JSpeech Markup Language

W3C Note 05 June 2000

This Version:
Latest version:
Andrew Hunt, Speech Works International <andrew.hunt@speechworks.com>


The JSpeech Markup Language (JSML) is a text format used by applications to annotate text input to speech synthesizers. JSML elements provide a speech synthesizer with detailed information on how to speak text and thus enable improvements in the quality, naturalness and understandability of synthesized speech output. JSML defines elements that describe the structure of a document, provide pronunciations of words and phrases, indicate phrasing, emphasis, pitch and speaking rate, and control other important speech characteristics. JSML is designed to be simple to learn and use, to be portable across different synthesizers and computing platforms, and to applicable to a wide range of languages.

This document is derived from the JavaTM Speech API Markup Language (Version 0.6, October, 1999) which is available from Sun Microsystems's web site: http://java.sun.com/products/java-media/speech/.

Sun Microsystems wishes to submit this document for consideration by the W3C Voice Browser Working Group towards the development of internet standards for speech technology. We expect the resulting W3C recommendations to be of great importance to the developer community.

Please refer to Sun's submission for statements on IP rights.

Status of This Document

This document is a submission to the World Wide Web Consortium from Sun Microsystems, Inc. (see Submission Request, W3C Staff Comment). For a full list of all acknowledged Submissions, please see Acknowledged Submissions to W3C.

This document is a Note made available by W3C for discussion only. This work does not imply endorsement by, or the consensus of the W3C membership, nor that W3C has, is, or will be allocating any resources to the issues addressed by the Note. This document is a work in progress and may be updated, replaced, or rendered obsolete by other documents at any time.

This document is derived from an existing specification published by Sun and developed together with companies that collectively wrote the JavaTM Speech API. That specification is known as the Java Speech API Markup Language, and is available for reference from http://java.sun.com/products/java-media/speech/. Except for the change in the specification's name and the corresponding references in the specification, this document is technically identical to the previously published document. We have changed the name simply to protect Sun trademarks. In any case, we expect that any derived specification produced by the Consortium will have a different name.

Should any changes be required to the document, we would expect future versions to be produced by the W3C process. Sun maintains ownership of the JSML specification and reserves the right to maintain and evolve the JSML specification independently and such independent maintenance and evolution shall be owned by Sun.

A list of current W3C technical documents can be found at the Technical Reports page.



1.   Introduction
1.1       Goals for JSML
1.2       Processing JSML Documents
2.   JSML as an XML Document
2.1       Well-Formed JSML Document
2.2       XML Declaration
2.3       XML Elements and Attributes
2.4       XML Comments, Entities, CDATA
2.5       HTML vs. XML: Syntax Differences
3.   JSML Elements
3.1       "jsml" Element: Document Root
3.2       "div" Element: Text Structure
3.3       "voice" Element: Speaking Voice
3.4       "sayas" Element: Text Constructs
3.5       "phoneme" Element: Pronunciation
3.6       "emphasis" Element: Emphasizing Text
3.7       "break" Element: Pauses and Other Boundaries
3.8       "prosody" Element: Pitch, Volume and Rate
3.9       "marker" Element: Notifications
3.10       "engine" Element: Proprietary Controls
A.   JSpeech Markup Language DTD



This specification describes a format for marked-up text input to a speech synthesizer. This specification does not address the following issues which are considered programmatic issues that should be handled through the API of the speech synthesizer:



Sun Microsystems, Inc. received contributions to this specification from Apple Computer, Inc., AT&T, Dragon Systems, Inc., IBM Corporation, Novell, Inc., Philips Speech Processing and Texas Instruments Incorporated as well as from many internet reviewers.

JSML has benefited from previous initiatives to mark-up speech output, in particular those that use an SGML or XML syntax:

JSpeech Synthesis Markup Specification

1 Introduction

A speech synthesizer provides a computer with the ability to speak. Users and applications provide text to a speech synthesizer, which is then converted to audio.application -> 'computers can speak' -> speech synthesizer -> speaker -> 'computers can speak'

Figure 1: Text from an application is converted to audio output

Speech synthesizers are developed to produce natural-sounding speech output. However, producing natural human speech is a complex process, and the ability of speech synthesizers to mimic human speech is limited in many ways. For example, speech synthesizers do not "understand" what they say, so they do not always use the right style or phrasing and do not provide the same nuances as people.

The JSpeech Markup Language (JSML) allows applications to annotate text that is to be spoken with additional information that can improve the quality and naturalness of synthesized speech.

JSML is an XML Application (eXtensible Markup Language). XML is an Internet standard for representing structure and meaning in documents (Section 2 reviews XML in more detail). JSML defines a specific set of elements to mark up text to be spoken, and defines the interpretation of those elements so that there is a common understanding between synthesizers and documents producers of how marked up text will be spoken.

The JSML element set includes several types of element. First, JSML documents can include structural elements that mark paragraphs and sentences. Second, there are JSML elements to control the production of synthesized speech, including the pronunciation of words and phrases, the emphasis of words (stressing or accenting), the placements of boundaries and pauses, and the control of pitch and speaking rate. Finally, JSML includes elements that represent markers embedded in text and that enable synthesizer-specific controls.

For example, for the text in Figure 1, we could use JSML to indicate sentence structure by placing tags at the start and end of the text and emphasize the word "can" by surrounding it in an emphasis element:

<div type="sentence">Computers <emphasis>can</emphasis> speak!</div>

1.1 Goals for JSML

The primary goals for the design of JSML were:

  1. JSML must enable consistent control of voice output by speech synthesizers.
  2. It must be possible to use JSML to produce speech output from text and other content for a wide range of applications, domains and contexts.
  3. JSML must be internationalized: it must enable speech output in as many languages as possible.
  4. It should be easy to write and process JSML documents.
  5. For consistency, all features of JSML should be implementable with existing, generally available technology and the number of optional features should be minimized.
  6. JSML documents should be human-legible.
  7. Terseness is of minimal importance.

1.2 Processing JSML Documents

In XML jargon, a speech synthesizer is an XML Application1 and includes an XML Processor. The XML processor reads a JSML document and extracts the elements, data and other information within the document. The synthesizer is then responsible for interpreting the document and converting it to spoken output.

JSML documents may be provided to a speech synthesizer from various sources and, as stated in the goals, JSML is intended to be effective for producing speech output for a wide range of text types in differing application domains. For instance, JSML could be used for reading books, technical documents, email, sports scores, web pages, airline flight information and much more.

However, a speech synthesizer cannot possibly understand how to clearly read plain text from such diverse sources as email, which often contains smilies:) and other idiosyncratic text forms, or airline flight information which might be extracted from a database into a software object, or an HTML with formatting intended to look good in a visual browser.

The role of JSML is as a consistent markup for text obtained from such diverse sources. Thus, it is the responsibility of the application or user that generates the JSML document to mark up the text in a way that provides the speech synthesizer with the structural and production information required to speak the text clearly and appropriately. Figure 2 illustrates the basic steps in this process.source data -> application -> JSML document -> speech synthesizer with XML processor -> speaker

Figure 2: JSML Processing

Consider an example of reading a web page. The source data for a web page is usually an HTML page (Hypertext Markup Language), possibly with Cascading Style Sheets (CSS) or Audio Cascading Style Sheets (ACSS) providing additional data on how to render the page visually or audibly. The application processing the web page is the web browser - an application designed specifically to process and then render HTML documents. To render an HTML document visually the browser controls a graphical display to write characters and images. To render an HTML document aurally (i.e. to speak it), the browser controls a speech synthesizer and provides the synthesizer with JSML documents to be read.

Another common example is reading email. When an email reader converts an email message to spoken text it can choose to include email header information (sender, subject, date, etc.) and can mark up special content such as times, dates and email addresses so that they are spoken clearly. The email application might also perform special processing of text in the body of the message to handle attachments, indented text, common email abbreviations and so on. Here is a sample of an email message converted to JSML:


<div type="paragraph">Message from
<emphasis>Alan Schwarz</emphasis> about new synthesis
technology. Arrived at <sayas class="time">2pm</sayas>

<div type="paragraph">I've attached a diagram showing the new way we do speech synthesis.</div>

<div>Regards, Alan.</div>


2 JSML as an XML Document

A legal JSML document must be a legal XML document. Thus, familiarity with XML is important for anyone planning to author JSML documents or planning to write applications that generate JSML documents.

With the rapid, wide-spread adoption of XML on the internet, developers now have access to many books, online guides and courses on XML. Some places to start looking for XML material include:

The following is a summary of core XML document features for the benefit of readers not yet familiar with XML.

2.1 Well-Formed JSML Document

A legal JSML document must be a Well-Formed XML document. A complete technical definition of this term is beyond the scope of this document and we refer readers to the additional resources listed above.

In practical terms, a well-formed document requires that all elements, entities and other items in the document be syntactically correct. For example, a container element must have matching start and end tags and elements must be correctly nested.

What is not required is that the document be valid. Being a valid document imposes the additional constraint that the elements, attributes and values of the document match the Document Type Declaration (DTD) for JSML that is provided in Appendix A. In XML terminology, a speech synthesizer uses a non- validating XML parser.

The practical implication is that if a JSML document contains an element or other item not defined in the JSML specification, the speech synthesizer is required to ignore it. An advantage of this is that applications may retain structural or other information within a JSML document that it is useful to the application but which is ignored by the synthesizer. A disadvantage of non-validation is that misspelled tag names do not generate errors which can make errors more difficult to detect. Thus, for development purposes, we include in this specification a Document Type Declaration (DTD) which can be used with XML tools during development to check JSML documents for such errors.

2.2 XML Declaration

Although optional, it is generally recommended to start every XML document with the XML declaration of the form:

<?xml version="1.0"?>

When included, the '<' character must be the very first character in the document (not even preceded by whitespace). The declaration may optionally define the character format of the document. This is most useful when authoring JSML documents for non-ASCII languages. For example, a JSML document in Japanese may have the following declaration that it uses a Japanese character set:

<?xml version="1.0" encoding="SJIS" ?>

2.3 XML Elements and Attributes

XML documents contain elements. In Section 3 we describe the set of defined JSML elements each of which has a specific meaning to a speech synthesizer.

Elements are either container elements or empty elements. A container element is marked by a balanced pair of start and end tags (e.g., <emphasis> to open paired with </emphasis> to close). The start and end tags must have exactly the same name, and that name defines the type of the element. The text appearing between the start and end tags is the contained text as shown in Figure 3 and may include other elements. The start tag may contain zero or more attributes. Each attribute has an attribute name and an attribute value. The attribute value is always in quotes.annotated elements and attributes

Figure 3: Container Element and Attributes

An empty element has a start tag but no end tag, but has no contained text. The tag for an empty element may have zero or more attributes. XML introduces a new syntax for empty elements, as shown in Figure 4, by requiring a closing slash in the tag.annotated empty element

Figure 4: Empty Element and Attributes

2.4 XML Comments, Entities, CDATA

As a type of XML document, a JSML document may use a number of standard XML constructs such as comments, CDATA elements, and entity definitions and references.

An XML comment begins with a '<!--' character sequence and ends with a '-->' character sequence and may contain any text except the two-character sequence '--'. For example,

How now brown <!-- This is an example comment --> cow.

A CDATA section can be used in XML documents to escape blocks of text that contain characters that would otherwise be considered as markup. For example, to avoid '<' and '>' characters being interpreted as the start and end of a tag we could place them within a CDATA section:

Email from <![CDATA[ <joe@acme.com> ]]>

Entities are useful as a short-hand for defining common chunks of content. All entities have two parts. The entity declaration must occur first in the document and is of the form

<!ENTITY jsml "JSpeech Markup Language">

The entity reference may occur any number of times following the declaration, and is of the form

This is a &jsml; document.

The effect of the reference is for the replacement text in declaration ("JSpeech Markup Language") to be inserted at the reference point.

Character entities serve two functions. First, they enable a document to use characters in the Unicode character set when they are not available from the keyboard. For example, the Greek small letter beta ('b') can written as either of the following:

&#x03B2; <!-- hexadecimal code -->

&#946; <!-- decimal code -->

Second, XML provides character entities that escape characters that might otherwise be considered as markup. This symbol set includes:

Entity Symbol Name
&lt; < less than
&gt; > greater than
&amp; & ampersand
&quot; " quote
&apos; ' apostrophe

2.5 HTML vs. XML: Syntax Differences

Since many readers are familiar with HTML, we briefly describe a few key syntactic differences between HTML and XML which reflect that XML is more "fussy" than HTML (for some good reasons!).

<emphasis> legal </emphasis>

<emphasis> illegal


<a> <b> legal </b> </a>
<a> legal </a> <b> legal </b>

<a> <b> illegal </a> </b>

<a value="legal">

<a value=illegal>

<emphasis> legal </emphasis>


3 JSML Elements

In this section we define the element set of JSML and the set of defined attributes for each element. A formal Document Type Definition (DTD) for JSML is provided in Appendix A.

A JSML document consists of a root element containing structural, production, and miscellaneous elements. All JSML elements are designed to provide a speech synthesizer with information on how to speak text contained within those elements. The following table presents an overview of JSML's elements. These elements are defined in detail in the following sections.

Element Name Element
Structure jsml Container Root element for JSML documents.
div Container Marks text content structures such as paragraphs
and sentences.
Production voice Container Specifies a speaking voice for contained text.
sayas Container Specifies how to say the contained text.
phoneme Container Specifies that the contained text is a phoneme
emphasis Container Specifies emphasis for the contained text or
immediately following text.
break Empty Specifies a break in the speech.
prosody Container

Specifies a prosodic property, such as baseline
pitch, rate, or volume, for the contained text.

Miscellaneous marker Empty Requests a notification when speech reaches the
engine Container Native instructions to a specified speech

3.1 "jsml" Element: Document Root

The body of a JSML document should be contained within a "jsml" element. For example:

<?xml version="1.0"?>
... the body ...

The body should represent one complete body of text to be spoken. It would not be appropriate, for example, to break a single sentence across two JSML documents.

The root jsml element may contain any sequence of the remaining JSML elements, entities, CDATA sections and unmarked text.

jsml Container element that marks text structures, or "divisions," such as paragraphs and
lang Optional attribute that indicates the language of the contained text.
The standard internet RFC 1766 format is used (outline below).
mark Optional attribute that requests a notification when the synthesizer's production of
audio reaches this element's contained text. Its value is the text to be made available
when the notification occurs.

The optional lang attribute allows a document to be marked as containing text of a particular language. The format of the language attribute following the internet standard defined by RFC 1766. In summary, the language is given as a primary tag followed by zero or more subtags, each separated by "-". White space is not allowed and all tags are case insensitive. The two letter primary tag is an ISO 639 language abbreviation: for example, "de" for German, "en" for English, "ja" for Japanese, or "es" for Spanish. The sub-tag may be an ISO 3166 country code: for example, "US" for the United States, "br" for Brazil, "cn" for China. Examples of complete language attributes are:

en, en-US, en-uk, de-ch, zh-cn

3.2 "div" Element: Text Structure

div Container element that marks text structures, or "divisions", such as paragraphs and
type Required attribute that indicates the type of text structure contained by the element.
Defined values are "paragraph" and "sentence" or their equivalent abbreviated forms
"para" and "sent".
mark Optional attribute that requests a notification when the synthesizer's production of
audio reaches this element's contained text. Its value is the text to be made available
when the notification occurs.

The "div" element declares a span of text to be of a specific text structure type. The current specification allows the "div" element to mark paragraphs and sentences. For example:

<div type="paragraph">This a short paragraph.</div>
<div type="para"><div type="sent">The subject has changed, so this is a new paragraph.</div><div type="sent">This paragraph contains two sentences.</div></div>

The "type" attribute has defined values of "paragraph" and "para" to mark paragraphs, and values of "sentence" and "sent" to mark sentences. The abbreviated forms have identical interpretation to the full form. It is typical that paragraphs contain sentences. It is not typical for paragraphs to be contained within other paragraphs or within sentences.

Future releases of JSML may add additional structural types. For example, types of conversational interactions may be useful for dialog systems and grammatical constructs within sentences might also be marked.

3.2.1 Text Structure Conventions

Each written language has conventions for representing text structure. For example, in English, and in many other languages, an empty line or some other form of whitespace in plain text represents a paragraph boundary. Similarly, a period character ('.'), or full stop, often means a sentence boundary, but not all periods mark a sentence boundary (e.g. U.S.), and not all sentences end with a period.

For text not contained within an explicit "div" element for a paragraph, synthesizers will typically apply heuristics to determine paragraph boundaries. For text not contained within an explicit "div" element for a sentence, synthesizers will typically apply heuristics to determine sentence boundaries. Developers should be aware that heuristics may be less reliable than explicitly marked structures.

3.3 "voice" Element: Speaking Voice

voice Empty element that marks a break in the speech output.
gender Optional attribute indicating the preferred gender of the voice to speak the contained
text. Defined values are "male", "female", and "neutral".
age Optional attribute indicating the preferred age of the voice to speak the contained text.
Defined values are an age in years or one of the following descriptive values:
"child", "teenager", "younger_adult", "middle_adult", "older_adult" or "adult".
variant Optional attribute with a value of an integer or '+' indicating a preferred variant of the
other voice characteristics to speak the contained text.
name Optional attribute indicating an engine-specific voice name to speak the
contained text.
mark Optional attribute that requests a notification when the synthesizer's production
of audio reaches this element's contained text. Its value is the text to be made
available when the notification occurs.

The "voice" element is a container element that is used to mark text to be spoken in a specified voice. Voices are defined using the "gender", "age" and "variant" attributes, or in certain cases, using the "name" attribute. For example, the following requests that the text be spoken in a 30 year-old female voice:

<voice gender="female" age="30"> Some text. </voice>

The voice element is a request for a specific speaking voice but it will not always be possible for a specific synthesizer to produce the speaking voice. This is because most speech synthesizers have installed a specific set of voices with specific characteristics. If the specified voice is not available then the synthesizer is responsible for selecting the closest approximation. In the example above, if a 30-year-old female voice where not available the synthesizer might select another female voice with a different perceived age.

The descriptive values for gender of "neutral" is intended for voices that are not obviously male or female, for example, robotic voices, other non-human voices, and some children's voices.

The descriptive values for age are intended to cover broad categories of perceived age in voice: "child" is up to 12 years old, "teenager" is roughly 13 to 19 years old, "younger_adult" is roughly 20 to 40 years old, "middle_adult" is roughly 40 to 60 years old, "older_adult" is roughly 60 years and older. The "adult" value represents any adult voice (i.e. younger, middle or older adult) and thus indicates 20 years or older.

In many documents that use multiple voices it is important to be able request different voices, for example, two different 20 year-old male voices. The "variant" attribute allows such requests to be made and is defined as a variant within the other specified attributes. For example, the following tags request the first and second teenaged male voices:

<voice gender="male" age="teenager" variant="1"> ...

<voice gender="male" age="teenager" variant="2"> ...

If the synthesizer has 3 built-in teenaged male voices then the variants will eventually cycle so that variants 1, 2 and 3 will repeat as variants 4, 5 and 6 and so on. If the age were not specified, then variants would cycle through all the available male voices. A synthesizer will guarantee that a voice defined by gender, age and variant will be the same whenever referred to in the same JSML document.

The "variant" attribute may have the special value of "+". With this value, the synthesizer will attempt to assign a different voice from the current speaking voice within the constraints of the age and gender parameters.

Because different speech synthesizers have different sets of available voices, there is not a guarantee that JSML documents will be produced identically on different systems. However, with consistent use of the three attributes described so far, reasonable behavior is supported.

The fourth voice selection attribute is the "name" attribute. Most synthesizers assign names to each of these voices (sometimes also called "voice fonts"). In many operating environments the names of these voices is available to the application or person writing a JSML document and can be used in the voice tag. If specified, the name attribute takes precedence over the other voice attributes and the synthesizer will attempt to use the named voice. If the name is unknown, the synthesizer then attempts to apply the other parameters. When the name parameter is included for a specific synthesizer, it is good practice to also include the age and gender parameters of the voice so that the document is spoken reasonably on other synthesizers. For example:

<voice gender="female" age="teenager" name="Yuriko"> ...

A change in voice will usually have an effect upon the prosodic attributes of the contained text, in particular upon the pitch, pitch range and speaking rate values. The natural speaking pitch of a voice is one of its intrinsic characteristics. For example, male voices are typically lower than female and child voices. The preferred speaking rate and range of acceptable rates are also intrinsic to a voice.

When changing voices, the synthesizer may make some effort to preserve the current setting of the prosodic parameters. For instance, if the speaking rate is high when a voice is changed, the synthesizer should attempt to maintain a similar speaking rate.

3.4 "sayas" Element: Text Constructs

Written languages have many conventions for representing data such as dates, times, URLs and so on. A speech synthesizer faces a significant challenge in interpreting and speaking such text constructs and an incorrect interpretation can lead to undesirable output. For example, "1/2" could be spoken as "half", "January second", "First of February", "one out of two" and so on.

Humans readers are usually able to resolve such issues because they can apply and understanding of the context (e.g. memo about a meeting date), understanding of the text context (e.g. the preceding and following words indicate the text construct's meeting), or understanding of the communication medium (e.g. email often contains text forms not found elsewhere).

sayas Container element that says how to interpret the text contained by the element.
class Required attribute indicating the type of text contained by the elements.
Defined values are in the following table.
mark Optional attribute that requests a notification when the synthesizer's production of
audio reaches this element's contained text. Its value is the text to be made available
when the notification occurs.

Whenever it is practical, such information should be incorporated into a JSML document using the "sayas" element. The "class" attribute is defined with a range of common text structures that can be interpreted by a speech synthesizer. The format of the "class" attribute is an identifier optionally followed by a colon (":") and a format. For example, class="date:mdy" indicates a date that is formatted in US style as month-day-year.

The following is a table of the currently defined list of class values and the optional formats. Values not included in this list will be ignored by speech synthesizers. The way in which the text is converted to a spoken form is determined by the speech synthesizer and not all forms will always be converted in the same way by all synthesizers. For example, "5/15" (or "15/5") may reasonably be spoken in English as "May fifteenth" or as "the fifteenth of May".

Class Description
literal Read the string of characters in the contained text. The implementation is language
dependent, for example, in English the characters would be "spelling out", in Chinese
there would character-by-character descriptions.
date Contained text is a date. Defined format values for dates are: "date:dmy", "date:mdy",
"date:ymd", "date:ym", "date:my", "date:md" etc. where the letters represent the order
of the "day", "month" and "year" values.
time Contained text is a time. Defined format values for times are: "time:hm", "time:hms",
"time:ms" etc. where the letters represent the order of the "hour", "minute" and
"second" values.
name Contained text is a proper name of a person, company etc.
phone Contained text is a phone number.
net Contained text is an internet address or handle. Defined format values for net are:
"net:email", "net:url".
address Contained text is a postal address.
currency Contained text is a currency amount.
measure Contained text is a measurement (e.g. "5.4cm").
number Contained text is an integer, faction or floating point number.

The following are examples of how "sayas" elements may be spoken:

<sayas class="literal">JSML</sayas>
<!-- spoken as "J. S. M. L." -->

<sayas class="literal">12</sayas>
<!-- spoken as "one two" -->

<sayas class="number">31.14</sayas>
<!-- spoken as "thirty one point one four" -->

<sayas class="currency">$49.50</sayas>
<!-- spoken as "forty nine dollars, fifty cents" -->

The defined list of classes and formats does not cover all possible formats that appear in text - it would be impossible to produce a list that covers all possible forms in a large number of languages. When a text form occurs that is not included in the list, an alternative markup is to convert the written form to the spoken form by hand. For example, if the date class did not exist, the spoken form of the text could be substituted so instead of:

The program starts in <sayas class="date:my">7/99</sayas>.

the document would include:

The program starts in July nineteen ninety nine.

One advantage of the "sayas" element, when it can be applied, is that the sometimes difficult task of converting text to a speakable form is delegated to the speech synthesizer. More importantly, when processing documents of different languages, you do not have to consider the text constructs of multiple languages.

In many cases, an application will be unable to identify or determine the class of all the text sequences that might be marked with the "sayas" element. In such cases the application can leave the text forms as is and let the synthesizer attempt to determine how to speak them. Since most speech synthesizers have some ability to detect convention text forms this approach will usually succeed but there is a greater risk of misinterpretation or mispronunciation.

The "sayas" element is a container element. It typically contains only plain text or CDATA sections. It should not contain "div" elements. It may contain other production elements but it is reasonable for the speech synthesizer to ignore them as it interprets the text.

3.5 "phoneme" Element: Pronunciation

The "phoneme" element marks a sequence of text as being a phonemic string. Phonemic strings are defined using the International Phonetic Alphabet (IPA).

phoneme Container element marking a text sequence that is phoneme string.
original Optional attribute that indicates the original text represented by the phoneme
string within the element. This value is usually ignored by the synthesizer but is
useful for readability and debugging.
mark Optional attribute that requests a notification when the synthesizer's production of
audio reaches this element's contained text. Its value is the text to be made available
when the notification occurs.

Phoneme sequences may be used where words are difficult to pronounce (e.g. words of foreign origin and many proper name) or where pronunciation is ambiguous (e.g. "I will read a book" pronounced "reed", compared to "I have read a book" pronounced "red").

Where a pronunciation is repeated many times in a document it is often convenient to define an entity for that pronunciation. For example:

... the <phoneme>&boat;</phoneme> is on the water...

The International Phonetic Alphabet character set is a subset of Unicode. The IPA characters are represented by codes from "&#x0250" to "&#x02AF", by modifiers from "&#x02B0" to "&#x02FF", by diacritic characters from "&#x0300" to "&#x036F", and by certain Latin, Greek and symbol characters from the range "&#x0000" to "&#x017F". Character entities are often useful in representing phonemic strings because most of these IPA characters do not appear on keyboards. Details of the Unicode IPA support are provided in The Unicode Standard, Version 2.0 (The Unicode Consortium, Addison-Wesley Developers Press, 1996).

Unfortunately, IPA is difficult to learn and use and there is not yet standardization on the use of subsets of IPA for particular languages and dialects. Nevertheless, speech technology is converging on IPA as the only available system to represent the sounds of a wide range of languages and dialects. There is some hope that this convergence will lead to developer tools and increased standardization that will make IPA more practical.

The "phoneme" element is a container element. It is not legal to nest any other JSML elements within the "phoneme" element.

3.6 "emphasis" Element: Emphasizing Text

emphasis Element that specifies a level of emphasis for the contained text.
level Optional attribute that indicates the level of emphasis. Defined values are
"strong", "moderate" (the default) or "none".
mark Optional attribute that requests a notification when the synthesizer's production of
audio reaches this element's contained text. Its value is the text to be made available
when the notification occurs.

The emphasis element marks a range of text that should be spoken with emphasis, or what is also referred to as stress or prominence. Depending upon the language and many other factors, emphasized text may be spoken more loudly, at a different speed, or at a different pitch.

The "level" attribute can be used to indicate the degree of emphasis to be applied to the contained text. Defined values are "strong" (for strong emphasis), "moderate" (for some emphasis) and "none" (for no emphasis). The default level is "moderate".

For example:

The car is <emphasis>red</emphasis>, not blue.

Buy <emphasis level="strong">4</emphasis> burgers and fries.

3.7 "break" Element: Pauses and Other Boundaries

break Empty element that marks a break in the speech output.
size Optional attribute having one of the following relative values: "none", "small",
"medium" (default value), or "large".
time Optional attribute indicating the duration of a pause in seconds or milliseconds.
Follows the Times attribute format from the Cascading Style Sheet Specification.
e.g. "250ms", "3s".
mark] Optional attribute that requests a notification when the synthesizer's production of audio
reaches this element's contained text. Its value is the text to be made available when the
notification occurs.

The "break" element is an empty element that is used to mark phrases and boundaries in the speech output, what are often though of as pauses. To indicate what type of break is desired, the element can include a "size" attribute or a "time" attribute. (If both attributes are included, the "size" attribute takes precedence.)

A "size" attribute indicates a break that is relative to the characteristics of the current speech. A "time" attribute requests a pause for an absolute amount of time in either seconds or milliseconds. Where possible, the break should be defined by a "size" attribute rather than "time". This is because, in most languages, the perception of phrasing is speech is produced by complex interactions of pitch, timing changes, and sometimes pauses. Those factors are significantly affected by speaking context. For example, a 300 millisecond break in fast speech sounds more significant than it does in slow speech.


Take a deep breath<break/> then continue.

1 <break size="small"/> 2 <break size="small"/> 3 ...

Press 1 or wait for the tone <break time="3s"/>.

3.8 "prosody" Element: Pitch, Volume and Rate

prosody Element that specifies prosodic information for the contained text.
rate Optional numeric attribute that sets the speaking rate in words per minute. See the text
following this table for the types of values allowed.
volume Optional numeric attribute that sets the output volume on a scale of 0.0 to 1.0 where
0.0 is silence and 1.0 is maximum loudness. See the text following this table for the
type of values allowed.
pitch Optional numeric attribute that sets the baseline pitch in Hertz. See the text following
this table for the type of values allowed.
range Optional numeric attribute that sets the pitch range in Hertz. See the text following this
table for the type of values allowed.
mark Optional attribute that requests a notification when the synthesizer's production of
audio reaches this element's contained text. Its value is the text to be made available
when the notification occurs.

The "prosody" element provides prosodic control for text segments. Prosody is a collection of features of speech that includes its timing, intonation and phrasing. Proper control of prosody can improve the understandability and naturalness of speech. For example, in English, important new information is often spoken more slowly and with greater pitch range to add emphasis.

The "prosody" element provides broad parameters to a speech synthesizer. For example, setting the rate to 120 words per minute does not mean that every word is spoken in half a second, but instead suggests an approximate average rate over a longer sequence of words.

Value Description
descriptive value Defined below for each attribute.
N Sets the attribute value to the absolute numeric value of N.
+N Increase the numeric value by N.
-N Decrease the numeric value by N.
N% Set the numeric value to N percent of the current value.
+N% Increase the numeric value by N percent.
-N% Decrease the numeric value by N percent.

The four prosodic attributes - "rate", "volume", "pitch", "range" - are all numeric values with descriptive equivalents. The legal absolute and relative numeric values are shown in the table. The legal numeric forms are integers and simple floating point values (e.g. "150", "+8.5", "-10.8%"). The reasonable numeric ranges for these values depend upon a number of factors including language, speaking voice and the speech synthesizer design. As a general rule, it is best to use the descriptive values as a first choice, relative values next, and absolute values as a last resort.

The descriptive values for rate are "fast", "medium", "slow" and "default". Numeric values for rate are difficult to define because words are different across different languages. In English, normal speaking rates may be 150 to 200 words per minute. 300 words per minute is very fast. Some users, particularly users with disabilities who listen regularly to speech synthesizers, may use speaking rates up to 500 words per minute. For example,

<prosody rate="150">Text at 150 words per minute</prosody>

The descriptive values for volume are "loud", "medium", "quiet" and "default". Numeric values for volume lie in the range 0.0, for silence, to 1.0 for maximum volume. For example,

I can speak <prosody volume="quiet"> softly </prosody>

The descriptive values for both pitch and pitch range are "high", "medium", "low" and "default". The reasonable range of numeric values will depend upon factors including the language and the voice. Female and child voices are typically higher than male voices. Different male or female voices may have different natural pitch ranges and therefore different defaults. Some languages have different cultural conventions for pitch (e.g. polite voices are sometimes higher). As a broad rule of thumb, male voices will usually have a baseline pitch between 80 Hertz and 180 Hertz. Female voices lie often between 150 Hertz and 300 Hertz. Pitch range is often between 20% and 60% of the baseline pitch, with smaller ranges producing more monotone, or flat, speech.

Value Description
Nst Sets the pitch value to N semitones.
+Nst Increase the pitch value by N semitones.
-Nst Decrease the pitch value by N semitones.

The pitch and pitch range values support semitone values for absolute and relative settings. A semitone is difference in pitch between notes on a piano and many other musical instruments and a semitone value of "60.0" corresponds to "middle C" on a conventional piano or to a frequency of 261.6Hz. Legal relative and absolute semitone attribute values are shown in the table above.

While speaking a sentence, pitch moves up and down in natural speech to convey extra information about what is being said. The baseline pitch represents the normal minimum pitch of a sentence. The pitch range represents the amount of variation in pitch above the baseline. Setting the baseline pitch and pitch range can affect whether speech sounds monotonous (small range) or dynamic (large range).Graph of pitch over time

Figure 5: Baseline Pitch and Pitch Range

Note that in all cases, relative values for pitch, rate and volume increase the portability of JSML across speaking voices and synthesizers. Relative settings allow users to apply the same JSML to different voices (e.g., male and female voices with very different pitch ranges) and to set a local preference for speaking rate. For example, some users set the speaking rate very high (300 words per minute or faster) so they can listen to a lot of text very quickly.

Finally, it is quite common for more than one prosodic attribute to be changed in a single prosody element. For example, in English, when speaking parenthetical text (such as this), the pitch, pitch range and volume are usually lowered together. For example:

<div type="sent">He drove his new car, <prosody pitch="-10%" range="-20%" volume="-20%">not his ugly old car</prosody>, because he wanted to seem more impressive.</div>

3.9 "marker" Element: Notifications

The "marker" element requests a notification from the speech synthesizer to the application when the element is reached during speech output. The "marker" element has the same effect as the "mark" attribute that is optionally available for all JSML elements, but has no other side-effects. For example:

Answer <marker mark="yes_no_prompt"/> yes or no.

The mechanisms for providing notifications to an application are left to the environment in which the JSML text is being produced. In some environments there may be no such mechanism available.

3.10 "engine" Element: Proprietary Controls

engine Container element that allows JSML documents to include engine-specific controls and
name Identifier for a speech synthesizer or a comma-separated set of speech synthesizer
data Required attribute having a value of the information for the synthesizer.
mark Optional attribute that requests a notification when the synthesizer's production of
audio reaches this element's contained text. Its value is the text to be made available
when the notification occurs.

This "engine" element allows applications to utilize a speech synthesizer's proprietary capabilities by substituting engine-specific control data for the contained text. The non-proprietary data is the contained text of the element and will be spoken by any synthesizer except one that matches the identifier provided in the "name" attribute. For a synthesizer that matches the "name" attribute, the text value of the "data" attribute is spoken instead of the contained text. For example, take the following JSML text:

I am <engine name="Acme Voice" data="an Acme"> another
</engine> speech synthesizer.

An "Acme Voice" synthesizer will say "I am an Acme speech synthesizer.". All other speech synthesizers will say "I am another speech synthesizer."

A JSML document may contain "engine" elements for any number of speech synthesizers. Nesting "engine" elements is a useful way of providing variants of the same span of text for multiple engines.

Appendix A : JSpeech Markup Language DTD

<?xml version="1.0" encoding="utf-8"?>

<!-- **************************************************** -->
<!-- DTD: JSpeech Markup Language - v0.6                  -->
<!--                                                      -->
<!-- Note: JSML is interpreted by speech synthesizers     -->
<!-- with a non-validating parser, so strictly speaking   -->
<!-- a DTD is not required.  This DTD is intended         -->
<!-- to be used by development tools such as format       -->
<!-- checkers to verify JSML documents.                   -->
<!-- **************************************************** -->

<!-- **************************************************** -->
<!-- Revision history:                                    -->
<!--   created 1 December 1998   by William Walker        -->
<!--                             v0.5 specification       -->
<!--   revised 12 October 1999   by Andrew Hunt           -->
<!--                             v0.6 specification       -->
<!-- **************************************************** -->

<!-- **************************************************** -->
<!-- Define common entities                      -->
<!-- **************************************************** -->

<!-- The set of production elements -->
<!ENTITY % production

<!-- The set of miscellaneous elements -->
<!ENTITY % miscellaneous 'marker|engine'>

<!-- The mark attribute present on all elements -->
<!ENTITY % att-mark  'mark CDATA #IMPLIED'>

<!-- **************************************************** -->
<!-- JSML structural elements and attributes              -->
<!-- **************************************************** -->

<!-- Root JSML element -->
<!ELEMENT jsml (#PCDATA | div | %production; | %miscellaneous;)*>

<!ATTLIST jsml
    lang    CDATA   #IMPLIED
    %att-mark; >

<!-- preserve white space - it is significant in JSML -->
<!ATTLIST jsml xml:space (default|preserve) "preserve">

<!-- div: text structure element -->
<!ELEMENT div (#PCDATA | div | %production; | %miscellaneous;)*>

    type        (para|paragraph|sent|sentence)              #REQUIRED

<!-- **************************************************** -->
<!-- JSML production elements and attributes              -->
<!-- **************************************************** -->

<!-- "voice" requests a change in speaking voice -->
<!ELEMENT voice (#PCDATA | div | %production; |%miscellaneous;)*>

<!ATTLIST voice
    gender  (male | female | neutral)       #IMPLIED
    age     CDATA   #IMPLIED
    variant CDATA   #IMPLIED
    name    CDATA   #IMPLIED

<!-- "sayas" indicates the type of the contained text -->
<!ELEMENT sayas (#PCDATA)>

<!-- The set of sayas classes -->
<!-- We do not enumerate all possible formats here -->
<!ENTITY % sayastypes

<!ATTLIST sayas
    class   (%sayastypes;|CDATA)    #REQUIRED

<!-- "phoneme": contained text is an IPA phoneme string -->
<!ELEMENT phoneme (#PCDATA)>

<!ATTLIST phoneme
    original  CDATA  #IMPLIED

<!-- "emphasis": specify stress for contained text -->
<!ELEMENT emphasis (#PCDATA | %production; | %miscellaneous;)*>

<!ATTLIST emphasis
    level   (none|moderate|strong)  "moderate"

<!-- "break": insert a pause or other boundary -->

<!ATTLIST break
    size    (none|small|medium|large)       "medium"
    time    CDATA   #IMPLIED

<!-- "prosody": set acoustic properties for contained text -->
<!ELEMENT prosody (#PCDATA |div|%production;|%miscellaneous;)*>

<!ATTLIST prosody
    rate    CDATA   #IMPLIED
    volume  CDATA   #IMPLIED
    pitch   CDATA   #IMPLIED
    range   CDATA   #IMPLIED

<!-- "marker": insert a callback request -->

<!ATTLIST marker %att-mark;>

<!-- "engine": insert synthesizer-specific data -->
<!ELEMENT engine (#PCDATA | div | %production;|%miscellaneous;)*>

<!ATTLIST engine
    name    CDATA   #IMPLIED
    data    CDATA   #REQUIRED
    %att-mark; >

1 Extensible Markup Language (XML) 1.0, World Wide Web Consortium Recommendation (February 10, 1998) at http://www.w3.org/TR/REC-xml
