paths-data-06-t

raster image of paths-data-06-t

Verify the basic capability to handle the 'path' element, and its data attribute (d) in combination with the straight-line path commands. Two pairs of staircase figures are drawn using respectively M,H,V,Z and m,h,v,z. The shapes in each pair are identical, with one stroked and one filled.

The rendered picture should match the reference image exactly, except for possible variations in the labelling text (per CSS2 rules).
