Developing Web Services

Adam Bosworth

Crossgain Corporation

adambos@crossgain.com






Abstract

Web-based application developers are attempting to move towards Web Services as a mechanism for developing component-based Web applications.  Unfortunately traditional tools and development models are inadequately architected to meet the rapidly evolving needs for the future of scalable Web Services.  Today's Web Services development model is mired with complexity as traditional tools and technologies, focused on client-server application development, are ill suited.  In this paper we examine the challenges of today’s Web Service development model.

1           Introduction

Developing Web Services with traditional technology requires costly and scarce programming resources, and heavy investments in hardware and software that create lengthy and costly development cycles.  These barriers to entry have delayed the rapid emergence of Web Services.  Crossgain enables the Web Services Era through a uniquely productive platform service, development model and community.

1.1         What is a Web Service?

The term “Web service,” describes specific functionality, value delivered via Internet protocols, for the purpose of providing a mechanism for another service or application to use.

Web Services enable the componentization and reuse of traditional web applications.   An example is a Web Service to calculate sales tax.  As a Web Service, applications have the ability to embed the sales tax function with other functions, or Web Services, to create an on-line consumer sales experience.

By exposing components of applications as Web Services, and enabling businesses to invoke these components, businesses can fundamentally transform their ability to interact and engage with both current as well as potential customers and partners.  Web Services will fundamentally transform Web-based applications by enabling them to participate more broadly as an integrated component to an eBusiness solution.

The industry is attempting to take advantage of World Wide Web Consortium (W3C, see www.w3c.org) and Internet Engineering Task Force (IETF, see www.ietf.org) standards such as Extensible Markup Language (XML), HTTP, and Domain Name System (DNS) protocols to create specifications that define a way to publish and discover information about Web services.  An example is the Universal Description, Discovery and Integration (UDDI) specification (see [1]).

1.2         Example Scenarios

Today, software applications deliver a wide variety of solutions to address a wide variety of customer and business needs.  These same needs create a similar market for Web Services, which means that someday there will also be a wide variety of Web Services available.  Here are three-example Web Service scenarios for business.

  1. Exposing Existing Infrastructure to the Internet

Many companies already have significant investments in automating their business processes on back-end systems.  One of the first steps these companies need to pursue is making these processes available to the appropriate partners, vendors, and customers on the Internet.

For example, suppose a shipping company wants to provide a Web Service that enables customers to determine what it costs to ship an item from point A to point B in a specified timeframe, to arrange for pick up and to track a shipped item. The business systems to track this information have already been developed and are used internally every day.

2.       Stand-Alone Internet Service

The Web Service is a new application or functionality that is being developed specifically to meet the needs of a Web-based service.

An example of this type of service is a financial retirement analysis service. Anyone willing to pay can send their personal financial information and have a personalized retirement analysis done.  This type of analysis is typically asynchronous, where the individual submits their personal information and awaits notification when the analysis is completed.  This service may also include the ability for groups to collaborate and create micro-communities around personal financing, a personalized layout for the analysis, ability to inspect work in progress and status through the web.

3.       Inter-Enterprise Integration Service

The Web Service is an integration or routing service.  The purpose of this type of service is to enable businesses or people to dynamically interact, exchange information, collaborate, and do business over the Internet.

An example of a routing service is the integration between sellers and suppliers.  To start, the seller takes an order from a customer.  Then the seller wants to send the order to the suppliers to send directly to the customer. The seller doesn’t want to handle the communication, routing, and error handling between each of the suppliers. Instead, they send the order to an Integration Service. This service will communicate with each supplier, to track failure to respond, to deliver notifications when problems emerge to the appropriate users, and to do the necessary document translations. This system delivers value by providing custom connectivity, store and forward, administration user interface, custom transformations.

These are just a few of the many potential scenarios businesses will look to enable via Web Services.  Therefore the ability to build and integrated these functions, or components, is critical to their success.

2           Developing a Web Service

Developing a scalable Web Service to address the scenarios noted above requires developing an infrastructure to address a few fundamental challenges related to offering a service.  1) Unpredictable loads, unreliable communications and unreliable access, 2) hardware scaling (i.e. the ability to arbitrarily throw hardware at scalability challenges) and 3) integration (i.e. the ability to interoperate with other systems and services).

2.1         Services should Support Asynchronous Messaging

Before the web, most communications between applications in the client-server world were synchronous.  The client sends a message and then waits for the server to respond.  The majority of Web-based applications today begin as client server applications on a single multi-function server (the single server handles multiple functions such as the handling of web requests and executing application and database logic).  However, businesses may quickly outgrow this setting and require developers to re-engineer many of these web-based applications.

Here is an example of the steps a client server web service would take to process a single request for an inventory look-up, where the look-up returns a single value indicating availability. 1) The web server receives the request.  2) This request is forwarded to the appropriate application. 3) The application logic submits a database query and sits idle awaiting the response.  4) The local database executes the query.  5) The result is returned to the application. 6) The application passes the result back to the web service. 7) The web server forwards the result to the requester.


In this simplified example, there is a predictable load (i.e. the single request), a simple response (i.e. short processing time) over a reliable communications (intra-computer) infrastructure with reliable access (i.e. high service availability).  For this example, a synchronous service is acceptable.

However, by the virtue of being on the Web, the service can be exposed to unpredictable loads (i.e. can’t predict the number users) from unknown users (i.e. can’t predict the users intent) over an unreliable communications (i.e. inter-computer) infrastructure with unreliable access (i.e. can’t predict the availability of other systems or Web Services).  On the Web, synchronous applications are often too rigid and inefficient to handle this level of uncertainty and an asynchronous messaging architecture is required.  The following scenarios highlight the fragility of a synchronous, client server, Web Service.

1.        Unpredictable Load

Because loads can be unpredictable, systems can become backlogged or unable to process requests in a timely manner.  This may lead to system failure as services time out or become unavailable.  When this occurs, consumers of synchronous web services may lock critical resources while waiting for a result that may never come.  In contrast, asynchronous messaging systems can better manage the load and make efficient use of available resources with techniques such as throttling since service consumers are not waiting idly for a response.  In addition, consumers of asynchronous web services, which may themselves be web services, can avoid locking critical resources, thereby enabling them to accommodate more load.

To better understand the inefficiencies of synchronous web services, consider the analogy of a telephone call center.  The call center has a limited number of operators taking calls.  At peak times, callers experience long delays doing very little but waiting for an operator.  Some get frustrated and hang-up maybe resulting in lost sales.  During slow times, the operators, who are now available to handle the lost calls, sit idle collecting their paychecks.  In contrast, an asynchronous web service is more like an e-mail processing center.  People send a quick e-mail message with their request and go back to their business.  A response comes back as soon as it is possible and the operators only sit idle when there is really no work to do.

2.        Unreliable Communications

Synchronous services assume reliable communications and may become unresponsive or unreliable over traditionally unreliable communications mediums such as: Local Area Networks (LANs), Internet Service Providers (ISPs) and Dial-up links.  Conversely, asynchronous messaging services make no assumptions about communications reliability and use a reliable message delivery system.  Messages are queued until they are successfully transmitted to the appropriate application queue.

A simple example is to contrast the use of the telephone, synchronous communications, to mailing a message, asynchronous communications.  In order for the telephone to be an effective communications device, there must be another telephone user on the other end that can communicate back.  Without both users on-line, or on the telephone, at the exact same time, User1 could not communicate with User2.  With mail, since there is no assumption as to User2’s availability, or that User2 can communicate back, User1 could create a piece of mail, send it to User2’s mailbox and continue processing other messages for User3, User4, etc....  User2’s message could be reliably delivered, regardless of their current availability. User2 can read the message at anytime and choose to respond, or not, without impacting User1.

3.
Unreliable Access

Because synchronous services assume system availability, unreliable access, like unreliable communications, may cause service slow-downs or failures.  Asynchronous message services, not only don’t assume a reliable communications infrastructure, they also don’t assume service availability.  This enables service consumers to use on-line, or running, services while queuing off-line, not running, services for later processing.

For example, in Step 3 the service assumes the availability of the database and if the database is off-line, or unavailable, the service consumer either waits for it to come back on-line, times-out and tries again or fails.  With an asynchronous messaging service, the service consumer can continue to submit requests for processing.  Once the database comes back on-line, requests can be processed by priority or in the order in which they were submitted.

Therefore asynchronous messaging services are often required for Web Services due to uncertainties (e.g. unpredictable load, unreliable communications and unreliable access) the Internet may present.

2.2         Service should Support Dynamic Hardware Scaling

So far we have limited our Web Service to a single server and assumed that by supporting a messaging-based communications model, the server would be able to address the service’s scalability needs.  However, how do we address the scenario where a single machine, no matter how the service is architected, doesn’t possess the processing power required to handle the Web Service requests?  In this scenario, the Web Service is deployed on a distributed multi-server architecture (functions such as the handling of web requests and the execution of application and database logic are distributed to individual servers).  However adding additional hardware to solve scalability challenges potentially introduces a new set of development complexity.

Here is an example of the steps a distributed multi-server architected service would take to process multiple requests for inventory availability. 1) The requests are spread across multiple, or a pool of web servers.  2) Individual requests are forwarded to the appropriate application on the appropriate application server. 3) The application submits a query to the appropriate database server.  4) The database executes the query.  5) The result is returned to the application. 6) The application passes the result to the web service. 7) And finally, the web server replies to the requester.  The Steps are almost identical with the exception of having multiple servers available to process, and share requests.

However, by the virtue of being distributed, developers must solve the following problems.

1.       Dynamic Load Balancing – since several servers can process requests, developers must determine how to most efficiently allocate, or spread, the requests across the server resources available.

2.       State Management – since it’s possible for multiple servers, in the same server pool, to handle the same user session, developers must determine how to maintain the state, or session context, as the session moves between servers.

3.
Caching and Cache Coherency – since communications infrastructures can become saturated, potentially causing performance problems, by processing redundant requests, developers must determine how to cache frequently requested data.  Not only must a developer determine an appropriate caching algorithm, they must develop cache coherency, or cache synchronization, algorithms in order to ensure cached data accuracy.

Asynchronous message services along with a distributed, multi-server architecture will provide consumers with a more satisfactory experience as it provides consumers with the perception of a rapid synchronous process.  As services can collect the necessary information for a business process, then begin processing once the consumer is off-line.

As developers apply more hardware to solve critical scaling challenges, they increase the complexity by introducing new factors into the architecture.  Key factors such as: load distribution, state management and caching must be taken into account.

2.3         Service should Support XML for Integration

As defined earlier, a Web Service needs to “provide a mechanism for another service or application to use”, or a method of integration.  So far we have focused on developing an asynchronous message service that will enable a service to handle some of the uncertainties of the Internet as well as providing hardware scalability.

The message format is at least as important as the communications infrastructure.  For example, if a supplier is able to successfully transmit a document to a buyer, but the document is in an unrecognizable format, the buyer may not be able to consume the information in the document.  Therefore, without a standard syntax, a lingua franca, for messages between Web Services, they will not be able to efficiently and effectively integrate to create powerful new web-based business solutions.

XML is such a standard.  Defined by the World Wide Web Consortium (W3C, see www.w3c.org), XML provides a self-describing, structured representation of data that can be implemented broadly.  The advantages of XML are: 1) XML is self-describing, 2) XML is platform independent, 3) XML is a general-purpose description language that can encode many types of information such as data, programs and types, and 4) XML is independent of applications or vendors, it provides an open mechanism for businesses to define and express business documents and services.

While XML itself is straight forward, some of the accompanying open and standard technologies make XML a flexible open standard message format.  Some of these technologies include:

·         Document Object Model – Called the DOM, the DOM enables programmatic access to the XML document by exposing a logical document structure.  Via this logical structure, programmers are able to extract necessary data as input into other processes or applications.

·         XML Schemas – XML Schemas enable developers to declare the structure (e.g. document structure, valid elements and element attributes) of an XML document.  Via XML Schemas, developers can validate entire XML documents or elements of the XML document.  Since the XML Schema is defined in XML, trading partners for example can agree on a document format.

·         Extensible Style Language for Transformations (XSLT) – XSLT enables developers to extract and transform XML Documents.  This transformation could be to another XML format as well as to non-XML formats such as HTML, or traditional B2B document formats such as EDI.

Utilizing the open XML standards for Web Service integration, Web Services, and Web Service developers, are able to exchange documents and document schemas in an open, standards based format.  Because it’s an open industry standard, developers can utilize a myriad of open tools and technologies (e.g. XML DOM and XSLT) to manipulate and integrate dynamic data from various sources.

2.4         The Complexity and Cost of Developing a Web Service

So far we have identified a few of the technologies that are required to build a Web Service infrastructure.  We have, for the most part, ignored the complexities and costs associated with this infrastructure and ultimately have ignored their impact on a business’ ability to meet time to market objectives.

Developers, or teams of developers, must grapple with the complexities of architecting a messaging-based infrastructure to maximize resource utilization and minimize the traditional Internet disruptions such as unreliable communications, unreliable access and unpredictable loads.  The complexity becomes exponentially greater as the load increases and the number of servers increases because developers must now deal with sophisticated load balancing, state management, caching and cache coherency algorithms.   Developers must also embrace XML and the complexity associated with creating schemas and XSL Transforms as well as the XML DOM.  Each of these areas requires it’s own programming expertise, and teams of developers must work together to ensure success.

To the complexity associated with developing the infrastructure, and the skills required, the challenge of building a scalable data center, or the hardware to deploy your infrastructure, must be factored.  Scalable data centers are not an after-thought, they must be architected for scale from the start.  A typical Web Service data center requires expertise in data center planning, system administration, database administration, router administration, systems management and hardware systems configuration.  As with developers, data center teams must work together, and with developers, to ensure the success of the Web Service.

So far we have only dealt with some of the basic requirements for building a Web Service infrastructure, and we have assumed that there are developers and data center resources available to address these challenges.  This assumption couldn’t be more false, as businesses all over are struggling to fill even the most basic of programming skills needs.  Unfortunately for businesses, the skilled programming resources required to build the scalable Web Service infrastructure are even scarcer.  This leaves many businesses aggressively bidding for these rare programming resources and leaving many businesses, especially those without significant financial resources, unable to meet their development needs.

Software development and data center operations costs are just the beginning.  Businesses must invest heavily, and continually re-invest, in the underlying hardware and software required for the infrastructure in the form of initial costs, upgrade costs and licensing fees.  In addition, to meet service goals and service availability, businesses must invest in redundancy, or multiple systems that can act as backup to each other.  This includes systems such as expensive intelligent routers, communications infrastructure, Web Servers, Large Application and Database Servers.  And finally, businesses must also license the operating software required to power the hardware.

A key attribute of a Web-based service must include the ability to evolve and adapt to ever changing technologies and market conditions.  This ability is vital in ensuring businesses can address evolving market conditions or an aggressive competitor. Unfortunately, once we have paid for all the expertise, hardware and software we have to realize a certain amount of time is required to put it all together.  Businesses must also factor that innovation from traditional technology providers may be slow to deliver what the business needs to remain competitive.

For example, a typical software delivery model requires 18-24 months for a major system release, 3-6 months for a Service Pack release, not to mention lengthy testing cycles, time lost re-architecting systems for a new feature(s) and the potential for service interruption during system rollouts.

When a business considers the infrastructure development, hardware and software licensing and data center operational costs and time, they often realize that a significantly large portion of their resources is dedicated to non-revenue bearing investments.  This often unknowingly transforms businesses with a vision and expertise for a simple Web Service, such as a tax calculation Web Service, into business focused on building technology.

2.5         In Summary

In order to build a Web Service that can scale to handle unpredictable loads over unreliable communications with unreliable access, which can interoperate with other Web Services and systems, the service should support: 1) Asynchronous Messaging, 2) Dynamic Hardware Scaling, and 3) XML.

In order for businesses to achieve their Web Services expectations, both internally and externally, the service must be architected from the ground up to support these. However, when a business considers the complexity, costs and time required to develop a scalable Web Service (e.g. infrastructure development, hardware and software licensing and data center operational costs), they often realize that a significantly large portion of their resources are dedicated to infrastructure, and away from the resources required to building the application.  Therefore businesses must weigh: the complexity, the costs and the time to market, against the value of building, deploying and managing a Web Service.
