This repo holds all audio maagement (mixer) related resources
Table of contents
General information
version: 1.5.3-W3C
Repository:
Author
Dr. Patrick Bartsch <patrick.bartsch@volkswagen.de>
Resources
/mixer/bindings/
This endpoint defines if a source will be played on output and on which. It is possible to use multiple sources on multiple outputs. Think of bindings like cable on your home stereo system.
audioBindingObject
Properties
name | description | type | format | unit(s) | value(s) |
---|---|---|---|---|---|
id | identifier | string | uuid | - | |
name | source name | string | - | ||
uri | object uri | string | uri | - | |
volume | current audio volume | integer | percent | [-inf..100] | |
volumestepsize | possible audio volume steps | integer | percent | [-inf..100] | |
source | the source that is bound | object | /mixer/audiosources/audioSourceObject | ||
output | the output the source is bound to | object | /mixer/outputs/audioOutputObject | ||
muted | muting state | boolean | - |
Resource level access (/mixer/bindings/)
POST
Note: Use a http POST request on /mixer/bindings/ to create a new element of type audioBindingObject
Subscribe to /mixer/bindings/ to receive updates for element creations or removals from the collection.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | format | mandatory |
---|---|---|---|
name | string | yes | |
volume | integer | yes | |
muted | boolean | no | |
source | string | uri | yes |
output | string | uri | yes |
Request/response example
POST /mixer/bindings/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
{
"viwi": "rockz.."
}
=>
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
Location: /mixer/bindings/3901a278-ba17-44d6-9aef-f7ca67c04840
{
"status": "ok"
}
GET
Note: Use a http GET request on /mixer/bindings/ to retrieve a list of available elements of type audioBindingObject
Subscribe to /mixer/bindings/ to receive updates for element creations or removals from the collection.
Request/response example
GET /mixer/bindings/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
=>
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/bindings/3901a278-ba17-44d6-9aef-f7ca67c04840"
},
{
"id": "8901870-b526-11e3-a5e2-0800200c9a66",
"name": "dolor sit",
"uri": "/mixer/bindings/8901870-b526-11e3-a5e2-0800200c9a66"
}
]
}
Element level access (/mixer/bindings/:uuid)
POST
Note:
Use a http POST request on /mixer/bindings/:uuid to update a particular audioBindingObject
Subscribe to /mixer/bindings/:uuid to receive updates on element level changes.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | mandatory |
---|---|---|
name | string | no |
volume | integer | no |
muted | boolean | no |
source | string | no |
output | string | no |
Request/response example
POST /mixer/bindings/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
{
"viwi": "rockz.."
}
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok"
}
GET
Note:
Use a http GET request on /mixer/bindings/:uuid to retrieve a particular audioBindingObject
Subscribe to /mixer/bindings/:uuid to receive updates on element level changes.
Request/response example
GET /mixer/bindings/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/bindings/3901a278-ba17-44d6-9aef-f7ca67c04840"
}
]
}
Events
This endpoint will not send any events. Therefor you can not register for them.
/mixer/audiosources/
Audio signal source, might be a bluetooth receiver, a CD player or the internal media renderer. Think of audio delivering blocks of a home stereo system. New Audio Sources like an external navigation announcement service might be added via POST and removed via DELETE. All standard source will return an error if a client tries to modify or remove them without permission.
audioSourceObject
Properties
name | description | type | format | unit(s) | value(s) |
---|---|---|---|---|---|
id | identifier | string | uuid | - | |
name | source name | string | main tuner mediaplayer phone navigation bluetooth speech |
||
uri | object uri | string | uri | - | |
muted | muting state | boolean | - | ||
gainoffset | input gain offset | integer | percent | [-inf..100] |
Resource level access (/mixer/audiosources/)
GET
Note: Use a http GET request on /mixer/audiosources/ to retrieve a list of available elements of type audioSourceObject
Subscribe to /mixer/audiosources/ to receive updates for element creations or removals from the collection.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | format | mandatory |
---|---|---|---|
Request/response example
GET /mixer/audiosources/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
=>
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/audiosources/3901a278-ba17-44d6-9aef-f7ca67c04840"
},
{
"id": "8901870-b526-11e3-a5e2-0800200c9a66",
"name": "dolor sit",
"uri": "/mixer/audiosources/8901870-b526-11e3-a5e2-0800200c9a66"
}
]
}
POST
Note: Use a http POST request on /mixer/audiosources/ to create a new element of type audioSourceObject
Subscribe to /mixer/audiosources/ to receive updates for element creations or removals from the collection.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | format | mandatory |
---|---|---|---|
muted | boolean | no | |
gainoffset | integer | no |
Request/response example
POST /mixer/audiosources/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
{
"viwi": "rockz.."
}
=>
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
Location: /mixer/audiosources/3901a278-ba17-44d6-9aef-f7ca67c04840
{
"status": "ok"
}
Element level access (/mixer/audiosources/:uuid)
GET
Note:
Use a http GET request on /mixer/audiosources/:uuid to retrieve a particular audioSourceObject
Subscribe to /mixer/audiosources/:uuid to receive updates on element level changes.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | mandatory |
---|---|---|
Request/response example
GET /mixer/audiosources/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/audiosources/3901a278-ba17-44d6-9aef-f7ca67c04840"
}
]
}
DELETE
Note:
Use a http DELETE request on /mixer/audiosources/:uuid to update a particular audioSourceObject
Subscribe to /mixer/audiosources/:uuid to receive updates on element level changes.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | mandatory |
---|---|---|
Request/response example
DELETE /mixer/audiosources/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok"
}
POST
Note:
Use a http POST request on /mixer/audiosources/:uuid to update a particular audioSourceObject
Subscribe to /mixer/audiosources/:uuid to receive updates on element level changes.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | mandatory |
---|---|---|
muted | boolean | no |
gainoffset | integer | no |
Request/response example
POST /mixer/audiosources/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
{
"viwi": "rockz.."
}
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok"
}
Events
The following events may be fired by client interaction or system side:
- /mixer/audiosources/ (resource level)
- /mixer/audiosources/:uuid (element level)
/mixer/outputs/
Audio outputs are sinks from the systems perspective like speakers, bluetooth streaming or headphones. A typical system has at least one output for the in-car speaker system (through amp) but can have multiple outputs. Clients may register for changes on outputs like on/off switching, volume changes or change of gala settings.
audioOutputObject
Properties
name | description | type | format | unit(s) | value(s) |
---|---|---|---|---|---|
id | identifier | string | uuid | - | |
name | output name | string | bluetooth rearset main headphones |
||
uri | object uri | string | uri | - | |
status | output status (on/off) | boolean | - | ||
positioner | audio positioner object | object | /mixer/positioners/audioPositionerObject | ||
equalizers | audio equalizer EqualizerObject | array | /mixer/equalizers/equalizerObject | ||
volume | the master volume of the output | integer | percent | [-inf..100] | |
volumestepsize | possible audio volume steps | integer | percent | [-inf..100] | |
gala | gala status | string | off auto curve1 curve2 curve3 curve4 curve5 curve6 curve7 |
||
soundlabel | property to determine the sound application and configuration for sound labeling | string | beats dynaudio bose bangAndOlufsen |
Resource level access (/mixer/outputs/)
GET
Note: Use a http GET request on /mixer/outputs/ to retrieve a list of available elements of type audioOutputObject
Subscribe to /mixer/outputs/ to receive updates for element creations or removals from the collection.
Request/response example
GET /mixer/outputs/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
=>
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/outputs/3901a278-ba17-44d6-9aef-f7ca67c04840"
},
{
"id": "8901870-b526-11e3-a5e2-0800200c9a66",
"name": "dolor sit",
"uri": "/mixer/outputs/8901870-b526-11e3-a5e2-0800200c9a66"
}
]
}
Element level access (/mixer/outputs/:uuid)
POST
Note:
Use a http POST request on /mixer/outputs/:uuid to update a particular audioOutputObject
Subscribe to /mixer/outputs/:uuid to receive updates on element level changes.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | mandatory |
---|---|---|
status | boolean | no |
volume | integer | no |
gala | string | no |
Request/response example
POST /mixer/outputs/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
{
"viwi": "rockz.."
}
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok"
}
GET
Note:
Use a http GET request on /mixer/outputs/:uuid to retrieve a particular audioOutputObject
Subscribe to /mixer/outputs/:uuid to receive updates on element level changes.
Request/response example
GET /mixer/outputs/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/outputs/3901a278-ba17-44d6-9aef-f7ca67c04840"
}
]
}
Events
The following events may be fired by client interaction or system side:
- /mixer/outputs/ (resource level)
- /mixer/outputs/:uuid (element level)
/mixer/positioners/
Audio center positioner provides access to the balance and fader settings of eachpositioner. The linking to an output is held by audioOutputObject.
audioPositionerObject
Properties
name | description | type | format | unit(s) | value(s) |
---|---|---|---|---|---|
id | identifier | string | uuid | - | |
name | audio positioner name | string | - | ||
uri | object uri | string | uri | - | |
balance | Balance settings | integer | percent | [-100..100] | |
fader | Fader settings | integer | percent | [-100..100] |
Resource level access (/mixer/positioners/)
GET
Note: Use a http GET request on /mixer/positioners/ to retrieve a list of available elements of type audioPositionerObject
Subscribe to /mixer/positioners/ to receive updates for element creations or removals from the collection.
Request/response example
GET /mixer/positioners/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
=>
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/positioners/3901a278-ba17-44d6-9aef-f7ca67c04840"
},
{
"id": "8901870-b526-11e3-a5e2-0800200c9a66",
"name": "dolor sit",
"uri": "/mixer/positioners/8901870-b526-11e3-a5e2-0800200c9a66"
}
]
}
Element level access (/mixer/positioners/:uuid)
POST
Note:
Use a http POST request on /mixer/positioners/:uuid to update a particular audioPositionerObject
Subscribe to /mixer/positioners/:uuid to receive updates on element level changes.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | mandatory |
---|---|---|
balance | integer | no |
fader | integer | no |
Request/response example
POST /mixer/positioners/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
{
"viwi": "rockz.."
}
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok"
}
GET
Note:
Use a http GET request on /mixer/positioners/:uuid to retrieve a particular audioPositionerObject
Subscribe to /mixer/positioners/:uuid to receive updates on element level changes.
Request/response example
GET /mixer/positioners/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/positioners/3901a278-ba17-44d6-9aef-f7ca67c04840"
}
]
}
Events
This endpoint will not send any events. Therefor you can not register for them.
/mixer/equalizers/
Think of an equalizer as one single bar of a home stereos equalizer display. Every bar and thus equalizerObject inhere corresponds to a certain frequency and represents its level
equalizerObject
Properties
name | description | type | format | unit(s) | value(s) |
---|---|---|---|---|---|
id | identifier | string | uuid | - | |
name | equalizer name | string | - | ||
uri | object uri | string | uri | - | |
level | level | integer | decibel | [-12..12] | |
freq | frequency | integer | Hz | [-inf..inf] |
Resource level access (/mixer/equalizers/)
GET
Note: Use a http GET request on /mixer/equalizers/ to retrieve a list of available elements of type equalizerObject
Subscribe to /mixer/equalizers/ to receive updates for element creations or removals from the collection.
Request/response example
GET /mixer/equalizers/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
=>
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/equalizers/3901a278-ba17-44d6-9aef-f7ca67c04840"
},
{
"id": "8901870-b526-11e3-a5e2-0800200c9a66",
"name": "dolor sit",
"uri": "/mixer/equalizers/8901870-b526-11e3-a5e2-0800200c9a66"
}
]
}
Element level access (/mixer/equalizers/:uuid)
POST
Note:
Use a http POST request on /mixer/equalizers/:uuid to update a particular equalizerObject
Subscribe to /mixer/equalizers/:uuid to receive updates on element level changes.
Request parameters
The following parameters can be used with the request and subscriptions:
name | type | mandatory |
---|---|---|
level | integer | no |
freq | integer | no |
Request/response example
POST /mixer/equalizers/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
{
"viwi": "rockz.."
}
HTTP/1.1 201 Created
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok"
}
GET
Note:
Use a http GET request on /mixer/equalizers/:uuid to retrieve a particular equalizerObject
Subscribe to /mixer/equalizers/:uuid to receive updates on element level changes.
Request/response example
GET /mixer/equalizers/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/equalizers/3901a278-ba17-44d6-9aef-f7ca67c04840"
}
]
}
Events
This endpoint will not send any events. Therefor you can not register for them.
/mixer/bluetoothdevices/
provides access to the mapping of bluetooth device to audiosource. Mappings are created on system side and thus read only.
bluetoothdeviceObject
Properties
name | description | type | format | unit(s) | value(s) |
---|---|---|---|---|---|
id | identifier | string | uuid | - | |
name | device name | string | - | ||
uri | object uri | string | uri | - | |
audiosource | audio source | object | /mixer/audiosources/audioSourceObject | ||
mac | device mac address | string | macaddress | - |
Resource level access (/mixer/bluetoothdevices/)
GET
Note: Use a http GET request on /mixer/bluetoothdevices/ to retrieve a list of available elements of type bluetoothdeviceObject
Subscribe to /mixer/bluetoothdevices/ to receive updates for element creations or removals from the collection.
Request/response example
GET /mixer/bluetoothdevices/ HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
=>
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/bluetoothdevices/3901a278-ba17-44d6-9aef-f7ca67c04840"
},
{
"id": "8901870-b526-11e3-a5e2-0800200c9a66",
"name": "dolor sit",
"uri": "/mixer/bluetoothdevices/8901870-b526-11e3-a5e2-0800200c9a66"
}
]
}
Element level access (/mixer/bluetoothdevices/:uuid)
GET
Note:
Use a http GET request on /mixer/bluetoothdevices/:uuid to retrieve a particular bluetoothdeviceObject
Subscribe to /mixer/bluetoothdevices/:uuid to receive updates on element level changes.
Request/response example
GET /mixer/bluetoothdevices/3901a278-ba17-44d6-9aef-f7ca67c04840 HTTP/1.1
Host: 127.0.0.1:9000
Connection: keep-alive
Accept: application/json
User-Agent: Chrome/34.0.1847.137 Safari/537.36
Accept-Encoding: gzip,deflate
Accept-Language: en-US,en;q=0.8,de;q=0.6
HTTP/1.1 200 OK
Vary: Accept-Encoding
Content-Type: application/json; charset=utf-8
ETag: "-32550834"
Content-Encoding: gzip
Date: Tue, 07 Apr 1980 00:00:00 GMT
Connection: keep-alive
Transfer-Encoding: chunked
{
"status": "ok",
"data": [
{
"id": "3901a278-ba17-44d6-9aef-f7ca67c04840",
"name": "lorem ipsum",
"uri": "/mixer/bluetoothdevices/3901a278-ba17-44d6-9aef-f7ca67c04840"
}
]
}
Events
The following events may be fired by client interaction or system side:
- /mixer/bluetoothdevices/ (resource level)
- /mixer/bluetoothdevices/:uuid (element level)
