Media Source Extensions™

W3C Working Draft

More details about this document
This version:
https://www.w3.org/TR/2023/WD-media-source-2-20231102/
Latest published version:
https://www.w3.org/TR/media-source-2/
Latest editor's draft:
https://w3c.github.io/media-source/
History:
https://www.w3.org/standards/history/media-source-2/
Commit history
Latest Recommendation:
https://www.w3.org/TR/2016/REC-media-source-20161117/
Editors:
(Apple Inc.)
Mark Watson (Netflix Inc.)
(W3C Invited Expert)
Former editors:
Jerry Smith (Microsoft Corporation) (Until September 2017)
Aaron Colwell (Google Inc.) (Until April 2015)
Adrian Bateman (Microsoft Corporation) (Until April 2015)
Feedback:
GitHub w3c/media-source (pull requests, new issue, open issues)
public-media-wg@w3.org with subject line [media-source-2] … message topic … (archives)
Browser support:
caniuse.com

Abstract

This specification extends HTMLMediaElement [HTML] to allow JavaScript to generate media streams for playback. Allowing JavaScript to generate streams facilitates a variety of use cases like adaptive streaming and time shifting live streams.

Status of This Document

This section describes the status of this document at the time of its publication. A list of current W3C publications and the latest revision of this technical report can be found in the W3C technical reports index at https://www.w3.org/TR/.

On top of editorial updates, substantives changes since publication as a W3C Recommendation in November 2016 are the addition of a changeType() method to switch codecs, the possibility to create and use MediaSource objects off the main thread in dedicated workers, and the removal of the createObjectURL() extension to the URL object following its integration in the File API [FILEAPI]. For a full list of changes done since the previous version, see the commits.

The working group maintains a list of all bug reports that the editors have not yet tried to address.

Implementors should be aware that this specification is not stable. Implementors who are not taking part in the discussions are likely to find the specification changing out from under them in incompatible ways. Vendors interested in implementing this specification before it eventually reaches the Candidate Recommendation stage should track the GitHub repository and take part in the discussions.

This document was published by the Media Working Group as a Working Draft using the Recommendation track.

Publication as a Working Draft does not imply endorsement by W3C and its Members.

This is a draft document and may be updated, replaced or obsoleted by other documents at any time. It is inappropriate to cite this document as other than work in progress.

This document was produced by a group operating under the W3C Patent Policy. W3C maintains a public list of any patent disclosures made in connection with the deliverables of the group; that page also includes instructions for disclosing a patent. An individual who has actual knowledge of a patent which the individual believes contains Essential Claim(s) must disclose the information in accordance with section 6 of the W3C Patent Policy.

This document is governed by the 12 June 2023 W3C Process Document.

1. Introduction

This section is non-normative.

This specification allows JavaScript to dynamically construct media streams for <audio> and <video>. It defines a MediaSource object that can serve as a source of media data for an HTMLMediaElement. MediaSource objects have one or more SourceBuffer objects. Applications append data segments to the SourceBuffer objects, and can adapt the quality of appended data based on system performance and other factors. Data from the SourceBuffer objects is managed as track buffers for audio, video and text data that is decoded and played. Byte stream specifications used with these extensions are available in the byte stream format registry [MSE-REGISTRY].

Media Source Pipeline Model Diagram

1.1 Goals

This specification was designed with the following goals in mind:

This specification defines:

1.2 Definitions

Active Track Buffers

The track buffers that provide coded frames for the enabled audioTracks, the selected videoTracks, and the "showing" or "hidden" textTracks. All these tracks are associated with SourceBuffer objects in the activeSourceBuffers list.

Append Window

A presentation timestamp range used to filter out coded frames while appending. The append window represents a single continuous time range with a single start time and end time. Coded frames with presentation timestamp within this range are allowed to be appended to the SourceBuffer while coded frames outside this range are filtered out. The append window start and end times are controlled by the appendWindowStart and appendWindowEnd attributes respectively.

Coded Frame

A unit of media data that has a presentation timestamp, a decode timestamp, and a coded frame duration.

Coded Frame Duration

The duration of a coded frame. For video and text, the duration indicates how long the video frame or text SHOULD be displayed. For audio, the duration represents the sum of all the samples contained within the coded frame. For example, if an audio frame contained 441 samples @44100Hz the frame duration would be 10 milliseconds.

Coded Frame End Timestamp

The sum of a coded frame presentation timestamp and its coded frame duration. It represents the presentation timestamp that immediately follows the coded frame.

Coded Frame Group

A group of coded frames that are adjacent and have monotonically increasing decode timestamps without any gaps. Discontinuities detected by the coded frame processing algorithm and abort() calls trigger the start of a new coded frame group.

Decode Timestamp

The decode timestamp indicates the latest time at which the frame needs to be decoded assuming instantaneous decoding and rendering of this and any dependant frames (this is equal to the presentation timestamp of the earliest frame, in presentation order, that is dependant on this frame). If frames can be decoded out of presentation order, then the decode timestamp MUST be present in or derivable from the byte stream. The user agent MUST run the append error algorithm if this is not the case. If frames cannot be decoded out of presentation order and a decode timestamp is not present in the byte stream, then the decode timestamp is equal to the presentation timestamp.

Initialization Segment

A sequence of bytes that contain all of the initialization information required to decode a sequence of media segments. This includes codec initialization data, Track ID mappings for multiplexed segments, and timestamp offsets (e.g., edit lists).

Note

The byte stream format specifications in the byte stream format registry [MSE-REGISTRY] contain format specific examples.

Media Segment

A sequence of bytes that contain packetized & timestamped media data for a portion of the media timeline. Media segments are always associated with the most recently appended initialization segment.

Note

The byte stream format specifications in the byte stream format registry [MSE-REGISTRY] contain format specific examples.

MediaSource object URL

A MediaSource object URL is a unique Blob URI [FILEAPI] created by createObjectURL(). It is used to attach a MediaSource object to an HTMLMediaElement.

These URLs are the same as a Blob URI, except that anything in the definition of that feature that refers to File and Blob objects is hereby extended to also apply to MediaSource objects.

The origin of the MediaSource object URL is the relevant settings object of this during the call to createObjectURL().

Note

For example, the origin of the MediaSource object URL affects the way that the media element is consumed by canvas.

Parent Media Source

The parent media source of a SourceBuffer object is the MediaSource object that created it.

Presentation Start Time

The presentation start time is the earliest time point in the presentation and specifies the initial playback position and earliest possible position. All presentations created using this specification have a presentation start time of 0.

Note

For the purposes of determining if HTMLMediaElement.buffered contains a TimeRanges that includes the current playback position, implementations MAY choose to allow a current playback position at or after presentation start time and before the first TimeRanges to play the first TimeRanges if that TimeRanges starts within a reasonably short time, like 1 second, after presentation start time. This allowance accommodates the reality that muxed streams commonly do not begin all tracks precisely at presentation start time. Implementations MUST report the actual buffered range, regardless of this allowance.

Presentation Interval

The presentation interval of a coded frame is the time interval from its presentation timestamp to the presentation timestamp plus the coded frame's duration. For example, if a coded frame has a presentation timestamp of 10 seconds and a coded frame duration of 100 milliseconds, then the presentation interval would be [10-10.1). Note that the start of the range is inclusive, but the end of the range is exclusive.

Presentation Order

The order that coded frames are rendered in the presentation. The presentation order is achieved by ordering coded frames in monotonically increasing order by their presentation timestamps.

Presentation Timestamp

A reference to a specific time in the presentation. The presentation timestamp in a coded frame indicates when the frame SHOULD be rendered.

Random Access Point

A position in a media segment where decoding and continuous playback can begin without relying on any previous data in the segment. For video this tends to be the location of I-frames. In the case of audio, most audio frames can be treated as a random access point. Since video tracks tend to have a more sparse distribution of random access points, the location of these points are usually considered the random access points for multiplexed streams.

SourceBuffer byte stream format specification

The specific byte stream format specification that describes the format of the byte stream accepted by a SourceBuffer instance. The byte stream format specification, for a SourceBuffer object, is initially selected based on the type passed to the addSourceBuffer() call that created the object, and can be updated by changeType() calls on the object.

SourceBuffer configuration

A specific set of tracks distributed across one or more SourceBuffer objects owned by a single MediaSource instance.

Implementations MUST support at least 1 MediaSource object with the following configurations:

  • A single SourceBuffer with 1 audio track and/or 1 video track.
  • Two SourceBuffers with one handling a single audio track and the other handling a single video track.

MediaSource objects MUST support each of the configurations above, but they are only required to support one configuration at a time. Supporting multiple configurations at once or additional configurations is a quality of implementation issue.

Track Description

A byte stream format specific structure that provides the Track ID, codec configuration, and other metadata for a single track. Each track description inside a single initialization segment has a unique Track ID. The user agent MUST run the append error algorithm if the Track ID is not unique within the initialization segment.

Track ID

A Track ID is a byte stream format specific identifier that marks sections of the byte stream as being part of a specific track. The Track ID in a track description identifies which sections of a media segment belong to that track.

2. MediaSource Object

The MediaSource object represents a source of media data for an HTMLMediaElement. It keeps track of the readyState for this source as well as a list of SourceBuffer objects that can be used to add media data to the presentation. MediaSource objects are created by the web application and then attached to an HTMLMediaElement. The application uses the SourceBuffer objects in sourceBuffers to add media data to this source. The HTMLMediaElement fetches this media data from the MediaSource object when it is needed during playback.

Each MediaSource object has a [[live seekable range]] internal slot that stores a normalized TimeRanges object. It is initialized to an empty TimeRanges object when the MediaSource object is created, is maintained by setLiveSeekableRange() and clearLiveSeekableRange(), and is used in 6. HTMLMediaElement Extensions to modify HTMLMediaElement.seekable behavior.

Each MediaSource object has a [[has ever been attached]] internal slot that stores a boolean. It is initialized to false when the MediaSource object is created, and is set true in the extended HTMLMediaElement's resource fetch algorithm as described in the attaching to a media element algorithm. The extended resource fetch algorithm uses this internal slot to conditionally fail attachment of a MediaSource using a MediaSourceHandle set on a HTMLMediaElement's srcObject attribute.

WebIDLenum ReadyState {
  "closed",
  "open",
  "ended",
};
closed
Indicates the source is not currently attached to a media element.
open
The source has been opened by a media element and is ready for data to be appended to the SourceBuffer objects in MediaSource's sourceBuffers.
ended
The source is still attached to a media element, but MediaSource's endOfStream() has been called.
Issue 276: MSE-in-Workers: Consider adding a "closing" readyState to explain new `InvalidStateError` exception when closing underway
WebIDLenum EndOfStreamError {
  "network",
  "decode",
};
network

Terminates playback and signals that a network error has occurred.

Note

JavaScript applications SHOULD use this status code to terminate playback with a network error. For example, if a network error occurs while fetching media data.

decode

Terminates playback and signals that a decoding error has occurred.

Note

JavaScript applications SHOULD use this status code to terminate playback with a decode error. For example, if a parsing error occurs while processing out-of-band media data.

WebIDL[Exposed=(Window,DedicatedWorker)]
interface MediaSource : EventTarget {
    constructor();

    [ SameObject, Exposed=DedicatedWorker ]
    readonly              attribute MediaSourceHandle   handle;

    readonly              attribute SourceBufferList    sourceBuffers;
    readonly              attribute SourceBufferList    activeSourceBuffers;
    readonly              attribute ReadyState          readyState;
                          attribute unrestricted double duration;
                          attribute EventHandler        onsourceopen;
                          attribute EventHandler        onsourceended;
                          attribute EventHandler        onsourceclose;
    static readonly       attribute boolean canConstructInDedicatedWorker;
    SourceBuffer          addSourceBuffer (DOMString type);
    undefined             removeSourceBuffer (SourceBuffer sourceBuffer);
    undefined             endOfStream (optional EndOfStreamError error);
    undefined             setLiveSeekableRange (double start, double end);
    undefined             clearLiveSeekableRange ();
    static boolean        isTypeSupported (DOMString type);
};

2.1 Attributes

handle of type MediaSourceHandle, [SameObject] readonly

Contains a handle useful for attachment of a dedicated worker MediaSource object to an HTMLMediaElement via srcObject. The handle remains the same object for this MediaSource object across accesses of this attribute, but it is distinct for each MediaSource object.

Note

This specification may eventually enable visibility of this attribute on MediaSource objects on the main Window context. If so, specification care will be necessary to prevent potential backwards incompatible changes, such as could happen if exceptions were thrown on accesses to this attribute.

On getting, run the following steps:

  1. If the handle for this MediaSource object has not yet been created, then run the following steps:
    1. Let created handle be the result of creating a new MediaSourceHandle object and associated resources, linked internally to this MediaSource.
    2. Update the attribute to be created handle.
  2. Return the MediaSourceHandle object that is this attribute's value.
sourceBuffers of type SourceBufferList, readonly
Contains the list of SourceBuffer objects associated with this MediaSource. When readyState equals "closed" this list will be empty. Once readyState transitions to "open" SourceBuffer objects can be added to this list by using addSourceBuffer().
activeSourceBuffers of type SourceBufferList, readonly

Contains the subset of sourceBuffers that are providing the selected video track, the enabled audio track(s), and the "showing" or "hidden" text track(s).

SourceBuffer objects in this list MUST appear in the same order as they appear in the sourceBuffers attribute; e.g., if only sourceBuffers[0] and sourceBuffers[3] are in activeSourceBuffers, then activeSourceBuffers[0] MUST equal sourceBuffers[0] and activeSourceBuffers[1] MUST equal sourceBuffers[3].

Note

Section 2.5.5 Changes to selected/enabled track state describes how this attribute gets updated.

readyState of type ReadyState, readonly

Indicates the current state of the MediaSource object. When the MediaSource is created readyState MUST be set to "closed".

duration of type unrestricted double

Allows the web application to set the presentation duration. The duration is initially set to NaN when the MediaSource object is created.

On getting, run the following steps:

  1. If the readyState attribute is "closed" then return NaN and abort these steps.
  2. Return the current value of the attribute.

On setting, run the following steps:

  1. If the value being set is negative or NaN then throw a TypeError exception and abort these steps.
  2. If the readyState attribute is not "open" then throw an InvalidStateError exception and abort these steps.
  3. If the updating attribute equals true on any SourceBuffer in sourceBuffers, then throw an InvalidStateError exception and abort these steps.
  4. Run the duration change algorithm with new duration set to the value being assigned to this attribute.
    Note

    The duration change algorithm will adjust new duration higher if there is any currently buffered coded frame with a higher end time.

    Note

    appendBuffer() and endOfStream() can update the duration under certain circumstances.

onsourceopen of type EventHandler

The event handler for the sourceopen event.

onsourceended of type EventHandler

The event handler for the sourceended event.

onsourceclose of type EventHandler

The event handler for the sourceclose event.

canConstructInDedicatedWorker of type boolean

Returns true.

Note

This attribute enables main thread and dedicated worker feature detection of support for creating and using a MediaSource object in a dedicated worker, and mitigates the need for higher latency detection polyfills like attempting creation of a MediaSource object from a dedicated worker, especially if the feature is not supported.

2.2 Methods

addSourceBuffer

Adds a new SourceBuffer to sourceBuffers.

ParameterTypeNullableOptionalDescription
typeDOMString
Return type: SourceBuffer

When this method is invoked, the user agent must run the following steps:

  1. If type is an empty string then throw a TypeError exception and abort these steps.
  2. If type contains a MIME type that is not supported or contains a MIME type that is not supported with the types specified for the other SourceBuffer objects in sourceBuffers, then throw a NotSupportedError exception and abort these steps.
  3. If the user agent can't handle any more SourceBuffer objects or if creating a SourceBuffer based on type would result in an unsupported SourceBuffer configuration, then throw a QuotaExceededError exception and abort these steps.
    Note

    For example, a user agent MAY throw a QuotaExceededError exception if the media element has reached the HAVE_METADATA readyState. This can occur if the user agent's media engine does not support adding more tracks during playback.

  4. If the readyState attribute is not in the "open" state then throw an InvalidStateError exception and abort these steps.
  5. Create a new SourceBuffer object and associated resources.
  6. Set the [[generate timestamps flag]] on the new object to the value in the "Generate Timestamps Flag" column of the byte stream format registry [MSE-REGISTRY] entry that is associated with type.
  7. If the [[generate timestamps flag]] equals true:
    Set the mode attribute on the new object to "sequence".
    Otherwise:
    Set the mode attribute on the new object to "segments".
  8. Add the new object to sourceBuffers and queue a task to fire an event named addsourcebuffer at sourceBuffers.
  9. Return the new object.
removeSourceBuffer

Removes a SourceBuffer from sourceBuffers.

ParameterTypeNullableOptionalDescription
sourceBufferSourceBuffer
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. If sourceBuffer specifies an object that is not in sourceBuffers then throw a NotFoundError exception and abort these steps.
  2. If the sourceBuffer.updating attribute equals true, then run the following steps:
    1. Abort the buffer append algorithm if it is running.
    2. Set the sourceBuffer.updating attribute to false.
    3. Queue a task to fire an event named abort at sourceBuffer.
    4. Queue a task to fire an event named updateend at sourceBuffer.
  3. Let SourceBuffer audioTracks list equal the AudioTrackList object returned by sourceBuffer.audioTracks.
  4. If the SourceBuffer audioTracks list is not empty, then run the following steps:
    1. For each AudioTrack object in the SourceBuffer audioTracks list, run the following steps:
      1. Set the sourceBuffer attribute on the AudioTrack object to null.
      2. Remove the AudioTrack object from the SourceBuffer audioTracks list.
        Note

        This should trigger AudioTrackList [HTML] logic to queue a task to fire an event named removetrack using TrackEvent with the track attribute initialized to the AudioTrack object, at the SourceBuffer audioTracks list. If the enabled attribute on the AudioTrack object was true at the beginning of this removal step, then this should also trigger AudioTrackList [HTML] logic to queue a task to fire an event named change at the SourceBuffer audioTracks list.

      3. Use the mirror if necessary algorithm to run the following steps in Window, to remove the AudioTrack object (or instead, the Window mirror of it if the MediaSource object was constructed in a DedicatedWorkerGlobalScope) from the media element:
        1. Let HTMLMediaElement audioTracks list equal the AudioTrackList object returned by the audioTracks attribute on the HTMLMediaElement.
        2. Remove the AudioTrack object from the HTMLMediaElement audioTracks list.
          Note

          This should trigger AudioTrackList [HTML] logic to queue a task to fire an event named removetrack using TrackEvent with the track attribute initialized to the AudioTrack object, at the HTMLMediaElement audioTracks list. If the enabled attribute on the AudioTrack object was true at the beginning of this removal step, then this should also trigger AudioTrackList [HTML] logic to queue a task to fire an event named change at the HTMLMediaElement audioTracks list.

  5. Let SourceBuffer videoTracks list equal the VideoTrackList object returned by sourceBuffer.videoTracks.
  6. If the SourceBuffer videoTracks list is not empty, then run the following steps:
    1. For each VideoTrack object in the SourceBuffer videoTracks list, run the following steps:
      1. Set the sourceBuffer attribute on the VideoTrack object to null.
      2. Remove the VideoTrack object from the SourceBuffer videoTracks list.
        Note

        This should trigger VideoTrackList [HTML] logic to queue a task to fire an event named removetrack using TrackEvent with the track attribute initialized to the VideoTrack object, at the SourceBuffer videoTracks list. If the selected attribute on the VideoTrack object was true at the beginning of this removal step, then this should also trigger VideoTrackList [HTML] logic to queue a task to fire an event named change at the SourceBuffer videoTracks list.

      3. Use the mirror if necessary algorithm to run the following steps in Window, to remove the VideoTrack object (or instead, the Window mirror of it if the MediaSource object was constructed in a DedicatedWorkerGlobalScope) from the media element:
        1. Let HTMLMediaElement videoTracks list equal the VideoTrackList object returned by the videoTracks attribute on the HTMLMediaElement.
        2. Remove the VideoTrack object from the HTMLMediaElement videoTracks list.
          Note

          This should trigger VideoTrackList [HTML] logic to queue a task to fire an event named removetrack using TrackEvent with the track attribute initialized to the VideoTrack object, at the HTMLMediaElement videoTracks list. If the selected attribute on the VideoTrack object was true at the beginning of this removal step, then this should also trigger VideoTrackList [HTML] logic to queue a task to fire an event named change at the HTMLMediaElement videoTracks list.

  7. Let SourceBuffer textTracks list equal the TextTrackList object returned by sourceBuffer.textTracks.
  8. If the SourceBuffer textTracks list is not empty, then run the following steps:
    1. For each TextTrack object in the SourceBuffer textTracks list, run the following steps:
      1. Set the sourceBuffer attribute on the TextTrack object to null.
      2. Remove the TextTrack object from the SourceBuffer textTracks list.
        Note

        This should trigger TextTrackList [HTML] logic to queue a task to fire an event named removetrack using TrackEvent with the track attribute initialized to the TextTrack object, at the SourceBuffer textTracks list. If the mode attribute on the TextTrack object was "showing" or "hidden" at the beginning of this removal step, then this should also trigger TextTrackList [HTML] logic to queue a task to fire an event named change at the SourceBuffer textTracks list.

      3. Use the mirror if necessary algorithm to run the following steps in Window, to remove the TextTrack object (or instead, the Window mirror of it if the MediaSource object was constructed in a DedicatedWorkerGlobalScope) from the media element:
        1. Let HTMLMediaElement textTracks list equal the TextTrackList object returned by the textTracks attribute on the HTMLMediaElement.
        2. Remove the TextTrack object from the HTMLMediaElement textTracks list.
          Note

          This should trigger TextTrackList [HTML] logic to queue a task to fire an event named removetrack using TrackEvent with the track attribute initialized to the TextTrack object, at the HTMLMediaElement textTracks list. If the mode attribute on the TextTrack object was "showing" or "hidden" at the beginning of this removal step, then this should also trigger TextTrackList [HTML] logic to queue a task to fire an event named change at the HTMLMediaElement textTracks list.

  9. If sourceBuffer is in activeSourceBuffers, then remove sourceBuffer from activeSourceBuffers and queue a task to fire an event named removesourcebuffer at the SourceBufferList returned by activeSourceBuffers.
  10. Remove sourceBuffer from sourceBuffers and queue a task to fire an event named removesourcebuffer at the SourceBufferList returned by sourceBuffers.
  11. Destroy all resources for sourceBuffer.
endOfStream

Signals the end of the stream.

ParameterTypeNullableOptionalDescription
errorEndOfStreamError
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. If the readyState attribute is not in the "open" state then throw an InvalidStateError exception and abort these steps.
  2. If the updating attribute equals true on any SourceBuffer in sourceBuffers, then throw an InvalidStateError exception and abort these steps.
  3. Run the end of stream algorithm with the error parameter set to error.
setLiveSeekableRange

Updates [[live seekable range]] that is used in section 6. HTMLMediaElement Extensions to modify HTMLMediaElement.seekable behavior.

Parameter Type Nullable Optional Description
start double The start of the range, in seconds measured from presentation start time. While set, and if duration equals positive Infinity, HTMLMediaElement.seekable will return a non-empty TimeRanges object with a lowest range start timestamp no greater than start.
end double The end of range, in seconds measured from presentation start time. While set, and if duration equals positive Infinity, HTMLMediaElement.seekable will return a non-empty TimeRanges object with a highest range end timestamp no less than end.
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. If the readyState attribute is not "open" then throw an InvalidStateError exception and abort these steps.
  2. If start is negative or greater than end, then throw a TypeError exception and abort these steps.
  3. Set [[live seekable range]] to be a new normalized TimeRanges object containing a single range whose start position is start and end position is end.
clearLiveSeekableRange

Updates [[live seekable range]] that is used in section 6. HTMLMediaElement Extensions to modify HTMLMediaElement.seekable behavior.

No parameters.
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. If the readyState attribute is not "open" then throw an InvalidStateError exception and abort these steps.
  2. If [[live seekable range]] contains a range, then set [[live seekable range]] to be a new empty TimeRanges object.
isTypeSupported, static

Check to see whether the MediaSource is capable of creating SourceBuffer objects for the specified MIME type.

Note

If true is returned from this method, it only indicates that the MediaSource implementation is capable of creating SourceBuffer objects for the specified MIME type. An addSourceBuffer() call SHOULD still fail if sufficient resources are not available to support the addition of a new SourceBuffer.

Note

This method returning true implies that HTMLMediaElement.canPlayType() will return "maybe" or "probably" since it does not make sense for a MediaSource to support a type the HTMLMediaElement knows it cannot play.

ParameterTypeNullableOptionalDescription
typeDOMString
Return type: boolean

When this method is invoked, the user agent must run the following steps:

  1. If type is an empty string, then return false.
  2. If type does not contain a valid MIME type string, then return false.
  3. If type contains a media type or media subtype that the MediaSource does not support, then return false.
  4. If type contains a codec that the MediaSource does not support, then return false.
  5. If the MediaSource does not support the specified combination of media type, media subtype, and codecs then return false.
  6. Return true.

2.3 Event Summary

Event name Interface Dispatched when...
sourceopen Event MediaSource's readyState transitions from "closed" to "open" or from "ended" to "open".
sourceended Event MediaSource's readyState transitions from "open" to "ended".
sourceclose Event MediaSource's readyState transitions from "open" to "closed" or "ended" to "closed".

2.4 Cross-context communication model

When a Window HTMLMediaElement is attached to a DedicatedWorkerGlobalScope MediaSource, each context has algorithms that depend on information from the other.

Note

HTMLMediaElement is exposed only to Window contexts, but MediaSource and related objects defined in this specification are exposed in Window and DedicatedWorkerGlobalScope contexts. This lets applications construct a MediaSource object in either of those types of context and attach it to an HTMLMediaElement object in a Window context using a MediaSource object URL or a MediaSourceHandle as described in the attaching to a media element algorithm. A MediaSource object is not Transferable; it is only visible in the context where it was created.

The rest of this section describes a model for bounding information latency for attachments of a Window media element to a DedicatedWorkerGlobalScope MediaSource. While the model describes communication using message passing, implementations MAY choose to communicate in potentially faster ways, such as using shared memory and locks. Attachments to a Window MediaSource synchronously have the information already without communicating it across contexts.

A MediaSource that is constructed in a DedicatedWorkerGlobalScope has a [[port to main]] internal slot that stores a MessagePort setup during attachment and nulled during detachment. A Window [[port to main]] is always null.

An HTMLMediaElement extended by this specification and attached to a DedicatedWorkerGlobalScope MediaSource similarly has a [[port to worker]] internal slot that stores a MessagePort and a [[channel with worker]] internal slot that stores a MessageChannel, both setup during attachment and nulled during detachment. Both [[port to worker]] and [[channel with worker]] are null unless attached to a DedicatedWorkerGlobalScope MediaSource.

Algorithms in this specification that need to communicate information from a Window HTMLMediaElement to an attached DedicatedWorkerGlobalScope MediaSource, or vice versa, will use these internal ports implicitly to post a message to their counterpart, where the implicit handler of the message runs steps as described in the algorithms.

2.5 Algorithms

2.5.1 Attaching to a media element

There are distinct mechanisms for attaching a MediaSource to a media element depending on where the MediaSource object was constructed, in a Window versus in a DedicatedWorkerGlobalScope:

If the resource fetch algorithm was invoked with a media provider object that is a MediaSource object, a MediaSourceHandle object or a URL record whose object is a MediaSource object, then let mode be local, skip the first step in the resource fetch algorithm (which may otherwise set mode to remote) and continue the execution of the resource fetch algorithm.

Note

The first step of the resource fetch algorithm is expected to eventually align with selecting local mode for URL records whose objects are media provider objects. The intent is that if the HTMLMediaElement's src attribute or selected child <source>'s src attribute is a blob: URL matching a MediaSource object URL when the respective src attribute was last changed, then that MediaSource object is used as the media provider object and current media resource in the local mode logic in the resource fetch algorithm. This also means that the remote mode logic that includes observance of any preload attribute is skipped when a MediaSource object is attached. Even with that eventual change to [HTML], the execution of the following steps at the beginning of the local mode logic is still required when the current media resource is a MediaSource object.

At the beginning of the "Otherwise (mode is local)" section of the resource fetch algorithm, execute the additional steps, below.

Note

Relative to the action which triggered the media element's resource selection algorithm, these steps are asynchronous. The resource fetch algorithm is run after the task that invoked the resource selection algorithm is allowed to continue and a stable state is reached. Implementations may delay the steps in the "Otherwise" clause, below, until the MediaSource object is ready for use.

  1. If the resource fetch algorithm was invoked with a media provider object that is a MediaSource object, a MediaSourceHandle object or a URL record whose object is a MediaSource object, then:
    If the media provider object is a URL record whose object is a MediaSource that was constructed in a DedicatedWorkerGlobalScope, such as would occur if attempting to use a MediaSource object URL from a DedicatedWorkerGlobalScope MediaSource
    Run the "If the media data cannot be fetched at all, due to network errors, causing the user agent to give up trying to fetch the resource" steps of the resource fetch algorithm's media data processing steps list.
    Note
    This prevents using MediaSource object URLs for DedicatedWorker MediaSource attachments. Transferring MediaSource.handle from the DedicatedWorker to the Window context and assigning it to the media element's srcObject attribute is the only way to attach such a MediaSource.
    If the media provider object is a MediaSourceHandle whose [[Detached]] internal slot is true
    Run the "If the media data cannot be fetched at all, due to network errors, causing the user agent to give up trying to fetch the resource" steps of the resource fetch algorithm's media data processing steps list.
    If the media provider object is a MediaSourceHandle whose underlying MediaSource's [[has ever been attached]] internal slot is true
    Run the "If the media data cannot be fetched at all, due to network errors, causing the user agent to give up trying to fetch the resource" steps of the resource fetch algorithm's media data processing steps list.
    Note
    This prevents loading an underlying MediaSource more than once using a MediaSourceHandle, even if the MediaSource was constructed on Window and had been loaded previously using a MediaSource object URL. This doesn't preclude subsequent use of a MediaSource object URL for a Window MediaSource from succeeding though.
    If readyState is NOT set to "closed"
    Run the "If the media data cannot be fetched at all, due to network errors, causing the user agent to give up trying to fetch the resource" steps of the resource fetch algorithm's media data processing steps list.
    Otherwise
    1. Set the MediaSource's [[has ever been attached]] internal slot to true.
    2. Set the media element's delaying-the-load-event-flag to false.
    3. If the MediaSource was constructed in a DedicatedWorkerGlobalScope, then setup worker attachment communication and open the MediaSource:
      1. Set [[channel with worker]] to be a new MessageChannel.
      2. Set [[port to worker]] to the port1 value of [[channel with worker]].
      3. Execute StructuredSerializeWithTransfer with the port2 of [[channel with worker]] as both the value and the sole member of the transferList, and let the result be serialized port2.
      4. Queue a task on the MediaSource's DedicatedWorkerGlobalScope that will
        1. Execute StructuredDeserializeWithTransfer with serialized port2 and DedicatedWorkerGlobalScope's realm, and set [[port to main]] to be the resulting deserialized clone of the transferred port2 value of [[channel with worker]].
        2. Set the readyState attribute to "open".
        3. Queue a task to fire an event named sourceopen at the MediaSource.
      Otherwise, the MediaSource was constructed in a Window:
      1. Set [[channel with worker]] null.
      2. Set [[port to worker]] null.
      3. Set [[port to main]] null.
      4. Set the readyState attribute to "open".
      5. Queue a task to fire an event named sourceopen at the MediaSource.
    4. Continue the resource fetch algorithm by running the remaining "Otherwise (mode is local)" steps, with these requirements:
      1. Text in the resource fetch algorithm or the media data processing steps list that refers to "the download", "bytes received", or "whenever new data for the current media resource becomes available" refers to data passed in via appendBuffer().
      2. References to HTTP in the resource fetch algorithm and the media data processing steps list shall not apply because the HTMLMediaElement does not fetch media data via HTTP when a MediaSource is attached.
Note

An attached MediaSource does not use the remote mode steps in the resource fetch algorithm, so the media element will not fire "suspend" events. Though future versions of this specification will likely remove "progress" and "stalled" events from a media element with an attached MediaSource, user agents conforming to this version of the specification may still fire these two events as these [HTML] references changed after implementations of this specification stabilized.

2.5.2 Detaching from a media element

The following steps are run in any case where the media element is going to transition to NETWORK_EMPTY and queue a task to fire an event named emptied at the media element. These steps SHOULD be run right before the transition.

  1. If the MediaSource was constructed in a DedicatedWorkerGlobalScope:
    1. Notify the MediaSource using an internal detach message posted to [[port to worker]].
    2. Set [[port to worker]] null.
    3. Set [[channel with worker]] null.
    4. The implicit message handler for this detach notification runs the remainder of these steps in the DedicatedWorkerGlobalScope MediaSource.
    Otherwise, the MediaSource was constructed in a Window:
    Continue the remainder of these steps on the Window MediaSource.
  2. Set [[port to main]] null.
  3. Set the readyState attribute to "closed".
  4. Update duration to NaN.
  5. Remove all the SourceBuffer objects from activeSourceBuffers.
  6. Queue a task to fire an event named removesourcebuffer at activeSourceBuffers.
  7. Remove all the SourceBuffer objects from sourceBuffers.
  8. Queue a task to fire an event named removesourcebuffer at sourceBuffers.
  9. Queue a task to fire an event named sourceclose at the MediaSource.
Note

Going forward, this algorithm is intended to be externally called and run in any case where the attached MediaSource, if any, must be detached from the media element. It MAY be called on HTMLMediaElement [HTML] operations like load() and resource fetch algorithm failures in addition to, or in place of, when the media element transitions to NETWORK_EMPTY. Resource fetch algorithm failures are those which abort either the resource fetch algorithm or the resource selection algorithm, with the exception that the "Final step" [HTML] is not considered a failure that triggers detachment.

2.5.3 Seeking

Run the following steps as part of the "Wait until the user agent has established whether or not the media data for the new playback position is available, and, if it is, until it has decoded enough data to play back that position" step of the seek algorithm:

  1. Note

    The media element looks for media segments containing the new playback position in each SourceBuffer object in activeSourceBuffers. Any position within a TimeRanges in the current value of the HTMLMediaElement.buffered attribute has all necessary media segments buffered for that position.

    If new playback position is not in any TimeRanges of HTMLMediaElement.buffered
    1. If the HTMLMediaElement.readyState attribute is greater than HAVE_METADATA, then set the HTMLMediaElement.readyState attribute to HAVE_METADATA.
      Note

      Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

    2. The media element waits until an appendBuffer() call causes the coded frame processing algorithm to set the HTMLMediaElement.readyState attribute to a value greater than HAVE_METADATA.
      Note

      The web application can use buffered and HTMLMediaElement.buffered to determine what the media element needs to resume playback.

    Otherwise
    Continue
    Note

    If the readyState attribute is "ended" and the new playback position is within a TimeRanges currently in HTMLMediaElement.buffered, then the seek operation must continue to completion here even if one or more currently selected or enabled track buffers' largest range end timestamp is less than new playback position. This condition should only occur due to logic in buffered when readyState is "ended".

  2. The media element resets all decoders and initializes each one with data from the appropriate initialization segment.
  3. The media element feeds coded frames from the active track buffers into the decoders starting with the closest random access point before the new playback position.
  4. Resume the seek algorithm at the "Await a stable state" step.

2.5.4 SourceBuffer Monitoring

The following steps are periodically run during playback to make sure that all of the SourceBuffer objects in activeSourceBuffers have enough data to ensure uninterrupted playback. Changes to activeSourceBuffers also cause these steps to run because they affect the conditions that trigger state transitions.

Having enough data to ensure uninterrupted playback is an implementation specific condition where the user agent determines that it currently has enough data to play the presentation without stalling for a meaningful period of time. This condition is constantly evaluated to determine when to transition the media element into and out of the HAVE_ENOUGH_DATA ready state. These transitions indicate when the user agent believes it has enough data buffered or it needs more data respectively.

Note

An implementation MAY choose to use bytes buffered, time buffered, the append rate, or any other metric it sees fit to determine when it has enough data. The metrics used MAY change during playback so web applications SHOULD only rely on the value of HTMLMediaElement.readyState to determine whether more data is needed or not.

Note

When the media element needs more data, the user agent SHOULD transition it from HAVE_ENOUGH_DATA to HAVE_FUTURE_DATA early enough for a web application to be able to respond without causing an interruption in playback. For example, transitioning when the current playback position is 500ms before the end of the buffered data gives the application roughly 500ms to append more data before playback stalls.

If the HTMLMediaElement.readyState attribute equals HAVE_NOTHING:
  1. Abort these steps.
If HTMLMediaElement.buffered does not contain a TimeRanges for the current playback position:
  1. Set the HTMLMediaElement.readyState attribute to HAVE_METADATA.
    Note

    Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  2. Abort these steps.
If HTMLMediaElement.buffered contains a TimeRanges that includes the current playback position and enough data to ensure uninterrupted playback:
  1. Set the HTMLMediaElement.readyState attribute to HAVE_ENOUGH_DATA.
    Note

    Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  2. Playback may resume at this point if it was previously suspended by a transition to HAVE_CURRENT_DATA.
  3. Abort these steps.
If HTMLMediaElement.buffered contains a TimeRanges that includes the current playback position and some time beyond the current playback position, then run the following steps:
  1. Set the HTMLMediaElement.readyState attribute to HAVE_FUTURE_DATA.
    Note

    Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  2. Playback may resume at this point if it was previously suspended by a transition to HAVE_CURRENT_DATA.
  3. Abort these steps.
If HTMLMediaElement.buffered contains a TimeRanges that ends at the current playback position and does not have a range covering the time immediately after the current position:
  1. Set the HTMLMediaElement.readyState attribute to HAVE_CURRENT_DATA.
    Note

    Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  2. Playback is suspended at this point since the media element doesn't have enough data to advance the media timeline.
  3. Abort these steps.

2.5.5 Changes to selected/enabled track state

During playback activeSourceBuffers needs to be updated if the selected video track, the enabled audio track(s), or a text track mode changes. When one or more of these changes occur the following steps need to be followed. Also, when MediaSource was constructed in a DedicatedWorkerGlobalScope, then each change that occurs to a Window mirror of a track created previously by the implicit handler for the internal create track mirror message MUST also be made to the corresponding DedicatedWorkerGlobalScope track using an internal update track state message posted to [[port to worker]] whose implicit handler makes the change and runs the following steps. Likewise, each change that occurs to a DedicatedWorkerGlobalScope track MUST also be made to the corresponding Window mirror of the track using an internal update track state message posted to [[port to main]] whose implicit handler makes the change to the mirror.

If the selected video track changes, then run the following steps:
  1. If the SourceBuffer associated with the previously selected video track is not associated with any other enabled tracks, run the following steps:
    1. Remove the SourceBuffer from activeSourceBuffers.
    2. Queue a task to fire an event named removesourcebuffer at activeSourceBuffers
  2. If the SourceBuffer associated with the newly selected video track is not already in activeSourceBuffers, run the following steps:
    1. Add the SourceBuffer to activeSourceBuffers.
    2. Queue a task to fire an event named addsourcebuffer at activeSourceBuffers
If an audio track becomes disabled and the SourceBuffer associated with this track is not associated with any other enabled or selected track, then run the following steps:
  1. Remove the SourceBuffer associated with the audio track from activeSourceBuffers
  2. Queue a task to fire an event named removesourcebuffer at activeSourceBuffers
If an audio track becomes enabled and the SourceBuffer associated with this track is not already in activeSourceBuffers, then run the following steps:
  1. Add the SourceBuffer associated with the audio track to activeSourceBuffers
  2. Queue a task to fire an event named addsourcebuffer at activeSourceBuffers
If a text track mode becomes "disabled" and the SourceBuffer associated with this track is not associated with any other enabled or selected track, then run the following steps:
  1. Remove the SourceBuffer associated with the text track from activeSourceBuffers
  2. Queue a task to fire an event named removesourcebuffer at activeSourceBuffers
If a text track mode becomes "showing" or "hidden" and the SourceBuffer associated with this track is not already in activeSourceBuffers, then run the following steps:
  1. Add the SourceBuffer associated with the text track to activeSourceBuffers
  2. Queue a task to fire an event named addsourcebuffer at activeSourceBuffers

2.5.6 Duration change

Follow these steps when duration needs to change to a new duration.

  1. If the current value of duration is equal to new duration, then return.
  2. If new duration is less than the highest presentation timestamp of any buffered coded frames for all SourceBuffer objects in sourceBuffers, then throw an InvalidStateError exception and abort these steps.
    Note

    Duration reductions that would truncate currently buffered media are disallowed. When truncation is necessary, use remove() to reduce the buffered range before updating duration.

  3. Let highest end time be the largest track buffer ranges end time across all the track buffers across all SourceBuffer objects in sourceBuffers.
  4. If new duration is less than highest end time, then
    Note

    This condition can occur because the coded frame removal algorithm preserves coded frames that start before the start of the removal range.

    1. Update new duration to equal highest end time.
  5. Update duration to new duration.
  6. Use the mirror if necessary algorithm to run the following steps in Window to update the media element's duration:
    1. Update the media element's duration to new duration.
    2. Run the HTMLMediaElement duration change algorithm.

2.5.7 End of stream

This algorithm gets called when the application signals the end of stream via an endOfStream() call or an algorithm needs to signal a decode error. This algorithm takes an error parameter that indicates whether an error will be signalled.

  1. Change the readyState attribute value to "ended".
  2. Queue a task to fire an event named sourceended at the MediaSource.
  3. If error is not set
    1. Run the duration change algorithm with new duration set to the largest track buffer ranges end time across all the track buffers across all SourceBuffer objects in sourceBuffers.
      Note

      This allows the duration to properly reflect the end of the appended media segments. For example, if the duration was explicitly set to 10 seconds and only media segments for 0 to 5 seconds were appended before endOfStream() was called, then the duration will get updated to 5 seconds.

    2. Notify the media element that it now has all of the media data.
    If error is set to "network"
    Use the mirror if necessary algorithm to run the following steps in Window:
    If the HTMLMediaElement.readyState attribute equals HAVE_NOTHING
    Run the "If the media data cannot be fetched at all, due to network errors, causing the user agent to give up trying to fetch the resource" steps of the resource fetch algorithm's media data processing steps list.
    If the HTMLMediaElement.readyState attribute is greater than HAVE_NOTHING
    Run the "If the connection is interrupted after some media data has been received, causing the user agent to give up trying to fetch the resource" steps of the resource fetch algorithm's media data processing steps list.
    If error is set to "decode"
    Use the mirror if necessary algorithm to run the following steps in Window:
    If the HTMLMediaElement.readyState attribute equals HAVE_NOTHING
    Run the "If the media data can be fetched but is found by inspection to be in an unsupported format, or can otherwise not be rendered at all" steps of the resource fetch algorithm's media data processing steps list.
    If the HTMLMediaElement.readyState attribute is greater than HAVE_NOTHING
    Run the media data is corrupted steps of the resource fetch algorithm's media data processing steps list.

2.5.8 Mirror if necessary

This algorithm is used to run steps on Window from a MediaSource attached from either the same Window or from a DedicatedWorkerGlobalScope, usually to update the state of the attached HTMLMediaElement. This algorithm takes a steps parameter that lists the steps to run on Window.

If the MediaSource was constructed in a DedicatedWorkerGlobalScope:
Post an internal mirror on window message to [[port to main]] whose implicit handler in Window will run steps. Return control to the caller without awaiting that handler's receipt of the message.
Note
The purpose of the mirror message mechanism is to ensure that:
  1. steps run asynchronously as their own task on Window rather than these steps somehow happening in the middle of some other Window task's execution, and
  2. steps are run without blocking the synchronous execution and return of this algorithm on DedicatedWorkerGlobalScope.
Otherwise:
Run steps.

3. MediaSourceHandle Object

The MediaSourceHandle object represents a proxy for a MediaSource object that is useful for attaching a DedicatedWorkerGlobalScope MediaSource to a Window HTMLMediaElement using srcObject as described in the attaching to a media element algorithm.

Note

This distinct object is necessary to attach a cross-context MediaSource to a media element because MediaSource objects themselves are not transferable since they are event targets.

Each MediaSourceHandle object has a [[has ever been assigned as srcobject]] internal slot that stores a boolean. It is initialized to false when the MediaSourceHandle object is created, is set true in the extended HTMLMediaElement's srcObject setter as described in section 6. HTMLMediaElement Extensions, and if true, prevents successful transfer of the MediaSourceHandle as described in section 3.1 Transfer.

MediaSourceHandle objects are Transferable, each having a [[Detached]] internal slot that is used to ensure that once the handle object instance has been transferred, that instance cannot be transferred again.

WebIDL[Transferable, Exposed=(Window,DedicatedWorker)]
interface MediaSourceHandle {};

3.1 Transfer

The MediaSourceHandle transfer steps and transfer-receiving steps require the implementation to maintain an implicit internal slot referencing the underlying MediaSource to enable attaching to a media element using srcObject and consequent setup of an attachment's cross-context communication model.

Note

Implementors should be aware that assumption of "move" semantics implied by Transferable is not always reality. For example, extensions or internal implementations of postMessage using broadcast may cause unintended multiple recipients of a transferred MediaSourceHandle. For this reason, implementations are guided to not resolve which potential clone of a transferred MediaSourceHandle is still valid for attachment until and unless any handle for the underlying MediaSource object is used in the asynchronous portion of the media element's resource selection algorithm. This is similar to the existing behavior for attachment via MediaSource object URLs, which can be cloned easily, where such a URL is valid for at most one attachment start (across all of its potentially many clones).

Implementations MUST support at most one attachment (load) via srcObject ever for the MediaSource object underlying a MediaSourceHandle, regardless of potential cloning of the MediaSourceHandle due to varying implementations of Transferable.

Note

See attaching to a media element for how this is enforced during the asynchronous portion of the media element's resource selection algorithm.

MediaSourceHandle is only exposed on Window and DedicatedWorkerGlobalScope contexts, and cannot successfully transfer between different agent clusters [ECMASCRIPT]. Transfer of a MediaSourceHandle object can only succeed within the same agent cluster.

Note

For example, transfer of a MediaSourceHandle object from either a Window or DedicatedWorkerGlobalScope to either a SharedWorker or a ServiceWorker will not succeed. Developers should be aware of this difference versus MediaSource object URLs which are DOMStrings that can be communicated many ways. Even so, attaching to a media element using a MediaSource object URL can only succeed for a MediaSource that was constructed in a Window context. See also the integration of the agent and agent cluster formalisms for Web Application APIs [HTML] where related concepts such as dedicated worker agents are defined.

Transfer steps for a MediaSourceHandle object MUST include the following step:

  1. If the MediaSourceHandle's [[has ever been assigned as srcobject]] internal slot is true, then the transfer steps must fail by throwing a DataCloneError exception.

4. SourceBuffer Object

WebIDLenum AppendMode {
  "segments",
  "sequence",
};
segments
The timestamps in the media segment determine where the coded frames are placed in the presentation. Media segments can be appended in any order.
sequence
Media segments will be treated as adjacent in time independent of the timestamps in the media segment. Coded frames in a new media segment will be placed immediately after the coded frames in the previous media segment. The timestampOffset attribute will be updated if a new offset is needed to make the new media segments adjacent to the previous media segment. Setting the timestampOffset attribute in "sequence" mode allows a media segment to be placed at a specific position in the timeline without any knowledge of the timestamps in the media segment.
WebIDL[Exposed=(Window,DedicatedWorker)]
interface SourceBuffer : EventTarget {
                    attribute AppendMode          mode;
    readonly        attribute boolean             updating;
    readonly        attribute TimeRanges          buffered;
                    attribute double              timestampOffset;
    readonly        attribute AudioTrackList      audioTracks;
    readonly        attribute VideoTrackList      videoTracks;
    readonly        attribute TextTrackList       textTracks;
                    attribute double              appendWindowStart;
                    attribute unrestricted double appendWindowEnd;
                    attribute EventHandler        onupdatestart;
                    attribute EventHandler        onupdate;
                    attribute EventHandler        onupdateend;
                    attribute EventHandler        onerror;
                    attribute EventHandler        onabort;
    undefined appendBuffer (BufferSource data);
    undefined abort ();
    undefined changeType (DOMString type);
    undefined remove (double start, unrestricted double end);
};
Issue 280: MSE-in-Workers: {Audio,Video,Text}Track{,List} IDL in HTML need additional DedicatedWorker in Exposed
[HTML] AudioTrackList, VideoTrackList and TextTrackList need Window+DedicatedWorker exposure.

4.1 Attributes

mode of type AppendMode

Controls how a sequence of media segments are handled. This attribute is initially set by addSourceBuffer() after the object is created, and can be updated by changeType() or setting this attribute.

On getting, Return the initial value or the last value that was successfully set.

On setting, run the following steps:

  1. If this object has been removed from the sourceBuffers attribute of the parent media source, then throw an InvalidStateError exception and abort these steps.
  2. If the updating attribute equals true, then throw an InvalidStateError exception and abort these steps.
  3. Let new mode equal the new value being assigned to this attribute.
  4. If [[generate timestamps flag]] equals true and new mode equals "segments", then throw a TypeError exception and abort these steps.
  5. If the readyState attribute of the parent media source is in the "ended" state then run the following steps:

    1. Set the readyState attribute of the parent media source to "open"
    2. Queue a task to fire an event named sourceopen at the parent media source.
  6. If the [[append state]] equals PARSING_MEDIA_SEGMENT, then throw an InvalidStateError and abort these steps.
  7. If the new mode equals "sequence", then set the [[group start timestamp]] to the [[group end timestamp]].
  8. Update the attribute to new mode.
updating of type boolean, readonly

Indicates whether the asynchronous continuation of an appendBuffer() or remove() operation is still being processed. This attribute is initially set to false when the object is created.

buffered of type TimeRanges, readonly

Indicates what TimeRanges are buffered in the SourceBuffer. This attribute is initially set to an empty TimeRanges object when the object is created.

When the attribute is read the following steps MUST occur:

  1. If this object has been removed from the sourceBuffers attribute of the parent media source then throw an InvalidStateError exception and abort these steps.
  2. Let highest end time be the largest track buffer ranges end time across all the track buffers managed by this SourceBuffer object.
  3. Let intersection ranges equal a TimeRanges object containing a single range from 0 to highest end time.
  4. For each audio and video track buffer managed by this SourceBuffer, run the following steps:
    Note

    Text track buffers are included in the calculation of highest end time, above, but excluded from the buffered range calculation here. They are not necessarily continuous, nor should any discontinuity within them trigger playback stall when the other media tracks are continuous over the same time range.

    1. Let track ranges equal the track buffer ranges for the current track buffer.
    2. If readyState is "ended", then set the end time on the last range in track ranges to highest end time.
    3. Let new intersection ranges equal the intersection between the intersection ranges and the track ranges.
    4. Replace the ranges in intersection ranges with the new intersection ranges.
  5. If intersection ranges does not contain the exact same range information as the current value of this attribute, then update the current value of this attribute to intersection ranges.
  6. Return the current value of this attribute.
timestampOffset of type double

Controls the offset applied to timestamps inside subsequent media segments that are appended to this SourceBuffer. The timestampOffset is initially set to 0 which indicates that no offset is being applied.

On getting, Return the initial value or the last value that was successfully set.

On setting, run the following steps:

  1. Let new timestamp offset equal the new value being assigned to this attribute.
  2. If this object has been removed from the sourceBuffers attribute of the parent media source, then throw an InvalidStateError exception and abort these steps.
  3. If the updating attribute equals true, then throw an InvalidStateError exception and abort these steps.
  4. If the readyState attribute of the parent media source is in the "ended" state then run the following steps:

    1. Set the readyState attribute of the parent media source to "open"
    2. Queue a task to fire an event named sourceopen at the parent media source.
  5. If the [[append state]] equals PARSING_MEDIA_SEGMENT, then throw an InvalidStateError and abort these steps.
  6. If the mode attribute equals "sequence", then set the [[group start timestamp]] to new timestamp offset.
  7. Update the attribute to new timestamp offset.
audioTracks of type AudioTrackList, readonly
The list of AudioTrack objects created by this object.
videoTracks of type VideoTrackList, readonly
The list of VideoTrack objects created by this object.
textTracks of type TextTrackList, readonly
The list of TextTrack objects created by this object.
appendWindowStart of type double

The presentation timestamp for the start of the append window. This attribute is initially set to the presentation start time.

On getting, Return the initial value or the last value that was successfully set.

On setting, run the following steps:

  1. If this object has been removed from the sourceBuffers attribute of the parent media source, then throw an InvalidStateError exception and abort these steps.
  2. If the updating attribute equals true, then throw an InvalidStateError exception and abort these steps.
  3. If the new value is less than 0 or greater than or equal to appendWindowEnd then throw a TypeError exception and abort these steps.
  4. Update the attribute to the new value.
appendWindowEnd of type unrestricted double

The presentation timestamp for the end of the append window. This attribute is initially set to positive Infinity.

On getting, Return the initial value or the last value that was successfully set.

On setting, run the following steps:

  1. If this object has been removed from the sourceBuffers attribute of the parent media source, then throw an InvalidStateError exception and abort these steps.
  2. If the updating attribute equals true, then throw an InvalidStateError exception and abort these steps.
  3. If the new value equals NaN, then throw a TypeError and abort these steps.
  4. If the new value is less than or equal to appendWindowStart then throw a TypeError exception and abort these steps.
  5. Update the attribute to the new value.
onupdatestart of type EventHandler

The event handler for the updatestart event.

onupdate of type EventHandler

The event handler for the update event.

onupdateend of type EventHandler

The event handler for the updateend event.

onerror of type EventHandler

The event handler for the error event.

onabort of type EventHandler

The event handler for the abort event.

4.2 Methods

appendBuffer

Appends the segment data in an BufferSource[WEBIDL] to the SourceBuffer.

ParameterTypeNullableOptionalDescription
dataBufferSource
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. Run the prepare append algorithm.
  2. Add data to the end of the [[input buffer]].
  3. Set the updating attribute to true.
  4. Queue a task to fire an event named updatestart at this SourceBuffer object.
  5. Asynchronously run the buffer append algorithm.
abort

Aborts the current segment and resets the segment parser.

No parameters.
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. If this object has been removed from the sourceBuffers attribute of the parent media source then throw an InvalidStateError exception and abort these steps.
  2. If the readyState attribute of the parent media source is not in the "open" state then throw an InvalidStateError exception and abort these steps.
  3. If the range removal algorithm is running, then throw an InvalidStateError exception and abort these steps.
  4. If the updating attribute equals true, then run the following steps:
    1. Abort the buffer append algorithm if it is running.
    2. Set the updating attribute to false.
    3. Queue a task to fire an event named abort at this SourceBuffer object.
    4. Queue a task to fire an event named updateend at this SourceBuffer object.
  5. Run the reset parser state algorithm.
  6. Set appendWindowStart to the presentation start time.
  7. Set appendWindowEnd to positive Infinity.
changeType

Changes the MIME type associated with this object. Subsequent appendBuffer() calls will expect the newly appended bytes to conform to the new type.

Parameter Type Nullable Optional Description
type DOMString
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. If type is an empty string then throw a TypeError exception and abort these steps.
  2. If this object has been removed from the sourceBuffers attribute of the parent media source, then throw an InvalidStateError exception and abort these steps.
  3. If the updating attribute equals true, then throw an InvalidStateError exception and abort these steps.
  4. If type contains a MIME type that is not supported or contains a MIME type that is not supported with the types specified (currently or previously) of SourceBuffer objects in the sourceBuffers attribute of the parent media source, then throw a NotSupportedError exception and abort these steps.
  5. If the readyState attribute of the parent media source is in the "ended" state then run the following steps:

    1. Set the readyState attribute of the parent media source to "open".
    2. Queue a task to fire an event named sourceopen at the parent media source.
  6. Run the reset parser state algorithm.
  7. Update the [[generate timestamps flag]] on this SourceBuffer object to the value in the "Generate Timestamps Flag" column of the byte stream format registry [MSE-REGISTRY] entry that is associated with type.
  8. If the [[generate timestamps flag]] equals true:
    Set the mode attribute on this SourceBuffer object to "sequence", including running the associated steps for that attribute being set.
    Otherwise:
    Keep the previous value of the mode attribute on this SourceBuffer object, without running any associated steps for that attribute being set.
  9. Set the [[pending initialization segment for changeType flag]] on this SourceBuffer object to true.
remove

Removes media for a specific time range.

Parameter Type Nullable Optional Description
start double The start of the removal range, in seconds measured from presentation start time.
end unrestricted double The end of the removal range, in seconds measured from presentation start time.
Return type: undefined

When this method is invoked, the user agent must run the following steps:

  1. If this object has been removed from the sourceBuffers attribute of the parent media source then throw an InvalidStateError exception and abort these steps.
  2. If the updating attribute equals true, then throw an InvalidStateError exception and abort these steps.
  3. If duration equals NaN, then throw a TypeError exception and abort these steps.
  4. If start is negative or greater than duration, then throw a TypeError exception and abort these steps.
  5. If end is less than or equal to start or end equals NaN, then throw a TypeError exception and abort these steps.
  6. If the readyState attribute of the parent media source is in the "ended" state then run the following steps:

    1. Set the readyState attribute of the parent media source to "open"
    2. Queue a task to fire an event named sourceopen at the parent media source.
  7. Run the range removal algorithm with start and end as the start and end of the removal range.

4.3 Track Buffers

A track buffer stores the track descriptions and coded frames for an individual track. The track buffer is updated as initialization segments and media segments are appended to the SourceBuffer.

Each track buffer has a last decode timestamp variable that stores the decode timestamp of the last coded frame appended in the current coded frame group. The variable is initially unset to indicate that no coded frames have been appended yet.

Each track buffer has a last frame duration variable that stores the coded frame duration of the last coded frame appended in the current coded frame group. The variable is initially unset to indicate that no coded frames have been appended yet.

Each track buffer has a highest end timestamp variable that stores the highest coded frame end timestamp across all coded frames in the current coded frame group that were appended to this track buffer. The variable is initially unset to indicate that no coded frames have been appended yet.

Each track buffer has a need random access point flag variable that keeps track of whether the track buffer is waiting for a random access point coded frame. The variable is initially set to true to indicate that random access point coded frame is needed before anything can be added to the track buffer.

Each track buffer has a track buffer ranges variable that represents the presentation time ranges occupied by the coded frames currently stored in the track buffer.

Note

For track buffer ranges, these presentation time ranges are based on presentation timestamps, frame durations, and potentially coded frame group start times for coded frame groups across track buffers in a muxed SourceBuffer.

For specification purposes, this information is treated as if it were stored in a normalized TimeRanges object. Intersected track buffer ranges are used to report HTMLMediaElement.buffered, and MUST therefore support uninterrupted playback within each range of HTMLMediaElement.buffered.

Note

These coded frame group start times differ slightly from those mentioned in the coded frame processing algorithm in that they are the earliest presentation timestamp across all track buffers following a discontinuity. Discontinuities can occur within the coded frame processing algorithm or result from the coded frame removal algorithm, regardless of mode. The threshold for determining disjointness of track buffer ranges is implementation-specific. For example, to reduce unexpected playback stalls, implementations MAY approximate the coded frame processing algorithm's discontinuity detection logic by coalescing adjacent ranges separated by a gap smaller than 2 times the maximum frame duration buffered so far in this track buffer. Implementations MAY also use coded frame group start times as range start times across track buffers in a muxed SourceBuffer to further reduce unexpected playback stalls.

4.4 Event Summary

Event name Interface Dispatched when...
updatestart Event SourceBuffer's updating transitions from false to true.
update Event A SourceBuffer's append or remove successfully completed. SourceBuffer's updating transitions from true to false.
updateend Event The append or remove of a SourceBuffer ended.
error Event An error occurred during the append to a SourceBuffer. updating transitions from true to false.
abort Event The SourceBuffer's append was aborted by an abort() call. updating transitions from true to false.

4.5 Algorithms

4.5.1 Segment Parser Loop

Each SourceBuffer object has an [[append state]] internal slot that keeps track of the high-level segment parsing state. It is initially set to WAITING_FOR_SEGMENT and can transition to the following states as data is appended.

Append state name Description
WAITING_FOR_SEGMENT Waiting for the start of an initialization segment or media segment to be appended.
PARSING_INIT_SEGMENT Currently parsing an initialization segment.
PARSING_MEDIA_SEGMENT Currently parsing a media segment.

Each SourceBuffer object has an [[input buffer]] internal slot that is a byte buffer that holds unparsed bytes across appendBuffer() calls. The buffer is empty when the SourceBuffer object is created.

Each SourceBuffer object has a [[buffer full flag]] internal slot that keeps track of whether appendBuffer() is allowed to accept more bytes. It is set to false when the SourceBuffer object is created and gets updated as data is appended and removed.

Each SourceBuffer object has a [[group start timestamp]] internal slot that keeps track of the starting timestamp for a new coded frame group in the "sequence" mode. It is unset when the SourceBuffer object is created and gets updated when the mode attribute equals "sequence" and the timestampOffset attribute is set, or the coded frame processing algorithm runs.

Each SourceBuffer object has a [[group end timestamp]] internal slot that stores the highest coded frame end timestamp across all coded frames in the current coded frame group. It is set to 0 when the SourceBuffer object is created and gets updated by the coded frame processing algorithm.

Note

The [[group end timestamp]] stores the highest coded frame end timestamp across all track buffers in a SourceBuffer. Therefore, care should be taken in setting the mode attribute when appending multiplexed segments in which the timestamps are not aligned across tracks.

Each SourceBuffer object has a [[generate timestamps flag]] internal slot that is a boolean that keeps track of whether timestamps need to be generated for the coded frames passed to the coded frame processing algorithm. This flag is set by addSourceBuffer() when the SourceBuffer object is created and is updated by changeType().

When the segment parser loop algorithm is invoked, run the following steps:

  1. Loop Top: If the [[input buffer]] is empty, then jump to the need more data step below.
  2. If the [[input buffer]] contains bytes that violate the SourceBuffer byte stream format specification, then run the append error algorithm and abort this algorithm.
  3. Remove any bytes that the byte stream format specifications say MUST be ignored from the start of the [[input buffer]].
  4. If the [[append state]] equals WAITING_FOR_SEGMENT, then run the following steps:

    1. If the beginning of the [[input buffer]] indicates the start of an initialization segment, set the [[append state]] to PARSING_INIT_SEGMENT.
    2. If the beginning of the [[input buffer]] indicates the start of a media segment, set [[append state]] to PARSING_MEDIA_SEGMENT.
    3. Jump to the loop top step above.
  5. If the [[append state]] equals PARSING_INIT_SEGMENT, then run the following steps:

    1. If the [[input buffer]] does not contain a complete initialization segment yet, then jump to the need more data step below.
    2. Run the initialization segment received algorithm.
    3. Remove the initialization segment bytes from the beginning of the [[input buffer]].
    4. Set [[append state]] to WAITING_FOR_SEGMENT.
    5. Jump to the loop top step above.
  6. If the [[append state]] equals PARSING_MEDIA_SEGMENT, then run the following steps:

    1. If the [[first initialization segment received flag]] is false or the [[pending initialization segment for changeType flag]] is true, then run the append error algorithm and abort this algorithm.
    2. If the [[input buffer]] contains one or more complete coded frames, then run the coded frame processing algorithm.
      Note

      The frequency at which the coded frame processing algorithm is run is implementation-specific. The coded frame processing algorithm MAY be called when the input buffer contains the complete media segment or it MAY be called multiple times as complete coded frames are added to the input buffer.

    3. If this SourceBuffer is full and cannot accept more media data, then set the [[buffer full flag]] to true.
    4. If the [[input buffer]] does not contain a complete media segment, then jump to the need more data step below.
    5. Remove the media segment bytes from the beginning of the [[input buffer]].
    6. Set [[append state]] to WAITING_FOR_SEGMENT.
    7. Jump to the loop top step above.
  7. Need more data: Return control to the calling algorithm.

4.5.2 Reset Parser State

When the parser state needs to be reset, run the following steps:

  1. If the [[append state]] equals PARSING_MEDIA_SEGMENT and the [[input buffer]] contains some complete coded frames, then run the coded frame processing algorithm until all of these complete coded frames have been processed.
  2. Unset the last decode timestamp on all track buffers.
  3. Unset the last frame duration on all track buffers.
  4. Unset the highest end timestamp on all track buffers.
  5. Set the need random access point flag on all track buffers to true.
  6. If the mode attribute equals "sequence", then set the [[group start timestamp]] to the [[group end timestamp]]
  7. Remove all bytes from the [[input buffer]].
  8. Set [[append state]] to WAITING_FOR_SEGMENT.

4.5.3 Append Error

This algorithm is called when an error occurs during an append.

  1. Run the reset parser state algorithm.
  2. Set the updating attribute to false.
  3. Queue a task to fire an event named error at this SourceBuffer object.
  4. Queue a task to fire an event named updateend at this SourceBuffer object.
  5. Run the end of stream algorithm with the error parameter set to "decode".

4.5.4 Prepare Append

When an append operation begins, the following steps are run to validate and prepare the SourceBuffer.

  1. If the SourceBuffer has been removed from the sourceBuffers attribute of the parent media source then throw an InvalidStateError exception and abort these steps.
  2. If the updating attribute equals true, then throw an InvalidStateError exception and abort these steps.
  3. Let recent element error be determined as follows:
    If the MediaSource was constructed in a Window
    Let recent element error be true if the HTMLMediaElement.error attribute is not null. If that attribute is null, then let recent element error be false.
    Otherwise
    Let recent element error be the value resulting from the steps for the Window case, but run on the Window HTMLMediaElement on any change to its error attribute and communicated by using [[port to worker]] implicit messages. If such a message has not yet been received, then let recent element error be false.
  4. If recent element error is true, then throw an InvalidStateError exception and abort these steps.
  5. If the readyState attribute of the parent media source is in the "ended" state then run the following steps:

    1. Set the readyState attribute of the parent media source to "open"
    2. Queue a task to fire an event named sourceopen at the parent media source.
  6. Run the coded frame eviction algorithm.
  7. If the [[buffer full flag]] equals true, then throw a QuotaExceededError exception and abort these steps.

    Note

    This is the signal that the implementation was unable to evict enough data to accommodate the append or the append is too big. The web application SHOULD use remove() to explicitly free up space and/or reduce the size of the append.

4.5.5 Buffer Append

When appendBuffer() is called, the following steps are run to process the appended data.

  1. Run the segment parser loop algorithm.
  2. If the segment parser loop algorithm in the previous step was aborted, then abort this algorithm.
  3. Set the updating attribute to false.
  4. Queue a task to fire an event named update at this SourceBuffer object.
  5. Queue a task to fire an event named updateend at this SourceBuffer object.

4.5.6 Range Removal

Follow these steps when a caller needs to initiate a JavaScript visible range removal operation that blocks other SourceBuffer updates:

  1. Let start equal the starting presentation timestamp for the removal range, in seconds measured from presentation start time.
  2. Let end equal the end presentation timestamp for the removal range, in seconds measured from presentation start time.
  3. Set the updating attribute to true.
  4. Queue a task to fire an event named updatestart at this SourceBuffer object.
  5. Return control to the caller and run the rest of the steps asynchronously.
  6. Run the coded frame removal algorithm with start and end as the start and end of the removal range.
  7. Set the updating attribute to false.
  8. Queue a task to fire an event named update at this SourceBuffer object.
  9. Queue a task to fire an event named updateend at this SourceBuffer object.

4.5.7 Initialization Segment Received

The following steps are run when the segment parser loop successfully parses a complete initialization segment:

Each SourceBuffer object has a [[first initialization segment received flag]] internal slot that tracks whether the first initialization segment has been appended and received by this algorithm. This flag is set to false when the SourceBuffer is created and updated by the algorithm below.

Each SourceBuffer object has a [[pending initialization segment for changeType flag]] internal slot that tracks whether an initialization segment is needed since the most recent changeType(). This flag is set to false when the SourceBuffer is created, set to true by changeType() and reset to false by the algorithm below.

  1. Update the duration attribute if it currently equals NaN:
    If the initialization segment contains a duration:
    Run the duration change algorithm with new duration set to the duration in the initialization segment.
    Otherwise:
    Run the duration change algorithm with new duration set to positive Infinity.
  2. If the initialization segment has no audio, video, or text tracks, then run the append error algorithm and abort these steps.
  3. If the [[first initialization segment received flag]] is true, then run the following steps:
    1. Verify the following properties. If any of the checks fail then run the append error algorithm and abort these steps.
      • The number of audio, video, and text tracks match what was in the first initialization segment.
      • If more than one track for a single type are present (e.g., 2 audio tracks), then the Track IDs match the ones in the first initialization segment.
      • The codecs for each track are supported by the user agent.
        Note

        User agents MAY consider codecs, that would otherwise be supported, as "not supported" here if the codecs were not specified in type parameter passed to (a) the most recently successful changeType() on this SourceBuffer object, or (b) if no successful changeType() has yet occurred on this object, the addSourceBuffer() that created this SourceBuffer object. For example, if the most recently successful changeType() was called with 'video/webm' or 'video/webm; codecs="vp8"', and a video track containing vp9 appears in the initialization segment, then the user agent MAY use this step to trigger a decode error even if the other two properties' checks, above, pass. Implementations are encouraged to trigger error in such cases only when the codec is indeed not supported or the other two properties' checks fail. Web authors are encouraged to use changeType(), addSourceBuffer() and isTypeSupported() with precise codec parameters to more proactively detect user agent support. changeType() is required if the SourceBuffer object's bytestream format is changing.

    2. Add the appropriate track descriptions from this initialization segment to each of the track buffers.
    3. Set the need random access point flag on all track buffers to true.
  4. Let active track flag equal false.
  5. If the [[first initialization segment received flag]] is false, then run the following steps:

    1. If the initialization segment contains tracks with codecs the user agent does not support, then run the append error algorithm and abort these steps.
      Note

      User agents MAY consider codecs, that would otherwise be supported, as "not supported" here if the codecs were not specified in type parameter passed to (a) the most recently successful changeType() on this SourceBuffer object, or (b) if no successful changeType() has yet occurred on this object, the addSourceBuffer() that created this SourceBuffer object. For example, MediaSource.isTypeSupported('video/webm;codecs="vp8,vorbis"') may return true, but if addSourceBuffer() was called with 'video/webm;codecs="vp8"' and a Vorbis track appears in the initialization segment, then the user agent MAY use this step to trigger a decode error. Implementations are encouraged to trigger error in such cases only when the codec is indeed not supported. Web authors are encouraged to use changeType(), addSourceBuffer() and isTypeSupported() with precise codec parameters to more proactively detect user agent support. changeType() is required if the SourceBuffer object's bytestream format is changing.

    2. For each audio track in the initialization segment, run following steps:

      1. Let audio byte stream track ID be the Track ID for the current track being processed.
      2. Let audio language be a BCP 47 language tag for the language specified in the initialization segment for this track or an empty string if no language info is present.
      3. If audio language equals the 'und' BCP 47 value, then assign an empty string to audio language.
      4. Let audio label be a label specified in the initialization segment for this track or an empty string if no label info is present.
      5. Let audio kinds be a sequence of kind strings specified in the initialization segment for this track or a sequence with a single empty string element in it if no kind information is provided.
      6. For each value in audio kinds, run the following steps:
        1. Let current audio kind equal the value from audio kinds for this iteration of the loop.
        2. Let new audio track be a new AudioTrack object.
        3. Generate a unique ID and assign it to the id property on new audio track.
        4. Assign audio language to the language property on new audio track.
        5. Assign audio label to the label property on new audio track.
        6. Assign current audio kind to the kind property on new audio track.
        7. If this SourceBuffer object's audioTracks.length equals 0, then run the following steps:

          1. Set the enabled property on new audio track to true.
          2. Set active track flag to true.
        8. Add new audio track to the audioTracks attribute on this SourceBuffer object.
          Note

          This should trigger AudioTrackList [HTML] logic to queue a task to fire an event named addtrack using TrackEvent with the track attribute initialized to new audio track, at the AudioTrackList object referenced by the audioTracks attribute on this SourceBuffer object.

        9. If the parent media source was constructed in a DedicatedWorkerGlobalScope:
          Post an internal create track mirror message to [[port to main]] whose implicit handler in Window runs the following steps:
          1. Let mirrored audio track be a new AudioTrack object.
          2. Assign the same property values to mirrored audio track as were determined for new audio track.
          3. Add mirrored audio track to the audioTracks attribute on the HTMLMediaElement.
          Otherwise:
          Add new audio track to the audioTracks attribute on the HTMLMediaElement.
          Note

          This should trigger AudioTrackList [HTML] logic to queue a task to fire an event named addtrack using TrackEvent with the track attribute initialized to mirrored audio track or new audio track, at the AudioTrackList object referenced by the audioTracks attribute on the HTMLMediaElement.

      7. Create a new track buffer to store coded frames for this track.
      8. Add the track description for this track to the track buffer.
    3. For each video track in the initialization segment, run following steps:

      1. Let video byte stream track ID be the Track ID for the current track being processed.
      2. Let video language be a BCP 47 language tag for the language specified in the initialization segment for this track or an empty string if no language info is present.
      3. If video language equals the 'und' BCP 47 value, then assign an empty string to video language.
      4. Let video label be a label specified in the initialization segment for this track or an empty string if no label info is present.
      5. Let video kinds be a sequence of kind strings specified in the initialization segment for this track or a sequence with a single empty string element in it if no kind information is provided.
      6. For each value in video kinds, run the following steps:
        1. Let current video kind equal the value from video kinds for this iteration of the loop.
        2. Let new video track be a new VideoTrack object.
        3. Generate a unique ID and assign it to the id property on new video track.
        4. Assign video language to the language property on new video track.
        5. Assign video label to the label property on new video track.
        6. Assign current video kind to the kind property on new video track.
        7. If this SourceBuffer object's videoTracks.length equals 0, then run the following steps:

          1. Set the selected property on new video track to true.
          2. Set active track flag to true.
        8. Add new video track to the videoTracks attribute on this SourceBuffer object.
          Note

          This should trigger VideoTrackList [HTML] logic to queue a task to fire an event named addtrack using TrackEvent with the track attribute initialized to new video track, at the VideoTrackList object referenced by the videoTracks attribute on this SourceBuffer object.

        9. If the parent media source was constructed in a DedicatedWorkerGlobalScope:
          Post an internal create track mirror message to [[port to main]] whose implicit handler in Window runs the following steps:
          1. Let mirrored video track be a new VideoTrack object.
          2. Assign the same property values to mirrored video track as were determined for new video track.
          3. Add mirrored video track to the videoTracks attribute on the HTMLMediaElement.
          Otherwise:
          Add new video track to the videoTracks attribute on the HTMLMediaElement.
          Note

          This should trigger VideoTrackList [HTML] logic to queue a task to fire an event named addtrack using TrackEvent with the track attribute initialized to mirrored video track or new video track, at the VideoTrackList object referenced by the videoTracks attribute on the HTMLMediaElement.

      7. Create a new track buffer to store coded frames for this track.
      8. Add the track description for this track to the track buffer.
    4. For each text track in the initialization segment, run following steps:

      1. Let text byte stream track ID be the Track ID for the current track being processed.
      2. Let text language be a BCP 47 language tag for the language specified in the initialization segment for this track or an empty string if no language info is present.
      3. If text language equals the 'und' BCP 47 value, then assign an empty string to text language.
      4. Let text label be a label specified in the initialization segment for this track or an empty string if no label info is present.
      5. Let text kinds be a sequence of kind strings specified in the initialization segment for this track or a sequence with a single empty string element in it if no kind information is provided.
      6. For each value in text kinds, run the following steps:
        1. Let current text kind equal the value from text kinds for this iteration of the loop.
        2. Let new text track be a new TextTrack object.
        3. Generate a unique ID and assign it to the id property on new text track.
        4. Assign text language to the language property on new text track.
        5. Assign text label to the label property on new text track.
        6. Assign current text kind to the kind property on new text track.
        7. Populate the remaining properties on new text track with the appropriate information from the initialization segment.
        8. If the mode property on new text track equals "showing" or "hidden", then set active track flag to true.
        9. Add new text track to the textTracks attribute on this SourceBuffer object.
          Note

          This should trigger TextTrackList [HTML] logic to queue a task to fire an event named addtrack using TrackEvent with the track attribute initialized to new text track, at the TextTrackList object referenced by the textTracks attribute on this SourceBuffer object.

        10. If the parent media source was constructed in a DedicatedWorkerGlobalScope:
          Post an internal create track mirror message to [[port to main]] whose implicit handler in Window runs the following steps:
          1. Let mirrored text track be a new TextTrack object.
          2. Assign the same property values to mirrored text track as were determined for new text track.
          3. Add mirrored text track to the textTracks attribute on the HTMLMediaElement.
          Otherwise:
          Add new text track to the textTracks attribute on the HTMLMediaElement.
          Note

          This should trigger TextTrackList [HTML] logic to queue a task to fire an event named addtrack using TrackEvent with the track attribute initialized to mirrored text track or new text track, at the TextTrackList object referenced by the textTracks attribute on the HTMLMediaElement.

      7. Create a new track buffer to store coded frames for this track.
      8. Add the track description for this track to the track buffer.
    5. If active track flag equals true, then run the following steps:
      1. Add this SourceBuffer to activeSourceBuffers.
      2. Queue a task to fire an event named addsourcebuffer at activeSourceBuffers
    6. Set [[first initialization segment received flag]] to true.
  6. Set [[pending initialization segment for changeType flag]] to false.
  7. If the active track flag equals true, then run the following steps:
  8. Use the parent media source's mirror if necessary algorithm to run the following step in Window:
    1. If the HTMLMediaElement.readyState attribute is greater than HAVE_CURRENT_DATA, then set the HTMLMediaElement.readyState attribute to HAVE_METADATA.
      Note

      Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  9. If each object in sourceBuffers of the parent media source has [[first initialization segment received flag]] equal to true, then use the parent media source's mirror if necessary algorithm to run the following step in Window:
    1. If the HTMLMediaElement.readyState attribute is HAVE_NOTHING, then set the HTMLMediaElement.readyState attribute to HAVE_METADATA.
      Note

      Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement. If transition from HAVE_NOTHING to HAVE_METADATA occurs, it should trigger HTMLMediaElement logic to queue a task to fire an event named loadedmetadata at the media element.

4.5.8 Coded Frame Processing

When complete coded frames have been parsed by the segment parser loop then the following steps are run:

  1. For each coded frame in the media segment run the following steps:

    1. Loop Top:
      If [[generate timestamps flag]] equals true:
      1. Let presentation timestamp equal 0.
      2. Let decode timestamp equal 0.
      Otherwise:
      1. Let presentation timestamp be a double precision floating point representation of the coded frame's presentation timestamp in seconds.
        Note

        Special processing may be needed to determine the presentation and decode timestamps for timed text frames since this information may not be explicitly present in the underlying format or may be dependent on the order of the frames. Some metadata text tracks, like MPEG2-TS PSI data, may only have implied timestamps. Format specific rules for these situations SHOULD be in the byte stream format specifications or in separate extension specifications.

      2. Let decode timestamp be a double precision floating point representation of the coded frame's decode timestamp in seconds.
        Note

        Implementations don't have to internally store timestamps in a double precision floating point representation. This representation is used here because it is the representation for timestamps in the HTML spec. The intention here is to make the behavior clear without adding unnecessary complexity to the algorithm to deal with the fact that adding a timestampOffset may cause a timestamp rollover in the underlying timestamp representation used by the byte stream format. Implementations can use any internal timestamp representation they wish, but the addition of timestampOffset SHOULD behave in a similar manner to what would happen if a double precision floating point representation was used.

    2. Let frame duration be a double precision floating point representation of the coded frame's duration in seconds.
    3. If mode equals "sequence" and [[group start timestamp]] is set, then run the following steps:
      1. Set timestampOffset equal to [[group start timestamp]] minus presentation timestamp.
      2. Set [[group end timestamp]] equal to [[group start timestamp]].
      3. Set the need random access point flag on all track buffers to true.
      4. Unset [[group start timestamp]].
    4. If timestampOffset is not 0, then run the following steps:

      1. Add timestampOffset to the presentation timestamp.
      2. Add timestampOffset to the decode timestamp.
    5. Let track buffer equal the track buffer that the coded frame will be added to.
    6. If last decode timestamp for track buffer is set and decode timestamp is less than last decode timestamp:
      OR
      If last decode timestamp for track buffer is set and the difference between decode timestamp and last decode timestamp is greater than 2 times last frame duration:
      1. If mode equals "segments":
        Set [[group end timestamp]] to presentation timestamp.
        If mode equals "sequence":
        Set [[group start timestamp]] equal to the [[group end timestamp]].
      2. Unset the last decode timestamp on all track buffers.
      3. Unset the last frame duration on all track buffers.
      4. Unset the highest end timestamp on all track buffers.
      5. Set the need random access point flag on all track buffers to true.
      6. Jump to the Loop Top step above to restart processing of the current coded frame.
      Otherwise:
      Continue.
    7. Let frame end timestamp equal the sum of presentation timestamp and frame duration.
    8. If presentation timestamp is less than appendWindowStart, then set the need random access point flag to true, drop the coded frame, and jump to the top of the loop to start processing the next coded frame.
      Note

      Some implementations MAY choose to collect some of these coded frames with presentation timestamp less than appendWindowStart and use them to generate a splice at the first coded frame that has a presentation timestamp greater than or equal to appendWindowStart even if that frame is not a random access point. Supporting this requires multiple decoders or faster than real-time decoding so for now this behavior will not be a normative requirement.

    9. If frame end timestamp is greater than appendWindowEnd, then set the need random access point flag to true, drop the coded frame, and jump to the top of the loop to start processing the next coded frame.
      Note

      Some implementations MAY choose to collect coded frames with presentation timestamp less than appendWindowEnd and frame end timestamp greater than appendWindowEnd and use them to generate a splice across the portion of the collected coded frames within the append window at time of collection, and the beginning portion of later processed frames which only partially overlap the end of the collected coded frames. Supporting this requires multiple decoders or faster than real-time decoding so for now this behavior will not be a normative requirement. In conjunction with collecting coded frames that span appendWindowStart, implementations MAY thus support gapless audio splicing.

    10. If the need random access point flag on track buffer equals true, then run the following steps:
      1. If the coded frame is not a random access point, then drop the coded frame and jump to the top of the loop to start processing the next coded frame.
      2. Set the need random access point flag on track buffer to false.
    11. Let spliced audio frame be an unset variable for holding audio splice information
    12. Let spliced timed text frame be an unset variable for holding timed text splice information
    13. If last decode timestamp for track buffer is unset and presentation timestamp falls within the presentation interval of a coded frame in track buffer, then run the following steps:
      1. Let overlapped frame be the coded frame in track buffer that matches the condition above.
      2. If track buffer contains audio coded frames:
        Run the audio splice frame algorithm and if a splice frame is returned, assign it to spliced audio frame.
        If track buffer contains video coded frames:
        1. Let remove window timestamp equal the overlapped frame presentation timestamp plus 1 microsecond.
        2. If the presentation timestamp is less than the remove window timestamp, then remove overlapped frame from track buffer.
          Note

          This is to compensate for minor errors in frame timestamp computations that can appear when converting back and forth between double precision floating point numbers and rationals. This tolerance allows a frame to replace an existing one as long as it is within 1 microsecond of the existing frame's start time. Frames that come slightly before an existing frame are handled by the removal step below.

        If track buffer contains timed text coded frames:
        Run the text splice frame algorithm and if a splice frame is returned, assign it to spliced timed text frame.
    14. Remove existing coded frames in track buffer:
      If highest end timestamp for track buffer is not set:
      Remove all coded frames from track buffer that have a presentation timestamp greater than or equal to presentation timestamp and less than frame end timestamp.
      If highest end timestamp for track buffer is set and less than or equal to presentation timestamp:
      Remove all coded frames from track buffer that have a presentation timestamp greater than or equal to highest end timestamp and less than frame end timestamp.
    15. Remove all possible decoding dependencies on the coded frames removed in the previous two steps by removing all coded frames from track buffer between those frames removed in the previous two steps and the next random access point after those removed frames.
      Note

      Removing all coded frames until the next random access point is a conservative estimate of the decoding dependencies since it assumes all frames between the removed frames and the next random access point depended on the frames that were removed.

    16. If spliced audio frame is set:
      Add spliced audio frame to the track buffer.
      If spliced timed text frame is set:
      Add spliced timed text frame to the track buffer.
      Otherwise:
      Add the coded frame with the presentation timestamp, decode timestamp, and frame duration to the track buffer.
    17. Set last decode timestamp for track buffer to decode timestamp.
    18. Set last frame duration for track buffer to frame duration.
    19. If highest end timestamp for track buffer is unset or frame end timestamp is greater than highest end timestamp, then set highest end timestamp for track buffer to frame end timestamp.
      Note

      The greater than check is needed because bidirectional prediction between coded frames can cause presentation timestamp to not be monotonically increasing even though the decode timestamps are monotonically increasing.

    20. If frame end timestamp is greater than [[group end timestamp]], then set [[group end timestamp]] equal to frame end timestamp.
    21. If [[generate timestamps flag]] equals true, then set timestampOffset equal to frame end timestamp.
  2. If the HTMLMediaElement.readyState attribute is HAVE_METADATA and the new coded frames cause HTMLMediaElement.buffered to have a TimeRanges for the current playback position, then set the HTMLMediaElement.readyState attribute to HAVE_CURRENT_DATA.

    Note

    Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  3. If the HTMLMediaElement.readyState attribute is HAVE_CURRENT_DATA and the new coded frames cause HTMLMediaElement.buffered to have a TimeRanges that includes the current playback position and some time beyond the current playback position, then set the HTMLMediaElement.readyState attribute to HAVE_FUTURE_DATA.

    Note

    Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  4. If the HTMLMediaElement.readyState attribute is HAVE_FUTURE_DATA and the new coded frames cause HTMLMediaElement.buffered to have a TimeRanges that includes the current playback position and enough data to ensure uninterrupted playback, then set the HTMLMediaElement.readyState attribute to HAVE_ENOUGH_DATA.

    Note

    Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

  5. If the media segment contains data beyond the current duration, then run the duration change algorithm with new duration set to the maximum of the current duration and the [[group end timestamp]].

4.5.9 Coded Frame Removal

Follow these steps when coded frames for a specific time range need to be removed from the SourceBuffer:

  1. Let start be the starting presentation timestamp for the removal range.
  2. Let end be the end presentation timestamp for the removal range.
  3. For each track buffer in this SourceBuffer, run the following steps:

    1. Let remove end timestamp be the current value of duration
    2. If this track buffer has a random access point timestamp that is greater than or equal to end, then update remove end timestamp to that random access point timestamp.

      Note

      Random access point timestamps can be different across tracks because the dependencies between coded frames within a track are usually different than the dependencies in another track.

    3. Remove all media data, from this track buffer, that contain starting timestamps greater than or equal to start and less than the remove end timestamp.
      1. For each removed frame, if the frame has a decode timestamp equal to the last decode timestamp for the frame's track, run the following steps:

        If mode equals "segments":
        Set [[group end timestamp]] to presentation timestamp.
        If mode equals "sequence":
        Set [[group start timestamp]] equal to the [[group end timestamp]].
      2. Unset the last decode timestamp on all track buffers.
      3. Unset the last frame duration on all track buffers.
      4. Unset the highest end timestamp on all track buffers.
      5. Set the need random access point flag on all track buffers to true.
    4. Remove all possible decoding dependencies on the coded frames removed in the previous step by removing all coded frames from this track buffer between those frames removed in the previous step and the next random access point after those removed frames.
      Note

      Removing all coded frames until the next random access point is a conservative estimate of the decoding dependencies since it assumes all frames between the removed frames and the next random access point depended on the frames that were removed.

    5. If this object is in activeSourceBuffers, the current playback position is greater than or equal to start and less than the remove end timestamp, and HTMLMediaElement.readyState is greater than HAVE_METADATA, then set the HTMLMediaElement.readyState attribute to HAVE_METADATA and stall playback.

      Note

      Per HTMLMediaElement ready states [HTML] logic, HTMLMediaElement.readyState changes may trigger events on the HTMLMediaElement.

      Note

      This transition occurs because media data for the current position has been removed. Playback cannot progress until media for the current playback position is appended or the 2.5.5 Changes to selected/enabled track state.

  4. If the [[buffer full flag]] equals true and this object is ready to accept more bytes, then set the [[buffer full flag]] to false.

4.5.10 Coded Frame Eviction

This algorithm is run to free up space in this SourceBuffer when new data is appended.

  1. Let new data equal the data that is about to be appended to this SourceBuffer.
    Issue 289: Editorial? Coded Frame eviction algorithm needs to note that "buffer full flag" may be updated immediately based on |new data|

    Need to recognize step here that implementations MAY decide to set [[buffer full flag]] true here if it predicts that processing new data in addition to any existing bytes in [[input buffer]] would exceed the capacity of the SourceBuffer. Such a step enables more proactive push-back from implementations before accepting new data which would overflow resources, for example. In practice, at least one implementation already does this.

  2. If the [[buffer full flag]] equals false, then abort these steps.
  3. Let removal ranges equal a list of presentation time ranges that can be evicted from the presentation to make room for the new data.
    Note

    Implementations MAY use different methods for selecting removal ranges so web applications SHOULD NOT depend on a specific behavior. The web application can use the buffered attribute to observe whether portions of the buffered data have been evicted.

  4. For each range in removal ranges, run the coded frame removal algorithm with start and end equal to the removal range start and end timestamp respectively.

4.5.11 Audio Splice Frame

Follow these steps when the coded frame processing algorithm needs to generate a splice frame for two overlapping audio coded frames:

  1. Let track buffer be the track buffer that will contain the splice.
  2. Let new coded frame be the new coded frame, that is being added to track buffer, which triggered the need for a splice.
  3. Let presentation timestamp be the presentation timestamp for new coded frame.
  4. Let decode timestamp be the decode timestamp for new coded frame.
  5. Let frame duration be the coded frame duration of new coded frame.
  6. Let overlapped frame be the coded frame in track buffer with a presentation interval that contains presentation timestamp.
  7. Update presentation timestamp and decode timestamp to the nearest audio sample timestamp based on sample rate of the audio in overlapped frame. If a timestamp is equidistant from both audio sample timestamps, then use the higher timestamp (e.g., floor(x * sample_rate + 0.5) / sample_rate).
    Note

    For example, given the following values:

    • The presentation timestamp of overlapped frame equals 10.
    • The sample rate of overlapped frame equals 8000 Hz
    • presentation timestamp equals 10.01255
    • decode timestamp equals 10.01255

    presentation timestamp and decode timestamp are updated to 10.0125 since 10.01255 is closer to 10 + 100/8000 (10.0125) than 10 + 101/8000 (10.012625)

  8. If the user agent does not support crossfading then run the following steps:
    1. Remove overlapped frame from track buffer.
    2. Add a silence frame to track buffer with the following properties:
      Note

      Some implementations MAY apply fades to/from silence to coded frames on either side of the inserted silence to make the transition less jarring.

    3. Return to caller without providing a splice frame.
      Note

      This is intended to allow new coded frame to be added to the track buffer as if overlapped frame had not been in the track buffer to begin with.

  9. Let frame end timestamp equal the sum of presentation timestamp and frame duration.
  10. Let splice end timestamp equal the sum of presentation timestamp and the splice duration of 5 milliseconds.
  11. Let fade out coded frames equal overlapped frame as well as any additional frames in track buffer that have a presentation timestamp greater than presentation timestamp and less than splice end timestamp.
  12. Remove all the frames included in fade out coded frames from track buffer.
  13. Return a splice frame with the following properties:
    • The presentation timestamp set to the overlapped frame presentation timestamp.
    • The decode timestamp set to the overlapped frame decode timestamp.
    • The coded frame duration set to difference between frame end timestamp and the overlapped frame presentation timestamp.
    • The fade out coded frames equals fade out coded frames.
    • The fade in coded frame equals new coded frame.
      Note

      If the new coded frame is less than 5 milliseconds in duration, then coded frames that are appended after the new coded frame will be needed to properly render the splice.

    • The splice timestamp equals presentation timestamp.
    Note

    See the audio splice rendering algorithm for details on how this splice frame is rendered.

4.5.12 Audio Splice Rendering

The following steps are run when a spliced frame, generated by the audio splice frame algorithm, needs to be rendered by the media element:

  1. Let fade out coded frames be the coded frames that are faded out during the splice.
  2. Let fade in coded frames be the coded frames that are faded in during the splice.
  3. Let presentation timestamp be the presentation timestamp of the first coded frame in fade out coded frames.
  4. Let end timestamp be the sum of the presentation timestamp and the coded frame duration of the last frame in fade in coded frames.
  5. Let splice timestamp be the presentation timestamp where the splice starts. This corresponds with the presentation timestamp of the first frame in fade in coded frames.
  6. Let splice end timestamp equal splice timestamp plus five milliseconds.
  7. Let fade out samples be the samples generated by decoding fade out coded frames.
  8. Trim fade out samples so that it only contains samples between presentation timestamp and splice end timestamp.
  9. Let fade in samples be the samples generated by decoding fade in coded frames.
  10. If fade out samples and fade in samples do not have a common sample rate and channel layout, then convert fade out samples and fade in samples to a common sample rate and channel layout.
  11. Let output samples be a buffer to hold the output samples.
  12. Apply a linear gain fade out with a starting gain of 1 and an ending gain of 0 to the samples between splice timestamp and splice end timestamp in fade out samples.
  13. Apply a linear gain fade in with a starting gain of 0 and an ending gain of 1 to the samples between splice timestamp and splice end timestamp in fade in samples.
  14. Copy samples between presentation timestamp to splice timestamp from fade out samples into output samples.
  15. For each sample between splice timestamp and splice end timestamp, compute the sum of a sample from fade out samples and the corresponding sample in fade in samples and store the result in output samples.
  16. Copy samples between splice end timestamp to end timestamp from fade in samples into output samples.
  17. Render output samples.
Note

Here is a graphical representation of this algorithm.

Audio splice diagram

4.5.13 Text Splice Frame

Follow these steps when the coded frame processing algorithm needs to generate a splice frame for two overlapping timed text coded frames:

  1. Let track buffer be the track buffer that will contain the splice.
  2. Let new coded frame be the new coded frame, that is being added to track buffer, which triggered the need for a splice.
  3. Let presentation timestamp be the presentation timestamp for new coded frame
  4. Let decode timestamp be the decode timestamp for new coded frame.
  5. Let frame duration be the coded frame duration of new coded frame.
  6. Let frame end timestamp equal the sum of presentation timestamp and frame duration.
  7. Let first overlapped frame be the coded frame in track buffer with a presentation interval that contains presentation timestamp.
  8. Let overlapped presentation timestamp be the presentation timestamp of the first overlapped frame.
  9. Let overlapped frames equal first overlapped frame as well as any additional frames in track buffer that have a presentation timestamp greater than presentation timestamp and less than frame end timestamp.
  10. Remove all the frames included in overlapped frames from track buffer.
  11. Update the coded frame duration of the first overlapped frame to presentation timestamp minus overlapped presentation timestamp.
  12. Add first overlapped frame to the track buffer.
  13. Return to caller without providing a splice frame.
    Note

    This is intended to allow new coded frame to be added to the track buffer as if it hadn't overlapped any frames in track buffer to begin with.

5. SourceBufferList Object

SourceBufferList is a simple container object for SourceBuffer objects. It provides read-only array access and fires events when the list is modified.

WebIDL[Exposed=(Window,DedicatedWorker)]
interface SourceBufferList : EventTarget {
    readonly        attribute unsigned long length;
                    attribute EventHandler  onaddsourcebuffer;
                    attribute EventHandler  onremovesourcebuffer;
    getter SourceBuffer (unsigned long index);
};

5.1 Attributes

length of type unsigned long, readonly

Indicates the number of SourceBuffer objects in the list.

onaddsourcebuffer of type EventHandler

The event handler for the addsourcebuffer event.

onremovesourcebuffer of type EventHandler

The event handler for the removesourcebuffer event.

5.2 Methods

getter

Allows the SourceBuffer objects in the list to be accessed with an array operator (i.e., []).

ParameterTypeNullableOptionalDescription
index unsigned long
Return type: SourceBuffer

When this method is invoked, the user agent must run the following steps:

  1. If index is greater than or equal to the length attribute then return undefined and abort these steps.
  2. Return the index'th SourceBuffer object in the list.

5.3 Event Summary

Event name Interface Dispatched when...
addsourcebuffer Event When a SourceBuffer is added to the list.
removesourcebuffer Event When a SourceBuffer is removed from the list.

6. HTMLMediaElement Extensions

This section specifies what existing HTMLMediaElement.seekable and HTMLMediaElement.buffered attributes on the HTMLMediaElement MUST return when a MediaSource is attached to the element, and what the existing HTMLMediaElement.srcObject attribute MUST also do when it is set to be a MediaSourceHandle object.

The HTMLMediaElement.seekable attribute returns a new static normalized TimeRanges object created based on the following steps:

  1. If the MediaSource was constructed in a DedicatedWorkerGlobalScope that is terminated or is closing then return an empty TimeRanges object and abort these steps.
    Note

    This case is intended to handle implementations that may no longer maintain any previous information about buffered or seekable media in a MediaSource that was constructed in a DedicatedWorkerGlobalScope that has been terminated by terminate() or user agent execution of terminate a worker for the MediaSource's DedicatedWorkerGlobalScope, for instance as the eventual result of close() execution.

    Issue 277: MSE-in-Workers: Consider (eventually) transitioning attached element to error upon termination of MediaSource's worker/what should media element do?

    Should there be some (eventual) media element error transition in the case of an attached worker MediaSource having its context destroyed? The experimental Chromium implementation of worker MSE just keeps the element readyState, networkState and error the same as prior to that context destruction, though the seekable and buffered attributes each report an empty TimeRange.

  2. Let recent duration and recent live seekable range respectively be the recent values of duration and [[live seekable range]], determined as follows:
    If the MediaSource was constructed in a Window
    Set recent duration to be duration and set recent live seekable range to be [[live seekable range]].
    Otherwise:
    Set recent duration and recent live seekable range respectively to be what the duration and [[live seekable range]] were recently, updated by handling implicit messages posted by the MediaSource to its [[port to main]] on every change to duration or [[live seekable range]].
  3. If recent duration equals NaN:
    Return an empty TimeRanges object.
    If recent duration equals positive Infinity:
    1. If recent live seekable range is not empty:
      1. Let union ranges be the union of recent live seekable range and the HTMLMediaElement.buffered attribute.
      2. Return a single range with a start time equal to the earliest start time in union ranges and an end time equal to the highest end time in union ranges and abort these steps.
    2. If the HTMLMediaElement.buffered attribute returns an empty TimeRanges object, then return an empty TimeRanges object and abort these steps.
    3. Return a single range with a start time of 0 and an end time equal to the highest end time reported by the HTMLMediaElement.buffered attribute.
    Otherwise:
    Return a single range with a start time of 0 and an end time equal to recent duration.

The HTMLMediaElement.buffered attribute returns a static normalized TimeRanges object based on the following steps.

  1. If the MediaSource was constructed in a DedicatedWorkerGlobalScope that is terminated or is closing then return an empty TimeRanges object and abort these steps.
    Note

    This case is intended to handle implementations that may no longer maintain any previous information about buffered or seekable media in a MediaSource that was constructed in a DedicatedWorkerGlobalScope that has been terminated by terminate() or user agent execution of terminate a worker for the MediaSource's DedicatedWorkerGlobalScope, for instance as the eventual result of close() execution.

    Issue 277: MSE-in-Workers: Consider (eventually) transitioning attached element to error upon termination of MediaSource's worker/what should media element do?

    Should there be some (eventual) media element error transition in the case of an attached worker MediaSource having its context destroyed? The experimental Chromium implementation of worker MSE just keeps the element readyState, networkState and error the same as prior to that context destruction, though the seekable and buffered attributes each report an empty TimeRange.

  2. Let recent intersection ranges be determined as follows:
    If the MediaSource was constructed in a Window
    1. Let recent intersection ranges equal an empty TimeRanges object.
    2. If activeSourceBuffers.length does not equal 0 then run the following steps:
      1. Let active ranges be the ranges returned by buffered for each SourceBuffer object in activeSourceBuffers.
      2. Let highest end time be the largest range end time in the active ranges.
      3. Let recent intersection ranges equal a TimeRanges object containing a single range from 0 to highest end time.
      4. For each SourceBuffer object in activeSourceBuffers run the following steps:
        1. Let source ranges equal the ranges returned by the buffered attribute on the current SourceBuffer.
        2. If readyState is "ended", then set the end time on the last range in source ranges to highest end time.
        3. Let new intersection ranges equal the intersection between the recent intersection ranges and the source ranges.
        4. Replace the ranges in recent intersection ranges with the new intersection ranges.
    Otherwise:
    Let recent intersection ranges be the TimeRanges resulting from the steps for the Window case, but run with the MediaSource and its SourceBuffer objects in their DedicatedWorkerGlobalScope and communicated by using [[port to main]] implicit messages on every update to the activeSourceBuffers, readyState, or any of the buffering state that would change any of the values of each of those buffered attributes of the activeSourceBuffers.
    Note

    The overhead of recalculating and communicating recent intersection ranges so frequently is one reason for allowing implementation flexibility to query this information on-demand using other mechanisms such as shared memory and locks as mentioned in cross-context communication model.

  3. If the current value of this attribute has not been set by this algorithm or recent intersection ranges does not contain the exact same range information as the current value of this attribute, then update the current value of this attribute to recent intersection ranges.
  4. Return the current value of this attribute.

If a HTMLMediaElement.srcObject attribute is assigned a MediaSourceHandle, then set [[has ever been assigned as srcobject]] for that MediaSourceHandle to true as part of the synchronous steps of the extended HTMLMediaElement's srcObject setter that occur before invoking the element's load algorithm.

Note

This prevents transferring that MediaSourceHandle object ever again, enabling clear synchronous exception if that is attempted.

Issue

MediaSourceHandle needs to be added to HTMLMediaElement's MediaProvider IDL typedef and related text involving media provider objects.

7. AudioTrack Extensions

This section specifies extensions to the [HTML] AudioTrack definition.

WebIDL[Exposed=(Window,DedicatedWorker)]
partial interface AudioTrack {
    readonly        attribute SourceBuffer? sourceBuffer;
};
Issue 280: MSE-in-Workers: {Audio,Video,Text}Track{,List} IDL in HTML need additional DedicatedWorker in Exposed
[HTML] AudioTrack needs Window+DedicatedWorker exposure.

Attributes

sourceBuffer of type SourceBuffer, readonly , nullable

On getting, run the following step:

If this track was created by a SourceBuffer that was created on the same realm as this track, and if that SourceBuffer has not been removed from the sourceBuffers attribute of its parent media source:
Return the SourceBuffer that created this track.
Otherwise:
Return null.
Note
For example, if a DedicatedWorkerGlobalScope SourceBuffer notified its internal create track mirror handler in Window to create this track, then the Window copy of the track would return null for this attribute.

8. VideoTrack Extensions

This section specifies extensions to the [HTML] VideoTrack definition.

WebIDL[Exposed=(Window,DedicatedWorker)]
partial interface VideoTrack {
    readonly        attribute SourceBuffer? sourceBuffer;
};
Issue 280: MSE-in-Workers: {Audio,Video,Text}Track{,List} IDL in HTML need additional DedicatedWorker in Exposed
[HTML] VideoTrack needs Window+DedicatedWorker exposure.

Attributes

sourceBuffer of type SourceBuffer, readonly , nullable

On getting, run the following step:

If this track was created by a SourceBuffer that was created on the same realm as this track, and if that SourceBuffer has not been removed from the sourceBuffers attribute of its parent media source:
Return the SourceBuffer that created this track.
Otherwise:
Return null.
Note
For example, if a DedicatedWorkerGlobalScope SourceBuffer notified its internal create track mirror handler in Window to create this track, then the Window copy of the track would return null for this attribute.

9. TextTrack Extensions

This section specifies extensions to the [HTML] TextTrack definition.

WebIDL[Exposed=(Window,DedicatedWorker)]
partial interface TextTrack {
    readonly        attribute SourceBuffer? sourceBuffer;
};
Issue 280: MSE-in-Workers: {Audio,Video,Text}Track{,List} IDL in HTML need additional DedicatedWorker in Exposed
[HTML] TextTrack needs Window+DedicatedWorker exposure.

Attributes

sourceBuffer of type SourceBuffer, readonly , nullable

On getting, run the following step:

If this track was created by a SourceBuffer that was created on the same realm as this track, and if that SourceBuffer has not been removed from the sourceBuffers attribute of its parent media source:
Return the SourceBuffer that created this track.
Otherwise:
Return null.
Note
For example, if a DedicatedWorkerGlobalScope SourceBuffer notified its internal create track mirror handler in Window to create this track, then the Window copy of the track would return null for this attribute.

10. Byte Stream Formats

The bytes provided through appendBuffer() for a SourceBuffer form a logical byte stream. The format and semantics of these byte streams are defined in byte stream format specifications. The byte stream format registry [MSE-REGISTRY] provides mappings between a MIME type that may be passed to addSourceBuffer(), isTypeSupported() or changeType() and the byte stream format expected by a SourceBuffer using that MIME type for parsing newly appended data. Implementations are encouraged to register mappings for byte stream formats they support to facilitate interoperability. The byte stream format registry [MSE-REGISTRY] is the authoritative source for these mappings. If an implementation claims to support a MIME type listed in the registry, its SourceBuffer implementation MUST conform to the byte stream format specification listed in the registry entry.

Note

The byte stream format specifications in the registry are not intended to define new storage formats. They simply outline the subset of existing storage format structures that implementations of this specification will accept.

Note

Byte stream format parsing and validation is implemented in the segment parser loop algorithm.

This section provides general requirements for all byte stream format specifications:

Byte stream specifications MUST at a minimum define constraints which ensure that the above requirements hold. Additional constraints MAY be defined, for example to simplify implementation.

11. Conformance

As well as sections marked as non-normative, all authoring guidelines, diagrams, examples, and notes in this specification are non-normative. Everything else in this specification is normative.

The key words MAY, MUST, MUST NOT, SHOULD, and SHOULD NOT in this document are to be interpreted as described in BCP 14 [RFC2119] [RFC8174] when, and only when, they appear in all capitals, as shown here.

12. Examples

Example use of the Media Source Extensions

<script>
  function onSourceOpen(videoTag, e) {
    var mediaSource = e.target;

    if (mediaSource.sourceBuffers.length > 0)
        return;

    var sourceBuffer = mediaSource.addSourceBuffer('video/webm; codecs="vorbis,vp8"');

    videoTag.addEventListener('seeking', onSeeking.bind(videoTag, mediaSource));
    videoTag.addEventListener('progress', onProgress.bind(videoTag, mediaSource));

    var initSegment = GetInitializationSegment();

    if (initSegment == null) {
      // Error fetching the initialization segment. Signal end of stream with an error.
      mediaSource.endOfStream("network");
      return;
    }

    // Append the initialization segment.
    var firstAppendHandler = function(e) {
      var sourceBuffer = e.target;
      sourceBuffer.removeEventListener('updateend', firstAppendHandler);

      // Append some initial media data.
      appendNextMediaSegment(mediaSource);
    };
    sourceBuffer.addEventListener('updateend', firstAppendHandler);
    sourceBuffer.appendBuffer(initSegment);
  }

  function appendNextMediaSegment(mediaSource) {
    if (mediaSource.readyState == "closed")
      return;

    // If we have run out of stream data, then signal end of stream.
    if (!HaveMoreMediaSegments()) {
      mediaSource.endOfStream();
      return;
    }

    // Make sure the previous append is not still pending.
    if (mediaSource.sourceBuffers[0].updating)
        return;

    var mediaSegment = GetNextMediaSegment();

    if (!mediaSegment) {
      // Error fetching the next media segment.
      mediaSource.endOfStream("network");
      return;
    }

    // NOTE: If mediaSource.readyState == “ended”, this appendBuffer() call will
    // cause mediaSource.readyState to transition to "open". The web application
    // should be prepared to handle multiple “sourceopen” events.
    mediaSource.sourceBuffers[0].appendBuffer(mediaSegment);
  }

  function onSeeking(mediaSource, e) {
    var video = e.target;

    if (mediaSource.readyState == "open") {
      // Abort current segment append.
      mediaSource.sourceBuffers[0].abort();
    }

    // Notify the media segment loading code to start fetching data at the
    // new playback position.
    SeekToMediaSegmentAt(video.currentTime);

    // Append a media segment from the new playback position.
    appendNextMediaSegment(mediaSource);
  }

  function onProgress(mediaSource, e) {
    appendNextMediaSegment(mediaSource);
  }
</script>

<video id="v" autoplay> </video>

<script>
  var video = document.getElementById('v');
  var mediaSource = new MediaSource();
  mediaSource.addEventListener('sourceopen', onSourceOpen.bind(this, video));
  video.src = window.URL.createObjectURL(mediaSource);
</script>

13. Acknowledgments

The editors would like to thank Alex Giladi, Bob Lund, Chris Poole, Cyril Concolato, David Dorwin, David Singer, Duncan Rowden, Frank Galligan, Glenn Adams, Jer Noble, Joe Steele, John Simmons, Kevin Streeter, Mark Vickers, Matt Ward, Matthew Gregan, Michael Thornburgh, Philip Jägenstedt, Pierre Lemieux, Ralph Giles, Steven Robertson, and Tatsuya Igarashi for their contributions to this specification.

A. VideoPlaybackQuality

This section is non-normative.

The video playback quality metrics described in previous revisions of this specification (e.g., sections 5 and 10 of the Candidate Recommendation) are now being developed as part of [MEDIA-PLAYBACK-QUALITY]. Some implementations may have implemented the earlier draft VideoPlaybackQuality object and the HTMLVideoElement extension method getVideoPlaybackQuality() described in those previous revisions.

B. Issue summary

C. References

C.1 Normative references

[dom]
DOM Standard. Anne van Kesteren. WHATWG. Living Standard. URL: https://dom.spec.whatwg.org/
[ECMASCRIPT]
ECMAScript Language Specification. Ecma International. URL: https://tc39.es/ecma262/multipage/
[FILEAPI]
File API. Marijn Kruisselbrink. W3C. 6 February 2023. W3C Working Draft. URL: https://www.w3.org/TR/FileAPI/
[HTML]
HTML Standard. Anne van Kesteren; Domenic Denicola; Ian Hickson; Philip Jägenstedt; Simon Pieters. WHATWG. Living Standard. URL: https://html.spec.whatwg.org/multipage/
[MSE-REGISTRY]
Media Source Extensions™ Byte Stream Format Registry. Matthew Wolenetz; Jerry Smith; Aaron Colwell. W3C. URL: https://www.w3.org/TR/mse-byte-stream-format-registry/
[RFC2119]
Key words for use in RFCs to Indicate Requirement Levels. S. Bradner. IETF. March 1997. Best Current Practice. URL: https://www.rfc-editor.org/rfc/rfc2119
[RFC8174]
Ambiguity of Uppercase vs Lowercase in RFC 2119 Key Words. B. Leiba. IETF. May 2017. Best Current Practice. URL: https://www.rfc-editor.org/rfc/rfc8174
[WEBIDL]
Web IDL Standard. Edgar Chen; Timothy Gu. WHATWG. Living Standard. URL: https://webidl.spec.whatwg.org/

C.2 Informative references

[INBANDTRACKS]
Sourcing In-band Media Resource Tracks from Media Containers into HTML. Silvia Pfeiffer; Bob Lund. W3C. 26 April 2015. Unofficial Draft. URL: https://dev.w3.org/html5/html-sourcing-inband-tracks/
[MEDIA-PLAYBACK-QUALITY]
Media Playback Quality. Mounir Lamouri. W3C. W3C Editor's Draft. URL: https://w3c.github.io/media-playback-quality/
[url]
URL Standard. Anne van Kesteren. WHATWG. Living Standard. URL: https://url.spec.whatwg.org/
