XML.
As with the restrictions on the syntax intended to allow for new syntax in future revisions of the language, some restrictions on the content models of elements and values of attributes are intended to allow for future expansion of the HTML vocabulary.
For example, limiting the values of the target
attribute that start
with an U+005F LOW LINE character (_) to only specific predefined
values allows new predefined values to be introduced at a future
time without conflicting with author-defined values.
Certain restrictions are intended to support the restrictions made by other specifications.
For example, requiring that attributes that take media queries use only valid media queries reinforces the importance of following the conformance rules of that specification.
This section is non-normative.
The following documents might be of interest to readers of this specification.
This Architectural Specification provides authors of specifications, software developers, and content developers with a common reference for interoperable text manipulation on the World Wide Web, building on the Universal Character Set, defined jointly by the Unicode Standard and ISO/IEC 10646. Topics addressed include use of the terms 'character', 'encoding' and 'string', a reference processing model, choice and identification of character encodings, character escaping, and string indexing.
Because Unicode contains such a large number of characters and incorporates the varied writing systems of the world, incorrect usage can expose programs or systems to possible security attacks. This is especially important as more and more products are internationalized. This document describes some of the security considerations that programmers, system analysts, standards developers, and users should take into account, and provides specific recommendations to reduce the risk of problems.
Web Content Accessibility Guidelines (WCAG) 2.0 covers a wide range of recommendations for making Web content more accessible. Following these guidelines will make content accessible to a wider range of people with disabilities, including blindness and low vision, deafness and hearing loss, learning disabilities, cognitive limitations, limited movement, speech disabilities, photosensitivity and combinations of these. Following these guidelines will also often make your Web content more usable to users in general.
A document that uses polyglot markup is a document that is a stream of bytes that parses into identical document trees (with the exception of the xmlns attribute on the root element) when processed as HTML and when processed as XML. Polyglot markup that meets a well defined set of constraints is interpreted as compatible, regardless of whether they are processed as HTML or as XHTML, per the HTML5 specification. Polyglot markup uses a specific DOCTYPE, namespace declarations, and a specific case — normally lower case but occasionally camel case — for element and attribute names. Polyglot markup uses lower case for certain attribute values. Further constraints include those on empty elements, named entity references, and the use of scripts and style.
This specification refers to both HTML and XML attributes and IDL attributes, often in the same context. When it is not clear which is being referred to, they are referred to as content attributes for HTML and XML attributes, and IDL attributes for those defined on IDL interfaces. Similarly, the term "properties" is used for both JavaScript object properties and CSS properties. When these are ambiguous they are qualified as object properties and CSS properties respectively.
Generally, when the specification states that a feature applies to the HTML syntax or the XHTML syntax, it also includes the other. When a feature specifically only applies to one of the two languages, it is called out by explicitly stating that it does not apply to the other format, as in "for HTML, ... (this does not apply to XHTML)".
This specification uses the term document to refer to any use of HTML, ranging from short static documents to long essays or reports with rich multimedia, as well as to fully-fledged interactive applications.
For simplicity, terms such as shown, displayed, and visible might sometimes be used when referring to the way a document is rendered to the user. These terms are not meant to imply a visual medium; they must be considered to apply to other media in equivalent ways.
The term "transparent black" refers to the color with red, green, blue, and alpha channels all set to zero.
The specification uses the term supported when referring to whether a user agent has an implementation capable of decoding the semantics of an external resource. A format or type is said to be supported if the implementation can process an external resource of that format or type without critical aspects of the resource being ignored. Whether a specific resource is supported can depend on what features of the resource's format are in use.
For example, a PNG image would be considered to be in a supported format if its pixel data could be decoded and rendered, even if, unbeknownst to the implementation, the image also contained animation data.
A MPEG4 video file would not be considered to be in a supported format if the compression format used was not supported, even if the implementation could determine the dimensions of the movie from the file's metadata.
What some specifications, in particular the HTTP and URI specifications, refer to as a representation is referred to in this specification as a resource. [HTTP] [RFC3986]
The term MIME type is used to refer to what is sometimes called an Internet media type in protocol literature. The term media type in this specification is used to refer to the type of media intended for presentation, as used by the CSS specifications. [RFC2046] [MQ]
A string is a valid MIME type if it matches the media-type
rule defined in section 3.7 "Media Types"
of RFC 2616. In particular, a valid MIME type may
include MIME type parameters. [HTTP]
A string is a valid MIME type with no parameters if it
matches the media-type
rule defined in section
3.7 "Media Types" of RFC 2616, but does not contain any U+003B
SEMICOLON characters (;). In other words, if it consists only of a
type and subtype, with no MIME Type parameters. [HTTP]
The term HTML MIME type is used to refer to the MIME types text/html
and
text/html-sandboxed
.
A resource's critical subresources are those that the
resource needs to have available to be correctly processed. Which
resources are considered critical or not is defined by the
specification that defines the resource's format. For CSS resources,
only @import
rules introduce critical
subresources; other resources, e.g. fonts or backgrounds, are
not.
The term data:
URL refers to URLs that use the data:
scheme. [RFC2397]
To ease migration from HTML to XHTML, UAs
conforming to this specification will place elements in HTML in the
http://www.w3.org/1999/xhtml
namespace, at least for
the purposes of the DOM and CSS. The term "HTML
elements", when used in this specification, refers to any
element in that namespace, and thus refers to both HTML and XHTML
elements.
Except where otherwise stated, all elements defined or mentioned
in this specification are in the
http://www.w3.org/1999/xhtml
namespace, and all
attributes defined or mentioned in this specification have no
namespace.
Attribute names are said to be XML-compatible if they
match the Name
production defined in XML, they contain no
U+003A COLON characters (:), and their first three characters are
not an ASCII case-insensitive match for the string
"xml
". [XML]
The term XML MIME type is used to refer to the MIME types text/xml
,
application/xml
, and any MIME
type whose subtype ends with the four characters "+xml
". [RFC3023]
The root element of a Document
object is
that Document
's first element child, if any. If it does
not have one then the Document
has no root element.
The term root element, when not referring to a
Document
object's root element, means the furthest
ancestor element node of whatever node is being discussed, or the
node itself if it has no ancestors. When the node is a part of the
document, then the node's root element is indeed the
document's root element; however, if the node is not currently part
of the document tree, the root element will be an orphaned node.
When an element's root element is the root
element of a Document
object, it is said to be
in a Document
. An element is said to have
been inserted into a
document when its root element changes and is now
the document's root element. Analogously, an element is
said to have been removed from a document when its root
element changes from being the document's root
element to being another element.
A node's home subtree is the subtree rooted at that
node's root element. When a node is in a
Document
, its home subtree is that
Document
's tree.
The Document
of a Node
(such as an
element) is the Document
that the Node
's
ownerDocument
IDL
attribute returns. When a Node
is in a
Document
then that Document
is
always the Node
's Document
, and the
Node
's ownerDocument
IDL attribute
thus always returns that Document
.
The term tree order means a pre-order, depth-first
traversal of DOM nodes involved (through the parentNode
/childNodes
relationship).
When it is stated that some element or attribute is ignored, or treated as some other value, or handled as if it was something else, this refers only to the processing of the node after it is in the DOM.
The term text node refers to any Text
node, including CDATASection
nodes; specifically, any
Node
with node type TEXT_NODE
(3)
or CDATA_SECTION_NODE
(4). [DOMCORE]
A content attribute is said to change value only if its new value is different than its previous value; setting an attribute to a value it already has does not change it.
The term empty, when used of an attribute value, text node, or string, means that the length of the text is zero (i.e. not even containing spaces or control characters).
Nodes can be cloned, as
described in the DOM Core specification. For example, the cloneNode()
and importNode()
methods of the
Node
interface both clone nodes, as do a number of
algorithms in this specification. Certain HTML elements
(in particular, input
and script
) apply
additional requirements on how they are cloned. [DOMCORE]
The construction "a Foo
object", where
Foo
is actually an interface, is sometimes used instead
of the more accurate "an object implementing the interface
Foo
".
An IDL attribute is said to be getting when its value is being retrieved (e.g. by author script), and is said to be setting when a new value is assigned to it.
If a DOM object is said to be live, then the attributes and methods on that object operate on the actual underlying data, not a snapshot of the data.
The terms fire and dispatch are used interchangeably in the context of events, as in the DOM Events specifications. The term trusted event is used as defined by the DOM Events specification. [DOMEVENTS]
The term plugin refers to a user-agent defined set of
content handlers used by the user agent that can take part in the
user agent's rendering of a Document
object, but that
neither act as child browsing
contexts of the Document
nor introduce any
Node
objects to the Document
's DOM.
Typically such content handlers are provided by third parties, though a user agent can also designate built-in content handlers as plugins.
One example of a plugin would be a PDF viewer that is instantiated in a browsing context when the user navigates to a PDF file. This would count as a plugin regardless of whether the party that implemented the PDF viewer component was the same as that which implemented the user agent itself. However, a PDF viewer application that launches separate from the user agent (as opposed to using the same interface) is not a plugin by this definition.
This specification does not define a mechanism for interacting with plugins, as it is expected to be user-agent- and platform-specific. Some UAs might opt to support a plugin mechanism such as the Netscape Plugin API; others might use remote content converters or have built-in support for certain types. Indeed, this specification doesn't require user agents to support plugins at all. [NPAPI]
The preferred MIME name of a character encoding is the name or alias labeled as "preferred MIME name" in the IANA Character Sets registry, if there is one, or the encoding's name, if none of the aliases are so labeled. [IANACHARSET]
An ASCII-compatible character encoding is a single-byte or variable-length encoding in which the bytes 0x09, 0x0A, 0x0C, 0x0D, 0x20 - 0x22, 0x26, 0x27, 0x2C - 0x3F, 0x41 - 0x5A, and 0x61 - 0x7A, ignoring bytes that are the second and later bytes of multibyte sequences, all correspond to single-byte sequences that map to the same Unicode characters as those bytes in ANSI_X3.4-1968 (US-ASCII). [RFC1345]
This includes such encodings as Shift_JIS, HZ-GB-2312, and variants of ISO-2022, even though it is possible in these encodings for bytes like 0x70 to be part of longer sequences that are unrelated to their interpretation as ASCII. It excludes such encodings as UTF-7, UTF-16, GSM03.38, and EBCDIC variants.
The term Unicode character is used to mean a Unicode scalar value (i.e. any Unicode code point that is not a surrogate code point). [UNICODE]
All diagrams, examples, and notes in this specification are non-normative, as are all sections explicitly marked non-normative. Everything else in this specification is normative.
The key words "MUST", "MUST NOT", "REQUIRED", "SHOULD", "SHOULD NOT", "RECOMMENDED", "MAY", and "OPTIONAL" in the normative parts of this document are to be interpreted as described in RFC2119. For readability, these words do not appear in all uppercase letters in this specification. [RFC2119]
HTML has a wide number of extensibility mechanisms that can be used for adding semantics in a safe manner:
class
attribute to extend elements, effectively creating their own
elements, while using the most applicable existing "real" HTML
element, so that browsers and other tools that don't know of the
extension can still support it somewhat well. This is the tack used
by Microformats, for example.data-*=""
attributes. These are
guaranteed to never be touched by browsers, and allow scripts to
include data on HTML elements that scripts can then look for and
process.<meta name=""
content="">
mechanism to include page-wide metadata by
registering extensions to the
predefined set of metadata names.rel=""
mechanism to annotate
links with specific meanings by registering extensions to the predefined set of
link types. This is also used by Microformats.<script type="">
mechanism with a custom
type, for further handling by inline or server-side scripts.embed
element. This is how Flash
works.Comparing two strings in a case-sensitive manner means comparing them exactly, code point for code point.
Comparing two strings in an ASCII case-insensitive manner means comparing them exactly, code point for code point, except that the characters in the range U+0041 to U+005A (i.e. LATIN CAPITAL LETTER A to LATIN CAPITAL LETTER Z) and the corresponding characters in the range U+0061 to U+007A (i.e. LATIN SMALL LETTER A to LATIN SMALL LETTER Z) are considered to also match.
Comparing two strings in a compatibility caseless manner means using the Unicode compatibility caseless match operation to compare the two strings. [UNICODE]
Except where otherwise stated, string comparisons must be performed in a case-sensitive manner.
A string pattern is a prefix match for a string s when pattern is not longer than s and truncating s to pattern's length leaves the two strings as matches of each other.
There are various places in HTML that accept particular data types, such as dates or numbers. This section describes what the conformance criteria for content in those formats is, and how to parse them.
A number of attributes are boolean attributes. The presence of a boolean attribute on an element represents the true value, and the absence of the attribute represents the false value.
If the attribute is present, its value must either be the empty string or a value that is an ASCII case-insensitive match for the attribute's canonical name, with no leading or trailing whitespace.
The values "true" and "false" are not allowed on boolean attributes. To represent a false value, the attribute has to be omitted altogether.
Here is an example of a checkbox that is checked and disabled.
The checked
and disabled
attributes are the
boolean attributes.
<label><input type=checkbox checked name=cheese disabled> Cheese</label>
This could be equivalently written as this:
<label><input type=checkbox checked=checked name=cheese disabled=disabled> Cheese</label>
You can also mix styles; the following is still equivalent:
<label><input type='checkbox' checked name=cheese disabled=""> Cheese</label>
Some attributes are defined as taking one of a finite set of keywords. Such attributes are called enumerated attributes. The keywords are each defined to map to a particular state (several keywords might map to the same state, in which case some of the keywords are synonyms of each other; additionally, some of the keywords can be said to be non-conforming, and are only in the specification for historical reasons). In addition, two default states can be given. The first is the invalid value default, the second is the missing value default.
If an enumerated attribute is specified, the attribute's value must be an ASCII case-insensitive match for one of the given keywords that are not said to be non-conforming, with no leading or trailing whitespace.
When the attribute is specified, if its value is an ASCII case-insensitive match for one of the given keywords then that keyword's state is the state that the attribute represents. If the attribute value matches none of the given keywords, but the attribute has an invalid value default, then the attribute represents that state. Otherwise, if the attribute value matches none of the keywords but there is a missing value default state defined, then that is the state represented by the attribute. Otherwise, there is no default, and invalid values must be ignored.
When the attribute is not specified, if there is a missing value default state defined, then that is the state represented by the (missing) attribute. Otherwise, the absence of the attribute means that there is no state represented.
The empty string can be a valid keyword.
A string is a valid non-negative integer if it consists of one or more characters in the range U+0030 DIGIT ZERO (0) to U+0039 DIGIT NINE (9).
A valid non-negative integer represents the number that is represented in base ten by that string of digits.
A string is a valid integer if it consists of one or more characters in the range U+0030 DIGIT ZERO (0) to U+0039 DIGIT NINE (9), optionally prefixed with a U+002D HYPHEN-MINUS character (-).
A valid integer without a U+002D HYPHEN-MINUS (-) prefix represents the number that is represented in base ten by that string of digits. A valid integer with a U+002D HYPHEN-MINUS (-) prefix represents the number represented in base ten by the string of digits that follows the U+002D HYPHEN-MINUS, subtracted from zero.
A string is a valid floating point number if it consists of:
A valid floating point number represents the number obtained by multiplying the significand by ten raised to the power of the exponent, where the significand is the first number, interpreted as base ten (including the decimal point and the number after the decimal point, if any, and interpreting the significand as a negative number if the whole string starts with a U+002D HYPHEN-MINUS character (-) and the number is not zero), and where the exponent is the number after the E, if any (interpreted as a negative number if there is a U+002D HYPHEN-MINUS character (-) between the E and the number and the number is not zero, or else ignoring a U+002B PLUS SIGN character (+) between the E and the number if there is one). If there is no E, then the exponent is treated as zero.
The Infinity and Not-a-Number (NaN) values are not valid floating point numbers.
A valid list of integers is a number of valid integers separated by U+002C COMMA characters, with no other characters (e.g. no space characters). In addition, there might be restrictions on the number of integers that can be given, or on the range of values allowed.
In the algorithms below, the number of days in month month of year year is: 31 if month is 1, 3, 5, 7, 8, 10, or 12; 30 if month is 4, 6, 9, or 11; 29 if month is 2 and year is a number divisible by 400, or if year is a number divisible by 4 but not by 100; and 28 otherwise. This takes into account leap years in the Gregorian calendar. [GREGORIAN]
The digits in the date and time syntaxes defined in this section must be characters in the range U+0030 DIGIT ZERO (0) to U+0039 DIGIT NINE (9), used to express numbers in base ten.
A month consists of a specific proleptic Gregorian date with no time-zone information and no date information beyond a year and a month. [GREGORIAN]
A string is a valid month string representing a year year and month month if it consists of the following components in the given order:
A date consists of a specific proleptic Gregorian date with no time-zone information, consisting of a year, a month, and a day. [GREGORIAN]
A string is a valid date string representing a year year, month month, and day day if it consists of the following components in the given order:
A time consists of a specific time with no time-zone information, consisting of an hour, a minute, a second, and a fraction of a second.
A string is a valid time string representing an hour hour, a minute minute, and a second second if it consists of the following components in the given order:
The second component cannot be 60 or 61; leap seconds cannot be represented.
A local date and time consists of a specific proleptic Gregorian date, consisting of a year, a month, and a day, and a time, consisting of an hour, a minute, a second, and a fraction of a second, but expressed without a time zone. [GREGORIAN]
A string is a valid local date and time string representing a date and time if it consists of the following components in the given order:
A global date and time consists of a specific proleptic Gregorian date, consisting of a year, a month, and a day, and a time, consisting of an hour, a minute, a second, and a fraction of a second, expressed with a time-zone offset, consisting of a signed number of hours and minutes. [GREGORIAN]
A string is a valid global date and time string representing a date, time, and a time-zone offset if it consists of the following components in the given order:
This format allows for time-zone offsets from -23:59 to +23:59. In practice, however, the range of offsets of actual time zones is -12:00 to +14:00, and the minutes component of offsets of actual time zones is always either 00, 30, or 45.
Times in dates before the formation of UTC in the mid twentieth century must be expressed and interpreted in terms of UT1 (contemporary Earth solar time at the 0° longitude), not UTC (the approximation of UT1 that ticks in SI seconds). Time before the formation of time zones must be expressed and interpeted as UT1 times with explicit time zones that approximate the contemporary difference between the appropriate local time and the time observed at the location of Greenwich, London.
The following are some examples of dates written as valid global date and time strings.
0037-12-13T00:00Z
"1979-10-14T12:00:00.001-04:00
"8592-01-01T02:09+02:09
"Several things are notable about these dates:
A week consists of a week-year number and a week number representing a seven-day period starting on a Monday. Each week-year in this calendaring system has either 52 or 53 such seven-day periods, as defined below. The seven-day period starting on the Gregorian date Monday December 29th 1969 (1969-12-29) is defined as week number 1 in week-year 1970. Consecutive weeks are numbered sequentially. The week before the number 1 week in a week-year is the last week in the previous week-year, and vice versa. [GREGORIAN]
A week-year with a number year has 53 weeks if it corresponds to either a year year in the proleptic Gregorian calendar that has a Thursday as its first day (January 1st), or a year year in the proleptic Gregorian calendar that has a Wednesday as its first day (January 1st) and where year is a number divisible by 400, or a number divisible by 4 but not by 100. All other week-years have 52 weeks.
The week number of the last day of a week-year with 53 weeks is 53; the week number of the last day of a week-year with 52 weeks is 52.
The week-year number of a particular day can be different than the number of the year that contains that day in the proleptic Gregorian calendar. The first week in a week-year y is the week that contains the first Thursday of the Gregorian year y.
A string is a valid week string representing a week-year year and week week if it consists of the following components in the given order:
A string is a valid date or time string if it is also one of the following:
A string is a valid date or time string in content if it consists of zero or more White_Space characters, followed by a valid date or time string, followed by zero or more further White_Space characters.
A string is a valid date string with optional time if it is also one of the following:
A string is a valid date string in content with optional time if it consists of zero or more White_Space characters, followed by a valid date string with optional time, followed by zero or more further White_Space characters.
A simple color consists of three 8-bit numbers in the range 0..255, representing the red, green, and blue components of the color respectively, in the sRGB color space. [SRGB]
A string is a valid simple color if it is exactly seven characters long, and the first character is a U+0023 NUMBER SIGN character (#), and the remaining six characters are all in the range U+0030 DIGIT ZERO (0) to U+0039 DIGIT NINE (9), U+0041 LATIN CAPITAL LETTER A to U+0046 LATIN CAPITAL LETTER F, U+0061 LATIN SMALL LETTER A to U+0066 LATIN SMALL LETTER F, with the first two digits representing the red component, the middle two digits representing the green component, and the last two digits representing the blue component, in hexadecimal.
A string is a valid lowercase simple color if it is a valid simple color and doesn't use any characters in the range U+0041 LATIN CAPITAL LETTER A to U+0046 LATIN CAPITAL LETTER F.
A set of space-separated tokens is a string containing zero or more words (known as tokens) separated by one or more space characters, where words consist of any string of one or more characters, none of which are space characters.
A string containing a set of space-separated tokens may have leading or trailing space characters.
An unordered set of unique space-separated tokens is a set of space-separated tokens where none of the tokens are duplicated.
An ordered set of unique space-separated tokens is a set of space-separated tokens where none of the tokens are duplicated but where the order of the tokens is meaningful.
Sets of space-separated tokens sometimes have a defined set of allowed values. When a set of allowed values is defined, the tokens must all be from that list of allowed values; other values are non-conforming. If no such set of allowed values is provided, then all values are conforming.
How tokens in a set of space-separated tokens are to be compared (e.g. case-sensitively or not) is defined on a per-set basis.
A set of comma-separated tokens is a string containing zero or more tokens each separated from the next by a single U+002C COMMA character (,), where tokens consist of any string of zero or more characters, neither beginning nor ending with space characters, nor containing any U+002C COMMA characters (,), and optionally surrounded by space characters.
For instance, the string " a ,b,,d d
" consists of four
tokens: "a", "b", the empty string, and "d d". Leading and
trailing whitespace around each token doesn't count as part of the
token, and the empty string can be a token.
Sets of comma-separated tokens sometimes have further restrictions on what consists a valid token. When such restrictions are defined, the tokens must all fit within those restrictions; other values are non-conforming. If no such restrictions are specified, then all values are conforming.
A valid hash-name reference to an element of type type is a string consisting of a U+0023 NUMBER SIGN
character (#) followed by a string which exactly matches the value
of the name
attribute of an element with type
type in the document.
A string is a valid media query if it matches the
media_query_list
production of the Media
Queries specification. [MQ]
A string matches the environment of the user if it is the empty string, a string consisting of only space characters, or is a media query that matches the user's environment according to the definitions given in the Media Queries specification. [MQ]
ISSUE-56 (urls-webarch) blocks progress to Last Call
A URL is a string used to identify a resource.
A URL is a valid URL if at least one of the following conditions holds:
The URL is a valid IRI reference and it has no query component. [RFC3987]
The URL is a valid IRI reference and its query component contains no unescaped non-ASCII characters. [RFC3987]
The URL is a valid IRI reference and the character encoding of
the URL's Document
is UTF-8 or UTF-16. [RFC3987]
A string is a valid non-empty URL if it is a valid URL but it is not the empty string.
A string is a valid URL potentially surrounded by spaces if, after stripping leading and trailing whitespace from it, it is a valid URL.
A string is a valid non-empty URL potentially surrounded by spaces if, after stripping leading and trailing whitespace from it, it is a valid non-empty URL.
A URL is an absolute URL if resolving it results in the same output regardless of what it is resolved relative to, and that output is not a failure.
An absolute URL is a hierarchical URL if, when resolved and then parsed, there is a character immediately after the <scheme> component and it is a U+002F SOLIDUS character (/).
An absolute URL is an authority-based URL if, when resolved and then parsed, there are two characters immediately after the <scheme> component and they are both U+002F SOLIDUS characters (//).
This specification defines the URL
about:legacy-compat
as a reserved, though
unresolvable, about:
URI, for use in DOCTYPEs in HTML
documents when needed for compatibility with XML tools. [ABOUT]
This specification defines the URL
about:srcdoc
as a reserved, though
unresolvable, about:
URI, that is used as
the document's address of iframe
srcdoc
documents. [ABOUT]
The term "URL" in this specification is used in a manner distinct from the precise technical meaning it is given in RFC 3986. Readers familiar with that RFC will find it easier to read this specification if they pretend the term "URL" as used herein is really called something else altogether. This is a willful violation of RFC 3986. [RFC3986]
An interface that has a complement of URL decomposition IDL attributes has seven attributes with the following definitions:
attribute DOMString protocol; attribute DOMString host; attribute DOMString hostname; attribute DOMString port; attribute DOMString pathname; attribute DOMString search; attribute DOMString hash;
protocol
[ = value ]Returns the current scheme of the underlying URL.
Can be set, to change the underlying URL's scheme.
host
[ = value ]Returns the current host and port (if it's not the default port) in the underlying URL.
Can be set, to change the underlying URL's host and port.
The host and the port are separated by a colon. The port part, if omitted, will be assumed to be the current scheme's default port.
hostname
[ = value ]Returns the current host in the underlying URL.
Can be set, to change the underlying URL's host.
port
[ = value ]Returns the current port in the underlying URL.
Can be set, to change the underlying URL's port.
pathname
[ = value ]Returns the current path in the underlying URL.
Can be set, to change the underlying URL's path.
search
[ = value ]Returns the current query component in the underlying URL.
Can be set, to change the underlying URL's query component.
hash
[ = value ]Returns the current fragment identifier in the underlying URL.
Can be set, to change the underlying URL's fragment identifier.
The table below demonstrates how the getter for search
results in different results
depending on the exact original syntax of the URL:
Input URL | search value
| Explanation |
---|---|---|
http://example.com/
| empty string | No <query> component in input URL. |
http://example.com/?
| ?
| There is a <query> component, but it is empty. |
http://example.com/?test
| ?test
| The <query> component has the value "test ".
|
http://example.com/?test#
| ?test
| The (empty) <fragment> component is not part of the <query> component. |
The following table is similar; it provides a list of what each of the URL decomposition IDL attributes returns for a given input URL.
Input | protocol
| host
| hostname
| port
| pathname
| search
| hash
|
---|---|---|---|---|---|---|---|
http://example.com/carrot#question%3f
| http:
| example.com
| example.com
| (empty string) | /carrot
| (empty string) | #question%3f
|
https://www.example.com:4443?
| https:
| www.example.com:4443
| www.example.com
| 4443
| /
| ?
| (empty string) |
Some IDL attributes are defined to reflect a particular content attribute. This means that on getting, the IDL attribute returns the current value of the content attribute, and on setting, the IDL attribute changes the value of the content attribute to the given value.
The HTMLCollection
, HTMLAllCollection
,
HTMLFormControlsCollection
,
HTMLOptionsCollection
,
interfaces represent various
lists of DOM nodes. Collectively, objects implementing these
interfaces are called collections.
When a collection is created, a filter and a root are associated with the collection.
For example, when the HTMLCollection
object for the document.images
attribute is
created, it is associated with a filter that selects only
elements, and rooted at the root of the
document.
The collection then represents a live view of the subtree rooted at the collection's root, containing only nodes that match the given filter. The view is linear.
The HTMLCollection
interface represents a generic
collection of elements.
interface HTMLCollection { readonly attribute unsigned long length; caller getter Element item(in unsigned long index); caller getter object namedItem(in DOMString name); // only returns Element };
length
Returns the number of elements in the collection.
item
(index)Returns the item with index index from the collection. The items are sorted in tree order.
Returns null if index is out of range.
namedItem
(name)Returns the first item with ID or name name from the collection.
Returns null if no element with that ID or name could be found.
Only a
, applet
, area
,
embed
, form
, frame
,
frameset
, iframe
, img
, and
object
elements can have a name for the purpose of
this method; their name is given by the value of their name
attribute.
The HTMLAllCollection
interface represents a generic
collection of elements just like
HTMLCollection
, with the exception that its namedItem()
method
returns an HTMLAllCollection
object when there are
multiple matching elements.
interface HTMLAllCollection : HTMLCollection { // inherits length and item() caller getter object namedItem(in DOMString name); // overrides inherited namedItem() HTMLAllCollection tags(in DOMString tagName); };
length
Returns the number of elements in the collection.
item
(index)Returns the item with index index from the collection. The items are sorted in tree order.
Returns null if index is out of range.
namedItem
(name)namedItem
(name)Returns the item with ID or name name from the collection.
If there are multiple matching items, then an HTMLAllCollection
object containing all those elements is returned.
Returns null if no element with that ID or name could be found.
Only a
, applet
, area
,
embed
, form
, frame
,
frameset
, iframe
, img
, and
object
elements can have a name for the purpose of
this method; their name is given by the value of their name
attribute.
tags
(tagName)Returns a collection that is a filtered view of the current collection, containing only elements with the given tag name.
The HTMLFormControlsCollection
interface represents
a collection of listed elements in form
and fieldset
elements.
interface HTMLFormControlsCollection : HTMLCollection { // inherits length and item() caller getter object namedItem(in DOMString name); // overrides inherited namedItem() }; interface RadioNodeList : NodeList { attribute DOMString value; };
length
Returns the number of elements in the collection.
item
(index)Returns the item with index index from the collection. The items are sorted in tree order.
Returns null if index is out of range.
namedItem
(name)namedItem
(name)Returns the item with ID or name
name from the collection.
If there are multiple matching items, then a RadioNodeList
object containing all those elements is returned.
Returns null if no element with that ID or name
could be found.
Returns the value of the first checked radio button represented by the object.
Can be set, to check the first radio button with the given value represented by the object.
The HTMLOptionsCollection
interface represents a
list of option
elements. It is always rooted on a
select
element and has attributes and methods that
manipulate that element's descendants.
interface HTMLOptionsCollection : HTMLCollection { // inherits item() attribute unsigned long length; // overrides inherited length caller getter object namedItem(in DOMString name); // overrides inherited namedItem() void add(in HTMLElement element, in optional HTMLElement before); void add(in HTMLElement element, in long before); void remove(in long index); attribute long selectedIndex; };
length
[ = value ]Returns the number of elements in the collection.
When set to a smaller number, truncates the number of option
elements in the corresponding container.
When set to a greater number, adds new blank option
elements to that container.
item
(index)Returns the item with index index from the collection. The items are sorted in tree order.
Returns null if index is out of range.
namedItem
(name)namedItem
(name)Returns the item with ID or name
name from the collection.
If there are multiple matching items, then a NodeList
object containing all those elements is returned.
Returns null if no element with that ID could be found.
add
(element [, before ] )Inserts element before the node given by before.
The before argument can be a number, in which case element is inserted before the item with that number, or an element from the collection, in which case element is inserted before that element.
If before is omitted, null, or a number out of range, then element will be added at the end of the list.
This method will throw a HIERARCHY_REQUEST_ERR
exception if element is an ancestor of the
element into which it is to be inserted. If element is not an option
or
optgroup
element, then the method does nothing.
selectedIndex
[ = value ]Returns the index of the first selected item, if any, or −1 if there is no selected item.
Can be set, to change the selection.
The DOMTokenList
interface represents an interface
to an underlying string that consists of a set of
space-separated tokens.
DOMTokenList
objects are always
case-sensitive, even when the underlying string might
ordinarily be treated in a case-insensitive manner.
interface DOMTokenList { readonly attribute unsigned long length; getter DOMString item(in unsigned long index); boolean contains(in DOMString token); void add(in DOMString token); void remove(in DOMString token); boolean toggle(in DOMString token); stringifier DOMString (); };
length
Returns the number of tokens in the string.
item
(index)Returns the token with index index. The tokens are returned in the order they are found in the underlying string.
Returns null if index is out of range.
contains
(token)Returns true if the token is present; false otherwise.
Throws a SYNTAX_ERR
exception if token is empty.
Throws an INVALID_CHARACTER_ERR
exception if token contains any spaces.
add
(token)Adds token, unless it is already present.
Throws a SYNTAX_ERR
exception if token is empty.
Throws an INVALID_CHARACTER_ERR
exception if token contains any spaces.
remove
(token)Removes token if it is present.
Throws a SYNTAX_ERR
exception if token is empty.
Throws an INVALID_CHARACTER_ERR
exception if token contains any spaces.
toggle
(token)Adds token if it is not present, or removes it if it is. Returns true if token is now present (it was added); returns false if it is not (it was removed).
Throws a SYNTAX_ERR
exception if token is empty.
Throws an INVALID_CHARACTER_ERR
exception if token contains any spaces.
The DOMSettableTokenList
interface is the same as the
DOMTokenList
interface, except that it allows the
underlying string to be directly changed.
interface DOMSettableTokenList : DOMTokenList { attribute DOMString value; };
value
Returns the underlying string.
Can be set, to change the underlying string.
The DOMStringMap
interface represents a set of
name-value pairs. It exposes these using the scripting language's
native mechanisms for property access.
The dataset
attribute on
elements exposes the data-*
attributes on the element.
Given the following fragment and elements with similar constructions:
<img class="tower" id="tower5" data-x="12" data-y="5" data-ai="robotarget" data-hp="46" data-ability="flames" src="towers/rocket.png alt="Rocket Tower">
...one could imagine a function splashDamage()
that takes some arguments, the first
of which is the element to process:
function splashDamage(node, x, y, damage) { if (node.classList.contains('tower') && // checking the 'class' attribute node.dataset.x == x && // reading the 'data-x' attribute node.dataset.y == y) { // reading the 'data-y' attribute var hp = parseInt(node.dataset.hp); // reading the 'data-hp' attribute hp = hp - damage; if (hp < 0) { hp = 0; node.dataset.ai = 'dead'; // setting the 'data-ai' attribute delete node.dataset.ability; // removing the 'data-ability' attribute } node.dataset.hp = hp; // setting the 'data-hp' attribute } }
DOM3 Core defines mechanisms for checking for interface support, and for obtaining implementations of interfaces, using feature strings. [DOMCORE]
Authors are strongly discouraged from using these, as they are notoriously unreliable and imprecise. Authors are encouraged to rely on explicit feature testing or the graceful degradation behavior intrinsic to some of the features in this specification.
The following are DOMException
codes. [DOMCORE]
INDEX_SIZE_ERR
DOMSTRING_SIZE_ERR
HIERARCHY_REQUEST_ERR
WRONG_DOCUMENT_ERR
INVALID_CHARACTER_ERR
NO_DATA_ALLOWED_ERR
NO_MODIFICATION_ALLOWED_ERR
NOT_FOUND_ERR
NOT_SUPPORTED_ERR
INUSE_ATTRIBUTE_ERR
INVALID_STATE_ERR
SYNTAX_ERR
INVALID_MODIFICATION_ERR
NAMESPACE_ERR
INVALID_ACCESS_ERR
VALIDATION_ERR
TYPE_MISMATCH_ERR
SECURITY_ERR
NETWORK_ERR
ABORT_ERR
URL_MISMATCH_ERR
QUOTA_EXCEEDED_ERR
TIMEOUT_ERR
DATA_CLONE_ERR
The HTML namespace is: http://www.w3.org/1999/xhtml
The MathML namespace is: http://www.w3.org/1998/Math/MathML
The SVG namespace is: http://www.w3.org/2000/svg
The XLink namespace is: http://www.w3.org/1999/xlink
The XML namespace is: http://www.w3.org/XML/1998/namespace
The XMLNS namespace is: http://www.w3.org/2000/xmlns/
Data mining tools and other user agents that perform operations on content without running scripts, evaluating CSS or XPath expressions, or otherwise exposing the resulting DOM to arbitrary content, may "support namespaces" by just asserting that their DOM node analogues are in certain namespaces, without actually exposing the above strings.
In the HTML syntax, namespace prefixes and namespace declarations do not have the same effect as in XML. For instance, the colon has no special meaning in HTML element names.
Every XML and HTML document in an HTML UA is represented by a
Document
object. [DOMCORE]
The document's address is an absolute URL
that is set when the Document
is created. The
document's current address is an absolute URL
that can change during the lifetime of the Document
,
for example when the user navigates to
a fragment identifier on the
page or when the pushState()
method is called
with a new URL.
Interactive user agents typically expose the document's current address in their user interface.
When a Document
is created by a script using the createDocument()
or createHTMLDocument()
APIs, the document's address is the same as the
document's address of the script's document.
Document
objects are assumed to be XML
documents unless they are flagged as being HTML
documents when they are created. Whether a document is an
HTML document or an XML document affects the behavior of
certain APIs and the case-sensitivity of some selectors.
Each Document
object has a reload override
flag that is originally unset. The flag is set by the document.open()
and document.write()
methods in certain
situations. When the flag is set, the Document
also has
a reload override buffer which is a Unicode string that
is used as the source of the document when it is reloaded.
When the user agent is to perform an overridden reload, it must act as follows:
Let source be the value of the browsing context's active document's reload override buffer.
Navigate the
browsing context to a resource whose source is source. When the navigate algorithm
creates a Document
object for this purpose, set that
Document
's reload override flag and set
its reload override buffer to source.
All Document
objects (in user agents implementing
this specification) also implement
the HTMLDocument
interface, available using
binding-specific methods. (This is the case whether or not the
document in question is an HTML
document or indeed whether it contains any HTML
elements at all.) Document
objects also implement the document-level interface
of any other namespaces that the UA supports.
For example, if an HTML implementation also
supports SVG, then the Document
object implements both
HTMLDocument
and SVGDocument
.
Because the HTMLDocument
interface is
now obtained using binding-specific casting methods instead of
simply being the primary interface of the document object, it is no
longer defined as inheriting from Document
.
[OverrideBuiltins] interface HTMLDocument { // resource metadata management [PutForwards=href] readonly attribute Location location; readonly attribute DOMString URL; attribute DOMString domain; readonly attribute DOMString referrer; attribute DOMString cookie; readonly attribute DOMString lastModified; readonly attribute DOMString compatMode; attribute DOMString charset; readonly attribute DOMString characterSet; readonly attribute DOMString defaultCharset; readonly attribute DOMString readyState; // DOM tree accessors getter any (in DOMString name); attribute DOMString title; attribute DOMString dir; attribute HTMLElement body; readonly attribute HTMLHeadElement head; readonly attribute HTMLCollection images; readonly attribute HTMLCollection embeds; readonly attribute HTMLCollection plugins; readonly attribute HTMLCollection links; readonly attribute HTMLCollection forms; readonly attribute HTMLCollection scripts; NodeList getElementsByName(in DOMString elementName); NodeList getElementsByClassName(in DOMString classNames); // dynamic markup insertion attribute DOMString innerHTML; HTMLDocument open(in optional DOMString type, in optional DOMString replace); WindowProxy open(in DOMString url, in DOMString name, in DOMString features, in optional boolean replace); void close(); void write(in DOMString... text); void writeln(in DOMString... text); // user interaction readonly attribute WindowProxy defaultView; readonly attribute Element activeElement; boolean hasFocus(); attribute DOMString designMode; boolean execCommand(in DOMString commandId); boolean execCommand(in DOMString commandId, in boolean showUI); boolean execCommand(in DOMString commandId, in boolean showUI, in DOMString value); boolean queryCommandEnabled(in DOMString commandId); boolean queryCommandIndeterm(in DOMString commandId); boolean queryCommandState(in DOMString commandId); boolean queryCommandSupported(in DOMString commandId); DOMString queryCommandValue(in DOMString commandId); readonly attribute HTMLCollection commands; // event handler IDL attributes attribute Function onabort; attribute Function onblur; attribute Function oncanplay; attribute Function oncanplaythrough; attribute Function onchange; attribute Function onclick; attribute Function oncontextmenu; attribute Function oncuechange; attribute Function ondblclick; attribute Function ondrag; attribute Function ondragend; attribute Function ondragenter; attribute Function ondragleave; attribute Function ondragover; attribute Function ondragstart; attribute Function ondrop; attribute Function ondurationchange; attribute Function onemptied; attribute Function onended; attribute Function onerror; attribute Function onfocus; attribute Function oninput; attribute Function oninvalid; attribute Function onkeydown; attribute Function onkeypress; attribute Function onkeyup; attribute Function onload; attribute Function onloadeddata; attribute Function onloadedmetadata; attribute Function onloadstart; attribute Function onmousedown; attribute Function onmousemove; attribute Function onmouseout; attribute Function onmouseover; attribute Function onmouseup; attribute Function onmousewheel; attribute Function onpause; attribute Function onplay; attribute Function onplaying; attribute Function onprogress; attribute Function onratechange; attribute Function onreadystatechange; attribute Function onreset; attribute Function onscroll; attribute Function onseeked; attribute Function onseeking; attribute Function onselect; attribute Function onshow; attribute Function onstalled; attribute Function onsubmit; attribute Function onsuspend; attribute Function ontimeupdate; attribute Function onvolumechange; attribute Function onwaiting; }; Document implements HTMLDocument;
Since the HTMLDocument
interface holds methods and
attributes related to a number of disparate features, the members of
this interface are described in various different sections.
User agents raise a
SECURITY_ERR
exception whenever any of the members of
an HTMLDocument
object are accessed by scripts whose
effective script origin is not the same as the Document
's effective
script origin.
URL
Returns the document's address.
referrer
Returns the
address of the Document
from which the user
navigated to this one, unless it was blocked or there was no such
document, in which case it returns the empty string.
The noreferrer
link
type can be used to block the referrer.
In the case of HTTP, the referrer
IDL attribute will
match the Referer
(sic) header
that was sent when fetching the current
page.
Typically user agents are configured to not report
referrers in the case where the referrer uses an encrypted protocol
and the current page does not (e.g. when navigating from an https:
page to an http:
page).
cookie
[ = value ]Returns the HTTP cookies that apply to the
Document
. If there are no cookies or cookies can't be
applied to this resource, the empty string will be returned.
Can be set, to add a new cookie to the element's set of HTTP cookies.
If the contents are sandboxed into a unique origin (in an
iframe
with the sandbox
attribute) or the
resource was labeled as text/html-sandboxed
, a
SECURITY_ERR
exception will be thrown on getting and
setting.
lastModified
Returns the date of the last modification to the document, as
reported by the server, in the form "MM/DD/YYYY hh:mm:ss
", in the user's local
time zone.
If the last modification date is not known, the current time is returned instead.
compatMode
In a conforming document, returns the string "CSS1Compat
". (In quirks mode
documents, returns the string "BackCompat
",
but a conforming document can never trigger quirks
mode.)
charset
[ = value ]Returns the document's character encoding.
Can be set, to dynamically change the document's character encoding.
New values that are not IANA-registered aliases supported by the user agent are ignored.
characterSet
Returns the document's character encoding.
defaultCharset
Returns what might be the user agent's default character encoding. (The user agent might return another character encoding altogether, e.g. to protect the user's privacy, or if the user agent doesn't use a single default encoding.)
readyState
Returns "loading" while the Document
is loading, "interactive" once it is finished parsing but still loading sub-resources, and "complete" once it has loaded.
The readystatechange
event fires on the Document
object when this value changes.
The html
element of a document is the
document's root element, if there is one and it's an
html
element, or null otherwise.
head
Returns the head
element.
The head
element of a document is the
first head
element that is a child of the
html
element, if there is one, or null
otherwise.
title
[ = value ]Returns the document's title, as given by the
title
element.
Can be set, to update the document's title. If there is no
head
element,
the new value is ignored.
In SVG documents, the SVGDocument
interface's
title
attribute takes
precedence.
The title
element of a document is the
first title
element in the document (in tree order), if
there is one, or null otherwise.
body
[ = value ]Returns the body element.
Can be set, to replace the body element.
If the new value is not a body
or frameset
element, this will throw a HIERARCHY_REQUEST_ERR
exception.
The body element of a document is the first child of
the html
element that is either a
body
element or a frameset
element. If
there is no such element, it is null.
images
Returns an HTMLCollection
of the img
elements in the Document
.
embeds
plugins
Return an HTMLCollection
of the embed
elements in the Document
.
links
Returns an HTMLCollection
of the a
and area
elements in the Document
that have href
attributes.
forms
Return an HTMLCollection
of the form
elements in the Document
.
scripts
Return an HTMLCollection
of the script
elements in the Document
.
getElementsByName
(name)Returns a NodeList
of elements in the
Document
that have a name
attribute with the value name.
getElementsByClassName(classes)
getElementsByClassName(classes)
Returns a NodeList
of the elements in the object
on which the method was invoked (a Document
or an
Element
) that have all the classes given by classes.
The classes argument is interpreted as a space-separated list of classes.
HTML, SVG, and MathML elements define which classes they are in
by having an attribute with no namespace with the name class
containing a space-separated list of classes
to which the element belongs. Other specifications may also allow
elements in their namespaces to be labeled as being in specific
classes.
Given the following XHTML fragment:
<div id="example"> <p id="p1" class="aaa bbb"/> <p id="p2" class="aaa ccc"/> <p id="p3" class="bbb ccc"/> </div>
A call to document.getElementById('example').getElementsByClassName('aaa')
would return a NodeList
with the two paragraphs p1
and p2
in it.
A call to getElementsByClassName('ccc bbb')
would only
return one node, however, namely p3
. A call
to document.getElementById('example').getElementsByClassName('bbb ccc ')
would return the same thing.
A call to getElementsByClassName('aaa,bbb')
would return no
nodes; none of the elements above are in the "aaa,bbb" class.
The dir
attribute on the HTMLDocument
interface is defined
along with the dir
content
attribute.
XML documents can be created from script using the
createDocument()
method on the DOMImplementation
interface.
HTML documents can be created using the createHTMLDocument()
method:
[Supplemental, NoInterfaceObject] interface DOMHTMLImplementation { Document createHTMLDocument(in DOMString title); }; DOMImplementation implements DOMHTMLImplementation;
implementation
. createHTMLDocument
( title )Returns a new Document
, with a basic DOM already
constructed with an appropriate title
element.
Elements, attributes, and attribute values in HTML are defined
(by this specification) to have certain meanings (semantics). For
example, the ol
element represents an ordered list, and
the lang
attribute represents the
language of the content.
Authors must not use elements, attributes, or attribute values for purposes other than their appropriate intended semantic purpose. Authors must not use elements, attributes, or attribute values that are not permitted by this specification or other applicable specifications.
For example, the following document is non-conforming, despite being syntactically correct:
<!DOCTYPE HTML> <html lang="en-GB"> <head> <title> Demonstration </title> </head> <body> <table> <tr> <td> My favourite animal is the cat. </td> </tr> <tr> <td> —<a href="http://example.org/~ernest/"><cite>Ernest</cite></a>, in an essay from 1992 </td> </tr> </table> </body> </html>
...because the data placed in the cells is clearly not tabular
data (and the cite
element mis-used). A corrected
version of this document might be:
<!DOCTYPE HTML> <html lang="en-GB"> <head> <title> Demonstration </title> </head> <body> <blockquote> <p> My favourite animal is the cat. </p> </blockquote> <p> —<a href="http://example.org/~ernest/">Ernest</a>, in an essay from 1992 </p> </body> </html>
This next document fragment, intended to represent the heading of a corporate site, is similarly non-conforming because the second line is not intended to be a heading of a subsection, but merely a subheading or subtitle (a subordinate heading for the same section).
<body> <h1>ABC Company</h1> <h2>Leading the way in widget design since 1432</h2> ...
The hgroup
element is intended for these kinds of
situations:
<body> <hgroup> <h1>ABC Company</h1> <h2>Leading the way in widget design since 1432</h2> </hgroup> ...
In the next example, there is a non-conforming attribute value ("carpet") and a non-conforming attribute ("texture"), which is not permitted by this specification:
<label>Carpet: <input type="carpet" name="c" texture="deep pile"></label>
Here would be an alternative and correct way to mark this up:
<label>Carpet: <input type="text" class="carpet" name="c" data-texture="deep pile"></label>
Through scripting and using other mechanisms, the values of attributes, text, and indeed the entire structure of the document may change dynamically while a user agent is processing it. The semantics of a document at an instant in time are those represented by the state of the document at that instant in time, and the semantics of a document can therefore change over time. User agents update their presentation of the document as this occurs.
HTML has a progress
element that
describes a progress bar. If its "value" attribute is dynamically
updated by a script, the UA would update the rendering to show the
progress changing.
The nodes representing HTML elements in the DOM implement, and expose to scripts, the interfaces listed for them in the relevant sections of this specification. This includes HTML elements in XML documents, even when those documents are in another context (e.g. inside an XSLT transform).
Elements in the DOM represent things; that is, they have intrinsic meaning, also known as semantics.
For example, an ol
element
represents an ordered list.
The basic interface, from which all the HTML
elements' interfaces inherit, is the HTMLElement
interface.
interface HTMLElement : Element { // DOM tree accessors NodeList getElementsByClassName(in DOMString classNames); // dynamic markup insertion attribute DOMString innerHTML; attribute DOMString outerHTML; void insertAdjacentHTML(in DOMString position, in DOMString text); // metadata attributes attribute DOMString id; attribute DOMString title; attribute DOMString lang; attribute DOMString dir; attribute DOMString className; readonly attribute DOMTokenList classList; readonly attribute DOMStringMap dataset; // user interaction attribute boolean hidden; void click(); attribute long tabIndex; void focus(); void blur(); attribute DOMString accessKey; readonly attribute DOMString accessKeyLabel; attribute boolean draggable; [PutForwards=value] attribute DOMSettableTokenList dropzone; attribute DOMString contentEditable; readonly attribute boolean isContentEditable; attribute HTMLMenuElement contextMenu; attribute boolean spellcheck; // command API readonly attribute DOMString commandType; readonly attribute DOMString label; readonly attribute DOMString icon; readonly attribute boolean disabled; readonly attribute boolean checked; // styling readonly attribute CSSStyleDeclaration style; // event handler IDL attributes attribute Function onabort; attribute Function onblur; attribute Function oncanplay; attribute Function oncanplaythrough; attribute Function onchange; attribute Function onclick; attribute Function oncontextmenu; attribute Function oncuechange; attribute Function ondblclick; attribute Function ondrag; attribute Function ondragend; attribute Function ondragenter; attribute Function ondragleave; attribute Function ondragover; attribute Function ondragstart; attribute Function ondrop; attribute Function ondurationchange; attribute Function onemptied; attribute Function onended; attribute Function onerror; attribute Function onfocus; attribute Function oninput; attribute Function oninvalid; attribute Function onkeydown; attribute Function onkeypress; attribute Function onkeyup; attribute Function onload; attribute Function onloadeddata; attribute Function onloadedmetadata; attribute Function onloadstart; attribute Function onmousedown; attribute Function onmousemove; attribute Function onmouseout; attribute Function onmouseover; attribute Function onmouseup; attribute Function onmousewheel; attribute Function onpause; attribute Function onplay; attribute Function onplaying; attribute Function onprogress; attribute Function onratechange; attribute Function onreadystatechange; attribute Function onreset; attribute Function onscroll; attribute Function onseeked; attribute Function onseeking; attribute Function onselect; attribute Function onshow; attribute Function onstalled; attribute Function onsubmit; attribute Function onsuspend; attribute Function ontimeupdate; attribute Function onvolumechange; attribute Function onwaiting; }; interface HTMLUnknownElement : HTMLElement { };
The HTMLElement
interface holds methods and
attributes related to a number of disparate features, and the
members of this interface are therefore described in various
different sections of this specification.
The following attributes are common to and may be specified on all HTML elements:
accesskey
class
contenteditable
contextmenu
dir
draggable
dropzone
id
lang
spellcheck
style
tabindex
title
The following event handler content attributes may be specified on any HTML element:
onabort
onblur
*oncanplay
oncanplaythrough
onchange
onclick
oncontextmenu
oncuechange
ondblclick
ondrag
ondragend
ondragenter
ondragleave
ondragover
ondragstart
ondrop
ondurationchange
onemptied
onended
onerror
*onfocus
*oninput
oninvalid
onkeydown
onkeypress
onkeyup
onload
*onloadeddata
onloadedmetadata
onloadstart
onmousedown
onmousemove
onmouseout
onmouseover
onmouseup
onmousewheel
onpause
onplay
onplaying
onprogress
onratechange
onreadystatechange
onreset
onscroll
*onseeked
onseeking
onselect
onshow
onstalled
onsubmit
onsuspend
ontimeupdate
onvolumechange
onwaiting
The attributes marked with an asterisk have a
different meaning when specified on body
elements as
those elements expose event handlers of the
Window
object with the same names.
While these attributes apply to all elements, they
are not useful on all elements. For example, only media elements will ever receive a volumechange
event fired by
the user agent.
Custom data attributes
(e.g. data-foldername
or data-msgid
) can be specified on any HTML element, to store custom data
specific to the page.
In HTML documents, elements in the HTML
namespace may have an xmlns
attribute
specified, if, and only if, it has the exact value
"http://www.w3.org/1999/xhtml
". This does not apply to
XML documents.
In HTML, the xmlns
attribute
has absolutely no effect. It is basically a talisman. It is allowed
merely to make migration to and from XHTML mildly easier. When
parsed by an HTML parser, the attribute ends up in no
namespace, not the "http://www.w3.org/2000/xmlns/
"
namespace like namespace declaration attributes in XML do.
In XML, an xmlns
attribute is
part of the namespace declaration mechanism, and an element cannot
actually have an xmlns
attribute in no
namespace specified.
The XML specification also allows the use of the xml:space
attribute in the XML
namespace on any element in an XML document. This attribute has no effect on
HTML elements, as the default behavior in HTML is to
preserve whitespace. [XML]
There is no way to serialize the xml:space
attribute on HTML
elements in the text/html
syntax.
To enable assistive technology products to expose a more
fine-grained interface than is otherwise possible with HTML elements
and attributes, a set of annotations for assistive technology
products can be specified (the ARIA role
and aria-*
attributes).
id
attributeThe id
attribute specifies its
element's unique identifier (ID). The
value must be unique amongst all the IDs in the element's home
subtree and must contain at least one character. The value
must not contain any space
characters.
An element's unique identifier can be used for a variety of purposes, most notably as a way to link to specific parts of a document using fragment identifiers, as a way to target an element when scripting, and as a way to style a specific element from CSS.
title
attributeThe title
attribute
represents advisory information for the element, such
as would be appropriate for a tooltip. On a link, this could be the
title or a description of the target resource; on an image, it could
be the image credit or a description of the image; on a paragraph,
it could be a footnote or commentary on the text; on a citation, it
could be further information about the source; and so forth. The
value is text.
If this attribute is omitted from an element, then it implies
that the title
attribute of the
nearest ancestor HTML element
with a title
attribute set is also
relevant to this element. Setting the attribute overrides this,
explicitly stating that the advisory information of any ancestors is
not relevant to this element. Setting the attribute to the empty
string indicates that the element has no advisory information.
If the title
attribute's value
contains U+000A LINE FEED (LF) characters, the content is split into
multiple lines. Each U+000A LINE FEED (LF) character represents a
line break.
Caution is advised with respect to the use of newlines in title
attributes.
For instance, the following snippet actually defines an abbreviation's expansion with a line break in it:
<p>My logs show that there was some interest in <abbr title="Hypertext Transport Protocol">HTTP</abbr> today.</p>
Some elements, such as link
, abbr
, and
input
, define additional semantics for the title
attribute beyond the semantics
described above.
lang
and xml:lang
attributesThe lang
attribute (in
no namespace) specifies the primary language for the element's
contents and for any of the element's attributes that contain
text. Its value must be a valid BCP 47 language tag, or the empty
string. Setting the attribute to the empty string indicates that the
primary language is unknown. [BCP47]
The lang
attribute in the XML namespace is defined in XML. [XML]
If these attributes are omitted from an element, then the language of this element is the same as the language of its parent element, if any.
The lang
attribute in no namespace
may be used on any HTML
element.
The lang
attribute in the XML namespace may be used on
HTML elements in XML documents, as well as
elements in other namespaces if the relevant specifications allow it
(in particular, MathML and SVG allow lang
attributes in the
XML namespace to be specified on their
elements). If both the lang
attribute
in no namespace and the lang
attribute in the XML
namespace are specified on the same element, they must
have exactly the same value when compared in an ASCII
case-insensitive manner.
Authors must not use the lang
attribute in the XML
namespace on HTML elements in HTML
documents. To ease migration to and from XHTML, authors may
specify an attribute in no namespace with no prefix and with the
literal localname "xml:lang
" on HTML
elements in HTML documents, but such attributes
must only be specified if a lang
attribute in no namespace is also specified, and both attributes
must have the same value when compared in an ASCII
case-insensitive manner.
The attribute in no namespace with no prefix and
with the literal localname "xml:lang
" has no
effect on language processing.
xml:base
attribute (XML only)The xml:base
attribute is
defined in XML Base. [XMLBASE]
The xml:base
attribute may be
used on elements of XML documents. Authors must not
use the xml:base
attribute in
HTML documents.
dir
attributeThe dir
attribute specifies the
element's text directionality. The attribute is an enumerated
attribute with the following keywords and states:
ltr
keyword, which maps to the ltr stateIndicates that the contents of the element are explicitly directionally embedded left-to-right text.
rtl
keyword, which maps to the rtl stateIndicates that the contents of the element are explicitly directionally embedded right-to-left text.
auto
keyword, which maps to the auto stateIndicates that the contents of the element are explicitly embedded text, but that the direction is to be determined programmatically using the contents of the element (as described below).
The heuristic used by this state is very crude (it just looks at the first character with a strong directionality, in a manner analogous to the Paragraph Level determination in the bidirectional algorithm). Authors are urged to only use this value as a last resort when the direction of the text is truly unknown and no better server-side heuristic can be applied.
For textarea
and pre
elements, the heuristic is applied on a per-paragraph level.
The attribute has no invalid value default and no missing value default.
The directionality of an element is either 'ltr' or 'rtl', and is determined as per the first appropriate set of steps from the following list:
dir
attribute is
in the ltr stateThe directionality of the element is 'ltr'.
dir
attribute is
in the rtl stateThe directionality of the element is 'rtl'.
dir
attribute is
in the auto statebdi
element and the dir
attribute is not in a defined state
(i.e. it is not present or has an invalid value)Find the first character in tree order that matches the following criteria:
The character is from a text node that is a descendant of the element whose directionality is being determined.
The character is of bidirectional character type L, AL, or R. [BIDI]
The character is not in a text node that has an ancestor element that is a descendant of the element whose directionality is being determined and that is either:
If such a character is found and it is of bidirectional character type AL or R, the directionality of the element is 'rtl'.
Otherwise, the directionality of the element is 'ltr'.
dir
attribute is not in a defined state
(i.e. it is not present or has an invalid value)The directionality of the element is 'ltr'.
dir
attribute is not in a defined state
(i.e. it is not present or has an invalid value)The directionality of the element is the same as the element's parent element's directionality.
The effect of this attribute is primarily on the presentation layer. For example, the rendering section in this specification defines a mapping from this attribute to the CSS 'direction' and 'unicode-bidi' properties, and CSS defines rendering in terms of those properties.
dir
[ = value ]Returns the html
element's dir
attribute's value, if any.
Can be set, to either "ltr
", "rtl
", or "auto
" to replace the html
element's dir
attribute's value.
If there is no html
element, returns the empty string and ignores new values.
Authors are strongly encouraged to use the dir
attribute to indicate text direction
rather than using CSS, since that way their documents will continue
to render correctly even in the absence of CSS (e.g. as interpreted
by search engines).
This markup fragment is of an IM conversation.
<p dir=auto class="u1"><b><bdi>Student</bdi>:</b> How do you write "What's your name?" in Arabic?</p> <p dir=auto class="u2"><b><bdi>Teacher</bdi>:</b> ما اسمك؟</p> <p dir=auto class="u1"><b><bdi>Student</bdi>:</b> Thanks.</p> <p dir=auto class="u2"><b><bdi>Teacher</bdi>:</b> That's written "شكرًا".</p> <p dir=auto class="u2"><b><bdi>Teacher</bdi>:</b> Do you know how to write "Please"?</p> <p dir=auto class="u1"><b><bdi>Student</bdi>:</b> "من فضلك", right?</p>
Given a suitable style sheet and the default alignment styles
for the p
element, namely to align the text to the
start edge of the paragraph, the resulting rendering could
be as follows:
As noted earlier, the auto
value is not a panacea. The final paragraph in this example is
misinterpreted as being right-to-left text, since it begins with an
Arabic character, which causes the "right?" to be to the left of
the Arabic text.
class
attributeEvery HTML element may have a
class
attribute specified.
The attribute, if specified, must have a value that is a set of space-separated tokens representing the various classes that the element belongs to.
Assigning classes to an element affects class
matching in selectors in CSS, the getElementsByClassName()
method in the DOM, and other such features.
There are no additional restrictions on the tokens authors can
use in the class
attribute, but
authors are encouraged to use values that describe the nature of the
content, rather than values that describe the desired presentation
of the content.
style
attributeAll HTML elements may have the style
content attribute set. This is a
CSS styling attribute as defined by the CSS Styling
Attribute Syntax specification. [CSSATTR]
Documents that use style
attributes on any of their elements must still be comprehensible and
usable if those attributes were removed.
In particular, using the style
attribute to hide and show content,
or to convey meaning that is otherwise not included in the document,
is non-conforming. (To hide and show content, use the attribute.)
style
Returns a CSSStyleDeclaration
object for the element's style
attribute.
In the following example, the words that refer to colors are
marked up using the span
element and the style
attribute to make those words show
up in the relevant colors in visual media.
<p>My sweat suit is <span style="color: green; background: transparent">green</span> and my eyes are <span style="color: blue; background: transparent">blue</span>.</p>
data-*
attributesA custom data attribute is an attribute in no
namespace whose name starts with the string "data-
", has at least one
character after the hyphen, is XML-compatible, and
contains no characters in the range U+0041 to U+005A (LATIN CAPITAL
LETTER A to LATIN CAPITAL LETTER Z).
All attributes on HTML elements in HTML documents get ASCII-lowercased automatically, so the restriction on ASCII uppercase letters doesn't affect such documents.
Custom data attributes are intended to store custom data private to the page or application, for which there are no more appropriate attributes or elements.
These attributes are not intended for use by software that is independent of the site that uses the attributes.
For instance, a site about music could annotate list items representing tracks in an album with custom data attributes containing the length of each track. This information could then be used by the site itself to allow the user to sort the list by track length, or to filter the list for tracks of certain lengths.
<ol> <li data-length="2m11s">Beyond The Sea</li> ... </ol>
It would be inappropriate, however, for the user to use generic software not associated with that music site to search for tracks of a certain length by looking at this data.
This is because these attributes are intended for use by the site's own scripts, and are not a generic extension mechanism for publicly-usable metadata.
Every HTML element may have any number of custom data attributes specified, with any value.
dataset
Returns a DOMStringMap
object for the element's data-*
attributes.
Hyphenated names become camel-cased. For example, data-foo-bar=""
becomes element.dataset.fooBar
.
If a Web page wanted an element to represent a space ship,
e.g. as part of a game, it would have to use the class
attribute along with data-*
attributes:
<div class="spaceship" data-ship-id="92432" data-weapons="laser 2" data-shields="50%" data-x="30" data-y="10" data-z="90"> <button class="fire" onclick="spaceships[this.parentNode.dataset.shipId].fire()"> Fire </button> </div>
Notice how the hyphenated attribute name becomes camel-cased in the API.
Authors should carefully design such extensions so that when the attributes are ignored and any associated CSS dropped, the page is still usable.
JavaScript libraries may use the custom data attributes, as they are considered to be part of the page on which they are used. Authors of libraries that are reused by many authors are encouraged to include their name in the attribute names, to reduce the risk of clashes. Where it makes sense, library authors are also encouraged to make the exact name used in the attribute names customizable, so that libraries whose authors unknowingly picked the same name can be used on the same page, and so that multiple versions of a particular library can be used on the same page even when those versions are not mutually compatible.
For example, a library called "DoQuery" could use attribute
names like data-doquery-range
, and a library
called "jJo" could use attributes names like data-jjo-range
. The jJo library could also provide
an API to set which prefix to use (e.g. J.setDataPrefix('j2')
, making the attributes have
names like data-j2-range
).
Each element in this specification has a definition that includes the following information:
A list of categories to which the element belongs. These are used when defining the content models for each element.
A non-normative description of where the element can be used. This information is redundant with the content models of elements that allow this one as a child, and is provided only as a convenience.
For simplicity, only the most specific expectations are listed. For example, an element that is both flow content and phrasing content can be used anywhere that either flow content or phrasing content is expected, but since anywhere that flow content is expected, phrasing content is also expected (since all phrasing content is flow content), only "where phrasing content is expected" will be listed.
A normative description of what content must be included as children and descendants of the element.
A normative list of attributes that may be specified on the element (except where otherwise disallowed).
A normative definition of a DOM interface that such elements must implement.
This is then followed by a description of what the element represents, along with any additional normative conformance criteria that may apply to authors. Examples are sometimes also included.
Except where otherwise specified, attributes on HTML elements may have any string value, including the empty string. Except where explicitly stated, there is no restriction on what text can be specified in such attributes.
Each element defined in this specification has a content model: a description of the element's expected contents. An HTML element must have contents that match the requirements described in the element's content model.
As noted in the conformance and terminology
sections, for the purposes of determining if an element matches its
content model or not, CDATASection
nodes in the DOM are treated as
equivalent to Text
nodes, and entity reference nodes are treated as if
they were expanded in place.
The space characters are always allowed between elements. User agents represent these characters between elements in the source markup as text nodes in the DOM. Empty text nodes and text nodes consisting of just sequences of those characters are considered inter-element whitespace.
Inter-element whitespace, comment nodes, and processing instruction nodes must be ignored when establishing whether an element's contents match the element's content model or not, and must be ignored when following algorithms that define document and element semantics.
Thus, an element A is said to be preceded or followed by a second element B if A and B have the same parent node and there are no other element nodes or text nodes (other than inter-element whitespace) between them. Similarly, a node is the only child of an element if that element contains no other nodes other than inter-element whitespace, comment nodes, and processing instruction nodes.
Authors must not use HTML elements anywhere except where they are explicitly allowed, as defined for each element, or as explicitly required by other specifications. For XML compound documents, these contexts could be inside elements from other namespaces, if those elements are defined as providing the relevant contexts.
For example, the Atom specification defines a content
element. When its type
attribute has the value xhtml
, the Atom specification requires that it
contain a single HTML div
element. Thus, a
div
element is allowed in that context, even though
this is not explicitly normatively stated by this specification. [ATOM]
In addition, HTML elements may be orphan nodes (i.e. without a parent node).
For example, creating a td
element and storing it
in a global variable in a script is conforming, even though
td
elements are otherwise only supposed to be used
inside tr
elements.
var data = { name: "Banana", cell: document.createElement('td'), };
Each element in HTML falls into zero or more categories that group elements with similar characteristics together. The following broad categories are used in this specification:
Some elements also fall into other categories, which are defined in other parts of this specification.
These categories are related as follows:
In addition, certain elements are categorized as form-associated elements and further subcategorized to define their role in various form-related processing models.
Some elements have unique requirements and do not fit into any particular category.
Metadata content is content that sets up the presentation or behavior of the rest of the content, or that sets up the relationship of the document with other documents, or that conveys other "out of band" information.
Elements from other namespaces whose semantics are primarily metadata-related (e.g. RDF) are also metadata content.
Thus, in the XML serialization, one can use RDF, like this:
<html xmlns="http://www.w3.org/1999/xhtml" xmlns:r="http://www.w3.org/1999/02/22-rdf-syntax-ns#"> <head> <title>Hedral's Home Page</title> <r:RDF> <Person xmlns="http://www.w3.org/2000/10/swap/pim/contact#" r:about="http://hedral.example.com/#"> <fullName>Cat Hedral</fullName> <mailbox r:resource="mailto:hedral@damowmow.com"/> <personalTitle>Sir</personalTitle> </Person> </r:RDF> </head> <body> <h1>My home page</h1> <p>I like playing with string, I guess. Sister says squirrels are fun too so sometimes I follow her to play with them.</p> </body> </html>
This isn't possible in the HTML serialization, however.
Most elements that are used in the body of documents and applications are categorized as flow content.
a
abbr
address
area
(if it is a descendant of a map
element)article
aside
audio
b
bdi
bdo
blockquote
br
button
canvas
cite
code
command
datalist
del
details
dfn
div
dl
em
embed
fieldset
figure
footer
form
h1
h2
h3
h4
h5
h6
header
hgroup
hr
i
iframe
input
ins
kbd
keygen
label
map
mark
math
menu
meter
nav
noscript
object
ol
output
p
pre
progress
q
ruby
s
samp
script
section
select
small
span
strong
style
(if the scoped
attribute is present)sub
sup
svg
table
textarea
time
ul
var
video
wbr
As a general rule, elements whose content model allows any
flow content should have either at least one descendant
text node that is not inter-element
whitespace, or at least one descendant element node that is
embedded content. For the purposes of this requirement,
del
elements and their descendants must not be counted
as contributing to the ancestors of the del
element.
This requirement is not a hard requirement, however, as there are many cases where an element can be empty legitimately, for example when it is used as a placeholder which will later be filled in by a script, or when the element is part of a template and would on most pages be filled in but on some pages is not relevant.
Sectioning content is content that defines the scope of headings and footers.
Each sectioning content element potentially has a heading and an outline. See the section on headings and sections for further details.
There are also certain elements that are sectioning roots. These are distinct from sectioning content, but they can also have an outline.
Heading content defines the header of a section (whether explicitly marked up using sectioning content elements, or implied by the heading content itself).
Phrasing content is the text of the document, as well as elements that mark up that text at the intra-paragraph level. Runs of phrasing content form paragraphs.
a
(if it contains only phrasing content)abbr
area
(if it is a descendant of a map
element)audio
b
bdi
bdo
br
button
canvas
cite
code
command
datalist
del
(if it contains only phrasing content)dfn
em
embed
i
iframe
input
ins
(if it contains only phrasing content)kbd
keygen
label
map
(if it contains only phrasing content)mark
math
meter
noscript
object
output
progress
q
ruby
s
samp
script
select
small
span
strong
sub
sup
svg
textarea
time
var
video
wbr
As a general rule, elements whose content model allows any
phrasing content should have either at least one
descendant text node that is not inter-element
whitespace, or at least one descendant element node that is
embedded content. For the purposes of this requirement,
nodes that are descendants of del
elements must not be
counted as contributing to the ancestors of the del
element.
Most elements that are categorized as phrasing content can only contain elements that are themselves categorized as phrasing content, not any flow content.
Text, in the context of content models, means text nodes. Text is sometimes used as a content model on its own, but is also phrasing content, and can be inter-element whitespace (if the text nodes are empty or contain just space characters).
ISSUE-80 (title-alternative) blocks progress to Last Call
Embedded content is content that imports another resource into the document, or content from another vocabulary that is inserted into the document.
Elements that are from namespaces other than the HTML namespace and that convey content but not metadata, are embedded content for the purposes of the content models defined in this specification. (For example, MathML, or SVG.)
Some embedded content elements can have fallback content: content that is to be used when the external resource cannot be used (e.g. because it is of an unsupported format). The element definitions state what the fallback is, if any.
Interactive content is content that is specifically intended for user interaction.
a
audio
(if the controls
attribute is present)button
details
embed
iframe
(if the usemap
attribute is present)input
(if the type
attribute is not in the state)keygen
label
menu
(if the type
attribute is in the toolbar state)object
(if the usemap
attribute is present)select
textarea
video
(if the controls
attribute is present)Certain elements in HTML have an activation
behavior, which means that the user can activate them. This
triggers a sequence of events dependent on the activation mechanism,
and normally culminating in a click
event.
Some elements are described as transparent; they have "transparent" in the description of their content model. The content model of a transparent element is derived from the content model of its parent element: the elements required in the part of the content model that is "transparent" are the same elements as required in the part of the content model of the parent of the transparent element in which the transparent element finds itself.
For instance, an ins
element inside a
ruby
element cannot contain an rt
element, because the part of the ruby
element's
content model that allows ins
elements is the part
that allows phrasing content, and the rt
element is not phrasing content.
In some cases, where transparent elements are nested in each other, the process has to be applied iteratively.
Consider the following markup fragment:
<p><object><param><ins><map><a href="/">Apples</a></map></ins></object></p>
To check whether "Apples" is allowed inside the a
element, the content models are examined. The a
element's content model is transparent, as is the map
element's, as is the ins
element's, as is the part of
the object
element's in which the ins
element is found. The object
element is found in the
p
element, whose content model is phrasing
content. Thus, "Apples" is allowed, as text is phrasing
content.
When a transparent element has no parent, then the part of its content model that is "transparent" must instead be treated as accepting any flow content.
The term paragraph as defined in this
section is distinct from (though related to) the p
element defined later. The paragraph concept defined
here is used to describe how to interpret documents.
A paragraph is typically a run of phrasing content that forms a block of text with one or more sentences that discuss a particular topic, as in typography, but can also be used for more general thematic grouping. For instance, an address is also a paragraph, as is a part of a form, a byline, or a stanza in a poem.
In the following example, there are two paragraphs in a section. There is also a heading, which contains phrasing content that is not a paragraph. Note how the comments and inter-element whitespace do not form paragraphs.
<section> <h1>Example of paragraphs</h1> This is the <em>first</em> paragraph in this example. <p>This is the second.</p> <!-- This is not a paragraph. --> </section>
Paragraphs in flow content are defined relative to
what the document looks like without the a
,
ins
, del
, and map
elements
complicating matters, since those elements, with their hybrid
content models, can straddle paragraph boundaries, as shown in the
first two examples below.
Generally, having elements straddle paragraph boundaries is best avoided. Maintaining such markup can be difficult.
The following example takes the markup from the earlier example
and puts ins
and del
elements around some
of the markup to show that the text was changed (though in this
case, the changes admittedly don't make much sense). Notice how
this example has exactly the same paragraphs as the previous one,
despite the ins
and del
elements —
the ins
element straddles the heading and the first
paragraph, and the del
element straddles the boundary
between the two paragraphs.
<section> <ins><h1>Example of paragraphs</h1> This is the <em>first</em> paragraph in</ins> this example<del>. <p>This is the second.</p></del> <!-- This is not a paragraph. --> </section>
A paragraph is also formed explicitly by
p
elements.
The p
element can be used to wrap
individual paragraphs when there would otherwise not be any content
other than phrasing content to separate the paragraphs from each
other.
In the following example, the link spans half of the first paragraph, all of the heading separating the two paragraphs, and half of the second paragraph. It straddles the paragraphs and the heading.
<aside> Welcome! <a href="about.html"> This is home of... <h1>The Falcons!</h1> The Lockheed Martin multirole jet fighter aircraft! </a> This page discusses the F-16 Fighting Falcon's innermost secrets. </aside>
Here is another way of marking this up, this time showing the paragraphs explicitly, and splitting the one link element into three:
<aside> <p>Welcome! <a href="about.html">This is home of...</a></p> <h1><a href="about.html">The Falcons!</a></h1> <p><a href="about.html">The Lockheed Martin multirole jet fighter aircraft!</a> This page discusses the F-16 Fighting Falcon's innermost secrets.</p> </aside>
It is possible for paragraphs to overlap when using certain elements that define fallback content. For example, in the following section:
<section> <h1>My Cats</h1> You can play with my cat simulator. <object data="cats.sim"> To see the cat simulator, use one of the following links: <ul> <li><a href="cats.sim">Download simulator file</a> <li><a href="http://sims.example.com/watch?v=LYds5xY4INU">Use online simulator</a> </ul> Alternatively, upgrade to the Mellblom Browser. </object> I'm quite proud of it. </section>
There are five paragraphs:
object
element.The first paragraph is overlapped by the other four. A user agent that supports the "cats.sim" resource will only show the first one, but a user agent that shows the fallback will confusingly show the first sentence of the first paragraph as if it was in the same paragraph as the second one, and will show the last paragraph as if it was at the start of the second sentence of the first paragraph.
To avoid this confusion, explicit p
elements can be
used.
Text content in HTML elements with child text nodes, and text in attributes of HTML elements that allow free-form text, may contain characters in the range U+202A to U+202E (the bidirectional-algorithm formatting characters). However, the use of these characters is restricted so that any embedding or overrides generated by these characters do not start and end with different parent elements, and so that all such embeddings and overrides are explicitly terminated by a U+202C POP DIRECTIONAL FORMATTING character. This helps reduce incidences of text being reused in a manner that has unforeseen effects on the bidirectional algorithm.
The aforementioned restrictions are defined by specifying that certain parts of documents form bidirectional-algorithm formatting character ranges, and then imposing a requirement on such ranges.
The string resulting from the concatenation of the data of all of an HTML element's text nodes, if any, is a bidirectional-algorithm formatting character range.
The value of a namespace-less attribute of an HTML element is a bidirectional-algorithm formatting character range.
Any strings that, as described above, are
bidirectional-algorithm formatting character ranges must
match the string
production in the following
ABNF, the character set for which is Unicode. [ABNF]
string = *( plaintext ( embedding / override ) ) plaintext embedding = ( lre / rle ) string pdf override = ( lro / rlo ) string pdf lre = %x202A ; U+202A LEFT-TO-RIGHT EMBEDDING rle = %x202B ; U+202B RIGHT-TO-LEFT EMBEDDING lro = %x202D ; U+202D LEFT-TO-RIGHT OVERRIDE rlo = %x202E ; U+202E RIGHT-TO-LEFT OVERRIDE pdf = %x202C ; U+202C POP DIRECTIONAL FORMATTING plaintext = *( %x0000-2029 / %x202F-10FFFF ) ; any string with no bidirectional-algorithm formatting characters
For convenience, where possible authors will likely
prefer to use the dir
attribute, the
bdo
element, and the bdi
element, rather
than maintaining the bidirectional-algorithm formatting characters
manually.
ISSUE-109 (aria-section-title) and ISSUE-129 (aria-mapping) block progress to Last Call
Authors may use the ARIA role
and aria-*
attributes on HTML
elements, in accordance with the requirements described in
the ARIA specifications, except where these conflict with the
strong native semantics described below. These
exceptions are intended to prevent authors from making assistive
technology products report nonsensical states that do not represent
the actual state of the document. [ARIA]
The following table defines the strong native
semantics that apply to HTML
elements. Each language feature (element or attribute) in a
cell in the first column implies the ARIA semantics (role, states,
and/or properties) given in the cell in the second column of the
same row. Authors must not set the ARIA role
and aria-*
attributes in a manner that
conflicts with the semantics described in the following table,
except that the presentation
role may
always be used.
Language feature | Strong native semantics |
---|---|
a element that creates a hyperlink
| link role
|
area element that creates a hyperlink
| link role
|
base element
| No role |
button element
| button role
|
datalist element
| listbox role, with the aria-multiselectable property set to "false"
|
details element
| aria-expanded state set to "true" if the element's open attribute is present, and set to "false" otherwise
|
h1 element that does not have an hgroup ancestor
| heading role, with the aria-level property set to the element's outline depth
|
h2 element that does not have an hgroup ancestor
| heading role, with the aria-level property set to the element's outline depth
|
h3 element that does not have an hgroup ancestor
| heading role, with the aria-level property set to the element's outline depth
|
h4 element that does not have an hgroup ancestor
| heading role, with the aria-level property set to the element's outline depth
|
h5 element that does not have an hgroup ancestor
| heading role, with the aria-level property set to the element's outline depth
|
h6 element that does not have an hgroup ancestor
| heading role, with the aria-level property set to the element's outline depth
|
head element
| No role |
hgroup element
| heading role, with the aria-level property set to the element's outline depth
|
hr element
| separator role
|
html element
| No role |
img element whose alt attribute's value is empty
| presentation role
|
input element with a type attribute in the Button state
| button role
|
input element with a type attribute in the Checkbox state
| aria-checked state set to "mixed" if the element's indeterminate IDL attribute is true, or "true" if the element's checkedness is true, or "false" otherwise
|
input element with a type attribute in the Color state
| No role |
input element with a type attribute in the Date state
| No role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Date and Time state
| No role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Local Date and Time state
| No role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the E-mail state with no suggestions source element
| textbox role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the File Upload state
| No role |
input element with a type attribute in the state
| No role |
input element with a type attribute in the Image Button state
| button role
|
input element with a type attribute in the Month state
| No role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Number state
| spinbutton role, with the aria-readonly state set to "true" if the element has a readonly attribute, the aria-valuemax property set to the element's maximum, the aria-valuemin property set to the element's minimum, and, if the result of applying the rules for parsing floating point number values to the element's value is a number, with the aria-valuenow property set to that number
|
input element with a type attribute in the Password state
| textbox role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Radio Button state
| aria-checked state set to "true" if the element's checkedness is true, or "false" otherwise
|
input element with a type attribute in the Range state
| slider role, with the aria-valuemax property set to the element's maximum, the aria-valuemin property set to the element's minimum, and the aria-valuenow property set to the result of applying the rules for parsing floating point number values to the element's value, if that results in a number, or the default value otherwise
|
input element with a type attribute in the Reset Button state
| button role
|
input element with a type attribute in the Search state with no suggestions source element
| textbox role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Submit Button state
| button role
|
input element with a type attribute in the Telephone state with no suggestions source element
| textbox role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Text state with no suggestions source element
| textbox role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Text, Search, Telephone, URL, or E-mail states with a suggestions source element
| combobox role, with the aria-owns property set to the same value as the list attribute, and the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Time state
| No role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the URL state with no suggestions source element
| textbox role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element with a type attribute in the Week state
| No role, with the aria-readonly state set to "true" if the element has a readonly attribute
|
input element that is required
| The aria-required state set to "true"
|
keygen element
| No role |
label element
| No role |
link element that creates a hyperlink
| link role
|
menu element with a type attribute in the context menu state
| No role |
menu element with a type attribute in the list state
| menu role
|
menu element with a type attribute in the toolbar state
| toolbar role
|
meta element
| No role |
meter element
| No role |
nav element
| navigation role
|
noscript element
| No role |
optgroup element
| No role |
option element that is in a list of options or that represents a suggestion in a datalist element
| option role, with the aria-selected state set to "true" if the element's selectedness is true, or "false" otherwise.
|
param element
| No role |
progress element
| progressbar role, with, if the progress bar is determinate, the aria-valuemax property set to the maximum value of the progress bar, the aria-valuemin property set to zero, and the aria-valuenow property set to the current value of the progress bar
|
script element
| No role |
select element with a multiple attribute
| listbox role, with the aria-multiselectable property set to "true"
|
select element with no multiple attribute
| listbox role, with the aria-multiselectable property set to "false"
|
select element with a required attribute
| The aria-required state set to "true"
|
source element
| No role |
style element
| No role |
summary element
| heading role
|
textarea element
| textbox role, with the aria-multiline property set to "true", and the aria-readonly state set to "true" if the element has a readonly attribute
|
textarea element with a required attribute
| The aria-required state set to "true"
|
title element
| No role |
An element that defines a command, whose Type facet is "checkbox", and that is a descendant of a menu element whose type attribute in the list state
| menuitemcheckbox role, with the aria-checked state set to "true" if the command's Checked State facet is true, and "false" otherwise
|
An element that defines a command, whose Type facet is "command", and that is a descendant of a menu element whose type attribute in the list state
| menuitem role
|
An element that defines a command, whose Type facet is "radio", and that is a descendant of a menu element whose type attribute in the list state
| menuitemradio role, with the aria-checked state set to "true" if the command's Checked State facet is true, and "false" otherwise
|
Element that is disabled | The aria-disabled state set to "true"
|
Element with a attribute
| The aria-hidden state set to "true"
|
Element that is a candidate for constraint validation but that does not satisfy its constraints | The aria-invalid state set to "true"
|
Some HTML elements have native semantics that can be
overridden. The following table lists these elements,
along with the restrictions that apply to those elements. Each
language feature (element or attribute) in a cell in the first
column implies, unless otherwise overridden, the ARIA semantic (role,
state, or property) given in the cell in the second column of the
same row, but this semantic may be overridden under the conditions
listed in the cell in the third column of that row. In addition, any
element may be given the presentation
role,
regardless of the restrictions below.
Language feature | Default implied ARIA semantic | Restrictions |
---|---|---|
address element
| No role | If specified, role must be contentinfo
|
article element
| article role
| Role must be either article , document , application , or main
|
aside element
| note role
| Role must be either note , complementary , or search
|
audio element
| No role | If specified, role must be application
|
details element
| group role
| Role must be a role that supports aria-expanded
|
embed element
| No role | If specified, role must be either application , document , or img
|
footer element
| No role | If specified, role must be contentinfo
|
header element
| No role | If specified, role must be banner
|
iframe element
| No role | If specified, role must be either application , document , or img
|
img element whose alt attribute's value is absent
| img role
| No restrictions |
input element with a type attribute in the Checkbox state
| checkbox role
| Role must be either checkbox or menuitemcheckbox
|
input element with a type attribute in the Radio Button state
| radio role
| Role must be either radio or menuitemradio
|
li element whose parent is an ol or ul element
| listitem role
| Role must be either listitem , menuitemcheckbox , menuitemradio , option , tab , or treeitem
|
object element
| No role | If specified, role must be either application , document , or img
|
ol element
| list role
| Role must be either directory , list , listbox , menu , menubar , tablist , toolbar , tree
|
output element
| status role
| No restrictions |
section element
| region role
| Role must be either
alert ,
alertdialog ,
application ,
contentinfo ,
dialog ,
document ,
log ,
main ,
marquee ,
region ,
search , or
status
|
ul element
| list role
| Role must be either directory , list , listbox , menu , menubar , tablist , toolbar , tree
|
video element
| No role | If specified, role must be application
|
The body element | document role
| Role must be either document or application
|
These features can be used to make accessibility tools render content to their users in more useful ways. For example, ASCII art, which is really an image, appears to be text, and in the absence of appropriate annotations would end up being rendered by screen readers as a very painful reading of lots of punctuation. Using the features described in this section, one can instead make the ATs skip the ASCII art and just read the caption:
<figure role="img" aria-labelledby="fish-caption"> <pre> o .'`/ ' / ( O .-'` ` `'-._ .') _/ (o) '. .' / ) ))) >< < `\ |_\ _.' '. \ '-._ _ .-' '.) jgs `\__\ </pre> <figcaption id="fish-caption"> Joan G. Stark, "<cite>fish</cite>". October 1997. ASCII on electrons. 28×8. </figcaption> </figure>
For HTML documents, and for HTML elements in HTML documents, certain APIs defined in DOM Core become case-insensitive or case-changing, as sometimes defined in DOM Core, and as summarized below. [DOMCORE]
This does not apply to XML documents or to elements that are not in the HTML namespace despite being in HTML documents.
Element.tagName
and Node.nodeName
These attributes return element names converted to ASCII uppercase, regardless of the case with which they were created.
Document.createElement()
The canonical form of HTML markup is all-lowercase; thus, this method will lowercase the argument before creating the requisite element. .
This doesn't apply to Document.createElementNS()
. Thus, it is possible,
by passing this last method a tag name in the wrong case, to
create an element that appears to have the same tag name as that
of an element defined in this specification when its tagName
attribute is examined, but that
doesn't support the corresponding interfaces. The "real" element
name (unaffected by case conversions) can be obtained from the
localName
attribute.
Element.setAttribute()
Element.setAttributeNode()
Attribute names are converted to ASCII lowercase.
This doesn't apply to Element.setAttributeNS()
and Element.setAttributeNodeNS()
.
Element.getAttribute()
Element.getAttributeNode()
Attribute names are converted to ASCII lowercase.
This doesn't apply to Element.getAttributeNS()
and Element.getAttributeNodeNS()
.
Document.getElementsByTagName()
Element.getElementsByTagName()
HTML elements match by lower-casing the argument before comparison, elements from other namespaces are treated as in XML (case-sensitively).
Thus, in an HTML document with nodes in multiple namespaces, these methods will effectively be both case-sensitive and case-insensitive at the same time.
APIs for dynamically inserting markup into the document interact with the parser, and thus their behavior varies depending on whether they are used with HTML documents (and the HTML parser) or XHTML in XML documents (and the XML parser).
The open()
method comes in several variants with different numbers of
arguments.
open
( [ type [, replace ] ] )Causes the Document
to be replaced in-place, as if
it was a new Document
object, but reusing the
previous object, which is then returned.
If the type argument is omitted or has the
value "text/html
", then the resulting
Document
has an HTML parser associated with it, which
can be given data to parse using document.write()
. Otherwise, all
content passed to document.write()
will be parsed
as plain text.
If the replace argument is present and has
the value "replace
", the existing entries in
the session history for the Document
object are
removed.
The method has no effect if the Document
is still
being parsed.
Throws an INVALID_STATE_ERR
exception if the
Document
is an XML
document.
open
( url, name, features [, replace ] )Works like the window.open()
method.
close
()Closes the input stream that was opened by the document.open()
method.
Throws an INVALID_STATE_ERR
exception if the
Document
is an XML
document.
document.write()
write
(text...)In general, adds the given string(s) to the
Document
's input stream.
This method has very idiosyncratic behavior. In
some cases, this method can affect the state of the HTML
parser while the parser is running, resulting in a DOM that
does not correspond to the source of the document. In other cases,
the call can clear the current page first, as if document.open()
had been called.
In yet more cases, the method is simply ignored, or throws an
exception. To make matters worse, the exact behavior of this
method can in some cases be dependent on network latency, which
can lead to failures that are very hard to debug. For all
these reasons, use of this method is strongly
discouraged.
This method throws an INVALID_STATE_ERR
exception
when invoked on XML documents.
document.writeln()
writeln
(text...)Adds the given string(s) to the Document
's input
stream, followed by a newline character. If necessary, calls the
open()
method implicitly
first.
This method throws an INVALID_STATE_ERR
exception
when invoked on XML documents.
innerHTML
The innerHTML
IDL
attribute represents the markup of the node's contents.
innerHTML
[ = value ]Returns a fragment of HTML or XML that represents the
Document
.
Can be set, to replace the Document
's contents
with the result of parsing the given string.
In the case of XML documents, will throw an
INVALID_STATE_ERR
if the Document
cannot
be serialized to XML, and a SYNTAX_ERR
if the given
string is not well-formed.
innerHTML
[ = value ]Returns a fragment of HTML or XML that represents the element's contents.
Can be set, to replace the contents of the element with nodes parsed from the given string.
In the case of XML documents, will throw an
INVALID_STATE_ERR
if the element cannot be serialized
to XML, and a SYNTAX_ERR
if the given string is not
well-formed.
outerHTML
The outerHTML
IDL
attribute represents the markup of the element and its contents.
outerHTML
[ = value ]Returns a fragment of HTML or XML that represents the element and its contents.
Can be set, to replace the element with nodes parsed from the given string.
In the case of XML documents, will throw an
INVALID_STATE_ERR
if the element cannot be serialized
to XML, and a SYNTAX_ERR
if the given string is not
well-formed.
Throws a NO_MODIFICATION_ALLOWED_ERR
exception if
the parent of the element is the Document
node.
insertAdjacentHTML()
insertAdjacentHTML
(position, text)Parses the given string text as HTML or XML and inserts the resulting nodes into the tree in the position given by the position argument, as follows:
Throws a SYNTAX_ERR
exception if the arguments
have invalid values (e.g., in the case of XML
documents, if the given string is not well-formed).
Throws a NO_MODIFICATION_ALLOWED_ERR
exception if
the given position isn't possible (e.g. inserting elements after
the root element of a Document
).
html
elementhead
element followed by a body
element.manifest
interface HTMLHtmlElement : HTMLElement {};
The html
element represents the root of
an HTML document.
The manifest
attribute gives the address of the document's application
cache manifest, if there is
one. If the attribute is present, the attribute's value must be a
valid non-empty URL potentially surrounded by
spaces.
The manifest
attribute
only has an effect during
the early stages of document load. Changing the attribute
dynamically thus has no effect (and thus, no DOM API is provided for
this attribute).
For the purposes of application cache selection,
later base
elements cannot affect the resolving of relative URLs in manifest
attributes, as the
attributes are processed before those elements are seen.
The window.applicationCache
IDL
attribute provides scripted access to the offline application
cache mechanism.
The html
element in the following example declares
that the document's language is English.
<!DOCTYPE html> <html lang="en"> <head> <title>Swapping Songs</title> </head> <body> <h1>Swapping Songs</h1> <p>Tonight I swapped some of the songs I wrote with some friends, who gave me some of the songs they wrote. I love sharing my music.</p> </body> </html>
head
elementhtml
element.iframe
srcdoc
document or if title information is available from a higher-level protocol: Zero or more elements of metadata content.title
element.interface HTMLHeadElement : HTMLElement {};
The head
element represents a
collection of metadata for the Document
.
The collection of metadata in a head
element can be
large or small. Here is an example of a very short one:
<!doctype html> <html> <head> <title>A document with a short head</title> </head> <body> ...
Here is an example of a longer one:
<!DOCTYPE HTML> <HTML> <HEAD> <META CHARSET="UTF-8"> <BASE HREF="http://www.example.com/"> <TITLE>An application with a long head</TITLE> <LINK REL="STYLESHEET" HREF="default.css"> <LINK REL="STYLESHEET ALTERNATE" HREF="big.css" TITLE="Big Text"> <SCRIPT SRC="support.js"></SCRIPT> <META NAME="APPLICATION-NAME" CONTENT="Long headed application"> </HEAD> <BODY> ...
The title
element is a required child
in most situations, but when a higher-level protocol provides title
information, e.g. in the Subject line of an e-mail when HTML is used
as an e-mail authoring format, the title
element can be
omitted.
title
elementhead
element containing no other title
elements.interface HTMLTitleElement : HTMLElement { attribute DOMString text; };
The title
element represents the
document's title or name. Authors should use titles that identify
their documents even when they are used out of context, for example
in a user's history or bookmarks, or in search results. The
document's title is often different from its first heading, since the
first heading does not have to stand alone when taken out of
context.
There must be no more than one title
element per
document.
text
[ = value ]Returns the contents of the element, ignoring child nodes that aren't text nodes.
Can be set, to replace the element's children with the given value.
Here are some examples of appropriate titles, contrasted with the top-level headings that might be used on those same pages.
<title>Introduction to The Mating Rituals of Bees</title> ... <h1>Introduction</h1> <p>This companion guide to the highly successful <cite>Introduction to Medieval Bee-Keeping</cite> book is...
The next page might be a part of the same site. Note how the title describes the subject matter unambiguously, while the first heading assumes the reader knows what the context is and therefore won't wonder if the dances are Salsa or Waltz:
<title>Dances used during bee mating rituals</title> ... <h1>The Dances</h1>
The string to use as the document's title is given by the document.title
IDL attribute.
base
elementhead
element containing no other base
elements.href
target
interface HTMLBaseElement : HTMLElement { attribute DOMString href; attribute DOMString target; };
The base
element allows authors to specify the
document base URL for the purposes of resolving relative URLs, and the name
of the default browsing context for the purposes of
following hyperlinks. The element does not represent any content beyond this
information.
There must be no more than one base
element per
document.
A base
element must have either an href
attribute, a target
attribute, or both.
The href
content
attribute, if specified, must contain a valid URL potentially
surrounded by spaces.
A base
element, if it has an href
attribute, must come before any
other elements in the tree that have attributes defined as taking
URLs, except the html
element
(its manifest
attribute
isn't affected by base
elements).
The target
attribute, if specified, must contain a valid browsing context
name or keyword, which specifies which browsing
context is to be used as the default when hyperlinks and forms in the Document
cause navigation.
A base
element, if it has a target
attribute, must come before
any elements in the tree that represent hyperlinks.
In this example, a base
element is used to set the
document base URL:
<!DOCTYPE html> <html> <head> <title>This is an example for the <base> element</title> <base href="http://www.example.com/news/index.html"> </head> <body> <p>Visit the <a href="archives.html">archives</a>.</p> </body> </html>
The link in the above example would be a link to "http://www.example.com/news/archives.html
".
link
elementnoscript
element that is a child of a head
element.href
rel
media
hreflang
type
sizes
title
attribute has special semantics on this element.interface HTMLLinkElement : HTMLElement {
attribute boolean disabled;
attribute DOMString href;
attribute DOMString rel;
readonly attribute DOMTokenList relList;
attribute DOMString media;
attribute DOMString hreflang;
attribute DOMString type;
[PutForwards=value] readonly attribute DOMSettableTokenList sizes;
};
HTMLLinkElement implements LinkStyle;
The link
element allows authors to link their
document to other resources.
The destination of the link(s) is given by the href
attribute, which must
be present and must contain a valid non-empty URL potentially
surrounded by spaces.
A link
element must have rel
attribute.
The types of link indicated (the relationships) are given by the
value of the rel
attribute, which, if present, must have a value that is a set
of space-separated tokens. The allowed
keywords and their meanings are defined in a later
section.
Two categories of links can be created using the
link
element: Links to external resources and hyperlinks. The link
types section defines whether a particular link type is an
external resource or a hyperlink. One link
element can
create multiple links (of which some might be external resource
links and some might be hyperlinks); exactly which and how many
links are created depends on the keywords given in the rel
attribute. User agents must process
the links on a per-link basis, not a per-element basis.
Each link created for a link
element is
handled separately. For instance, if there are two link
elements with rel="stylesheet"
, they each
count as a separate external resource, and each is affected by its
own attributes independently. Similarly, if a single
link
element has a rel
attribute with the value next stylesheet
, it creates both a
hyperlink (for the next
keyword) and an external resource link (for the stylesheet
keyword), and they are
affected by other attributes (such as media
or title
) differently.
The exact behavior for links to external resources depends on the exact relationship, as defined for the relevant link type. Some of the attributes control whether or not the external resource is to be applied (as defined below).
Hyperlinks created with the link
element and its rel
attribute
apply to the whole page. This contrasts with the rel
attribute of a
and area
elements, which indicates the type of a link
whose context is given by the link's location within the
document.
The media
attribute says which media the resource applies to. The value must
be a valid media query.
The default, if the media
attribute is omitted, is "all
", meaning that by default links apply to all
media.
The hreflang
attribute on the link
element has the same semantics as
the hreflang
attribute on a
and area
elements.
The type
attribute
gives the MIME type of the linked resource. It is
purely advisory. The value must be a valid MIME
type.
For external resource
links, the type
attribute
is used as a hint to user agents so that they can avoid fetching
resources they do not support.
The title
attribute gives the title of the link. With one exception, it is
purely advisory. The value is text. The exception is for style sheet
links, where the title
attribute defines alternative style sheet sets.
The title
attribute on link
elements differs from the global
title
attribute of most other
elements in that a link without a title does not inherit the title
of the parent element: it merely has no title.
The sizes
attribute is used
with the icon
link type. The attribute
must not be specified on link
elements that do not have
a rel
attribute that specifies
the icon
keyword.
The IDL attribute disabled
only applies
to style sheet links. When the link
element defines a
style sheet link, then the disabled
attribute behaves as
defined for the alternative
style sheets DOM. For all other link
elements it
always return false and does nothing on setting.
The LinkStyle
interface is also implemented by
this element; the styling processing model defines
how. [CSSOM]
Here, a set of link
elements provide some style
sheets:
<!-- a persistent style sheet --> <link rel="stylesheet" href="default.css"> <!-- the preferred alternate style sheet --> <link rel="stylesheet" href="green.css" title="Green styles"> <!-- some alternate style sheets --> <link rel="alternate stylesheet" href="contrast.css" title="High contrast"> <link rel="alternate stylesheet" href="big.css" title="Big fonts"> <link rel="alternate stylesheet" href="wide.css" title="Wide screen">
The following example shows how you can specify versions of the page that use alternative formats, are aimed at other languages, and that are intended for other media:
<link rel=alternate href="/en/html" hreflang=en type=text/html title="English HTML"> <link rel=alternate href="/fr/html" hreflang=fr type=text/html title="French HTML"> <link rel=alternate href="/en/html/print" hreflang=en type=text/html media=print title="English HTML (for printing)"> <link rel=alternate href="/fr/html/print" hreflang=fr type=text/html media=print title="French HTML (for printing)"> <link rel=alternate href="/en/pdf" hreflang=en type=application/pdf title="English PDF"> <link rel=alternate href="/fr/pdf" hreflang=fr type=application/pdf title="French PDF">
meta
elementcharset
attribute is present, or if the element's http-equiv
attribute is in the Encoding declaration state: in a head
element.http-equiv
attribute is present but not in the Encoding declaration state: in a head
element.http-equiv
attribute is present but not in the Encoding declaration state: in a noscript
element that is a child of a head
element.name
attribute is present: where metadata content is expected.name
http-equiv
content
charset
interface HTMLMetaElement : HTMLElement { attribute DOMString name; attribute DOMString httpEquiv; attribute DOMString content; };
The meta
element represents various
kinds of metadata that cannot be expressed using the
title
, base
, link
,
style
, and script
elements.
The meta
element can represent document-level
metadata with the name
attribute, pragma directives with the http-equiv
attribute, and the
file's character encoding declaration when an HTML
document is serialized to string form (e.g. for transmission over
the network or for disk storage) with the charset
attribute.
Exactly one of the name
,
http-equiv
, and charset
attributes must be
specified.
If either name
or http-equiv
is specified, then
the content
attribute must
also be specified. Otherwise, it must be omitted.
The charset
attribute specifies the character encoding used by the
document. This is a character encoding declaration. If
the attribute is present in an XML
document, its value must be an ASCII
case-insensitive match for the string "UTF-8
" (and the document is therefore forced to use
UTF-8 as its encoding).
The charset
attribute on the meta
element has no effect in XML
documents, and is only allowed in order to facilitate migration to
and from XHTML.
There must not be more than one meta
element with a
charset
attribute per
document.
The content
attribute gives the value of the document metadata or pragma
directive when the element is used for those purposes. The allowed
values depend on the exact context, as described in subsequent
sections of this specification.
If a meta
element has a name
attribute, it sets
document metadata. Document metadata is expressed in terms of
name/value pairs, the name
attribute on the meta
element giving the name, and the
content
attribute on the same
element giving the value. The name specifies what aspect of metadata
is being set; valid names and the meaning of their values are
described in the following sections. If a meta
element
has no content
attribute,
then the value part of the metadata name/value pair is the empty
string.
This specification defines a few names for the name
attribute of the
meta
element.
Names are case-insensitive.
application-name
The value must be a short free-form string giving the name
of the Web application that the page represents. If the page is not
a Web application, the application-name
metadata name
must not be used. There must not be more than one meta
element with its name
attribute
set to the value application-name
per
document.
author
The value must be a free-form string giving the name of one of the page's authors.
description
The value must be a free-form string that describes the
page. The value must be appropriate for use in a directory of
pages, e.g. in a search engine. There must not be more than one
meta
element with its name
attribute set to the value description
per document.
generator
The value must be a free-form string that identifies one of the software packages used to generate the document. This value must not be used on hand-authored pages.
Here is what a tool called "Frontweaver" could include in its
output, in the page's head
element, to identify
itself as the tool used to generate the page:
<meta name=generator content="Frontweaver 8.2">
keywords
The value must be a set of comma-separated tokens, each of which is a keyword relevant to the page.
This page about typefaces on British motorways uses a
meta
element to specify some keywords that users
might use to look for the page:
<!DOCTYPE HTML> <html> <head> <title>Typefaces on UK motorways</title> <meta name="keywords" content="british,type face,font,fonts,highway,highways"> </head> <body> ...
Many search engines do not consider such keywords, because this feature has historically been used unreliably and even misleadingly as a way to spam search engine results in a way that is not helpful for users.
ISSUE-27 (rel-ownership) blocks progress to Last Call
Extensions to the predefined set of metadata names may be registered in the WHATWG Wiki MetaExtensions page. [WHATWGWIKI]
Anyone is free to edit the WHATWG Wiki MetaExtensions page at any time to add a type. These new names must be specified with the following information:
The actual name being defined. The name should not be confusingly similar to any other defined name (e.g. differing only in case).
A short non-normative description of what the metadata name's meaning is, including the format the value is required to be in.
A list of other names that have exactly the same processing requirements. Authors should not use the names defined to be synonyms, they are only intended to allow user agents to support legacy content. Anyone may remove synonyms that are not used in practice; only names that need to be processed as synonyms for compatibility with legacy content are to be registered in this way.
One of the following:
If a metadata name is found to be redundant with existing values, it should be removed and listed as a synonym for the existing value.
If a metadata name is registered in the "proposed" state for a period of a month or more without being used or specified, then it may be removed from the registry.
If a metadata name is added with the "proposed" status and found to be redundant with existing values, it should be removed and listed as a synonym for the existing value. If a metadata name is added with the "proposed" status and found to be harmful, then it should be changed to "discontinued" status.
Anyone can change the status at any time, but should only do so in accordance with the definitions above.
Metadata names whose values are to be URLs must not be proposed or accepted. Links must
be represented using the link
element, not the
meta
element.
When the http-equiv
attribute
is specified on a meta
element, the element is a pragma
directive.
The http-equiv
attribute is an enumerated attribute. The following
table lists the keywords defined for this attribute. The states
given in the first cell of the rows with keywords give the states to
which those keywords map.
State | Keyword | Notes |
---|---|---|
Content Language | content-language
| Conformance checkers will include a warning |
Encoding declaration | content-type
| |
Default style | default-style
| |
Refresh | refresh
|
http-equiv="content-language"
)
This pragma sets the pragma-set default language. Until the pragma is successfully processed, there is no pragma-set default language.
Conformance checkers will include a warning if
this pragma is used. Authors are encouraged to use the lang
attribute instead.
For meta
elements with an http-equiv
attribute in the
Content
Language state, the content
attribute must have a
value consisting of a valid BCP 47 language tag. [BCP47]
This pragma is not exactly equivalent to the HTTP
Content-Language
header, for instance it only
supports one language. [HTTP]
http-equiv="content-type"
)
The Encoding
declaration state is just an alternative form of setting
the charset
attribute: it is a
character encoding declaration.
For meta
elements with an http-equiv
attribute in the
Encoding
declaration state, the content
attribute must have a
value that is an ASCII case-insensitive match for a
string that consists of: the literal string "text/html;
", optionally followed by any number of
space characters, followed by
the literal string "charset=
", followed by
the character encoding name of the character encoding
declaration.
If the document contains a meta
element with an
http-equiv
attribute in
the Encoding
declaration state, then the document must not contain a
meta
element with the charset
attribute present.
The Encoding
declaration state may be used in HTML
documents, but elements with an http-equiv
attribute in that
state must not be used in XML documents.
http-equiv="default-style"
)
This pragma sets the name of the default alternative style sheet set.
http-equiv="refresh"
)
This pragma acts as timed redirect.
For meta
elements with an http-equiv
attribute in the
Refresh state,
the content
attribute must
have a value consisting either of:
URL
", followed by a U+003D
EQUALS SIGN character (=), followed by a valid URL
that does not start with a literal U+0027 APOSTROPHE (') or
U+0022 QUOTATION MARK (") character.In the former case, the integer represents a number of seconds before the page is to be reloaded; in the latter case the integer represents a number of seconds before the page is to be replaced by the page at the given URL.
A news organization's front page could include the following
markup in the page's head
element, to ensure that
the page automatically reloads from the server every five
minutes:
<meta http-equiv="Refresh" content="300">
A sequence of pages could be used as an automated slide show by making each page refresh to the next page in the sequence, using markup such as the following:
<meta http-equiv="Refresh" content="20; URL=page4.html">
There must not be more than one meta
element with
any particular state in the document at a time.
Extensions to the predefined set of pragma directives may, under certain conditions, be registered in the WHATWG Wiki PragmaExtensions page. [WHATWGWIKI]
Such extensions must use a name that is identical to an HTTP header registered in the Permanent Message Header Field Registry, and must have behavior identical to that described for the HTTP header. [IANAPERMHEADERS]
Pragma directives corresponding to headers describing metadata, or not requiring specific user agent processing, must not be registered; instead, use metadata names. Pragma directives corresponding to headers that affect the HTTP processing model (e.g. caching) must not be registered, as they would result in HTTP-level behavior being different for user agents that implement HTML than for user agents that do not.
Anyone is free to edit the WHATWG Wiki PragmaExtensions page at any time to add a pragma directive satisfying these conditions. Such registrations must specify the following information:
The actual name being defined. The name must match a previously-registered HTTP name with the same requirements.
A short non-normative description of the purpose of the pragma directive.
A character encoding declaration is a mechanism by which the character encoding used to store or transmit a document is specified.
The following restrictions apply to character encoding declarations:
If an HTML document does not
start with a BOM, and if its encoding is not explicitly given by
Content-Type metadata, and the
document is not an iframe
srcdoc
document, then the
character encoding used must be an ASCII-compatible character
encoding, and, in addition, if that encoding isn't US-ASCII
itself, then the encoding must be specified using a
meta
element with a charset
attribute or a
meta
element with an http-equiv
attribute in the
Encoding declaration
state.
If the document is an iframe
srcdoc
document, the
document must not have a character encoding
declaration. (In this case, the source is already decoded,
since it is part of the document that contained the
iframe
.)
If an HTML document contains
a meta
element with a charset
attribute or a
meta
element with an http-equiv
attribute in the
Encoding declaration
state, then the character encoding used must be an
ASCII-compatible character encoding.
Authors are encouraged to use UTF-8. Conformance checkers may advise authors against using legacy encodings. [RFC3629]
Encodings in which a series of bytes in the range 0x20 to 0x7E
can encode characters other than the corresponding characters in the
range U+0020 to U+007E represent a potential security vulnerability:
a user agent that does not support the encoding (or does not support
the label used to declare the encoding, or does not use the same
mechanism to detect the encoding of unlabelled content as another
user agent) might end up interpreting technically benign plain text
content as HTML tags and JavaScript. For example, this applies to
encodings in which the bytes corresponding to "<script>
" in ASCII can encode a different
string. Authors should not use such encodings, which are known to
include JIS_C6226-1983,
JIS_X0212-1990, HZ-GB-2312, JOHAB (Windows code
page 1361), encodings based on ISO-2022, and encodings based on EBCDIC. Furthermore, authors must not
use the CESU-8, UTF-7, BOCU-1 and SCSU encodings, which also fall
into this category, because these encodings were never intended for
use for Web content.
[RFC1345]
[RFC1842]
[RFC1468]
[RFC2237]
[RFC1554]
[RFC1922]
[RFC1557]
[CESU8]
[UTF7]
[BOCU1]
[SCSU]
Authors should not use UTF-32, as the encoding detection algorithms described in this specification intentionally do not distinguish it from UTF-16. [UNICODE]
Using non-UTF-8 encodings can have unexpected results on form submission and URL encodings, which use the document's character encoding by default.
In XHTML, the XML declaration should be used for inline character encoding information, if necessary.
In HTML, to declare that the character encoding is UTF-8, the
author could include the following markup near the top of the
document (in the head
element):
<meta charset="utf-8">
In XML, the XML declaration would be used instead, at the very top of the markup:
<?xml version="1.0" encoding="utf-8"?>
style
elementscoped
attribute is present: flow content.scoped
attribute is absent: where metadata content is expected.scoped
attribute is absent: in a noscript
element that is a child of a head
element.scoped
attribute is present: where flow content is expected, but before any other flow content other than other style
elements and inter-element whitespace.type
attribute, but must match requirements described in prose below.media
type
scoped
title
attribute has special semantics on this element.interface HTMLStyleElement : HTMLElement {
attribute boolean disabled;
attribute DOMString media;
attribute DOMString type;
attribute boolean scoped;
};
HTMLStyleElement implements LinkStyle;
The style
element allows authors to embed style
information in their documents. The style
element is
one of several inputs to the styling processing
model. The element does not represent content for the user.
The type
attribute gives the styling language. If the attribute is present,
its value must be a valid MIME type that designates a
styling language. The charset
parameter must
not be specified. The default value for the type
attribute, which is used if the
attribute is absent, is "text/css
". [RFC2318]
The media
attribute says which media the styles apply to. The value must be a
valid media query.
The default, if the media
attribute is omitted, is
"all
", meaning that by default styles apply to
all media.
The scoped
attribute is a boolean attribute. If set, it indicates
that the styles are intended just for the subtree rooted at the
style
element's parent element, as opposed to the whole
Document
.
The title
attribute on
style
elements defines alternative style sheet
sets. If the style
element has no title
attribute, then it has no
title; the title
attribute of
ancestors does not apply to the style
element. [CSSOM]
The title
attribute on style
elements, like the title
attribute on link
elements, differs from the global title
attribute in that a
style
block without a title does not inherit the title
of the parent element: it merely has no title.
The textContent
of a style
element must
match the style
production in the following
ABNF, the character set for which is Unicode. [ABNF]
style = no-c-start *( c-start no-c-end c-end no-c-start ) no-c-start = <any string that doesn't contain a substring that matches c-start > c-start = "<!--" no-c-end = <any string that doesn't contain a substring that matches c-end > c-end = "-->"
This specification does not specify a style system, but CSS is expected to be supported by most Web browsers. [CSS]
The disabled
IDL attribute behaves as defined for the alternative style sheets
DOM.
The LinkStyle
interface is also implemented by
this element; the styling processing model defines
how. [CSSOM]
The following document has its emphasis styled as bright red text rather than italics text, while leaving titles of works and Latin words in their default italics. It shows how using appropriate elements enables easier restyling of documents.
<!DOCTYPE html> <html lang="en-US"> <head> <title>My favorite book</title> <style> body { color: black; background: white; } em { font-style: normal; color: red; } </style> </head> <body> <p>My <em>favorite</em> book of all time has <em>got</em> to be <cite>A Cat's Life</cite>. It is a book by P. Rahmel that talks about the <i lang="la">Felis Catus</i> in modern human society.</p> </body> </html>
The link
and style
elements can provide
styling information for the user agent to use when rendering the
document. The DOM Styling specification specifies what styling
information is to be used by the user agent and how it is to be
used. [CSSOM]
The style
and link
elements implement
the LinkStyle
interface. [CSSOM]
Scripts allow authors to add interactivity to their documents.
Authors are encouraged to use declarative alternatives to scripting where possible, as declarative mechanisms are often more maintainable, and many users disable scripting.
For example, instead of using script to show or hide a section
to show more details, the details
element could be
used.
Authors are also encouraged to make their applications degrade gracefully in the absence of scripting support.
For example, if an author provides a link in a table header to dynamically resort the table, the link could also be made to function without scripts by requesting the sorted table from the server.
script
elementsrc
attribute, depends on the value of the type
attribute, but must match
script content restrictions.src
attribute, the element must be either empty or contain only
script documentation that also matches script
content restrictions.src
async
defer
type
charset
interface HTMLScriptElement : HTMLElement { attribute DOMString src; attribute boolean async; attribute boolean defer; attribute DOMString type; attribute DOMString charset; attribute DOMString text; };
The script
element allows authors to include dynamic
script and data blocks in their documents. The element does not
represent content for the user.
When used to include dynamic scripts, the scripts may either be
embedded inline or may be imported from an external file using the
src
attribute. If the language
is not that described by "text/javascript
",
then the type
attribute must
be present, as described below. Whatever language is used, the
contents of the script
element must conform with the
requirements of that language's specification.
When used to include data blocks (as opposed to scripts), the
data must be embedded inline, the format of the data must be given
using the type
attribute, the
src
attribute must not be
specified, and the contents of the script
element must
conform to the requirements defined for the format used.
The type
attribute gives the language of the script or format of the data. If
the attribute is present, its value must be a valid MIME
type. The charset
parameter must not be
specified. The default, which is used if the attribute is absent,
is "text/javascript
".
The src
attribute, if specified, gives the address of the external script
resource to use. The value of the attribute must be a valid
non-empty URL potentially surrounded by spaces identifying a
script resource of the type given by the type
attribute, if the attribute is
present, or of the type "text/javascript
", if
the attribute is absent. A resource is a script resource of a given
type if that type identifies a scripting language and the resource
conforms with the requirements of that language's specification.
The charset
attribute gives the character encoding of the external script
resource. The attribute must not be specified if the src
attribute is not present. If the
attribute is set, its value must be a valid character encoding name,
must be an ASCII case-insensitive match for the
preferred MIME name for that encoding, and must match
the encoding given in the charset
parameter of
the Content-Type metadata of the
external file, if any. [IANACHARSET]
The async
and
defer
attributes
are boolean attributes that
indicate how the script should be executed. The defer
and async
attributes must not be
specified if the src
attribute
is not present.
There are three possible modes that can be selected using these
attributes. If the async
attribute is present, then the script will be executed
asynchronously, as soon as it is available. If the async
attribute is not present but
the defer
attribute is
present, then the script is executed when the page has finished
parsing. If neither attribute is present, then the script is
fetched and executed immediately, before the user agent continues
parsing the page.
The exact processing details for these attributes
are, for mostly historical reasons, somewhat non-trivial, involving
a number of aspects of HTML. The implementation requirements are
therefore by necessity scattered throughout the specification. The
algorithms below (in this section) describe the core of this
processing, but these algorithms reference and are referenced by the
parsing rules for script
start
and end tags in HTML, in foreign content, and in XML, the rules for the document.write()
method, the
handling of scripting, etc.
The defer
attribute may be
specified even if the async
attribute is specified, to cause legacy Web browsers that only
support defer
(and not async
) to fall back to the defer
behavior instead of the
synchronous blocking behavior that is the default.
Changing the src
, type
, charset
, async
, and defer
attributes dynamically has no
direct effect; these attribute are only used at specific times
described below.
text
[ = value ]Returns the contents of the element, ignoring child nodes that aren't text nodes.
Can be set, to replace the element's children with the given value.
When inserted using the document.write()
method,
script
elements execute (typically synchronously), but
when inserted using innerHTML
and outerHTML
attributes, they do not
execute at all.
In this example, two script
elements are used. One
embeds an external script, and the other includes some data.
<script src="game-engine.js"></script> <script type="text/x-game-map"> ........U.........e o............A....e .....A.....AAA....e .A..AAA...AAAAA...e </script>
The data in this case might be used by the script to generate the map of a video game. The data doesn't have to be used that way, though; maybe the map data is actually embedded in other parts of the page's markup, and the data block here is just used by the site's search engine to help users who are looking for particular features in their game maps.
The following sample shows how a script element can be used to
define a function that is then used by other parts of the
document. It also shows how a script
element can be
used to invoke script while the document is being parsed, in this
case to initialize the form's output.
<script> function calculate(form) { var price = 52000; if (form.elements.brakes.checked) price += 1000; if (form.elements.radio.checked) price += 2500; if (form.elements.turbo.checked) price += 5000; if (form.elements.sticker.checked) price += 250; form.elements.result.value = price; } </script> <form name="pricecalc" onsubmit="return false"> <fieldset> <legend>Work out the price of your car</legend> <p>Base cost: £52000.</p> <p>Select additional options:</p> <ul onchange="calculate(form)"> <li><label><input type=checkbox name=brakes> Ceramic brakes (£1000)</label></li> <li><label><input type=checkbox name=radio> Satellite radio (£2500)</label></li> <li><label><input type=checkbox name=turbo> Turbo charger (£5000)</label></li> <li><label><input type=checkbox name=sticker> "XZ" sticker (£250)</label></li> </ul> <p>Total: £<output name=result></output></p> </fieldset> <script> calculate(document.forms.pricecalc); </script> </form>
The following lists some MIME type strings and the languages to which they refer:
application/ecmascript
"application/javascript
"application/x-ecmascript
"application/x-javascript
"text/ecmascript
"text/javascript
"text/javascript1.0
"text/javascript1.1
"text/javascript1.2
"text/javascript1.3
"text/javascript1.4
"text/javascript1.5
"text/jscript
"text/livescript
"text/x-ecmascript
"text/x-javascript
"text/javascript;e4x=1
"script
elementsThe textContent
of a script
element
must match the script
production in the
following ABNF, the character set for which is Unicode. [ABNF]
script = data1 *( escape [ script-start data3 ] "-->" data1 ) [ escape ] escape = "<!--" data2 *( script-start data3 script-end data2 ) data1 = <any string that doesn't contain a substring that matches not-data1> not-data1 = "<!--" data2 = <any string that doesn't contain a substring that matches not-data2> not-data2 = script-start / "-->" data3 = <any string that doesn't contain a substring that matches not-data3> not-data3 = script-end / "-->" script-start = lt s c r i p t tag-end script-end = lt slash s c r i p t tag-end lt = %x003C ; U+003C LESS-THAN SIGN character (<) slash = %x002F ; U+002F SOLIDUS character (/) s = %x0053 ; U+0053 LATIN CAPITAL LETTER S s =/ %x0073 ; U+0073 LATIN SMALL LETTER S c = %x0043 ; U+0043 LATIN CAPITAL LETTER C c =/ %x0063 ; U+0063 LATIN SMALL LETTER C r = %x0052 ; U+0052 LATIN CAPITAL LETTER R r =/ %x0072 ; U+0072 LATIN SMALL LETTER R i = %x0049 ; U+0049 LATIN CAPITAL LETTER I i =/ %x0069 ; U+0069 LATIN SMALL LETTER I p = %x0050 ; U+0050 LATIN CAPITAL LETTER P p =/ %x0070 ; U+0070 LATIN SMALL LETTER P t = %x0054 ; U+0054 LATIN CAPITAL LETTER T t =/ %x0074 ; U+0074 LATIN SMALL LETTER T tag-end = %x0009 ; U+0009 CHARACTER TABULATION tag-end =/ %x000A ; U+000A LINE FEED (LF) tag-end =/ %x000C ; U+000C FORM FEED (FF) tag-end =/ %x0020 ; U+0020 SPACE tag-end =/ %x002F ; U+002F SOLIDUS (/) tag-end =/ %x003E ; U+003E GREATER-THAN SIGN (>)
When a script
element contains script
documentation, there are further restrictions on the contents
of the element, as described in the section below.
If a script
element's src
attribute is specified, then the
contents of the script
element, if any, must be such
that the value of the text
IDL
attribute, which is derived from the element's contents, matches the
documentation
production in the following
ABNF, the character set for which is Unicode. [ABNF]
documentation = *( *( space / tab / comment ) [ line-comment ] newline ) comment = slash star *( not-star / star not-slash ) 1*star slash line-comment = slash slash *not-newline ; characters tab = %x0009 ; U+0009 TAB newline = %x000A ; U+000A LINE FEED (LF) space = %x0020 ; U+0020 SPACE star = %x002A ; U+002A ASTERISK (*) slash = %x002F ; U+002F SOLIDUS (/) not-newline = %x0000-0009 / %x000B-10FFFF ; a Unicode character other than U+000A LINE FEED (LF) not-star = %x0000-0029 / %x002B-10FFFF ; a Unicode character other than U+002A ASTERISK (*) not-slash = %x0000-002E / %x0030-10FFFF ; a Unicode character other than U+002F SOLIDUS (/)
This corresponds to putting the contents of the element in JavaScript comments.
This requirement is in addition to the earlier
restrictions on the syntax of contents of script
elements.
This allows authors to include documentation, such as license
information or API information, inside their documents while still
referring to external script files. The syntax is constrained so
that authors don't accidentally include what looks like valid
script while also providing a src
attribute.
<script src="cool-effects.js"> // create new instances using: // var e = new Effect(); // start the effect using .play, stop using .stop: // e.play(); // e.stop(); </script>
noscript
elementhead
element of an HTML document, if there are no ancestor noscript
elements.noscript
elements.head
element: in any order, zero or more link
elements, zero or more style
elements, and zero or more meta
elements.head
element: transparent, but there must be no noscript
element descendants.HTMLElement
.The noscript
element represents nothing
if scripting is enabled, and
represents its children if scripting is disabled. It is used
to present different markup to user agents that support scripting
and those that don't support scripting, by affecting how the
document is parsed.
When used in HTML documents, the allowed content model is as follows:
head
element, if scripting is disabled for the
noscript
elementThe noscript
element must contain only
link
, style
, and meta
elements.
head
element, if scripting is enabled for the
noscript
elementThe noscript
element must contain only text,
except that invoking the HTML fragment parsing
algorithm with
the noscript
element as the context element and the text contents as the input must result in a list of nodes that consists
only of link
, style
, and
meta
elements that would be conforming if they were
children of the noscript
element, and no parse errors.
head
elements, if scripting is disabled for the
noscript
elementThe noscript
element's content model is
transparent, with the additional restriction that a
noscript
element must not have a noscript
element as an ancestor (that is, noscript
can't be
nested).
head
elements, if scripting is enabled for the
noscript
elementThe noscript
element must contain only text,
except that the text must be such that running the following
algorithm results in a conforming document with no
noscript
elements and no script
elements, and such that no step in the algorithm causes an
HTML parser to flag a parse error:
script
element from the
document.noscript
element in the
document. For every noscript
element in that list,
perform the following steps:
noscript
element.noscript
element, and call these
elements the before children.noscript
element, and
call these elements the after children.noscript
element.innerHTML
attribute of the parent element to the value
of s. (This, as a side-effect, causes the
noscript
element to be removed from the
document.)All these contortions are required because, for
historical reasons, the noscript
element is handled
differently by the HTML parser based on whether scripting was enabled or not when the
parser was invoked.
The noscript
element must not be used in XML
documents.
The noscript
element is only
effective in the HTML syntax, it has no effect in
the XHTML syntax.
In the following example, a noscript
element is
used to provide fallback for a script.
<form action="calcSquare.php"> <p> <label for=x>Number</label>: <input id="x" name="x" type="number"> </p> <script> var x = document.getElementById('x'); var output = document.createElement('p'); output.textContent = 'Type a number; it will be squared right then!'; x.form.appendChild(output); x.form.onsubmit = function () { return false; } x.oninput = function () { var v = x.valueAsNumber; output.textContent = v + ' squared is ' + v * v; }; </script> <noscript> <input type=submit value="Calculate Square"> </noscript> </form>
When script is disabled, a button appears to do the calculation on the server side. When script is enabled, the value is computed on-the-fly instead.
The noscript
element is a blunt
instrument. Sometimes, scripts might be enabled, but for some
reason the page's script might fail. For this reason, it's
generally better to avoid using noscript
, and to
instead design the script to change the page from being a
scriptless page to a scripted page on the fly, as in the next
example:
<form action="calcSquare.php"> <p> <label for=x>Number</label>: <input id="x" name="x" type="number"> </p> <input id="submit" type=submit value="Calculate Square"> <script> var x = document.getElementById('x'); var output = document.createElement('p'); output.textContent = 'Type a number; it will be squared right then!'; x.form.appendChild(output); x.form.onsubmit = function () { return false; } x.oninput = function () { var v = x.valueAsNumber; output.textContent = v + ' squared is ' + v * v; }; var submit = document.getElementById('submit'); submit.parentNode.removeChild(submit); </script> </form>
The above technique is also useful in XHTML, since
noscript
is not supported in the XHTML
syntax.
body
elementhtml
element.onafterprint
onbeforeprint
onbeforeunload
onblur
onerror
onfocus
onhashchange
onload
onmessage
onoffline
ononline
onpagehide
onpageshow
onpopstate
onredo
onresize
onscroll
onstorage
onundo
onunload
interface HTMLBodyElement : HTMLElement { attribute Function onafterprint; attribute Function onbeforeprint; attribute Function onbeforeunload; attribute Function onblur; attribute Function onerror; attribute Function onfocus; attribute Function onhashchange; attribute Function onload; attribute Function onmessage; attribute Function onoffline; attribute Function ononline; attribute Function onpopstate; attribute Function onpagehide; attribute Function onpageshow; attribute Function onredo; attribute Function onresize; attribute Function onscroll; attribute Function onstorage; attribute Function onundo; attribute Function onunload; };
The body
element represents the main
content of the document.
In conforming documents, there is only one body
element. The document.body
IDL attribute provides scripts with easy access to a document's
body
element.
The body
element exposes as event handler
content attributes a number of the event
handlers of the Window
object. It also mirrors
their event handler IDL attributes.
The onblur
, onerror
, onfocus
, onload
, and onscroll
event
handlers of the Window
object, exposed on the
body
element, shadow the generic event
handlers with the same names normally supported by HTML
elements.
Thus, for example, a bubbling error
event fired on a child of the
body element of a Document
would first trigger
the onerror
event handler
content attributes of that element, then that of the root
html
element, and only then would it trigger
the onerror
event handler content
attribute on the body
element. This is because
the event would bubble from the target, to the body
, to
the html
, to the Document
, to the
Window
, and the event
handler on the body
is watching the
Window
not the body
. A regular event
listener attached to the body
using addEventListener()
, however, would fire when the
event bubbled through the body
and not when it reaches
the Window
object.
This page updates an indicator to show whether or not the user is online:
<!DOCTYPE HTML> <html> <head> <title>Online or offline?</title> <script> function update(online) { document.getElementById('status').textContent = online ? 'Online' : 'Offline'; } </script> </head> <body ononline="update(true)" onoffline="update(false)" onload="update(navigator.onLine)"> <p>You are: <span id="status">(Unknown)</span></p> </body> </html>
section
elementformatBlock
candidate.HTMLElement
.The section
element represents a
generic section of a document or application. A section, in this
context, is a thematic grouping of content, typically with a
heading.
Examples of sections would be chapters, the various tabbed pages in a tabbed dialog box, or the numbered sections of a thesis. A Web site's home page could be split into sections for an introduction, news items, and contact information.
Authors are encouraged to use the
article
element instead of the section
element when it would make sense to syndicate the contents of the
element.
The section
element is not a generic container element. When an element is
needed for styling purposes or as a convenience for scripting,
authors are encouraged to use the div
element
instead. A general rule is that the section
element is
appropriate only if the element's contents would be listed
explicitly in the document's outline.
In the following example, we see an article (part of a larger Web page) about apples, containing two short sections.
<article> <hgroup> <h1>Apples</h1> <h2>Tasty, delicious fruit!</h2> </hgroup> <p>The apple is the pomaceous fruit of the apple tree.</p> <section> <h1>Red Delicious</h1> <p>These bright red apples are the most common found in many supermarkets.</p> </section> <section> <h1>Granny Smith</h1> <p>These juicy, green apples make a great filling for apple pies.</p> </section> </article>
Notice how the use of section
means that the author
can use h1
elements throughout, without having to
worry about whether a particular section is at the top level, the
second level, the third level, and so on.
Here is a graduation programme with two sections, one for the list of people graduating, and one for the description of the ceremony.
<!DOCTYPE Html> <Html ><Head ><Title >Graduation Ceremony Summer 2022</Title ></Head ><Body ><H1 >Graduation</H1 ><Section ><H1 >Ceremony</H1 ><P >Opening Procession</P ><P >Speech by Validactorian</P ><P >Speech by Class President</P ><P >Presentation of Diplomas</P ><P >Closing Speech by Headmaster</P ></Section ><Section ><H1 >Graduates</H1 ><Ul ><Li >Molly Carpenter</Li ><Li >Anastasia Luccio</Li ><Li >Ebenezar McCoy</Li ><Li >Karrin Murphy</Li ><Li >Thomas Raith</Li ><Li >Susan Rodriguez</Li ></Ul ></Section ></Body ></Html>
nav
elementformatBlock
candidate.HTMLElement
.The nav
element represents a section of
a page that links to other pages or to parts within the page: a
section with navigation links.
Not all groups of links on a page need to be in a
nav
element — only sections that consist of major
navigation blocks are appropriate for the nav
element. In particular, it is common for footers to have a short
list of links to various pages of a site, such as the terms of
service, the home page, and a copyright page. The
footer
element alone is sufficient for such cases,
without a nav
element.
User agents (such as screen readers) that are targeted at users who can benefit from navigation information being omitted in the initial rendering, or who can benefit from navigation information being immediately available, can use this element as a way to determine what content on the page to initially skip and/or provide on request.
In the following example, the page has several places where links are present, but only one of those places is considered a navigation section.
<body> <header> <h1>Wake up sheeple!</h1> <p><a href="news.html">News</a> - <a href="blog.html">Blog</a> - <a href="forums.html">Forums</a></p> <p>Last Modified: <time>2009-04-01</time></p> <nav> <h1>Navigation</h1> <ul> <li><a href="articles.html">Index of all articles</a></li> <li><a href="today.html">Things sheeple need to wake up for today</a></li> <li><a href="successes.html">Sheeple we have managed to wake</a></li> </ul> </nav> </header> <div> <article> <header> <h1>My Day at the Beach</h1> </header> <div> <p>Today I went to the beach and had a lot of fun.</p> ...more content... </div> <footer> <p>Posted <time pubdate="" datetime="2009-10-10T14:36-08:00">Thursday</time>.</p> </footer> </article> ...more blog posts... </div> <footer> <p>Copyright © 2006 The Example Company</p> <p><a href="about.html">About</a> - <a href="policy.html">Privacy Policy</a> - <a href="contact.html">Contact Us</a></p> </footer> </body>
Notice the div
elements being used to wrap all the
contents of the page other than the header and footer, and all the
contents of the blog entry other than its header and footer.
In the following example, there are two nav
elements, one for primary navigation around the site, and one for
secondary navigation around the page itself.
<body> <h1>The Wiki Center Of Exampland</h1> <nav> <ul> <li><a href="/">Home</a></li> <li><a href="/events">Current Events</a></li> ...more... </ul> </nav> <article> <header> <h1>Demos in Exampland</h1> <p>Written by A. N. Other.</p> </header> <nav> <ul> <li><a href="#public">Public demonstrations</a></li> <li><a href="#destroy">Demolitions</a></li> ...more... </ul> </nav> <div> <section id="public"> <h1>Public demonstrations</h1> <p>...more...</p> </section> <section id="destroy"> <h1>Demolitions</h1> <p>...more...</p> </section> ...more... </div> <footer> <p><a href="?edit">Edit</a> | <a href="?delete">Delete</a> | <a href="?Rename">Rename</a></p> </footer> </article> <footer> <p><small>© copyright 1998 Exampland Emperor</small></p> </footer> </body>
A nav
element doesn't have to contain a list, it
can contain other kinds of content as well. In this navigation
block, links are provided in prose:
<nav> <h1>Navigation</h1> <p>You are on my home page. To the north lies <a href="/blog">my blog</a>, from whence the sounds of battle can be heard. To the east you can see a large mountain, upon which many <a href="/school">school papers</a> are littered. Far up thus mountain you can spy a little figure who appears to be me, desperately scribbling a <a href="/school/thesis">thesis</a>.</p> <p>To the west are several exits. One fun-looking exit is labeled <a href="http://games.example.com/">"games"</a>. Another more boring-looking exit is labeled <a href="http://isp.example.net/">ISP™</a>.</p> <p>To the south lies a dark and dank <a href="/about">contacts page</a>. Cobwebs cover its disused entrance, and at one point you see a rat run quickly out of the page.</p> </nav>
article
elementformatBlock
candidate.HTMLElement
.The article
element represents a
self-contained composition in a document, page, application, or site
and that is, in principle, independently distributable or reusable,
e.g. in syndication. This could be a forum post, a magazine or
newspaper article, a blog entry, a user-submitted comment, an
interactive widget or gadget, or any other independent item of
content.
When article
elements are nested, the inner
article
elements represent articles that are in
principle related to the contents of the outer article. For
instance, a blog entry on a site that accepts user-submitted
comments could represent the comments as article
elements nested within the article
element for the blog
entry.
Author information associated with an article
element (q.v. the address
element) does not apply to
nested article
elements.
When used specifically with content to be
redistributed in syndication, the article
element is
similar in purpose to the entry
element in
Atom. [ATOM]
The time
element's pubdate
attribute can be used to
provide the publication date for an article
element.
This example shows a blog post using the article
element:
<article> <header> <h1>The Very First Rule of Life</h1> <p><time pubdate datetime="2009-10-09T14:28-08:00"></time></p> </header> <p>If there's a microphone anywhere near you, assume it's hot and sending whatever you're saying to the world. Seriously.</p> <p>...</p> <footer> <a href="?comments=1">Show comments...</a> </footer> </article>
Here is that same blog post, but showing some of the comments:
<article> <header> <h1>The Very First Rule of Life</h1> <p><time pubdate datetime="2009-10-09T14:28-08:00"></time></p> </header> <p>If there's a microphone anywhere near you, assume it's hot and sending whatever you're saying to the world. Seriously.</p> <p>...</p> <section> <h1>Comments</h1> <article> <footer> <p>Posted by: George Washington</p> <p><time pubdate datetime="2009-10-10T19:10-08:00"></time></p> </footer> <p>Yeah! Especially when talking about your lobbyist friends!</p> </article> <article> <footer> <p>Posted by: George Hammond</p> <p><time pubdate datetime="2009-10-10T19:15-08:00"></time></p> </footer> <p>Hey, you have the same first name as me.</p> </article> </section> </article>
Notice the use of footer
to give the information
for each comment (such as who wrote it and when): the
footer
element can appear at the start of its
section when appropriate, such as in this case. (Using
header
in this case wouldn't be wrong either; it's
mostly a matter of authoring preference.)
aside
elementformatBlock
candidate.HTMLElement
.The aside
element represents a section
of a page that consists of content that is tangentially related to
the content around the aside
element, and which could
be considered separate from that content. Such sections are often
represented as sidebars in printed typography.
The element can be used for typographical effects like pull
quotes or sidebars, for advertising, for groups of nav
elements, and for other content that is considered separate from the
main content of the page.
It's not appropriate to use the aside
element just for parentheticals, since those are part of the main
flow of the document.
The following example shows how an aside is used to mark up background material on Switzerland in a much longer news story on Europe.
<aside> <h1>Switzerland</h1> <p>Switzerland, a land-locked country in the middle of geographic Europe, has not joined the geopolitical European Union, though it is a signatory to a number of European treaties.</p> </aside>
The following example shows how an aside is used to mark up a pull quote in a longer article.
... <p>He later joined a large company, continuing on the same work. <q>I love my job. People ask me what I do for fun when I'm not at work. But I'm paid to do my hobby, so I never know what to answer. Some people wonder what they would do if they didn't have to work... but I know what I would do, because I was unemployed for a year, and I filled that time doing exactly what I do now.</q></p> <aside> <q> People ask me what I do for fun when I'm not at work. But I'm paid to do my hobby, so I never know what to answer. </q> </aside> <p>Of course his work — or should that be hobby? — isn't his only passion. He also enjoys other pleasures.</p> ...
The following extract shows how aside
can be used
for blogrolls and other side content on a blog:
<body> <header> <h1>My wonderful blog</h1> <p>My tagline</p> </header> <aside> <!-- this aside contains two sections that are tangentially related to the page, namely, links to other blogs, and links to blog posts from this blog --> <nav> <h1>My blogroll</h1> <ul> <li><a href="http://blog.example.com/">Example Blog</a> </ul> </nav> <nav> <h1>Archives</h1> <ol reversed> <li><a href="/last-post">My last post</a> <li><a href="/first-post">My first post</a> </ol> </nav> </aside> <aside> <!-- this aside is tangentially related to the page also, it contains twitter messages from the blog author --> <h1>Twitter Feed</h1> <blockquote cite="http://twitter.example.net/t31351234"> I'm on vacation, writing my blog. </blockquote> <blockquote cite="http://twitter.example.net/t31219752"> I'm going to go on vacation soon. </blockquote> </aside> <article> <!-- this is a blog post --> <h1>My last post</h1> <p>This is my last post.</p> <footer> <p><a href="/last-post" rel=bookmark>Permalink</a> </footer> </article> <article> <!-- this is also a blog post --> <h1>My first post</h1> <p>This is my first post.</p> <aside> <!-- this aside is about the blog post, since it's inside the <article> element; it would be wrong, for instance, to put the blogroll here, since the blogroll isn't really related to this post specifically, only to the page as a whole --> <h1>Posting</h1> <p>While I'm thinking about it, I wanted to say something about posting. Posting is fun!</p> </aside> <footer> <p><a href="/first-post" rel=bookmark>Permalink</a> </footer> </article> <footer> <nav> <a href="/archives">Archives</a> — <a href="/about">About me</a> — <a href="/copyright">Copyright</a> </nav> </footer> </body>
h1
, h2
,
h3
, h4
,
h5
, and h6
elementsformatBlock
candidate.hgroup
element.interface HTMLHeadingElement : HTMLElement {};
These elements represent headings for their sections.
The semantics and meaning of these elements are defined in the section on headings and sections.
These elements have a rank given by the number in
their name. The h1
element is said to have the highest
rank, the h6
element has the lowest rank, and two
elements with the same name have equal rank.
These two snippets are equivalent:
<body> <h1>Let's call it a draw(ing surface)</h1> <h2>Diving in</h2> <h2>Simple shapes</h2> <h2>Canvas coordinates</h2> <h3>Canvas coordinates diagram</h3> <h2>Paths</h2> </body>
<body> <h1>Let's call it a draw(ing surface)</h1> <section> <h1>Diving in</h1> </section> <section> <h1>Simple shapes</h1> </section> <section> <h1>Canvas coordinates</h1> <section> <h1>Canvas coordinates diagram</h1> </section> </section> <section> <h1>Paths</h1> </section> </body>
hgroup
elementformatBlock
candidate.h1
, h2
, h3
, h4
, h5
, and/or h6
elements.HTMLElement
.The hgroup
element represents the
heading of a section. The element is used to group a set of
h1
–h6
elements when the heading has
multiple levels, such as subheadings, alternative titles, or
taglines.
For the purposes of document summaries, outlines, and the like,
the text of hgroup
elements is defined to be the text
of the highest ranked
h1
–h6
element descendant of the
hgroup
element, if there are any such elements, and the
first such element if there are multiple elements with that
rank. If there are no such elements, then the text of
the hgroup
element is the empty string.
Other elements of heading content in the
hgroup
element indicate subheadings or subtitles.
The rank of an hgroup
element is the
rank of the highest-ranked h1
–h6
element descendant of the hgroup
element, if there are
any such elements, or otherwise the same as for an h1
element (the highest rank).
The section on headings and sections
defines how hgroup
elements are assigned to individual
sections.
Here are some examples of valid headings. In each case, the emphasized text represents the text that would be used as the heading in an application extracting heading data and ignoring subheadings.
<hgroup> <h1>The reality dysfunction</h1> <h2>Space is not the only void</h2> </hgroup>
<hgroup> <h1>Dr. Strangelove</h1> <h2>Or: How I Learned to Stop Worrying and Love the Bomb</h2> </hgroup>
The point of using hgroup
in these examples is to
mask the h2
element (which acts as a secondary title)
from the outline algorithm.
header
elementformatBlock
candidate.header
or
footer
element descendants.HTMLElement
.The header
element represents a group
of introductory or navigational aids.
A header
element is intended to usually
contain the section's heading (an
h1
–h6
element or an
hgroup
element), but this is not required. The
header
element can also be used to wrap a section's
table of contents, a search form, or any relevant logos.
Here are some sample headers. This first one is for a game:
<header> <p>Welcome to...</p> <h1>Voidwars!</h1> </header>
The following snippet shows how the element can be used to mark up a specification's header:
<header> <hgroup> <h1>Scalable Vector Graphics (SVG) 1.2</h1> <h2>W3C Working Draft 27 October 2004</h2> </hgroup> <dl> <dt>This version:</dt> <dd><a href="http://www.w3.org/TR/2004/WD-SVG12-20041027/">http://www.w3.org/TR/2004/WD-SVG12-20041027/</a></dd> <dt>Previous version:</dt> <dd><a href="http://www.w3.org/TR/2004/WD-SVG12-20040510/">http://www.w3.org/TR/2004/WD-SVG12-20040510/</a></dd> <dt>Latest version of SVG 1.2:</dt> <dd><a href="http://www.w3.org/TR/SVG12/">http://www.w3.org/TR/SVG12/</a></dd> <dt>Latest SVG Recommendation:</dt> <dd><a href="http://www.w3.org/TR/SVG/">http://www.w3.org/TR/SVG/</a></dd> <dt>Editor:</dt> <dd>Dean Jackson, W3C, <a href="mailto:dean@w3.org">dean@w3.org</a></dd> <dt>Authors:</dt> <dd>See <a href="#authors">Author List</a></dd> </dl> <p class="copyright"><a href="http://www.w3.org/Consortium/Legal/ipr-notic ... </header>
The header
element is not
sectioning content; it doesn't introduce a new
section.
In this example, the page has a page heading given by the
h1
element, and two subsections whose headings are
given by h2
elements. The content after the
header
element is still part of the last subsection
started in the header
element, because the
header
element doesn't take part in the
outline algorithm.
<body> <header> <h1>Little Green Guys With Guns</h1> <nav> <ul> <li><a href="/games">Games</a> <li><a href="/forum">Forum</a> <li><a href="/download">Download</a> </ul> </nav> <h2>Important News</h2> <!-- this starts a second subsection --> <!-- this is part of the subsection entitled "Important News" --> <p>To play today's games you will need to update your client.</p> <h2>Games</h2> <!-- this starts a third subsection --> </header> <p>You have three active games:</p> <!-- this is still part of the subsection entitled "Games" --> ...
footer
elementformatBlock
candidate.header
or
footer
element descendants.HTMLElement
.The footer
element represents a footer
for its nearest ancestor sectioning content or
sectioning root element. A footer typically contains
information about its section such as who wrote it, links to related
documents, copyright data, and the like.
Contact information for the author or editor of a
section belongs in an address
element, possibly itself
inside a footer
.
Footers don't necessarily have to appear at the end of a section, though they usually do.
When the footer
element contains entire sections,
they represent appendices, indexes,
long colophons, verbose license agreements, and other such
content.
The footer
element is not
sectioning content; it doesn't introduce a new
section.
When the nearest ancestor sectioning content or sectioning root element is the body element, then it applies to the whole page.
Here is a page with two footers, one at the top and one at the bottom, with the same content:
<body> <footer><a href="../">Back to index...</a></footer> <hgroup> <h1>Lorem ipsum</h1> <h2>The ipsum of all lorems</h2> </hgroup> <p>A dolor sit amet, consectetur adipisicing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.</p> <footer><a href="../">Back to index...</a></footer> </body>
Here is an example which shows the footer
element
being used both for a site-wide footer and for a section
footer.
<!DOCTYPE HTML> <HTML><HEAD> <TITLE>The Ramblings of a Scientist</TITLE> <BODY> <H1>The Ramblings of a Scientist</H1> <ARTICLE> <H1>Episode 15</H1> <VIDEO SRC="/fm/015.ogv" CONTROLS PRELOAD> <P><A HREF="/fm/015.ogv">Download video</A>.</P> </VIDEO> <FOOTER> <!-- footer for article --> <P>Published <TIME PUBDATE DATETIME="2009-10-21T18:26-07:00"></TIME></P> </FOOTER> </ARTICLE> <ARTICLE> <H1>My Favorite Trains</H1> <P>I love my trains. My favorite train of all time is a Köf.</P> <P>It is fun to see them pull some coal cars because they look so dwarfed in comparison.</P> <FOOTER> <!-- footer for article --> <P>Published <TIME PUBDATE DATETIME="2009-09-15T14:54-07:00"></TIME></P> </FOOTER> </ARTICLE> <FOOTER> <!-- site wide footer --> <NAV> <P><A HREF="/credits.html">Credits</A> — <A HREF="/tos.html">Terms of Service</A> — <A HREF="/index.html">Blog Index</A></P> </NAV> <P>Copyright © 2009 Gordon Freeman</P> </FOOTER> </BODY> </HTML>
address
elementformatBlock
candidate.header
, footer
, or
address
element descendants.HTMLElement
.The address
element represents the
contact information for its nearest article
or
body
element ancestor. If that is the body
element, then the contact information applies to the document
as a whole.
For example, a page at the W3C Web site related to HTML might include the following contact information:
<ADDRESS> <A href="../People/Raggett/">Dave Raggett</A>, <A href="../People/Arnaud/">Arnaud Le Hors</A>, contact persons for the <A href="Activity">W3C HTML Activity</A> </ADDRESS>
The address
element must not be used to represent
arbitrary addresses (e.g. postal addresses), unless those addresses
are in fact the relevant contact information. (The p
element is the appropriate element for marking up postal addresses
in general.)
The address
element must not contain information
other than contact information.
For example, the following is non-conforming use of the
address
element:
<ADDRESS>Last Modified: 1999/12/24 23:37:50</ADDRESS>
Typically, the address
element would be included
along with other information in a footer
element.
In this example the footer contains contact information and a copyright notice.
<footer> <address> For more details, contact <a href="mailto:js@example.com">John Smith</a>. </address> <p><small>© copyright 2038 Example Corp.</small></p> </footer>
The h1
–h6
elements and the
hgroup
element are headings.
The first element of heading content in an element of sectioning content represents the heading for that section. Subsequent headings of equal or higher rank start new (implied) sections, headings of lower rank start implied subsections that are part of the previous one. In both cases, the element represents the heading of the implied section.
Certain elements are said to be sectioning roots, including blockquote
and
td
elements. These elements can have their own
outlines, but the sections and headings inside these elements do not
contribute to the outlines of their ancestors.
Sectioning content elements are always considered subsections of their nearest ancestor sectioning root or their nearest ancestor element of sectioning content, whichever is nearest, regardless of what implied sections other headings may have created.
For the following fragment:
<body> <h1>Foo</h1> <h2>Bar</h2> <blockquote> <h3>Bla</h3> </blockquote> <p>Baz</p> <h2>Quux</h2> <section> <h3>Thud</h3> </section> <p>Grunt</p> </body>
...the structure would be:
body
section, containing the "Grunt" paragraph)
section
section)
Notice how the section
ends the earlier implicit
section so that a later paragraph ("Grunt") is back at the top
level.
Sections may contain headings of any rank, but
authors are strongly encouraged to either use only h1
elements, or to use elements of the appropriate rank
for the section's nesting level.
Authors are also encouraged to explicitly wrap sections in elements of sectioning content, instead of relying on the implicit sections generated by having multiple headings in one element of sectioning content.
For example, the following is correct:
<body> <h4>Apples</h4> <p>Apples are fruit.</p> <section> <h2>Taste</h2> <p>They taste lovely.</p> <h6>Sweet</h6> <p>Red apples are sweeter than green ones.</p> <h1>Color</h1> <p>Apples come in various colors.</p> </section> </body>
However, the same document would be more clearly expressed as:
<body> <h1>Apples</h1> <p>Apples are fruit.</p> <section> <h2>Taste</h2> <p>They taste lovely.</p> <section> <h3>Sweet</h3> <p>Red apples are sweeter than green ones.</p> </section> </section> <section> <h2>Color</h2> <p>Apples come in various colors.</p> </section> </body>
Both of the documents above are semantically identical and would produce the same outline in compliant user agents.
This third example is also semantically identical, and might be easier to maintain (e.g. if sections are often moved around in editing):
<body> <h1>Apples</h1> <p>Apples are fruit.</p> <section> <h1>Taste</h1> <p>They taste lovely.</p> <section> <h1>Sweet</h1> <p>Red apples are sweeter than green ones.</p> </section> </section> <section> <h1>Color</h1> <p>Apples come in various colors.</p> </section> </body>
The outline for a sectioning content
element or a sectioning root element consists of a list
of one or more potentially nested sections. A section is a container that
corresponds to some nodes in the original DOM tree. Each section can
have one heading associated with it, and can contain any number of
further nested sections. (The sections in the
outline aren't section
elements, though some may
correspond to such elements — they are merely conceptual
sections.)
The following markup fragment:
<body> <h1>A</h1> <p>B</p> <h2>C</h2> <p>D</p> <h2>E</h2> <p>F</p> </body>
...results in the following outline being created for the
body
node (and thus the entire document):
Section created for body
node.
Associated with heading "A".
Also associated with paragraph "B".
Nested sections:
p
elementformatBlock
candidate.interface HTMLParagraphElement : HTMLElement {};
The p
element represents a
paragraph.
While paragraphs are usually represented in visual media by blocks of text that are physically separated from adjacent blocks through blank lines, a style sheet or user agent would be equally justified in presenting paragraph breaks in a different manner, for instance using inline pilcrows (¶).
The following examples are conforming HTML fragments:
<p>The little kitten gently seated himself on a piece of carpet. Later in his life, this would be referred to as the time the cat sat on the mat.</p>
<fieldset> <legend>Personal information</legend> <p> <label>Name: <input name="n"></label> <label><input name="anon" type="checkbox"> Hide from other users</label> </p> <p><label>Address: <textarea name="a"></textarea></label></p> </fieldset>
<p>There was once an example from Femley,<br> Whose markup was of dubious quality.<br> The validator complained,<br> So the author was pained,<br> To move the error from the markup to the rhyming.</p>
The p
element should not be used when a more
specific element is more appropriate.
The following example is technically correct:
<section> <!-- ... --> <p>Last modified: 2001-04-23</p> <p>Author: fred@example.com</p> </section>
However, it would be better marked-up as:
<section> <!-- ... --> <footer>Last modified: 2001-04-23</footer> <address>Author: fred@example.com</address> </section>
Or:
<section> <!-- ... --> <footer> <p>Last modified: 2001-04-23</p> <address>Author: fred@example.com</address> </footer> </section>
hr
elementinterface HTMLHRElement : HTMLElement {};
The hr
element represents a
paragraph-level thematic break, e.g. a scene change in
a story, or a transition to another topic within a section of a
reference book.
The following fictional extract from a project manual shows two
sections that use the hr
element to separate topics
within the section.
<section> <h1>Communication</h1> <p>There are various methods of communication. This section covers a few of the important ones used by the project.</p> <hr> <p>Communication stones seem to come in pairs and have mysterious properties:</p> <ul> <li>They can transfer thoughts in two directions once activated if used alone.</li> <li>If used with another device, they can transfer one's consciousness to another body.</li> <li>If both stones are used with another device, the consciousnesses switch bodies.</li> </ul> <hr> <p>Radios use the electromagnetic spectrum in the meter range and longer.</p> <hr> <p>Signal flares use the electromagnetic spectrum in the nanometer range.</p> </section> <section> <h1>Food</h1> <p>All food at the project is rationed:</p> <dl> <dt>Potatoes</dt> <dd>Two per day</dd> <dt>Soup</dt> <dd>One bowl per day</dd> </dl> <hr> <p>Cooking is done by the chefs on a set rotation.</p> </section>
There is no need for an hr
element between the
sections themselves, since the section
elements and
the h1
elements imply thematic changes themselves.
The following extract from Pandora's Star by Peter
F. Hamilton shows two paragraphs that precede a scene change and
the paragraph that follows it. The scene change, represented in the
printed book by a gap containing a solitary centered star between
the second and third paragraphs, is here represented using the
hr
element.
<p>Dudley was ninety-two, in his second life, and fast approaching
time for another rejuvenation. Despite his body having the physical
age of a standard fifty-year-old, the prospect of a long degrading
campaign within academia was one he regarded with dread. For a
supposedly advanced civilization, the Intersolar Commonwearth could be
appallingly backward at times, not to mention cruel.</p>
<p><i>Maybe it won't be that bad</i>, he told himself. The lie was
comforting enough to get him through the rest of the night's
shift.</p>
<hr>
<p>The Carlton AllLander drove Dudley home just after dawn. Like the
astronomer, the vehicle was old and worn, but perfectly capable of
doing its job. It had a cheap diesel engine, common enough on a
semi-frontier world like Gralmond, although its drive array was a
thoroughly modern photoneural processor. With its high suspension and
deep-tread tyres it could plough along the dirt track to the
observatory in all weather and seasons, including the metre-deep snow
of Gralmond's winters.</p>
The hr
element does not affect the
document's outline.
pre
elementformatBlock
candidate.interface HTMLPreElement : HTMLElement {};
The pre
element represents a block of
preformatted text, in which structure is represented by typographic
conventions rather than by elements.
In the HTML syntax, a leading
newline character immediately following the pre
element
start tag is stripped.
Some examples of cases where the pre
element could
be used:
Authors are encouraged to consider how preformatted text will be experienced when the formatting is lost, as will be the case for users of speech synthesizers, braille displays, and the like. For cases like ASCII art, it is likely that an alternative presentation, such as a textual description, would be more universally accessible to the readers of the document.
To represent a block of computer code, the pre
element can be used with a code
element; to represent a
block of computer output the pre
element can be used
with a samp
element. Similarly, the kbd
element can be used within a pre
element to indicate
text that the user is to enter.
In the following snippet, a sample of computer code is presented.
<p>This is the <code>Panel</code> constructor:</p> <pre><code>function Panel(element, canClose, closeHandler) { this.element = element; this.canClose = canClose; this.closeHandler = function () { if (closeHandler) closeHandler() }; }</code></pre>
In the following snippet, samp
and kbd
elements are mixed in the contents of a pre
element to
show a session of Zork I.
<pre><samp>You are in an open field west of a big white house with a boarded front door. There is a small mailbox here. ></samp> <kbd>open mailbox</kbd> <samp>Opening the mailbox reveals: A leaflet. ></samp></pre>
The following shows a contemporary poem that uses the
pre
element to preserve its unusual formatting, which
forms an intrinsic part of the poem itself.
<pre> maxling it is with a heart heavy that i admit loss of a feline so loved a friend lost to the unknown (night) ~cdr 11dec07</pre>
blockquote
elementformatBlock
candidate.cite
interface HTMLQuoteElement : HTMLElement { attribute DOMString cite; };
The HTMLQuoteElement
interface is
also used by the q
element.
The blockquote
element represents a
section that is quoted from another source.
Content inside a blockquote
must be quoted from
another source, whose address, if it has one, may be cited in the
cite
attribute.
If the cite
attribute
is present, it must be a valid URL potentially surrounded by
spaces.
This next example shows the use of cite
alongside
blockquote
:
<p>His next piece was the aptly named <cite>Sonnet 130</cite>:</p> <blockquote cite="http://quotes.example.org/s/sonnet130.html"> <p>My mistress' eyes are nothing like the sun,<br> Coral is far more red, than her lips red,<br> ...
This example shows how a forum post could use
blockquote
to show what post a user is replying
to. The article
element is used for each post, to mark
up the threading.
<article> <h1><a href="http://bacon.example.com/?blog=109431">Bacon on a crowbar</a></h1> <article> <header><strong>t3yw</strong> 12 points 1 hour ago</header> <p>I bet a narwhal would love that.</p> <footer><a href="?pid=29578">permalink</a></footer> <article> <header><strong>greg</strong> 8 points 1 hour ago</header> <blockquote><p>I bet a narwhal would love that.</p></blockquote> <p>Dude narwhals don't eat bacon.</p> <footer><a href="?pid=29579">permalink</a></footer> <article> <header><strong>t3yw</strong> 15 points 1 hour ago</header> <blockquote> <blockquote><p>I bet a narwhal would love that.</p></blockquote> <p>Dude narwhals don't eat bacon.</p> </blockquote> <p>Next thing you'll be saying they don't get capes and wizard hats either!</p> <footer><a href="?pid=29580">permalink</a></footer> <article> <article> <header><strong>boing</strong> -5 points 1 hour ago</header> <p>narwhals are worse than ceiling cat</p> <footer><a href="?pid=29581">permalink</a></footer> </article> </article> </article> </article> <article> <header><strong>fred</strong> 1 points 23 minutes ago</header> <blockquote><p>I bet a narwhal would love that.</p></blockquote> <p>I bet they'd love to peel a banana too.</p> <footer><a href="?pid=29582">permalink</a></footer> </article> </article> </article>
This example shows the use of a blockquote
for
short snippets, demonstrating that one does not have to use
p
elements inside blockquote
elements:
<p>He began his list of "lessons" with the following:</p> <blockquote>One should never assume that his side of the issue will be recognized, let alone that it will be conceded to have merits.</blockquote> <p>He continued with a number of similar points, ending with:</p> <blockquote>Finally, one should be prepared for the threat of breakdown in negotiations at any given moment and not be cowed by the possiblity.</blockquote> <p>We shall now discuss these points...
Examples of how to
represent a conversation are shown in a later section; it is not
appropriate to use the cite
and blockquote
elements for this purpose.
ol
elementli
elements.reversed
start
type
interface HTMLOListElement : HTMLElement { attribute boolean reversed; attribute long start; attribute DOMString type; };
The ol
element represents a list of
items, where the items have been intentionally ordered, such that
changing the order would change the meaning of the document.
The items of the list are the li
element child nodes
of the ol
element, in tree order.
The reversed
attribute is a boolean attribute. If present, it
indicates that the list is a descending list (..., 3, 2, 1). If the
attribute is omitted, the list is an ascending list (1, 2, 3,
...).
The start
attribute, if present, must be a valid integer giving
the ordinal value of the first list item.
The type
attribute
can be used to specify the kind of marker to use in the list, in the
cases where that matters (e.g. because items are to be referenced by
their number/letter). The attribute, if specified, must have a value
that is a case-sensitive match for one of the
characters given in the first cell of one of the rows of the
following table.
Keyword | State | Description | Examples for values 1-3 and 3999-4001 | |||||||
---|---|---|---|---|---|---|---|---|---|---|
1 (U+0031)
| decimal | Decimal numbers | 1. | 2. | 3. | ... | 3999. | 4000. | 4001. | ... |
a (U+0061)
| lower-alpha | Lowercase latin alphabet | a. | b. | c. | ... | ewu. | ewv. | eww. | ... |
A (U+0041)
| upper-alpha | Uppercase latin alphabet | A. | B. | C. | ... | EWU. | EWV. | EWW. | ... |
i (U+0069)
| lower-roman | Lowercase roman numerals | i. | ii. | iii. | ... | mmmcmxcix. | i̅v̅. | i̅v̅i. | ... |
I (U+0049)
| upper-roman | Uppercase roman numerals | I. | II. | III. | ... | MMMCMXCIX. | I̅V̅. | I̅V̅I. | ... |
The following markup shows a list where the order matters, and
where the ol
element is therefore appropriate. Compare
this list to the equivalent list in the ul
section to
see an example of the same items using the ul
element.
<p>I have lived in the following countries (given in the order of when I first lived there):</p> <ol> <li>Switzerland <li>United Kingdom <li>United States <li>Norway </ol>
Note how changing the order of the list changes the meaning of the document. In the following example, changing the relative order of the first two items has changed the birthplace of the author:
<p>I have lived in the following countries (given in the order of when I first lived there):</p> <ol> <li>United Kingdom <li>Switzerland <li>United States <li>Norway </ol>
ul
elementli
elements.interface HTMLUListElement : HTMLElement {};
The ul
element represents a list of
items, where the order of the items is not important — that
is, where changing the order would not materially change the meaning
of the document.
The items of the list are the li
element child nodes
of the ul
element.
The following markup shows a list where the order does not
matter, and where the ul
element is therefore
appropriate. Compare this list to the equivalent list in the
ol
section to see an example of the same items using
the ol
element.
<p>I have lived in the following countries:</p> <ul> <li>Norway <li>Switzerland <li>United Kingdom <li>United States </ul>
Note that changing the order of the list does not change the meaning of the document. The items in the snippet above are given in alphabetical order, but in the snippet below they are given in order of the size of their current account balance in 2007, without changing the meaning of the document whatsoever:
<p>I have lived in the following countries:</p> <ul> <li>Switzerland <li>Norway <li>United Kingdom <li>United States </ul>
li
elementol
elements.ul
elements.menu
elements.ol
element: value
interface HTMLLIElement : HTMLElement { attribute long value; };
The li
element represents a list
item. If its parent element is an ol
, ul
,
or menu
element, then the element is an item of the
parent element's list, as defined for those elements. Otherwise, the
list item has no defined list-related relationship to any other
li
element.
If the parent element is an ol
element, then the
li
element has an ordinal value.
The value
attribute, if present, must be a valid integer giving
the ordinal value of the list item.
The following example, the top ten movies are listed (in reverse
order). Note the way the list is given a title by using a
figure
element and its figcaption
element.
<figure> <figcaption>The top 10 movies of all time</figcaption> <ol> <li value="10"><cite>Josie and the Pussycats</cite>, 2001</li> <li value="9"><cite lang="sh">Црна мачка, бели мачор</cite>, 1998</li> <li value="8"><cite>A Bug's Life</cite>, 1998</li> <li value="7"><cite>Toy Story</cite>, 1995</li> <li value="6"><cite>Monsters, Inc</cite>, 2001</li> <li value="5"><cite>Cars</cite>, 2006</li> <li value="4"><cite>Toy Story 2</cite>, 1999</li> <li value="3"><cite>Finding Nemo</cite>, 2003</li> <li value="2"><cite>The Incredibles</cite>, 2004</li> <li value="1"><cite>Ratatouille</cite>, 2007</li> </ol> </figure>
The markup could also be written as follows, using the reversed
attribute on the
ol
element:
<figure> <figcaption>The top 10 movies of all time</figcaption> <ol reversed> <li><cite>Josie and the Pussycats</cite>, 2001</li> <li><cite lang="sh">Црна мачка, бели мачор</cite>, 1998</li> <li><cite>A Bug's Life</cite>, 1998</li> <li><cite>Toy Story</cite>, 1995</li> <li><cite>Monsters, Inc</cite>, 2001</li> <li><cite>Cars</cite>, 2006</li> <li><cite>Toy Story 2</cite>, 1999</li> <li><cite>Finding Nemo</cite>, 2003</li> <li><cite>The Incredibles</cite>, 2004</li> <li><cite>Ratatouille</cite>, 2007</li> </ol> </figure>
If the li
element is the child of a
menu
element and itself has a child that defines a
command, then the
li
element will match the :enabled
and :disabled
pseudo-classes in the
same way as the first such child element does.
dl
elementdt
elements followed by one or more dd
elements.interface HTMLDListElement : HTMLElement {};
The dl
element represents an
association list consisting of zero or more name-value groups (a
description list). Each group must consist of one or more names
(dt
elements) followed by one or more values
(dd
elements). Within a single dl
element,
there should not be more than one dt
element for each
name.
Name-value groups may be terms and definitions, metadata topics and values, questions and answers, or any other groups of name-value data.
The values within a group are alternatives; multiple paragraphs
forming part of the same value must all be given within the same
dd
element.
The order of the list of groups, and of the names and values within each group, may be significant.
In the following example, one entry ("Authors") is linked to two values ("John" and "Luke").
<dl> <dt> Authors <dd> John <dd> Luke <dt> Editor <dd> Frank </dl>
In the following example, one definition is linked to two terms.
<dl> <dt lang="en-US"> <dfn>color</dfn> </dt> <dt lang="en-GB"> <dfn>colour</dfn> </dt> <dd> A sensation which (in humans) derives from the ability of the fine structure of the eye to distinguish three differently filtered analyses of a view. </dd> </dl>
The following example illustrates the use of the dl
element to mark up metadata of sorts. At the end of the example,
one group has two metadata labels ("Authors" and "Editors") and two
values ("Robert Rothman" and "Daniel Jackson").
<dl> <dt> Last modified time </dt> <dd> 2004-12-23T23:33Z </dd> <dt> Recommended update interval </dt> <dd> 60s </dd> <dt> Authors </dt> <dt> Editors </dt> <dd> Robert Rothman </dd> <dd> Daniel Jackson </dd> </dl>
The following example shows the dl
element used to
give a set of instructions. The order of the instructions here is
important (in the other examples, the order of the blocks was not
important).
<p>Determine the victory points as follows (use the first matching case):</p> <dl> <dt> If you have exactly five gold coins </dt> <dd> You get five victory points </dd> <dt> If you have one or more gold coins, and you have one or more silver coins </dt> <dd> You get two victory points </dd> <dt> If you have one or more silver coins </dt> <dd> You get one victory point </dd> <dt> Otherwise </dt> <dd> You get no victory points </dd> </dl>
The following snippet shows a dl
element being used
as a glossary. Note the use of dfn
to indicate the
word being defined.
<dl> <dt><dfn>Apartment</dfn>, n.</dt> <dd>An execution context grouping one or more threads with one or more COM objects.</dd> <dt><dfn>Flat</dfn>, n.</dt> <dd>A deflated tire.</dd> <dt><dfn>Home</dfn>, n.</dt> <dd>The user's login directory.</dd> </dl>
The dl
element is inappropriate for
marking up dialogue. Examples of how to
mark up dialogue are shown below.
dt
elementdd
or dt
elements inside dl
elements.HTMLElement
.The dt
element represents the term, or
name, part of a term-description group in a description list
(dl
element).
The dt
element itself, when used in a
dl
element, does not indicate that its contents are a
term being defined, but this can be indicated using the
dfn
element.
This example shows a list of frequently asked questions (a FAQ)
marked up using the dt
element for questions and the
dd
element for answers.
<article> <h1>FAQ</h1> <dl> <dt>What do we want?</dt> <dd>Our data.</dd> <dt>When do we want it?</dt> <dd>Now.</dd> <dt>Where is it?</dt> <dd>We are not sure.</dd> </dl> </article>
dd
elementdt
or dd
elements inside dl
elements.HTMLElement
.The dd
element represents the
description, definition, or value, part of a term-description group
in a description list (dl
element).
A dl
can be used to define a vocabulary list, like
in a dictionary. In the following example, each entry, given by a
dt
with a dfn
, has several
dd
s, showing the various parts of the definition.
<dl> <dt><dfn>happiness</dfn></dt> <dd class="pronunciation">/'hæ p. nes/</dd> <dd class="part-of-speech"><i><abbr>n.</abbr></i></dd> <dd>The state of being happy.</dd> <dd>Good fortune; success. <q>Oh <b>happiness</b>! It worked!</q></dd> <dt><dfn>rejoice</dfn></dt> <dd class="pronunciation">/ri jois'/</dd> <dd><i class="part-of-speech"><abbr>v.intr.</abbr></i> To be delighted oneself.</dd> <dd><i class="part-of-speech"><abbr>v.tr.</abbr></i> To cause one to be delighted.</dd> </dl>
figure
elementfigcaption
element followed by flow content.figcaption
element.HTMLElement
.The figure
element represents some
flow content, optionally with a caption, that is
self-contained and is typically referenced as a single unit from the
main flow of the document.
The element can thus be used to annotate illustrations, diagrams, photos, code listings, etc, that are referred to from the main content of the document, but that could, without affecting the flow of the document, be moved away from that primary content, e.g. to the side of the page, to dedicated pages, or to an appendix.
The figcaption
element child of the element, if any, represents the caption of the
figure
element's contents. If there is no child
figcaption
element, then there is no caption.
This example shows the figure
element to mark up a
code listing.
<p>In <a href="#l4">listing 4</a> we see the primary core interface API declaration.</p> <figure id="l4"> <figcaption>Listing 4. The primary core interface API declaration.</figcaption> <pre><code>interface PrimaryCore { boolean verifyDataLine(); void sendData(in sequence<byte> data); void initSelfDestruct(); }</code></pre> </figure> <p>The API is designed to use UTF-8.</p>
Here we see a figure
element to mark up a
photo.
<figure> <img src="bubbles-work.jpeg" alt="Bubbles, sitting in his office chair, works on his latest project intently."> <figcaption>Bubbles at work</figcaption> </figure>
In this example, we see an image that is not a figure, as well as an image and a video that are.
<h2>Malinko's comics</h2> <p>This case centered on some sort of "intellectual property" infringement related to a comic (see Exhibit A). The suit started after a trailer ending with these words: <blockquote> <img src="promblem-packed-action.png" alt="ROUGH COPY! Promblem-Packed Action!"> </blockquote> <p>...was aired. A lawyer, armed with a Bigger Notebook, launched a preemptive strike using snowballs. A complete copy of the trailer is included with Exhibit B. <figure> <img src="ex-a.png" alt="Two squiggles on a dirty piece of paper."> <figcaption>Exhibit A. The alleged <cite>rough copy</cite> comic.</figcaption> </figure> <figure> <video src="ex-b.mov"></video> <figcaption>Exhibit B. The <cite>Rough Copy</cite> trailer.</figcaption> </figure> <p>The case was resolved out of court.
Here, a part of a poem is marked up using
figure
.
<figure> <p>'Twas brillig, and the slithy toves<br> Did gyre and gimble in the wabe;<br> All mimsy were the borogoves,<br> And the mome raths outgrabe.</p> <figcaption><cite>Jabberwocky</cite> (first verse). Lewis Carroll, 1832-98</figcaption> </figure>
In this example, which could be part of a much larger work discussing a castle, the figure has three images in it.
<figure> <img src="castle1423.jpeg" title="Etching. Anonymous, ca. 1423." alt="The castle has one tower, and a tall wall around it."> <img src="castle1858.jpeg" title="Oil-based paint on canvas. Maria Towle, 1858." alt="The castle now has two towers and two walls."> <img src="castle1999.jpeg" title="Film photograph. Peter Jankle, 1999." alt="The castle lies in ruins, the original tower all that remains in one piece."> <figcaption>The castle through the ages: 1423, 1858, and 1999 respectively.</figcaption> </figure>
figcaption
elementfigure
element.HTMLElement
.The figcaption
element represents a
caption or legend for the rest of the contents of the
figcaption
element's parent figure
element.
div
elementformatBlock
candidate.interface HTMLDivElement : HTMLElement {};
The div
element has no special meaning at all. It
represents its children. It can be used with the class
, lang
, and title
attributes to mark up semantics
common to a group of consecutive elements.
Authors are strongly encouraged to view the
div
element as an element of last resort, for when no
other element is suitable. Use of the div
element
instead of more appropriate elements leads to poor accessibility for
readers and poor maintainability for authors.
For example, a blog post would be marked up using
article
, a chapter using section
, a
page's navigation aids using nav
, and a group of form
controls using fieldset
.
On the other hand, div
elements can be useful for
stylistic purposes or to wrap multiple paragraphs within a section
that are all to be annotated in a similar way. In the following
example, we see div
elements used as a way to set the
language of two paragraphs at once, instead of setting the language
on the two paragraph elements separately:
<article lang="en-US"> <h1>My use of language and my cats</h1> <p>My cat's behavior hasn't changed much since her absence, except that she plays her new physique to the neighbors regularly, in an attempt to get pets.</p> <div lang="en-GB"> <p>My other cat, coloured black and white, is a sweetie. He followed us to the pool today, walking down the pavement with us. Yesterday he apparently visited our neighbours. I wonder if he recognises that their flat is a mirror image of ours.</p> <p>Hm, I just noticed that in the last paragraph I used British English. But I'm supposed to write in American English. So I shouldn't say "pavement" or "flat" or "colour"...</p> </div> <p>I should say "sidewalk" and "apartment" and "color"!</p> </article>
a
elementhref
target
rel
media
hreflang
type
interface HTMLAnchorElement : HTMLElement { stringifier attribute DOMString href; attribute DOMString target; attribute DOMString rel; readonly attribute DOMTokenList relList; attribute DOMString media; attribute DOMString hreflang; attribute DOMString type; attribute DOMString text; // URL decomposition IDL attributes attribute DOMString protocol; attribute DOMString host; attribute DOMString hostname; attribute DOMString port; attribute DOMString pathname; attribute DOMString search; attribute DOMString hash; };
If the a
element has an href
attribute, then it
represents a hyperlink (a hypertext
anchor).
If the a
element has no href
attribute, then the element
represents a placeholder for where a link might
otherwise have been placed, if it had been relevant.
The target
,
rel
, media
, hreflang
, and type
attributes must be omitted
if the href
attribute is
not present.
If a site uses a consistent navigation toolbar on every page,
then the link that would normally link to the page itself could be
marked up using an a
element:
<nav> <ul> <li> <a href="/">Home</a> </li> <li> <a href="/news">News</a> </li> <li> <a>Examples</a> </li> <li> <a href="/legal">Legal</a> </li> </ul> </nav>
text
Same as textContent
.
The a
element may be wrapped around entire
paragraphs, lists, tables, and so forth, even entire sections, so
long as there is no interactive content within (e.g. buttons or
other links). This example shows how this can be used to make an
entire advertising block into a link:
<aside class="advertising"> <h1>Advertising</h1> <a href="http://ad.example.com/?adid=1929&pubid=1422"> <section> <h1>Mellblomatic 9000!</h1> <p>Turn all your widgets into mellbloms!</p> <p>Only $9.99 plus shipping and handling.</p> </section> </a> <a href="http://ad.example.com/?adid=375&pubid=1422"> <section> <h1>The Mellblom Browser</h1> <p>Web browsing at the speed of light.</p> <p>No other browser goes faster!</p> </section> </a> </aside>
em
elementHTMLElement
.The em
element represents stress
emphasis of its contents.
The level of emphasis that a particular piece of content has is
given by its number of ancestor em
elements.
The placement of emphasis changes the meaning of the sentence. The element thus forms an integral part of the content. The precise way in which emphasis is used in this way depends on the language.
These examples show how changing the emphasis changes the meaning. First, a general statement of fact, with no emphasis:
<p>Cats are cute animals.</p>
By emphasizing the first word, the statement implies that the kind of animal under discussion is in question (maybe someone is asserting that dogs are cute):
<p><em>Cats</em> are cute animals.</p>
Moving the emphasis to the verb, one highlights that the truth of the entire sentence is in question (maybe someone is saying cats are not cute):
<p>Cats <em>are</em> cute animals.</p>
By moving it to the adjective, the exact nature of the cats is reasserted (maybe someone suggested cats were mean animals):
<p>Cats are <em>cute</em> animals.</p>
Similarly, if someone asserted that cats were vegetables, someone correcting this might emphasize the last word:
<p>Cats are cute <em>animals</em>.</p>
By emphasizing the entire sentence, it becomes clear that the speaker is fighting hard to get the point across. This kind of emphasis also typically affects the punctuation, hence the exclamation mark here.
<p><em>Cats are cute animals!</em></p>
Anger mixed with emphasizing the cuteness could lead to markup such as:
<p><em>Cats are <em>cute</em> animals!</em></p>
The em
element isn't a generic "italics"
element. Sometimes, text is intended to stand out from the rest of
the paragraph, as if it was in a different mood or voice. For this,
the i
element is more appropriate.
The em
element also isn't intended to convey
importance; for that purpose, the strong
element is
more appropriate.
strong
elementHTMLElement
.The strong
element represents strong
importance for its contents.
The relative level of importance of a piece of content is given
by its number of ancestor strong
elements; each
strong
element increases the importance of its
contents.
Changing the importance of a piece of text with the
strong
element does not change the meaning of the
sentence.
Here is an example of a warning notice in a game, with the various parts marked up according to how important they are:
<p><strong>Warning.</strong> This dungeon is dangerous. <strong>Avoid the ducks.</strong> Take any gold you find. <strong><strong>Do not take any of the diamonds</strong>, they are explosive and <strong>will destroy anything within ten meters.</strong></strong> You have been warned.</p>
small
elementHTMLElement
.The small
element represents side
comments such as small print.
Small print typically features disclaimers, caveats, legal restrictions, or copyrights. Small print is also sometimes used for attribution, or for satisfying licensing requirements.
The small
element does not
"de-emphasize" or lower the importance of text emphasized by the
em
element or marked as important with the
strong
element. To mark text as not emphasized or
important, simply do not mark it up with the em
or
strong
elements respectively.
The small
element should not be used for extended
spans of text, such as multiple paragraphs, lists, or sections of
text. It is only intended for short runs of text. The text of a page
listing terms of use, for instance, would not be a suitable
candidate for the small
element: in such a case, the
text is not a side comment, it is the main content of the page.
In this example, the small
element is used to
indicate that value-added tax is not included in a price of a hotel
room:
<dl> <dt>Single room <dd>199 € <small>breakfast included, VAT not included</small> <dt>Double room <dd>239 € <small>breakfast included, VAT not included</small> </dl>
In this second example, the small
element is used
for a side comment in an article.
<p>Example Corp today announced record profits for the second quarter <small>(Full Disclosure: Foo News is a subsidiary of Example Corp)</small>, leading to speculation about a third quarter merger with Demo Group.</p>
This is distinct from a sidebar, which might be multiple paragraphs long and is removed from the main flow of text. In the following example, we see a sidebar from the same article. This sidebar also has small print, indicating the source of the information in the sidebar.
<aside> <h1>Example Corp</h1> <p>This company mostly creates small software and Web sites.</p> <p>The Example Corp company mission is "To provide entertainment and news on a sample basis".</p> <p><small>Information obtained from <a href="http://example.com/about.html">example.com</a> home page.</small></p> </aside>
In this last example, the small
element is marked
as being important small print.
<p><strong><small>Continued use of this service will result in a kiss.</small></strong></p>
s
elementHTMLElement
.The s
element represents contents that
are no longer accurate or no longer relevant.
The s
element is not appropriate when
indicating document edits; to mark a span of text as having been
removed from a document, use the del
element.
In this example a recommended retail price has been marked as no longer relevant as the product in question has a new sale price.
<p>Buy our Iced Tea and Lemonade!</p> <p><s>Recommended retail price: $3.99 per bottle</s></p> <p><strong>Now selling for just $2.99 a bottle!</strong></p>
cite
elementHTMLElement
.The cite
element represents the title
of a work (e.g.
a book,
a paper,
an essay,
a poem,
a score,
a song,
a script,
a film,
a TV show,
a game,
a sculpture,
a painting,
a theatre production,
a play,
an opera,
a musical,
an exhibition,
a legal case report,
etc). This can be a work that is being quoted or
referenced in detail (i.e. a citation), or it can just be a work
that is mentioned in passing.
A person's name is not the title of a work — even if people
call that person a piece of work — and the element must
therefore not be used to mark up people's names. (In some cases, the
b
element might be appropriate for names; e.g. in a
gossip article where the names of famous people are keywords
rendered with a different style to draw attention to them. In other
cases, if an element is really needed, the
span
element can be used.)
This next example shows a typical use of the cite
element:
<p>My favorite book is <cite>The Reality Dysfunction</cite> by Peter F. Hamilton. My favorite comic is <cite>Pearls Before Swine</cite> by Stephan Pastis. My favorite track is <cite>Jive Samba</cite> by the Cannonball Adderley Sextet.</p>
This is correct usage:
<p>According to the Wikipedia article <cite>HTML</cite>, as it stood in mid-February 2008, leaving attribute values unquoted is unsafe. This is obviously an over-simplification.</p>
The following, however, is incorrect usage, as the
cite
element here is containing far more than the
title of the work:
<!-- do not copy this example, it is an example of bad usage! --> <p>According to <cite>the Wikipedia article on HTML</cite>, as it stood in mid-February 2008, leaving attribute values unquoted is unsafe. This is obviously an over-simplification.</p>
The cite
element is obviously a key part of any
citation in a bibliography, but it is only used to mark the
title:
<p><cite>Universal Declaration of Human Rights</cite>, United Nations, December 1948. Adopted by General Assembly resolution 217 A (III).</p>
A citation is not a quote (for
which the q
element is appropriate).
This is incorrect usage, because cite
is not for
quotes:
<p><cite>This is wrong!</cite>, said Ian.</p>
This is also incorrect usage, because a person is not a work:
<p><q>This is still wrong!</q>, said <cite>Ian</cite>.</p>
The correct usage does not use a cite
element:
<p><q>This is correct</q>, said Ian.</p>
As mentioned above, the b
element might be relevant
for marking names as being keywords in certain kinds of
documents:
<p>And then <b>Ian</b> said <q>this might be right, in a gossip column, maybe!</q>.</p>
q
elementcite
HTMLQuoteElement
.The q
element represents some phrasing content quoted from another
source.
Quotation punctuation (such as quotation marks) that is quoting
the contents of the element must not appear immediately before,
after, or inside q
elements; they will be inserted into
the rendering by the user agent.
Content inside a q
element must be quoted from
another source, whose address, if it has one, may be cited in the
cite
attribute. The
source may be fictional, as when quoting characters in a novel or
screenplay.
If the cite
attribute is
present, it must be a valid URL potentially surrounded by
spaces.
The q
element must not be used in place of quotation
marks that do not represent quotes; for example, it is inappropriate
to use the q
element for marking up sarcastic
statements.
The use of q
elements to mark up quotations is
entirely optional; using explicit quotation punctuation without
q
elements is just as correct.
Here is a simple example of the use of the q
element:
<p>The man said <q>Things that are impossible just take longer</q>. I disagreed with him.</p>
Here is an example with both an explicit citation link in the
q
element, and an explicit citation outside:
<p>The W3C page <cite>About W3C</cite> says the W3C's mission is <q cite="http://www.w3.org/Consortium/">To lead the World Wide Web to its full potential by developing protocols and guidelines that ensure long-term growth for the Web</q>. I disagree with this mission.</p>
In the following example, the quotation itself contains a quotation:
<p>In <cite>Example One</cite>, he writes <q>The man said <q>Things that are impossible just take longer</q>. I disagreed with him</q>. Well, I disagree even more!</p>
In the following example, quotation marks are used instead of
the q
element:
<p>His best argument was ❝I disagree❞, which I thought was laughable.</p>
In the following example, there is no quote — the
quotation marks are used to name a word. Use of the q
element in this case would be inappropriate.
<p>The word "ineffable" could have been used to describe the disaster resulting from the campaign's mismanagement.</p>
dfn
elementdfn
element descendants.title
attribute has special semantics on this element.HTMLElement
.The dfn
element represents the defining
instance of a term. The paragraph,
description list group, or section that is the nearest
ancestor of the dfn
element must also contain the
definition(s) for the term given
by the dfn
element.
Defining term: If the dfn
element has a
title
attribute, then
the exact value of that attribute is the term being defined.
Otherwise, if it contains exactly one element child node and no
child text nodes, and that child
element is an abbr
element with a title
attribute, then the exact value
of that attribute is the term being defined. Otherwise, it
is the exact textContent
of the dfn
element that gives the term being defined.
If the title
attribute of the
dfn
element is present, then it must contain only the
term being defined.
The title
attribute
of ancestor elements does not affect dfn
elements.
An a
element that links to a dfn
element represents an instance of the term defined by the
dfn
element.
In the following fragment, the term "GDO" is first defined in the first paragraph, then used in the second.
<p>The <dfn><abbr title="Garage Door Opener">GDO</abbr></dfn> is a device that allows off-world teams to open the iris.</p> <!-- ... later in the document: --> <p>Teal'c activated his <abbr title="Garage Door Opener">GDO</abbr> and so Hammond ordered the iris to be opened.</p>
With the addition of an a
element, the reference
can be made explicit:
<p>The <dfn id=gdo><abbr title="Garage Door Opener">GDO</abbr></dfn> is a device that allows off-world teams to open the iris.</p> <!-- ... later in the document: --> <p>Teal'c activated his <a href=#gdo><abbr title="Garage Door Opener">GDO</abbr></a> and so Hammond ordered the iris to be opened.</p>
abbr
elementtitle
attribute has special semantics on this element.HTMLElement
.The abbr
element represents an
abbreviation or acronym, optionally with its expansion. The title
attribute may be
used to provide an expansion of the abbreviation. The attribute, if
specified, must contain an expansion of the abbreviation, and
nothing else.
The paragraph below contains an abbreviation marked up with the
abbr
element. This paragraph defines the term "Web Hypertext Application Technology
Working Group".
<p>The <dfn id=whatwg><abbr title="Web Hypertext Application Technology Working Group">WHATWG</abbr></dfn> is a loose unofficial collaboration of Web browser manufacturers and interested parties who wish to develop new technologies designed to allow authors to write and deploy Applications over the World Wide Web.</p>
An alternative way to write this would be:
<p>The <dfn id=whatwg>Web Hypertext Application Technology Working Group</dfn> (<abbr title="Web Hypertext Application Technology Working Group">WHATWG</abbr>) is a loose unofficial collaboration of Web browser manufacturers and interested parties who wish to develop new technologies designed to allow authors to write and deploy Applications over the World Wide Web.</p>
This paragraph has two abbreviations. Notice how only one is
defined; the other, with no expansion associated with it, does not
use the abbr
element.
<p>The <abbr title="Web Hypertext Application Technology Working Group">WHATWG</abbr> started working on HTML5 in 2004.</p>
This paragraph links an abbreviation to its definition.
<p>The <a href="#whatwg"><abbr title="Web Hypertext Application Technology Working Group">WHATWG</abbr></a> community does not have much representation from Asia.</p>
This paragraph marks up an abbreviation without giving an expansion, possibly as a hook to apply styles for abbreviations (e.g. smallcaps).
<p>Philip` and Dashiva both denied that they were going to get the issue counts from past revisions of the specification to backfill the <abbr>WHATWG</abbr> issue graph.</p>
If an abbreviation is pluralized, the expansion's grammatical number (plural vs singular) must match the grammatical number of the contents of the element.
Here the plural is outside the element, so the expansion is in the singular:
<p>Two <abbr title="Working Group">WG</abbr>s worked on this specification: the <abbr>WHATWG</abbr> and the <abbr>HTMLWG</abbr>.</p>
Here the plural is inside the element, so the expansion is in the plural:
<p>Two <abbr title="Working Groups">WGs</abbr> worked on this specification: the <abbr>WHATWG</abbr> and the <abbr>HTMLWG</abbr>.</p>
Abbreviations do not have to be marked up using this element. It is expected to be useful in the following cases:
abbr
element with a title
attribute is an alternative to
including the expansion inline (e.g. in parentheses).abbr
element with a title
attribute or include the expansion
inline in the text the first time the abbreviation is used.abbr
element
can be used without a title
attribute.Providing an expansion in a title
attribute once will not necessarily
cause other abbr
elements in the same document with the
same contents but without a title
attribute to behave as if they had the same expansion. Every
abbr
element is independent.
time
elementtime
element descendants.datetime
pubdate
interface HTMLTimeElement : HTMLElement {
attribute DOMString dateTime;
attribute boolean pubDate;
readonly attribute Date valueAsDate;
};
The time
element represents either a
time on a 24 hour clock, or a precise date in the proleptic
Gregorian calendar, optionally with a time and a time-zone
offset. [GREGORIAN]
This element is intended as a way to encode modern dates and times in a machine-readable way so that, for example, user agents can offer to add birthday reminders or scheduled events to the user's calendar.
The time
element is not intended for encoding times
for which a precise date or time cannot be established. For
example, it would be inappropriate for encoding times like "one
millisecond after the big bang", "the early part of the Jurassic
period", or "a winter around 250 BCE".
For dates before the introduction of the Gregorian calendar,
authors are encouraged to not use the time
element, or
else to be very careful about converting dates and times from the
period to the Gregorian calendar. This is complicated by the manner
in which the Gregorian calendar was phased in, which occurred at
different times in different countries, ranging from partway
through the 16th century all the way to early in the 20th.
The pubdate
attribute is a boolean attribute. If specified, it
indicates that the date and time given by the element is the
publication date and time of the nearest ancestor
article
element, or, if the element has no ancestor
article
element, of the document as a whole. If the
element has a pubdate
attribute specified, then the element needs a date. For
each article
element, there must be no more than one
time
element with a pubdate
attribute whose nearest
ancestor is that article
element. Furthermore, for each
Document
, there must be no more than one
time
element with a pubdate
attribute that does not
have an ancestor article
element.
The datetime
attribute, if present, gives the date or time being
specified. Otherwise, the date or time is given by the element's
contents.
If the element needs a date, and the datetime
attribute is present,
then the attribute's value must be a valid date string with
optional time.
If the element needs a date, but the datetime
attribute is not present,
then the element's textContent
must be a valid
date string in content with optional time.
If the element does not need a date,
and the datetime
attribute
is present, then the attribute's value must be a valid date or
time string.
If the element does not need a date,
but the datetime
attribute
is not present, then the element's textContent
must be
a valid date or time string in content.
The date, if any, must be expressed using the Gregorian calendar.
The time
element can be used to encode dates, for
example in Microformats. The following shows a hypothetical way of
encoding an event using a variant on hCalendar that uses the
time
element:
<div class="vevent"> <a class="url" href="http://www.web2con.com/">http://www.web2con.com/</a> <span class="summary">Web 2.0 Conference</span>: <time class="dtstart" datetime="2007-10-05">October 5</time> - <time class="dtend" datetime="2007-10-20">19</time>, at the <span class="location">Argent Hotel, San Francisco, CA</span> </div>
(The end date is encoded as one day after the last date of the event because in the iCalendar format, end dates are exclusive, not inclusive.)
The time
element is not necessary for encoding
dates or times. In the following snippet, the time is encoded using
time
, so that it can be restyled (e.g. using XBL2) to
match local conventions, while the year is not marked up at all,
since marking it up would not be particularly useful, and doing so
is thus not allowed.
<p>I usually have a snack at <time>16:00</time>.</p> <p>I've liked model trains since at least 1983.</p>
Using a styling technology that supports restyling times, the first paragraph from the above snippet could be rendered as follows:
I usually have a snack at 4pm.
Or it could be rendered as follows:
I usually have a snack at 16h00.
valueAsDate
Returns a Date
object representing the specified date and time.
In the following snippet:
<p>Our first date was <time datetime="2006-09-23">a Saturday</time>.</p>
...the time
element's valueAsDate
attribute would
have the value 1,158,969,600,000ms.
In the following snippet:
<p>Many people get up at <time>08:00</time>.</p>
...the time
element's valueAsDate
attribute would
have the value 28,800,000ms.
In this example, an article's publication date is marked up
using time
:
<article> <h1>Small tasks</h1> <footer>Published <time pubdate>2009-08-30</time>.</footer> <p>I put a bike bell on his bike.</p> </article>
Here is another way that could be marked up. In this example, legacy user agents would say "today", while newer user agents would render the time in a locale-specific manner based on the value of the attribute.
<article> <h1>Small tasks</h1> <footer>Published <time pubdate datetime="2009-08-30">today</time>.</footer> <p>I put a bike bell on his bike.</p> </article>
Here is the same thing but with the time included only. Because the element is empty, legacy user agents will not show anything useful; user agents that implement this specification, on the other hand, would show the date and time in a locale-specific manner.
<article> <h1>Small tasks</h1> <footer>Published <time pubdate datetime="2009-08-30T07:13Z"></time>.</footer> <p>I put a bike bell on his bike.</p> </article>
code
elementHTMLElement
.The code
element represents a fragment
of computer code. This could be an XML element name, a filename, a
computer program, or any other string that a computer would
recognize.
Although there is no formal way to indicate the language of
computer code being marked up, authors who wish to mark
code
elements with the language used, e.g. so that
syntax highlighting scripts can use the right rules, may do so by
adding a class prefixed with "language-
" to
the element.
The following example shows how the element can be used in a paragraph to mark up element names and computer code, including punctuation.
<p>The <code>code</code> element represents a fragment of computer code.</p> <p>When you call the <code>activate()</code> method on the <code>robotSnowman</code> object, the eyes glow.</p> <p>The example below uses the <code>begin</code> keyword to indicate the start of a statement block. It is paired with an <code>end</code> keyword, which is followed by the <code>.</code> punctuation character (full stop) to indicate the end of the program.</p>
The following example shows how a block of code could be marked
up using the pre
and code
elements.
<pre><code class="language-pascal">var i: Integer; begin i := 1; end.</code></pre>
A class is used in that example to indicate the language used.
See the pre
element for more details.
var
elementHTMLElement
.The var
element represents a
variable. This could be an actual variable in a mathematical
expression or programming context, or it could just be a term used
as a placeholder in prose.
In the paragraph below, the letter "n" is being used as a variable in prose:
<p>If there are <var>n</var> pipes leading to the ice cream factory then I expect at <em>least</em> <var>n</var> flavors of ice cream to be available for purchase!</p>
For mathematics, in particular for anything beyond the simplest
of expressions, MathML is more appropriate. However, the
var
element can still be used to refer to specific
variables that are then mentioned in MathML expressions.
In this example, an equation is shown, with a legend that
references the variables in the equation. The expression itself is
marked up with MathML, but the variables are mentioned in the
figure's legend using var
.
<figure> <math> <mi>a</mi> <mo>=</mo> <msqrt> <msup><mi>b</mi><mn>2</mn></msup> <mi>+</mi> <msup><mi>c</mi><mn>2</mn></msup> </msqrt> </math> <figcaption> Using Pythagoras' theorem to solve for the hypotenuse <var>a</var> of a triangle with sides <var>b</var> and <var>c</var> </figcaption> </figure>
samp
elementHTMLElement
.The samp
element represents (sample)
output from a program or computing system.
See the pre
and kbd
elements for more details.
This example shows the samp
element being used
inline:
<p>The computer said <samp>Too much cheese in tray two</samp> but I didn't know what that meant.</p>
This second example shows a block of sample output. Nested
samp
and kbd
elements allow for the
styling of specific elements of the sample output using a
style sheet.
<pre><samp><span class="prompt">jdoe@mowmow:~$</span> <kbd>ssh demo.example.com</kbd> Last login: Tue Apr 12 09:10:17 2005 from mowmow.example.com on pts/1 Linux demo 2.6.10-grsec+gg3+e+fhs6b+nfs+gr0501+++p3+c4a+gr2b-reslog-v6.189 #1 SMP Tue Feb 1 11:22:36 PST 2005 i686 unknown <span class="prompt">jdoe@demo:~$</span> <span class="cursor">_</span></samp></pre>
kbd
elementHTMLElement
.The kbd
element represents user input
(typically keyboard input, although it may also be used to represent
other input, such as voice commands).
When the kbd
element is nested inside a
samp
element, it represents the input as it was echoed
by the system.
When the kbd
element contains a
samp
element, it represents input based on system
output, for example invoking a menu item.
When the kbd
element is nested inside another
kbd
element, it represents an actual key or other
single unit of input as appropriate for the input mechanism.
Here the kbd
element is used to indicate keys to press:
<p>To make George eat an apple, press <kbd><kbd>Shift</kbd>+<kbd>F3</kbd></kbd></p>
In this second example, the user is told to pick a particular
menu item. The outer kbd
element marks up a block of
input, with the inner kbd
elements representing each
individual step of the input, and the samp
elements
inside them indicating that the steps are input based on something
being displayed by the system, in this case menu labels:
<p>To make George eat an apple, select <kbd><kbd><samp>File</samp></kbd>|<kbd><samp>Eat Apple...</samp></kbd></kbd> </p>
Such precision isn't necessary; the following is equally fine:
<p>To make George eat an apple, select <kbd>File | Eat Apple...</kbd></p>
sub
and sup
elementsHTMLElement
.The sup
element represents a
superscript and the sub
element represents
a subscript.
These elements must be used only to mark up typographical
conventions with specific meanings, not for typographical
presentation for presentation's sake. For example, it would be
inappropriate for the sub
and sup
elements
to be used in the name of the LaTeX document preparation system. In
general, authors should use these elements only if the
absence of those elements would change the meaning of the
content.
In certain languages, superscripts are part of the typographical conventions for some abbreviations.
<p>The most beautiful women are <span lang="fr"><abbr>M<sup>lle</sup></abbr> Gwendoline</span> and <span lang="fr"><abbr>M<sup>me</sup></abbr> Denise</span>.</p>
The sub
element can be used inside a
var
element, for variables that have subscripts.
Here, the sub
element is used to represents the
subscript that identifies the variable in a family of
variables:
<p>The coordinate of the <var>i</var>th point is (<var>x<sub><var>i</var></sub></var>, <var>y<sub><var>i</var></sub></var>). For example, the 10th point has coordinate (<var>x<sub>10</sub></var>, <var>y<sub>10</sub></var>).</p>
Mathematical expressions often use subscripts and superscripts.
Authors are encouraged to use MathML for marking up mathematics, but
authors may opt to use sub
and sup
if
detailed mathematical markup is not desired. [MATHML]
<var>E</var>=<var>m</var><var>c</var><sup>2</sup>
f(<var>x</var>, <var>n</var>) = log<sub>4</sub><var>x</var><sup><var>n</var></sup>
i
elementHTMLElement
.The i
element represents a span of text
in an alternate voice or mood, or otherwise offset from the normal
prose, such as a taxonomic designation, a technical term, an
idiomatic phrase from another language, a thought, a ship name, or
some other prose whose typical typographic presentation is
italicized.
Terms in languages different from the main text should be
annotated with lang
attributes (or,
in XML, lang
attributes in the XML namespace).
The examples below show uses of the i
element:
<p>The <i class="taxonomy">Felis silvestris catus</i> is cute.</p> <p>The term <i>prose content</i> is defined above.</p> <p>There is a certain <i lang="fr">je ne sais quoi</i> in the air.</p>
In the following example, a dream sequence is marked up using
i
elements.
<p>Raymond tried to sleep.</p> <p><i>The ship sailed away on Thursday</i>, he dreamt. <i>The ship had many people aboard, including a beautiful princess called Carey. He watched her, day-in, day-out, hoping she would notice him, but she never did.</i></p> <p><i>Finally one night he picked up the courage to speak with her—</i></p> <p>Raymond woke with a start as the fire alarm rang out.</p>
Authors can use the class
attribute on the i
element to identify why the element
is being used, so that if the style of a particular use (e.g. dream
sequences as opposed to taxonomic terms) is to be changed at a later
date, the author doesn't have to go through the entire document (or
series of related documents) annotating each use.
Authors are encouraged to consider whether other elements might
be more applicable than the i
element, for instance the
em
element for marking up stress emphasis, or the
dfn
element to mark up the defining instance of a
term.
Style sheets can be used to format i
elements, just like any other element can be restyled. Thus, it is
not the case that content in i
elements will
necessarily be italicized.
b
elementHTMLElement
.The b
element represents a span of text
to be stylistically offset from the normal prose without conveying
any extra importance, such as key words in a document abstract,
product names in a review, or other spans of text whose typical
typographic presentation is boldened.
The following example shows a use of the b
element
to highlight key words without marking them up as important:
<p>The <b>frobonitor</b> and <b>barbinator</b> components are fried.</p>
In the following example, objects in a text adventure are
highlighted as being special by use of the b
element.
<p>You enter a small room. Your <b>sword</b> glows brighter. A <b>rat</b> scurries past the corner wall.</p>
Another case where the b
element is appropriate is
in marking up the lede (or lead) sentence or paragraph. The
following example shows how a BBC
article about kittens adopting a rabbit as their own could be
marked up:
<article> <h2>Kittens 'adopted' by pet rabbit</h2> <p><b class="lede">Six abandoned kittens have found an unexpected new mother figure — a pet rabbit.</b></p> <p>Veterinary nurse Melanie Humble took the three-week-old kittens to her Aberdeen home.</p> [...]
As with the i
element, authors can use the class
attribute on the b
element to identify why the element is being used, so that if the
style of a particular use is to be changed at a later date, the
author doesn't have to go through annotating each use.
The b
element should be used as a last resort when
no other element is more appropriate. In particular, headings should
use the h1
to h6
elements, stress emphasis
should use the em
element, importance should be denoted
with the strong
element, and text marked or highlighted
should use the mark
element.
The following would be incorrect usage:
<p><b>WARNING!</b> Do not frob the barbinator!</p>
In the previous example, the correct element to use would have
been strong
, not b
.
Style sheets can be used to format b
elements, just like any other element can be restyled. Thus, it is
not the case that content in b
elements will
necessarily be boldened.
mark
elementHTMLElement
.The mark
element represents a run of
text in one document marked or highlighted for reference purposes,
due to its relevance in another context. When used in a quotation or
other block of text referred to from the prose, it indicates a
highlight that was not originally present but which has been added
to bring the reader's attention to a part of the text that might not
have been considered important by the original author when the block
was originally written, but which is now under previously unexpected
scrutiny. When used in the main prose of a document, it indicates a
part of the document that has been highlighted due to its likely
relevance to the user's current activity.
This example shows how the mark
element can be used
to bring attention to a particular part of a quotation:
<p lang="en-US">Consider the following quote:</p> <blockquote lang="en-GB"> <p>Look around and you will find, no-one's really <mark>colour</mark> blind.</p> </blockquote> <p lang="en-US">As we can tell from the <em>spelling</em> of the word, the person writing this quote is clearly not American.</p>
Another example of the mark
element is highlighting
parts of a document that are matching some search string. If
someone looked at a document, and the server knew that the user was
searching for the word "kitten", then the server might return the
document with one paragraph modified as follows:
<p>I also have some <mark>kitten</mark>s who are visiting me these days. They're really cute. I think they like my garden! Maybe I should adopt a <mark>kitten</mark>.</p>
In the following snippet, a paragraph of text refers to a specific part of a code fragment.
<p>The highlighted part below is where the error lies:</p> <pre><code>var i: Integer; begin i := <mark>1.1</mark>; end.</code></pre>
This is separate from syntax highlighting, for which
span
is more appropriate. Combining both, one would
get:
<p>The highlighted part below is where the error lies:</p> <pre><code><span class=keyword>var</span> <span class=ident>i</span>: <span class=type>Integer</span>; <span class=keyword>begin</span> <span class=ident>i</span> := <span class=literal><mark>1.1</mark></span>; <span class=keyword>end</span>.</code></pre>
This is another example showing the use of mark
to
highlight a part of quoted text that was originally not
emphasized. In this example, common typographic conventions have
led the author to explicitly style mark
elements in
quotes to render in italics.
<article> <style scoped> blockquote mark, q mark { font: inherit; font-style: italic; text-decoration: none; background: transparent; color: inherit; } .bubble em { font: inherit; font-size: larger; text-decoration: underline; } </style> <h1>She knew</h1> <p>Did you notice the subtle joke in the joke on panel 4?</p> <blockquote> <p class="bubble">I didn't <em>want</em> to believe. <mark>Of course on some level I realized it was a known-plaintext attack.</mark> But I couldn't admit it until I saw for myself.</p> </blockquote> <p>(Emphasis mine.) I thought that was great. It's so pedantic, yet it explains everything neatly.</p> </article>
Note, incidentally, the distinction between the em
element in this example, which is part of the original text being
quoted, and the mark
element, which is highlighting a
part for comment.
The following example shows the difference between denoting the
importance of a span of text (strong
) as
opposed to denoting the relevance of a span of text
(mark
). It is an extract from a textbook, where the
extract has had the parts relevant to the exam highlighted. The
safety warnings, important though they may be, are apparently not
relevant to the exam.
<h3>Wormhole Physics Introduction</h3> <p><mark>A wormhole in normal conditions can be held open for a maximum of just under 39 minutes.</mark> Conditions that can increase the time include a powerful energy source coupled to one or both of the gates connecting the wormhole, and a large gravity well (such as a black hole).</p> <p><mark>Momentum is preserved across the wormhole. Electromagnetic radiation can travel in both directions through a wormhole, but matter cannot.</mark></p> <p>When a wormhole is created, a vortex normally forms. <strong>Warning: The vortex caused by the wormhole opening will annihilate anything in its path.</strong> Vortexes can be avoided when using sufficiently advanced dialing technology.</p> <p><mark>An obstruction in a gate will prevent it from accepting a wormhole connection.</mark></p>
ruby
elementrt
element, or an rp
element, an rt
element, and another rp
element.HTMLElement
.The ruby
element allows one or more spans of
phrasing content to be marked with ruby annotations. Ruby
annotations are short runs of text presented alongside base text,
primarily used in East Asian typography as a guide for
pronunciation or to include other annotations. In Japanese, this
form of typography is also known as furigana.
A ruby
element represents the spans of
phrasing content it contains, ignoring all the child rt
and rp
elements and their descendants. Those spans of
phrasing content have associated annotations created using the
rt
element.
In this example, each ideograph in the Japanese text 漢字 is annotated with its reading in hiragana.
...
<ruby>漢<rt>かん</rt>字<rt>じ </rt></ruby>
...
This might be rendered as:
In this example, each ideograph in the traditional Chinese text 漢字 is annotated with its bopomofo reading.
<ruby>漢<rt>ㄏㄢˋ</rt>字<rt>ㄗˋ </rt></ruby>
This might be rendered as:
In this example, each ideograph in the simplified Chinese text 汉字 is annotated with its pinyin reading.
...<ruby>汉<rt>hàn</rt>字<rt>zì </rt></ruby>...
This might be rendered as:
rt
elementruby
element.HTMLElement
.The rt
element marks the ruby text component of a
ruby annotation.
An rt
element represents an
annotation (given by its children) for the zero or more nodes of
phrasing content that immediately precedes it in the
ruby
element, ignoring rp
elements.
rp
elementruby
element, either immediately before or immediately after an rt
element.HTMLElement
.The rp
element can be used to provide parentheses
around a ruby text component of a ruby annotation, to be shown by
user agents that don't support ruby annotations.
An rp
element represents
nothing.
The example above, in which each ideograph in the text 漢字 is annotated with its
phonetic reading, could be expanded to use rp
so that in
legacy user agents the readings are in parentheses:
...
<ruby>
漢 <rp>(</rp><rt>かん</rt><rp>)</rp>
字 <rp>(</rp><rt>じ</rt><rp>)</rp>
</ruby>
...
In conforming user agents the rendering would be as above, but in user agents that do not support ruby, the rendering would be:
... 漢 (かん) 字 (じ) ...
bdi
elementdir
global attribute has special semantics on this element.HTMLElement
.The bdi
element represents a span of
text that is to be isolated from its surroundings for the purposes
of bidirectional text formatting. [BIDI]
The dir
global
attribute defaults to auto
on
this element (it never inherits from the parent element like with
other elements).
This element is especially useful when embedding user-generated content with an unknown directionality.
In this example, usernames are shown along with the number of
posts that the user has submitted. If the bdi
element
were not used, the username of the Arabic user would end up
confusing the text (the bidirectional algorithm would put the colon
and the number "3" next to the word "User" rather than next to the
word "posts").
<ul> <li>User <bdi>jcranmer</bdi>: 12 posts. <li>User <bdi>hober</bdi>: 5 posts. <li>User <bdi>إيان</bdi>: 3 posts. </ul>
bdo
elementdir
global attribute has special semantics on this element.HTMLElement
.The bdo
element represents explicit
text directionality formatting control for its children. It allows
authors to override the Unicode bidirectional algorithm by
explicitly specifying a direction override. [BIDI]
Authors must specify the dir
attribute on this element, with the value ltr
to
specify a left-to-right override and with the value rtl
to specify a right-to-left override.
span
elementinterface HTMLSpanElement : HTMLElement {};
The span
element doesn't mean anything on its own,
but can be useful when used together with the global
attributes, e.g. class
, lang
, or dir
.
It represents its children.
In this example, a code fragment is marked up using
span
elements and class
attributes so that its keywords and
identifiers can be color-coded from CSS:
<pre><code class="lang-c"><span class="keyword">for</span> (<span class="ident">j</span> = 0; <span class="ident">j</span> < 256; <span class="ident">j</span>++) { <span class="ident">i_t3</span> = (<span class="ident">i_t3</span> & 0x1ffff) | (<span class="ident">j</span> << 17); <span class="ident">i_t6</span> = (((((((<span class="ident">i_t3</span> >> 3) ^ <span class="ident">i_t3</span>) >> 1) ^ <span class="ident">i_t3</span>) >> 8) ^ <span class="ident">i_t3</span>) >> 5) & 0xff; <span class="keyword">if</span> (<span class="ident">i_t6</span> == <span class="ident">i_t1</span>) <span class="keyword">break</span>; }</code></pre>
br
elementinterface HTMLBRElement : HTMLElement {};
The br
element represents a line
break.
While line breaks are usually represented in visual media by physically moving subsequent text to a new line, a style sheet or user agent would be equally justified in causing line breaks to be rendered in a different manner, for instance as green dots, or as extra spacing.
br
elements must be used only for line breaks that
are actually part of the content, as in poems or addresses.
The following example is correct usage of the br
element:
<p>P. Sherman<br> 42 Wallaby Way<br> Sydney</p>
br
elements must not be used for separating thematic
groups in a paragraph.
The following examples are non-conforming, as they abuse the
br
element:
<p><a ...>34 comments.</a><br> <a ...>Add a comment.</a></p>
<p><label>Name: <input name="name"></label><br> <label>Address: <input name="address"></label></p>
Here are alternatives to the above, which are correct:
<p><a ...>34 comments.</a></p> <p><a ...>Add a comment.</a></p>
<p><label>Name: <input name="name"></label></p> <p><label>Address: <input name="address"></label></p>
If a paragraph consists of nothing but a single
br
element, it represents a placeholder blank line
(e.g. as in a template). Such blank lines must not be used for
presentation purposes.
wbr
elementHTMLElement
.The wbr
element represents a line break
opportunity.
In the following example, someone is quoted as saying something
which, for effect, is written as one long word. However, to ensure
that the text can be wrapped in a readable fashion, the individual
words in the quote are separated using a wbr
element.
<p>So then he pointed at the tiger and screamed "there<wbr>is<wbr>no<wbr>way<wbr>you<wbr>are<wbr>ever<wbr>going<wbr>to<wbr>catch<wbr>me"!</p>
This section is non-normative.
Element | Purpose | Example |
---|---|---|
a
| Hyperlinks | Visit my <a href="drinks.html">drinks</a> page. |
em
| Stress emphasis | I must say I <em>adore</em> lemonade. |
strong
| Importance | This tea is <strong>very hot</strong>. |
small
| Side comments | These grapes are made into wine. <small>Alcohol is addictive.</small> |
s
| Inaccurate text | Price: <s>£4.50</s> £2.00! |
cite
| Titles of works | The case <cite>Hugo v. Danielle</cite> is relevant here. |
q
| Quotations | The judge said <q>You can drink water from the fish tank</q> but advised against it. |
dfn
| Defining instance | The term <dfn>organic food</dfn> refers to food produced without synthetic chemicals. |
abbr
| Abbreviations | Organic food in Ireland is certified by the <abbr title="Irish Organic Farmers and Growers Association">IOFGA</abbr>. |
time
| Date and/or time | Published <time>2009-10-21</time>. |
code
| Computer code | The <code>fruitdb</code> program can be used for tracking fruit production. |
var
| Variables | If there are <var>n</var> fruit in the bowl, at least <var>n</var>÷2 will be ripe. |
samp
| Computer output | The computer said <samp>Unknown error -3</samp>. |
kbd
| User input | Hit <kbd>F1</kbd> to continue. |
sub
| Subscripts | Water is H<sub>2</sub>O. |
sup
| Superscripts | The Hydrogen in heavy water is usually <sup>2</sup>H. |
i
| Alternative voice | Lemonade consists primarily of <i>Citrus limon</i>. |
b
| Keywords | Take a <b>lemon</b> and squeeze it with a <b>juicer</b>. |
mark
| Highlight | Elderflower cordial, with one <mark>part</mark> cordial to ten <mark>part</mark>s water, stands a<mark>part</mark> from the rest. |
ruby , rt , rp
| Ruby annotations | <ruby> OJ <rp>(<rt>Orange Juice<rp>)</ruby> |
bdi
| Text directionality isolation | The recommended restaurant is <bdi lang="">My Juice Café (At The Beach)</bdi>. |
bdo
| Text directionality formatting | The proposal is to write English, but in reverse order. "Juice" would become "<bdo dir=rtl>Juice</bdo>" |
span
| Other | In French we call it <span lang="fr">sirop de sureau</span>. |
br
| Line break | Simply Orange Juice Company<br>Apopka, FL 32703<br>U.S.A. |
wbr
| Line breaking opportunity | www.simply<wbr>orange<wbr>juice.com |
The ins
and del
elements represent
edits to the document.
ins
elementcite
datetime
HTMLModElement
interface.The ins
element represents an addition
to the document.
The following represents the addition of a single paragraph:
<aside> <ins> <p> I like fruit. </p> </ins> </aside>
As does this, because everything in the aside
element here counts as phrasing content and therefore
there is just one paragraph:
<aside> <ins> Apples are <em>tasty</em>. </ins> <ins> So are pears. </ins> </aside>
ins
elements should not cross implied paragraph boundaries.
The following example represents the addition of two paragraphs,
the second of which was inserted in two parts. The first
ins
element in this example thus crosses a paragraph
boundary, which is considered poor form.
<aside> <!-- don't do this --> <ins datetime="2005-03-16T00:00Z"> <p> I like fruit. </p> Apples are <em>tasty</em>. </ins> <ins datetime="2007-12-19T00:00Z"> So are pears. </ins> </aside>
Here is a better way of marking this up. It uses more elements, but none of the elements cross implied paragraph boundaries.
<aside> <ins datetime="2005-03-16T00:00Z"> <p> I like fruit. </p> </ins> <ins datetime="2005-03-16T00:00Z"> Apples are <em>tasty</em>. </ins> <ins datetime="2007-12-19T00:00Z"> So are pears. </ins> </aside>
del
elementcite
datetime
HTMLModElement
interface.The del
element represents a removal
from the document.
del
elements should not cross implied paragraph boundaries.
The following shows a "to do" list where items that have been done are crossed-off with the date and time of their completion.
<h1>To Do</h1> <ul> <li>Empty the dishwasher</li> <li><del datetime="2009-10-11T01:25-07:00">Watch Walter Lewin's lectures</del></li> <li><del datetime="2009-10-10T23:38-07:00">Download more tracks</del></li> <li>Buy a printer</li> </ul>
ins
and del
elementsThe cite
attribute
may be used to specify the address of a document that explains the
change. When that document is long, for instance the minutes of a
meeting, authors are encouraged to include a fragment identifier
pointing to the specific part of that document that discusses the
change.
If the cite
attribute is
present, it must be a valid URL potentially surrounded by
spaces that explains the change.
The datetime
attribute may be used to specify the time and date of the change.
If present, the datetime
attribute's value must be a valid date string with optional
time.
The ins
and del
elements implement the HTMLModElement
interface:
interface HTMLModElement : HTMLElement { attribute DOMString cite; attribute DOMString dateTime; };
This section is non-normative.
Since the ins
and del
elements do not
affect paragraphing, it is possible,
in some cases where paragraphs are implied (without explicit p
elements), for an ins
or del
element to
span both an entire paragraph or other non-phrasing
content elements and part of another paragraph. For
example:
<section> <ins> <p> This is a paragraph that was inserted. </p> This is another paragraph whose first sentence was inserted at the same time as the paragraph above. </ins> This is a second sentence, which was there all along. </section>
By only wrapping some paragraphs in p
elements, one
can even get the end of one paragraph, a whole second paragraph,
and the start of a third paragraph to be covered by the same
ins
or del
element (though this is very
confusing, and not considered good practice):
<section> This is the first paragraph. <ins>This sentence was inserted. <p>This second paragraph was inserted.</p> This sentence was inserted too.</ins> This is the third paragraph in this example. <!-- (don't do this) --> </section>
However, due to the way implied
paragraphs are defined, it is not possible to mark up the
end of one paragraph and the start of the very next one using the
same ins
or del
element. You instead have
to use one (or two) p
element(s) and two
ins
or del
elements, as for example:
<section> <p>This is the first paragraph. <del>This sentence was deleted.</del></p> <p><del>This sentence was deleted too.</del> That sentence needed a separate <del> element.</p> </section>
Partly because of the confusion described above, authors are
strongly encouraged to always mark up all paragraphs with the
p
element, instead of having ins
or
del
elements that cross implied
paragraphs boundaries.
This section is non-normative.
The content models of the ol
and ul
elements do not allow ins
and del
elements
as children. Lists always represent all their items, including items
that would otherwise have been marked as deleted.
To indicate that an item is inserted or deleted, an
ins
or del
element can be wrapped around
the contents of the li
element. To indicate that an
item has been replaced by another, a single li
element
can have one or more del
elements followed by one or
more ins
elements.
In the following example, a list that started empty had items added and removed from it over time. The bits in the example that have been emphasized show the parts that are the "current" state of the list. The list item numbers don't take into account the edits, though.
<h1>Stop-ship bugs</h1> <ol> <li><ins datetime="2008-02-12T15:20Z">Bug 225: Rain detector doesn't work in snow</ins></li> <li><del datetime="2008-03-01T20:22Z"><ins datetime="2008-02-14T12:02Z">Bug 228: Water buffer overflows in April</ins></del></li> <li><ins datetime="2008-02-16T13:50Z">Bug 230: Water heater doesn't use renewable fuels</ins></li> <li><del datetime="2008-02-20T21:15Z"><ins datetime="2008-02-16T14:25Z">Bug 232: Carbon dioxide emissions detected after startup</ins></del></li> </ol>
In the following example, a list that started with just fruit was replaced by a list with just colors.
<h1>List of <del>fruits</del><ins>colors</ins></h1> <ul> <li><del>Lime</del><ins>Green</ins></li> <li><del>Apple</del></li> <li>Orange</li> <li><del>Pear</del></li> <li><ins>Teal</ins></li> <li><del>Lemon</del><ins>Yellow</ins></li> <li>Olive</li> <li><ins>Purple</ins></li> </ul>
elementISSUE-30 (longdesc) blocks progress to Last Call
usemap
attribute: Interactive content.alt
src
usemap
ismap
width
height
[NamedConstructor=Image(), NamedConstructor=Image(in unsigned long width), NamedConstructor=Image(in unsigned long width, in unsigned long height)] interface HTMLImageElement : HTMLElement { attribute DOMString alt; attribute DOMString src; attribute DOMString useMap; attribute boolean isMap; attribute unsigned long width; attribute unsigned long height; readonly attribute unsigned long naturalWidth; readonly attribute unsigned long naturalHeight; readonly attribute boolean complete; };
An img
element represents an image.
The image given by the src
attribute is the
embedded content, and the value of the alt
attribute is the
element's fallback content.
The src
attribute must be
present, and must contain a valid non-empty URL potentially
surrounded by spaces referencing a non-interactive,
optionally animated, image resource that is neither paged nor
scripted.
Images can thus be static bitmaps (e.g. PNGs, GIFs, JPEGs), single-page vector documents (single-page PDFs, XML files with an SVG root element), animated bitmaps (APNGs, animated GIFs), animated vector graphics (XML files with an SVG root element that use declarative SMIL animation), and so forth. However, this also precludes SVG files with script, multipage PDF files, interactive MNG files, HTML documents, plain text documents, and so forth.
The requirements on the alt
attribute's value are described in the next
section.
The img
element must not be used as a layout tool.
In particular, img
elements should not be used to
display transparent images, as they rarely convey meaning and rarely
add anything useful to the document.
The usemap
attribute,
if present, can indicate that the image has an associated
image map.
The ismap
attribute, when used on an element that is a descendant of an
a
element with an href
attribute, indicates by its
presence that the element provides access to a server-side image
map. This affects how events are handled on the corresponding
a
element.
The ismap
attribute is a
boolean attribute. The attribute must not be specified
on an element that does not have an ancestor a
element
with an href
attribute.
The img
element supports dimension
attributes.
width
[ = value ]height
[ = value ]These attributes return the actual rendered dimensions of the image, or zero if the dimensions are not known.
They can be set, to change the corresponding content attributes.
naturalWidth
naturalHeight
These attributes return the intrinsic dimensions of the image, or zero if the dimensions are not known.
complete
Returns true if the image has been completely downloaded or if no image is specified; otherwise, returns false.
( [ width [, height ] ] )Returns a new img
element, with the width
and height
attributes set to the values
passed in the relevant arguments, if applicable.
A single image can have different appropriate alternative text depending on the context.
In each of the following cases, the same image is used, yet the
alt
text is different each
time. The image is the coat of arms of the Carouge municipality in
the canton Geneva in Switzerland.
Here it is used as a supplementary icon:
<p>I lived in <img src="carouge.svg" alt=""> Carouge.</p>
Here it is used as an icon representing the town:
<p>Home town: <img src="carouge.svg" alt="Carouge"></p>
Here it is used as part of a text on the town:
<p>Carouge has a coat of arms.</p> <p><img src="carouge.svg" alt="The coat of arms depicts a lion, sitting in front of a tree."></p> <p>It is used as decoration all over the town.</p>
Here it is used as a way to support a similar text where the description is given as well as, instead of as an alternative to, the image:
<p>Carouge has a coat of arms.</p> <p><img src="carouge.svg" alt=""></p> <p>The coat of arms depicts a lion, sitting in front of a tree. It is used as decoration all over the town.</p>
Here it is used as part of a story:
<p>He picked up the folder and a piece of paper fell out.</p> <p><img src="carouge.svg" alt="Shaped like a shield, the paper had a red background, a green tree, and a yellow lion with its tongue hanging out and whose tail was shaped like an S."></p> <p>He stared at the folder. S! The answer he had been looking for all this time was simply the letter S! How had he not seen that before? It all came together now. The phone call where Hector had referred to a lion's tail, the time Marco had stuck his tongue out...</p>
Here it is not known at the time of publication what the image
will be, only that it will be a coat of arms of some kind, and thus
no replacement text can be provided, and instead only a brief
caption for the image is provided, in the title
attribute:
<p>The last user to have uploaded a coat of arms uploaded this one:</p> <p><img src="last-uploaded-coat-of-arms.cgi" title="User-uploaded coat of arms."></p>
Ideally, the author would find a way to provide real replacement text even in this case, e.g. by asking the previous user. Not providing replacement text makes the document more difficult to use for people who are unable to view images, e.g. blind users, or users or very low-bandwidth connections or who pay by the byte, or users who are forced to use a text-only Web browser.
Here are some more examples showing the same picture used in different contexts, with different appropriate alternate texts each time.
<article> <h1>My cats</h1> <h2>Fluffy</h2> <p>Fluffy is my favorite.</p> <img src="fluffy.jpg" alt="She likes playing with a ball of yarn."> <p>She's just too cute.</p> <h2>Miles</h2> <p>My other cat, Miles just eats and sleeps.</p> </article>
<article> <h1>Photography</h1> <h2>Shooting moving targets indoors</h2> <p>The trick here is to know how to anticipate; to know at what speed and what distance the subject will pass by.</p> <img src="fluffy.jpg" alt="A cat flying by, chasing a ball of yarn, can be photographed quite nicely using this technique."> <h2>Nature by night</h2> <p>To achieve this, you'll need either an extremely sensitive film, or immense flash lights.</p> </article>
<article> <h1>About me</h1> <h2>My pets</h2> <p>I've got a cat named Fluffy and a dog named Miles.</p> <img src="fluffy.jpg" alt="Fluffy, my cat, tends to keep itself busy."> <p>My dog Miles and I like go on long walks together.</p> <h2>music</h2> <p>After our walks, having emptied my mind, I like listening to Bach.</p> </article>
<article> <h1>Fluffy and the Yarn</h1> <p>Fluffy was a cat who liked to play with yarn. He also liked to jump.</p> <aside><img src="fluffy.jpg" alt="" title="Fluffy"></aside> <p>He would play in the morning, he would play in the evening.</p> </article>
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
Except where otherwise specified, the alt
attribute must be specified and its
value must not be empty; the value must be an appropriate
replacement for the image. The specific requirements for the alt
attribute depend on what the image
is intended to represent, as described in the following
sections.
The most general rule to consider when writing alternative text
is the following: the intent is that replacing every image
with the text of its alt
attribute
not change the meaning of the page.
So, in general, alternative text can be written by considering what one would have written had one not been able to include the image.
A corollary to this is that the alt
attribute's value should never
contain text that could be considered the image's caption,
title, or legend. It is supposed to contain
replacement text that could be used by users instead of the
image; it is not meant to supplement the image. The title
attribute can be used for
supplemental information.
One way to think of alternative text is to think about how you would read the page containing the image to someone over the phone, without mentioning that there is an image present. Whatever you say instead of the image is typically a good start for writing the alternative text.
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
When an a element that creates a
hyperlink, or a button
element, has no
textual content but contains one or more images, the alt
attributes must contain text that
together convey the purpose of the link or button.
In this example, a user is asked to pick his preferred color from a list of three. Each color is given by an image, but for users who have configured their user agent not to display images, the color names are used instead:
<h1>Pick your color</h1> <ul> <li><a href="green.html"><img src="green.jpeg" alt="Green"></a></li> <li><a href="blue.html"><img src="blue.jpeg" alt="Blue"></a></li> <li><a href="red.html"><img src="red.jpeg" alt="Red"></a></li> </ul>
In this example, each button has a set of images to indicate the kind of color output desired by the user. The first image is used in each case to give the alternative text.
<button name="rgb"><img src="red" alt="RGB"><img src="green" alt=""><img src="blue" alt=""></button> <button name="cmyk"><img src="cyan" alt="CMYK"><img src="magenta" alt=""><img src="yellow" alt=""><img src="black" alt=""></button>
Since each image represents one part of the text, it could also be written like this:
<button name="rgb"><img src="red" alt="R"><img src="green" alt="G"><img src="blue" alt="B"></button> <button name="cmyk"><img src="cyan" alt="C"><img src="magenta" alt="M"><img src="yellow" alt="Y"><img src="black" alt="K"></button>
However, with other alternative text, this might not work, and putting all the alternative text into one image in each case might make more sense:
<button name="rgb"><img src="red" alt="sRGB profile"><img src="green" alt=""><img src="blue" alt=""></button> <button name="cmyk"><img src="cyan" alt="CMYK profile"><img src="magenta" alt=""><img src="yellow" alt=""><img src="black" alt=""></button>
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
Sometimes something can be more clearly stated in graphical
form, for example as a flowchart, a diagram, a graph, or a simple
map showing directions. In such cases, an image can be given using
the img
element, but the lesser textual version must
still be given, so that users who are unable to view the image
(e.g. because they have a very slow connection, or because they
are using a text-only browser, or because they are listening to
the page being read out by a hands-free automobile voice Web
browser, or simply because they are blind) are still able to
understand the message being conveyed.
The text must be given in the alt
attribute, and must convey the
same message as the image specified in the src
attribute.
It is important to realize that the alternative text is a replacement for the image, not a description of the image.
In the following example we have a flowchart in image
form, with text in the alt
attribute rephrasing the flowchart in prose form:
<p>In the common case, the data handled by the tokenization stage comes from the network, but it can also come from script.</p> <p><img src="http://dev.w3.org/html5/spec/images/parsing-model-overview.png" alt="The network passes data to the Tokenizer stage, which passes data to the Tree Construction stage. From there, data goes to both the DOM and to Script Execution. Script Execution is linked to the DOM, and, using document.write(), passes data to the Tokenizer."></p>
Here's another example, showing a good solution and a bad solution to the problem of including an image in a description.
First, here's the good solution. This sample shows how the alternative text should just be what you would have put in the prose if the image had never existed.
<!-- This is the correct way to do things. --> <p> You are standing in an open field west of a house. <img src="house.jpeg" alt="The house is white, with a boarded front door."> There is a small mailbox here. </p>
Second, here's the bad solution. In this incorrect way of doing things, the alternative text is simply a description of the image, instead of a textual replacement for the image. It's bad because when the image isn't shown, the text doesn't flow as well as in the first example.
<!-- This is the wrong way to do things. --> <p> You are standing in an open field west of a house. <img src="house.jpeg" alt="A white house, with a boarded front door."> There is a small mailbox here. </p>
Text such as "Photo of white house with boarded door" would be
equally bad alternative text (though it could be suitable for the
title
attribute or in the
figcaption
element of a figure
with this
image).
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
A document can contain information in iconic form. The icon is intended to help users of visual browsers to recognize features at a glance.
In some cases, the icon is supplemental to a text label
conveying the same meaning. In those cases, the alt
attribute must be present but must
be empty.
Here the icons are next to text that conveys the same meaning,
so they have an empty alt
attribute:
<nav> <p><a href="/help/"><img src="/icons/help.png" alt=""> Help</a></p> <p><a href="/configure/"><img src="/icons/configuration.png" alt=""> Configuration Tools</a></p> </nav>
In other cases, the icon has no text next to it describing what
it means; the icon is supposed to be self-explanatory. In those
cases, an equivalent textual label must be given in the alt
attribute.
Here, posts on a news site are labeled with an icon indicating their topic.
<body> <article> <header> <h1>Ratatouille wins <i>Best Movie of the Year</i> award</h1> <p><img src="movies.png" alt="Movies"></p> </header> <p>Pixar has won yet another <i>Best Movie of the Year</i> award, making this its 8th win in the last 12 years.</p> </article> <article> <header> <h1>Latest TWiT episode is online</h1> <p><img src="podcasts.png" alt="Podcasts"></p> </header> <p>The latest TWiT episode has been posted, in which we hear several tech news stories as well as learning much more about the iPhone. This week, the panelists compare how reflective their iPhones' Apple logos are.</p> </article> </body>
Many pages include logos, insignia, flags, or emblems, which stand for a particular entity such as a company, organization, project, band, software package, country, or some such.
If the logo is being used to represent the entity, e.g. as a page
heading, the alt
attribute must
contain the name of the entity being represented by the logo. The
alt
attribute must not
contain text like the word "logo", as it is not the fact that it is
a logo that is being conveyed, it's the entity itself.
If the logo is being used next to the name of the entity that
it represents, then the logo is supplemental, and its alt
attribute must instead be
empty.
If the logo is merely used as decorative material (as branding, or, for example, as a side image in an article that mentions the entity to which the logo belongs), then the entry below on purely decorative images applies. If the logo is actually being discussed, then it is being used as a phrase or paragraph (the description of the logo) with an alternative graphical representation (the logo itself), and the first entry above applies.
In the following snippets, all four of the above cases are present. First, we see a logo used to represent a company:
<h1><img src="XYZ.gif" alt="The XYZ company"></h1>
Next, we see a paragraph which uses a logo right next to the company name, and so doesn't have any alternative text:
<article> <h2>News</h2> <p>We have recently been looking at buying the <img src="alpha.gif" alt=""> ΑΒΓ company, a small Greek company specializing in our type of product.</p>
In this third snippet, we have a logo being used in an aside, as part of the larger article discussing the acquisition:
<aside><p><img src="alpha-large.gif" alt=""></p></aside> <p>The ΑΒΓ company has had a good quarter, and our pie chart studies of their accounts suggest a much bigger blue slice than its green and orange slices, which is always a good sign.</p> </article>
Finally, we have an opinion piece talking about a logo, and the logo is therefore described in detail in the alternative text.
<p>Consider for a moment their logo:</p> <p><img src="/images/logo" alt="It consists of a green circle with a green question mark centered inside it."></p> <p>How unoriginal can you get? I mean, oooooh, a question mark, how <em>revolutionary</em>, how utterly <em>ground-breaking</em>, I'm sure everyone will rush to adopt those specifications now! They could at least have tried for some sort of, I don't know, sequence of rounded squares with varying shades of green and bold white outlines, at least that would look good on the cover of a blue book.</p>
This example shows how the alternative text should be written such that if the image isn't available, and the text is used instead, the text flows seamlessly into the surrounding text, as if the image had never been there in the first place.
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
Sometimes, an image just consists of text, and the purpose of the image is not to highlight the actual typographic effects used to render the text, but just to convey the text itself.
In such cases, the alt
attribute must be present but must consist of the same text as
written in the image itself.
Consider a graphic containing the text "Earth Day", but with the letters all decorated with flowers and plants. If the text is merely being used as a heading, to spice up the page for graphical users, then the correct alternative text is just the same text "Earth Day", and no mention need be made of the decorations:
<h1><img src="earthdayheading.png" alt="Earth Day"></h1>
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
In many cases, the image is actually just supplementary, and
its presence merely reinforces the surrounding text. In these
cases, the alt
attribute must be
present but its value must be the empty string.
In general, an image falls into this category if removing the image doesn't make the page any less useful, but including the image makes it a lot easier for users of visual browsers to understand the concept.
A flowchart that repeats the previous paragraph in graphical form:
<p>The network passes data to the Tokenizer stage, which passes data to the Tree Construction stage. From there, data goes to both the DOM and to Script Execution. Script Execution is linked to the DOM, and, using document.write(), passes data to the Tokenizer.</p> <p><img src="http://dev.w3.org/html5/spec/images/parsing-model-overview.png" alt=""></p>
In these cases, it would be wrong to include alternative text
that consists of just a caption. If a caption is to be included,
then either the title
attribute can
be used, or the figure
and figcaption
elements can be used. In the latter case, the image would in fact
be a phrase or paragraph with an alternative graphical
representation, and would thus require alternative text.
<!-- Using the title="" attribute --> <p>The network passes data to the Tokenizer stage, which passes data to the Tree Construction stage. From there, data goes to both the DOM and to Script Execution. Script Execution is linked to the DOM, and, using document.write(), passes data to the Tokenizer.</p> <p><img src="http://dev.w3.org/html5/spec/images/parsing-model-overview.png" alt="" title="Flowchart representation of the parsing model."></p>
<!-- Using <figure> and <figcaption> --> <p>The network passes data to the Tokenizer stage, which passes data to the Tree Construction stage. From there, data goes to both the DOM and to Script Execution. Script Execution is linked to the DOM, and, using document.write(), passes data to the Tokenizer.</p> <figure> <img src="http://dev.w3.org/html5/spec/images/parsing-model-overview.png" alt="The Network leads to the Tokenizer, which leads to the Tree Construction. The Tree Construction leads to two items. The first is Script Execution, which leads via document.write() back to the Tokenizer. The second item from which Tree Construction leads is the DOM. The DOM is related to the Script Execution."> <figcaption>Flowchart representation of the parsing model.</figcaption> </figure>
<!-- This is WRONG. Do not do this. Instead, do what the above examples do. --> <p>The network passes data to the Tokenizer stage, which passes data to the Tree Construction stage. From there, data goes to both the DOM and to Script Execution. Script Execution is linked to the DOM, and, using document.write(), passes data to the Tokenizer.</p> <p><img src="http://dev.w3.org/html5/spec/images/parsing-model-overview.png" alt="Flowchart representation of the parsing model."></p> <!-- Never put the image's caption in the alt="" attribute! -->
A graph that repeats the previous paragraph in graphical form:
<p>According to a study covering several billion pages, about 62% of documents on the Web in 2007 triggered the Quirks rendering mode of Web browsers, about 30% triggered the Almost Standards mode, and about 9% triggered the Standards mode.</p> <p><img src="rendering-mode-pie-chart.png" alt=""></p>
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
In general, if an image is decorative but isn't especially page-specific, for example an image that forms part of a site-wide design scheme, the image should be specified in the site's CSS, not in the markup of the document.
However, a decorative image that isn't discussed by the
surrounding text but still has some relevance can be included in a page
using the img
element. Such images are decorative, but
still form part of the content. In these cases, the alt
attribute must be present but its
value must be the empty string.
Examples where the image is purely decorative despite being relevant would include things like a photo of the Black Rock City landscape in a blog post about an event at Burning Man, or an image of a painting inspired by a poem, on a page reciting that poem. The following snippet shows an example of the latter case (only the first verse is included in this snippet):
<h1>The Lady of Shalott</h1> <p><img src="shalott.jpeg" alt=""></p> <p>On either side the river lie<br> Long fields of barley and of rye,<br> That clothe the wold and meet the sky;<br> And through the field the road run by<br> To many-tower'd Camelot;<br> And up and down the people go,<br> Gazing where the lilies blow<br> Round an island there below,<br> The island of Shalott.</p>
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
When a picture has been sliced into smaller image files that are
then displayed together to form the complete picture again, one of
the images must have its alt
attribute set as per the relevant rules that would be appropriate
for the picture as a whole, and then all the remaining images must
have their alt
attribute set to
the empty string.
In the following example, a picture representing a company logo for XYZ Corp has been split into two pieces, the first containing the letters "XYZ" and the second with the word "Corp". The alternative text ("XYZ Corp") is all in the first image.
<h1><img src="logo1.png" alt="XYZ Corp"><img src="logo2.png" alt=""></h1>
In the following example, a rating is shown as three filled stars and two empty stars. While the alternative text could have been "★★★☆☆", the author has instead decided to more helpfully give the rating in the form "3 out of 5". That is the alternative text of the first image, and the rest have blank alternative text.
<p>Rating: <meter max=5 value=3><img src="1" alt="3 out of 5" ><img src="1" alt=""><img src="1" alt=""><img src="0" alt="" ><img src="0" alt=""></meter></p>
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
Generally, image maps should be used instead of slicing an image for links.
However, if an image is indeed sliced and any of the components
of the sliced picture are the sole contents of links, then one image
per link must have alternative text in its alt
attribute representing the purpose
of the link.
In the following example, a picture representing the flying spaghetti monster emblem, with each of the left noodly appendages and the right noodly appendages in different images, so that the user can pick the left side or the right side in an adventure.
<h1>The Church</h1> <p>You come across a flying spaghetti monster. Which side of His Noodliness do you wish to reach out for?</p> <p><a href="?go=left" ><img src="fsm-left.png" alt="Left side. "></a ><img src="fsm-middle.png" alt="" ><a href="?go=right"><img src="fsm-right.png" alt="Right side."></a></p>
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
In some cases, the image is a critical part of the content. This could be the case, for instance, on a page that is part of a photo gallery. The image is the whole point of the page containing it.
How to provide alternative text for an image that is a key part of the content depends on the image's provenance.
When it is possible for detailed alternative text to be
provided, for example if the image is part of a series of
screenshots in a magazine review, or part of a comic strip, or is
a photograph in a blog entry about that photograph, text that can
serve as a substitute for the image must be given as the contents
of the alt
attribute.
A screenshot in a gallery of screenshots for a new OS, with some alternative text:
<figure> <img src="KDE%20Light%20desktop.png" alt="The desktop is blue, with icons along the left hand side in two columns, reading System, Home, K-Mail, etc. A window is open showing that menus wrap to a second line if they cannot fit in the window. The window has a list of icons along the top, with an address bar below it, a list of icons for tabs along the left edge, a status bar on the bottom, and two panes in the middle. The desktop has a bar at the bottom of the screen with a few buttons, a pager, a list of open applications, and a clock."> <figcaption>Screenshot of a KDE desktop.</figcaption> </figure>
A graph in a financial report:
<img src="sales.gif" title="Sales graph" alt="From 1998 to 2005, sales increased by the following percentages with each year: 624%, 75%, 138%, 40%, 35%, 9%, 21%">
Note that "sales graph" would be inadequate alternative text for a sales graph. Text that would be a good caption is not generally suitable as replacement text.
In certain cases, the nature of the image might be such that providing thorough alternative text is impractical. For example, the image could be indistinct, or could be a complex fractal, or could be a detailed topographical map.
In these cases, the alt
attribute must contain some suitable alternative text, but it may
be somewhat brief.
Sometimes there simply is no text that can do justice to an image. For example, there is little that can be said to usefully describe a Rorschach inkblot test. However, a description, even if brief, is still better than nothing:
<figure> <img src="/commons/a/a7/Rorschach1.jpg" alt="A shape with left-right symmetry with indistinct edges, with a small gap in the center, two larger gaps offset slightly from the center, with two similar gaps under them. The outline is wider in the top half than the bottom half, with the sides extending upwards higher than the center, and the center extending below the sides."> <figcaption>A black outline of the first of the ten cards in the Rorschach inkblot test.</figcaption> </figure>
Note that the following would be a very bad use of alternative text:
<!-- This example is wrong. Do not copy it. --> <figure> <img src="/commons/a/a7/Rorschach1.jpg" alt="A black outline of the first of the ten cards in the Rorschach inkblot test."> <figcaption>A black outline of the first of the ten cards in the Rorschach inkblot test.</figcaption> </figure>
Including the caption in the alternative text like this isn't useful because it effectively duplicates the caption for users who don't have images, taunting them twice yet not helping them any more than if they had only read or heard the caption once.
Another example of an image that defies full description is a fractal, which, by definition, is infinite in detail.
The following example shows one possible way of providing alternative text for the full view of an image of the Mandelbrot set.
<img src="ms1.jpeg" alt="The Mandelbrot set appears as a cardioid with its cusp on the real axis in the positive direction, with a smaller bulb aligned along the same center line, touching it in the negative direction, and with these two shapes being surrounded by smaller bulbs of various sizes.">
In some unfortunate cases, there might be no alternative text available at all, either because the image is obtained in some automated fashion without any associated alternative text (e.g. a Webcam), or because the page is being generated by a script using user-provided images where the user did not provide suitable or usable alternative text (e.g. photograph sharing sites), or because the author does not himself know what the images represent (e.g. a blind photographer sharing an image on his blog).
In such cases, the alt
attribute may be omitted, but one of the following conditions must
be met as well:
title
attribute is
present and has a non-empty value.Such cases are to be kept to an absolute
minimum. If there is even the slightest possibility of the author
having the ability to provide real alternative text, then it would
not be acceptable to omit the alt
attribute.
A photo on a photo-sharing site, if the site received the image with no metadata other than the caption, could be marked up as follows:
<figure> <img src="1100670787_6a7c664aef.jpg"> <figcaption>Bubbles traveled everywhere with us.</figcaption> </figure>
It would be better, however, if a detailed description of the important parts of the image obtained from the user and included on the page.
A blind user's blog in which a photo taken by the user is shown. Initially, the user might not have any idea what the photo he took shows:
<article> <h1>I took a photo</h1> <p>I went out today and took a photo!</p> <figure> <img src="photo2.jpeg"> <figcaption>A photograph taken blindly from my front porch.</figcaption> </figure> </article>
Eventually though, the user might obtain a description of the image from his friends and could then include alternative text:
<article> <h1>I took a photo</h1> <p>I went out today and took a photo!</p> <figure> <img src="photo2.jpeg" alt="The photograph shows my hummingbird feeder hanging from the edge of my roof. It is half full, but there are no birds around. In the background, out-of-focus trees fill the shot. The feeder is made of wood with a metal grate, and it contains peanuts. The edge of the roof is wooden too, and is painted white with light blue streaks."> <figcaption>A photograph taken blindly from my front porch.</figcaption> </figure> </article>
Sometimes the entire point of the image is that a textual
description is not available, and the user is to provide the
description. For instance, the point of a CAPTCHA image is to see
if the user can literally read the graphic. Here is one way to
mark up a CAPTCHA (note the title
attribute):
<p><label>What does this image say? <img src="captcha.cgi?id=8934" title="CAPTCHA"> <input type=text name=captcha></label> (If you cannot see the image, you can use an <a href="?audio">audio</a> test instead.)</p>
Another example would be software that displays images and asks for alternative text precisely for the purpose of then writing a page with correct alternative text. Such a page could have a table of images, like this:
<table> <thead> <tr> <th> Image <th> Description <tbody> <tr> <td> <img src="2421.png" title="Image 640 by 100, filename 'banner.gif'"> <td> <input name="alt2421"> <tr> <td> <img src="2422.png" title="Image 200 by 480, filename 'ad3.gif'"> <td> <input name="alt2422"> </table>
Notice that even in this example, as much useful information
as possible is still included in the title
attribute.
Since some users cannot use images at all
(e.g. because they have a very slow connection, or because they
are using a text-only browser, or because they are listening to
the page being read out by a hands-free automobile voice Web
browser, or simply because they are blind), the alt
attribute is only allowed to be
omitted rather than being provided with replacement text when no
alternative text is available and none can be made available, as
in the above examples. Lack of effort from the part of the author
is not an acceptable reason for omitting the alt
attribute.
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
Generally authors should avoid using img
elements
for purposes other than showing images.
If an img
element is being used for purposes other
than showing an image, e.g. as part of a service to count page
views, then the alt
attribute must
be the empty string.
In such cases, the width
and
height
attributes should both
be set to zero.
ISSUE-31 (alt-conformance-requirements) blocks progress to Last Call
This section does not apply to documents that are publicly accessible, or whose target audience is not necessarily personally known to the author, such as documents on a Web site, e-mails sent to public mailing lists, or software documentation.
When an image is included in a private communication (such as an
HTML e-mail) aimed at a specific person who is known to be able to
view images, the alt
attribute may
be omitted. However, even in such cases it is strongly recommended
that alternative text be included (as appropriate according to the
kind of image involved, as described in the above entries), so that
the e-mail is still usable should the user use a mail client that
does not support images, or should the document be forwarded on to
other users whose abilities might not include easily seeing
images.
iframe
elementsrc
srcdoc
name
sandbox
seamless
width
height
interface HTMLIFrameElement : HTMLElement { attribute DOMString src; attribute DOMString srcdoc; attribute DOMString name; [PutForwards=value] readonly attribute DOMSettableTokenList sandbox; attribute boolean seamless; attribute DOMString width; attribute DOMString height; readonly attribute Document contentDocument; readonly attribute WindowProxy contentWindow; };
The iframe
element represents a
nested browsing context.
The src
attribute
gives the address of a page that the nested browsing
context is to contain. The attribute, if present, must be a
valid non-empty URL potentially surrounded by
spaces.
The srcdoc
attribute gives the content of the page that the nested
browsing context is to contain. The value of the attribute is
the source of an iframe
srcdoc
document.
For iframe
elements in HTML documents,
the attribute, if present, must have a value using the HTML
syntax that consists of the following syntactic components,
in the given order:
html
element.For iframe
elements in XML documents,
the attribute, if present, must have a value that matches the
production labeled document
in the XML
specification. [XML]
If the src
attribute and the
srcdoc
attribute are both
specified together, the srcdoc
attribute takes priority. This allows authors to provide a fallback
URL for legacy user agents that do not support the
srcdoc
attribute.
If, when the element is created, the srcdoc
attribute is not set, and
the src
attribute is either
also not set or set but its value cannot be resolved, the browsing context will remain at the
initial about:blank
page.
If the user navigates
away from this page, the iframe
's corresponding
WindowProxy
object will proxy new Window
objects for new Document
objects, but the src
attribute will not change.
Here a blog uses the srcdoc
attribute in conjunction
with the sandbox
and seamless
attributes described
below to provide users of user agents that support this feature
with an extra layer of protection from script injection in the blog
post comments:
<article> <h1>I got my own magazine!</h1> <p>After much effort, I've finally found a publisher, and so now I have my own magazine! Isn't that awesome?! The first issue will come out in September, and we have articles about getting food, and about getting in boxes, it's going to be great!</p> <footer> <p>Written by <a href="/users/cap">cap</a>. <time pubdate>2009-08-21T23:32Z</time></p> </footer> <article> <footer> At <time pubdate>2009-08-21T23:35Z</time>, <a href="/users/ch">ch</a> writes: </footer> <iframe seamless sandbox srcdoc="<p>did you get a cover picture yet?"></iframe> </article> <article> <footer> At <time pubdate>2009-08-21T23:44Z</time>, <a href="/users/cap">cap</a> writes: </footer> <iframe seamless sandbox srcdoc="<p>Yeah, you can see it <a href="/gallery?mode=cover&amp;page=1">in my gallery</a>."></iframe> </article> <article> <footer> At <time pubdate>2009-08-21T23:58Z</time>, <a href="/users/ch">ch</a> writes: </footer> <iframe seamless sandbox srcdoc="<p>hey that's earl's table. <p>you should get earl&amp;me on the next cover."></iframe> </article>
Notice the way that quotes have to be escaped (otherwise the
sandbox
attribute would
end prematurely), and the way raw ampersands (e.g. in URLs or in
prose) mentioned in the sandboxed content have to be
doubly escaped — once so that the ampersand is
preserved when originally parsing the sandbox
attribute, and once more
to prevent the ampersand from being misinterpreted when parsing the
sandboxed content.
In the HTML syntax, authors need only
remember to use U+0022 QUOTATION MARK characters (") to wrap the
attribute contents and then to escape all U+0022 QUOTATION MARK (")
and U+0026 AMPERSAND (&) characters, and to specify the sandbox
attribute, to ensure safe
embedding of content.
Due to restrictions of the XML syntax, in XML the U+003C LESS-THAN SIGN character (<) needs to be escaped as well. In order to prevent attribute-value normalization, some of XML's whitespace characters — specifically U+0009 CHARACTER TABULATION (HT), U+000A LINE FEED (LF), and U+000D CARRIAGE RETURN (CR) — also need to be escaped. [XML]
The name
attribute, if present, must be a valid browsing context
name. The given value is used to name the nested
browsing context.
The sandbox
attribute, when specified, enables a set of extra restrictions on
any content hosted by the iframe
. Its value must be an
unordered set of unique space-separated tokens that are
ASCII case-insensitive. The allowed values are allow-same-origin
,
allow-top-navigation
,
allow-forms
,
and allow-scripts
. When
the attribute is set, the content is treated as being from a unique
origin, forms and scripts are disabled, links are
prevented from targeting other browsing contexts, and plugins are disabled. The
allow-same-origin
keyword allows the content to be treated as being from the same
origin instead of forcing it into a unique origin, the allow-top-navigation
keyword allows the content to navigate its
top-level browsing context, and the allow-forms
and allow-scripts
keywords re-enable forms and scripts respectively (though scripts
are still prevented from creating popups).
Setting both the allow-scripts
and
allow-same-origin
keywords together when the embedded page has the same
origin as the page containing the iframe
allows
the embedded page to simply remove the sandbox
attribute.
Sandboxing hostile content is of minimal help if
an attacker can convince the user to just visit the hostile content
directly, rather than in the iframe
. To limit the
damage that can be caused by hostile HTML content, it should be
served using the text/html-sandboxed
MIME type.
In this example, some completely-unknown, potentially hostile, user-provided HTML content is embedded in a page. Because it is sandboxed, it is treated by the user agent as being from a unique origin, despite the content being served from the same site. Thus it is affected by all the normal cross-site restrictions. In addition, the embedded page has scripting disabled, plugins disabled, forms disabled, and it cannot navigate any frames or windows other than itself (or any frames or windows it itself embeds).
<p>We're not scared of you! Here is your content, unedited:</p> <iframe sandbox src="getusercontent.cgi?id=12193"></iframe>
Note that cookies are still sent to the server in the getusercontent.cgi
request, though they are not
visible in the document.cookie
IDL
attribute.
It is important that the server serve the
user-provided HTML using the text/html-sandboxed
MIME
type so that if the attacker convinces the user to visit that page
directly, the page doesn't run in the context of the site's origin,
which would make the user vulnerable to any attack found in the
page.
In this example, a gadget from another site is embedded. The gadget has scripting and forms enabled, and the origin sandbox restrictions are lifted, allowing the gadget to communicate with its originating server. The sandbox is still useful, however, as it disables plugins and popups, thus reducing the risk of the user being exposed to malware and other annoyances.
<iframe sandbox="allow-same-origin allow-forms allow-scripts" src="http://maps.example.com/embedded.html"></iframe>
Suppose a file A contained the following fragment:
<iframe sandbox="allow-same-origin allow-forms" src=B></iframe>
Suppose that file B contained an iframe also:
<iframe sandbox="allow-scripts" src=C></iframe>
Further, suppose that file C contained a link:
<a href=D>Link</a>
For this example, suppose all the files were served as
text/html
.
Page C in this scenario has all the sandboxing flags
set. Scripts are disabled, because the iframe
in A has
scripts disabled, and this overrides the allow-scripts
keyword set on the iframe
in B. Forms are also
disabled, because the inner iframe
(in B) does not
have the allow-forms
keyword
set.
Suppose now that a script in A removes all the sandbox
attributes in A and
B. This would change nothing immediately. If the user clicked the
link in C, loading page D into the iframe
in B, page D
would now act as if the iframe
in B had the allow-same-origin
and allow-forms
keywords
set, because that was the state of the nested browsing
context in the iframe
in A when page B was
loaded.
Generally speaking, dynamically removing or changing the sandbox
attribute is
ill-advised, because it can make it quite hard to reason about what
will be allowed and what will not.
Potentially hostile files can be served from the
same server as the file containing the iframe
element
by labeling them as text/html-sandboxed
instead of
text/html
. This ensures that scripts in the files are
unable to attack the site (as if they were actually served from
another server), even if the user is tricked into visiting those
pages directly, without the protection of the sandbox
attribute.
If the allow-scripts
keyword is set along with allow-same-origin
keyword, and the file is from the same origin as the
iframe
's Document
, then a script in the
"sandboxed" iframe could just reach out, remove the sandbox
attribute, and then
reload itself, effectively breaking out of the sandbox
altogether.
The seamless
attribute is a boolean attribute. When specified, it
indicates that the iframe
element's browsing
context is to be rendered in a manner that makes it appear to
be part of the containing document (seamlessly included in the
parent document).
The attribute can be set or removed dynamically, with the rendering updating in tandem.
In this example, the site's navigation is embedded using a
client-side include using an iframe
. Any links in the
iframe
will, in new user agents, be automatically
opened in the iframe
's parent browsing context; for
legacy user agents, the site could also include a base
element with a target
attribute with the value _parent
. Similarly,
in new user agents the styles of the parent page will be
automatically applied to the contents of the frame, but to support
legacy user agents authors might wish to include the styles
explicitly.
<nav><iframe seamless src="nav.include.html"></iframe></nav>
The iframe
element supports dimension
attributes for cases where the embedded content has specific
dimensions (e.g. ad units have well-defined dimensions).
An iframe
element never has fallback
content, as it will always create a nested browsing
context, regardless of whether the specified initial contents
are successfully used.
Descendants of iframe
elements represent
nothing. (In legacy user agents that do not support
iframe
elements, the contents would be parsed as markup
that could act as fallback content.)
When used in HTML
documents, the allowed content model of iframe
elements is text, except that invoking the HTML fragment
parsing algorithm with the iframe
element as the
context element and the text contents as the
input must result in a list of nodes that are
all phrasing content, with no parse errors having occurred, with no
script
elements being anywhere in the list or as
descendants of elements in the list, and with all the elements in
the list (including their descendants) being themselves
conforming.
The iframe
element must be empty in XML
documents.
The HTML parser treats markup inside
iframe
elements as text.
Here is an example of a page using an iframe
to
include advertising from an advertising broker:
<iframe src="http://ads.example.com/?customerid=923513721&format=banner" width="468" height="60"></iframe>
embed
elementsrc
type
width
height
interface HTMLEmbedElement : HTMLElement { attribute DOMString src; attribute DOMString type; attribute DOMString width; attribute DOMString height; };
The embed
element represents an
integration point for an external (typically non-HTML) application
or interactive content.
The src
attribute
gives the address of the resource being embedded. The attribute, if
present, must contain a valid non-empty URL potentially
surrounded by spaces.
The type
attribute, if present, gives the MIME type by which the
plugin to instantiate is selected. The value must be a valid
MIME type. If both the type
attribute and the src
attribute are present, then the
type
attribute must specify the
same type as the explicit Content-Type
metadata of the resource given by the src
attribute.
Any namespace-less attribute other than name
, align
, hspace
, and vspace
may be specified on the embed
element,
so long as its name is XML-compatible and contains no
characters in the range U+0041 to U+005A (LATIN CAPITAL LETTER A to
LATIN CAPITAL LETTER Z). These attributes are then passed as
parameters to the plugin.
All attributes in HTML documents get lowercased automatically, so the restriction on uppercase letters doesn't affect such documents.
The four exceptions are to exclude legacy attributes that have side-effects beyond just sending parameters to the plugin.
The embed
element supports dimension
attributes.
Here's a way to embed a resource that requires a proprietary plug-in, like Flash:
<embed src="catgame.swf">
If the user does not have the plug-in (for example if the plug-in vendor doesn't support the user's platform), then the user will be unable to use the resource.
To pass the plugin a parameter "quality" with the value "high", an attribute can be specified:
<embed src="catgame.swf" quality="high">
This would be equivalent to the following, when using an
object
element instead:
<object data="catgame.swf"> <param name="quality" value="high"> </object>
object
elementusemap
attribute: Interactive content.param
elements, then, transparent.data
type
name
usemap
form
width
height
interface HTMLObjectElement : HTMLElement { attribute DOMString data; attribute DOMString type; attribute DOMString name; attribute DOMString useMap; readonly attribute HTMLFormElement form; attribute DOMString width; attribute DOMString height; readonly attribute Document contentDocument; readonly attribute WindowProxy contentWindow; readonly attribute boolean willValidate; readonly attribute ValidityState validity; readonly attribute DOMString validationMessage; boolean checkValidity(); void setCustomValidity(in DOMString error); };
The object
element can represent an external
resource, which, depending on the type of the resource, will either
be treated as an image, as a nested browsing context,
or as an external resource to be processed by a
plugin.
The data
attribute, if present, specifies the address of the resource. If
present, the attribute must be a valid non-empty
URL potentially surrounded by spaces.
The type
attribute, if present, specifies the type of the resource. If
present, the attribute must be a valid MIME type.
At least one of either the data
attribute or the type
attribute must be present.
The name
attribute, if present, must be a valid browsing context
name. The given value is used to name the nested
browsing context, if applicable.
The usemap
attribute,
if present while the object
element represents an
image, can indicate that the object has an associated image
map.
The form
attribute is used to
explicitly associate the object
element with its
form owner.
The object
element supports dimension
attributes.
In the following example, a Java applet is embedded in a page
using the object
element. (Generally speaking, it is
better to avoid using applets like these and instead use native
JavaScript and HTML to provide the functionality, since that way
the application will work on all Web browsers without requiring a
third-party plugin. Many devices, especially embedded devices, do
not support third-party technologies like Java.)
<figure> <object type="application/x-java-applet"> <param name="code" value="MyJavaClass"> <p>You do not have Java available, or it is disabled.</p> </object> <figcaption>My Java Clock</figcaption> </figure>
In this example, an HTML page is embedded in another using the
object
element.
<figure> <object data="clock.html"></object> <figcaption>My HTML Clock</figcaption> </figure>
The following example shows how a plugin can be used in HTML (in
this case the Flash plugin, to show a video file). Fallback is
provided for users who do not have Flash enabled, in this case
using the video
element to show the video for those
using user agents that support video
, and finally
providing a link to the video for those who have neither Flash nor
a video
-capable browser.
<p>Look at my video: <object type="application/x-shockwave-flash"> <param name=movie value="http://video.example.com/library/watch.swf"> <param name=allowfullscreen value=true> <param name=flashvars value="http://video.example.com/vids/315981"> <video controls src="http://video.example.com/vids/315981"> <a href="http://video.example.com/vids/315981">View video</a>. </video> </object> </p>
param
elementobject
element, before any flow content.name
value
interface HTMLParamElement : HTMLElement { attribute DOMString name; attribute DOMString value; };
The param
element defines parameters for plugins
invoked by object
elements. It does not represent anything on its own.
The name
attribute gives the name of the parameter.
The value
attribute gives the value of the parameter.
Both attributes must be present. They may have any value.
The following example shows how the param
element
can be used to pass a parameter to a plugin, in this case the O3D
plugin.
<!DOCTYPE HTML> <html lang="en"> <head> <title>O3D Utah Teapot</title> </head> <body> <p> <object type="application/vnd.o3d.auto"> <param name="o3d_features" value="FloatingPointTextures"> <img src="o3d-teapot.png" title="3D Utah Teapot illustration rendered using O3D." alt="When O3D renders the Utah Teapot, it appears as a squat teapot with a shiny metallic finish on which the surroundings are reflected, with a faint shadow caused by the lighting."> <p>To see the teapot actually rendered by O3D on your computer, please download and install the <a href="http://code.google.com/apis/o3d/docs/gettingstarted.html#install">O3D plugin</a>.</p> </object> <script src="o3d-teapot.js"></script> </p> </body> </html>
video
elementcontrols
attribute: Interactive content.src
attribute:
zero or more track
elements, then
transparent, but with no media element descendants.src
attribute: zero or more source
elements, then
zero or more track
elements, then
transparent, but with no media element descendants.src
poster
preload
autoplay
loop
audio
controls
width
height
interface HTMLVideoElement : HTMLMediaElement { attribute unsigned long width; attribute unsigned long height; readonly attribute unsigned long videoWidth; readonly attribute unsigned long videoHeight; attribute DOMString poster; [PutForwards=value] attribute DOMSettableTokenList audio; };
A video
element is used for playing videos or
movies.
Content may be provided inside the video
element; it is intended for older Web browsers which do
not support video
, so that legacy video plugins can be
tried, or to show text to the users of these older browsers informing
them of how to access the video contents.
In particular, this content is not intended to address accessibility concerns. To make video content accessible to the blind, deaf, and those with other physical or cognitive disabilities, authors are expected to provide alternative media streams and/or to embed accessibility aids (such as caption or subtitle tracks, audio description tracks, or sign-language overlays) into their media streams.
The video
element is a media element
whose media data is ostensibly video data, possibly
with associated audio data.
The src
, preload
, autoplay
,
loop
, and controls
attributes are the attributes common to all media
elements. The audio
attribute controls the audio
channel.
The poster
attribute gives the address of an image file that the user agent can
show while no video data is available. The attribute, if present,
must contain a valid non-empty URL potentially surrounded by
spaces.
The image given by the poster
attribute, the poster
frame, is intended to be a representative frame of the video
(typically one of the first non-blank frames) that gives the user an
idea of what the video is like.
videoWidth
videoHeight
These attributes return the intrinsic dimensions of the video, or zero if the dimensions are not known.
The video
element supports dimension
attributes.
This example shows how to detect when a video has failed to play correctly:
<script> function failed(e) { // video playback failed - show a message saying why switch (e.target.error.code) { case e.target.error.MEDIA_ERR_ABORTED: alert('You aborted the video playback.'); break; case e.target.error.MEDIA_ERR_NETWORK: alert('A network error caused the video download to fail part-way.'); break; case e.target.error.MEDIA_ERR_DECODE: alert('The video playback was aborted due to a corruption problem or because the video used features your browser did not support.'); break; case e.target.error.MEDIA_ERR_SRC_NOT_SUPPORTED: alert('The video could not be loaded, either because the server or network failed or because the format is not supported.'); break; default: alert('An unknown error occurred.'); break; } } </script> <p><video src="tgif.vid" autoplay controls onerror="failed(event)"></video></p> <p><a href="tgif.vid">Download the video file</a>.</p>
audio
elementcontrols
attribute: Interactive content.src
attribute:
zero or more track
elements, then
transparent, but with no media element descendants.src
attribute: one or more source
elements, then
zero or more track
elements, then
transparent, but with no media element descendants.src
preload
autoplay
loop
controls
[NamedConstructor=Audio(), NamedConstructor=Audio(in DOMString src)] interface HTMLAudioElement : HTMLMediaElement {};
An audio
element represents a sound or
audio stream.
Content may be provided inside the audio
element; it is intended for older Web browsers which do
not support audio
, so that legacy audio plugins can be
tried, or to show text to the users of these older browsers informing
them of how to access the audio contents.
In particular, this content is not intended to address accessibility concerns. To make audio content accessible to the deaf or to those with other physical or cognitive disabilities, authors are expected to provide alternative media streams and/or to embed accessibility aids (such as transcriptions) into their media streams.
The audio
element is a media element
whose media data is ostensibly audio data.
The src
, preload
, autoplay
,
loop
, and controls
attributes are the attributes common to all media
elements.
Audio
( [ url ] )Returns a new audio
element, with the src
attribute set to the value
passed in the argument, if applicable.
source
elementtrack
elements.src
type
media
interface HTMLSourceElement : HTMLElement { attribute DOMString src; attribute DOMString type; attribute DOMString media; };
The source
element allows authors to specify
multiple alternative media
resources for media
elements. It does not represent anything on its own.
The src
attribute
gives the address of the media resource. The value must
be a valid non-empty URL potentially surrounded by
spaces. This attribute must be present.
Dynamically modifying a source
element
and its attribute when the element is already inserted in a
video
or audio
element will have no
effect. To change what is playing, either just use the src
attribute on the media
element directly, or call the load()
method on the media
element after manipulating the source
elements.
The type
attribute gives the type of the media resource, to help
the user agent determine if it can play this media
resource before fetching it. If specified, its value must be
a valid MIME type. The codecs
parameter, which certain MIME types define, might be necessary to
specify exactly how the resource is encoded. [RFC4281]
The following list shows some examples of how to use the codecs=
MIME parameter in the type
attribute.
<source src='video.mp4' type='video/mp4; codecs="avc1.42E01E, mp4a.40.2"'>
<source src='video.mp4' type='video/mp4; codecs="avc1.58A01E, mp4a.40.2"'>
<source src='video.mp4' type='video/mp4; codecs="avc1.4D401E, mp4a.40.2"'>
<source src='video.mp4' type='video/mp4; codecs="avc1.64001E, mp4a.40.2"'>
<source src='video.mp4' type='video/mp4; codecs="mp4v.20.8, mp4a.40.2"'>
<source src='video.mp4' type='video/mp4; codecs="mp4v.20.240, mp4a.40.2"'>
<source src='video.3gp' type='video/3gpp; codecs="mp4v.20.8, samr"'>
<source src='video.ogv' type='video/ogg; codecs="theora, vorbis"'>
<source src='video.ogv' type='video/ogg; codecs="theora, speex"'>
<source src='audio.ogg' type='audio/ogg; codecs=vorbis'>
<source src='audio.spx' type='audio/ogg; codecs=speex'>
<source src='audio.oga' type='audio/ogg; codecs=flac'>
<source src='video.ogv' type='video/ogg; codecs="dirac, vorbis"'>
<source src='video.mkv' type='video/x-matroska; codecs="theora, vorbis"'>
The media
attribute gives the intended media type of the media
resource, to help the user agent determine if this
media resource is useful to the user before fetching
it. Its value must be a valid media query.
The default, if the media
attribute is omitted, is
"all
", meaning that by default the media
resource is suitable for all media.
If the author isn't sure if the user agents will all be able to
render the media resources provided, the author can listen to the
error
event on the last
source
element and trigger fallback behavior:
<script> function fallback(video) { // replace <video> with its contents while (video.hasChildNodes()) { if (video.firstChild instanceof HTMLSourceElement) video.removeChild(video.firstChild); else video.parentNode.insertBefore(video.firstChild, video); } video.parentNode.removeChild(video); } </script> <video controls autoplay> <source src='video.mp4' type='video/mp4; codecs="avc1.42E01E, mp4a.40.2"'> <source src='video.ogv' type='video/ogg; codecs="theora, vorbis"' onerror="fallback(parentNode)"> ... </video>
track
elementkind
src
srclang
label
default
interface HTMLTrackElement : HTMLElement { attribute DOMString kind; attribute DOMString src; attribute DOMString srclang; attribute DOMString label; attribute boolean default; readonly attribute TextTrack track; };
The track
element allows authors to specify explicit
external timed text tracks for media elements. It does not represent anything on its own.
The kind
attribute is an enumerated attribute. The following
table lists the keywords defined for this attribute. The keyword
given in the first cell of each row maps to the state given in the
second cell.
Keyword | State | Brief description |
---|---|---|
subtitles
| Subtitles | Transcription or translation of the dialogue, suitable for when the sound is available but not understood (e.g. because the user does not understand the language of the media resource's soundtrack). Displayed over the video. |
captions
| Captions | Transcription or translation of the dialogue, sound effects, relevant musical cues, and other relevant audio information, suitable for when the soundtrack is unavailable (e.g. because it is muted or because the user is deaf). Displayed over the video; labeled as appropriate for the hard-of-hearing. |
descriptions
| Descriptions | Textual descriptions of the video component of the media resource, intended for audio synthesis when the visual component is unavailable (e.g. because the user is interacting with the application without a screen while driving, or because the user is blind). Synthesized as separate audio track. |
chapters
| Chapters | Chapter titles, intended to be used for navigating the media resource. Displayed as an interactive list in the user agent's interface. |
metadata
| Metadata | Tracks intended for use from script. Not displayed by the user agent. |
The attribute may be omitted. The missing value default is the subtitles state.
The src
attribute
gives the address of the text track data. The value must be a
valid non-empty URL potentially surrounded by
spaces. This attribute must be present.
The srclang
attribute gives the language of the text track data. The value must
be a valid BCP 47 language tag. This attribute must be present if
the element's kind
attribute is
in the subtitles
state. [BCP47]
The label
attribute gives a user-readable title for the track. This title is
used by user agents when listing subtitle, caption, and audio description tracks
in their user interface.
The value of the label
attribute, if the attribute is present, must not be the empty
string. Furthermore, there must not be two track
element children of the same media element whose kind
attributes are in the same
state, whose srclang
attributes are both missing or have values that represent the same
language, and whose label
attributes are again both missing or both have the same value.
The default
attribute, if specified, indicates that the track is to be enabled
if the user's preferences do not indicate that another track would
be more appropriate. There must not be more than one
track
element with the same parent node with the default
attribute specified.
track
Returns the TextTrack
object corresponding to the text track of the track
element.
This video has subtitles in several languages:
<video src="brave.webm"> <track kind=subtitles src=brave.en.vtt srclang=en label="English"> <track kind=captions src=brave.en.vtt srclang=en label="English for the Hard of Hearing"> <track kind=subtitles src=brave.fr.vtt srclang=fr label="Français"> <track kind=subtitles src=brave.de.vtt srclang=de label="Deutsch"> </video>
Media elements
(audio
and video
, in this specification)
implement the following interface:
interface HTMLMediaElement : HTMLElement {
// error state
readonly attribute MediaError error;
// network state
attribute DOMString src;
readonly attribute DOMString currentSrc;
const unsigned short NETWORK_EMPTY = 0;
const unsigned short NETWORK_IDLE = 1;
const unsigned short NETWORK_LOADING = 2;
const unsigned short NETWORK_NO_SOURCE = 3;
readonly attribute unsigned short networkState;
attribute DOMString preload;
readonly attribute TimeRanges buffered;
void load();
DOMString canPlayType(in DOMString type);
// ready state
const unsigned short HAVE_NOTHING = 0;
const unsigned short HAVE_METADATA = 1;
const unsigned short HAVE_CURRENT_DATA = 2;
const unsigned short HAVE_FUTURE_DATA = 3;
const unsigned short HAVE_ENOUGH_DATA = 4;
readonly attribute unsigned short readyState;
readonly attribute boolean seeking;
// playback state
attribute double currentTime;
readonly attribute double initialTime;
readonly attribute double duration;
readonly attribute Date startOffsetTime;
readonly attribute boolean paused;
attribute double defaultPlaybackRate;
attribute double playbackRate;
readonly attribute TimeRanges played;
readonly attribute TimeRanges seekable;
readonly attribute boolean ended;
attribute boolean autoplay;
attribute boolean loop;
void play();
void pause();
// controls
attribute boolean controls;
attribute double volume;
attribute boolean muted;
// tracks
readonly attribute TextTrack[] textTracks;
MutableTextTrack addTrack(in DOMString kind, in optional DOMString label, in optional DOMString language);
};
The media element attributes, src
, preload
, autoplay
,
loop
, and controls
, apply to all media elements. They are defined in
this section.
Media elements are used to present audio data, or video and audio data, to the user. This is referred to as media data in this section, since this section applies equally to media elements for audio or for video. The term media resource is used to refer to the complete set of media data, e.g. the complete video file, or complete audio file.
error
Returns a MediaError
object representing the
current error state of the element.
Returns null if there is no error.
interface MediaError { const unsigned short MEDIA_ERR_ABORTED = 1; const unsigned short MEDIA_ERR_NETWORK = 2; const unsigned short MEDIA_ERR_DECODE = 3; const unsigned short MEDIA_ERR_SRC_NOT_SUPPORTED = 4; readonly attribute unsigned short code; };
error
. code
Returns the current error's error code, from the list below.
MEDIA_ERR_ABORTED
(numeric value 1)MEDIA_ERR_NETWORK
(numeric value 2)MEDIA_ERR_DECODE
(numeric value 3)MEDIA_ERR_SRC_NOT_SUPPORTED
(numeric value 4)src
attribute was not suitable.The src
content
attribute on media elements gives
the address of the media resource (video, audio) to show. The
attribute, if present, must contain a valid non-empty
URL potentially surrounded by spaces.
currentSrc
Returns the address of the current media resource.
Returns the empty string when there is no media resource.
There are two ways to specify a media
resource, the src
attribute, or source
elements. The attribute overrides
the elements.
ISSUE-145 (codecs-vs-octet) blocks progress to Last Call
A media resource can be described in terms of its
type, specifically a MIME type, in some cases
with a codecs
parameter. (Whether the codecs
parameter is allowed or not depends on the
MIME type.) [RFC4281]
Types are usually somewhat incomplete descriptions; for example
"video/mpeg
" doesn't say anything except what
the container type is, and even a type like "video/mp4; codecs="avc1.42E01E,
mp4a.40.2"
" doesn't include information like the actual
bitrate (only the maximum bitrate). Thus, given a type, a user agent
can often only know whether it might be able to play
media of that type (with varying levels of confidence), or whether
it definitely cannot play media of that type.
A type that the user agent knows it cannot render is one that describes a resource that the user agent definitely does not support, for example because it doesn't recognize the container type, or it doesn't support the listed codecs.
The MIME type
"application/octet-stream
" with no parameters is never
a type that the user agent knows it cannot render. User
agents must treat that type as equivalent to the lack of any
explicit Content-Type metadata
when it is used to label a potential media
resource.
In the absence of a
specification to the contrary, the MIME type
"application/octet-stream
" when used with
parameters, e.g.
"application/octet-stream;codecs=theora
", is
a type that the user agent knows it cannot render,
since that parameter is not defined for that type.
canPlayType
(type)Returns the empty string (a negative response), "maybe", or "probably" based on how confident the user agent is that it can play media resources of the given type.
This script tests to see if the user agent supports a
(fictional) new format to dynamically decide whether to use a
video
element or a plugin:
<section id="video"> <p><a href="playing-cats.nfv">Download video</a></p> </section> <script> var videoSection = document.getElementById('video'); var videoElement = document.createElement('video'); var support = videoElement.canPlayType('video/x-new-fictional-format;codecs="kittens,bunnies"'); if (support != "probably" && "New Fictional Video Plug-in" in navigator.plugins) { // not confident of browser support // but we have a plugin // so use plugin instead videoElement = document.createElement("embed"); } else if (support == "") { // no support from browser and no plugin // do nothing videoElement = null; } if (videoElement) { while (videoSection.hasChildNodes()) videoSection.removeChild(videoSection.firstChild); videoElement.setAttribute("src", "playing-cats.nfv"); videoSection.appendChild(videoElement); } </script>
The type
attribute of the source
element allows the user agent
to avoid downloading resources that use formats it cannot
render.
networkState
Returns the current state of network activity for the element, from the codes in the list below.
NETWORK_EMPTY
(numeric value 0)NETWORK_IDLE
(numeric value 1)NETWORK_LOADING
(numeric value 2)NETWORK_NO_SOURCE
(numeric value 3)load
()Causes the element to reset and start selecting and loading a new media resource from scratch.
The preload
attribute is an enumerated attribute. The following table
lists the keywords and states for the attribute — the keywords
in the left column map to the states in the cell in the second
column on the same row as the keyword.
Keyword | State | Brief description |
---|---|---|
none
| None | Hints to the user agent that either the author does not expect the user to need the media resource, or that the server wants to minimise unnecessary traffic. |
metadata
| Metadata | Hints to the user agent that the author does not expect the user to need the media resource, but that fetching the resource metadata (dimensions, first frame, track list, duration, etc) is reasonable. |
auto
| Automatic | Hints to the user agent that the user agent can put the user's needs first without risk to the server, up to and including optimistically downloading the entire resource. |
The empty string is also a valid keyword, and maps to the Automatic state. The attribute's missing value default is user-agent defined, though the Metadata state is suggested as a compromise between reducing server load and providing an optimal user experience.
The autoplay
attribute can override
the preload
attribute (since
if the media plays, it naturally has to buffer first, regardless of
the hint given by the preload
attribute). Including
both is not an error, however.
