4.7. Embedded content
4.7.1. Introduction
This section is non-normative.
To embed an image in HTML, when there is only a single image resource,
use the img
element and with its src
and alt
attributes.
<h2>From today’s featured article</h2> <img src="/uploads/100-marie-lloyd.jpg" alt="" width="100" height="150"> <p><b><a href="/wiki/Marie_Lloyd">Marie Lloyd</a></b> (1870–1922) was an English <a href="/wiki/Music_hall">music hall</a> singer, ...
However, there are a number of situations for which the author might wish to use multiple image resources that the user agent can choose from:
-
Different users might have different environmental characteristics:
-
The users' physical screen size might be different from one another.
A mobile phone’s screen might be 4 inches diagonally, while a laptop’s screen might be 14 inches diagonally.This is only relevant when an image’s rendered size depends on the viewport size.
-
The users' screen pixel density might be different from one another.
-
The users' zoom level might be different from one another, or might change for a single user over time.
A user might zoom in to a particular image to be able to get a more detailed look.
The zoom level and the screen pixel density (the previous point) can both affect the number of physical screen pixels per CSS pixel. This ratio is usually referred to as device-pixel-ratio.
-
The users' screen orientation might be different from one another, or might change for a single user over time.
-
The users' network speed, network latency and bandwidth cost might be different from one another, or might change for a single user over time.
A user might be on a fast, low-latency and constant-cost connection while at work, on a slow, low-latency and constant-cost connection while at home, and on a variable-speed, high-latency and variable-cost connection anywhere else.
-
-
Authors might want to show the same image content but with different rendered size depending on, usually, the width of the viewport. This is usually referred to as viewport-based selection.
A Web page might have a banner at the top that always spans the entire viewport width. In this case, the rendered size of the image depends on the physical size of the screen (assuming a maximised browser window).Another Web page might have images in columns, with a single column for screens with a small physical size, two columns for screens with medium physical size, and three columns for screens with big physical size, with the images varying in rendered size in each case to fill up the viewport. In this case, the rendered size of an image might be bigger in the one-column layout compared to the two-column layout, despite the screen being smaller. -
Authors might want to show different image content depending on the rendered size of the image. This is usually referred to as art direction.
When a Web page is viewed on a screen with a large physical size (assuming a maximised browser window), the author might wish to include some less relevant parts surrounding the critical part of the image. When the same Web page is viewed on a screen with a small physical size, the author might wish to show only the critical part of the image. -
Authors might want to show the same image content but using different image formats, depending on which image formats the user agent supports. This is usually referred to as image format-based selection.
A Web page might have some images in the JPEG, WebP and JPEG XR image formats, with the latter two having better compression abilities compared to JPEG. Since different user agents can support different image formats, with some formats offering better compression ratios, the author would like to serve the better formats to user agents that support them, while providing JPEG fallback for user agents that don’t.
The above situations are not mutually exclusive. For example, it is reasonable to combine different resources for different device-pixel-ratio with different resources for art direction.
While it is possible to solve these problems using scripting, doing so introduces some other problems:
- Some user agents aggressively download images specified in the HTML markup, before scripts have had a chance to run, so that Web pages complete loading sooner. If a script changes which image to download, the user agent will potentially start two separate downloads, which can instead cause worse page loading performance.
- If the author avoids specifying any image in the HTML markup and instead instantiates a single download from script, that avoids the double download problem above but instead it makes no image be downloaded at all for users with scripting disabled and it disables the agressive image downloading optimization.
With this in mind, this specification introduces a number of features to address the above problems in a declarative manner.
- Device-pixel-ratio-based selection when the rendered size of the image is fixed
-
The
src
andsrcset
attributes on theimg
element can be used, using thex
descriptor, to provide multiple images that only vary in their size (the smaller image is a scaled-down version of the bigger image).The
x
descriptor is not appropriate when the rendered size of the image depends on the viewport width (viewport-based selection), but can be used together with art direction.<h2>From today’s featured article</h2> <img src="/uploads/100-marie-lloyd.jpg" srcset="/uploads/150-marie-lloyd.jpg 1.5x, /uploads/200-marie-lloyd.jpg 2x" alt="" width="100" height="150"> <p><b><a href="/wiki/Marie_Lloyd">Marie Lloyd</a></b> (1870–1922) was an English <a href="/wiki/Music_hall">music hall</a> singer, ...
The user agent can choose any of the given resources depending on the user’s screen’s pixel density, zoom level, and possibly other factors such as the user’s network conditions.
For backwards compatibility with older user agents that don’t yet understand the
srcset
attribute, one of the URLs is specified in theimg
element’ssrc
attribute. This will result in something useful (though perhaps lower-resolution than the user would like) being displayed even in older user agents. For new user agents, thesrc
attribute participates in the resource selection, as if it was specified insrcset
with a1x
descriptor.The image’s rendered size is given in the
width
andheight
attributes, which allows the user agent to allocate space for the image before it is downloaded. - Viewport-based selection
-
The
srcset
andsizes
attributes can be used, using thew
descriptor, to provide multiple images that only vary in their size (the smaller image is a scaled-down version of the bigger image).In this example, a banner image takes up the entire viewport width (using appropriate CSS).<h1><img sizes="100vw" srcset="wolf-400.jpg 400w, wolf-800.jpg 800w, wolf-1600.jpg 1600w" src="wolf-400.jpg" alt="The rad wolf"></h1>
The user agent will calculate the effective pixel density of each image from the specified
w
descriptors and the specified rendered size in thesizes
attribute. It can then choose any of the given resources depending on the user’s screen’s pixel density, zoom level, and possibly other factors such as the user’s network conditions.If the user’s screen is 320 CSS pixels wide, this is equivalent to specifying
wolf-400.jpg 1.25x, wolf-800.jpg 2.5x, wolf-1600.jpg 5x
. On the other hand, if the user’s screen is 1200 CSS pixels wide, this is equivalent to specifyingwolf-400.jpg 0.33x, wolf-800.jpg 0.67x, wolf-1600.jpg 1.33x
. By using thew
descriptors and thesizes
attribute, the user agent can choose the correct image source to download regardless of how large the user’s device is.For backwards compatibility, one of the URLs is specified in the
element’ssrc
attribute. In new user agents, thesrc
attribute is ignored when thesrcset
attribute usesw
descriptors.In this example, the
sizes
attribute could be omitted because the default value is100vw
.In this example, the Web page has three layouts depending on the width of the viewport. The narrow layout has one column of images (the width of each image is about 100%), the middle layout has two columns of images (the width of each image is about 50%), and the widest layout has three columns of images, and some page margin (the width of each image is about 33%). It breaks between these layouts when the viewport is30em
wide and50em
wide, respectively.<img sizes="(max-width: 30em) 100vw, (max-width: 50em) 50vw, calc(33vw - 100px)" srcset="swing-200.jpg 200w, swing-400.jpg 400w, swing-800.jpg 800w, swing-1600.jpg 1600w" src="swing-400.jpg" alt="Kettlebell Swing">
The
sizes
attribute sets up the layout breakpoints at30em
and50em
, and declares the image sizes between these breakpoints to be100vw
,50vw
, orcalc(33vw - 100px)
. These sizes do not necessarily have to match up exactly with the actual image width as specified in the CSS.The user agent will pick a width from the
sizes
attribute, using the first item with a <media-condition> (the part in parentheses) that evaluates to true, or using the last item (calc(33vw - 100px)
) if they all evaluate to false.For example, if the viewport width is
29em
, then(max-width: 30em)
evaluates to true and100vw
is used, so the image size, for the purpose of resource selection, is29em
. If the viewport width is instead32em
, then(max-width: 30em)
evaluates to false, but(max-width: 50em)
evaluates to true and50vw
is used, so the image size, for the purpose of resource selection, is16em
(half the viewport width). Notice that the slightly wider viewport results in a smaller image because of the different layout.The user agent can then calculate the effective pixel density and choose an appropriate resource similarly to the previous example.
- Art direction-based selection
-
The
element and thesource
element, together with themedia
attribute, can be used, to provide multiple images that vary the image content (for intance the smaller image might be a cropped version of the bigger image).<picture> <source media="(min-width: 45em)" srcset="large.jpg"> <source media="(min-width: 32em)" srcset="med.jpg"> <img src="small.jpg" alt="The wolf runs through the snow."> </picture>
The user agent will choose the first
source
element for which the media query in themedia
attribute matches, and then choose an appropriate URL from itssrcset
attribute.The rendered size of the image varies depending on which resource is chosen. To specify dimensions that the user agent can use before having downloaded the image, CSS can be used.
img { width: 300px; height: 300px } @media (min-width: 32em) { img { width: 500px; height:300px } } @media (min-width: 45em) { img { width: 700px; height:400px } }
This example combines art direction- and device-pixel-ratio-based selection. A banner that takes half the viewport is provided in two versions, one for wide screens and one for narrow screens.<h1> <picture> <source media="(max-width: 500px)" srcset="banner-phone.jpeg, banner-phone-HD.jpeg 2x"> <img src="banner.jpeg" srcset="banner-HD.jpeg 2x" alt="The Breakfast Combo"> </picture> </h1>
- Image format-based selection
-
The
type
attribute on thesource
element can be used, to provide multiple images in different formats.<h2>From today’s featured article</h2> <picture> <source srcset="/uploads/100-marie-lloyd.webp" type="image/webp"> <source srcset="/uploads/100-marie-lloyd.jxr" type="image/vnd.ms-photo"> <img src="/uploads/100-marie-lloyd.jpg" alt="" width="100" height="150"> </picture> <p><b><a href="/wiki/Marie_Lloyd">Marie Lloyd</a></b> (1870–1922) was an English <a href="/wiki/Music_hall">music hall</a> singer, ...
In this example, the user agent will choose the first
source
that has atype
attribute with a supported MIME type. If the user agent supports WebP images, the firstsource
element will be chosen. If not, but the user agent does support JPEG XR images, the secondsource
element will be chosen. If neither of those formats are supported, theimg
element will be chosen.
4.7.2. Dependencies
- Media Queries [MEDIAQ]
- CSS Values and Units [CSS-VALUES]
- CSS Syntax [CSS-SYNTAX-3]
4.7.3. The picture
element
- Categories:
- Flow content.
- Phrasing content.
- Embedded content.
- Contexts in which this element can be used:
- Where embedded content is expected.
- Content model:
- Zero or more
source
elements, followed by oneimg
element, optionally intermixed with script-supporting elements. - Tag omission in text/html:
- Neither tag is omissible
- Content attributes:
- Global attributes
- Allowed ARIA role attribute values:
- None
- Allowed ARIA state and property attributes:
- None
- DOM interface:
-
interface HTMLPictureElement : HTMLElement {};
The picture
element is a container
which provides multiples sources to its contained img
element
to allow authors to declaratively control or give hints to the user agent about which image resource to use,
based on the screen pixel density, viewport size, image format, and other factors. It represents its children.
The picture
element is somewhat different
from the similar-looking video
and audio
elements.
While all of them contain source
elements,
the source
element’s src
attribute has no meaning
when the element is nested within a picture
element,
and the resource selection algorithm is different.
As well, the picture
element itself does not display anything;
it merely provides a context for its contained img
element
that enables it to choose from multiple URLs.
4.7.4. The source
element
- Categories:
- None.
- Contexts in which this element can be used:
- As a child of a
element, before theimg
element. - As a child of a media element, before any flow content or
track
elements. - Content model:
- Nothing.
- Tag omission in text/html:
- No end tag
- Content attributes:
- Global attributes
src
- Address of the resourcetype
- Type of embedded resourcesrcset
- Images to use in different situations (e.g., high-resolution displays, small monitors, etc)sizes
- Image sizes between breakpointsmedia
- Applicable media- Allowed ARIA role attribute values:
- None
- Allowed ARIA state and property attributes:
- Global aria-* attributes
- DOM interface:
-
interface HTMLSourceElement : HTMLElement { attribute DOMString src; attribute DOMString type; attribute DOMString srcset; attribute DOMString sizes; attribute DOMString media; };
The source
element allows authors to specify multiple alternative source sets for img
elements or multiple alternative media resources for media elements. It does
not represent anything on its own.
The type
attribute may be present. If present,
the value must be a valid MIME type.
The remainder of the requirements depend on whether the parent is a picture
element or a media element:
source
element’s parent is apicture
element-
The
srcset
content attribute must be present, and must consist of one or more image candidate strings, each separated from the next by a U+002C COMMA character (,). If an image candidate string contains no descriptors and no space characters after the URL, the following image candidate string, if there is one, must begin with one or more space characters.If the
srcset
attribute has any image candidate strings using a width descriptor, thesizes
content attribute must also be present, and the value must be a valid source size list.The
media
content attribute may also be present. If present, the value must contain a valid media query list.The
type
gives the type of the images in the source set, to allow the user agent to skip to the nextsource
element if it does not support the given type.If the
type
attribute is not specified, the user agent will not select a differentsource
element if it finds that it does not support the image format after fetching it.When a
source
element has a following siblingsource
element orimg
element with asrcset
attribute specified, it must have at least one of the following:-
A
media
attribute specified with a value that, after stripping leading and trailing white space, is not the empty string and is not an ASCII case-insensitive match for the string "all
". -
A
type
attribute specified.
The
src
attribute must not be present. -
source
element’s parent is a media element-
The
src
attribute gives the address of the media resource. The value must be a valid non-empty URL potentially surrounded by spaces. This attribute must be present.Dynamically modifying a
source
element and its attribute when the element is already inserted in avideo
oraudio
element will have no effect. To change what is playing, just use thesrc
attribute on the media element directly, possibly making use of thecanPlayType()
method to pick from amongst available resources. Generally, manipulatingsource
elements manually after the document has been parsed is an unnecessarily complicated approach.The
type
content attribute gives the type of the media resource, to help the user agent determine if it can play this media resource before fetching it. If specified, its value must be a valid MIME type. Thecodecs
parameter, which certain MIME types define, might be necessary to specify exactly how the resource is encoded. [RFC6381]The following list shows some examples of how to use thecodecs=
MIME parameter in thetype
attribute.- H.264 Constrained baseline profile video (main and extended video compatible) level 3 and Low-Complexity AAC audio in MP4 container
- H.264 Extended profile video (baseline-compatible) level 3 and Low-Complexity AAC audio in MP4 container
- H.264 Main profile video level 3 and Low-Complexity AAC audio in MP4 container
- H.264 "High" profile video (incompatible with main, baseline, or extended profiles) level 3 and Low-Complexity AAC audio in MP4 container
- MPEG-4 Visual Simple Profile Level 0 video and Low-Complexity AAC audio in MP4 container
- MPEG-4 Advanced Simple Profile Level 0 video and Low-Complexity AAC audio in MP4 container
- MPEG-4 Visual Simple Profile Level 0 video and AMR audio in 3GPP container
- Theora video and Vorbis audio in Ogg container
- Theora video and Speex audio in Ogg container
- Vorbis audio alone in Ogg container
- Speex audio alone in Ogg container
- FLAC audio alone in Ogg container
- Dirac video and Vorbis audio in Ogg container
The
srcset
,sizes
, andmedia
attributes must not be present.
If a source
element is inserted as a child of a media element that has no src
attribute and whose networkState
has the value NETWORK_EMPTY
, the user agent must invoke the media element’s resource selection algorithm.
The IDL attributes src
, type
, srcset
, sizes
and media
must reflect the
respective content attributes of the same name.
error
event on the last source
element and trigger fallback behavior:
<script> function fallback(video) { // replace <video> with its contents while (video.hasChildNodes()) { if (video.firstChild instanceof HTMLSourceElement) video.removeChild(video.firstChild); else video.parentNode.insertBefore(video.firstChild, video); } video.parentNode.removeChild(video); } </script> <video controls autoplay> <source src='video.mp4' type='video/mp4; codecs="avc1.42E01E, mp4a.40.2"'> <source src='video.ogv' type='video/ogg; codecs="theora, vorbis"' onerror="fallback(parentNode)"> ... </video>
4.7.5. The img
element
- Categories:
- Flow content.
- Phrasing content.
- Embedded content.
- Form-associated element.
- If the element has a
usemap
attribute: interactive content. - Palpable content.
- Contexts in which this element can be used:
- Where embedded content is expected.
- Content model:
- Nothing
- Tag omission in text/html:
- No end tag.
- Content attributes:
- Global attributes
alt
- Replacement text for use when images are not availablesrc
- Address of the resourcesrcset
- Images to use in different situations (e.g., high-resolution displays, small monitors, etc)sizes
- Image sizes between breakpointscrossorigin
- How the element handles crossorigin requestsusemap
- Name of image map to useismap
- Whether the image is a server-side image mapwidth
- Horizontal dimensionheight
- Vertical dimensionlongdesc
- A url that provides a link to an expanded description of the image, defined in [html-longdesc]- Allowed ARIA role attribute values:
presentation
ornone
role only, for animg
element whosealt
attribute’s value is empty (alt=""
), otherwise Any role value.- Allowed ARIA state and property attributes:
- Global aria-* attributes
- Any
aria-*
attributes applicable to the allowed roles. - DOM interface:
-
[NamedConstructor=Image(optional unsigned long width, optional unsigned long height)] interface HTMLImageElement : HTMLElement { attribute DOMString alt; attribute DOMString src; attribute DOMString srcset; attribute DOMString sizes; attribute DOMString? crossOrigin; attribute DOMString useMap; attribute DOMString longDesc; attribute boolean isMap; attribute unsigned long width; attribute unsigned long height; readonly attribute unsigned long naturalWidth; readonly attribute unsigned long naturalHeight; readonly attribute boolean complete; readonly attribute DOMString currentSrc; };
An img
element represents an image and its fallback content.
The image given by the src
and srcset
attributes,
and any previous sibling source
elements' srcset
attributes if the parent is a picture
element,
is the embedded content; the value of
the alt
attribute and the content referred to by
the longdesc
attribute are the img
element’s fallback content, and provide equivalent content for
users and user agents who cannot process images or have image loading disabled.
Requirements for alternative representations of the image are described in the next section.
The src
attribute must be present, and must contain a valid non-empty URL potentially surrounded by spaces referencing a non-interactive,
optionally animated, image resource that is neither paged nor scripted.
The srcset
attribute may also be present.
If present, its value must consist of one or more image candidate strings,
each separated from the next by a U+002C COMMA character (,).
If an image candidate string contains no descriptors
and no space characters after the URL,
the following image candidate string, if there is one,
must begin with one or more space characters.
An image candidate string consists of the following components, in order, with the further restrictions described below this list:
- Zero or more space characters.
- A valid non-empty URL that does not start or end with a U+002C COMMA character (,), referencing a non-interactive, optionally animated, image resource that is neither paged nor scripted.
- Zero or more space characters.
-
Zero or one of the following:
- A width descriptor, consisting of: a space character, a valid non-negative integer giving a number greater than zero representing the width descriptor value, and a U+0077 LATIN SMALL LETTER W character.
- A pixel density descriptor, consisting of: a space character, a valid floating-point number giving a number greater than zero representing the pixel density descriptor value, and a U+0078 LATIN SMALL LETTER X character.
- Zero or more space characters.
There must not be an image candidate string for an element that has the same width descriptor value as another image candidate string’s width descriptor value for the same element.
There must not be an image candidate string for an element that
has the same pixel density descriptor value as another image candidate string’s pixel density descriptor value for the same element.
For the purpose of this requirement,
an image candidate string with no descriptors is equivalent to
an image candidate string with a 1x
descriptor.
If a source
element has a sizes
attribute present
or an img
element has a sizes
attribute present,
all image candidate strings for that
element must have the width descriptor specified.
If an image candidate string for a source
or img
element has the width descriptor specified, all other image candidate strings for that element must also
have the width descriptor specified.
The specified width in an image candidate string’s width descriptor must match the intrinsic width in the resource given by the image candidate string’s URL, if it has an intrinsic width.
The requirements above imply that images can be static bitmaps (e.g., PNGs, GIFs, JPEGs), single-page vector documents (single-page PDFs, XML files with an SVG document element), animated bitmaps (APNGs, animated GIFs), animated vector graphics (XML files with an SVG document element that use declarative SMIL animation), and so forth. However, these definitions preclude SVG files with script, multipage PDF files, interactive MNG files, HTML documents, plain text documents, and so forth. [PNG] [GIF] [JPEG] [PDF] [XML] [APNG] [SVG] [MNG]
If the srcset
attribute is present,
the sizes
attribute may also be present.
If present, its value must be a valid source size list.
A valid source size list is a string that matches the following grammar: [CSS-VALUES] [MEDIAQ]
<source-size-list> = <source-size># [ , <source-size-value> ]? | <source-size-value> <source-size> = <media-condition> <source-size-value> <source-size-value> = <length>
A <source-size-value>
must not be negative.
Percentages are not allowed in a <source-size-value>
,
to avoid confusion about what it would be relative to.
The vw
unit can be used for sizes relative to the viewport width.
The img
element must not be used as a layout tool. In particular, img
elements should not be used to display transparent images, as such images rarely convey meaning and
rarely add anything useful to the document.
The crossorigin
attribute is a CORS
settings attribute. Its purpose is to allow images from third-party sites that allow
cross-origin access to be used with canvas
.
An img
element has a current request and a pending request.
The current request is initially set to a new image request.
The pending request is initially set to null.
The current request is usually referred to as the img
element itself.
An image request has a state, current URL and image data.
An image request’s state is one of the following:
- Unavailable
- The user agent hasn’t obtained any image data, or has obtained some or all of the image data but hasn’t yet decoded enough of the image to get the image dimensions.
- Partially available
- The user agent has obtained some of the image data and at least the image dimensions are available.
- Completely available
- The user agent has obtained all of the image data and at least the image dimensions are available.
- Broken
- The user agent has obtained all of the image data that it can, but it cannot even decode the image enough to get the image dimensions (e.g., the image is corrupted, or the format is not supported, or no data could be obtained).
An image request’s current URL is initially the empty string.
An image request’s image data is the decoded image data.
When an image request is either in the partially available state or in the completely available state, it is said to be available.
An image request is initially unavailable.
When an img
element is available,
it provides a paint source whose width is the image’s density-corrected intrinsic width (if any),
whose height is the image’s density-corrected intrinsic height (if any),
and whose appearance is the intrinsic appearance of the image.
In a browsing context where scripting is disabled, user agents may obtain images immediately or on demand. In a browsing context where scripting is enabled, user agents must obtain images immediately.
A user agent that obtains images immediately must immediately update the image data of an img
element,
with the restart animation flag set if so stated,
whenever that element is created or has experienced relevant mutations.
A user agent that obtains images on demand must update the image data of an img
element whenever it needs the image data (i.e., on demand),
but only if the img
element is in the unavailable state. When an img
element
has experienced relevant mutations, if the user
agent only obtains images on demand, the img
element must return to the unavailable state.
The relevant mutations for an img
element are as follows:
- The element’s
src
,srcset
,width
, orsizes
attributes are set, changed, or removed. - The element’s
src
attribute is set to the same value as the previous value. This must set the restart animation flag for the update the image data algorithm. - The element’s
crossorigin
attribute’s state is changed. - The element is inserted into or removed from a
parent element. - The element’s parent is a
element and asource
element is inserted as a previous sibling. - The element’s parent is a
element and asource
element that was a previous sibling is removed. - The element’s parent is a
element and asource
element that is a previous sibling has itssrcset
,sizes
,media
ortype
attributes set, changed, or removed. - The element’s adopting steps are run.
Each img
element has a last selected source, which must initially be
null.
Each image request has a current pixel density, which must initially be undefined.
When an img
element has a current pixel density that is not 1.0, the
element’s image data must be treated as if its resolution, in device pixels per CSS pixels, was
the current pixel density.
The image’s density-corrected intrinsic width and height are the intrinsic width and height after taking into account the current pixel density.
For example, given a screen with 96 CSS pixels per CSS inch, if the current pixel density is 3.125, that means that there are 96 × 3.125 = 300 device pixels per CSS inch, and thus if the image data is 300x600, it has intrinsic dimensions of 300 ÷ 3.125 = 96 CSS pixels by 600 ÷ 3.125 = 192 CSS pixels. With a current pixel density of 2.0 (192 device pixels per CSS inch) and the same image data (300x600), the intrinsic dimensions would be 150x300.
Each Document
object must have a list of available images. Each image
in this list is identified by a tuple consisting of an absolute URL, a CORS
settings attribute mode, and, if the mode is not No CORS, an origin.
Each image furthermore has an ignore higher-layer caching flag.
User agents may copy entries from one Document
object’s list of available images to another at any time (e.g., when the Document
is created, user agents can add to it all the images that are loaded in
other Document
s), but must not change the keys of entries copied in this way when
doing so, and must unset the ignore higher-layer caching flag for the copied entry.
User agents may also remove images from such lists at any time (e.g., to save
memory).
User agents must remove entries in the list of available images as appropriate
given higher-layer caching semantics for the resource (e.g., the HTTP Cache-Control
response header) when the ignore higher-layer caching flag is unset.
The list of available images is intended to enable synchronous
switching when changing the src
attribute to a URL that has
previously been loaded, and to avoid re-downloading images in the same document even when they
don’t allow caching per HTTP. It is not used to avoid re-downloading the same image while the
previous image is still loading.
For example, if a resource has the HTTP response header Cache-Control: must-revalidate
,
the user agent would remove it from the list of available images but could keep the image data separately,
and use that if the server responds with a 204 No Content
status.
When the user agent is to update the image data of an img
element,
optionally with the restart animations flag set,
it must run the following steps:
-
If the element’s node document is not the active document, then run these substeps:
- Continue running this algorithm in parallel.
- Wait until the element’s node document is the active document.
- If another instance of this algorithm for this
element was started after this instance (even if it aborted and is no longer running), then abort these steps. - Queue a microtask to continue this algorithm.
- If the user agent cannot support images, or its support for images has been disabled, then abort the image request for the current request and the pending request, set current request to the unavailable state, let pending request be null, and abort these steps.
-
If the element does not use
srcset
orpicture
and it does not have a parent or it has a parent but it is not apicture
element, and it has asrc
attribute specified and its value is not the empty string, let selected source be the value of the element’ssrc
attribute, and selected pixel density be 1.0. Otherwise, let selected source be null and selected pixel density be undefined. - Let the
element’s last selected source be selected source. -
If selected source is not null, run these substeps:
- Parse selected source, relative to the element’s node document. If that is not successful, then abort these inner set of steps. Otherwise, let urlString be the resulting URL string.
- Let key be a tuple consisting of urlString, the
element’scrossorigin
attribute’s mode, and, if that mode is not No CORS, the node document’s origin. -
If the list of available images contains an entry for key, run these subsubsteps:
- Set the ignore higher-layer caching flag for that entry.
- Abort the image request for the current request and the pending request.
- Let pending request be null.
- Let current request be a new image request whose image data is that of the entry and whose state is set to the completely available state.
- Update the presentation of the image appropriately.
- Let the current request’s current pixel density be selected pixel density.
- Queue a task to restart the animation if restart
animation is set, change current request’s current URL to urlString, and then fire a simple event named
load
at theimg
element. - Abort the update the image data algorithm.
- in parallel await a stable state, allowing the task that invoked this algorithm to continue. The synchronous section consists of all the remaining steps of this algorithm until the algorithm says the synchronous section has ended. (Steps in synchronous sections are marked with ⌛.)
-
⌛ If another instance of this algorithm for this
element was started after this instance (even if it aborted and is no longer running), then abort these steps.Only the last instance takes effect, to avoid multiple requests when, for example, the
src
,srcset
, andcrossorigin
attributes are all set in succession. -
⌛ Let selected source and selected pixel density be the URL and pixel density that results from selecting an image source, respectively.
-
⌛ If selected source is null, run these substeps:
- ⌛ Set the current request to the broken state, abort the image request for the current request and the pending request, and let pending request be null.
- ⌛ Queue a task to change the current request’s current URL to
the empty string, and then, if the element has a
src
attribute or it usessrcset
orpicture
, fire a simple event namederror
at theimg
element. - ⌛ Abort this algorithm.
-
⌛ Queue a task to fire a progress event named
loadstart
at theimg
element.⌛ Parse selected source, relative to the element’s node document, and let urlString be the resulting URL string. If that is not successful, run these substeps:
- ⌛ Abort the image request for the current request and the pending request.
- ⌛ Set the current request to the broken state.
- ⌛ Let pending request be null.
- ⌛ Queue a task to change the current request’s current URL to selected source, fire a simple event named
error
at theimg
element and then fire a simple event namedloadend
at theimg
element. - ⌛ Abort the update the image data algorithm.
-
⌛ If the pending request is not null, and urlString is the same as the pending request’s current URL, then abort these steps.
⌛ If urlString is the same as the current request’s current URL, and current request is in the partially available state, then abort the image request for the pending request, queue a task to restart the animation if restart animation is set, and abort these steps.
⌛ If the pending request is not null, abort the image request for the pending request.
⌛ Let image request be a new image request whose current URL is urlString.
⌛ If current request is in the unavailable state or the broken state, let the current request be image request. Otherwise, let the pending request be image request.
⌛ Let request be the result of creating a potential-CORS request given urlString and the current state of the element’s
crossorigin
content attribute.⌛ Set request’s client to the element’s node document’s
Window
object’s environment settings object and type to "image
".⌛ If the element uses
srcset
orpicture
, set request’s initiator to "imageset
".⌛ Set request’s same-origin data-URL flag.
⌛ Fetch request. Let this instance of the fetching algorithm be associated with image request.
The resource obtained in this fashion, if any, is image request’s image data. It can be either CORS-same-origin or CORS-cross-origin; this affects the origin of the image itself (e.g., when used on a
canvas
).Fetching the image must delay the load event of the element’s node document until the task that is queued by the networking task source once the resource has been fetched (defined below) has been run.
This, unfortunately, can be used to perform a rudimentary port scan of the user’s local network (especially in conjunction with scripting, though scripting isn’t actually necessary to carry out such an attack). User agents may implement cross-origin access control policies that are stricter than those described above to mitigate this attack, but unfortunately such policies are typically not compatible with existing Web content.
If the resource is CORS-same-origin, each task that is queued by the networking task source while the image is being fetched, if image request is the current request, must fire a progress event named
progress
at theimg
element. - End the synchronous section, continuing the remaining steps in parallel, but without missing any data from fetching.
-
As soon as possible, jump to the first applicable entry from the following list:
- If the resource type is
multipart/x-mixed-replace
-
The next task that is queued by the networking task source while the image is being fetched must run the following steps:
-
If image request is the pending request and at least one body part has been completely decoded, abort the image request for the current request, upgrade the pending request to the current request.
-
Otherwise, if image request is the pending request and the user agent is able to determine that image request’s image is corrupted in some fatal way such that the image dimensions cannot be obtained, abort the image request for the current request, upgrade the pending request to the current request and set the current request’s state to broken.
-
Otherwise, if image request is the current request, it is in the unavailable state, and the user agent is able to determine image request’s image’s width and height, set the current request’s state to partially available.
-
Otherwise, if image request is the current request, it is in the unavailable state, and the user agent is able to determine that image request’s image is corrupted in some fatal way such that the image dimensions cannot be obtained, set the current request’s state to broken.
Each task that is queued by the networking task source while the image is being fetched must update the presentation of the image, but as each new body part comes in, it must replace the previous image. Once one body part has been completely decoded, the user agent must set the
element to the completely available state and queue a task to fire a simple event namedload
at theimg
element.The
progress
andloadend
events are not fired formultipart/x-mixed-replace
image streams. -
- If the resource type and data corresponds to a supported image format, as described below
-
The next task that is queued by the networking task source while the image is being fetched must run the following steps:
-
If the user agent is able to determine image request’s image’s width and height, and image request is pending request, set image request’s state to partially available.
-
Otherwise, if the user agent is able to determine image request’s image’s width and height, and image request is current request, update the
element’s presentation appropriately and set image request’s state to partially available. -
Otherwise, if the user agent is able to determine that image request’s image is corrupted in some fatal way such that the image dimensions cannot be obtained, and image request is pending request, abort the image request for the current request and the pending request, upgrade the pending request to the current request, set current request to the broken state, fire a simple event named
error
at theimg
element, fire a simple event namedloadend
at theimg
element, and abort these steps. -
Otherwise, if the user agent is able to determine that image request’s image is corrupted in some fatal way such that the image dimensions cannot be obtained, and image request is current request, abort the image request for image request, fire a simple event named
error
at theimg
element, fire a simple event namedloadend
at theimg
element, and abort these steps.
That task, and each subsequent task, that is queued by the networking task source while the image is being fetched, if image request is the current request, must update the presentation of the image appropriately (e.g., if the image is a progressive JPEG, each packet can improve the resolution of the image).
Furthermore, the last task that is queued by the networking task source once the resource has been fetched must additionally run these steps:
- If image request is the pending request, abort the image request for the current request, upgrade the pending request to the current request and
update the
element’s presentation appropriately. - Set image request to the completely available state.
- Add the image to the list of available images using the key key, with the ignore higher-layer caching flag set.
- Fire a progress event or simple event named
load
at theimg
element, depending on the resource in image request. - Fire a progress event or simple event named
loadend
at theimg
element, depending on the resource in image request.
-
- Otherwise
-
The image data is not in a supported file format; the user agent must set image request to the broken state, abort the image request for the current request and the pending request, upgrade the pending request to the current request if image request is the pending request, and then queue a task to first fire a simple event named
error
at theimg
element and then fire a simple event namedloadend
at theimg
element.
- If the resource type is
To abort the image request for an image request image request means to run the following steps:
- Forget image request’s image data, if any.
- Abort any instance of the fetching algorithm for image request, discarding any pending tasks generated by that algorithm.
To upgrade the pending request to the current request for an img
element means to run the following steps:
- Let the
element’s current request be the pending request. - Let the
element’s pending request be null.
To fire a progress event or simple event named type at an element e, depending on resource r, means to fire a progress event named type at e if r is CORS-same-origin, and otherwise fire a simple event named type at e.
While a user agent is running the above algorithm for an element x, there
must be a strong reference from the element’s node document to the element x,
even if that element is not in its Document
.
An img
element is said to use srcset
or picture
if it has a srcset
attribute specified or if it has a parent that is a picture
element.
When an img
element is in the completely available state and the user agent can decode the media data without errors, then the img
element is said to be fully decodable.
Whether the image is fetched successfully or not (e.g., whether the response status was an ok status) must be ignored when determining the image’s type and whether it is a valid image.
This allows servers to return images with error responses, and have them displayed.
The user agent should apply the image sniffing rules to determine the type of the image, with the image’s associated Content-Type headers giving the official type. If these rules are not applied, then the type of the image must be the type given by the image’s associated Content-Type headers.
User agents must not support non-image resources with the img
element (e.g., XML files whose document element is an HTML element). User agents must not run executable code (e.g.,
scripts) embedded in the image resource. User agents must only display the first page of a
multipage resource (e.g., a PDF file). User agents must not allow the resource to act in an
interactive fashion, but should honor any animation in the resource.
This specification does not specify which image types are to be supported.
An img
element is associated with a source set.
A source set is an ordered set of zero or more image sources and a source size.
An image source is a URL, and optionally either a density descriptor, or a width descriptor.
A source size is a <source-size-value>
.
When a source size has a unit relative to the viewport,
it must be interpreted relative to the img
element’s document’s viewport.
Other units must be interpreted the same as in Media Queries. [MEDIAQ]
When asked to select an image source for a given img
element el, user agents must do the following:
- Update the source set for el.
- If el’s source set is empty, return null as the URL and undefined as the pixel density and abort these steps.
- Otherwise, take el’s source set and let it be source set.
- If an entry b in source set has the same associated density descriptor as an earlier entry a in source set, then remove entry b. Repeat this step until none of the entries in source set have the same associated density descriptor as an earlier entry.
- In a user agent-specific manner, choose one image source from source set. Let this be selected source.
- Return selected source and its associated pixel density.
When asked to update the source set for a given img
element el,
user agents must do the following:
- Set el’s source set to an empty source set.
- If el has a parent node and that is a
element, let elements be an array containing el’s parent node’s child elements, retaining relative order. Otherwise, let elements be array containing only el. - If el has a
width
attribute, and parsing that attribute’s value using the rules for parsing dimension values doesn’t generate an error or a percentage value, then let width be the returned integer value. Otherwise, let width be null. -
Iterate through elements, doing the following for each item child:
-
If child is el:
- If child has a
srcset
attribute, parse child’s srcset attribute and let the returned source set be source set. Otherwise, let source set be an empty source set. - Parse child’s sizes attribute with the fallback width width, and let source set’s source size be the returned value.
- If child has a
src
attribute whose value is not the empty string and source set does not contain an image source with a density descriptor value of 1, and no image source with a width descriptor, append child’ssrc
attribute value to source set. - Normalize the source densities of source set.
- Let el’s source set be source set.
- Abort this algorithm.
- If child has a
- If child is not a
source
element, continue to the next child. Otherwise, child is asource
element. - If child does not have a
srcset
attribute, continue to the next child. - Parse child’s
srcset
attribute and let the returned source set be source set. - If source set has zero image sources, continue to the next child.
- If child has a
media
attribute, and its value does not match the environment, continue to the next child. - Parse child’s
sizes
attribute with the fallback width width, and let source set’s source size be the returned value. - If child has a
type
attribute, and its value is an unknown or unsupported MIME type, continue to the next child. - Normalize the source densities of source set.
- Let el’s source set be source set.
- Abort this algorithm.
-
Each img
element independently considers
its previous sibling source
elements
plus the img
element itself
for selecting an image source, ignoring any other (invalid) elements,
including other img
elements in the same picture
element,
or source
elements that are following siblings
of the relevant img
element.
When asked to parse a srcset attribute from an element,
parse the value of the element’s srcset
attribute as follows:
- Let input be the value passed to this algorithm.
- Let position be a pointer into input, initially pointing at the start of the string.
- Let candidates be an initially empty source set.
- Splitting loop: Collect a sequence of characters that are space characters or U+002C COMMA characters. If any U+002C COMMA characters were collected, that is a parse error.
- If position is past the end of input, return candidates and abort these steps.
- Collect a sequence of characters that are not space characters, and let that be url.
- Let descriptors be a new empty list.
-
If url ends with a U+002C COMMA character (,), follow these substeps:
- Remove all trailing U+002C COMMA characters from url. If this removed more than one character, that is a parse error.
Otherwise, follow these substeps:
- Descriptor tokenizer: Skip white space
- Let current descriptor be the empty string.
- Let state be in descriptor.
-
Let c be the character at position. Do the following depending on the value of state. For the purpose of this step, "EOF" is a special character representing that position is past the end of input.
- In descriptor
-
Do the following, depending on the value of c:
- Space character
- If current descriptor is not empty, append current descriptor to descriptors and let current descriptor be the empty string. Set state to after descriptor.
- U+002C COMMA (,)
- Advance position to the next character in input. If current descriptor is not empty, append current descriptor to descriptors. Jump to the step labeled descriptor parser.
- U+0028 LEFT PARENTHESIS (()
- Append c to current descriptor. Set state to in parens.
- EOF
- If current descriptor is not empty, append current descriptor to descriptors. Jump to the step labeled descriptor parser.
- Anything else
- Append c to current descriptor.
- In parens
-
Do the following, depending on the value of c:
- U+0029 RIGHT PARENTHESIS ())
- Append c to current descriptor. Set state to in descriptor.
- EOF
- Append current descriptor to descriptors. Jump to the step labeled descriptor parser.
- Anything else
- Append c to current descriptor.
- After descriptor
-
Do the following, depending on the value of c:
- Space character
- Stay in this state.
- EOF
- Jump to the step labeled descriptor parser.
- Anything else
- Set state to in descriptor. Set position to the previous character in input.
Advance position to the next character in input. Repeat this substep.
In order to be compatible with future additions, this algorithm supports multiple descriptors and descriptors with parens.
- Descriptor parser: Let error be no.
- Let width be absent.
- Let density be absent.
- Let future-compat-h be absent.
-
For each descriptor in descriptors, run the appropriate set of steps from the following list:
- If the descriptor consists of a valid non-negative integer followed by a U+0077 LATIN SMALL LETTER W character
-
-
If the user agent does not support the
sizes
attribute, let error be yes.A conforming user agent will support the
sizes
attribute. However, user agents typically implement and ship features in an incremental manner in practice. - If width and density are not both absent, then let error be yes.
- Apply the rules for parsing non-negative integers to the descriptor. If the result is zero, let error be yes. Otherwise, let width be the result.
-
- If the descriptor consists of a valid floating-point number followed by a U+0078 LATIN SMALL LETTER X character
-
- If width, density and future-compat-h are not all absent, then let error be yes.
-
Apply the rules for parsing floating-point number values to the descriptor. If the result is less than zero, let error be yes. Otherwise, let density be the result.
If density is zero, the intrinsic dimensions will be infinite. User agents are expected to have limits in how big images can be rendered, which is allowed by the hardware limitations clause.
- If the descriptor consists of a valid non-negative integer followed by a U+0068 LATIN SMALL LETTER H character
-
This is a parse error.
- If future-compat-h and density are not both absent, then let error be yes.
- Apply the rules for parsing non-negative integers to the descriptor. If the result is zero, let error be yes. Otherwise, let future-compat-h be the result.
- Anything else
- Let error be yes.
- If future-compat-h is not absent and width is absent, let error be yes.
- If error is still no, then append a new image source to candidates whose URL is url, associated with a width width if not absent and a pixel density density if not absent. Otherwise, there is a parse error.
- Return to the step labeled splitting loop.
When asked to parse a sizes attribute from an element, parse a comma-separated list of component values from the value of the element’s sizes
attribute
(or the empty string, if the attribute is absent),
and let unparsed sizes list be the result. [CSS-SYNTAX-3]
For each unparsed size in unparsed sizes list:
- Remove all consecutive <whitespace-token>s from the end of unparsed size. If unparsed size is now empty, that is a parse error; continue to the next iteration of this algorithm.
- If the last component value in unparsed size is a valid non-negative
<source-size-value>
, let size be its value and remove the component value from unparsed size. Any CSS function other than thecalc()
function is invalid. Otherwise, there is a parse error; continue to the next iteration of this algorithm. - Remove all consecutive <whitespace-token>s from the end of unparsed size. If unparsed size is now empty, return size and exit this algorithm. If this was not the last item in unparsed sizes list, that is a parse error.
- Parse the remaining component values in unparsed size as a <media-condition>. If it does not parse correctly, or it does parse correctly but the <media-condition> evaluates to false, continue to the next iteration of this algorithm. [MEDIAQ]
- Return size and exit this algorithm.
If the above algorithm exhausts unparsed sizes list without returning a size value, follow these steps:
- If width is not null, return a
<length>
with the value width and the unitpx
. - Return
100vw
.
A parse error for the algorithms above indicates a non-fatal mismatch between input and requirements. User agents are encouraged to expose parse errors somehow.
While a valid source size list only contains a bare <source-size-value>
(without an accompanying <media-condition>)
as the last entry in the <source-size-list>
,
the parsing algorithm technically allows such at any point in the list,
and will accept it immediately as the size
if the preceding entries in the list weren’t used.
This is to enable future extensions,
and protect against simple author errors such as a final trailing comma.
An image source can have a density descriptor, a width descriptor, or no descriptor at all accompanying its URL. Normalizing a source set gives every image source a density descriptor.
When asked to normalize the source densities of a source set source set, the user agent must do the following:
- Let source size be source set’s source size.
-
For each image source in source set:
- If the image source has a density descriptor, continue to the next image source.
-
Otherwise, if the image source has a width descriptor, replace the width descriptor with a density descriptor with a value of the width descriptor divided by the source size and a unit of
x
.If the source size is zero, the density would be infinity, which results in the intrinsic dimensions being zero by zero.
- Otherwise, give the image source a density descriptor of
1x
.
The user agent may at any time run the following algorithm to update an img
element’s image in order to react to changes in the environment. (User agents are not
required to ever run this algorithm; for example, if the user is not looking at the page any
more, the user agent might want to wait until the user has returned to the page before determining
which image to use, in case the environment changes again in the meantime.)
User agents are encouraged to run this algorithm in particular when the user changes the viewport’s size
(e.g., by resizing the window or changing the page zoom),
and when an img
element is inserted into a document,
so that the density-corrected intrinsic width and height match the new viewport,
and so that the correct image is chosen when art direction is involved.
- in parallel await a stable state. The synchronous section consists of all the remaining steps of this algorithm until the algorithm says the synchronous section has ended. (Steps in synchronous sections are marked with ⌛.)
- ⌛ If the
element does not usesrcset
orpicture
, its node document is not the active document, has image data whose resource type ismultipart/x-mixed-replace
, or the pending request is not null, then abort this algorithm. - ⌛ Let selected source and selected pixel density be the URL and pixel density that results from selecting an image source, respectively.
- ⌛ If selected source is null, then abort these steps.
- ⌛ If selected source and selected pixel density are the same as the element’s last selected source and current pixel density, then abort these steps.
- ⌛ Parse selected source, relative to the element’s node document, and let urlString be the resulting URL string. If that is not successful, abort these steps.
- ⌛ Let corsAttributeState be the state of the element’s
crossorigin
content attribute. - ⌛ Let origin be the origin of the
element’s node document. - ⌛ Let client be the
element’s node document’sWindow
object’s environment settings object. - ⌛ Let key be a tuple consisting of urlString, corsAttributeState, and, if corsAttributeState is not No CORS, origin.
- ⌛ Let image request be a new image request whose current URL is urlString
- ⌛ Let the element’s pending request be image request.
- End the synchronous section, continuing the remaining steps in parallel.
-
If the list of available images contains an entry for key, then set image request’s image data to that of the entry. Continue to the next step.
Otherwise, run these substeps:
- Let request be the result of creating a potential-CORS request given urlString and corsAttributeState.
- Set request’s client to client, type to "
", and set request’s synchronous flag. - Let response be the result of fetching request.
- If response’s unsafe response is a network error or
if the image format is unsupported (as determined by applying the image sniffing rules, again as mentioned earlier),
or if the user agent is able to determine that image request’s image is corrupted in
some fatal way such that the image dimensions cannot be obtained, or if the resource type is
multipart/x-mixed-replace
, then let pending request be null and abort these steps. - Otherwise, response’s unsafe response is image
request’s image data. It can be either CORS-same-origin or CORS-cross-origin; this affects the origin of the image itself (e.g., when used on a
canvas
).
-
Queue a task to run the following substeps:
- If the
element has experienced relevant mutations since this algorithm started, then let pending request be null and abort these steps. - Let the
element’s last selected source be selected source and theimg
element’s current pixel density be selected pixel density. - Set image request to the completely available state.
- Add the image to the list of available images using the key key, with the ignore higher-layer caching flag set.
- Upgrade the pending request to the current request.
- Update the
element’s presentation appropriately. - Fire a simple event named
load
at theimg
element.
- If the
The task source for the tasks queued by algorithms in this section is the DOM manipulation task source.
What an img
element represents depends on the src
attribute and the alt
attribute.
- If the
src
attribute is set and thealt
attribute is set to the empty string -
The image is either decorative or supplemental to the rest of the content, redundant with some other information in the document.
If the image is available and the user agent is configured to display that image, then the element represents the element’s image data.
Otherwise, the element represents nothing, and may be omitted completely from the rendering. User agents may provide the user with a notification that an image is present but has been omitted from the rendering.
- If the
src
attribute is set and thealt
attribute is set to a value that isn’t empty -
The image is a key part of the content; the
alt
attribute gives a textual equivalent or replacement for the image.If the image is available and the user agent is configured to display that image, then the element represents the element’s image data.
Otherwise, the element represents the text given by the
alt
attribute. User agents may provide the user with a notification that an image is present but has been omitted from the rendering. - If the
src
attribute is set and thealt
attribute is not -
There is no textual equivalent of the image available.
If the image is available and the user agent is configured to display that image, then the element represents the element’s image data.
Otherwise, the user agent should display some sort of indicator that there is an image that is not being rendered, and may, if requested by the user, or if so configured, or when required to provide contextual information in response to navigation, provide caption information for the image, derived as follows:
- If the image is a descendant of a
figure
element that has a childfigcaption
element, and, ignoring thefigcaption
element and its descendants, thefigure
element has noText
node descendants other than inter-element white space, and no embedded content descendant other than theimg
element, then the contents of the first suchfigcaption
element are the caption information; abort these steps. - There is no caption information.
- If the image is a descendant of a
- If the
src
attribute is not set and either thealt
attribute is set to the empty string or thealt
attribute is not set at all -
The element represents nothing.
- Otherwise
-
The element represents the text given by the
alt
attribute.
The alt
attribute does not represent advisory information.
User agents must not present the contents of the alt
attribute
in the same way as content of the title
attribute.
User agents may always provide the user with the option to display any image, or to prevent any image from being displayed. User agents may also apply heuristics to help the user make use of the image when the user is unable to see it, e.g., due to a visual disability or because they are using a text terminal with no graphics capabilities. Such heuristics could include, for instance, optical character recognition (OCR) of text found within the image.
In the case where an img
without an alt
attribute is the child of a figure
element with a non-empty figcaption
element, the image’s presence should be minimally conveyed
to a user by Assistive Technology, typically by identifying the image role
.
While user agents are encouraged to repair cases of missing alt
attributes, authors must not rely on such behavior. Requirements for providing
text to act as an alternative for images are described in detail below.
The contents of img
elements, if any, are ignored for the purposes of
rendering.
The usemap
attribute,
if present, can indicate that the image has an associated image map.
The ismap
attribute, when used on an element that is a descendant of an a
element with an href
attribute, indicates by its
presence that the element provides access to a server-side image
map. This affects how events are handled on the corresponding a
element.
The ismap
attribute is a boolean attribute. The attribute must not be specified
on an element that does not have an ancestor a
element
with an href
attribute.
The usemap
and ismap
attributes
can result in confusing behavior when used together with source
elements with the media
attribute specified
in a picture
element.
The img
element supports dimension
attributes.
The alt
, src
, srcset
and sizes
IDL attributes must reflect the
respective content attributes of the same name.
The crossOrigin
IDL attribute must reflect the crossorigin
content attribute.
The useMap
IDL attribute must reflect the usemap
content attribute.
The isMap
IDL attribute must reflect the ismap
content attribute.
The longDesc
IDL attribute is defined in [html-longdesc]. The IDL attribute must reflect the longdesc
content attribute.
- image .
width
[ = value ] - image .
height
[ = value ] -
These attributes return the actual rendered dimensions of the image, or zero if the dimensions are not known.
They can be set, to change the corresponding content attributes.
- image .
naturalWidth
- image .
naturalHeight
-
These attributes return the intrinsic dimensions of the image, or zero if the dimensions are not known.
- image .
complete
-
Returns true if the image has been completely downloaded or if no image is specified; otherwise, returns false.
- image .
currentSrc
-
Returns the image’s absolute URL.
- image = new
( [ width [, height ] ] ) -
Returns a new
element, with thewidth
andheight
attributes set to the values passed in the relevant arguments, if applicable.
The IDL attributes width
and height
must return the rendered width and height of the
image, in CSS pixels, if the image is being rendered, and is being rendered to a
visual medium; or else the density-corrected intrinsic width and height of the image, in CSS pixels, if the image has intrinsic dimensions and is available but not being rendered to a visual medium; or else 0, if
the image is not available or does not have intrinsic dimensions. [CSS-2015]
On setting, they must act as if they reflected the respective content attributes of the same name.
The IDL attributes naturalWidth
and naturalHeight
must return
the density-corrected intrinsic width and height of the image, in CSS pixels, if the image has intrinsic dimensions and is available, or else 0. [CSS-2015]
The IDL attribute complete
must return true if
any of the following conditions is true:
- Both the
src
attribute and thesrcset
attribute are omitted. - The
srcset
attribute is omitted and thesrc
attribute’s value is the empty string. - The final task that is queued by the networking task source once the resource has been fetched has been queued.
- The
element is completely available. - The
element is broken.
Otherwise, the attribute must return false.
The value of complete
can thus change while
a script is executing.
The currentSrc
IDL attribute
must return the img
element’s current request’s current URL.
A constructor is provided for creating HTMLImageElement
objects (in addition to
the factory methods from DOM such as createElement()
): Image(width, height)
.
When invoked as a constructor, this must return a new HTMLImageElement
object (a new img
element). If the width argument is present, the new object’s width
content attribute must be set to width. If the height argument is also present, the new object’s height
content attribute must be set to height.
The element’s node document must be the active document of the browsing context of the Window
object on which the interface object of
the invoked constructor is found.
4.7.5.1. Requirements for providing text to act as an alternative for images
Text alternatives, [WCAG20] are a primary way of making visual information accessible, because they can be rendered through many sensory modalities (for example, visual, auditory or tactile) to match the needs of the user. Providing text alternatives allows the information to be rendered in a variety of ways by a variety of user agents. For example, a person who cannot see a picture can hear the text alternative read aloud using synthesized speech.
The alt
attribute on images is a very important accessibility attribute.
Authoring useful alt
attribute content requires the author to
carefully consider the context in which the image appears and the function that
image may have in that context.
The longdesc
attribute on images is likely to be read far less often by users
and is necessary for far fewer images. Nevertheless it provides an important way for
users who cannot see an image or cannot see it clearly, and user agents that cannot automatically process images,
to understand what it shows. The longdesc
attribute’s use cases are more fully described in [html-longdesc]
The guidance included here addresses the most common ways authors use images. Additional guidance and techniques are available in Resources on Alternative Text for Images.
4.7.5.1.1. Examples of scenarios where users benefit from text alternatives for images
- They have a very slow connection and are browsing with images disabled.
- They have a vision impairment and use text to speech software.
- They have a cognitive impairment and use text to speech software.
- They are using a text-only browser.
- They are listening to the page being read out by a voice Web browser.
- They have images disabled to save on download costs.
- They have problems loading images or the source of an image is wrong.
4.7.5.1.2. General guidelines
Except where otherwise specified, the alt
attribute must be specified and its value must not be empty;
the value must be an appropriate functional replacement for the image. The specific requirements for the alt
attribute content depend on the image’s function in the page, as described in the following sections.
To determine an appropriate text alternative it is important to think about why an image is being included in a page. What is its purpose? Thinking like this will help you to understand what is important about the image for the intended audience. Every image has a reason for being on a page, because it provides useful information, performs a function, labels an interactive element, enhances aesthetics or is purely decorative. Therefore, knowing what the image is for, makes writing an appropriate text alternative easier.
4.7.5.1.3. A link or button containing nothing but an image
When an a
element that is a hyperlink, or a button
element, has no text content
but contains one or more images, include text in the alt
attribute(s) that together convey the purpose of the link or button.
alt
attributes of the images:
<ul> <li><button><img src="b.png" alt="Bold"></button></li> <li><button><img src="i.png" alt="Italics"></button></li> <li><button><img src="strike.png" alt="Strike through"></button></li> <li><button><img src="blist.png" alt="Bulleted list"></button></li> <li><button><img src="nlist.png" alt="Numbered list"></button></li> </ul>
<a href="https://w3.org"> <img src="images/w3c_home.png" width="72" height="48" alt="W3C web site"> </a>
<a href="https://w3.org"> <img src="images/w3c_home.png" width="72" height="48" alt="W3C home"> </a>
Depending on the context in which an image of a logo is used it could be appropriate to provide an indication, as part of the text alternative, that the image is a logo. Refer to section §4.7.5.1.19 Logos, insignia, flags, or emblems.
<a href="preview.html"> <img src="images/preview.png" width="32" height="30" alt="Print preview."> </a>
<button> <img src="images/search.png" width="74" height="29" alt="Search"> </button>
alt
attribute of the first image.
<a href="pipco-home.html"> <img src="pip.gif" alt="PIP CO home"><img src="co.gif" alt=""> </a>
4.7.5.1.4. Graphical Representations: Charts, diagrams, graphs, maps, illustrations
Users can benefit when content is presented in graphical form, for example as a flowchart, a diagram, a graph, or a map showing directions. Users who are unable to view the image also benefit when content presented in a graphical form is provided in a text-based format. Software agents that process text content, but cannot automatically process images (e.g. translation services, many search engines), also benefit from a text-based description.
alt
attribute representing the data shown in the pie chart:
<img src="piechart.gif" alt="Pie chart: Browser Share - Internet Explorer 25%, Firefox 40%, Chrome 25%, Safari 6% and Opera 4%.">
alt
attribute content labels the image and the longdesc
attribute identifies it as a description.
<p id="graph7">According to a recent study Firefox has a 40% browser share, Internet Explorer has 25%, Chrome has 25%, Safari has 6% and Opera has 4%.</p> <p><img src="piechart.gif" alt="The browser shares as a pie chart." longdesc="graph7"></p>
It can be seen that when the image is not available, for example because the src
attribute value is incorrect, the text alternative provides the user with a brief description of
the image content:
In cases where the text alternative is lengthy, more than a sentence or two, or would benefit
from the use of structured markup, provide a brief description or label using the alt
attribute, and an associated text alternative.
alt
attribute, in this case the text alternative is a description of the link target
as the image is the sole content of a link. The link points to a description, within the same document, of the
process represented in the flowchart.
<a href="#desc"><img src="flowchart.gif" alt="Flowchart: Dealing with a broken lamp." longdesc="#desc"></a> ... ... <div id="desc"> <h2>Dealing with a broken lamp</h2> <ol> <li>Check if it’s plugged in, if not, plug it in.</li> <li>If it still doesn’t work; check if the bulb is burned out. If it is, replace the bulb.</li> <li>If it still doesn’t work; buy a new lamp.</li> </ol> </div>
alt
attribute as the information is a data set. Instead a
structured text alternative is provided below the image in the form of a data table using the data that is represented
in the chart image.
Indications of the highest and lowest rainfall for each season have been included in the table, so trends easily identified in the chart are also available in the data table.
United Kingdom | Japan | Australia | |
---|---|---|---|
Spring | 5.3 (highest) | 2.4 | 2 (lowest) |
Summer | 4.5 (highest) | 3.4 | 2 (lowest) |
Autumn | 3.5 (highest) | 1.8 | 1.5 (lowest) |
Winter | 1.5 (highest) | 1.2 | 1 (lowest) |
<figure> <figcaption>Rainfall Data</figcaption> <img src="rainchart.gif" alt="Bar chart: average rainfall by Country and Season. Full description in Table below." longdesc="table-4"> <table id="table-4"> <caption>Rainfall in millimetres by Country and Season.</caption> <tr><td><th scope="col">UK <th scope="col">Japan<th scope="col">Australia</tr> <tr><th scope="row">Spring <td>5.5 (highest)<td>2.4 <td>2 (lowest)</tr> <tr><th scope="row">Summer <td>4.5 (highest)<td>3.4<td>2 (lowest)</tr> <tr><th scope="row">Autumn <td>3.5 (highest) <td>1.8 <td>1.5 (lowest)</tr> <tr><th scope="row">Winter <td>1.5 (highest) <td>1.2 <td>1 lowest</tr> </table> </figure>
The figure
element is used to group the Bar Chart image and data table.
The figcaption
element provides a caption for the grouped content.
For any of the examples in this section the details
and summary
elements could be used so that the text descriptions for the images are only displayed on demand:
<figure> <img src="flowchart.gif" alt="Flowchart: Dealing with a broken lamp."> <details> <summary>Dealing with a broken lamp</summary> <ol> <li>Check if it’s plugged in, if not, plug it in.</li> <li>If it still doesn’t work; check if the bulb is burned out. If it is, replace the bulb.</li> <li>If it still doesn’t work; buy a new lamp.</li> </ol> </details> </figure>
The details
and summary
elements are not currently well supported by
browsers, until such times they are supported, if used, you will need to use scripting to
provide the functionality. There are a number of scripted Polyfills and scripted custom
controls available, in popular JavaScript UI widget libraries, which provide similar
functionality.
4.7.5.1.5. Images of text
Sometimes, an image only contains text, and the purpose of the image
is to display text using visual effects and /or fonts. It is strongly recommended that text styled using CSS be used, but if this is not possible, provide
the same text in the alt
attribute as is in the image.
<h1><img src="gethappy.gif" alt="Get Happy!"></h1>
<p><img src="sale.gif" alt="The BIG sale ...ends Friday."></p>
In situations where there is also a photo or other graphic along with the image of text, ensure that the words in the image text are included in the text alternative, along with any other description of the image that conveys meaning to users who can view the image, so the information is also available to users who cannot view the image.
Only 5.99!
<p>Only <img src="euro.png" alt="euro ">5.99!
An image should not be used if Unicode characters would serve an identical purpose. Only when the text cannot be directly represented using Unicode, e.g., because of decorations or because the character is not in the Unicode character set (as in the case of gaiji), would an image be appropriate.
If an author is tempted to use an image because their default system font does not support a given character, then Web Fonts are a better solution than images.
<p><img src="initials/fancyO.png" alt="O">nce upon a time and a long long time ago...
longdesc
can provide a link to a more detailed description: nce upon a time and a long long time ago...
<p><img src="initials/story-o.jpg" alt="O" longdesc="letters/story-0.html">nce upon a time and a long long time ago...
4.7.5.1.6. Images that include text
Sometimes, an image consists of a graphics such as a chart and associated text. In this case it is recommended that the text in the image is included in the text alternative.
<p><img src="figure1.gif" alt="Figure 1. Distribution of Articles by Journal Category. Pie chart: Language=68%, Education=14% and Science=18%."></p>
alt
attribute
and a longer text alternative in text. The figure
and figcaption
elements are used to associate the longer text alternative with the image. The alt
attribute is used
to label the image.
<figure> <img src="figure1.gif" alt="Figure 1"> <figcaption><strong>Figure 1.</strong> Distribution of Articles by Journal Category. Pie chart: Language=68%, Education=14% and Science=18%.</figcaption> </figure>
The advantage of this method over the previous example is that the text alternative
is available to all users at all times. It also allows structured mark up to be used in the text
alternative, where as a text alternative provided using the alt
attribute does not.
4.7.5.1.7. Images that enhance the themes or subject matter of the page content
An image that isn’t discussed directly by the surrounding text but still has
some relevance can be included in a page using the img
element. Such images
are more than mere decoration, they may augment the themes or subject matter of the page
content and so still form part of the content. In these cases, it is recommeneded that a
text alternative be provided.
alt
attribute and
a link below the image to a longer description located at the bottom of the document. At the end
of the longer description there is also a link to further information about the painting.
<header> <h1>The Lady of Shalott</h1> <p>A poem by Alfred Lord Tennyson</p> </header> <img src="shalott.jpeg" alt="Painting - a young woman with long hair, sitting in a wooden boat. Full description below." longdesc="#des"> <p><a href="#des">Description of the painting</a>.</p> <!-- Full Recitation of Alfred, Lord Tennyson’s Poem. --> ... ... ... <p id="des">The woman in the painting is wearing a flowing white dress. A large piece of intricately patterned fabric is draped over the side. In her right hand she holds the chain mooring the boat. Her expression is mournful. She stares at a crucifix lying in front of her. Beside it are three candles. Two have blown out. <a href="https://bit.ly/5HJvVZ">Further information about the painting</a>.</p>
This example illustrates the provision of a text alternative identifying an image as a photo of the main subject of a page.
<img src="orateur_robin_berjon.png" alt="Portrait photo(black and white) of Robin."> <h1>Robin Berjon</h1> <p>What more needs to be said?</p>
4.7.5.1.8. A graphical representation of some of the surrounding text
In many cases, the image is actually just supplementary, and its presence merely reinforces the
surrounding text. In these cases, the alt
attribute must be
present but its value must be the empty string.
In general, an image falls into this category if removing the image doesn’t make the page any less useful, but including the image makes it a lot easier for users of visual browsers to understand the concept.
alt
attribute, and
there is a link after the image. The link points to a page containing information about the painting.
The Lady of Shalott
A poem by Alfred Lord Tennyson.
Full recitation of Alfred, Lord Tennyson’s poem.
<header><h1>The Lady of Shalott</h1> <p>A poem by Alfred Lord Tennyson</p></header> <figure> <img src="shalott.jpeg" alt="Painting: a woman in a white flowing dress, sitting in a small boat." longdesc="https://bit.ly/5HJvVZ"> <p><a href="https://bit.ly/5HJvVZ">About this painting.</a></p> </figure> <!-- Full Recitation of Alfred, Lord Tennyson’s Poem. -->
4.7.5.1.9. A purely decorative image that doesn’t add any information
Purely decorative images are visual enhancements, decorations or embellishments that provide no function or information beyond aesthetics to users who can view the images.
Mark up purely decorative images so they can be ignored by assistive technology by using an empty alt
attribute (alt=""
). While it is not unacceptable to include decorative images inline,
it is recommended if they are purely decorative to include the image using CSS.
alt
attribute is used.
Clara’s Blog Welcome to my blog...
<header> <div><img src="border.gif" alt="" width="400" height="30"></div> <h1>Clara’s Blog</h1> </header> <p>Welcome to my blog...</p>
4.7.5.1.10. Inline images
When images are used inline as part of the flow of text in a sentence, provide a word or phrase as a text alternative which makes sense in the context of the sentence it is apart of.
I <img src="heart.png" alt="love"> you.
My breaks.
My <img src="heart.png" alt="heart"> breaks.
4.7.5.1.11. A group of images that form a single larger picture with no links
When a picture has been sliced into smaller image files that are then displayed
together to form the complete picture again, include a text alternative for one
of the images using the alt
attribute as per the relevant relevant
guidance for the picture as a whole, and then include an empty alt
attribute on the other images.
alt
attribute of the first image.
<img src="pip.gif" alt="PIP CO"><img src="co.gif" alt="">
alt
attributes.
<p>Rating: <img src="1" alt="3 out of 5"> <img src="1" alt=""><img src="1" alt=""> <img src="0" alt=""><img src="0" alt=""> </p>
4.7.5.1.12. Image maps
If animg
element has a usemap
attribute which references a map
element containing area
elements that have href
attributes, the img
is considered to be interactive content.
In such cases, always provide a text alternative for the image using the alt
attribute.
alt
attribute on each
of the area
elements provides text describing the content of the target page of each linked region:
<p>View houses for sale in North Katoomba or South Katoomba:</p> <p><img src="imagemap.png" width="209" alt="Map of Katoomba" height="249" usemap="#Map"> <map name="Map"> <area shape="poly" coords="78,124,124,10,189,29,173,93,168,132,136,151,110,130" href="north.html" alt="Houses in North Katoomba"> <area shape="poly" coords="66,63,80,135,106,138,137,154,167,137,175,133,144,240,49,223,17,137,17,61" alt="Houses in South Katoomba" href="south.html"> </map>
4.7.5.1.13. A group of images that form a single larger picture with links
Sometimes, when you create a composite picture from multiple images, you may wish to
link one or more of the images. Provide an alt
attribute
for each linked image to describe the purpose of the link.
<h1>The crocoduck</h1> <p>You encounter a strange creature called a "crocoduck". The creature seems angry! Perhaps some friendly stroking will help to calm it, but be careful not to stroke any crocodile parts. This would just enrage the beast further.</p> <a href="?stroke=head"><img src="crocoduck1.png" alt="Stroke crocodile’s angry, chomping head"></a> <a href="?stroke=body"><img src="crocoduck2.png" alt="Stroke duck’s soft, feathery body"></a>
4.7.5.1.14. Images of Pictures
Images of pictures or graphics include visual representations of objects, people, scenes, abstractions, etc. This non-text content, [WCAG20] can convey a significant amount of information visually or provide a specific sensory experience, [WCAG20] to a sighted person. Examples include photographs, paintings, drawings and artwork.
An appropriate text alternative for a picture is a brief description, or name [WCAG20]. As in all text alternative authoring decisions, writing suitable text alternatives for pictures requires
human judgment. The text value is subjective to the context where the image is used and the page author’s writing style. Therefore,
there is no single "right" or "correct" piece of alt
text for any particular image. In addition to providing a short text
alternative that gives a brief description of the non-text content, also providing supplemental content through another means when
appropriate may be useful.
element’s alt
attribute. It also has a caption provided by including
the img
element in a figure
element and using a figcaption
element to identify the caption text.
Lola prefers a bath to a shower.
<figure> <img src="664aef.jpg" alt="Lola the cat sitting under an umbrella in the bath tub."> <figcaption>Lola prefers a bath to a shower.</figcaption> </figure>
alt
attribute which gives users who cannot view the image a sense
of what the image is. It also has a caption provided by including the img
element in a figure
element and using a figcaption
element to identify the caption text.
The first of the ten cards in the Rorschach test.
<figure> <img src="Rorschach1.jpg" alt="An abstract, freeform, vertically symmetrical, black inkblot on a light background."> <figcaption>The first of the ten cards in the Rorschach test.</figcaption> </figure>
4.7.5.1.15. Webcam images
Webcam images are static images that are automatically updated periodically. Typically the images are from a fixed viewpoint, the images may update on the page automatically as each new image is uploaded from the camera or the user may be required to refresh the page to view an updated image. Examples include traffic and weather cameras.
figure
and figcaption
elements. As the image is provided to give a visual indication of the current weather near a building,
a link to a local weather forecast is provided, as with automatically generated and uploaded webcam images it may be impractical to
provide such information as a text alternative.
The text of the alt
attribute includes a prose version of the timestamp, designed to make the text more
understandable when announced by text to speech software. The text alternative also includes a description of some aspects
of what can be seen in the image which are unchanging, although weather conditions and time of day change.
View from the top of Sopwith house, looking towards North Kingston. This image is updated every hour.
View the latest weather details for Kingston upon Thames.
<figure> <img src="webcam1.jpg" alt="Sopwith house weather cam. Taken on the 21/04/10 at 11:51 and 34 seconds. In the foreground are the safety rails on the flat part of the roof. Nearby there are low rize industrial buildings, beyond are blocks of flats. In the distance there’s a church steeple."> <figcaption>View from Sopwith house, looking towards north Kingston. This image is updated every hour.</figcaption> </figure> <p>View the <a href="https://news.bbc.co.uk/weather/forecast/4296?area=Kingston">latest weather details</a> for Kingston upon Thames.</p>
4.7.5.1.16. When a text alternative is not available at the time of publication
In some cases an image is included in a published document, but the author is unable to provide an appropriate text alternative.
In such cases the minimum requirement is to provide a caption for the image using the figure
and figcaption
elements under the following conditions:
- The
element is in afigure
element - The
figure
element contains afigcaption
element - The
figcaption
element contains content other than inter-element white space - Ignoring the
figcaption
element and its descendants, thefigure
element has noText
node descendants other than inter-element white space, and no embedded content descendant other than theimg
element.
In other words, the only content of the figure
is an img
element and a figcaption
element, and the figcaption
element must include (caption) content.
Such cases are to be kept to an absolute
minimum. If there is even the slightest possibility of the author
having the ability to provide real alternative text, then it would
not be acceptable to omit the alt
attribute.
The caption text in the example below is not a suitable text alternative and is not conforming to the Web Accessibility Guidelines 2.0. [WCAG20]
clara.jpg, taken on 12/11/2010.
<figure> <img src="clara.jpg"> <figcaption>clara.jpg, taken on 12/11/2010.</figcaption> </figure>
Notice that even in this example, as much useful information
as possible is still included in the figcaption
element.
alt
attribute.
Eloisa with Princess Belle
<figure> <img src="elo.jpg"> <figcaption>Eloisa with Princess Belle</figcaption> </figure>
<table> <tr><tr> <th> Image <th> Description<tr> <td> <figure> <img src="2421.png"> <figcaption>Image 640 by 100, filename 'banner.gif'</figcaption> </figure> <td> <input name="alt2421"> <tr> <td> <figure> <img src="2422.png"> <figcaption>Image 200 by 480, filename 'ad3.gif'</figcaption> </figure> <td> <input name="alt2422"> </table>
Since some users cannot use images at all (e.g., because they are blind) the alt
attribute is only allowed to be omitted when no text
alternative is available and none can be made available, as in the above examples.
4.7.5.1.17. An image not intended for the user
Generally authors should avoid using img
elements
for purposes other than showing images.
If an img
element is being used for purposes other
than showing an image, e.g., as part of a service to count page
views, use an empty alt
attribute.
element used to collect web page statistics.
The alt
attribute is empty as the image has no meaning.
<img src="https://server3.stats.com/count.pl?NeonMeatDream.com" width="0" height="0" alt="">
It is recommended for the example use above the width
and height
attributes be set to zero.
alt
attribute is empty as the image has no meaning.
<img src="spacer.gif" width="10" height="10" alt="">
It is recommended that CSS be used to position content instead of img
elements.
4.7.5.1.18. Icon Images
An icon is usually a simple picture representing a program, action, data file or a concept. Icons are intended to help users of visual browsers to recognize features at a glance.
Use an empty alt
attribute when an icon is supplemental to
text conveying the same meaning.
alt
text.
<a href="home.html"><img src="home.gif" width="15" height="15" alt="">Home</a>
Where images are used in this way, it would also be appropriate to add the image using CSS.
#home:before { content: url(home.png); } <a href="home.html" id="home">Home</a>
element is given an empty alt
attribute.
Warning! Your session is about to expire.
<p><img src="warning.png" width="15" height="15" alt=""> <strong>Warning!</strong> Your session is about to expire</p>
When an icon conveys additional information not available in text, provide a text alternative.
Your session is about to expire.
<p><img src="warning.png" width="15" height="15" alt="Warning!"> Your session is about to expire</p>
4.7.5.1.19. Logos, insignia, flags, or emblems
Many pages include logos, insignia, flags, or emblems, which stand for a company, organization, project, band, software package, country, or other entity. What can be considered as an appropriate text alternative depends upon, like all images, the context in which the image is being used and what function it serves in the given context.
If a logo is the sole content of a link, provide a brief description of the link target in the alt
attribute.
<a href="https://w3c.github.io/html/"> <img src="HTML5_Logo.png" alt="HTML 5.1 specification"></a>
If a logo is being used to represent the entity, e.g., as a page heading, provide the name of the entity being represented by the logo as the text alternative.
and other developer resources
<h2><img src="images/webplatform.png" alt="WebPlatform.org"> and other developer resources<h2>
The text alternative in the example above could also include the word "logo" to describe the
type of image content. If so, it is suggested that square brackets be used to delineate this
information: alt="[logo] WebPlatform.org"
.
If a logo is being used next to the name of the what that it represents, then the logo is
supplemental. Include an empty alt
attribute as the text alternative is already
provided.
WebPlatform.org
<img src="images/webplatform1.png" alt=""> WebPlatform.org
If the logo is used alongside text discussing the subject or entity the logo represents, then provide a text alternative which describes the logo.
HTML is a language for structuring and presenting content for the World Wide Web, a core technology of the Internet. It is the latest revision of the HTML specification (originally created in 1990 and most recently standardized as HTML 4.01 in 1997) and currently remains under development. Its core aims have been to improve the language with support for the latest multimedia while keeping it easily readable by humans and consistently understood by computers and devices (web browsers, parsers etc.).
<p><img src="HTML5_Logo.png" alt="HTML5 logo: Shaped like a shield with the text 'HTML' above and the numeral '5' prominent on the face of the shield."></p> Information about HTML
4.7.5.1.20. CAPTCHA Images
CAPTCHA stands for "Completely Automated Public Turing test to tell Computers and Humans Apart". CAPTCHA images are used for security purposes to confirm that content is being accessed by a person rather than a computer. This authentication is done through visual verification of an image. CAPTCHA typically presents an image with characters or words in it that the user is to re-type. The image is usually distorted and has some noise applied to it to make the characters difficult to read.
To improve the accessibility of CAPTCHA provide text alternatives that identify and describe the purpose of the image, and provide alternative forms of the CAPTCHA using output modes for different types of sensory perception. For instance provide an audio alternative along with the visual image. Place the audio option right next to the visual one. This helps but is still problematic for people without sound cards, the deaf-blind, and some people with limited hearing. Another method is to include a form that asks a question along with the visual image. This helps but can be problematic for people with cognitive impairments.
It is strongly recommended that alternatives to CAPTCHA be used, as all forms of CAPTCHA introduce unacceptable barriers to entry for users with disabilities. Further information is available in Inaccessibility of CAPTCHA.
alt
attribute provides instructions for a user in the case where she cannot
access the image content.
Example code:
<img src="captcha.png" alt="If you cannot view this image an audio challenge is provided."> <!-- audio CAPTCHA option that allows the user to listen and type the word --> <!-- form that asks a question -->
4.7.5.1.21. An image in a picture
element
The picture
element and any source
elements it contains have no semantics for users,
only the img
element or its text alternative is displayed to users. Provide a text alternative for an img
element without regard to it being within a picture
element. Refer to Requirements for providing text to act as an alternative for images for more information on how to provide
useful alt
text for images.
Art directed images that rely on picture
need to depict
the same content (irrespective of size, pixel density, or any other discriminating factor). Therefore the appropriate
text alternative for an image will always be the same irrespective of which source file ends up being chosen by the browser.
<h2>Is it a ghost?</h2> <picture> <source media="(min-width: 32em)" srcset="large.jpg"> <img src="small.jpg" alt="Reflection of a girls face in a train window."> </picture>
The large and small versions (both versions are displayed for demonstration purposes) of
the image portray the same scene: Reflection of a girls face in a train window,
while the small version (displayed on smaller screens) is cropped, this does not effect the subject matter
or the appropriateness of the alt
text.
4.7.5.1.22. Guidance for markup generators
Markup generators (such as WYSIWYG authoring tools) should, wherever possible, obtain alternative text from their users. However, it is recognized that in many cases, this will not be possible.
For images that are the sole contents of links, markup generators should examine the link target to determine the title of the target, or the URL of the target, and use information obtained in this manner as the alternative text.
For images that have captions, markup generators should use the figure
and figcaption
elements to provide the image’s caption.
As a last resort, implementors should either set the alt
attribute to the empty string, under
the assumption that the image is a purely decorative image that
doesn’t add any information but is still specific to the surrounding
content, or omit the alt
attribute
altogether, under the assumption that the image is a key part of the
content.
Markup generators may specify a generator-unable-to-provide-required-alt
attribute on img
elements for which they have been
unable to obtain a text alternative and for which they have therefore
omitted the alt
attribute. The
value of this attribute must be the empty string. Documents
containing such attributes are not conforming, but conformance
checkers will silently ignore this error.
This is intended to avoid markup generators from
being pressured into replacing the error of omitting the alt
attribute with the even more
egregious error of providing phony text alternatives, because
state-of-the-art automated conformance checkers cannot distinguish
phony text alternatives from correct text alternatives.
Markup generators should generally avoid using the image’s own file name as the text alternative. Similarly, markup generators should avoid generating text alternatives from any content that will be equally available to presentation user agents (e.g., Web browsers).
This is because once a page is generated, it will typically not be updated, whereas the browsers that later read the page can be updated by the user, therefore the browser is likely to have more up-to-date and finely-tuned heuristics than the markup generator did when generating the page.
4.7.5.1.23. Guidance for conformance checkers
A conformance checker must report the lack of an alt
attribute as an error unless one
of the conditions listed below applies:
-
The
element is in afigure
element that satisfies the conditions described above. -
The
element has a (non-conforming)generator-unable-to-provide-required-alt
attribute whose value is the empty string. A conformance checker that is not reporting the lack of analt
attribute as an error must also not report the presence of the emptygenerator-unable-to-provide-required-alt
attribute as an error. (This case does not represent a case where the document is conforming, only that the generator could not determine appropriate alternative text — validators are not required to show an error in this case, because such an error might encourage markup generators to include bogus alternative text purely in an attempt to silence validators. Naturally, conformance checkers may report the lack of analt
attribute as an error even in the presence of thegenerator-unable-to-provide-required-alt
attribute; for example, there could be a user option to report all conformance errors even those that might be the more or less inevitable result of using a markup generator.)
4.7.6. The iframe
element
- Categories:
- Flow content.
- Phrasing content.
- Embedded content.
- Interactive content.
- Palpable content.
- Contexts in which this element can be used:
- Where embedded content is expected.
- Content model:
- Text that conforms to the requirements given in the prose.
- Tag omission in text/html:
- Neither tag is omissible
- Content attributes:
- Global attributes
src
- Address of the resourcesrcdoc
- A document to render in theiframe
name
- Name of nested browsing contextsandbox
- Security rules for nested contentallowfullscreen
- Whether to allow theiframe
’s contents to userequestFullscreen()
allowpaymentrequest
- Whether theiframe
’s contents are allowed to use thePaymentRequest
interface to make payment requestswidth
- Horizontal dimensionheight
- Vertical dimension- Allowed ARIA role attribute values:
application
,document
, orimg
.- Allowed ARIA state and property attributes:
- Global aria-* attributes
- Any
aria-*
attributes applicable to the allowed roles. - DOM interface:
-
interface HTMLIFrameElement : HTMLElement { attribute DOMString src; attribute DOMString srcdoc; attribute DOMString name; [SameObject, PutForwards=value] readonly attribute DOMTokenList sandbox; attribute boolean allowFullscreen; attribute boolean allowPaymentRequest; attribute DOMString width; attribute DOMString height; readonly attribute Document? contentDocument; readonly attribute WindowProxy? contentWindow; };
The iframe
element represents a nested browsing context.
The src
attribute gives the address of a page
that the nested browsing context is to contain. The attribute, if present, must be a valid non-empty URL potentially surrounded by spaces.
The srcdoc
attribute gives the content of
the page that the nested browsing context is to contain. The value of the attribute
is the source of an iframe
srcdoc
document.
The srcdoc
attribute, if present, must have a value
using the HTML syntax that consists of the following syntactic components, in the
given order:
- Any number of comments and space characters.
- Optionally, a DOCTYPE.
- Any number of comments and space characters.
- The document element, in the form of an
html
element. - Any number of comments and space characters.
For iframe
elements in XML documents, the srcdoc
attribute, if present, must have a value that matches the
production labeled document
in the XML specification. [XML]
srcdoc
attribute in conjunction
with the sandbox
attributes described below to provide users of user
agents that support this feature with an extra layer of protection from script injection in the
blog post comments:
<article> <h1>I got my own magazine!</h1> <p>After much effort, I’ve finally found a publisher, and so now I have my own magazine! Isn’t that awesome?! The first issue will come out in September, and we have articles about getting food, and about getting in boxes, it’s going to be great!</p> <footer> <p>Written by <a href="/users/cap">cap</a>, 1 hour ago. </footer> <article> <footer> Thirteen minutes ago, <a href="/users/ch">ch</a> wrote: </footer> <iframe sandbox srcdoc="<p>did you get a cover picture yet?"></iframe> </article> <article> <footer> Nine minutes ago, <a href="/users/cap">cap</a> wrote: </footer> <iframe sandbox srcdoc="<p>Yeah, you can see it <a href="/gallery?mode=cover&amp;page=1">in my gallery</a>."></iframe> </article> <article> <footer> Five minutes ago, <a href="/users/ch">ch</a> wrote: </footer> <iframe sandbox srcdoc="<p>hey that’s earl’s table. <p>you should get earl&amp;me on the next cover."></iframe> </article>
Notice the way that quotes have to be escaped (otherwise the srcdoc
attribute would end prematurely), and the way raw
ampersands (e.g., in URLs or in prose) mentioned in the sandboxed content have to be doubly escaped — once so that the ampersand is preserved when originally parsing
the srcdoc
attribute, and once more to prevent the
ampersand from being misinterpreted when parsing the sandboxed content.
Furthermore, notice that since the DOCTYPE is optional in iframe
srcdoc
documents, and the html
, head
, and body
elements have optional
start and end tags, and the title
element is also optional in iframe
srcdoc
documents, the markup in a srcdoc
attribute can be
relatively succinct despite representing an entire document, since only the contents of the body
element need appear literally in the syntax. The other elements are still
present, but only by implication.
In the HTML syntax, authors need only remember to use U+0022
QUOTATION MARK characters (") to wrap the attribute contents and then to escape all U+0026
AMPERSAND (&) and U+0022 QUOTATION MARK (") characters, and to specify the sandbox
attribute, to ensure safe embedding of content.
Due to restrictions of the XHTML syntax, in XML the U+003C LESS-THAN SIGN character (<) needs to be escaped as well. In order to prevent attribute-value normalization, some of XML’s white space characters — specifically U+0009 CHARACTER TABULATION (tab), U+000A LINE FEED (LF), and U+000D CARRIAGE RETURN (CR) — also need to be escaped. [XML]
If the src
attribute and the srcdoc
attribute are both specified together, the srcdoc
attribute takes priority. This allows authors to provide
a fallback URL for legacy user agents that do not support the srcdoc
attribute.
When an iframe
element is inserted into a document that has a browsing context, the user agent must create a nested browsing context, and
then process the iframe
attributes for the "first time".
When an iframe
element is removed from a document, the user agent must discard the nested browsing context, if any.
This happens without any unload
events firing
(the nested browsing context and its Document
are discarded, not unloaded).
Whenever an iframe
element with a nested browsing context has its srcdoc
attribute set, changed, or removed, the user agent
must process the iframe
attributes.
Similarly, whenever an iframe
element with a nested browsing context but with no srcdoc
attribute specified has its src
attribute set, changed, or removed, the user agent must process the iframe
attributes.
When the user agent is to process the iframe
attributes, it must run
the first appropriate steps from the following list:
- If the
srcdoc
attribute is specified -
Navigate the element’s child browsing context to a new response whose url list consists of about:srcdoc, header list consists of
Content-Type
/text/html
, body is the value of the attribute, CSP list is the CSP list of theiframe
element’s node document, and HTTPS state is the HTTPS state of theiframe
element’s node document.The resulting
Document
must be considered aniframe
srcdoc
document. - Otherwise, if the element has no
src
attribute specified, and the user agent is processing theiframe
’s attributes for the "first time" -
Queue a task to run the iframe load event steps.
The task source for this task is the DOM manipulation task source.
- Otherwise
- Run the otherwise steps for iframe or frame elements.
The otherwise steps for iframe or frame elements are as follows:
1: If the element has no src
attribute specified, or its
value is the empty string, let url be the URL "about:blank
".
Otherwise, parse the value of the src
attribute, relative to the element’s node document.
If that is not successful, then let url be the URL "about:blank
". Otherwise, let url be the resulting URL record.
-
If there exists an ancestor browsing context whose active document’s URL, ignoring fragments, is equal to url, then abort these steps.
-
Navigate the element’s child browsing context to url.
Furthermore, if the active document of the element’s child browsing context before such a navigation was not completely loaded at the time of the new navigation, then the navigation must be completed with replacement enabled.
Similarly, if the child browsing context’s session history contained only one Document
when the process the iframe
attributes algorithm was invoked, and
that was the about:blank
Document
created when the child browsing context was created, then any navigation required of the user agent in that algorithm must be
completed with replacement enabled.
When a Document
in an iframe
is marked as completely loaded, the user
agent must run the iframe load event steps in parallel.
A load
event is also fired at the iframe
element when it is created if no other
data is loaded in it.
Each Document
has an iframe load in progress flag and a mute iframe load flag. When a Document
is created, these flags must be unset for that Document
.
The iframe load event steps are as follows:
- Let child document be the active document of the
iframe
element’s nested browsing context. - If child document has its mute iframe load flag set, abort these steps.
- Set child document’s iframe load in progress flag.
- Fire a simple event named
load
at theiframe
element. - Unset child document’s iframe load in progress flag.
This, in conjunction with scripting, can be used to probe the URL space of the local network’s HTTP servers. User agents may implement cross-origin access control policies that are stricter than those described above to mitigate this attack, but unfortunately such policies are typically not compatible with existing Web content.
When the iframe
’s browsing context’s active document is
not ready for post-load tasks, and when anything in the iframe
is delaying the load event of the iframe
’s browsing context’s active document, and when the iframe
’s browsing context is in the delaying load
events
mode, the iframe
must delay the load event of its document.
If, during the handling of the load
event, the browsing context in the iframe
is again navigated, that will further delay the load event.
If, when the element is created, the srcdoc
attribute is not set, and the src
attribute is either also not set or set but its value cannot be parsed, the browsing context will remain at the initial about:blank
page.
If the user navigates away from this page, the iframe
’s corresponding WindowProxy
object will proxy new Window
objects for new Document
objects, but the src
attribute will not change.
The name
attribute, if present, must be a valid browsing context name. The given value is used to name the nested browsing context. When the browsing context is created, if the attribute
is present, the browsing context name must be set to the value of this attribute;
otherwise, the browsing context name must be set to the empty string.
Whenever the name
attribute is set, the nested browsing context’s name must be changed to
the new value. If the attribute is removed, the browsing context name must be set to
the empty string.
The sandbox
attribute, when specified,
enables a set of extra restrictions on any content hosted by the iframe
. Its value
must be an unordered set of unique space-separated tokens that are ASCII
case-insensitive. The allowed values are allow-forms
, allow-pointer-lock
, allow-popups
, allow-presentation
, allow-same-origin
, allow-scripts
, and allow-top-navigation
.
When the attribute is set, the content is treated as being from a unique origin,
forms, scripts, and various potentially annoying APIs are disabled, links are prevented from
targeting other browsing contexts, and plugins are secured.
The allow-same-origin
keyword causes
the content to be treated as being from its real origin instead of forcing it into a unique
origin; the allow-top-navigation
keyword allows the content to navigate its top-level browsing context;
and the allow-forms
, allow-pointer-lock
, allow-popups
, allow-presentation
and allow-scripts
keywords re-enable forms, the
pointer lock API, popups, the presentation API, and scripts respectively. [POINTERLOCK] [PRESENTATION-API]
Setting both the allow-scripts
and allow-same-origin
keywords together when the
embedded page has the same origin as the page containing the iframe
allows the embedded page to simply remove the sandbox
attribute and then reload itself, effectively breaking out of the sandbox altogether.
These flags only take effect when the nested browsing context of
the iframe
is navigated. Removing them, or removing the
entire sandbox
attribute, has no effect on an
already-loaded page.
Potentially hostile files should not be served from the same server as the file
containing the iframe
element. Sandboxing hostile content is of minimal help if an
attacker can convince the user to just visit the hostile content directly, rather than in the iframe
. To limit the damage that can be caused by hostile HTML content, it should be
served from a separate dedicated domain. Using a different domain ensures that scripts in the
files are unable to attack the site, even if the user is tricked into visiting those pages
directly, without the protection of the sandbox
attribute.
When an iframe
element with a sandbox
attribute has its nested browsing context created (before the initial about:blank
Document
is created), and when an iframe
element’s sandbox
attribute is set or changed while it
has a nested browsing context, the user agent must parse the sandboxing directive using the attribute’s value as the input, the iframe
element’s nested browsing context’s iframe
sandboxing flag set as the output, and, if the iframe
has an allowfullscreen
attribute, the allow fullscreen flag.
When an iframe
element’s sandbox
attribute is removed while it has a nested browsing context, the user agent must
empty the iframe
element’s nested browsing context’s iframe
sandboxing flag set as the output.
<p>We’re not scared of you! Here is your content, unedited:</p> <iframe title="Example iframe" sandbox src="https://usercontent.example.net/getusercontent.cgi?id=12193"></iframe>
It is important to use a separate domain so that if the attacker convinces the user to visit that page directly, the page doesn’t run in the context of the site’s origin, which would make the user vulnerable to any attack found in the page.
<iframe title="Maps" sandbox="allow-same-origin allow-forms allow-scripts" src="https://maps.example.com/embedded.html"></iframe>
<iframe title="Example iframe" sandbox="allow-same-origin allow-forms" src=B></iframe>
Suppose that file B contained an iframe also:
<iframe title="Example iframe" sandbox="allow-scripts" src=C></iframe>
Further, suppose that file C contained a link:
<a href=D>Link</a>
For this example, suppose all the files were served as text/html
.
Page C in this scenario has all the sandboxing flags set. Scripts are disabled, because the iframe
in A has scripts disabled, and this overrides the allow-scripts
keyword set on the iframe
in B. Forms are also disabled, because the inner iframe
(in B)
does not have the allow-forms
keyword
set.
Suppose now that a script in A removes all the sandbox
attributes in A and B.
This would change nothing immediately. If the user clicked the link in C, loading page D into the iframe
in B, page D would now act as if the iframe
in B had the allow-same-origin
and allow-forms
keywords set, because that was the
state of the nested browsing context in the iframe
in A when page B was
loaded.
Generally speaking, dynamically removing or changing the sandbox
attribute is ill-advised, because it can make it quite
hard to reason about what will be allowed and what will not.
The allowfullscreen
attribute is a boolean attribute. When specified, it indicates that Document
objects in
the iframe
element’s browsing context are to be allowed to use requestFullscreen()
(if it’s not blocked for other
reasons, e.g., there is another ancestor iframe
without this attribute set).
iframe
is used to embed a player from a video site. The allowfullscreen
attribute is needed to enable the
player to show its video fullscreen.
<article> <header> <p><img src="/usericons/1627591962735"> <b>Fred Flintstone</b></p> <p><a href="/posts/3095182851" rel=bookmark>12:44</a> — <a href="#acl-3095182851">Private Post</a></p> </header> <main> <p>Check out my new ride!</p> <iframe title="Video" src="https://video.example.com/embed?id=92469812" allowfullscreen></iframe> </main> </article>
The allowpaymentrequest
attribute is a boolean attribute. When specified, it indicates that Document
objects in the iframe
element’s browsing context are to be allowed to use the PaymentRequest
interface
to make payment requests.
To determine whether a Document
object document is allowed to use the feature indicated by attribute name allowattribute, run these steps:
-
If document has no browsing context, then return false.
-
If document’s browsing context is a top-level browsing context, then return true.
-
If document’s browsing context has a browsing context container that is an
iframe
element with an allowattribute attribute specified, and whose node document is allowed to use the feature indicated by allowattribute, then return true. -
Return false.
The iframe
element supports dimension attributes for cases where the
embedded content has specific dimensions (e.g., ad units have well-defined dimensions).
An iframe
element never has fallback content, as it will always
create a nested browsing context, regardless of whether the specified initial
contents are successfully used.
Descendants of iframe
elements represent nothing. (In legacy user agents that do
not support iframe
elements, the contents would be parsed as markup that could act as
fallback content.)
When used in HTML documents, the allowed content model
of iframe
elements is text, except that invoking the HTML fragment parsing
algorithm with the iframe
element as the context element and the text contents as
the input must result in a list of nodes that are all phrasing content,
with no parse errors having occurred, with no script
elements being anywhere in the list or as descendants of elements in the list, and with all the
elements in the list (including their descendants) being themselves conforming.
The iframe
element must be empty in XML documents.
The HTML parser treats markup inside iframe
elements as
text.
The IDL attributes src
, srcdoc
, name
, and sandbox
must reflect the respective
content attributes of the same name.
The supported tokens for sandbox
's DOMTokenList
are the
allowed values defined in the sandbox
attribute and supported by the user agent.
The allowFullscreen
IDL attribute
must reflect the allowfullscreen
content attribute.
The allowPaymentRequest
IDL
attribute must reflect the allowpaymentrequest
content attribute.
The contentDocument
IDL attribute must
return the Document
object of the active document of the iframe
element’s nested browsing context, if any and if its origin is the same origin-domain as the origin specified by the incumbent settings object, or null otherwise.
The contentWindow
IDL attribute must
return the WindowProxy
object of the iframe
element’s nested browsing context, if any, or null otherwise.
iframe
to include advertising from an
advertising broker:
<iframe title="Advert" src="https://ads.example.com/?customerid=923513721&format=banner" width="468" height="60"></iframe>
4.7.7. The embed
element
- Categories:
- Flow content.
- Phrasing content.
- Embedded content.
- Interactive content.
- Palpable content.
- Contexts in which this element can be used:
- Where embedded content is expected.
- Content model:
- Nothing.
- Tag omission in text/html:
- No end tag
- Content attributes:
- Global attributes
src
- Address of the resourcetype
- Type of embedded resourcewidth
- Horizontal dimensionheight
- Vertical dimension- Any other attribute that has no namespace (see prose).
- Allowed ARIA role attribute values:
application
,document
orimg
orpresentation
.- Allowed ARIA state and property attributes:
- Global aria-* attributes
- Any
aria-*
attributes applicable to the allowed roles. - DOM interface:
-
interface HTMLEmbedElement : HTMLElement { attribute DOMString src; attribute DOMString type; attribute DOMString width; attribute DOMString height; legacycaller any (any... arguments); };
Depending on the type of content instantiated by theembed
element, the node may also support other interfaces.
The embed
element provides an integration point for an external (typically
non-HTML) application or interactive content.
The src
attribute gives the address of the
resource being embedded. The attribute, if present, must contain a valid non-empty URL
potentially surrounded by spaces.
The type
attribute, if present, gives the MIME type by which the plugin to instantiate is selected. The value must be a valid mime type. If both the type
attribute and
the src
attribute are present, then the type
attribute must specify the same type as the explicit Content-Type metadata of the resource given by the src
attribute.
While any of the following conditions are occurring, any plugin instantiated for
the element must be removed, and the embed
element represents nothing:
- The element has neither a
src
attribute nor atype
attribute. - The element has a media element ancestor.
- The element has an ancestor
object
element that is not showing its fallback content.
An embed
element is said to be potentially
active when the following conditions are all met simultaneously:
- The element is in a
Document
or was in aDocument
the last time the event loop reached step 1. - The element’s node document is fully active.
- The element has either a
src
attribute set or atype
attribute set (or both). - The element’s
src
attribute is either absent or its value is not the empty string. - The element is not a descendant of a media element.
- The element is not a descendant of an
object
element that is not showing its fallback content. - The element is being rendered, or was being rendered the last time the event loop reached step 1.
Whenever an embed
element that was not potentially active becomes potentially active, and whenever a potentially active embed
element that is
remaining potentially active and has its src
attribute set, changed, or removed or its type
attribute set, changed, or removed, the user agent must queue a task using the embed task source to run the embed
element setup steps.
The embed
element setup steps are as follows:
- If another task has since been queued to run the
embed
element setup steps for this element, then abort these steps. -
- If the element has a
src
attribute set -
The user agent must parse the value of the element’s
src
attribute, relative to the element. If that is successful, the user agent should run these steps:- Let request be a new request whose URL is the resulting URL string, client is the element’s node
document’s
Window
object’s environment settings object, destination is "unknown
", omit-Origin
-header flag is set if the element doesn’t have a browsing context scope origin, credentials mode is "include
", and whose use-URL-credentials flag is set. - Fetch request.
The task that is queued by the networking task source once the resource has been fetched must run the following steps:
- If another task has since been queued to run the
embed
element setup steps for this element, then abort these steps. -
Determine the type of the content being embedded, as follows (stopping at the first substep that determines the type):
- If the element has a
type
attribute, and that attribute’s value is a type that a plugin supports, then the value of thetype
attribute is the content’s type. -
Otherwise, if applying the URL parser algorithm to the URL of the specified resource (after any redirects) results in a URL record whose path component matches a pattern that a plugin supports, then the content’s type is the type that the plugin can handle.
For example, a plugin might say that it can handle resources with path components that end with the four character string "
.swf
". - Otherwise, if the specified resource has explicit Content-Type metadata, then that is the content’s type.
- Otherwise, the content has no type and there can be no appropriate plugin for it.
- If the element has a
-
If the previous step determined that the content’s type is
image/svg+xml
, then run the following substeps:- If the
embed
element is not associated with a nested browsing context, associate the element with a newly created nested browsing context, and, if the element has aname
attribute, set the browsing context name of the element’s nested browsing context to the value of this attribute. - Navigate the nested browsing context to
the fetched resource, with replacement enabled, and with the
embed
element’s node document’s browsing context as the source browsing context. (Thesrc
attribute of theembed
element doesn’t get updated if the browsing context gets further navigated to other locations.) - The
embed
element now represents its associated nested browsing context.
- If the
-
Otherwise, find and instantiate an appropriate plugin based on the content’s type, and hand that plugin the content of the resource, replacing any previously instantiated plugin for the element. The
embed
element now represents this plugin instance. - Once the resource or plugin has completely loaded, queue a task to fire a simple event named
load
at the element.
Whether the resource is fetched successfully or not (e.g., whether the response status was an ok status) must be ignored when determining the content’s type and when handing the resource to the plugin.
This allows servers to return data for plugins even with error responses (e.g., HTTP 500 Internal Server Error codes can still contain plugin data).
Fetching the resource must delay the load event of the element’s node document.
- Let request be a new request whose URL is the resulting URL string, client is the element’s node
document’s
- If the element has no
src
attribute set -
The user agent should find and instantiate an appropriate plugin based on the value of the
type
attribute. Theembed
element now represents this plugin instance.Once the plugin is completely loaded, queue a task to fire a simple event named
load
at the element.
- If the element has a
The embed
element has no fallback content. If the user agent can’t
find a suitable plugin when attempting to find and instantiate one for the algorithm above, then
the user agent must use a default plugin. This default could be as simple as saying "Unsupported
Format".
Whenever an embed
element that was potentially
active stops being potentially active, any plugin that had been instantiated for that element must be unloaded.
When a plugin is to be instantiated but it cannot be secured and the sandboxed plugins browsing context
flag is set on the embed
element’s node document’s active
sandboxing flag set, then the user agent must not instantiate the plugin, and
must instead render the embed
element in a manner that conveys that the plugin was disabled. The user agent may offer the user the option to override the
sandbox and instantiate the plugin anyway; if the user invokes such an option, the
user agent must act as if the conditions above did not apply for the purposes of this element.
Plugins that cannot be secured are disabled in sandboxed browsing contexts because they might not honor the restrictions imposed by the sandbox (e.g., they might allow scripting even when scripting in the sandbox is disabled). User agents should convey the danger of overriding the sandbox to the user if an option to do so is provided.
When an embed
element represents a nested browsing context: if the embed
element’s nested browsing context’s active document is not ready for post-load tasks, and when anything is delaying the load event of the embed
element’s browsing context’s active document, and when the embed
element’s browsing context is in the delaying load
events mode, the embed
must delay the load event of its
document.
The task source for the tasks mentioned in this section is the DOM manipulation task source.
Any namespace-less attribute other than name
, align
, hspace
, and vspace
may be
specified on the embed
element, so long as its name is XML-compatible and contains no uppercase ASCII letters. These attributes are then passed as
parameters to the plugin.
All attributes in HTML documents get lowercased automatically, so the restriction on uppercase letters doesn’t affect such documents.
The four exceptions are to exclude legacy attributes that have side-effects beyond just sending parameters to the plugin.
The user agent should pass the names and values of all the attributes of the embed
element that have no namespace to the plugin used, when one is instantiated.
The HTMLEmbedElement
object representing the element must expose the scriptable
interface of the plugin instantiated for the embed
element, if any. At a
minimum, this interface must implement the legacy caller
operation. (It is suggested that the default behavior of this legacy caller operation, e.g.,
the behavior of the default plugin’s legacy caller operation, be to throw a NotSupportedError
exception.)
The embed
element supports dimension attributes.
The IDL attributes src
and type
each must reflect the
respective content attributes of the same name.
<embed src="catgame.swf">
If the user does not have the plugin (for example if the plugin vendor doesn’t support the user’s platform), then the user will be unable to use the resource.
To pass the plugin a parameter "quality" with the value "high", an attribute can be specified:
<embed src="catgame.swf" quality="high">
This would be equivalent to the following, when using an object
element
instead:
<object data="catgame.swf"> <param name="quality" value="high"> </object>
4.7.8. The object
element
- Categories:
- Flow content.
- Phrasing content.
- Embedded content.
- listed, submittable, and reassociateable form-associated element.
- Palpable content.
- Contexts in which this element can be used:
- Where embedded content is expected.
- Content model:
- Zero or more
param
elements, then, transparent. - Tag omission in text/html:
- Neither tag is omissible.
- Content attributes:
- Global attributes
data
- Address of the resourcetype
- Type of embedded resourcetypemustmatch
- Whether thetype
attribute and the Content-Type value need to match for the resource to be usedname
- Name of nested browsing contextform
- Associates the control with aform
elementwidth
- Horizontal dimensionheight
- Vertical dimension- Allowed ARIA role attribute values:
application
,document
orimg
orpresentation
.- Allowed ARIA state and property attributes:
- Global aria-* attributes
- Any
aria-*
attributes applicable to the allowed roles. - DOM interface:
-
interface HTMLObjectElement : HTMLElement { attribute DOMString data; attribute DOMString type; attribute boolean typeMustMatch; attribute DOMString name; readonly attribute HTMLFormElement? form; attribute DOMString width; attribute DOMString height; readonly attribute Document? contentDocument; readonly attribute WindowProxy? contentWindow; readonly attribute boolean willValidate; readonly attribute ValidityState validity; readonly attribute DOMString validationMessage; boolean checkValidity(); boolean reportValidity(); void setCustomValidity(DOMString error); legacycaller any (any... arguments); };
Depending on the type of content instantiated by theobject
element, the node also supports other interfaces.
The object
element can represent an external resource, which, depending on the
type of the resource, will either be treated as an image, as a nested browsing context, or as an external resource to be processed by a plugin.
The data
attribute, if present, specifies the
address of the resource. If present, the attribute must be a valid non-empty URL potentially
surrounded by spaces.
Authors who reference resources from other origins that they do not trust are urged to use the typemustmatch
attribute defined below. Without that
attribute, it is possible in certain cases for an attacker on the remote host to use the plugin
mechanism to run arbitrary scripts, even if the author has used features such as the Flash
"allowScriptAccess" parameter.
The type
attribute, if present, specifies the
type of the resource. If present, the attribute must be a valid mime type.
At least one of either the data
attribute or the type
attribute must be present.
The typemustmatch
attribute is a boolean attribute whose presence indicates that the resource specified by the data
attribute is only to be used if the value of the type
attribute and the Content-Type of the
aforementioned resource match.
The typemustmatch
attribute must not be
specified unless both the data
attribute and the type
attribute are present.
The name
attribute, if present, must be a valid browsing context name. The given value is used to name the nested browsing context, if applicable.
Whenever one of the following conditions occur:
- the element is created,
- the element is popped off the stack of open elements of an HTML parser or XML parser,
- the element is not on the stack of open elements of an HTML parser or XML parser, and it is either inserted into a document or removed from a document,
- the element’s node document changes whether it is fully active,
- one of the element’s ancestor
object
elements changes to or from showing its fallback content, - the element’s
classid
attribute is set, changed, or removed, - the element’s
classid
attribute is not present, and itsdata
attribute is set, changed, or removed, - neither the element’s
classid
attribute nor itsdata
attribute are present, and itstype
attribute is set, changed, or removed, - the element changes from being rendered to not being rendered, or vice versa,
...the user agent must queue a task to run the following steps to (re)determine
what the object
element represents. This task being queued or actively running must delay the load
event of the element’s node document.
-
If the user has indicated a preference that this
object
element’s fallback content be shown instead of the element’s usual behavior, then jump to the step below labeled fallback.For example, a user could ask for the element’s fallback content to be shown because that content uses a format that the user finds more accessible.
-
If the element has an ancestor media element, or has an ancestor
object
element that is not showing its fallback content, or if the element is not in aDocument
with a browsing context, or if the element’s node document is not fully active, or if the element is still in the stack of open elements of an HTML parser or XML parser, or if the element is not being rendered, or if the Should element be blocked a priori by Content Security Policy? algorithm returns "Blocked" when executed on the element, then jump to the step below labeled fallback. [CSP3]. -
If the
classid
attribute is present, and has a value that isn’t the empty string, then: if the user agent can find a plugin suitable according to the value of theclassid
attribute, and either plugins aren’t being sandboxed or that plugin can be secured, then that plugin should be used, and the value of thedata
attribute, if any, should be passed to the plugin. If no suitable plugin can be found, or if the plugin reports an error, jump to the step below labeled fallback. -
If the
data
attribute is present and its value is not the empty string, then:- If the
type
attribute is present and its value is not a type that the user agent supports, and is not a type that the user agent can find a plugin for, then the user agent may jump to the step below labeled fallback without fetching the content to examine its real type. - Parse the URL specified by the
data
attribute, relative to the element. - If that failed, fire a simple event named
error
at the element, then jump to the step below labeled fallback. - Let request be a new request whose URL is the resulting URL string, client is the element’s node
document’s
Window
object’s environment settings object, destination is "unknown
", omit-Origin
-header flag is set if the element doesn’t have a browsing context scope origin, credentials mode is "include
", and whose use-URL-credentials flag is set. -
Fetch request.
Fetching the resource must delay the load event of the element’s node document until the task that is queued by the networking task source once the resource has been fetched (defined next) has been run.
- If the resource is not yet available (e.g., because the resource was not available in the cache, so that loading the resource required making a request over the network), then jump to the step below labeled fallback. The task that is queued by the networking task source once the resource is available must restart this algorithm from this step. Resources can load incrementally; user agents may opt to consider a resource "available" whenever enough data has been obtained to begin processing the resource.
- If the load failed (e.g., there was an HTTP 404 error, there was a DNS error), fire
a simple event named
error
at the element, then jump to the step below labeled fallback. -
Determine the resource type, as follows:
-
Let the resource type be unknown.
-
If the
object
element has atype
attribute and atypemustmatch
attribute, and the resource has associated Content-Type metadata, and the type specified in the resource’s Content-Type metadata is an ASCII case-insensitive match for the value of the element’stype
attribute, then let resource type be that type and jump to the step below labeled handler. -
If the
object
element has atypemustmatch
attribute, jump to the step below labeled handler. -
If the user agent is configured to strictly obey Content-Type headers for this resource, and the resource has associated Content-Type metadata, then let the resource type be the type specified in the resource’s Content-Type metadata, and jump to the step below labeled handler.
This can introduce a vulnerability, wherein a site is trying to embed a resource that uses a particular plugin, but the remote site overrides that and instead furnishes the user agent with a resource that triggers a different plugin with different security characteristics.
-
If there is a
type
attribute present on theobject
element, and that attribute’s value is not a type that the user agent supports, but it is a type that a plugin supports, then let the resource type be the type specified in thattype
attribute, and jump to the step below labeled handler. -
Run the appropriate set of steps from the following list:
- If the resource has associated Content-Type metadata
-
-
Let binary be false.
-
If the type specified in the resource’s Content-Type metadata is "
text/plain
", and the result of applying the rules for distinguishing if a resource is text or binary to the resource is that the resource is nottext/plain
, then set binary to true. -
If the type specified in the resource’s Content-Type metadata is "
application/octet-stream
", then set binary to true. -
If binary is false, then let the resource type be the type specified in the resource’s Content-Type metadata, and jump to the step below labeled handler.
-
If there is a
type
attribute present on theobject
element, and its value is notapplication/octet-stream
, then run the following steps:-
If the attribute’s value is a type that a plugin supports, or the
attribute’s value is a type that starts with "image/
" that is not also an XML MIME type, then let the resource type be the type specified in thattype
attribute. -
Jump to the step below labeled handler.
-
-
- Otherwise, if the resource does not have associated Content-Type metadata
-
-
If there is a
type
attribute present on theobject
element, then let the tentative type be the type specified in thattype
attribute.Otherwise, let tentative type be the computed type of the resource.
-
If tentative type is not
application/octet-stream
, then let resource type be tentative type and jump to the step below labeled handler.
-
-
If applying the URL parser algorithm to the URL of the specified resource (after any redirects) results in a URL record whose path component matches a pattern that a plugin supports, then let resource type be the type that the plugin can handle.
For example, a plugin might say that it can handle resources with path components that end with the four character string "
.swf
".
It is possible for this step to finish, or for one of the substeps above to jump straight to the next step, with resource type still being unknown. In both cases, the next step will trigger fallback.
-
-
Handler: Handle the content as given by the first of the following cases that
matches:
- If the resource type is not a type that the user agent supports, but it is a type that a plugin supports
-
If plugins are being sandboxed and the plugin that supports resource type cannot be secured, jump to the step below labeled fallback.
Otherwise, the user agent should use the plugin that supports resource type and pass the content of the resource to that plugin. If the plugin reports an error, then jump to the step below labeled fallback.
- If the resource type is an XML MIME type, or if the resource type does not start with "
image/
" -
The
object
element must be associated with a newly created nested browsing context, if it does not already have one.If the URL of the given resource is not
about:blank
, the element’s nested browsing context must then be navigated to that resource, with replacement enabled, and with theobject
element’s node document’s browsing context as the source browsing context. (Thedata
attribute of theobject
element doesn’t get updated if the browsing context gets further navigated to other locations.)If the URL of the given resource is
about:blank
, then, instead, the user agent must queue a task to fire a simple event namedload
at theobject
element. Noload
event is fired at theabout:blank
document itself.The
object
element represents the nested browsing context.If the
name
attribute is present, the browsing context name must be set to the value of this attribute; otherwise, the browsing context name must be set to the empty string. - If the resource type starts with "
image/
", and support for images has not been disabled -
Apply the image sniffing rules to determine the type of the image.
The
object
element represents the specified image. The image is not a nested browsing context.If the image cannot be rendered, e.g., because it is malformed or in an unsupported format, jump to the step below labeled fallback.
- Otherwise
-
The given resource type is not supported. Jump to the step below labeled fallback.
If the previous step ended with the resource type being unknown, this is the case that is triggered.
- The element’s contents are not part of what the
object
element represents. -
Abort these steps. Once the resource is completely loaded, queue a task to fire a simple event named
load
at the element.
- If the
- If the
data
attribute is absent but thetype
attribute is present, and the user agent can find a plugin suitable according to the value of thetype
attribute, and either plugins aren’t being sandboxed or the plugin can be secured, then that plugin should be used. If these conditions cannot be met, or if the plugin reports an error, jump to the step below labeled fallback. Otherwise abort these steps; once the plugin is completely loaded, queue a task to fire a simple event namedload
at the element. - Fallback: The
object
element represents the element’s children, ignoring any leadingparam
element children. This is the element’s fallback content. If the element has an instantiated plugin, then unload it.
When the algorithm above instantiates a plugin, the user agent
should pass to the plugin used the names and values of all the attributes on the
element, in the order they were added to the element, with the attributes added by the parser
being ordered in source order, followed by a parameter named "PARAM" whose value is null, followed
by all the names and values of parameters given by param
elements that are children of the object
element, in tree
order. If the plugin supports a scriptable interface, the HTMLObjectElement
object representing the element should expose that interface. The object
element represents the plugin. The plugin is not a nested browsing context.
Plugins are considered sandboxed for the purpose of an object
element if the sandboxed plugins browsing context flag is set on
the object
element’s node document’s active sandboxing flag
set.
Due to the algorithm above, the contents of object
elements act as fallback
content, used only when referenced resources can’t be shown (e.g., because it returned a 404
error). This allows multiple object
elements to be nested inside each other,
targeting multiple user agents with different capabilities, with the user agent picking the first
one it supports.
When an object
element represents a nested browsing context: if the object
element’s nested browsing context’s active document is not ready for post-load tasks, and when anything is delaying the load event of the object
element’s browsing context’s active document, and when the object
element’s browsing context is in the delaying load
events mode, the object
must delay the load event of its
document.
The task source for the tasks mentioned in this section is the DOM manipulation task source.
Whenever the name
attribute is set, if the object
element has a nested browsing context, its name must be changed to the new value. If the attribute is removed, if the object
element has a browsing context, the browsing context name must be set to the empty string.
The form
attribute is used to explicitly associate the object
element with its form owner.
Constraint validation: object
elements are always barred
from constraint validation.
The object
element supports dimension attributes.
The IDL attributes data
, type
and name
each must reflect the
respective content attributes of the same name. The typeMustMatch
IDL attribute must reflect the typemustmatch
content attribute.
The contentDocument
IDL attribute must
return the Document
object of the active document of the object
element’s nested browsing context, if any and if its origin is the same origin-domain as the origin specified by the incumbent settings object, or null otherwise.
The contentWindow
IDL attribute must
return the WindowProxy
object of the object
element’s nested browsing context, if
it has one; otherwise, it must return null.
The willValidate
, validity
, and validationMessage
attributes, and the checkValidity()
, reportValidity()
, and setCustomValidity()
methods, are
part of the constraint validation API. The form
IDL attribute is part
of the element’s forms API.
All object
elements have a legacy caller
operation. If the object
element has an instantiated plugin that
supports a scriptable interface that defines a legacy caller operation, then that must be the
behavior of the object’s legacy caller operation. Otherwise, the object’s legacy caller operation
must be to throw a NotSupportedError
exception.
object
element. (Generally speaking, it is better to avoid using applets like these and instead use
native JavaScript and HTML to provide the functionality, since that way the application will work
on all Web browsers without requiring a third-party plugin. Many devices, especially embedded
devices, do not support third-party technologies like Java.)
<figure> <object type="application/x-java-applet"> <param name="code" value="MyJavaClass"> <p>You do not have Java available, or it is disabled.</p> </object> <figcaption>My Java Clock</figcaption> </figure>
object
element.
<figure> <object data="clock.html"></object> <figcaption>My HTML Clock</figcaption> </figure>
video
element to show the video for those using user agents that support video
, and finally providing a link to the video for those who have neither Flash
nor a video
-capable browser.
<p>Look at my video: <object type="application/x-shockwave-flash"> <param name=movie value="https://video.example.com/library/watch.swf"> <param name=allowfullscreen value=true> <param name=flashvars value="https://video.example.com/vids/315981"> <video controls src="https://video.example.com/vids/315981"> <a href="https://video.example.com/vids/315981">View video</a>. </video> </object> </p>
4.7.9. The param
element
- Categories:
- None.
- Contexts in which this element can be used:
- As a child of an
object
element, before any flow content. - Content model:
- Nothing.
- Tag omission in text/html:
- No end tag
- Content attributes:
- Global attributes
name
- Name of parametervalue
- Value of parameter- Allowed ARIA role attribute values:
- None
- Allowed ARIA state and property attributes:
- Global aria-* attributes
- DOM interface:
-
interface HTMLParamElement : HTMLElement { attribute DOMString name; attribute DOMString value; };
The param
element defines parameters for plugins invoked by object
elements. It does not represent anything on its own.
The name
attribute gives the name of the
parameter.
The value
attribute gives the value of the
parameter.
Both attributes must be present. They may have any value.
If both attributes are present, and if the parent element of the param
is an object
element, then the element defines a parameter with the given name-value pair.
If either the name or value of a parameter defined
by a param
element that is the child of an object
element that represents an instantiated plugin changes, and if that plugin is communicating with the user agent using an API that features the ability to
update the plugin when the name or value of a parameter so changes, then the user agent must
appropriately exercise that ability to notify the plugin of the change.
The IDL attributes name
and value
must both reflect the respective
content attributes of the same name.
param
element can be used to pass a parameter
to a plugin, in this case the O3D plugin.
<!DOCTYPE HTML> <html lang="en"> <head> <title>O3D Utah Teapot</title> </head> <body> <p> <object type="application/vnd.o3d.auto"> <param name="o3d_features" value="FloatingPointTextures"> <img src="o3d-teapot.png" title="3D Utah Teapot illustration rendered using O3D." alt="When O3D renders the Utah Teapot, it appears as a squat teapot with a shiny metallic finish on which the surroundings are reflected, with a faint shadow caused by the lighting."> <p>To see the teapot actually rendered by O3D on your computer, please download and install the <a href="https://code.google.com/apis/o3d/docs/gettingstarted.html#install">O3D plugin</a>.</p> </object> <script src="o3d-teapot.js"></script> </p> </body> </html>
4.7.10. The video
element
- Categories:
- Flow content.
- Phrasing content.
- Embedded content.
- If the element has a
controls
attribute: interactive content. - Palpable content.
- Contexts in which this element can be used:
- Where embedded content is expected.
- Content model:
- If the element has a
src
attribute: zero or moretrack
elements, then transparent, but with no media element descendants. - If the element does not have a
src
attribute: zero or moresource
elements, then zero or moretrack
elements, then transparent, but with no media element descendants. - Tag omission in text/html:
- Neither tag is omissible
- Content attributes:
- Global attributes
src
- Address of the resourcecrossorigin
- How the element handles crossorigin requestsposter
- Poster frame to show prior to video playbackpreload
- Hints how much buffering the media resource will likely needautoplay
- Hint that the media resource can be started automatically when the page is loadedloop
- Whether to loop the media resourcemuted
- Whether to mute the media resource by defaultcontrols
- Show user agent controlswidth
- Horizontal dimensionheight
- Vertical dimension- Allowed ARIA role attribute values:
application
.- Allowed ARIA state and property attributes:
- Global aria-* attributes
- Any
aria-*
attributes applicable to the allowed roles. - DOM interface:
-
interface HTMLVideoElement : HTMLMediaElement { attribute unsigned long width; attribute unsigned long height; readonly attribute unsigned long videoWidth; readonly attribute unsigned long videoHeight; attribute DOMString poster; };
A video
element is used for playing videos or movies, and audio files with
captions.
Content may be provided inside the video
element. User agents
should not show this content to the user; it is intended for older Web browsers which do
not support video
, so that legacy video plugins can be tried, or to show text to the
users of these older browsers informing them of how to access the video contents.
In particular, this content is not intended to address accessibility concerns. To
make video content accessible to people with disabilities, a variety of features are available.
Captions and sign language tracks can be embedded in the video stream, or as external files using the track
element. Audio descriptions can be provided, either as a separate track embedded in the video
stream, or by referencing a WebVTT file with the track
element that the user agent can present
as synthesized speech. WebVTT can also be used to provide chapter titles. For
users who would rather not use a media element at all, transcripts or other textual alternatives
can be provided by simply linking to them in the prose near the video
element. [WEBVTT]
The video
element is a media element whose media data is
ostensibly video data, possibly with associated audio data.
The src
, preload
, autoplay
, loop
, muted
, and controls
attributes are the attributes common to all media elements.
The poster
content attribute gives the address of an
image file that the user agent can show while no video data is available. The attribute, if
present, must contain a valid non-empty URL potentially surrounded by spaces.
If the specified resource is to be used, then, when the element is created or when the poster
attribute is set, changed, or removed, the user agent must
run the following steps to determine the element’s poster frame (regardless of the
value of the element’s show poster flag):
- If there is an existing instance of this algorithm running for this
video
element, abort that instance of this algorithm without changing the poster frame. - If the
poster
attribute’s value is the empty string or if the attribute is absent, then there is no poster frame; abort these steps. - Parse the
poster
attribute’s value relative to the element. If this fails, then there is no poster frame; abort these steps. - Let request be a new request whose URL is the resulting URL string, client is the element’s node document’s
Window
object’s environment settings object, type is "image
", destination is "subresource
", credentials mode is "include
", and whose use-URL-credentials flag is set. - Fetch request. This must delay the load event of the element’s node document.
- If an image is thus obtained, the poster frame is that image. Otherwise, there is no poster frame.
The image given by the poster
attribute,
the poster frame, is intended to be a representative frame of the
video (typically one of the first non-blank frames) that gives the user an idea of what the video
is like.
A video
element represents what is given for the first matching condition in the
list below:
- When no video data is available (the element’s
readyState
attribute is eitherHAVE_NOTHING
, orHAVE_METADATA
but no video data has yet been obtained at all, or the element’sreadyState
attribute is any subsequent value but the media resource does not have a video channel) - The
video
element represents its poster frame, if any, or else transparent black with no intrinsic dimensions. - When the
video
element ispaused
, the current playback position is the first frame of video, and the element’s show poster flag is set - The
video
element represents its poster frame, if any, or else the first frame of the video. - When the
video
element ispaused
, and the frame of video corresponding to the current playback position is not available (e.g., because the video is seeking or buffering) - When the
video
element is neither potentially playing norpaused
(e.g., when seeking or stalled) - The
video
element represents the last frame of the video to have been rendered. - When the
video
element ispaused
- The
video
element represents the frame of video corresponding to the current playback position. - Otherwise (the
video
element has a video channel and is potentially playing) - The
video
element represents the frame of video at the continuously increasing "current" position. When the current playback position changes such that the last frame rendered is no longer the frame corresponding to the current playback position in the video, the new frame must be rendered.
Frames of video must be obtained from the video track that was selected when the event loop last reached step 1.
Which frame in a video stream corresponds to a particular playback position is defined by the video stream’s format.
The video
element also represents any text track cues whose text track cue active flag is set and whose text track is in the showing mode, and any
audio from the media resource, at the current playback position.
Any audio associated with the media resource must, if played, be played synchronized with the current playback position, at the element’s effective media volume. The user agent must play the audio from audio tracks that were enabled when the event loop last reached step 1.
In addition to the above, the user agent may provide messages to the user (such as "buffering", "no video loaded", "error", or more detailed information) by overlaying text or icons on the video or other areas of the element’s playback area, or in another appropriate manner.
User agents that cannot render the video may instead make the element represent a link to an external video playback utility or to the video data itself.
When a video
element’s media resource has a video channel, the
element provides a paint source whose width is the media resource’s intrinsic width, whose height is the media resource’s intrinsic height, and whose appearance is
the frame of video corresponding to the current playback position, if that is available, or else
(e.g., when the video is seeking or buffering) its previous appearance, if any, or else (e.g.,
because the video is still loading the first frame) blackness.
- video .
videoWidth
- video .
videoHeight
-
These attributes return the intrinsic dimensions of the video, or zero if the dimensions are not known.
The intrinsic width and intrinsic height of the media resource are the dimensions of the resource in CSS pixels after taking into account the resource’s dimensions, aspect ratio, clean aperture, resolution, and so forth, as defined for the format used by the resource. If an anamorphic format does not define how to apply the aspect ratio to the video data’s dimensions to obtain the "correct" dimensions, then the user agent must apply the ratio by increasing one dimension and leaving the other unchanged.
The videoWidth
IDL attribute must return
the intrinsic width of the video in CSS pixels.
The videoHeight
IDL attribute must return
the intrinsic height of the video in CSS
pixels. If the element’s readyState
attribute is HAVE_NOTHING
, then the attributes must return 0.
Whenever the intrinsic width or intrinsic height of the video changes
(including, for example, because the selected video
track was changed), if the element’s readyState
attribute is not HAVE_NOTHING
, the user agent must queue a task to fire a simple event named resize
at the media element.
The video
element supports dimension attributes.
In the absence of style rules to the contrary, video content should be rendered inside the element’s playback area such that the video content is shown centered in the playback area at the largest possible size that fits completely within it, with the video content’s aspect ratio being preserved. Thus, if the aspect ratio of the playback area does not match the aspect ratio of the video, the video will be shown letterboxed or pillarboxed. Areas of the element’s playback area that do not contain the video represent nothing.
In user agents that implement CSS, the above requirement can be implemented by using the style rule suggested in §10 Rendering.
The intrinsic width of a video
element’s playback area is the intrinsic width of the poster frame, if that is available and the
element currently represents its poster frame; otherwise, it is the intrinsic width of the video resource, if that is
available; otherwise the intrinsic width is missing.
The intrinsic height of a video
element’s playback area is the intrinsic height of the poster frame, if that is available and the
element currently represents its poster frame; otherwise it is the intrinsic height of the video resource, if that is
available; otherwise the intrinsic height is missing.
The default object size is a width of 300 CSS pixels and a height of 150 CSS pixels. [CSS3-IMAGES]
User agents should provide controls to enable or disable the display of closed captions, audio description tracks, and other additional data associated with the video stream, though such features should, again, not interfere with the page’s normal rendering.
User agents may allow users to view the video content in manners more suitable to the user
(e.g., fullscreen or in an independent resizable window). Captions, subtitles or other additional
visual tracks should remain available and visible when enabled. As for the other user interface
features, controls to enable this should not interfere with the page’s normal rendering unless
the user agent is exposing a user interface. As for the other user interface features, controls to
enable this should not interfere with the page’s normal rendering unless the user agent is exposing a user interface. In such an independent context, however, user agents may make
full user interfaces visible e.g., play, pause, seeking, and volume controls even if the controls
attribute is absent.
User agents may allow video playback to affect system features that could interfere with the user’s experience; for example, user agents could disable screensavers while video playback is in progress.
The poster
IDL attribute must reflect the poster
content attribute.
<script> function failed(e) { // video playback failed - show a message saying why switch (e.target.error.code) { case e.target.error.MEDIA_ERR_ABORTED: alert('You aborted the video playback.'); break; case e.target.error.MEDIA_ERR_NETWORK: alert('A network error caused the video download to fail part-way.'); break; case e.target.error.MEDIA_ERR_DECODE: alert('The video playback was aborted due to a corruption problem or because the video used features your browser did not support.'); break; case e.target.error.MEDIA_ERR_SRC_NOT_SUPPORTED: alert('The video could not be loaded, either because the server or network failed or because the format is not supported.'); break; default: alert('An unknown error occurred.'); break; } } </script> <p><video src="tgif.vid" autoplay controls onerror="failed(event)"></video></p> <p><a href="tgif.vid">Download the video file</a>.</p>
4.7.11. The audio
element
- Categories:
- Flow content.
- Phrasing content.
- Embedded content.
- If the element has a
controls
attribute: Interactive content. - If the element has a
controls
attribute: Palpable content. - Contexts in which this element can be used:
- Where embedded content is expected.
- Content model:
- If the element has a
src
attribute: zero or moretrack
elements, then transparent, but with no media element descendants. - If the element does not have a
src
attribute: zero or moresource
elements, then zero or moretrack
elements, then transparent, but with no media element descendants. - Tag omission in text/html:
- Neither tag is omissible
- Content attributes:
- Global attributes
src
- Address of the resourcecrossorigin
- How the element handles crossorigin requestspreload
- Hints how much buffering the media resource will likely needautoplay
- Hint that the media resource can be started automatically when the page is loadedloop
- Whether to loop the media resourcemuted
- Whether to mute the media resource by defaultcontrols
- Show user agent controls- Allowed ARIA role attribute values:
application
.- Allowed ARIA state and property attributes:
- Global aria-* attributes
- Any
aria-*
attributes applicable to the allowed roles. - DOM interface:
-
[NamedConstructor=Audio(optional DOMString src)] interface HTMLAudioElement : HTMLMediaElement {};
An audio
element represents a sound or audio stream.
Content may be provided inside the audio
element. User agents
should not show this content to the user; it is intended for older Web browsers which do
not support audio
, so that legacy audio plugins can be tried, or to show text to the
users of these older browsers informing them of how to access the audio contents.
In particular, this content is not intended to address accessibility concerns. To
make audio content accessible to the deaf or to those with other physical or cognitive
disabilities, a variety of features are available. If captions or a sign language video are
available, the video
element can be used instead of the audio
element to
play the audio, allowing users to enable the visual alternatives. Chapter titles can be provided
to aid navigation, using the track
element and a WebVTT file. And,
naturally, transcripts or other textual alternatives can be provided by simply linking to them in
the prose near the audio
element. [WEBVTT]
The audio
element is a media element whose media data is
ostensibly audio data.
The src
, preload
, autoplay
, loop
, muted
, and controls
attributes are the attributes common to all media elements.
When an audio
element is potentially playing, it must have its audio
data played synchronized with the current playback position, at the element’s effective media volume. The user agent must play the audio from audio tracks that
were enabled when the event loop last reached step 1.
When an audio
element is not potentially playing, audio must not play
for the element.
- audio = new
Audio
( [ url ] ) -
Returns a new
audio
element, with thesrc
attribute set to the value passed in the argument, if applicable.
A constructor is provided for creating HTMLAudioElement
objects (in addition to
the factory methods from DOM such as createElement()
): Audio(src)
. When invoked as a
constructor, it must return a new HTMLAudioElement
object (a new audio
element). The element must be created with its preload
attribute set to the literal value "auto
". If the src argument is present, the object created must be created with its src
content attribute set to the provided value (this will cause the user agent to invoke the object’s resource selection algorithm before returning).
The element’s node document must be the active document of the browsing context of the Window
object on which the interface object of the invoked
constructor is found.
4.7.12. The track
element
- Categories:
- None.
- Contexts in which this element can be used:
- As a child of a media element, before any flow content.
- Content model:
- Nothing.
- Tag omission in text/html:
- No end tag
- Content attributes:
- Global attributes
kind
- The type of text tracksrc
- Address of the resourcesrclang
- Language of the text tracklabel
- User-visible labeldefault
- Enable the track if no other text track is more suitable- Allowed ARIA role attribute values:
- None
- Allowed ARIA state and property attributes:
- Global aria-* attributes
- DOM interface:
-
interface HTMLTrackElement : HTMLElement { attribute DOMString kind; attribute DOMString src; attribute DOMString srclang; attribute DOMString label; attribute boolean default; const unsigned short NONE = 0; const unsigned short LOADING = 1; const unsigned short LOADED = 2; const unsigned short ERROR = 3; readonly attribute unsigned short readyState; readonly attribute TextTrack track; };
The track
element allows authors to specify explicit external text resources for media elements. It
does not represent anything on its own.
The kind
attribute is an enumerated
attribute. The following table lists the keywords defined for this attribute. The keyword
given in the first cell of each row maps to the state given in the second cell.
Keyword | State | Brief description |
---|---|---|
subtitles
| Subtitles | Transcription or translation of the dialog, suitable for when the sound is available but not understood (e.g., because the user does not understand the language of the media resource’s audio track). Overlaid on the video. |
captions
| Captions | Transcription or translation of the dialog, sound effects, relevant musical cues, and other relevant audio information, suitable for when sound is unavailable or not clearly audible (e.g., because it is muted, drowned-out by ambient noise, or because the user is deaf). Overlaid on the video; labeled as appropriate for the hard-of-hearing. |
descriptions
| Descriptions | Textual descriptions of the video component of the media resource, intended for audio synthesis when the visual component is obscured, unavailable, or not usable (e.g., because the user is interacting with the application without a screen while driving, or because the user is blind). Synthesized as audio. |
chapters
| Chapters | Chapter titles, intended to be used for navigating the media resource. Displayed as an interactive (potentially nested) list in the user agent’s interface. |
metadata
| Metadata | Tracks intended for use from script. Not displayed by the user agent. |
The attribute may be omitted. The missing value default is the subtitles state. The invalid value default is the metadata state.
The src
attribute gives the address of the text
track data. The value must be a valid non-empty URL potentially surrounded by spaces.
This attribute must be present.
If the element has a src
attribute whose value is not the
empty string and whose value, when the attribute was set, could be successfully parsed relative to the element’s node document, then the element’s track URL is the resulting URL string. Otherwise, the element’s track URL is the empty string.
kind
attribute is not in the Metadata state, then the WebVTT file must be
a WebVTT file using cue text. [WEBVTT]
Furthermore, if the element’s track URL identifies a WebVTT resource,
and the element’s kind
attribute is in the chapters state, then the WebVTT file must be
both a WebVTT file using chapter title text and a WebVTT file using only nested
cues. [WEBVTT]
The srclang
attribute gives the language of
the text track data. The value must be a valid BCP 47 language tag. This attribute must be present
if the element’s kind
attribute is in the subtitles state. [BCP47]
If the element has a srclang
attribute whose value is
not the empty string, then the element’s track language is the value of the attribute.
Otherwise, the element has no track language.
The label
attribute gives a user-readable
title for the track. This title is used by user agents when listing subtitle, caption, and audio description tracks in their user interface.
The value of the label
attribute, if the attribute is
present, must not be the empty string. Furthermore, there must not be two track
element children of the same media element whose kind
attributes are in the same state, whose srclang
attributes are both missing or have values that
represent the same language, and whose label
attributes are
again both missing or both have the same value.
If the element has a label
attribute whose value is not
the empty string, then the element’s track label is the value of the attribute.
Otherwise, the element’s track label is an empty string.
The default
attribute is a boolean
attribute, which, if specified, indicates that the track is to be enabled if the user’s
preferences do not indicate that another track would be more appropriate.
Each media element must have no more than one track
element child
whose kind
attribute is in the Subtitles or Captions state and whose default
attribute is specified.
Each media element must have no more than one track
element child
whose kind
attribute is in the Descriptions state and whose default
attribute is specified.
Each media element must have no more than one track
element child
whose kind
attribute is in the Chapters state and whose default
attribute is specified.
There is no limit on the number of track
elements whose kind
attribute is in the Metadata state and whose default
attribute is specified.
- track .
readyState
-
Returns the text track readiness state,
represented by a number from the following list:
- track .
NONE
(0) - The text track not loaded state.
- track .
LOADING
(1) - The text track loading state.
- track .
LOADED
(2) - The text track loaded state.
- track .
ERROR
(3) - The text track failed to load state.
- track .
- track .
track
-
Returns the
TextTrack
object corresponding to the text track of thetrack
element.
The readyState
attribute must return the
numeric value corresponding to the text track readiness state of the track
element’s text track, as defined by the following list:
NONE
(numeric value 0)- The text track not loaded state.
LOADING
(numeric value 1)- The text track loading state.
LOADED
(numeric value 2)- The text track loaded state.
ERROR
(numeric value 3)- The text track failed to load state.
The track
IDL attribute must, on getting,
return the track
element’s text track’s corresponding TextTrack
object.
The src
, srclang
, label
, and default
IDL attributes must reflect the
respective content attributes of the same name. The kind
IDL attribute must reflect the content
attribute of the same name, limited to only known values.
<video src="brave.webm"> <track kind=subtitles src=brave.en.vtt srclang=en label="English"> <track kind=captions src=brave.en.hoh.vtt srclang=en label="English for the Hard of Hearing"> <track kind=subtitles src=brave.fr.vtt srclang=fr lang=fr label="Français"> <track kind=subtitles src=brave.de.vtt srclang=de lang=de label="Deutsch"> </video>
(The lang
attributes on the last two describe the language of
the label
attribute, not the language of the subtitles
themselves. The language of the subtitles is given by the srclang
attribute.)
4.7.13. Media elements
HTMLMediaElement
objects (audio
and video
, in this specification) are simply known as media elements.
enum CanPlayTypeResult { "" /* empty string */, "maybe", "probably" };
typedef (MediaStream or MediaSource or Blob) MediaProvider;
interface HTMLMediaElement : HTMLElement { // error state readonly attribute MediaError? error; // network state attribute DOMString src; attribute MediaProvider? srcObject; readonly attribute DOMString currentSrc; attribute DOMString? crossOrigin; const unsigned short NETWORK_EMPTY = 0; const unsigned short NETWORK_IDLE = 1; const unsigned short NETWORK_LOADING = 2; const unsigned short NETWORK_NO_SOURCE = 3; readonly attribute unsigned short networkState; attribute DOMString preload; readonly attribute TimeRanges buffered; void load(); CanPlayTypeResult canPlayType(DOMString type); // ready state const unsigned short HAVE_NOTHING = 0; const unsigned short HAVE_METADATA = 1; const unsigned short HAVE_CURRENT_DATA = 2; const unsigned short HAVE_FUTURE_DATA = 3; const unsigned short HAVE_ENOUGH_DATA = 4; readonly attribute unsigned short readyState; readonly attribute boolean seeking; // playback state attribute double currentTime; void fastSeek(double time); readonly attribute unrestricted double duration; object getStartDate(); readonly attribute boolean paused; attribute double defaultPlaybackRate; attribute double playbackRate; readonly attribute TimeRanges played; readonly attribute TimeRanges seekable; readonly attribute boolean ended; attribute boolean autoplay; attribute boolean loop; void play(); void pause(); // controls attribute boolean controls; attribute double volume; attribute boolean muted; attribute boolean defaultMuted; // tracks [SameObject] readonly attribute AudioTrackList audioTracks; [SameObject] readonly attribute VideoTrackList videoTracks; [SameObject] readonly attribute TextTrackList textTracks; TextTrack addTextTrack(TextTrackKind kind, optional DOMString label = "", optional DOMString language = ""); };
The media element attributes, src
, crossorigin
, preload
, autoplay
, loop
, muted
, and controls
, apply to all media elements. They are defined in this section.
Media elements are used to present audio data, or video and audio data, to the user. This is referred to as media data in this section, since this section applies equally to media elements for audio or for video.
The term media resource is used to refer to the complete set of media data, e.g., the complete video file, or complete audio file.
A media resource can have multiple audio and video tracks. For the purposes of a media element, the video data of the media resource is only that of the
currently selected track (if any) as given by the element’s videoTracks
attribute when the event loop last
reached step 1, and the audio data of the media resource is the result of mixing all
the currently enabled tracks (if any) given by the element’s audioTracks
attribute when the event loop last
reached step 1.
Both audio
and video
elements can be used for both audio
and video. The main difference between the two is simply that the audio
element has
no playback area for visual content (such as video or captions), whereas the video
element does.
Except where otherwise explicitly specified, the task source for all the tasks queued in this section and its subsections is the media element event task source of the media element in question.
4.7.13.1. Error codes
- media .
error
-
Returns a
MediaError
object representing the current error state of the element.Returns null if there is no error.
All media elements have an associated error status, which
records the last error the element encountered since its resource selection algorithm was last invoked. The error
attribute, on getting, must return the MediaError
object created for this last error, or null if there has not been an
error.
interface MediaError { const unsigned short MEDIA_ERR_ABORTED = 1; const unsigned short MEDIA_ERR_NETWORK = 2; const unsigned short MEDIA_ERR_DECODE = 3; const unsigned short MEDIA_ERR_SRC_NOT_SUPPORTED = 4; readonly attribute unsigned short code; };
- media .
error
.code
-
Returns the current error’s error code, from the list below.
The code
attribute of a MediaError
object must return the code for the error, which must be one of the
following:
MEDIA_ERR_ABORTED
(numeric value 1)- The fetching process for the media resource was aborted by the user agent at the user’s request.
MEDIA_ERR_NETWORK
(numeric value 2)- A network error of some description caused the user agent to stop fetching the media resource, after the resource was established to be usable.
MEDIA_ERR_DECODE
(numeric value 3)- An error of some description occurred while decoding the media resource, after the resource was established to be usable.
MEDIA_ERR_SRC_NOT_SUPPORTED
(numeric value 4)- The media resource indicated by the
src
attribute or assigned media provider object was not suitable.
4.7.13.2. Location of the media resource
The src
content attribute on media elements gives the address of the media resource (video, audio) to show. The
attribute, if present, must contain a valid non-empty URL potentially surrounded by
spaces.
The crossorigin
content attribute on media elements is a CORS settings attribute.
If a media element is created with a src
attribute, the user agent must immediately invoke the media element’s resource selection
algorithm.
If a src
attribute of a media element is set
or changed, the user agent must invoke the media element’s media element load
algorithm. (Removing the src
attribute does
not do this, even if there are source
elements present.)
The src
IDL attribute on media elements must reflect the content attribute of the same
name.
The crossOrigin
IDL attribute must reflect the crossorigin
content attribute.
A media provider object is an object that can represent a media resource,
separate from a URL. MediaStream
objects, MediaSource
objects, Blob
objects, and File
objects are all media provider objects.
Each media element can have an assigned media provider object, which is a media provider object. When a media element is created, it has no assigned media provider object.
- media .
srcObject
[ = source ] - Allows the media element to be assigned a media provider object.
- media .
currentSrc
-
Returns the URL of the current media resource, if any.
Returns the empty string when there is no media resource, or it doesn’t have a URL.
The currentSrc
IDL attribute is initially
the empty string. Its value is changed by the resource
selection algorithm defined below.
The srcObject
IDL attribute, on getting,
must return the element’s assigned media provider object, if any, or null otherwise. On
setting, it must set the element’s assigned media provider object to the new value, and
then invoke the element’s media element load algorithm.
There are three ways to specify a media resource, the srcObject
IDL attribute, the src
content attribute, and source
elements. The IDL attribute takes priority, followed by the content attribute, followed by the
elements.
4.7.13.3. MIME types
A media resource can be described in terms of its type, specifically a MIME type, in some cases with a codecs
parameter. (Whether the codecs
parameter is allowed or not depends on the MIME type.) [RFC6381]
Types are usually somewhat incomplete descriptions; for example "video/mpeg
" doesn’t say anything except what the container type is, and even a
type like "video/mp4; codecs="avc1.42E01E, mp4a.40.2"
" doesn’t
include information like the actual bitrate (only the maximum bitrate). Thus, given a type, a user
agent can often only know whether it might be able to play media of that type (with
varying levels of confidence), or whether it definitely cannot play media of that
type.
A type that the user agent knows it cannot render is one that describes a resource that the user agent definitely does not support, for example because it doesn’t recognize the container type, or it doesn’t support the listed codecs.
The MIME type "application/octet-stream
" with no parameters is never a type that the user agent knows it cannot render. User agents must treat that type
as equivalent to the lack of any explicit Content-Type metadata when it is used to label a potential media resource.
Only the MIME type "application/octet-stream
" with no
parameters is special-cased here; if any parameter appears with it, it will be treated just like
any other MIME type. This is a deviation from the rule that unknown MIME type parameters should be ignored.
- media .
canPlayType
(type) -
Returns the empty string (a negative response), "maybe", or "probably" based on how confident the user agent is that it can play media resources of the given type.
The canPlayType(type)
method must return the
empty string if type is a type that the user agent knows it cannot
render or is the type "application/octet-stream
"; it must return "probably
" if the user agent is confident
that the type represents a media resource that it can render if used in with this audio
or video
element; and it must return "maybe
" otherwise. Implementors are encouraged
to return "maybe
" unless the type can be
confidently established as being supported or not. Generally, a user agent should never return
"probably
" for a type that allows the codecs
parameter if that parameter is not present.
video
element or a plugin:
<section id="video"> <p><a href="playing-cats.nfv">Download video</a></p> </section> <script> var videoSection = document.getElementById('video'); var videoElement = document.createElement('video'); var support = videoElement.canPlayType('video/x-new-fictional-format;codecs="kittens,bunnies"'); if (support != "probably" && "New Fictional Video Plugin" in navigator.plugins) { // not confident of browser support // but we have a plugin // so use plugin instead videoElement = document.createElement("embed"); } else if (support == "") { // no support from browser and no plugin // do nothing videoElement = null; } if (videoElement) { while (videoSection.hasChildNodes()) videoSection.removeChild(videoSection.firstChild); videoElement.setAttribute("src", "playing-cats.nfv"); videoSection.appendChild(videoElement); } </script>
The type
attribute of the source
element allows the user agent to avoid downloading resources that use formats
it cannot render.
4.7.13.4. Network states
- media .
networkState
- Returns the current state of network activity for the element, from the codes in the list below.
As media elements interact with the network, their current network activity is represented
by the networkState
attribute. On
getting, it must return the current network state of the element, which must be one of the
following values:
NETWORK_EMPTY
(numeric value 0)-
The element has not yet been initialized. All attributes are in their initial states.
NETWORK_IDLE
(numeric value 1)-
The element’s resource selection algorithm is active and has selected a resource, but it is not actually using the network at this time.
NETWORK_LOADING
(numeric value 2)-
The user agent is actively trying to download data.
NETWORK_NO_SOURCE
(numeric value 3)-
The element’s resource selection algorithm is active, but it has not yet found a resource to use.
The resource selection algorithm defined below describes exactly when the networkState
attribute changes value and what events fire to indicate changes
in this state.
4.7.13.5. Loading the media resource
- media .
load
() -
Causes the element to reset and start selecting and loading a new media resource from scratch.
All media elements have an autoplaying flag, which must begin in the true state, and a delaying-the-load-event flag, which must begin in the false state. While the delaying-the-load-event flag is true, the element must delay the load event of its document.
When the load()
method on a media element is invoked, the user agent must run the media element load
algorithm.
The media element load algorithm consists of the following steps.
- Abort any already-running instance of the resource selection algorithm for this element.
-
If there are any tasks from the media element’s media element event task source in one of the task queues, then remove those tasks.
Basically, pending events and callbacks for the media element are discarded when the media element starts loading a new resource.
- If the media element’s
networkState
is set toNETWORK_LOADING
orNETWORK_IDLE
, queue a task to fire a simple event namedabort
at the media element. -
If the media element’s
networkState
is not set toNETWORK_EMPTY
, then run these substeps:- Queue a task to fire a simple event named emptied at the media element.
- If a fetching process is in progress for the media element, the user agent should stop it.
- If the media element’s assigned media provider object is a
MediaSource
object, then detach it. - Forget the media element’s media-resource-specific tracks.
- If
readyState
is not set toHAVE_NOTHING
, then set it to that state. - If the
paused
attribute is false, then set it to true. - If
seeking
is true, set it to false. -
Set the current playback position to 0.
Set the official playback position to 0.
If this changed the official playback position, then queue a task to fire a simple event named
timeupdate
at the media element. - Set the initial playback position to 0.
- Set the timeline offset to Not-a-Number (NaN).
-
Update the
duration
attribute to Not-a-Number (NaN).The user agent will not fire a
durationchange
event for this particular change of the duration.
- Set the
playbackRate
attribute to the value of thedefaultPlaybackRate
attribute. - Set the
error
attribute to null and the autoplaying flag to true. - Invoke the media element’s resource selection algorithm.
-
Playback of any previously playing media resource for this element stops.
The resource selection algorithm for a media element is as follows. This algorithm is always invoked as part of a task, but one of the first steps in the algorithm is to return and continue running the remaining steps in parallel. In addition, this algorithm interacts closely with the event loop mechanism; in particular, it has synchronous sections (which are triggered as part of the event loop algorithm). Steps in such sections are marked with ⌛.
- Set the element’s
networkState
attribute to theNETWORK_NO_SOURCE
value. - Set the element’s show poster flag to true.
- Set the media element’s delaying-the-load-event flag to true (this delays the load event).
- in parallel await a stable state, allowing the task that invoked this algorithm to continue. The synchronous section consists of all the remaining steps of this algorithm until the algorithm says the synchronous section has ended. (Steps in synchronous sections are marked with ⌛.)
-
⌛ If the media element’s blocked-on-parser flag is false, then populate the list of pending text tracks.
-
⌛ If the media element has an assigned media provider object, then let mode be object.
⌛ Otherwise, if the media element has no assigned media provider object but has a
src
attribute, then let mode be attribute.⌛ Otherwise, if the media element does not have an assigned media provider object and does not have a
src
attribute, but does have asource
element child, then let mode be children and let candidate be the first suchsource
element child in tree order.⌛ Otherwise the media element has no assigned media provider object and has neither a
src
attribute nor asource
element child: set thenetworkState
toNETWORK_EMPTY
, and abort these steps; the synchronous section ends. - ⌛ Set the media element’s
networkState
toNETWORK_LOADING
. - ⌛ Queue a task to fire a simple event named
loadstart
at the media element. -
Run the appropriate steps from the following list:
- If mode is object
-
- ⌛ Set the
currentSrc
attribute to the empty string. - End the synchronous section, continuing the remaining steps in parallel.
- Run the resource fetch algorithm with the assigned media provider object. If that algorithm returns without aborting this one, then the load failed.
- Failed with media provider: Reaching this step indicates that the media resource failed to load. Queue a task to run the dedicated media source failure steps.
- Wait for the task queued by the previous step to have executed.
- Abort these steps. The element won’t attempt to load another resource until this algorithm is triggered again.
- ⌛ Set the
- If mode is attribute
-
- ⌛ If the
src
attribute’s value is the empty string, then end the synchronous section, and jump down to the failed with attribute step below. - ⌛ Let urlString and urlRecord be the resulting URL string and the resulting URL record, respectively, that would have resulted from parsing the URL specified by the
src
attribute’s value relative to the media element's node document when thesrc
attribute was last changed. - ⌛ If urlString was obtained successfully, set the
currentSrc
attribute to urlString. - End the synchronous section, continuing the remaining steps in parallel.
- If urlRecord was obtained successfully, run the resource fetch algorithm with urlRecord. If that algorithm returns without aborting this one, then the load failed.
- Failed with attribute: Reaching this step indicates that the media resource failed to load or that the given URL could not be parsed. Queue a task to run the dedicated media source failure steps.
- Wait for the task queued by the previous step to have executed.
- Abort these steps. The element won’t attempt to load another resource until this algorithm is triggered again.
- ⌛ If the
- Otherwise (mode is children)
-
-
⌛ Let pointer be a position defined by two adjacent nodes in the media element’s child list, treating the start of the list (before the first child in the list, if any) and end of the list (after the last child in the list, if any) as nodes in their own right. One node is the node before pointer, and the other node is the node after pointer. Initially, let pointer be the position between the candidate node and the next node, if there are any, or the end of the list, if it is the last node.
As nodes are inserted and removed into the media element, pointer must be updated as follows:
- If a new node is inserted between the two nodes that define pointer
- Let pointer be the point between the node before pointer and the new node. In other words, insertions at pointer go after pointer.
- If the node before pointer is removed
- Let pointer be the point between the node after pointer and the node before the node after pointer. In other words, pointer doesn’t move relative to the remaining nodes.
- If the node after pointer is removed
- Let pointer be the point between the node before pointer and the node after the node before pointer. Just as with the previous case, pointer doesn’t move relative to the remaining nodes.
Other changes don’t affect pointer.
- ⌛ Process candidate: If candidate does not have a
src
attribute, or if itssrc
attribute’s value is the empty string, then end the synchronous section, and jump down to the failed with elements step below. - ⌛ Let urlString and urlRecord be the resulting URL string and the resulting URL record, respectively, that would have resulted from parsing the URL specified by candidate’s
src
attribute’s value relative to the candidate’s node document when thesrc
attribute was last changed. - ⌛ If urlString was not obtained successfully, then end the synchronous section, and jump down to the Failed with elements step below.
- ⌛ If candidate has a
type
attribute whose value, when parsed as a MIME type (including any codecs described by thecodecs
parameter, for types that define that parameter), represents a type that the user agent knows it cannot render, then end the synchronous section, and jump down to the failed with elements step below. - ⌛ Set the
currentSrc
attribute to urlString. - End the synchronous section, continuing the remaining steps in parallel.
- Run the resource fetch algorithm with urlRecord. If that algorithm returns without aborting this one, then the load failed.
- Failed with elements: Queue a task to fire a simple
event named
error
at the candidate element. - Await a stable state. The synchronous section consists of all the remaining steps of this algorithm until the algorithm says the synchronous section has ended. (Steps in synchronous sections are marked with ⌛.)
- ⌛ Forget the media element’s media-resource-specific tracks.
- ⌛ Find next candidate: Let candidate be null.
- ⌛ Search loop: If the node after pointer is the end of the list, then jump to the waiting step below.
- ⌛ If the node after pointer is a
source
element, let candidate be that element. - ⌛ Advance pointer so that the node before pointer is now the node that was after pointer, and the node after pointer is the node after the node that used to be after pointer, if any.
- ⌛ If candidate is null, jump back to the search loop step. Otherwise, jump back to the process candidate step.
- ⌛ Waiting: Set the element’s
networkState
attribute to theNETWORK_NO_SOURCE
value. - ⌛ Set the element’s show poster flag to true.
- ⌛ Queue a task to set the element’s delaying-the-load-event flag to false. This stops delaying the load event.
- End the synchronous section, continuing the remaining steps in parallel.
- Wait until the node after pointer is a node other than the end of the list. (This step might wait forever.)
- Await a stable state. The synchronous section consists of all the remaining steps of this algorithm until the algorithm says the synchronous section has ended. (Steps in synchronous sections are marked with ⌛.)
- ⌛ Set the element’s delaying-the-load-event flag back to true (this delays the load event again, in case it hasn’t been fired yet).
- ⌛ Set the
networkState
back toNETWORK_LOADING
. - ⌛ Jump back to the find next candidate step above.
-
The dedicated media source failure steps are the following steps:
- Set the
error
attribute to a newMediaError
object whosecode
attribute is set toMEDIA_ERR_SRC_NOT_SUPPORTED
. - Forget the media element’s media-resource-specific tracks.
- Set the element’s
networkState
attribute to theNETWORK_NO_SOURCE
value. - Set the element’s show poster flag to true.
- Fire a simple event named
error
at the media element. - Set the element’s delaying-the-load-event flag to false. This stops delaying the load event.
The resource fetch algorithm for a media element and a given URL record or media provider object is as follows:
- If the algorithm was invoked with media provider object or a URL record whose object is a media provider object, then let mode be local. Otherwise let mode be remote.
- If mode is remote, then let the current media resource be the resource given by the URL record passed to this algorithm; otherwise, let the current media resource be the resource given by the media provider object. Either way, the current media resource is now the element’s media resource.
- Remove all media-resource-specific text tracks from the media element’s list of pending text tracks, if any.
-
Run the appropriate steps from the following list:
- If mode is remote
-
-
Optionally, run the following substeps. This is the expected behavior if the user agent intends to not attempt to fetch the resource until the user requests it explicitly (e.g., as a way to implement the
preload
attribute’snone
keyword).- Set the
networkState
toNETWORK_IDLE
. - Queue a task to fire a simple event named
suspend
at the element. - Queue a task to set the element’s delaying-the-load-event flag to false. This stops delaying the load event.
- Wait for the task to be run.
- Wait for an implementation-defined event (e.g., the user requesting that the media element begin playback).
- Set the element’s delaying-the-load-event flag back to true (this delays the load event again, in case it hasn’t been fired yet).
- Set the
networkState
toNETWORK_LOADING
.
- Set the
-
Let request be the result of creating a potential-CORS request given current media resource’s URL record and the media element’s
crossorigin
content attribute value.Set request’s client to the media element’s node document’s
Window
object’s environment settings object and type to "audio
" if the media element is anaudio
element and to "video
" otherwise.Fetch request.
The response’s unsafe response obtained in this fashion, if any, contains the media data. It can be CORS-same-origin or CORS-cross-origin; this affects whether subtitles referenced in the media data are exposed in the API and, for
video
elements, whether acanvas
gets tainted when the video is drawn on it.The stall timeout is a user-agent defined length of time, which should be about three seconds. When a media element that is actively attempting to obtain media data has failed to receive any data for a duration equal to the stall timeout, the user agent must queue a task to fire a simple event named
stalled
at the element.User agents may allow users to selectively block or slow media data downloads. When a media element’s download has been blocked altogether, the user agent must act as if it was stalled (as opposed to acting as if the connection was closed). The rate of the download may also be throttled automatically by the user agent, e.g., to balance the download with other connections sharing the same bandwidth.
User agents may decide to not download more content at any time, e.g., after buffering five minutes of a one hour media resource, while waiting for the user to decide whether to play the resource or not, while waiting for user input in an interactive resource, or when the user navigates away from the page. When a media element’s download has been suspended, the user agent must queue a task, to set the
networkState
toNETWORK_IDLE
and fire a simple event namedsuspend
at the element. If and when downloading of the resource resumes, the user agent must queue a task to set thenetworkState
toNETWORK_LOADING
. Between the queuing of these tasks, the load is suspended (soprogress
events don’t fire, as described above).The
preload
attribute provides a hint regarding how much buffering the author thinks is advisable, even in the absence of theautoplay
attribute.When a user agent decides to completely suspend a download, e.g., if it is waiting until the user starts playback before downloading any further content, the user agent must queue a task to set the element’s delaying-the-load-event flag to false. This stops delaying the load event.
The user agent may use whatever means necessary to fetch the resource (within the constraints put forward by this and other specifications); for example, reconnecting to the server in the face of network errors, using HTTP range retrieval requests, or switching to a streaming protocol. The user agent must consider a resource erroneous only if it has given up trying to fetch it.
To determine the format of the media resource, the user agent must use the rules for sniffing audio and video specifically.
While the load is not suspended (see below), every 350ms (±200ms) or for every byte received, whichever is least frequent, queue a task to fire a simple event named
progress
at the element.The networking task source tasks to process the data as it is being fetched must each immediately queue a task to run the first appropriate steps from the media data processing steps list below. (A new task is used for this so that the work described below occurs relative to the media element event task source rather than the networking task source.)
When the networking task source has queued the last task as part of fetching the media resource (i.e., once the download has completed), if the fetching process completes without errors, including decoding the media data, and if all of the data is available to the user agent without network access, then, the user agent must move on to the final step below. This might never happen, e.g., when streaming an infinite resource such as Web radio, or if the resource is longer than the user agent’s ability to cache data.
While the user agent might still need network access to obtain parts of the media resource, the user agent must remain on this step.
For example, if the user agent has discarded the first half of a video, the user agent will remain at this step even once the playback has ended, because there is always the chance the user will seek back to the start. In fact, in this situation, once playback has ended, the user agent will end up firing a
suspend
event, as described earlier.
-
- Otherwise (mode is local)
-
The resource described by the current media resource, if any, contains the media data. It is CORS-same-origin.
If the current media resource is a raw data stream (e.g., from a
File
object), then to determine the format of the media resource, the user agent must use the rules for sniffing audio and video specifically. Otherwise, if the data stream is pre-decoded, then the format is the format given by the relevant specification.Whenever new data for the current media resource becomes available, queue a task to run the first appropriate steps from the media data processing steps list below.
When the current media resource is permanently exhausted (e.g., all the bytes of a
Blob
have been processed), if there were no decoding errors, then the user agent must move on to the final step below. This might never happen, e.g., if the current media resource is aMediaStream
.
The media data processing steps list is as follows:
- If the media data cannot be fetched at all, due to network errors, causing the user agent to give up trying to fetch the resource
- If the media data can be fetched but is found by inspection to be in an unsupported format, or can otherwise not be rendered at all
-
DNS errors, HTTP 4xx and 5xx errors (and equivalents in other protocols), and other fatal network errors that occur before the user agent has established whether the current media resource is usable, as well as the file using an unsupported container format, or using unsupported codecs for all the data, must cause the user agent to execute the following steps:
- The user agent should cancel the fetching process.
- Abort this subalgorithm, returning to the resource selection algorithm.
- If the media resource is found to have an audio track
-
- Create an
AudioTrack
object to represent the audio track. - Update the media element’s
audioTracks
attribute’sAudioTrackList
object with the newAudioTrack
object. - Let enable be unknown.
-
If either the media resource or the address of the current media resource indicate a particular set of audio tracks to enable, or if the user agent has information that would facilitate the selection of specific audio tracks to improve the user’s experience, then: if this audio track is one of the ones to enable, then set enable to true, otherwise, set enable to false.
This could be triggered by Media Fragments URI fragment identifier syntax, but it could also be triggered e.g., by the user agent selecting a 5.1 surround sound audio track over a stereo audio track. [MEDIA-FRAGS]
- If enable is still unknown, then, if the media element does not yet have an enabled audio track, then set enable to true, otherwise, set enable to false.
- If enable is true, then enable this audio track, otherwise, do not enable this audio track.
- Fire a trusted event with the name
addtrack
, that does not bubble and is not cancelable, and that uses theTrackEvent
interface, with thetrack
attribute initialized to the newAudioTrack
object, at thisAudioTrackList
object.
- Create an
- If the media resource is found to have a video track
-
- Create a
VideoTrack
object to represent the video track. - Update the media element’s
videoTracks
attribute’sVideoTrackList
object with the newVideoTrack
object. - Let enable be unknown.
-
If either the media resource or the address of the current media resource indicate a particular set of video tracks to enable, or if the user agent has information that would facilitate the selection of specific video tracks to improve the user’s experience, then: if this video track is the first such video track, then set enable to true, otherwise, set enable to false.
- If enable is still unknown, then, if the media element does not yet have a selected video track, then set enable to true, otherwise, set enable to false.
- If enable is true, then select this track and unselect any
previously selected video tracks, otherwise, do not select this video track. If other tracks
are unselected, then a
change
event will be fired. - Fire a trusted event with the name
addtrack
, that does not bubble and is not cancelable, and that uses theTrackEvent
interface, with thetrack
attribute initialized to the newVideoTrack
object, at thisVideoTrackList
object.
- Create a
- Once enough of the media data has been fetched to determine the duration of the media resource, its dimensions, and other metadata
-
This indicates that the resource is usable. The user agent must follow these substeps:
-
Establish the media timeline for the purposes of the current playback position and the earliest possible position, based on the media data.
-
Update the timeline offset to the date and time that corresponds to the zero time in the media timeline established in the previous step, if any. If no explicit time and date is given by the media resource, the timeline offset must be set to Not-a-Number (NaN).
- Set the current playback position and the official playback position to the earliest possible position.
-
Update the
duration
attribute with the time of the last frame of the resource, if known, on the media timeline established above. If it is not known (e.g., a stream that is in principle infinite), update theduration
attribute to the value positive Infinity.The user agent will queue a task to fire a simple event named
durationchange
at the element at this point. -
For
video
elements, set thevideoWidth
andvideoHeight
attributes, and queue a task to fire a simple event namedresize
at the media element.Further
resize
events will be fired if the dimensions subsequently change. -
Set the
readyState
attribute toHAVE_METADATA
.A
loadedmetadata
DOM event will be fired as part of setting thereadyState
attribute to a new value. - Let jumped be false.
- If the media element’s default playback start position is greater than zero, then seek to that time, and let jumped be true.
- Let the media element’s default playback start position be zero.
- Let the initial playback position be zero.
-
If either the media resource or the address of the current media resource indicate a particular start time, then set the initial playback position to that time and, if jumped is still false, seek to that time and let jumped be true.
For example, with media formats that support the media fragment syntax the fragment, can be used to indicate a start position. [MEDIA-FRAGS]
- If there is no enabled audio track, then
enable an audio track. This will cause a
change
event to be fired. - If there is no selected video track,
then select a video track. This will cause a
change
event to be fired.
Once the
readyState
attribute reachesHAVE_CURRENT_DATA
, after theloadeddata
event has been fired, set the element’s delaying-the-load-event flag to false. This stops delaying the load event.A user agent that is attempting to reduce network usage while still fetching the metadata for each media resource would also stop buffering at this point, following the rules described previously, which involve the
networkState
attribute switching to theNETWORK_IDLE
value and asuspend
event firing.The user agent is required to determine the duration of the media resource and go through this step before playing.
-
- Once the entire media resource has been fetched (but potentially before any of it has been decoded)
-
Fire a simple event named
progress
at the media element.Set the
networkState
toNETWORK_IDLE
and fire a simple event namedsuspend
at the media element.If the user agent ever discards any media data and then needs to resume the network activity to obtain it again, then it must queue a task to set the
networkState
toNETWORK_LOADING
.If the user agent can keep the media resource loaded, then the algorithm will continue to its final step below, which aborts the algorithm.
- If the connection is interrupted after some media data has been received, causing the user agent to give up trying to fetch the resource
-
Fatal network errors that occur after the user agent has established whether the current media resource is usable (i.e., once the media element’s
readyState
attribute is no longerHAVE_NOTHING
) must cause the user agent to execute the following steps:- The user agent should cancel the fetching process.
- Set the
error
attribute to a newMediaError
object whosecode
attribute is set toMEDIA_ERR_NETWORK
. - Set the element’s
networkState
attribute to theNETWORK_IDLE
value. - Set the element’s delaying-the-load-event flag to false. This stops delaying the load event.
- Fire a simple event named
error
at the media element. - Abort the overall resource selection algorithm.
- If the media data is corrupted
-
Fatal errors in decoding the media data that occur after the user agent has established whether the current media resource is usable (i.e., once the media element’s
readyState
attribute is no longerHAVE_NOTHING
) must cause the user agent to execute the following steps:- The user agent should cancel the fetching process.
- Set the
error
attribute to a newMediaError
object whosecode
attribute is set toMEDIA_ERR_DECODE
. - Set the element’s
networkState
attribute to theNETWORK_IDLE
value. - Set the element’s delaying-the-load-event flag to false. This stops delaying the load event.
- Fire a simple event named
error
at the media element. - Abort the overall resource selection algorithm.
- If the media data fetching process is aborted by the user
-
The fetching process is aborted by the user, e.g., because the user pressed a "stop" button, the user agent must execute the following steps. These steps are not followed if the
load()
method itself is invoked while these steps are running, as the steps above handle that particular kind of abort.- The user agent should cancel the fetching process.
- Set the
error
attribute to a newMediaError
object whosecode
attribute is set toMEDIA_ERR_ABORTED
. - Fire a simple event named
abort
at the media element. -
If the media element’s
readyState
attribute has a value equal toHAVE_NOTHING
, set the element’snetworkState
attribute to theNETWORK_EMPTY
value, set the element’s show poster flag to true, and fire a simple event named emptied at the element.Otherwise, set the element’s
networkState
attribute to theNETWORK_IDLE
value. - Set the element’s delaying-the-load-event flag to false. This stops delaying the load event.
- Abort the overall resource selection algorithm.
- If the media data can be fetched but has non-fatal errors or uses, in part, codecs that are unsupported, preventing the user agent from rendering the content completely correctly but not preventing playback altogether
-
The server returning data that is partially usable but cannot be optimally rendered must cause the user agent to render just the bits it can handle, and ignore the rest.
- If the media resource is found to declare a media-resource-specific text track that the user agent supports
-
If the media data is CORS-same-origin, run the steps to expose a media-resource-specific text track with the relevant data.
Cross-origin videos do not expose their subtitles, since that would allow attacks such as hostile sites reading subtitles from confidential videos on a user’s intranet.
- Final step: If the user agent ever reaches this step (which can only happen if the entire resource gets loaded and kept available): abort the overall resource selection algorithm.
When a media element is to forget the media element’s media-resource-specific
tracks, the user agent must remove from the media element’s list of text
tracks all the media-resource-specific
text tracks, then empty the media element’s audioTracks
attribute’s AudioTrackList
object,
then empty the media element’s videoTracks
attribute’s VideoTrackList
object. No events (in particular, no removetrack
events) are fired as part of this; the error
and emptied events, fired by the algorithms that invoke this one, can be used instead.
The preload
attribute is an enumerated
attribute. The following table lists the keywords and states for the attribute — the
keywords in the left column map to the states in the cell in the second column on the same row as
the keyword. The attribute can be changed even once the media resource is being
buffered or played; the descriptions in the table below are to be interpreted with that in
mind.
Keyword | State | Brief description |
---|---|---|
none
| None | Hints to the user agent that either the author does not expect the user to need the media resource, or that the server wants to minimize unnecessary traffic. This state does not provide a hint regarding how aggressively to actually download the media resource if buffering starts anyway (e.g., once the user hits "play"). |
metadata
| Metadata | Hints to the user agent that the author does not expect the user to need the media resource, but that fetching the resource metadata (dimensions, track list, duration, etc), and maybe even the first few frames, is reasonable. If the user agent precisely fetches no more than the metadata, then the media element will end up with its readyState attribute set to HAVE_METADATA ; typically though, some frames will be obtained as well and it will probably be HAVE_CURRENT_DATA or HAVE_FUTURE_DATA .
When the media resource is playing, hints to the user agent that bandwidth is to be considered scarce, e.g., suggesting throttling the download so that the media data is obtained at the slowest possible rate that still maintains consistent playback.
|
auto
| Automatic | Hints to the user agent that the user agent can put the user’s needs first without risk to the server, up to and including optimistically downloading the entire resource. |
The empty string is also a valid keyword, and maps to the Automatic state. The attribute’s missing value default is user-agent defined, though the Metadata state is suggested as a compromise between reducing server load and providing an optimal user experience.
Authors might switch the attribute from "none
" or "metadata
" to "auto
" dynamically once the user begins playback. For
example, on a page with many videos this might be used to indicate that the many videos are not to
be downloaded unless requested, but that once one is requested it is to be downloaded
aggressively.
The preload
attribute is intended to provide a hint to
the user agent about what the author thinks will lead to the best user experience. The attribute
may be ignored altogether, for example based on explicit user preferences or based on the
available connectivity.
The preload
IDL attribute must reflect the content attribute of the same name, limited to only known
values.
The autoplay
attribute can override the preload
attribute (since if the media plays, it naturally
has to buffer first, regardless of the hint given by the preload
attribute). Including both is not an error, however.
- media .
buffered
-
Returns a
TimeRanges
object that represents the ranges of the media resource that the user agent has buffered.
The buffered
attribute must return a new
static normalized TimeRanges
object that represents the ranges of the media resource, if any, that the user agent has buffered, at the time the attribute
is evaluated. Users agents must accurately determine the ranges available, even for media streams
where this can only be determined by tedious inspection.
Typically this will be a single range anchored at the zero point, but if, e.g., the user agent uses HTTP range requests in response to seeking, then there could be multiple ranges.
User agents may discard previously buffered data.
Thus, a time position included within a range of the objects return by the buffered
attribute at one time can end up being not included in
the range(s) of objects returned by the same attribute at later times.
4.7.13.6. Offsets into the media resource
- media .
duration
-
Returns the length of the media resource, in seconds, assuming that the start of the media resource is at time zero.
Returns NaN if the duration isn’t available.
Returns Infinity for unbounded streams.
- media .
currentTime
[ = value ] -
Returns the official playback position, in seconds.
Can be set, to seek to the given time.
A media resource has a media timeline that maps times (in seconds) to positions in the media resource. The origin of a timeline is its earliest defined position. The duration of a timeline is its last defined position.
Establishing the media timeline: If the media resource somehow specifies an explicit timeline whose
origin is not negative (i.e., gives each frame a specific time offset and gives the first frame a
zero or positive offset), then the media timeline should be that timeline. (Whether
the media resource can specify a timeline or not depends on the media resource’s format.) If the media resource specifies an
explicit start time and date, then that time and date should be considered the zero point
in the media timeline; the timeline offset will be the time and date,
exposed using the getStartDate()
method.
If the media resource has a discontinuous timeline, the user agent must extend the timeline used at the start of the resource across the entire resource, so that the media timeline of the media resource increases linearly starting from the earliest possible position (as defined below), even if the underlying media data has out-of-order or even overlapping time codes.
For example, if two clips have been concatenated into one video file, but the video format exposes the original times for the two clips, the video data might expose a timeline that goes, say, 00:15..00:29 and then 00:05..00:38. However, the user agent would not expose those times; it would instead expose the times as 00:15..00:29 and 00:29..01:02, as a single video.
In the rare case of a media resource that does not have an explicit timeline, the zero time on the media timeline should correspond to the first frame of the media resource. In the even rarer case of a media resource with no explicit timings of any kind, not even frame durations, the user agent must itself determine the time for each frame in a user-agent-defined manner.
An example of a file format with no explicit timeline but with explicit frame
durations is the Animated GIF format. An example of a file format with no explicit timings at all
is the JPEG-push format (multipart/x-mixed-replace
with JPEG frames, often
used as the format for MJPEG streams).
If, in the case of a resource with no timing information, the user agent will nonetheless be able to seek to an earlier point than the first frame originally provided by the server, then the zero time should correspond to the earliest seekable time of the media resource; otherwise, it should correspond to the first frame received from the server (the point in the media resource at which the user agent began receiving the stream).
At the time of writing, there is no known format that lacks explicit frame time offsets yet still supports seeking to a frame before the first frame sent by the server.
getStartDate()
method would always return the date that the
broadcast started; this would allow controllers to display real times in their scrubber (e.g.,
"2:30pm") rather than a time relative to when the broadcast began ("8 months, 4 hours, 12
minutes, and 23 seconds").
Consider a stream that carries a video with several concatenated fragments, broadcast by a
server that does not allow user agents to request specific times but instead just streams the
video data in a predetermined order, with the first frame delivered always being identified as
the frame with time zero. If a user agent connects to this stream and receives fragments defined
as covering timestamps 2010-03-20 23:15:00 UTC to 2010-03-21 00:05:00 UTC and 2010-02-12 14:25:00
UTC to 2010-02-12 14:35:00 UTC, it would expose this with a media timeline starting
at 0s and extending to 3,600s (one hour). Assuming the streaming server disconnected at the end
of the second clip, the duration
attribute would then
return 3,600. The getStartDate()
method would return a Date
object with a time corresponding to 2010-03-20 23:15:00 UTC. However, if a
different user agent connected five minutes later, it would (presumably) receive
fragments covering timestamps 2010-03-20 23:20:00 UTC to 2010-03-21 00:05:00 UTC and 2010-02-12
14:25:00 UTC to 2010-02-12 14:35:00 UTC, and would expose this with a media timeline starting at 0s and extending to 3,300s (fifty five minutes). In this case, the getStartDate()
method would return a Date
object
with a time corresponding to 2010-03-20 23:20:00 UTC.
In both of these examples, the seekable
attribute
would give the ranges that the controller would want to actually display in its UI; typically, if
the servers don’t support seeking to arbitrary times, this would be the range of time from the
moment the user agent connected to the stream up to the latest frame that the user agent has
obtained; however, if the user agent starts discarding earlier information, the actual range
might be shorter.
In any case, the user agent must ensure that the earliest possible position (as defined below) using the established media timeline, is greater than or equal to zero.
The media timeline also has an associated clock. Which clock is used is user-agent defined, and may be media resource-dependent, but it should approximate the user’s wall clock.
Media elements have a current playback position, which must initially (i.e., in the absence of media data) be zero seconds. The current playback position is a time on the media timeline.
Media elements also have an official playback position, which must initially be set to zero seconds. The official playback position is an approximation of the current playback position that is kept stable while scripts are running.
Media elements also have a default playback start position, which must initially be set to zero seconds. This time is used to allow the element to be seeked even before the media is loaded.
Each media element has a show poster flag. When a media element is created, this flag must be set to true. This flag is used to control when the
user agent is to show a poster frame for a video
element instead of showing the video
contents.
The currentTime
attribute must, on
getting, return the media element’s default playback start position,
unless that is zero, in which case it must return the element’s official playback
position. The returned value must be expressed in seconds. On setting, if the media element’s readyState
is HAVE_NOTHING
,
then it must set the media element’s default playback start position to the new value; otherwise, it must
set the official playback position to the new value and then seek to the new value. The new value must be interpreted as being in
seconds.
Media elements have an initial playback position, which must initially (i.e., in the absence of media data) be zero seconds. The initial playback position is updated when a media resource is loaded. The initial playback position is a time on the media timeline.
If the media resource is a streaming resource, then the user agent might be unable to obtain certain parts of the resource after it has expired from its buffer. Similarly, some media resources might have a media timeline that doesn’t start at zero. The earliest possible position is the earliest position in the stream or resource that the user agent can ever obtain again. It is also a time on the media timeline.
The earliest possible position is not explicitly exposed in the API;
it corresponds to the start time of the first range in the seekable
attribute’s TimeRanges
object, if any, or
the current playback position otherwise.
When the earliest possible position changes, then: if the current playback
position is before the earliest possible position, the user agent must seek to the earliest possible position; otherwise, if
the user agent has not fired a timeupdate
event at the
element in the past 15 to 250ms and is not still running event handlers for such an event, then
the user agent must queue a task to fire a simple event named timeupdate
at the element.
Because of the above requirement and the requirement in the resource fetch algorithm that kicks in when the metadata of the clip becomes known, the current playback position can never be less than the earliest possible position.
If at any time the user agent learns that an audio or video track has ended and all media
data relating to that track corresponds to parts of the media timeline that
are before the earliest possible position, the user agent may queue a
task to first remove the track from the audioTracks
attribute’s AudioTrackList
object or the videoTracks
attribute’s VideoTrackList
object as
appropriate and then fire a trusted event with the name removetrack
, that does not bubble and is not cancelable, and that
uses the TrackEvent
interface, with the track
attribute initialized to the AudioTrack
or VideoTrack
object representing the track, at the media element’s
aforementioned AudioTrackList
or VideoTrackList
object.
The duration
attribute must return the time
of the end of the media resource, in seconds, on the media timeline. If
no media data is available, then the attributes must return the Not-a-Number (NaN)
value. If the media resource is not known to be bounded (e.g., streaming radio, or a
live event with no announced end time), then the attribute must return the positive Infinity
value.
The user agent must determine the duration of the media resource before playing
any part of the media data and before setting readyState
to a value equal to or greater than HAVE_METADATA
, even if doing so requires fetching multiple
parts of the resource.
When the length of the media resource changes to a known value (e.g., from being unknown to known, or from a previously established length to a new length) the user agent must queue a task to fire a simple event named durationchange at the media element. (The event is not fired when the duration is reset as part of loading a new media resource.) If the duration is changed such that the current playback position ends up being greater than the time of the end of the media resource, then the user agent must also seek to the time of the end of the media resource.
If an "infinite" stream ends for some reason, then the duration would change
from positive Infinity to the time of the last frame or sample in the stream, and the durationchange
event would be fired. Similarly, if the
user agent initially estimated the media resource’s duration instead of determining
it precisely, and later revises the estimate based on new information, then the duration would
change and the durationchange
event would be
fired.
Some video files also have an explicit date and time corresponding to the zero time in the media timeline, known as the timeline offset. Initially, the timeline offset must be set to Not-a-Number (NaN).
The getStartDate()
method must return a new Date
object representing the current timeline offset.
The loop
attribute is a boolean
attribute that, if specified, indicates that the media element is to seek back
to the start of the media resource upon reaching the end.
The loop
IDL attribute must reflect the content attribute of the same name.
4.7.13.7. Ready states
- media .
readyState
-
Returns a value that expresses the current state of the element with respect to rendering the current playback position, from the codes in the list below.
Media elements have a ready state, which describes to what degree they are ready to be rendered at the current playback position. The possible values are as follows; the ready state of a media element at any particular time is the greatest value describing the state of the element:
HAVE_NOTHING
(numeric value 0)- No information regarding the media resource is available. No data for the current playback position is available. Media elements whose
networkState
attribute are set toNETWORK_EMPTY
are always in theHAVE_NOTHING
state. HAVE_METADATA
(numeric value 1)- Enough of the resource has been obtained that the duration of the resource is available.
In the case of a
video
element, the dimensions of the video are also available. No media data is available for the immediate current playback position. HAVE_CURRENT_DATA
(numeric value 2)- Data for the immediate current playback position is available, but either not
enough data is available that the user agent could successfully advance the current
playback position in the direction of playback at all without immediately
reverting to the
HAVE_METADATA
state, or there is no more data to obtain in the direction of playback. For example, in video this corresponds to the user agent having data from the current frame, but not the next frame, when the current playback position is at the end of the current frame; and to when playback has ended. HAVE_FUTURE_DATA
(numeric value 3)- Data for the immediate current playback position is available, as well as
enough data for the user agent to advance the current playback position in the direction of playback at least a little without immediately reverting to the
HAVE_METADATA
state, and the text tracks are ready. For example, in video this corresponds to the user agent having data for at least the current frame and the next frame when the current playback position is at the instant in time between the two frames, or to the user agent having the video data for the current frame and audio data to keep playing at least a little when the current playback position is in the middle of a frame. The user agent cannot be in this state if playback has ended, as the current playback position can never advance in this case. HAVE_ENOUGH_DATA
(numeric value 4)-
All the conditions described for the
HAVE_FUTURE_DATA
state are met, and, in addition, either of the following conditions is also true:- The user agent estimates that data is being fetched at a rate where the current playback position, if it were to advance at the effective playback rate, would not overtake the available data before playback reaches the end of the media resource.
- The user agent has entered a state where waiting longer will not result in further data being obtained, and therefore nothing would be gained by delaying playback any further. (For example, the buffer might be full.)
In practice, the difference between HAVE_METADATA
and HAVE_CURRENT_DATA
is negligible. Really the only time
the difference is relevant is when painting a video
element onto a canvas
, where it distinguishes the case where something will be drawn (HAVE_CURRENT_DATA
or greater) from the case where
nothing is drawn (HAVE_METADATA
or less). Similarly,
the difference between HAVE_CURRENT_DATA
(only
the current frame) and HAVE_FUTURE_DATA
(at least
this frame and the next) can be negligible (in the extreme, only one frame). The only time that
distinction really matters is when a page provides an interface for "frame-by-frame"
navigation.
When the ready state of a media element whose networkState
is not NETWORK_EMPTY
changes, the user agent must follow the steps
given below:
-
Apply the first applicable set of substeps from the following list:
- If the previous ready state was
HAVE_NOTHING
, and the new ready state isHAVE_METADATA
-
Queue a task to fire a simple event named
loadedmetadata
at the element.Before this task is run, as part of the event loop mechanism, the rendering will have been updated to resize the
video
element if appropriate. - If the previous ready state was
HAVE_METADATA
and the new ready state isHAVE_CURRENT_DATA
or greater -
If this is the first time this occurs for this media element since the
load()
algorithm was last invoked, the user agent must queue a task to fire a simple event namedloadeddata
at the element.If the new ready state is
HAVE_FUTURE_DATA
orHAVE_ENOUGH_DATA
, then the relevant steps below must then be run also. - If the previous ready state was
HAVE_FUTURE_DATA
or more, and the new ready state isHAVE_CURRENT_DATA
or less -
If the media element was potentially playing before its
readyState
attribute changed to a value lower thanHAVE_FUTURE_DATA
, and the element has not ended playback, and playback has not stopped due to errors, paused for user interaction, or paused for in-band content, the user agent must queue a task to fire a simple event namedtimeupdate
at the element, and queue a task to fire a simple event namedwaiting
at the element. - If the previous ready state was
HAVE_CURRENT_DATA
or less, and the new ready state isHAVE_FUTURE_DATA
-
The user agent must queue a task to fire a simple event named
canplay
at the element.If the element’s
paused
attribute is false, the user agent must queue a task to fire a simple event namedplaying
at the element. - If the new ready state is
HAVE_ENOUGH_DATA
-
If the previous ready state was
HAVE_CURRENT_DATA
or less, the user agent must queue a task to fire a simple event namedcanplay
at the element, and, if the element’spaused
attribute is false, queue a task to fire a simple event namedplaying
at the element.If the autoplaying flag is true, and the
paused
attribute is true, and the media element has anautoplay
attribute specified, and the media element’s node document’s active sandboxing flag set does not have the sandboxed automatic features browsing context flag set, then the user agent may also run the following substeps:- Set the
paused
attribute to false. - If the element’s show poster flag is true, set it to false and run the time marches on steps.
- Queue a task to fire a simple event named
play
at the element. - Queue a task to fire a simple event named
playing
at the element. - Set the autoplaying flag to false.
User agents do not need to support autoplay, and it is suggested that user agents honor user preferences on the matter. Authors are urged to use the
autoplay
attribute rather than using script to force the video to play, so as to allow the user to override the behavior if so desired.In any case, the user agent must finally queue a task to fire a simple event named
canplaythrough
at the element. - Set the
- If the previous ready state was
It is possible for the ready state of a media element to jump between these states
discontinuously. For example, the state of a media element can jump straight from HAVE_METADATA
to HAVE_ENOUGH_DATA
without passing through the HAVE_CURRENT_DATA
and HAVE_FUTURE_DATA
states.
The readyState
IDL attribute must, on
getting, return the value described above that describes the current ready state of the media element.
The autoplay
attribute is a boolean
attribute. When present, the user agent (as described in the algorithm
described herein) will automatically begin playback of the media resource as
soon as it can do so without stopping.
Authors are urged to use the autoplay
attribute rather than using script to trigger automatic playback, as this allows the user to
override the automatic playback when it is not desired, e.g., when using a screen reader. Authors
are also encouraged to consider not using the automatic playback behavior at all, and instead to
let the user agent wait for the user to start playback explicitly.
The autoplay
IDL attribute must reflect the content attribute of the same name.
4.7.13.8. Playing the media resource
- media .
paused
-
Returns true if playback is paused; false otherwise.
- media .
ended
-
Returns true if playback has reached the end of the media resource.
- media .
defaultPlaybackRate
[ = value ] -
Returns the default rate of playback, for when the user is not fast-forwarding or reversing through the media resource.
Can be set, to change the default rate of playback.
The default rate has no direct effect on playback, but if the user switches to a fast-forward mode, when they return to the normal playback mode, it is expected that the rate of playback will be returned to the default rate of playback.
- media .
playbackRate
[ = value ] -
Returns the current rate playback, where 1.0 is normal speed.
Can be set, to change the rate of playback.
- media .
played
-
Returns a
TimeRanges
object that represents the ranges of the media resource that the user agent has played. - media .
play()
-
Sets the
paused
attribute to false, loading the media resource and beginning playback if necessary. If the playback had ended, will restart it from the start. - media .
pause
() -
Sets the
paused
attribute to true, loading the media resource if necessary.
The paused
attribute represents whether
the media element is paused or not. The attribute must initially be true.
A media element is a blocked media element if its readyState
attribute is in the HAVE_NOTHING
state, the HAVE_METADATA
state, or the HAVE_CURRENT_DATA
state, or if the element has paused for user interaction or paused for in-band content.
A media element is said to be potentially playing when its paused
attribute is false, the element has not ended playback,
playback has not stopped due to errors, and the element is not a blocked media element.
A waiting
DOM event can be fired as a result of an element that is potentially playing stopping playback due to its readyState
attribute changing to a value lower than HAVE_FUTURE_DATA
.
A media element is said to have ended playback when:
- The element’s
readyState
attribute isHAVE_METADATA
or greater, and -
Either:
- The current playback position is the end of the media resource, and
- The direction of playback is forwards, and
- The media element does not have a
loop
attribute specified.
Or:
- The current playback position is the earliest possible position, and
- The direction of playback is backwards.
The ended
attribute must return true if,
the last time the event loop reached step 1, the media element had ended playback and the direction of playback was forwards, and false otherwise.
A media element is said to have stopped due to errors when the
element’s readyState
attribute is HAVE_METADATA
or greater, and the user agent encounters a non-fatal error during the processing of the media data, and due to that error, is not able to play the content at the current playback position.
A media element is said to have paused for user interaction when its paused
attribute is false, the readyState
attribute is
either HAVE_FUTURE_DATA
or HAVE_ENOUGH_DATA
and the user agent has
reached a point in the media resource where the user has to make a selection for the
resource to continue.
It is possible for a media element to have both ended playback and paused for user interaction at the same time.
When a media element that is potentially playing stops playing
because it has paused for user interaction, the user agent must queue a
task to fire a simple event named timeupdate
at the element.
A media element is said to have paused for in-band content when its paused
attribute is false, the readyState
attribute is
either HAVE_FUTURE_DATA
or HAVE_ENOUGH_DATA
and the user agent has
suspended playback of the media resource in order to play content that is temporally
anchored to the media resource and has a non-zero length, or to play content that is
temporally anchored to a segment of the media resource but has a length longer than
that segment.
One example of when a media element would be paused for in-band content is when the user agent is playing audio descriptions from an external WebVTT file, and the synthesized speech generated for a cue is longer than the time between the text track cue start time and the text track cue end time.
When the current playback position reaches the end of the media resource when the direction of playback is forwards, then the user agent must follow these steps:
- If the media element has a
loop
attribute specified, then seek to the earliest possible position of the media resource and abort these steps. - As defined above, the
ended
IDL attribute starts returning true once the event loop returns to step 1. - Queue a task to fire a simple event named
timeupdate
at the media element. - Queue a task that, if the media element has still ended playback, and
the direction of playback is still forwards, and
paused
is false, changespaused
to true and fires a simple event namedpause
at the media element. - Queue a task to fire a simple event named
ended
at the media element.
When the current playback position reaches the earliest possible
position of the media resource when the direction of playback is
backwards, then the user agent must only queue a task to fire a simple
event named timeupdate
at the element.
The word "reaches" here does not imply that the current playback position needs to have changed during normal playback; it could be via seeking, for instance.
The defaultPlaybackRate
attribute
gives the desired speed at which the media resource is to play, as a multiple of its
intrinsic speed. The attribute is mutable: on getting it must return the last value it was set to,
or 1.0 if it hasn’t yet been set; on setting the attribute must be set to the new value.
The defaultPlaybackRate
is used by the user agent when it exposes a user interface to the user.
The playbackRate
attribute gives the effective playback rate which is the speed at which the media resource plays, as a
multiple of its intrinsic speed. If it is not equal to the defaultPlaybackRate
, then the implication is that the user is using a feature
such as fast forward or slow motion playback. The attribute is mutable: on getting it must return
the last value it was set to, or 1.0 if it hasn’t yet been set; on setting the attribute must be
set to the new value, and the playback will change speed (if the element is potentially playing).
When the defaultPlaybackRate
or playbackRate
attributes
change value (either by being set by script or by being changed directly by the user agent, e.g.,
in response to user control) the user agent must queue a task to fire a simple event named ratechange
at the media element.
The played
attribute must return a new
static normalized TimeRanges
object that represents the ranges of points on
the media timeline of the media resource reached through the usual monotonic
increase of the current playback position during normal playback, if any, at the time
the attribute is evaluated.
When the play()
method on a media element is invoked, the user agent must run the following steps.
- If the media element’s
networkState
attribute has the valueNETWORK_EMPTY
, invoke the media element’s resource selection algorithm. -
If the playback has ended and the direction of playback is forwards, seek to the earliest possible position of the media resource.
This will cause the user agent to queue a task to fire a simple event named
timeupdate
at the media element. -
If the media element’s
paused
attribute is true, run the following substeps:- Change the value of
paused
to false. - If the show poster flag is true, set the element’s show poster flag to false and run the time marches on steps.
- Queue a task to fire a simple event named
play
at the element. -
If the media element’s
readyState
attribute has the valueHAVE_NOTHING
,HAVE_METADATA
, orHAVE_CURRENT_DATA
, queue a task to fire a simple event namedwaiting
at the element.Otherwise, the media element’s
readyState
attribute has the valueHAVE_FUTURE_DATA
orHAVE_ENOUGH_DATA
: queue a task to fire a simple event namedplaying
at the element.
- Change the value of
- Set the media element’s autoplaying flag to false.
When the pause()
method is invoked, and when
the user agent is required to pause the media element, the user agent must run the
following steps:
- If the media element’s
networkState
attribute has the valueNETWORK_EMPTY
, invoke the media element’s resource selection algorithm. - Run the internal pause steps for the media element.
The internal pause steps for a media element are as follows:
- Set the media element’s autoplaying flag to false.
-
If the media element’s
paused
attribute is false, run the following steps:- Change the value of
paused
to true. - Queue a task to fire a simple
event named
timeupdate
at the element. - Queue a task to fire a simple
event named
pause
at the element. - Set the official playback position to the current playback position.
- Change the value of
The effective playback rate is just the element’s playbackRate
.
If the effective playback rate is positive or zero, then the direction of playback is forwards. Otherwise, it is backwards.
When a media element is potentially playing and
its Document
is a fully active Document
, its current
playback position must increase monotonically at effective playback rate units
of media time per unit time of the media timeline’s clock. (This specification always
refers to this as an increase, but that increase could actually be a decrease if
the effective playback rate is negative.)
The effective playback rate can be 0.0, in which case the current playback position doesn’t move, despite playback not being paused
(paused
doesn’t become true, and the pause
event doesn’t fire).
This specification doesn’t define how the user agent achieves the appropriate playback rate — depending on the protocol and media available, it is plausible that the user agent could negotiate with the server to have the server provide the media data at the appropriate rate, so that (except for the period between when the rate is changed and when the server updates the stream’s playback rate) the client doesn’t actually have to drop or interpolate any frames.
Any time the user agent provides a stable state, the official playback position must be set to the current playback position.
While the direction of playback is backwards, any corresponding audio must be muted. While the effective playback rate is so low or so high that the user agent cannot play audio usefully, the corresponding audio must also be muted. If the effective playback rate is not 1.0, the user agent may apply pitch adjustments to the audio as necessary to render it faithfully.
Media elements that are potentially playing while not in a Document
must not play any video, but should play any
audio component. Media elements must not stop playing just because all references to them have
been removed; only once a media element is in a state where no further audio could ever be played
by that element may the element be garbage collected.
It is possible for an element to which no explicit references exist to play audio, even if such an element is not still actively playing: for instance, a media element whose media resource has no audio tracks could eventually play audio again if it had an event listener that changes the media resource.
Each media element has a list of newly introduced cues, which must be initially empty. Whenever a text track cue is added to the list of cues of a text track that is in the list of text tracks for a media element, that cue must be added to the media element’s list of newly introduced cues. Whenever a text track is added to the list of text tracks for a media element, all of the cues in that text track’s list of cues must be added to the media element’s list of newly introduced cues. When a media element’s list of newly introduced cues has new cues added while the media element’s show poster flag is not set, then the user agent must run the time marches on steps.
When a text track cue is removed from the list of cues of a text track that is in the list of text tracks for a media element, and whenever a text track is removed from the list of text tracks of a media element, if the media element’s show poster flag is not set, then the user agent must run the time marches on steps.
When the current playback position of a media element changes (e.g., due to playback or seeking), the user agent must run the time marches on steps. If the current playback position changes while the steps are running, then the user agent must wait for the steps to complete, and then must immediately rerun the steps. (These steps are thus run as often as possible or needed — if one iteration takes a long time, this can cause certain cues to be skipped over as the user agent rushes ahead to "catch up".)
The time marches on steps are as follows:
- Let current cues be a list of cues, initialized to contain all the cues of all the or showing text tracks of the media element (not the disabled ones) whose start times are less than or equal to the current playback position and whose end times are greater than the current playback position.
- Let other cues be a list of cues, initialized to contain all the cues of and showing text tracks of the media element that are not present in current cues.
- Let last time be the current playback position at the time this algorithm was last run for this media element, if this is not the first time it has run.
- If the current playback position has, since the last time this algorithm was run, only changed through its usual monotonic increase during normal playback, then let missed cues be the list of cues in other cues whose start times are greater than or equal to last time and whose end times are less than or equal to the current playback position. Otherwise, let missed cues be an empty list.
- Remove all the cues in missed cues that are also in the media element’s list of newly introduced cues, and then empty the element’s list of newly introduced cues.
-
If the time was reached through the usual monotonic increase of the current playback
position during normal playback, and if the user agent has not fired a
timeupdate
event at the element in the past 15 to 250ms and is not still running event handlers for such an event, then the user agent must queue a task to fire a simple event namedtimeupdate
at the element. (In the other cases, such as explicit seeks, relevant events get fired as part of the overall process of changing the current playback position.)The event thus is not to be fired faster than about 66Hz or slower than 4Hz (assuming the event handlers don’t take longer than 250ms to run). User agents are encouraged to vary the frequency of the event based on the system load and the average cost of processing the event each time, so that the UI updates are not any more frequent than the user agent can comfortably handle while decoding the video.
- If all of the cues in current cues have their text track cue active flag set, none of the cues in other cues have their text track cue active flag set, and missed cues is empty, then abort these steps.
-
If the time was reached through the usual monotonic increase of the current playback position during normal playback, and there are cues in other cues that have their text track cue pause-on-exit flag set and that either have their text track cue active flag set or are also in missed cues, then immediately pause the media element.
In the other cases, such as explicit seeks, playback is not paused by going past the end time of a cue, even if that cue has its text track cue pause-on-exit flag set.
-
Let events be a list of tasks, initially empty. Each task in this list will be associated with a text track, a text track cue, and a time, which are used to sort the list before the tasks are queued.
Let affected tracks be a list of text tracks, initially empty.
When the steps below say to prepare an event named event for a text track cue target with a time time, the user agent must run these substeps:
- Let track be the text track with which the text track cue target is associated.
- Create a task to fire a simple event named event at target.
- Add the newly created task to events, associated with the time time, the text track track, and the text track cue target.
- Add track to affected tracks.
- For each text track cue in missed
cues, prepare an event named
enter
for theTextTrackCue
object with the text track cue start time. - For each text track cue in other
cues that either has its text track cue active flag set or is in missed cues, prepare an event named
exit
for theTextTrackCue
object with the later of the text track cue end time and the text track cue start time. - For each text track cue in current
cues that does not have its text track cue active flag set, prepare an
event named
enter
for theTextTrackCue
object with the text track cue start time. -
Sort the tasks in events in ascending time order (tasks with earlier times first).
Further sort tasks in events that have the same time by the relative text track cue order of the text track cues associated with these tasks.
Finally, sort tasks in events that have the same time and same text track cue order by placing tasks that fire
enter
events before those that fireexit
events. - Queue each task in events, in list order.
- Sort affected tracks in the same order as the text tracks appear in the media element’s list of text tracks, and remove duplicates.
- For each text track in affected tracks, in the list
order, queue a task to fire a simple event named
cuechange
at theTextTrack
object, and, if the text track has a correspondingtrack
element, to then fire a simple event namedcuechange
at thetrack
element as well. - Set the text track cue active flag of all the cues in the current cues, and unset the text track cue active flag of all the cues in the other cues.
- Run the rules for updating the text track rendering of each of the text tracks in affected tracks that are showing, providing the text track’s text track language as the fallback language if it is not the empty string. For example, for text tracks based on WebVTT, the rules for updating the display of WebVTT text tracks. [WEBVTT]
For the purposes of the algorithm above, a text track cue is considered to be part of a text track only if it is listed in the text track list of cues, not merely if it is associated with the text track.
If the media element’s node document stops being a fully active document, then the playback will stop until the document is active again.
When a media element is removed
from a Document
, the user agent must run the following steps:
- Await a stable state, allowing the task that removed the media element from the
Document
to continue. The synchronous section consists of all the remaining steps of this algorithm. (Steps in the synchronous section are marked with ⌛.) - ⌛ If the media element is in a
Document
, abort these steps. - ⌛ Run the internal pause steps for the media element.
4.7.13.9. Seeking
- media .
seeking
-
Returns true if the user agent is currently seeking.
- media .
seekable
-
Returns a
TimeRanges
object that represents the ranges of the media resource to which it is possible for the user agent to seek. - media .
fastSeek
( time ) -
Seeks to near the given time as fast as possible, trading precision for speed. (To seek to a precise time, use the
currentTime
attribute.)This does nothing if the media resource has not been loaded.
The seeking
attribute must initially have the
value false.
The fastSeek()
method must seek to the time given by the method’s argument, with the approximate-for-speed flag set.
When the user agent is required to seek to a particular new playback position in the media resource, optionally with the approximate-for-speed flag set, it means that the user agent must run the following steps. This algorithm interacts closely with the event loop mechanism; in particular, it has a synchronous section (which is triggered as part of the event loop algorithm). Steps in that section are marked with ⌛.
- Set the media element’s show poster flag to false.
- If the media element’s
readyState
isHAVE_NOTHING
, abort these steps. - If the element’s
seeking
IDL attribute is true, then another instance of this algorithm is already running. Abort that other instance of the algorithm without waiting for the step that it is running to complete. - Set the
seeking
IDL attribute to true. - If the seek was in response to a DOM method call or setting of an IDL attribute, then continue the script. The remainder of these steps must be run in parallel. With the exception of the steps marked with ⌛, they could be aborted at any time by another instance of this algorithm being invoked.
- If the new playback position is later than the end of the media resource, then let it be the end of the media resource instead.
- If the new playback position is less than the earliest possible position, let it be that position instead.
- If the (possibly now changed) new playback position is not in one of
the ranges given in the
seekable
attribute, then let it be the position in one of the ranges given in theseekable
attribute that is the nearest to the new playback position. If two positions both satisfy that constraint (i.e., the new playback position is exactly in the middle between two ranges in theseekable
attribute) then use the position that is closest to the current playback position. If there are no ranges given in theseekable
attribute then set theseeking
IDL attribute to false and abort these steps. -
If the approximate-for-speed flag is set, adjust the new playback position to a value that will allow for playback to resume promptly. If new playback position before this step is before current playback position, then the adjusted new playback position must also be before the current playback position. Similarly, if the new playback position before this step is after current playback position, then the adjusted new playback position must also be after the current playback position.
For example, the user agent could snap to a nearby key frame, so that it doesn’t have to spend time decoding then discarding intermediate frames before resuming playback.
- Queue a task to fire a simple event named
seeking
at the element. -
Set the current playback position to the new playback position.
If the media element was potentially playing immediately before it started seeking, but seeking caused its
readyState
attribute to change to a value lower thanHAVE_FUTURE_DATA
, then awaiting
event will be fired at the element.This step sets the current playback position, and thus can immediately trigger other conditions, such as the rules regarding when playback "reaches the end of the media resource" (part of the logic that handles looping), even before the user agent is actually able to render the media data for that position (as determined in the next step).
The
currentTime
attribute returns the official playback position, not the current playback position, and therefore gets updated before script execution, separate from this algorithm. - Wait until the user agent has established whether or not the media data for the new playback position is available, and, if it is, until it has decoded enough data to play back that position.
- Await a stable state. The synchronous section consists of all the remaining steps of this algorithm. (Steps in the synchronous section are marked with ⌛.)
- ⌛ Set the
seeking
IDL attribute to false. - ⌛ Run the time marches on steps.
- ⌛ Queue a task to fire a simple event named
timeupdate
at the element. - ⌛ Queue a task to fire a simple event named
seeked
at the element.
The seekable
attribute must return a new
static normalized TimeRanges
object that represents the ranges of the media resource, if any, that the user agent is able to seek to, at the time the
attribute is evaluated.
If the user agent can seek to anywhere in the media resource, e.g.,
because it is a simple movie file and the user agent and the server support HTTP Range requests,
then the attribute would return an object with one range, whose start is the time of the first
frame (the earliest possible position, typically zero), and whose end is the same as
the time of the first frame plus the duration
attribute’s
value (which would equal the time of the last frame, and might be positive Infinity).
The range might be continuously changing, e.g., if the user agent is buffering a sliding window on an infinite stream. This is the behavior seen with DVRs viewing live TV, for instance.
User agents should adopt a very liberal and optimistic view of what is seekable. User agents should also buffer recent content where possible to enable seeking to be fast.
For instance, consider a large video file served on an HTTP server without support for HTTP Range requests. A browser could implement this by only buffering the current frame and data obtained for subsequent frames, never allow seeking, except for seeking to the very start by restarting the playback. However, this would be a poor implementation. A high quality implementation would buffer the last few minutes of content (or more, if sufficient storage space is available), allowing the user to jump back and rewatch something surprizing without any latency, and would in addition allow arbitrary seeking by reloading the file from the start if necessary, which would be slower but still more convenient than having to literally restart the video and watch it all the way through just to get to an earlier unbuffered spot.
Media resources might be internally scripted or interactive. Thus, a media element could play in a non-linear fashion. If this happens, the user agent must act as if the algorithm for seeking was used whenever the current playback position changes in a discontinuous fashion (so that the relevant events fire).
4.7.13.10. Media resources with multiple media tracks
A media resource can have multiple embedded audio and video tracks. For example, in addition to the primary video and audio tracks, a media resource could have foreign-language dubbed dialogs, director’s commentaries, audio descriptions, alternative angles, or sign-language overlays.
- media .
audioTracks
-
Returns an
AudioTrackList
object representing the audio tracks available in the media resource. - media .
videoTracks
-
Returns a
VideoTrackList
object representing the video tracks available in the media resource.
The audioTracks
attribute of a media element must return a live AudioTrackList
object
representing the audio tracks available in the media element’s media
resource.
The videoTracks
attribute of a media element must return a live VideoTrackList
object
representing the video tracks available in the media element’s media
resource.
There are only ever one AudioTrackList
object and one VideoTrackList
object per media element, even if another media
resource is loaded into the element: the objects are reused. (The AudioTrack
and VideoTrack
objects are not, though.)
<script> function loadVideo(url, container) { var video = document.createElement('video'); video.src = url; video.autoplay = true; video.controls = true; container.appendChild(video); video.onloadedmetadata = function (event) { for (var i = 0; i < video.videoTracks.length; i += 1) { if (video.videoTracks[i].kind == 'sign') { var sign = document.createElement('video'); sign.src = url + '#track=' + video.videoTracks[i].id; sign.autoplay = true; container.appendChild(sign); return; } } }; } </script>
4.7.13.10.1. AudioTrackList
and VideoTrackList
objects
The AudioTrackList
and VideoTrackList
interfaces are used by
attributes defined in the previous section.
interface AudioTrackList : EventTarget { readonly attribute unsigned long length; getter AudioTrack (unsigned long index); AudioTrack? getTrackById(DOMString id); attribute EventHandler onchange; attribute EventHandler onaddtrack; attribute EventHandler onremovetrack; };
interface AudioTrack { readonly attribute DOMString id; readonly attribute DOMString kind; readonly attribute DOMString label; readonly attribute DOMString language; attribute boolean enabled; };
interface VideoTrackList : EventTarget { readonly attribute unsigned long length; getter VideoTrack (unsigned long index); VideoTrack? getTrackById(DOMString id); readonly attribute long selectedIndex; attribute EventHandler onchange; attribute EventHandler onaddtrack; attribute EventHandler onremovetrack; };
interface VideoTrack { readonly attribute DOMString id; readonly attribute DOMString kind; readonly attribute DOMString label; readonly attribute DOMString language; attribute boolean selected; };
- media .
audioTracks
.length
- media .
videoTracks
.length
-
Returns the number of tracks in the list.
- audioTrack = media .
audioTracks
[index] - videoTrack = media .
videoTracks
[index] -
Returns the specified
AudioTrack
orVideoTrack
object. - audioTrack = media .
audioTracks
.getTrackById
( id ) - videoTrack = media .
videoTracks
.getTrackById
( id ) -
Returns the
AudioTrack
orVideoTrack
object with the given identifier, or null if no track has that identifier. - audioTrack .
id
- videoTrack .
id
-
Returns the ID of the given track. This is the ID that can be used with a fragment if the format supports the media fragments syntax, and that can be used with the
getTrackById()
method. [MEDIA-FRAGS] - audioTrack .
kind
- videoTrack .
kind
-
Returns the category the given track falls into. The possible track categories are given below.
- audioTrack .
label
- videoTrack .
label
-
Returns the label of the given track, if known, or the empty string otherwise.
- audioTrack .
language
- videoTrack .
language
-
Returns the language of the given track, if known, or the empty string otherwise.
- audioTrack .
enabled
[ = value ] -
Returns true if the given track is active, and false otherwise.
Can be set, to change whether the track is enabled or not. If multiple audio tracks are enabled simultaneously, they are mixed.
- media .
videoTracks
.selectedIndex
-
Returns the index of the currently selected track, if any, or -1 otherwise.
- videoTrack .
selected
[ = value ] -
Returns true if the given track is active, and false otherwise.
Can be set, to change whether the track is selected or not. Either zero or one video track is selected; selecting a new track while a previous one is selected will unselect the previous one.
An AudioTrackList
object represents a dynamic list of zero or more audio tracks,
of which zero or more can be enabled at a time. Each audio track is represented by an AudioTrack
object.
A VideoTrackList
object represents a dynamic list of zero or more video tracks, of
which zero or one can be selected at a time. Each video track is represented by a VideoTrack
object.
Tracks in AudioTrackList
and VideoTrackList
objects must be
consistently ordered. If the media resource is in a format that defines an order,
then that order must be used; otherwise, the order must be the relative order in which the tracks
are declared in the media resource. The order used is called the natural order of the list.
Each track in one of these objects thus has an index; the first has the index 0, and each subsequent track is numbered one higher than the previous one. If a media resource dynamically adds or removes audio or video tracks, then the indices of the tracks will change dynamically. If the media resource changes entirely, then all the previous tracks will be removed and replaced with new tracks.
The AudioTrackList.length
and VideoTrackList.length
attributes must return the number of tracks represented by their objects at the time of getting.
The supported property indices of AudioTrackList
and VideoTrackList
objects at any instant are the numbers from zero to the number of
tracks represented by the respective object minus one, if any tracks are represented. If an AudioTrackList
or VideoTrackList
object represents no tracks, it has no supported property indices.
To determine the value of an indexed property for a given index index in an AudioTrackList
or VideoTrackList
object list, the user agent must return the AudioTrack
or VideoTrack
object that represents the indexth track in list.
The AudioTrackList.getTrackById(id)
and VideoTrackList.getTrackById(id)
methods must return the first AudioTrack
or VideoTrack
object (respectively) in the AudioTrackList
or VideoTrackList
object (respectively) whose identifier is equal to the
value of the id argument (in the natural order of the list, as defined above). When no
tracks match the given argument, the methods must return null.
The AudioTrack
and VideoTrack
objects represent specific tracks of a media resource. Each track can have an identifier, category, label, and language.
These aspects of a track are permanent for the lifetime of the track; even if a track is removed
from a media resource’s AudioTrackList
or VideoTrackList
objects, those aspects do not change.
In addition, AudioTrack
objects can each be enabled or disabled; this is the audio
track’s enabled state. When an AudioTrack
is created, its enabled state must be set to false (disabled). The resource fetch
algorithm can override this.
Similarly, a single VideoTrack
object per VideoTrackList
object can
be selected, this is the video track’s selection state. When a VideoTrack
is
created, its selection state must be set to false (not selected). The resource fetch algorithm can override this.
The AudioTrack.id
and VideoTrack.id
attributes must return
the identifier of the track, if it has one, or the empty string otherwise. If the media resource is in a format that supports the Media Fragments URI fragment
identifier syntax, the identifier returned for a particular track must be the same identifier that
would enable the track if used as the name of a track in the track dimension of such a fragment
identifier. [MEDIA-FRAGS] [INBANDTRACKS]
For example, in Ogg files, this would be the Name header field of the track. [OGGSKELETON]
The AudioTrack.kind
and VideoTrack.kind
attributes must
return the category of the track, if it has one, or the empty string otherwise.
The category of a track is the string given in the first column of the table below that is the
most appropriate for the track based on the definitions in the table’s second and third columns,
as determined by the metadata included in the track in the media resource. The cell
in the third column of a row says what the category given in the cell in the first column of that
row applies to; a category is only appropriate for an audio track if it applies to audio tracks,
and a category is only appropriate for video tracks if it applies to video tracks. Categories must
only be returned for AudioTrack
objects if they are appropriate for audio, and must
only be returned for VideoTrack
objects if they are appropriate for video.
The AudioTrack.label
and VideoTrack.label
attributes must
return the label of the track, if it has one, or the empty string otherwise. [INBANDTRACKS]
The AudioTrack.language
and VideoTrack.language
attributes
must return the BCP 47 language tag of the language of the track, if it has one, or the empty
string otherwise. If the user agent is not able to express that language as a BCP 47 language tag
(for example because the language information in the media resource’s format is a free-form
string without a defined interpretation), then the method must return the empty string, as if the
track had no language.
Source attribute values for id, kind, label and language of multitrack audio and video tracks as described for the relevant media resource format. [INBANDTRACKS]
The AudioTrack.enabled
attribute,
on getting, must return true if the track is currently enabled, and false otherwise. On setting,
it must enable the track if the new value is true, and disable it otherwise. (If the track is no
longer in an AudioTrackList
object, then the track being enabled or disabled has no
effect beyond changing the value of the attribute on the AudioTrack
object.)
Whenever an audio track in an AudioTrackList
that was
disabled is enabled, and whenever one that was enabled is disabled, the user agent must queue a task to fire a simple event named change
at the AudioTrackList
object.
An audio track that has no data for a particular position on the media timeline, or that does not exist at that position, must be interpreted as being silent at that point on the timeline.
The VideoTrackList.selectedIndex
attribute must return the index of the currently selected track, if any. If the VideoTrackList
object does not currently represent any tracks, or if none of the tracks are selected, it must
instead return -1.
The VideoTrack.selected
attribute, on getting, must return true if the track is currently selected, and false otherwise.
On setting, it must select the track if the new value is true, and unselect it otherwise. If the
track is in a VideoTrackList
, then all the other VideoTrack
objects in that list must
be unselected. (If the track is no longer in a VideoTrackList
object, then the track
being selected or unselected has no effect beyond changing the value of the attribute on the VideoTrack
object.)
Whenever a track in a VideoTrackList
that was previously
not selected is selected, and whenever the selected track in a VideoTrackList
is
unselected without a new track being selected in its stead, the user agent must queue a task to fire a simple
event named change
at the VideoTrackList
object. This task must be queued before the task that fires
the resize
event, if any.
A video track that has no data for a particular position on the media timeline must be interpreted as being fully transparent black at that point on the timeline, with the same dimensions as the last frame before that position, or, if the position is before all the data for that track, the same dimensions as the first frame for that track. A track that does not exist at all at the current position must be treated as if it existed but had no data.
For instance, if a video has a track that is only introduced after one hour of playback, and the user selects that track then goes back to the start, then the user agent will act as if that track started at the start of the media resource but was simply transparent until one hour in.
The following are the event handlers (and their corresponding event handler event types) that must be supported, as event handler IDL attributes,
by all objects implementing the AudioTrackList
and VideoTrackList
interfaces:
Event handler | Event handler event type |
---|---|
onchange
| change
|
onaddtrack
| addtrack
|
onremovetrack
| removetrack
|
4.7.13.10.2. Selecting specific audio and video tracks declaratively
The audioTracks
and videoTracks
attributes allow scripts to select which track
should play, but it is also possible to select specific tracks declaratively, by specifying
particular tracks in the fragment of the URL of the media
resource. The format of the fragment depends on the MIME type of
the media resource. [RFC2046] [URL]
<video src="myvideo#track=Alternative"></video>
4.7.13.11. Timed text tracks
4.7.13.11.1. Text track model
A media element can have a group of associated text tracks, known as the media element’s list of text tracks. The text tracks are sorted as follows:
- The text tracks corresponding to
track
element children of the media element, in tree order. - Any text tracks added using the
addTextTrack()
method, in the order they were added, oldest first. - Any media-resource-specific text tracks (text tracks corresponding to data in the media resource), in the order defined by the media resource’s format specification.
A text track consists of:
- The kind of text track
-
This decides how the track is handled by the user agent. The kind is represented by a string. The possible strings are:
subtitles
captions
descriptions
chapters
metadata
The kind of track can change dynamically, in the case of a text track corresponding to a
track
element. - A label
-
This is a human-readable string intended to identify the track for the user.
The label of a track can change dynamically, in the case of a text track corresponding to a
track
element.When a text track label is the empty string, the user agent should automatically generate an appropriate label from the text track’s other properties (e.g., the kind of text track and the text track’s language) for use in its user interface. This automatically-generated label is not exposed in the API.
- An in-band metadata track dispatch type
-
This is a string extracted from the media resource specifically for in-band metadata tracks to enable such tracks to be dispatched to different scripts in the document.
For example, a traditional TV station broadcast streamed on the Web and augmented with Web-specific interactive features could include text tracks with metadata for ad targeting, trivia game data during game shows, player states during sports games, recipe information during food programs, and so forth. As each program starts and ends, new tracks might be added or removed from the stream, and as each one is added, the user agent could bind them to dedicated script modules using the value of this attribute.
Other than for in-band metadata text tracks, the in-band metadata track dispatch type is the empty string. How this value is populated for different media formats is described in steps to expose a media-resource-specific text track.
- A language
-
This is a string (a BCP 47 language tag) representing the language of the text track’s cues. [BCP47]
The language of a text track can change dynamically, in the case of a text track corresponding to a
track
element. - A readiness state
-
One of the following:
- Not loaded
-
Indicates that the text track’s cues have not been obtained.
- Loading
-
Indicates that the text track is loading and there have been no fatal errors encountered so far. Further cues might still be added to the track by the parser.
- Loaded
-
Indicates that the text track has been loaded with no fatal errors.
- Failed to load
-
Indicates that the text track was enabled, but when the user agent attempted to obtain it, this failed in some way (e.g., URL could not be parsed, network error, unknown text track format). Some or all of the cues are likely missing and will not be obtained.
The readiness state of a text track changes dynamically as the track is obtained.
- A mode
-
One of the following:
- Disabled
-
Indicates that the text track is not active. Other than for the purposes of exposing the track in the DOM, the user agent is ignoring the text track. No cues are active, no events are fired, and the user agent will not attempt to obtain the track’s cues.
- Hidden
-
Indicates that the text track is active, but that the user agent is not actively displaying the cues. If no attempt has yet been made to obtain the track’s cues, the user agent will perform such an attempt momentarily. The user agent is maintaining a list of which cues are active, and events are being fired accordingly.
- Showing
-
Indicates that the text track is active. If no attempt has yet been made to obtain the track’s cues, the user agent will perform such an attempt momentarily. The user agent is maintaining a list of which cues are active, and events are being fired accordingly. In addition, for text tracks whose kind is
subtitles
orcaptions
, the cues are being overlaid on the video as appropriate; for text tracks whose kind isdescriptions
, the user agent is making the cues available to the user in a non-visual fashion; and for text tracks whose kind ischapters
, the user agent is making available to the user a mechanism by which the user can navigate to any point in the media resource by selecting a cue.
- A list of zero or more cues
-
A list of text track cues, along with rules for updating the text track rendering. For example, for WebVTT, the rules for updating the display of WebVTT text tracks. [WEBVTT]
The list of cues of a text track can change dynamically, either because the text track has not yet been loaded or is still loading, or due to DOM manipulation.
Each text track has a corresponding TextTrack
object.
Each media element has a list of pending text tracks, which must initially be empty, a blocked-on-parser flag, which must initially be false, and a did-perform-automatic-track-selection flag, which must also initially be false.
When the user agent is required to populate the list of pending text tracks of a media element, the user agent must add to the element’s list of pending text tracks each text track in the element’s list of text tracks whose text track mode is not disabled and whose text track readiness state is loading.
Whenever a track
element’s parent node changes, the user agent must remove the
corresponding text track from any list of pending text tracks that it is
in.
Whenever a text track’s text track readiness state changes to either loaded or failed to load, the user agent must remove it from any list of pending text tracks that it is in.
When a media element is created by an HTML parser or XML parser, the user agent must set the element’s blocked-on-parser flag to true. When a media element is popped off the stack of open elements of an HTML parser or XML parser, the user agent must honor user preferences for automatic text track selection, populate the list of pending text tracks, and set the element’s blocked-on-parser flag to false.
The text tracks of a media element are ready when both the element’s list of pending text tracks is empty and the element’s blocked-on-parser flag is false.
Each media element has a pending text track change notification flag, which must initially be unset.
Whenever a text track that is in a media element’s list of text tracks has its text track mode change value, the user agent must run the following steps for the media element:
- If the media element’s pending text track change notification flag is set, abort these steps.
- Set the media element’s pending text track change notification flag.
-
Queue a task that runs the following substeps:
- Unset the media element’s pending text track change notification flag.
- Fire a simple event named
change
at the media element’stextTracks
attribute’sTextTrackList
object.
- If the media element’s show poster flag is not set, run the time marches on steps.
The task source for the tasks listed in this section is the DOM manipulation task source.
A text track cue is the unit of time-sensitive data in a text track, corresponding for instance for subtitles and captions to the text that appears at a particular time and disappears at another time.
Each text track cue consists of:
- An identifier
- An arbitrary string.
- A start time
- The time, in seconds and fractions of a second, that describes the beginning of the range of the media data to which the cue applies.
- An end time
- The time, in seconds and fractions of a second, that describes the end of the range of the media data to which the cue applies.
- A pause-on-exit flag
- A boolean indicating whether playback of the media resource is to pause when the end of the range to which the cue applies is reached.
- Some additional format-specific data
- Additional fields, as needed for the format. For example, WebVTT has a text track cue writing direction and so forth. [WEBVTT]
- Rules for extracting the chapter title
- An algorithm which, when applied to the cue, returns a string that can be used in user interfaces that use the cue as a chapter title.
The text track cue start time and text track cue end time can be negative. (The current playback position can never be negative, though, so cues entirely before time zero cannot be active.)
Each text track cue has a corresponding TextTrackCue
object (or more
specifically, an object that inherits from TextTrackCue
— for example, WebVTT
cues use the VTTCue
interface). A text track cue’s in-memory
representation can be dynamically changed through this TextTrackCue
API. [WEBVTT]
A text track cue is associated with rules for updating the text track
rendering, as defined by the specification for the specific kind of text track
cue. These rules are used specifically when the object representing the cue is added to a TextTrack
object using the addCue()
method.
In addition, each text track cue has two pieces of dynamic information:
- The active flag
-
This flag must be initially unset. The flag is used to ensure events are fired appropriately when the cue becomes active or inactive, and to make sure the right cues are rendered.
The user agent must immediately unset this flag whenever the text track cue is removed from its text track’s text track list of cues; whenever the text track itself is removed from its media element’s list of text tracks or has its text track mode changed to disabled; and whenever the media element’s
readyState
is changed back toHAVE_NOTHING
. When the flag is unset in this way for one or more cues in text tracks that were showing prior to the relevant incident, the user agent must, after having unset the flag for all the affected cues, apply the rules for updating the text track rendering of those text tracks. For example, for text tracks based on WebVTT, the rules for updating the display of WebVTT text tracks. [WEBVTT] - The display state
-
This is used as part of the rendering model, to keep cues in a consistent position. It must initially be empty. Whenever the text track cue active flag is unset, the user agent must empty the text track cue display state.
The text track cues of a media element’s text tracks are ordered relative to each other in the text track cue order, which is determined as follows: first group the cues by their text track, with the groups being sorted in the same order as their text tracks appear in the media element’s list of text tracks; then, within each group, cues must be sorted by their start time, earliest first; then, any cues with the same start time must be sorted by their end time, latest first; and finally, any cues with identical end times must be sorted in the order they were last added to their respective text track list of cues, oldest first (so e.g., for cues from a WebVTT file, that would initially be the order in which the cues were listed in the file). [WEBVTT]
4.7.13.11.2. Sourcing in-band text tracks
A media-resource-specific text track is a text track that corresponds to data found in the media resource.
Rules for processing and rendering such data are defined by the relevant specifications, e.g., the specification of the video format if the media resource is a video. Details for some legacy formats can be found in the Sourcing In-band Media Resource Tracks from Media Containers into HTML specification. [INBANDTRACKS]
When a media resource contains data that the user agent recognizes and supports as being equivalent to a text track, the user agent runs the steps to expose a media-resource-specific text track with the relevant data, as follows.
- Associate the relevant data with a new text track and its corresponding new
TextTrack
object. The text track is a media-resource-specific text track. - Set the new text track’s kind, label, and language based on the semantics of the relevant data, as defined for the relevant format [INBANDTRACKS]. If there is no label in that data, then the label must be set to the empty string.
- Associate the text track list of cues with the rules for updating the text track rendering appropriate for the format in question.
-
If the new text track’s kind is
metadata
, then set the text track in-band metadata track dispatch type as follows, based on the type of the media resource:- If the media resource is an Ogg file
- The text track in-band metadata track dispatch type must be set to the value of the Role header field. [OGGSKELETON]
- If the media resource is a WebM file
- The text track in-band metadata track dispatch type must be set to the value
of the
CodecID
element. [WEBM] - If the media resource is an MPEG-2 file
- Let stream type be the value of the "stream_type" field describing the text track’s type in the file’s program map section, interpreted as an 8-bit unsigned integer. Let length be the value of the "ES_info_length" field for the track in the same part of the program map section, interpreted as an integer as defined by the MPEG-2 specification. Let descriptor bytes be the length bytes following the "ES_info_length" field. The text track in-band metadata track dispatch type must be set to the concatenation of the stream type byte and the zero or more descriptor bytes bytes, expressed in hexadecimal using uppercase ASCII hex digits. [MPEG2TS]
- If the media resource is an MPEG-4 file
-
Let the
first
stsd
box of the firststbl
box of the firstminf
box of the firstmdia
box of the text track’strak
box in the firstmoov
box of the file be the stsd box, if any.If the file has no stsd box, or if the stsd box has neither a
mett
box nor ametx
box, then the text track in-band metadata track dispatch type must be set to the empty string.Otherwise, if the stsd box has a
mett
box then the text track in-band metadata track dispatch type must be set to the concatenation of the string "mett
", a U+0020 SPACE character, and the value of the firstmime_format
field of the firstmett
box of the stsd box, or the empty string if that field is absent in that box.Otherwise, if the stsd box has no
mett
box but has ametx
box then the text track in-band metadata track dispatch type must be set to the concatenation of the string "metx
", a U+0020 SPACE character, and the value of the firstnamespace
field of the firstmetx
box of the stsd box, or the empty string if that field is absent in that box. - If the media resource is a DASH media resource
- The text track in-band metadata track dispatch type must be set to the concatenation of the "AdaptationSet" element attributes and all child Role descriptors. [MPEGDASH]
- Populate the new text track’s list of cues with the cues parsed so far, following the guidelines for exposing cues, and begin updating it dynamically as necessary.
- Set the new text track’s readiness state to loaded.
-
Set the new text track’s mode to the
mode consistent with the user’s preferences and the requirements of the relevant specification
for the data.
For instance, if there are no other active subtitles, and this is a forced subtitle track (a subtitle track giving subtitles in the audio track’s primary language, but only for audio that is actually in another language), then those subtitles might be activated here.
- Add the new text track to the media element’s list of text tracks.
- Fire a trusted event with the name
addtrack
, that does not bubble and is not cancelable, and that uses theTrackEvent
interface, with thetrack
attribute initialized to the text track’sTextTrack
object, at the media element’stextTracks
attribute’sTextTrackList
object.
4.7.13.11.3. Sourcing out-of-band text tracks
When a track
element is created, it must be associated with a new text
track (with its value set as defined below) and its corresponding new TextTrack
object.
The text track kind is determined from the state of the element’s kind
attribute according to the following table; for a state given
in a cell of the first column, the kind is the string given
in the second column:
State | String |
---|---|
Subtitles | subtitles
|
Captions | captions
|
Descriptions | descriptions
|
Chapters | chapters
|
Metadata | metadata
|
The text track label is the element’s track label.
The text track language is the element’s track language, if any, or the empty string otherwise.
As the kind
, label
,
and srclang
attributes are set, changed, or removed, the text track must update accordingly, as per the definitions above.
Changes to the track URL are handled in the algorithm below.
The text track readiness state is initially not loaded, and the text track mode is initially disabled.
The text track list of cues is initially empty. It is dynamically modified when the referenced file is parsed. Associated with the list are the rules for updating the text track rendering appropriate for the format in question; for WebVTT, this is the rules for updating the display of WebVTT text tracks. [WEBVTT]
When a track
element’s parent element changes and the new parent is a media element, then the user agent must add the track
element’s corresponding text track to the media element’s list of text tracks, and
then queue a task to fire a trusted event with the name addtrack
, that does not bubble and is not cancelable, and that uses
the TrackEvent
interface, with the track
attribute initialized to the text track’s TextTrack
object, at the media element’s textTracks
attribute’s TextTrackList
object.
When a track
element’s parent element changes and the old parent was a media element, then the user agent must remove the track
element’s corresponding text track from the media element’s list of text tracks,
and then queue a task to fire a trusted event with the name removetrack
, that does not bubble and is not cancelable, and that
uses the TrackEvent
interface, with the track
attribute initialized to the text track’s TextTrack
object, at the media element’s textTracks
attribute’s TextTrackList
object.
When a text track corresponding to a track
element is added to a media element’s list of text tracks, the user agent must queue a
task to run the following steps for the media element:
- If the element’s blocked-on-parser flag is true, abort these steps.
- If the element’s did-perform-automatic-track-selection flag is true, abort these steps.
- Honor user preferences for automatic text track selection for this element.
When the user agent is required to honor user preferences for automatic text track selection for a media element, the user agent must run the following steps:
- Perform automatic text track selection for
subtitles
andcaptions
. - Perform automatic text track selection for
descriptions
. - Perform automatic text track selection for
chapters
. - If there are any text tracks in the media element’s list of text tracks whose text track kind is
metadata
that correspond totrack
elements with adefault
attribute set whose text track mode is set to disabled, then set the text track mode of all such tracks to - Set the element’s did-perform-automatic-track-selection flag to true.
When the steps above say to perform automatic text track selection for one or more text track kinds, it means to run the following steps:
- Let candidates be a list consisting of the text tracks in the media element’s list of text tracks whose text track kind is one of the kinds that were passed to the algorithm, if any, in the order given in the list of text tracks.
- If candidates is empty, then abort these steps.
- If any of the text tracks in candidates have a text track mode set to showing, abort these steps.
-
If the user has expressed an interest in having a track from candidates enabled based on its text track kind, text track language, and text track label, then set its text track mode to showing.
For example, the user could have set a browser preference to the effect of "I want French captions whenever possible", or "If there is a subtitle track with "Commentary" in the title, enable it", or "If there are audio description tracks available, enable one, ideally in Swiss German, but failing that in Standard Swiss German or Standard German".
Otherwise, if there are any text tracks in candidates that correspond to
track
elements with adefault
attribute set whose text track mode is set to disabled, then set the text track mode of the first such track to showing.
When a text track corresponding to a track
element experiences any of
the following circumstances, the user agent must start the track
processing
model for that text track and its track
element:
- The
track
element is created. - The text track has its text track mode changed.
- The
track
element’s parent element changes and the new parent is a media element.
When a user agent is to start the track
processing model for a text track and its track
element, it must run the following algorithm.
This algorithm interacts closely with the event loop mechanism; in particular, it has
a synchronous section (which is triggered as part of the event loop algorithm). The steps in that section are marked with ⌛.
- If another occurrence of this algorithm is already running for this text
track and its
track
element, abort these steps, letting that other algorithm take care of this element. - If the text track’s text track mode is not set to one of or showing, abort these steps.
- If the text track’s
track
element does not have a media element as a parent, abort these steps. - Run the remainder of these steps in parallel, allowing whatever caused these steps to run to continue.
- Top: Await a stable state. The synchronous section consists of the following steps. (The steps in the synchronous section are marked with ⌛.)
- ⌛ Set the text track readiness state to loading.
- ⌛ Let URL be the track URL of the
track
element. - ⌛ If the
track
element’s parent is a media element then let corsAttributeState be the state of the parent media element’scrossorigin
content attribute. Otherwise, let corsAttributeState be No CORS. - End the synchronous section, continuing the remaining steps in parallel.
-
If URL is not the empty string, run these substeps:
- Let request be the result of creating a potential-CORS request given URL, corsAttributeState, and with the same-origin fallback flag set.
- Set request’s client to the
track
element’s node document’sWindow
object’s environment settings object and type to "track
". - Fetch request.
The tasks queued by the fetching algorithm on the networking task source to process the data as it is being fetched must determine the type of the resource. If the type of the resource is not a supported text track format, the load will fail, as described below. Otherwise, the resource’s data must be passed to the appropriate parser (e.g., the WebVTT parser) as it is received, with the text track list of cues being used for that parser’s output. [WEBVTT]
The appropriate parser will incrementally update the text track list of cues during these networking task source tasks, as each such task is run with whatever data has been received from the network).
This specification does not currently say whether or how to check the MIME types of text tracks, or whether or how to perform file type sniffing using the actual file data. Implementors differ in their intentions on this matter and it is therefore unclear what the right solution is. In the absence of any requirement here, the HTTP specification’s strict requirement to follow the Content-Type header prevails ("Content-Type specifies the media type of the underlying data." ... "If and only if the media type is not given by a Content-Type field, the recipient MAY attempt to guess the media type via inspection of its content and/or the name extension(s) of the URI used to identify the resource.").
If the fetching algorithm fails for any reason (network error, the server returns an error code, a cross-origin check fails, etc), or if URL is the empty string, then queue a task to first change the text track readiness state to failed to load and then fire a simple event named
error
at thetrack
element. This task must use the DOM manipulation task source.If the fetching algorithm does not fail, but the type of the resource is not a supported text track format, or the file was not successfully processed (e.g., the format in question is an XML format and the file contained a well-formedness error that the XML specification requires be detected and reported to the application), then the task that is queued by the networking task source in which the aforementioned problem is found must change the text track readiness state to failed to load and fire a simple event named
error
at thetrack
element.If the fetching algorithm does not fail, and the file was successfully processed, then the final task that is queued by the networking task source, after it has finished parsing the data, must change the text track readiness state to
