1. Introduction
This subsection is not normative.
CSS describes how each element and each string of text in a source document is laid out by transforming the document tree into a set of boxes, whose size, position, and stacking level on the canvas depend on the values of their CSS properties.
Note: CSS Cascading and Inheritance describes how properties are assigned to elements in the box tree, while CSS Display 3 §1 Introduction describes how the document tree is transformed into the box tree.
Each CSS box has a rectangular content area,
a band of padding around the content,
a border around the padding,
and a margin outside the border.
The sizing properties [css-sizing-3],
together with various other properties that control layout,
define the size of the content area.
The box styling properties—
Note: This module originally contained the CSS Level 3 specification prose relating to box generation (now defined in [[css-display-3]), the box model (defined here), as well as block layout (now only defined in [CSS2] Chapters 9 and 10). Since its maintenance was put aside during the development of CSS2.1, its prose was severely outdated by the time CSS2 Revision 1 was finally completed. Therefore, the block layout portion of the prose has been retired, to be re-synched to CSS2 and updated as input to a new Block Layout module at some point in the future. It is being split apart from this module and from the CSS Display Module both because of the practical concern that it would be a huge amount of work and also in recognition that CSS now has multiple layout models (Flex Layout, Grid Layout, Positioned Layout, and Table Layout, in addition to Block Layout) which each deserve their own parallel module.
1.1. Values
This specification follows the CSS property definition conventions from [CSS2] using the value definition syntax from [CSS-VALUES-3]. Value types not defined in this specification are defined in CSS Values & Units [CSS-VALUES-3]. Other CSS modules may expand the definitions of these value types.
In addition to the property-specific values listed in their definitions, all properties defined in this specification also accept the CSS-wide keywords keywords as their property value. For readability they have not been repeated explicitly.
1.2. Module Interactions
This module replaces the definitions of the margin and padding properties defined in [CSS2] sections 8.1, 8.2, 8.3 (but not 8.3.1), and 8.4.
All properties in this module apply to the ::first-line and ::first-letter pseudo-elements.
2. The CSS Box Model
Each box has a content area (which contains its content—
The margin, border, and padding can be broken down into top, right, bottom, and left segments, each of which can be controlled independently by its corresponding property.
The perimeter of each of the four areas (content, padding, border, and margin) is called an “edge”, and each edge can be broken down into a top, right, bottom, and left side. Thus each box has four edges each composed of four sides:
- content edge or inner edge
- The content edge surrounds the rectangle given by the width and height of the box, which often depend on the element’s content and/or its containing block size. The four sides of the content edge together define the box’s content box.
- padding edge
- The padding edge surrounds the box’s padding. If the padding has zero width on a given side, the padding edge coincides with the content edge on that side. The four sides of the padding edge together define the box’s padding box, which contains both the content and padding areas.
- border edge
- The border edge surrounds the box’s border. If the border has zero width on a given side, the border edge coincides with the padding edge on that side. The four sides of the border edge together define the box’s border box, which contains the box’s content, padding, and border areas.
- margin edge or outer edge
- The margin edge surrounds the box’s margin. If the margin has zero width on a given side, the margin edge coincides with the border edge on that side. The four sides of the margin edge together define the box’s margin box, which contains the all of the box’s content, padding, border, and margin areas.
The background of the content, padding, and border areas of a box is specified by its background properties. The border area can additionally be painted with a border style using the border properties. Margins are always transparent. See [css-backgrounds-3].
When a box fragments—
3. Margins
Margins surround the border edge of a box, providing spacing between boxes. The margin properties specify the thickness of the margin area of a box. The margin shorthand property sets the margin for all four sides while the margin longhand properties only set their respective side. This specification defines the physical margin longhands; [css-logical-1] additionally defines flow-relative margin longhands. Both sets of properties control the same set of margins: they are just different ways of indexing each side.
Note: Adjoining margins in block layout collapse. See CSS2§8.3.1 Collapsing Margins for details. Also, margins adjoining a fragmentation break are sometimes truncated. See CSS Fragmentation 3 §5.2 Adjoining Margins at Breaks for details.
3.1. Page-relative (Physical) Margin Properties: the margin-top, margin-right, margin-bottom, and margin-left properties
Name: | margin-top, margin-right, margin-bottom, margin-left |
---|---|
Value: | <length-percentage> | auto |
Initial: | 0 |
Applies to: | all elements except internal table elements |
Inherited: | no |
Percentages: | refer to logical width of containing block |
Media: | visual |
Computed value: | absolute length |
Canonical order: | per grammar |
Animation type: | discrete |
These properties set the top, right, bottom, and left margin of a box, respectively.
Negative values for margin properties are allowed, but there may be implementation-specific limits.
3.2. Margin Shorthand: the margin property
Name: | margin |
---|---|
Value: | <‘margin-top’>{1,4} |
Initial: | 0 |
Applies to: | all elements except internal table elements |
Inherited: | no |
Percentages: | refer to logical width of containing block |
Media: | visual |
Computed value: | absolute length |
Canonical order: | per grammar |
Animation type: | discrete |
The margin property is a shorthand property for setting margin-top, margin-right, margin-bottom, and margin-left in a single declaration.
If there is only one component value, it applies to all sides. If there are two values, the top and bottom margins are set to the first value and the right and left margins are set to the second. If there are three values, the top is set to the first value, the left and right are set to the second, and the bottom is set to the third. If there are four values they apply to the top, right, bottom, and left, respectively.
body { margin: 2em } /* all margins set to 2em */ body { margin: 1em 2em } /* top & bottom = 1em, right & left = 2em */ body { margin: 1em 2em 3em } /* top=1em, right=2em, bottom=3em, left=2em */
The last rule of the example above is equivalent to the example below:
body { margin-top: 1em; margin-right: 2em; margin-bottom: 3em; margin-left: 2em; /* copied from opposite side (right) */ }
4. Padding
Padding is inserted between the content edge and the padding edge of a box, providing spacing between the content and the border. The padding properties specify the thickness of the padding area of a box. The padding shorthand property sets the padding for all four sides while the padding longhand properties only set their respective side. This specification defines the physical padding longhands; [css-logical-1] additionally defines flow-relative padding longhands. Both sets of properties control the same set of padding: they are just different ways of indexing each side.
Note: Backgrounds specified on the box are by default laid out and painted within the padding edges. (They are additionally painted underneath the border, in the border area.) This behavior can be adjusted using the background-origin and background-clip properties.
4.1. Page-relative (Physical) Padding Properties: the padding-top, padding-right, padding-bottom, and padding-left properties
Name: | padding-top, padding-right, padding-bottom, padding-left |
---|---|
Value: | <length-percentage> |
Initial: | 0 |
Applies to: | all elements except internal table elements |
Inherited: | no |
Percentages: | refer to logical width of containing block |
Media: | visual |
Computed value: | absolute length |
Canonical order: | per grammar |
Animation type: | discrete |
These properties set the top, right, bottom, and left padding of a box, respectively.
Negative values for padding properties are invalid.
4.2. Padding Shorthand: the padding property
Name: | padding |
---|---|
Value: | <‘padding-top’>{1,4} |
Initial: | 0 |
Applies to: | all elements except internal table elements |
Inherited: | no |
Percentages: | refer to logical width of containing block |
Media: | visual |
Computed value: | absolute length |
Canonical order: | per grammar |
Animation type: | discrete |
The padding property is a shorthand property for setting padding-top, padding-right, padding-bottom, and padding-left in a single declaration.
If there is only one component value, it applies to all sides. If there are two values, the top and bottom padding are set to the first value and the right and left padding are set to the second. If there are three values, the top is set to the first value, the left and right are set to the second, and the bottom is set to the third.
body { padding: 2em } /* all padding set to 2em */ body { padding: 1em 2em } /* top & bottom = 1em, right & left = 2em */ body { padding: 1em 2em 3em } /* top=1em, right=2em, bottom=3em, left=2em */
The last rule of the example above is equivalent to the example below:
body { padding-top: 1em; padding-right: 2em; padding-bottom: 3em; padding-left: 2em; /* copied from opposite side (right) */ }
5. Changes Since CSS Level 2
There are no non-editorial changes since CSS Level 2, other than adapting the prose slightly to account for vertical writing modes.
6. Privacy and Security Considerations
Box Model introduces no new privacy leaks, or security considerations beyond "implement it correctly".
