Test name:painting-stroke-02-t
raster of painting-stroke-02-t

Verify the basic capability to handle the stroke properties (stroke, stroke-width stroke-linejoin)in combination with the rect element and straight-line path commands. The pair should be rendered as two red rectangles without an interior fill. The upper rectangle should have a stroke width of 5 with sharp corners. The lower rectangle should have a stroke width of 5 with round corners.

The rendered picture should match the reference image, except for possible variations in the labelling text (per CSS2 rules).

The test uses the 'rect' element, as well as basic fill (solid primary colors), stroke, stroke:red stroke-width:10 stroke-linejoin:round font-family (Arial) and font-size properties.
