1 Introduction
This document defines the XQuery 1.0 and XPath 2.0 Data
Model, which is the data model of [XPath
2.0], [XSLT 2.0] and [XQuery 1.0: A Query Language for
XML]
The XQuery 1.0 and XPath 2.0 Data Model (henceforth
"data model") serves two purposes. First, it defines
precisely the information contained in the input to an XSLT
or XQuery processor. Second, it defines all permissible
values of expressions in the XSLT, XQuery, and XPath
languages. A language is closed with respect to a
data model if the value of every expression in a language
is guaranteed to be in the data model. XSLT 2.0, XQuery
1.0, and XPath 2.0 are all closed with respect to the data
model.
The data model is based on the [XML Information Set] (henceforth
"Infoset"), but it requires the following new features to
meet the [XPath Requirements Version
2.0] and [XML Query
Requirements]:
-
Support for XML Schema types. The XML Schema
recommendations define features, such as structures ([XMLSchema Part 1]) and simple
data types ([XMLSchema Part
2]), that extend the XML Information Set with
precise type information.
-
Representation of collections of documents and of
complex values. ([XML Query
Requirements])
As with the Infoset, the XQuery 1.0 and XPath 2.0 Data
Model specifies what information in the documents is
accessible, but it does not specify the
programming-language interfaces or bindings used to
represent or access the data.
Every value handled by the data model is a
sequence of zero or more items. An
item is either a node or an atomic
value. A node is defined in 4
Nodes and is one of seven node kinds. An atomic
value encapsulates an XML Schema atomic type and a
corresponding value of that type. They are defined in 5 Atomic Values. A sequence
is an ordered collection of nodes, atomic values, or any
mixture of nodes and atomic values. A sequence cannot be a
member of a sequence. A single item appearing on its own is
modeled as a sequence containing one item. Sequences are
defined in 6 Sequences.
|
Note: |
In XPath 1.0, the data model only defines nodes.
The primitive data types (number, boolean, string,
node-set) are part of the expression language, not
the data model.
|
The data model can represent various values including
not only the input and the output of a stylesheet or query,
but all values of expressions used during the intermediate
calculations. Examples include the input document or
document repository (represented as a document node or a
sequence of document nodes), the result of a path
expression (represented as a sequence of nodes), the result
of an arithmetic or a logical expression (represented as an
atomic value), a sequence expression resulting in a
sequence of items, etc.
In this document, we provide a precise definition of the
properties of nodes in the XQuery 1.0 and XPath 2.0 Data
Model, how they are accessed, and how they relate to values
in the Infoset. We note wherever the XQuery 1.0 and XPath
2.0 Data Model differs from that of XPath 1.0.
2 Notation
In addition to prose, we define a set of accessor
functions to explain the data model. The accessors defined
by the data model are shown with the prefix dm.
The prefix is always shown in italics to emphasize that
these functions are abstract; they exist to explain the
interface between the data model and specifications that
rely on the data model: they are not and cannot be made
accessible directly from the host language.
The signature of accessors is shown using the same style
as [XQuery 1.0 and XPath 2.0 Functions and
Operators]. For example:
dm:typed-value(
$n as Node)
as xdt:anyAtomicType*
In the notation syntax, the term Node denotes
the category of node values and Item refers to the
category of either node values or atomic values.
Some accessors can accept or return sequences. The
following notation is used to denote sequence values:
-
V* denotes a sequence of zero or more items
of type V.
-
V? denotes a sequence of exactly zero or
one items of type V.
-
V+ denotes a sequence of one or more items
of type V.
In a sequence, V may be a Node or
AtomicValue, or the union (choice) of several
categories of Items.
There are some functions in the data model that are
partial functions. We use the occurrence
indicators ? or * when specifying the
return type of such functions. For example, a node may have
one parent node or no parent. If the node argument has a
parent, the dm:parent accessor returns
a singleton sequence. If the node argument does not have a
parent, it returns the empty sequence. The signature of
dm:parent specifies that
it returns an empty sequence or a sequence containing one
node:
This document relies on the [XML
Information Set]. Information items and properties are
indicated by the styles information item and
[property], respectively.
This document frequently uses the term
expanded-QName. [Definition: An
expanded-QName is a pair of values consisting of a
namespace URI and a local name. They belong to the value
space of the XML Schema type xs:QName. When this document
refers to xs:QName we always mean the value space, i.e. a
namespace URI, local name pair (and not the lexical space
referring to constructs of the form
prefix:local-name).]
3 Concepts
3.1
Node Identity
Because XML documents are tree-structured, we define
the data model using conventional terminology for trees.
The data model is a node-labeled, directed graph, in
which each node has a unique identity. Every node in the
data model is unique: identical to itself, and not
identical to any other node.
This concept should not be confused with the concept
of a unique ID, which is a unique name assigned to an
element by the author to represent references using
ID/IDREF correlation.
3.2
Document Order
[Definition: A document
order is defined on all the nodes in a document.
Document order is a total ordering, although the relative
order of some nodes is implementation-dependent.
Informally, document order is the order returned by an
in-order, depth-first, left-to-right traversal of the
data model.] There is precisely one document order and it
satisfies the following constraints.
-
The document node is the first node.
-
The relative order of siblings is determined by
their order in the XML representation. A node N1
occurs before a node N2 in document order if and only
if the start of N1 occurs before the start of N2 in
the XML document.
-
Element nodes occur before their children;
children occur before following-siblings.
-
Namespace nodes immediately follow the element
node with which they are associated. The relative
order of namespace nodes is stable but
implementation-dependent.
-
Attribute nodes immediately follow the namespace
nodes of the element with which they are associated.
The relative order of attribute nodes is stable but
implementation-dependent.
The relative order of nodes in distinct documents is
implementation-dependent but stable. In other words,
given two distinct documents A and B, if a node in
document A is before a node in document B, then every
node in document A is before every node in document
B.
The relative order of free-standing nodes (elements,
attributes, and other nodes created outside the context
of a particular document) is also
implementation-dependent but stable.
3.3 XML Schemas and the
XML Information Set
This document describes how to construct an instance
of the data model from an [XML
Information Set]. Some aspects of the data model are
dependent upon XML Schema validity assessment; this
document describes how to determine those aspects of the
data model from a Post Schema Validation Infoset. [Definition:
A Post Schema Validation Infoset, or PSVI, is the
augmented infoset produced by an XML Schema validation
episode.].
Although we describe construction of a data model in
terms of infoset properties, an infoset is not an
absolutely necessary precondition for building an
instance of the Data Model. Purely synthetic data model
instances are entirely appropriate as long as they obey
all of the constraints described in this document.
The data model supports well-formed XML documents
conforming to [Namespaces in
XML]. XML documents that are not well-formed are not
XML, by definition. XML documents that do not conform to
[Namespaces in XML] are not
supported (nor are they supported by [XML Information Set]).
In other words, the data model supports the following
classes of XML documents:
The data model supports some kinds of values that are
not supported by [XML Information
Set]. Examples of these are well-formed document
fragments, sequences of fragments or sequences of
documents. The data model also supports values that are
not nodes. Examples of these are atomic values, sequences
of atomic values, or sequences mixing nodes and atomic
values. These are necessary to be able to represent the
results of intermediate expressions in the data model
during expression processing.
Schema-validated documents include documents in which
some elements or attributes have been validated by "lax"
or "skip" validation ([XMLSchema
Part 1]).
An "incompletely validated document" is an XML
document that has a corresponding schema but whose
schema-validity assessment has resulted in one or more
element or attribute information items being assigned
values other than 'valid' for the [validity]
property in the PSVI.
The data model supports incompletely validated
documents, but inconsistent data models are forbidden.
Elements and attributes that are not valid are treated as
untyped.
In addition to specifying the transformation from the
Post Schema Validation Infoset (PSVI) to the data model,
this document also specifies the transformation from the
data model back to the XML Information Set. This is a
useful notion that can be used for defining serialization
and validation. Serialization can be viewed as a two step
process, first transforming to the XML Infoset and then
to an XML document. Validation is described conceptually
as a process of mapping the data model to the XML Infoset
followed by XML Schema validation producing a PSVI which
is then loaded into the data model.
3.4 Types
The data model supports a representation of named
types as stipulated by [XQuery 1.0 Formal
Semantics].
For named types, which includes both the built-in
types defined by [XMLSchema Part
2] and named user-defined types declared in a schema
and imported by a stylesheet or query, the data model
uses expanded-QNames to
represent their names. Since named types in XML Schema
are global, an expanded-QName uniquely identifies such a
type. The namespace name of the expanded-QName is the
target namespace of the schema and its local name is the
name of the type.
For anonymous types, the processor must construct an
anonymous type name
that is distinct from the name of every named type and
the name of every other anonymous type. [Definition: An
anonymous type name is an implementation-defined,
globally unique type name provided by the processor for
every anonymous type declared in an imported schema.]
In either case, the type names must also appear in the
In-scope Schema Definitions (as defined in [XPath 2.0]) available to the
processor.
The data model associates type information with
element nodes, attribute nodes and atomic values. The
item is guaranteed to be a valid instance of that type as
defined by XML Schema.
The data model defines an accessor dm:type that returns an
expanded-QName corresponding to the type of the element
node, attribute node or atomic value. It returns
xs:anyType or xs:anySimpleType
if no type information exists, or if it failed W3C XML
Schema validity assessment.
When no type information exists for an element or an
attribute node we frequently use the terminology "element
with unknown type" or "attribute with unknown simple
type".
The data model does not represent element or attribute
declaration schema components, but it supports various
type-related operations. The semantics of such
operations, e.g. checking if a particular instance of an
element node has a given type is defined in [XQuery 1.0 Formal Semantics].
3.5 Typed
Value and String Value
The content of a text, attribute, or element node can
be interpreted in two ways: as a string value or as a
typed value. For these types of nodes, the typed value
can be extracted by the dm:typed-value accessor,
and the string value can be extracted by the dm:string-value
accessor.
The string value of a node is a single
xs:string derived from the content of the
node as described in the definitions of the accessor
functions for each kind of node.
The typed value of a node is a sequence of atomic
values derived from its string value and its type in a
way that is consistent with schema validation, as
described in the definitions of the accessor functions
for each kind of node.
3.6 Mapping
PSV Infoset additions to Types
This section specifies how the type of an element or
attribute node is computed from the PSVI properties that specify validity
and type assessment for the node's corresponding
information item.
A PSVI element or attribute information item has a
[validity] property. The [validity]
property may be "valid", "invalid", or
"notKnown" and reflects the outcome of
schema-validity assessment. The only information that can
be inferred from an invalid or not known validity value
is that the information item is well-formed, therefore,
we must associate some general type information with the
element or attribute node if it is not known to be
valid.
The precise definition of the type of an element or
attribute information item depends on the properties of
the Infoset or PSVI. In a PSVI, XML Schema only
guarantees the existence of either the [type
definition] property, or the [type definition
namespace], [type definition name] and
[type definition anonymous] properties. If the
type definition refers to a union type, there are further
properties defined, that refer to the type definition
which actually validated the item's normalized value.
These properties are either the [member type
definition], or the [member type definition
namespace], [member type definition name] and
[member type definition anonymous] properties. If
these are available, the type of an element or attribute
will refer to the member type that actually validated the
schema normalized value.
If a PSVI is not available, then the data model is
constructed from the Infoset in a manner that is
compatible with the expectations of well-formed or
DTD-validated parsing of an XML document.
The type of an element information item is
represented by an expanded-QName whose
namespace and local name correspond to the first
applicable items in the following list:
-
If the [validity] property exists and is
"valid":
-
If [member type definition] exists and
its {name} property is present:
-
If the [type definition] property
exists and its {name} property is present:
-
If [member type definition anonymous]
exists:
-
If it is false: the [member
type definition namespace] and the
[member type definition name].
-
Otherwise, the namespace and local name of
the appropriate anonymous type
name.
-
If [type definition anonymous]
exists:
-
If it is false: the [type
definition namespace] and the [type
definition name]
-
Otherwise, the namespace and local name of
the appropriate anonymous type
name.
-
If the [validity] property does not
exist on this node or any of its ancestors,
Infoset-only processing is applied:
-
If the [attribute type] property exists
and has one of the following values: ID, IDREF,
IDREFS, ENTITY, ENTITIES, NMTOKEN, or NMTOKENS,
the {target namespace} is
"http://www.w3.org/2001/XMLSchema" and the {name}
is the [attribute type].
Note that this processing is only performed if no
part of the subtree that contains the node was schema
validated. In particular, Infoset-only processing
does not apply to subtrees that are "skip" validated
in a document.
-
Otherwise, xs:anyType for elements or
xs:anySimpleType for attributes.
If the expanded-QName that results from this
derivation is not available in the processor's In-Scope
Schema Definitions, the expanded-QName is promoted to
xs:anyType for elements or
xs:anySimpleType for attributes. This can
occur, for example, if the processor does not support the
schema import feature or if it was unable to import the
necessary schema.
Attributes from the XML Schema instance namespace,
"http://www.w3.org/2001/XMLSchema-instance",
(xsi:schemaLocation, xsi:type,
etc.) appear as ordinary attributes in the data model.
They will be validated appropriately by schema processors
and will simply appear as attributes of type
xs:anySimpleType if they haven't been schema
validated.
3.6.1
Mapping xs:dateTime, xs:date,
and xs:time Values
[XMLSchema Part 2]
permits xs:dateTime, xs:date,
and xs:time values both with and without
timezones. In the context of validation, this is a
purely lexical distinction. In order to compare dates
and times, an XML Schema validator converts all times
to Coordinated Universal Time (UTC or timezone Z). But
in the data model, it is necessary to preserve timezone
information.
In order to achieve this goal
xs:dateTime, xs:date, and
xs:time values are represented as tuples
in the data model: a time value normalized to UTC and a
timezone represented as a
xdt:dayTimeDuration.
The lexical representation of the value is converted
to UTC as defined by [XMLSchema
Part 2] and the timezone in the lexical
representation is converted to a
xdt:dayTimeDuration value. These two
values are stored in the tuple.
Lexical representations that do not have a timezone
are assumed to be in UTC for the purposes of
normalization. An empty sequence is used for their
timezone in the tuple.
Thus, for the purpose of validation,
"2003-01-02T11:30:00-05:00" is converted to
"2003-01-02T16:30:00Z", but the data model stores it as
"(2003-01-02T16:30:00Z, -PT5H0M)". The value
"2003-01-16T16:30:00" is stored as it is
"(2003-01-02T16:30:00Z, ())" because it has no
timezone.
3.6.2 Mapping
xsi:nil on Element Nodes
[XMLSchema Part 2]
introduced a mechanism for signaling that an element
should be accepted as valid when it has no content
despite a content type which does not require or even
necessarily allow empty content. That mechanism is the
xsi:nil attribute.
The data model exposes this special semantic in the
nilled property.
If the [validity] property exists on an
element node and is "valid" then nilled
may be set. The nilled property is never set for
nodes that have not been successfully schema
validated.
If the element is valid and has a PSVI [nil]
property and that property is true, then nilled
is true. In all other cases, nilled is
false.
3.7 Comments,
Processing Instructions, and Whitespace
Although the data model is able to represent comments,
processing instructions, and insignificant whitespace,
preservation of this information may be unnecessary and
onerous for some applications.
An instance of the data model can be constructed from
an Infoset, a PSVI, or from some other data source
entirely. Different applications may or may not choose to
construct nodes in the data model to represent comments,
processing instructions, and insignificant white space.
These decisions are considered outside the scope of the
data model. Consequently the data model makes no attempt
to control or identify the sort of processing in this
regard that an application uses to construct a data model
instance.
4 Nodes
The category of Node values contains seven
distinct kinds of nodes: document, element, attribute, text, namespace, processing
instruction, and comment.
The seven kinds of nodes are defined in the following
subsections.
A tree contains a root plus all nodes that are reachable
directly or indirectly from the root via the dm:children, dm:attributes, and dm:namespaces accessors.
Every node belongs to exactly one tree, and every tree has
exactly one root node. A tree whose root node is a document
node is referred to as a document. A tree whose
root node is some other kind of node is referred to as a
fragment.
4.1
Accessors
A set of accessors is defined on all seven kinds of
Nodes. Some accessors return a constant empty sequence on
certain node kinds. Some node kinds have additional
accessors that are not summarized here.
In order for applications to be able to operate on
instances of the data model, the model must expose
properties of the items it contains. The data model does
this by defining a family of accessor functions. These
are not functions in the literal sense, they are not
available for users or applications to call directly,
rather they are descriptions of the interface that an
implementation of the data model must expose to
applications. Functions and operators available to
end-users are described in [XQuery 1.0 and
XPath 2.0 Functions and Operators].
4.1.1
base-uri Accessor
dm:base-uri(
$n as Node)
as xs:anyURI?
The dm:base-uri accessor
returns a sequence containing zero or one uri
references.
Document, element, and processing-instruction nodes
have a base-uri property. The base-uri of all other
node types is the empty sequence.
If the base-uri property of a document, element, or
processing-instruction node is non-empty, its value is
returned.
If the accessor is called on a node that does not
have a base-uri property, or whose base-uri property is
empty, the base-uri of that node's parent is returned.
If the node has no parent, the empty sequence is
returned.
4.1.2
node-kind Accessor
dm:node-kind(
$n as Node)
as xs:string
The dm:node-kind accessor
returns a string value identifying the kind of node on
which the accessor was called. One of the following
values is returned:
-
"document" for document nodes.
-
"element" for element nodes.
-
"attribute" for attribute
nodes.
-
"text" for text nodes.
-
"namespace" for namespace
nodes.
-
"processing-instruction" for
processing instruction nodes.
-
"comment" for comment nodes.
4.1.3
node-name Accessor
dm:node-name(
$n as Node)
as xs:QName?
The dm:node-name accessor
returns a sequence of zero or one xs:QNames.
-
For element and attribute nodes, dm:node-name
returns the qualified name of the element or
attribute.
-
For processing-instructions nodes, dm:node-name
returns an xs:QName with the processing instruction
target name in the local-name and no namespace
URI.
-
For namespace nodes, dm:node-name
returns an xs:QName with the prefix of the
namespace declaration in the local-name and no
namespace URI. If the namespace declaration
declares the default namespace, which has no
prefix, an empty sequence is returned.
Some implementations may not preserve
information about the prefixes declared. In these
cases, the dm:node-name
accessor returns the empty sequence when applied to
namespace nodes.
4.1.4
parent Accessor
The dm:parent accessor
returns a sequence containing zero or one nodes.
For nodes that have a parent, dm:parent returns the
parent node. For all other nodes, it returns the empty
sequence.
If the return value is not the empty sequence, it
will always be either an element node or a document
node.
4.1.5
string-value Accessor
dm:string-value(
$n as Node)
as xs:string
Every node has a string value; the way in which the
string value of a node is computed is different for
each kind of node and is specified in the sections on
nodes below.
The string value of an atomic value is computed by
casting it to an xs:string as per the
rules described in [XQuery 1.0 and XPath
2.0 Functions and Operators].
4.1.6
typed-value Accessor
dm:typed-value(
$n as Node)
as xdt:anyAtomicType*
The dm:typed-value
accessor returns the typed-value of the node, which is
a sequence of zero or more atomic values derived from
the string-value of the node and its type in such a way
as to be consistent with validation.
-
If the node is a comment, document, namespace,
processing-instruction, or text node, then its
typed value is equal to its string value as an
instance of xdt:untypedAtomic.
-
If the node is an attribute node with type
xs:anySimpleType, then its typed value
is equal to its string value as an instance of
xdt:untypedAtomic. The typed value of
an attribute node with any other type is derived
from its string value and type annotation in a way
that is consistent with XML Schema validation.
-
If the node is an element node with type
xs:anyType, then its typed value is
equal to its string value, as an instance of
xdt:untypedAtomic.
-
If the node is an element node with a simple
type or with a complex type of simple content, then
its typed value is derived from its string value
and type in a way that is consistent with XML
Schema validation.
-
If the item is an element node with complex type
of empty content, then its typed value is the empty
sequence.
-
If the node is an element node with a complex
type of mixed content, then its typed value is its
string value as an instance of
xdt:untypedAtomic.
-
If the item is an element node with complex type
of complex content, then its typed value is
undefined and dm:typed-value
raises a type error, which may be handled by the
host language.
For detailed semantics see [XQuery
1.0 Formal Semantics].
For xs:dateTime, xs:date
and xs:time, the typed value is the atomic
value that is determined from its tuple representation
as follows:
-
If the timezone component is not the empty
sequence, then the value contains the time
component, normalized to the timezone specified by
the timezone component, as well as the timezone
component. The tuple "(2003-01-02T16:30:00Z,
-PT5H0M)" produces the value
"2003-01-02T11:30:00-05:00".
-
If the timezone component is the empty sequence,
then the time component without any indication of
timezone. The tuple "(2003-01-02T16:30:00Z, ())"
produces the value "2003-01-02T16:30:00".
4.1.7
type Accessor
dm:type(
$n as Node)
as xs:QName?
The dm:type accessor
returns the name of the type of a node.
For element nodes and attribute nodes, dm:type returns the
name of the type of the node (as an
xs:QName) if it has one. If the type is
anonymous, or if no type information exists, the name
returned will be unique but implementation defined.
|
Note: |
The use of xs:QName in this
signature is part of the data model formalism.
In practice, implementations are not required
to use xs:QNames to represent the
implementation-defined names of anonymous
types.
|
For text nodes, dm:type returns
xdt:untypedAtomic.
For other node kinds, it always returns the empty
sequence.
4.1.8
children Accessor
The dm:children accessor
returns a sequence containing zero or more nodes.
For document and element nodes, it returns the nodes
that are the children of that node in document order.
It returns the empty sequence for document and element
nodes that have no children. If children exist, they
will always consist exclusively of element,
processing-instruction, comment, and text nodes.
Attribute, namespace, and document nodes can never
appear as children.
For all other nodes, it always returns the empty
sequence.
A document node or an element node is the parent of
each of its child nodes. Nodes never share children: if
two nodes have distinct identities, then no child of
one node will be a child of the other node.
The sequence of children will never contain adjacent
text nodes.
4.1.9 attributes
Accessor
The dm:attributes accessor
returns a sequence containing zero or more attribute
nodes.
For element nodes, these are the attributes of the
node. For all other nodes, it always returns the empty
sequence.
4.1.10 namespaces
Accessor
The dm:namespaces accessor
returns a sequence containing zero or more namespace
nodes.
For element nodes, these are the namespaces of the
node. For all other nodes, it always returns the empty
sequence.
4.2
Documents
4.2.1 Overview
Document nodes encapsulate XML documents. Documents
have the following properties:
-
base-uri, possibly empty.
-
children, possibly empty.
-
unparsed-entities, possibly empty.
-
document-uri, possibly empty.
Document nodes must satisfy the following
constraints.
-
Every document node must have a unique identity,
distinct from all other nodes.
-
The children must consist exclusively of
element, processing instruction, comment, and text
nodes if it is not empty. Attribute, namespace, and
document nodes can never appear as children
-
The sequence of nodes in the children
property is ordered and must be in document
order.
-
The children property must not contain
two consecutive text nodes.
-
If a node N is a child of a document
D, then the parent of N must be
D.
-
If a node N has a parent document
D, then N must be among the
children of D.
-
Every child of a document must be distinct.
In a well-formed document, the children of the
document node must not be empty and consist exclusively
of element nodes, processing-instruction nodes, and
comment nodes, and exactly one of these children is an
element node. A document node in the data model is more
permissive: it may be empty and it allows more than one
element node as a child and also permits text nodes as
children.
|
Note: |
Document nodes and XPath 1.0 root nodes are
essentially identical.
|
Implementations that support DTD processing and
access to the unparsed entity accessors, use the
unparsed-entities property to associate
information about an unordered collection of unparsed
entities with a document node.
4.2.2 Accessors
Three additional accessors are defined on document
nodes:
dm:unparsed-entity-system-id( |
$node |
as DocumentNode, |
$entityname |
as xs:string) as xs:string? |
The dm:unparsed-entity-system-id
accessor returns the system identifier of an unparsed
external entity declared in the specified document. If
no entity with the name specified in
$entityname exists, or if the entity is
not an external unparsed entity, the empty sequence is
returned.
dm:unparsed-entity-public-id( |
$node |
as DocumentNode, |
$entityname |
as xs:string) as xs:string? |
The dm:unparsed-entity-public-id
accessor returns the public identifier of an unparsed
external entity declared in the specified document. If
no entity with the name specified in
$entityname exists, or if the entity is
not an external unparsed entity, or if the entity has
no public identifier, the empty sequence is
returned.
The dm:document-uri accessor
returns the absolute URI of the resource from which the
document node was constructed, if the absolute URI is
available. If there is no URI available, or if it
cannot be made absolute when the data model is
constructed, the empty sequence is returned.
For example, if a collection of documents is
returned by the fn:collection function,
the dm:document-uri may serve
to distinguish between them even though each has the
same dm:base-uri.
4.2.3 PSVI to Data Model
Mapping
When a data model fragment is created from the PSVI,
a document information item is mapped to a
Document Node. The precise transformation is described
by specifying the PSVI property corresponding to each
property of a document node.
- base-uri
-
The value of the [base URI] property.
- children
-
The sequence of nodes constructed from the
information items found in the [children]
property.
To construct the value of the children
property, for each element, processing instruction,
comment, and maximal sequence of adjacent character
information items found in the [children]
property, a corresponding Element, Processing
Instruction, Comment, and Text node is constructed and
that sequence of nodes is used as the value. If present
among the [children], the [document type
declaration] information item is ignored.
4.2.4 Data Model to
Infoset Mapping
The mapping of the data model to the XML Information
Set maps a Document Node to a document information
item. The properties of the document information
item are constructed as follows:
| Property |
Value: |
| [base
URI] |
The value returned by
the dm:base-uri
accessor |
|
[children] |
The sequence of
information items constructed from the nodes
returned by the dm:children
accessor. In other words, for each node returned
by the dm:children
accessor, a corresponding information item is
constructed and that sequence of information
items is used as the value for the
[children] property. |
| [document
element] |
The values of these
properties are implementation-defined but must be
consistent with the rest of the Infoset
constructed. |
|
[notations] |
| [unparsed
entities] |
| [character
encoding scheme] |
|
[standalone] |
| [version] |
| [all declarations
processed] |
|
Note: |
Since Document Nodes are more permissive
than document information items, the
resulting Infoset may be invalid.
|
4.3
Elements
4.3.1 Overview
Element nodes encapsulate XML elements. Elements
have the following properties:
-
base-uri, possibly empty.
-
node-name
-
parent, possibly empty
-
type
-
children, possibly empty
-
attributes, possibly empty
-
namespaces, possibly empty
-
nilled
Element nodes must satisfy the following
constraints.
-
Every element node must have a unique identity,
distinct from all other nodes.
-
The children must consist exclusively of
element, processing instruction, comment, and text
nodes if it is not empty. Attribute, namespace, and
document nodes can never appear as children
-
The sequence of nodes in the children
property is ordered and must be in document
order.
-
The children property must not contain
two consecutive text nodes.
-
Every child of an element must be distinct.
-
The attributes of an element must have distinct
names.
-
The namespace nodes of an element must have
distinct names. At most one of the namespace nodes
of an element has no name (this is the default
namespace). A namespace node whose namespace URI is
the zero-length string must have no name. No
namespace node may have the name
"xmlns".
-
If a node N is a child of an element
E, then the parent of N must be
E.
-
Exclusive of attribute nodes, if a node
N has a parent element E, then
N must be among the children of
E. (Attribute nodes have a parent, but
they do not appear among the children of their
parent.)
The data model permits element nodes without
parents (to represent partial results during
expression processing, for example). Such elements
must not appear among the children of any other
node.
-
If an attribute node A has a parent
element E, then A must be among
the attributes of E.
The data model permits attribute nodes without
parents (to represent partial results during
expression processing, for example). Such
attributes must not appear among the attributes of
any element node.
The data model does not enforce a constraint that
the namespaces of an element must be a superset of the
namespaces of its parent, nor does it enforce a
constraint that the namespaces of an element must
include namespace nodes for each of the namespace URIs
used in the element name and the names of its
attributes, or of namespace URIs used in the content of
elements and attributes of type xs:QName. Applications
of the data model (such as XSLT and XQuery) may enforce
such constraints in particular circumstances, but these
constraints are not part of the data model.
4.3.2 Accessors
The dm:base-uri accessor
returns the base-uri property of the element
node, if it exists. If it does not exist, the base URI
of the element's parent is returned.
The accessors dm:namespaces and
dm:attributes return
the same set of namespace and attribute nodes
(respectively) associated with the element. They are
not constrained to return them in any particular
order.
The dm:parent accessor
returns the empty sequence if the element has no
parent.
If the element node's type is
xs:anyType, the dm:typed-value
accessor returns the node's string value as
xs:anySimpleType. If the type is a complex
type with complex content, invoking dm:typed-value raises
an error.
The dm:typed-value
accessor returns the typed-value of the node, which is
a sequence of zero or more atomic values. The
typed-value is closely related to the node's
string-value and its type. For example:
-
When the node's string-value is "3.14" and its
type is xs:decimal, the typed-value is
a sequence containing the atomic value 3.14 of type
decimal.
-
When the node's string-value is "foo bar baz"
and its type is xs:IDREFS, the
typed-value is a sequence containing the atomic
values "foo", "bar", and "baz", each of type
xs:IDREF.
-
When the node's string-value is "17" and its
type is xs:anyType, the typed-value is
a sequence containing the atomic value "17" of type
xs:anySimpleType.
In fact, when the type is an atomic type,
typed-value is always the atomic-value constructed from
the string-value and the type.
In the general case, dm:typed-value
constructs a sequence of atomic values. These values
are derived from the string-value of the element and
its type, in such a way as to be consistent with
validation.
One additional accessors is defined on element
nodes:
dm:element-declaration(
$node as ElementNode)
as xs:string*
The dm:element-declaration
accessor returns the xs:QName of the global element
declaration associated with this element. If the
element declaration is local, it returns a sequence
consisting of the xs:QName of the local element
declaration and the SchemaGlobalContext of the declaration.
This declaration can be used by implementations to
identify substitution groups, nillability, and other
aspects of the declaration.
4.3.3 PSVI to Data Model
Mapping
When a data model fragment is created from the PSVI,
an element information item is mapped to an
Element Node. The precise transformation is described
by specifying the PSVI property corresponding to each
property of an element node.
- base-uri
-
The value of the [base URI] property.
- node-name
-
An xs:QName constructed from the
[local name] property and the [namespace
name] property
- parent
-
The value of the [parent] property.
- type
-
The xs:QName computed as described
in 3.6 Mapping PSV Infoset
additions to Types. Note that if the type
referenced would be a union type then type refers
to the member type that actually validated the
schema normalized value.
- children
-
-
If the [schema normalized value] PSVI
property exists and is not absent, the
processor may, depending on the implementation,
use a sequence of nodes containing the
Processing Instruction and Comment nodes
corresponding to the processing
instruction and comment information
items found in the [children] property,
plus a single text node whose string value is
the the [schema normalized value]. The
order of these nodes is implementation
defined.
-
Otherwise, a sequence of nodes constructed
in the following way from the information items
found in the [children] property: for
each element, processing instruction, comment,
and maximal sequence of adjacent character
information items found in the
[children] property, a corresponding
Element, Processing Instruction, Comment, and
Text node is constructed.
Because the data model requires that all general
entities be expanded, there will never be
unexpanded entity reference information item
children.
- attributes
-
A set of Attribute Nodes constructed from the
attribute information items appearing in the
[attributes] property. This includes all of
the "special" attributes (xml:lang,
xml:space, xsi:type,
etc.) but does not include namespace declarations
(because they are not attributes).
- namespaces
-
A set of Namespace Nodes constructed from the
namespace information items appearing in the
[in-scope namespaces] property.
Some implementations may choose to use only a
subset of the namespaces present in the PSVI. In
particular, they may exclude namespace nodes for
namespaces which do not appear in the qualified
name of any element or attribute information item.
This can arise when xs:QNames are used in
content.
- nilled
-
If the [validity] property exists and is
"valid" and the [attributes]
property contains an attribute with the local-name
"nil" and the namespace URI
"http://www.w3.org/2001/XMLSchema-instance",
then "true", otherwise
"false".
4.3.4 Data Model to Infoset
Mapping
The mapping of the data model to the XML Information
Set maps an Element Node to an element information
item. The properties of the element information
item are constructed as follows:
| Property |
Value: |
| [namespace
name] |
The namespace name of
the xs:QName returned by the dm:node-name
accessor |
| [local
name] |
The local name of the
xs:QName returned by the dm:node-name
accessor |
| [prefix] |
An appropriate
namespace prefix, as described below |
|
[children] |
The sequence of
information items constructed from the nodes
returned by the dm:children
accessor. In other words, for each node returned
by the dm:children
accessor, a corresponding information item is
constructed and that sequence of information
items is used as the value for the [namespace
name] property. |
|
[attributes] |
The sequence of
attribute information items constructed
from the nodes returned by the dm:attributes
accessor. |
| [in-scope
namespaces] |
The sequence of
namespace information items constructed
from the nodes returned by the dm:namespaces
accessor. |
| [base
URI] |
The value returned by
the dm:base-uri
accessor |
| [parent] |
The information item
constructed from the node returned by the dm:parent
accessor. If the node has no parent, the property
must be left absent and the resulting Infoset
will not be valid. |
| [namespace
attributes] |
The sequence of
namespace information items constructed
from the nodes that are present in the difference
between the sequence of nodes returned by the
dm:namespaces
accessor on this element and the sequence of
nodes returned by the dm:namespaces
accessor of this element's dm:parent; see
below. |
An implementation must construct the value of the
[prefix] property as if the following algorithm
was applied: if the element has at least one namespace
node whose namespace URI is the same as the namespace
name of the xs:QName returned by the dm:node-name accessor,
it returns the local part of the name of that namespace
node or the empty string if the namespace node has no
name. If there are several such namespace nodes, it
chooses one of them arbitrarily. If there is no such
namespace node, it generates an arbitrary prefix that
is distinct from the dm:node-name of any of
the element's namespaces. The [prefix] is the
empty string if the element has an empty [namespace
name] (if it is in the null namespace).
If a new prefix is generated, a corresponding
namespace information item must be added to the
[in-scope namespaces] property of the element
information item. The namespace information
item must associate the generated prefix with the
namespace name of the xs:QName returned by the
element's dm:node-name
accessor.
|
Note: |
If the implementation has allowed in-scope
namespaces to be discarded from the data model,
then these namespaces may need to be
reintroduced when creating an Infoset in order
to ensure that the Infoset corresponds to a
document that is namespace well-formed as
defined in [Namespaces in
XML].
|
|
Note: |
The algorithm used to calculate namespace
attributes will need to be adjusted to cater
for XML Namespaces 1.1, which allows the
"undeclaration" of all namespaces, whether they
have a prefix or not.
|
The [namespace attributes] property is
computed so that it contains the smallest possible set
of namespace attributes. For example, suppose that the
dm:namespaces accessor
for this element returns namespace nodes for the "foo",
"bar", and "baz" namespaces and the dm:namespaces accessor
for this element's parent returns namespace nodes for
the "foo" and "bar" namespaces. In this case, the
[namespace attributes] property will contain a
single namespace information item for the "baz"
namespace.
4.4
Attributes
4.4.1 Overview
Attribute nodes encapsulate XML attributes.
Attributes have the following properties:
-
node-name
-
string-value
-
parent, possibly empty
-
type
Attribute nodes must satisfy the following
constraints.
-
Every attribute node must have a unique
identity, distinct from all other nodes.
-
If a attribute node A has a parent
element E, then A must be among
the attributes of E.
The data model permits attribute nodes without
parents (to represent partial results during
expression processing, for example). Such
attributes must not appear among the attributes of
any element node.
For convenience, the element node that owns this
attribute is called its "parent" even though an
attribute node is not a "child" of its parent
element.
4.4.2 Accessors
If the attribute node's type is
xs:anySimpleType, the dm:typed-value
accessor returns the node's string value as
xdt:untypedAtomic.
The dm:typed-value
accessor returns the typed-value of the node, which is
a sequence of zero or more atomic values. The
typed-value is closely related to the node's
string-value and its type. For example:
-
When the node's string-value is "3.14" and its
type is xs:decimal, the typed-value is
a sequence containing the atomic value 3.14 of type
decimal.
-
When the node's string-value is "foo bar baz"
and its type is xs:IDREFS, the
typed-value is a sequence containing the atomic
values "foo", "bar", and "baz", each of type
xs:IDREF.
-
When the node's string-value is "17" and its
type is xs:anyType, the typed-value is
a sequence containing the atomic value "17" of type
xs:untypedAtomic.
In fact, when the type is an atomic type,
typed-value is always the atomic-value constructed from
the string-value and the type.
In the general case, dm:typed-value
constructs a sequence of atomic values. These values
are derived from the string-value of the element and
its type, in such a way as to be consistent with
validation.
4.4.3 PSVI to Data
Model Mapping
When a data model fragment is created from the PSVI
an attribute information item is mapped to an
Attribute Node. The precise transformation is described
by specifying the PSVI property corresponding to each
property of an attribute node.
- node-name
-
An xs:QName constructed from the
[local name] property and the [namespace
name] property
- string-value
-
- parent
-
The value of the [parent] property.
- type
-
The xs:QName computed as described
in 3.6 Mapping PSV Infoset
additions to Types. Note that if the type
referenced would be a union type then type refers
to the member type that actually validated the
schema normalized value.
4.4.4 Data Model to
Infoset Mapping
The mapping of the data model to the XML Information
Set maps an Attribute Node to an attribute
information item. The properties of the
corresponding attribute information item are
constructed as follows:
| Property |
Value: |
| [namespace
name] |
The namespace name of
the xs:QName returned by the |
