R2RML and Direct Mapping Test Cases

W3C RDB2RDF Working Group Note 12 July 2012

This version:
http://www.w3.org/2001/sw/rdb2rdf/test-cases/NOTE-rdb2rdf-tc-20120712/
Latest version:
http://www.w3.org/2001/sw/rdb2rdf/test-cases/NOTE-rdb2rdf-tc-20120712/
Editors:
Boris Villazón-Terrazas, Universidad Politécnica de Madrid
Michael Hausenblas, DERI, NUI Galway

Abstract

This document defines the R2RML and Direct Mapping Test Cases deliverable for the RDB2RDF Working Group as defined in the Working Group's Charter.

Status of this Document

This section describes the status of this document at the time of its publication. Other documents may supersede this document. A list of current W3C publications and the latest revision of this technical report can be found in the W3C technical reports index at http://www.w3.org/TR/.

This is an Editor's Draft for review by W3C members and other interested parties.

Comments on this document should be sent to public-rdb2rdf-comments@w3.org, a mailing list with a public archive.

Publication as a Editor's Draft does not imply endorsement by the W3C Membership. This is a draft document and may be updated, replaced or obsoleted by other documents at any time. It is inappropriate to cite this document as other than work in progress.

The W3C RDB2RDF Working Group is the W3C working group responsible for this document.

This document was produced by a group operating under the 5 February 2004 W3C Patent Policy. W3C maintains a public list of any patent disclosures made in connection with the deliverables of the group; that page also includes instructions for disclosing a patent. An individual who has actual knowledge of a patent which the individual believes contains Essential Claim(s) must disclose the information in accordance with section 6 of the W3C Patent Policy.

Last Modified: $Date: 2012/07/16 16:42:36 $

Table of Contents

1 Introduction
2 Organization
3 Terminology
4 Test Cases
5 Acknowledgements

1 Introduction

This document defines the R2RML and Direct mapping test cases, consisting of a collection of test case documents (input and expected output) and the test case manifest document (describing each test case).

The purpose of the Test Cases is to verify and validate the specification of the R2RML language and Direct mapping. Moreover, these test cases can be useful to create a test harness or automated test framework for testing the interoperable implementors, i.e. R2RML engines.

The R2RML Test Case coverage matrix is available here . The DM Test Case coverage matrix is available here .

2 Organization

Test cases are organized by database. We use a descriptive naming convention for the databases. For each database we have:

The associated files (sql, ttl, and nq) are available at the W3C repository.

The following picture illustrates the organization.

RDB2RDF Test Cases

3 Terminology

R2RML engine
A software that takes a relational database (RDB) and a R2RML mapping document as input and produces an RDF graph according to the mapping document.
Test case manifest document
An RDF document that describe the test cases, relating input with expected output as well as containing additional metadata (such as description) about each test case. Typically used in a harness to automatically test an implementation regarding its conformance.

4 Test Cases

This section presents the set of test cases we have created. It is worth mentioning that the schema-qualified name feature is not excercise in the test cases.

Each test case is described using the Test Metadata vocabulary in RDFa.

Throughout all test cases, we use the base IRI <http://example.com/base/>:

R2RML is a mapping language for SQL 2008. Databases that do not support the standard SQL 2008 datatypes cannot pass the tests. Section 10 of the R2RML specification already discusses how you are supposed to deal with vendor-specific types. Implemenetors who are interested in supporting R2RML over non-SQL-compatible databases like PostgreSQL essentially need to define a slightly modified flavour of R2MRL that can handle the vendor-specific aspects. To validate an implementation of such a modified R2RML flavour, implementors obviously need a slightly modified test suite. It is not the responsibility of the WG to produce such R2RML flavours or modified test suites. On the other hand, several WG members will be interested in producing some of those, and of course it would be good if they collaborate and share results, and the WG mailing lists are a good place to discuss such work.

D000-1table1column0rows

Title: One table, a column, zero rows, no primary key

Graphical representation:

Student
Name
VARCHAR(50)

SQL:

CREATE TABLE "Student" (
       "Name" varchar(50)
);



File: D000-1table1column0rows

DirectGraphTC0000

Title: Direct mapping of an empty table

Purpose: Tests if an empty table produces an empty RDF graph

Specification reference: #no-pk

Review status: unreviewed

Input: D000-1table1column0rows

Expected result: DirectGraphTC0000

RDF:

# empty graph



R2RMLTC0000

Title: one table, one column, zero rows

Purpose: Tests if an empty table produces an empty RDF graph

Specification reference: #physical-tables

Review status: unreviewed

Input: D000-1table1column0rows

Expected result: mapped.nq

RDF:

SubjectPredicateObjectGraph

R2RML mapping: R2RMLTC0000

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\""; ] ;

    rr:subjectMap [ rr:template "http://example.com/{\"Name\"}" ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]
    .



D001-1table1column1row

Title: One table, one column, one row, no primary key

Graphical representation:

Student
Name
VARCHAR(50)
Venus

SQL:

CREATE TABLE "Student" (
"Name" varchar(50)
);
INSERT INTO "Student" ("Name") VALUES ('Venus');



File: D001-1table1column1row

DirectGraphTC0001

Title: Direct mapping that generates a BlankNode

Purpose: Tests: (1) one column mapping, no primary key; (2) generation of a "BlankNode" subject; (3) one column to one property

Specification reference: #no-pk

Review status: unreviewed

Input: D001-1table1column1row

Expected result: DirectGraphTC0001

RDF:

@base <http://example.com/base/> .

_:a <Student#Name> "Venus".
_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .



R2RMLTC0001a

Title: One column mapping, subject URI generation by using rr:template

Purpose: Tests: (1) one column mapping; (2) subject URI generation by using rr:tmplate; (3) one column to one property

Specification reference: #dfn-template-valued-term-map

Review status: unreviewed

Input: D001-1table1column1row

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Venus><http://xmlns.com/foaf/0.1/name>"Venus"

R2RML mapping: R2RMLTC0001a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"Name\"}" ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]
    .



R2RMLTC0001b

Title: One column mapping, generation of a BlankNode subject by using rr:termType

Purpose: Tests: (1) one column mapping; (2) generation of a BlankNode subject by using rr:termType; (3) one column to one property

Specification reference: #termtype

Review status: unreviewed

Input: D001-1table1column1row

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
_:Venus<http://xmlns.com/foaf/0.1/name>"Venus"

R2RML mapping: R2RMLTC0001b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "{\"Name\"}"; rr:termType rr:BlankNode ];

    rr:predicateObjectMap
    [
      rr:predicate 	  foaf:name;
      rr:objectMap    [ rr:column "\"Name\"" ]
    ]
    .



D002-1table2columns1row

Title: One table, two columns, one row, no primary key

Graphical representation:

Student
ID
INTEGER
Name
VARCHAR(15)
10Venus

SQL:

CREATE TABLE "Student" (
"ID" INTEGER,
"Name" VARCHAR(15)
);
INSERT INTO "Student" ("ID", "Name") VALUES(10,'Venus');



File: D002-1table2columns1row

DirectGraphTC0002

Title: Two columns mapping, generation of a BlankNode subject

Purpose: Tests: (1) two columns mapping; (2) generation of a BlankNode subject; (3) one column to one property

Specification reference: #no-pk

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: DirectGraphTC0002

RDF:

@base <http://example.com/base/> .

_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
_:a <Student#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
_:a <Student#Name> "Venus" .



R2RMLTC0002a

Title: Two columns mapping, generation of a subject URI by the concatenation of two column values

Purpose: Tests: (1) two column mapping, no primary key; (2) subject URI generated by the concatenation of two column values; (3) one column to one property

Specification reference: #from-template

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"
<http://example.com/10/Venus><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>

R2RML mapping: R2RMLTC0002a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"ID\"}/{\"Name\"}";
                    rr:class foaf:Person ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"ID\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]
    .



R2RMLTC0002b

Title: Two columns mapping, generation of a BlankNode subject by using rr:template and rr:termType

Purpose: Tests: (1) two column mapping, no primary key; (2) generation of a BlankNode subject by using rr:template; (3) one column to one property

Specification reference: #termtype

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
_:students10<http://xmlns.com/foaf/0.1/name>"Venus"

R2RML mapping: R2RMLTC0002b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\""; ];

    rr:subjectMap [ rr:template "students{\"ID\"}"; rr:termType rr:BlankNode;  ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]
    .



R2RMLTC0002c

Title: Two columns mapping, an undefined SQL identifier

Purpose: Tests the presence of an undefined SQL identifier

Specification reference: #dfn-sql-identifier

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0002c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"ID\"}/{\"Name\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"IDs\""; ]
    ]

    .



R2RMLTC0002d

Title: Two columns mapping, generation of a BlankNode subject by using a SQL Query that concatenates two columns

Purpose: Tests (1) two column mapping, no primary key; (2) generation of a BlankNode subject by using a SQL Query that concatenates two columns; (3) one column to one property

Specification reference: #dfn-sql-query

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: mappedd.nq

RDF:

SubjectPredicateObjectGraph
_:Student10<http://xmlns.com/foaf/0.1/name>"Venus"

R2RML mapping: R2RMLTC0002d

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

    rr:logicalTable [
                     rr:sqlQuery """
                       Select ('Student' || "ID" ) AS StudentId
                            , "ID"
                            , "Name"
                         from "Student"
                       """
                       ];

    rr:subjectMap [ rr:column "StudentId"; rr:termType rr:BlankNode; ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]
    .



R2RMLTC0002e

Title: Two columns mapping, an undefined rr:tableName

Purpose: Tests the presence of an undefined rr:tableName

Specification reference: #dfn-sql-identifier

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0002e

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Students\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"ID\"}/{\"Name\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"ID\"";  ]
    ];

    .



R2RMLTC0002f

Title: Two columns mapping, delimited identifiers referenced as regular identifiers

Purpose: Tests the presence of delimited identifiers referenced as regular identifiers. Within rr:template ID is ok, but Name is not

Specification reference: #from-template

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0002f

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/{ID}/{Name}";
                    rr:class foaf:Person ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"ID\"";  ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
	]
    .



R2RMLTC0002g

Title: Two columns mapping, invalid SQL query

Purpose: Tests the presence of an invalid SQL query

Specification reference: #dfn-sql-identifier

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0002g

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

    rr:logicalTable [
                     rr:sqlQuery """
                       THIS IS NOT A VALID SQL QUERY
                       """
                       ];

    rr:subjectMap [ rr:column "StudentId"; ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"ID\""; ]
    ];
    .



R2RMLTC0002h

Title: Two columns mapping, duplicate column name in SELECT

Purpose: Tests the presence of duplicate column names in the SELECT list of the SQL query

Specification reference: #dfn-sql-identifier

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0002h

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

    rr:logicalTable [
                     rr:sqlQuery """
                       Select ('Student' || ID ) AS StudentId
                            , "ID"
                            , "Name"
					, 1 AS "ID"
                       from "Student"
                       """
                       ];

    rr:subjectMap [ rr:column "StudentId"; ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"ID\""; ]
    ];

    .



R2RMLTC0002i

Title: Two columns mapping, SQL Version identifier

Purpose: Tests the presence of a SQL Version identifier

Specification reference: #dfn-sql-version-identifier

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: mappedi.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"

R2RML mapping: R2RMLTC0002i

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

    rr:logicalTable [
                     rr:sqlQuery """
                       SELECT "ID",
                              "Name"
                         FROM "Student"
                       """;

			rr:sqlVersion rr:SQL2008

                       ];

    rr:subjectMap [ rr:template "http://example.com/{\"ID\"}/{\"Name\"}";  ];

    rr:predicateObjectMap
    [
      rr:predicate	foaf:name ;
      rr:objectMap	[ rr:column "\"Name\"" ]
    ]
    .



R2RMLTC0002j

Title: Two columns mapping, qualified column names

Purpose: Tests the presence of qualified column names in the SELECT list of the SQL query

Specification reference: #dfn-schema-qualified-name

Review status: unreviewed

Input: D002-1table2columns1row

Expected result: mappedj.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"

R2RML mapping: R2RMLTC0002j

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [
                     rr:sqlQuery """
                       SELECT "Student"."ID", "Student"."Name"
                       FROM "Student"
                       """
                       ];

    rr:subjectMap [ rr:template "http://example.com/{\"ID\"}/{\"Name\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
	]
    .



D003-1table3columns1row

Title: One table, three columns, one row, no primary key

Graphical representation:

Student
ID
INTEGER
FirstName
VARCHAR(50)
LastName
VARCHAR(50)
10VenusWilliams

SQL:

CREATE TABLE "Student" (
"ID" INTEGER,
"FirstName" VARCHAR(50),
"LastName" VARCHAR(50)
);
INSERT INTO "Student" ("ID", "FirstName", "LastName") VALUES (10,'Venus', 'Williams');



File: D003-1table3columns1row

DirectGraphTC0003

Title: Three columns mapping, generation of a BlankNode

Purpose: Tests: (1) three columns mapping; (2) generation of a "BlankNode" subject; (3) one column to one property

Specification reference: #no-pk

Review status: unreviewed

Input: D003-1table3columns1row

Expected result: DirectGraphTC0003

RDF:

@base <http://example.com/base/> .

_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
_:a <Student#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
_:a <Student#FirstName> "Venus" .
_:a <Student#LastName> "Williams" .



R2RMLTC0003a

Title: Three columns mapping, undefined SQL Version identifier

Purpose: Tests the presence of an undefined SQL Version identifier

Specification reference: #dfn-sql-version-identifier

Review status: unreviewed

Input: D003-1table3columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0003a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [
						rr:sqlQuery """
							SELECT 	"ID",
									"FirstName",
									"LastName"
							FROM "Student"
                       """;
						rr:sqlVersion rr:SQL1979
                       ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"FirstName\"}-{\"LastName\"}";
                    rr:class foaf:Person  ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"ID\""; ]
    ];
     .



R2RMLTC0003b

Title: Three columns mapping, concatenation of columns, by using a rr:sqlQuery to produce literal

Purpose: Tests: (1) three column mapping; and (2) concatenation of columns to produce literal, by using a rr:sqlQuery

Specification reference: #dfn-sql-query

Review status: unreviewed

Input: D003-1table3columns1row

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10><http://xmlns.com/foaf/0.1/name>"Venus Williams"

R2RML mapping: R2RMLTC0003b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

     rr:logicalTable [
                     rr:sqlQuery """
                     SELECT "ID",
                            ("FirstName" || ' ' || "LastName") AS Name
                     FROM "Student"
                     """
                     ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "Name" ]
    ]
    .



R2RMLTC0003c

Title: Three columns mapping, by using a rr:template to produce literal

Purpose: Tests: (1) three column mapping; and (2) the use of rr:template to produce literal

Specification reference: #from-template

Review status: unreviewed

Input: D003-1table3columns1row

Expected result: mappedc.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student10><http://xmlns.com/foaf/0.1/name>"Venus Williams"

R2RML mapping: R2RMLTC0003c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

     rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/Student{\"ID\"}";  ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:template "{\"FirstName\"} {\"LastName\"}"; rr:termType rr:Literal; ]
    ]
    .



D004-1table2columns1row

Title: One table, two columns, one row, projection, no primary key

Graphical representation:

Student_Sport
Student
VARCHAR(50)
Sport
VARCHAR(50)
VenusTennis

SQL:

CREATE TABLE "Student_Sport"(
      "Student" varchar(50),
      "Sport" varchar(50)
);
INSERT INTO "Student_Sport" ("Student","Sport") VALUES ('Venus', 'Tennis');



File: D004-1table2columns1row

DirectGraphTC0004

Title: Two column mapping, generation of a BlankNode subject

Purpose: Tests: (1) two column mapping (2) generation of a "BlankNode" subject

Specification reference: #no-pk

Review status: unreviewed

Input: D004-1table2columns1row

Expected result: DirectGraphTC0004

RDF:

@base <http://example.com/base/> .

_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student_Sport> .
_:a <Student_Sport#Student> "Venus" .
_:a <Student_Sport#Sport> "Tennis" .



R2RMLTC0004a

Title: Two column mapping, from one row table to two different triples

Purpose: Tests: (1) two column mapping, (2) subject URI generated by a column value; (3) from one row table to two different triples (4) typing by using rr:class

Specification reference: #typing

Review status: unreviewed

Input: D004-1table2columns1row

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Venus><http://xmlns.com/foaf/0.1/name>"Venus"
<http://example.com/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/Student>
<http://example.com/Tennis><http://xmlns.com/foaf/0.1/name>"Tennis"
<http://example.com/Tennis><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/Sport>

R2RML mapping: R2RMLTC0004a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Student_Sport\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"Student\"}";
                    rr:class ex:Student ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Student\"" ]
    ]
    .

<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Student_Sport\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"Sport\"}";
                    rr:class ex:Sport  ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Sport\"" ]
    ]
	.



R2RMLTC0004b

Title: Two column mapping, presence of rr:termType rr:Literal on rr:subjectMap

Purpose: Tests: (1) two column mapping (2) the presence of rr:termType rr:Literal on rr:subjectMap, which is invalid

Specification reference: #termtype

Review status: unreviewed

Input: D004-1table2columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0004b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

      rr:logicalTable [ rr:sqlQuery """
       SELECT ('Student' || "Student") AS StudentId,
				"Student"
         FROM "Student_Sport"
       """;
	   ] ;

    rr:subjectMap [ rr:column "StudentId"; rr:termType rr:Literal;
                    rr:class ex:Student ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Student\"" ]
    ]
    .



D005-1table3columns3rows2duplicates

Title: One table, three columns, three rows, two duplicate tuples, no primary key

Graphical representation:

IOUs
fname
VARCHAR(20)
lname
VARCHAR(20)
amount
DOUBLE
BobSmith30.0E0
SueJones20.0E0
BobSmith30.0E0

SQL:

CREATE TABLE "IOUs" (
      "fname" VARCHAR(20),
      "lname"  VARCHAR(20),
      "amount" FLOAT);
INSERT INTO "IOUs" ("fname", "lname", "amount") VALUES ('Bob', 'Smith', 30);
INSERT INTO "IOUs" ("fname", "lname", "amount") VALUES ('Sue', 'Jones', 20);
INSERT INTO "IOUs" ("fname", "lname", "amount") VALUES ('Bob', 'Smith', 30);



File: D005-1table3columns3rows2duplicates

DirectGraphTC0005

Title: Generation of BlankNodes from duplicate tuples

Purpose: Tests the generation of Blank Nodes for duplicate tuples

Specification reference: #no-pk

Review status: unreviewed

Input: D005-1table3columns3rows2duplicates

Expected result: DirectGraphTC0005

RDF:

@base <http://example.com/base/> .

_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <IOUs> .
_:a <IOUs#fname> "Bob" .
_:a <IOUs#lname> "Smith" .
_:a <IOUs#amount> "3.0E1"^^<http://www.w3.org/2001/XMLSchema#double> .

_:b <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <IOUs> .
_:b <IOUs#fname> "Sue" .
_:b <IOUs#lname> "Jones" .
_:b <IOUs#amount> "2.0E1"^^<http://www.w3.org/2001/XMLSchema#double> .

_:c <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <IOUs> .
_:c <IOUs#fname> "Bob" .
_:c <IOUs#lname> "Smith" .
_:c <IOUs#amount> "3.0E1"^^<http://www.w3.org/2001/XMLSchema#double> .



R2RMLTC0005a

Title: Typing of resources

Purpose: Tests the typing of resources

Specification reference: #typing

Review status: unreviewed

Input: D005-1table3columns3rows2duplicates

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Bob;Smith><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Bob;Smith><http://example.com/owes>"3.0E1"^^<http://www.w3.org/2001/XMLSchema#double>
<http://example.com/Sue;Jones><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Sue;Jones><http://example.com/owes>"2.0E1"^^<http://www.w3.org/2001/XMLSchema#double>

R2RML mapping: R2RMLTC0005a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"IOUs\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"fname\"};{\"lname\"}";
                    rr:class foaf:Person ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:owes ;
      rr:objectMap		[ rr:column "\"amount\""; ]
    ];

    .



R2RMLTC0005b

Title: Default mapping

Purpose: Tests the generation of a default mapping for tables without a primary key

Specification reference: #default-mappings

Review status: unreviewed

Input: D005-1table3columns3rows2duplicates

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
_:BobSmith<http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/base/IOUs>
_:BobSmith<http://example.com/base/IOUs#fname>"Bob"
_:BobSmith<http://example.com/base/IOUs#lname>"Smith"
_:BobSmith<http://example.com/base/IOUs#amount>"3.0E1"^^<http://www.w3.org/2001/XMLSchema#double>
_:SueJones<http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/base/IOUs>
_:SueJones<http://example.com/base/IOUs#fname>"Sue"
_:SueJones<http://example.com/base/IOUs#lname>"Jones"
_:SueJones<http://example.com/base/IOUs#amount>"2.0E1"^^<http://www.w3.org/2001/XMLSchema#double>

R2RML mapping: R2RMLTC0005b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"IOUs\"" ];

    rr:subjectMap [ rr:template "{\"fname\"}_{\"lname\"}";
                    rr:class <IOUs>;
                    rr:termType rr:BlankNode; ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#fname> ;
      rr:objectMap		[ rr:column "\"fname\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#lname> ;
      rr:objectMap		[ rr:column "\"lname\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#amount> ;
      rr:objectMap		[ rr:column "\"amount\""; ]
    ];
    .



D006-1table1primarykey1column1row

Title: One table, one primary key, one column, one row

Graphical representation:

Student
Name (PK)
VARCHAR(50)
Venus

SQL:

CREATE TABLE "Student" (
"Name" varchar(50) PRIMARY KEY
);
INSERT INTO "Student" ("Name") VALUES ('Venus');



File: D006-1table1primarykey1column1row

DirectGraphTC0006

Title: Generation of subjects

Purpose: Tests the generation of subjects

Specification reference: #lead-ex

Review status: unreviewed

Input: D006-1table1primarykey1column1row

Expected result: DirectGraphTC0006

RDF:

@base <http://example.com/base/> .

<Student/Name=Venus> <Student#Name> "Venus" .
<Student/Name=Venus> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .




R2RMLTC0006a

Title: Long form of R2RML by using rr:constant in rr:subjectMap, rr:predicateMap, rr:objectMap and rr:graphMap

Purpose: Tests the use of rr:constant in rr:subjectMap, rr:predicateMap, rr:objectMap and rr:graphMap

Specification reference: #constant

Review status: unreviewed

Input: D006-1table1primarykey1column1row

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/BadStudent><http://example.com/description>"Bad Student"<http://example.com/graph/student>

R2RML mapping: R2RMLTC0006a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:constant ex:BadStudent;
    				rr:graphMap [ rr:constant <http://example.com/graph/student> ]; ];

    rr:predicateObjectMap
    [
      rr:predicateMap [ rr:constant ex:description ];
      rr:objectMap    [ rr:constant "Bad Student"; ]
    ]
    .



D007-1table1primarykey2columns1row

Title: One table, one primary key, two columns, one row

Graphical representation:

Student
ID (PK)
INTEGER
Name
VARCHAR(50)
10Venus

SQL:

CREATE TABLE "Student" (
"ID" integer,
"Name" varchar(50),
PRIMARY KEY ("ID")
);
INSERT INTO "Student" ("ID", "Name") VALUES(10,'Venus');



File: D007-1table1primarykey2columns1row

DirectGraphTC0007

Title: Generation of a subject

Purpose: Tests the generation of a subject

Specification reference: #lead-ex

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: DirectGraphTC0007

RDF:

@base <http://example.com/base/> .

<Student/ID=10> <Student#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=10> <Student#Name> "Venus" .
<Student/ID=10> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .



R2RMLTC0007a

Title: Typing resources by relying on rdf:type predicate

Purpose: Tests the typing resources by relying on rdf:type predicate

Specification reference: #typing

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>

R2RML mapping: R2RMLTC0007a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type ;
		rr:object		foaf:Person;
	];
    .



R2RMLTC0007b

Title: Assigning triples to Named Graphs

Purpose: Tests the generation of triples to a named graph

Specification reference: #named-graphs

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"<http://example.com/PersonGraph>
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person><http://example.com/PersonGraph>

R2RML mapping: R2RMLTC0007b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\""; ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
				    rr:graph ex:PersonGraph;
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]

    .



R2RMLTC0007c

Title: One column mapping, using rr:class

Purpose: Tests subjectmap with more than one class IRIs, rr:class

Specification reference: #typing

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: mappedc.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"
<http://example.com/Student/10/Venus><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/Student>

R2RML mapping: R2RMLTC0007c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [
		rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
		rr:class foaf:Person,ex:Student;
	];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap	[ rr:column "\"ID\"";  ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]

    .



R2RMLTC0007d

Title: One column mapping, specifying an rr:predicateObjectMap with rdf:type

Purpose: Tests subjectmap with an alternative of having rr:class, i.e., by specifying an rr:predicateObjectMap with predicate rdf:type

Specification reference: #typing

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: mappedd.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"
<http://example.com/Student/10/Venus><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/Student>

R2RML mapping: R2RMLTC0007d

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [
		rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object	foaf:Person;
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object	ex:Student;
	];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap    [ rr:column "\"ID\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]

    .



R2RMLTC0007e

Title: One column mapping, using rr:graphMap and rr:class

Purpose: Tests subjectmap with rr:graphMap and rr:class

Specification reference: #named-graphs

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: mappede.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer><http://example.com/PersonGraph>
<http://example.com/Student/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"<http://example.com/PersonGraph>
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person><http://example.com/PersonGraph>

R2RML mapping: R2RMLTC0007e

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
					rr:graph	ex:PersonGraph ;
					rr:class foaf:Person
	];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap	[ rr:column "\"ID\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]

    .



R2RMLTC0007f

Title: One column mapping, using rr:graphMap and specifying an rr:predicateObjectMap with rdf:type

Purpose: Tests subjectmap with rr:graphMap and specifying an rr:predicateObjectMap with predicate rdf:type

Specification reference: #named-graphs

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: mappedf.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person><http://example.com/PersonGraph>
<http://example.com/Student/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"<http://example.com/PersonGraph>
<http://example.com/Student/10/Venus><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer><http://example.com/PersonGraph>

R2RML mapping: R2RMLTC0007f

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

	rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
					rr:graph	ex:PersonGraph ;
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type ;
		rr:object	foaf:Person ;
	];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap    [ rr:column "\"ID\"";  ]
    ];

    rr:predicateObjectMap
    [
		rr:predicate	foaf:name ;
		rr:objectMap	[ rr:column "\"Name\"" ]
    ]
    .



R2RMLTC0007g

Title: Assigning triples to the default graph

Purpose: Tests the generation of triples to the default graph

Specification reference: #named-graphs

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: mappedg.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus><http://xmlns.com/foaf/0.1/name>"Venus"
<http://example.com/Student/10/Venus><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>

R2RML mapping: R2RMLTC0007g

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\""; ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
				    rr:graph rr:defaultGraph;
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]

    .



R2RMLTC0007h

Title: Assigning triples to a non-IRI named graph

Purpose: Tests the generation of triples to a non-IRI named graph, which is an error

Specification reference: #named-graphs

Review status: unreviewed

Input: D007-1table1primarykey2columns1row

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0007h

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\""; ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
				    rr:graphMap [ rr:column "\"Name\""; rr:termType rr:Literal; ]
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]

    .



D008-1table1compositeprimarykey3columns1row

Title: One table, a composite primary key, three columns, one row

Graphical representation:

Student
ID (PK)
INTEGER
Name (PK)
VARCHAR(50)
Sport
VARCHAR(50)
10Venus WilliamsTennis

SQL:

CREATE TABLE "Student" (
"ID" integer,
"Name" varchar(50),
"Sport" varchar (50),
PRIMARY KEY ("ID","Name")
);
INSERT INTO "Student" ("ID", "Name","Sport") VALUES(10,'Venus Williams','Tennis');



File: D008-1table1compositeprimarykey3columns1row

DirectGraphTC0008

Title: Generation of direct graph from a table with composite primary key

Purpose: Tests the generation of a direct graph from a table with a composite primary key

Specification reference: #lead-ex

Review status: unreviewed

Input: D008-1table1compositeprimarykey3columns1row

Expected result: DirectGraphTC0008

RDF:

@base <http://example.com/base/> .

<Student/ID=10;Name=Venus%20Williams> <Student#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=10;Name=Venus%20Williams> <Student#Name> "Venus Williams" .
<Student/ID=10;Name=Venus%20Williams> <Student#Sport> "Tennis" .
<Student/ID=10;Name=Venus%20Williams> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .




R2RMLTC0008a

Title: Generation of triples to a target graph by using rr:graphMap and rr:template

Purpose: Test that results of the mapping can be directed to a target graph by using rr:graphMap and rr:template

Specification reference: #named-graphs

Review status: unreviewed

Input: D008-1table1compositeprimarykey3columns1row

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus%20Williams><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person><http://example.com/graph/Student/10/Venus%20Williams>
<http://example.com/Student/10/Venus%20Williams><http://xmlns.com/foaf/0.1/name>"Venus Williams"<http://example.com/graph/Student/10/Venus%20Williams>
<http://example.com/Student/10/Venus%20Williams><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer><http://example.com/graph/Student/10/Venus%20Williams>
<http://example.com/Student/10/Venus%20Williams><http://example.com/Sport>"Tennis"<http://example.com/graph/Student/10/Venus%20Williams>

R2RML mapping: R2RMLTC0008a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

	rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
					rr:graphMap [ rr:template "http://example.com/graph/Student/{\"ID\"}/{\"Name\"}"; ]
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type ;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap    [ rr:column "\"ID\"";  ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:Sport ;
      rr:objectMap    [ rr:column "\"Sport\"" ]
    ]

    .



R2RMLTC0008b

Title: Generation of triples referencing object map

Purpose: Tests the mapping specification referencing object map without join

Specification reference: #dfn-referencing-object-map

Review status: unreviewed

Input: D008-1table1compositeprimarykey3columns1row

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus%20Williams><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Student/10/Venus%20Williams><http://xmlns.com/foaf/0.1/name>"Venus Williams"
<http://example.com/Student/10/Venus%20Williams><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/Student/10/Venus%20Williams><http://example.com/Sport><http://example.com/Tennis>
<http://example.com/Tennis><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://activity.com/Sport>

R2RML mapping: R2RMLTC0008b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix activity: <http://activity.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap2>
	a rr:TriplesMap;
	rr:logicalTable [ rr:tableName "\"Student\"" ];

	rr:subjectMap [ rr:template "http://example.com/{\"Sport\"}"; ];

	rr:predicateObjectMap [
		rr:predicate	rdf:type ;
		rr:object		activity:Sport ;
	];
.

<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}";
	];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type ;
		rr:object		foaf:Person ;
	];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap    [ rr:column "\"ID\"";  ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:Sport ;
      rr:objectMap		<RefObjectMap1>
    ]

 .


<RefObjectMap1>
	a rr:RefObjectMap;
	rr:parentTriplesMap <TriplesMap2> ;
.





R2RMLTC0008c

Title: Generation of triples by using multiple predicateMaps within a rr:predicateObjectMap

Purpose: Tests the generation of triples by using multiple predicateMaps within a rr:predicateObjectMap

Specification reference: #physical-tables

Review status: unreviewed

Input: D008-1table1compositeprimarykey3columns1row

Expected result: mappedc.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Student/10/Venus%20Williams><http://xmlns.com/foaf/0.1/name>"Venus Williams"
<http://example.com/Student/10/Venus%20Williams><http://example.com/name>"Venus Williams"

R2RML mapping: R2RMLTC0008c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/Student/{\"ID\"}/{\"Name\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	foaf:name ;
		rr:predicate	ex:name ;
		rr:objectMap	[ rr:column "\"Name\"" ]
    ];
    .



D009-2tables1primarykey1foreignkey

Title: Two tables, a primary key, a foreign key

Graphical representation:

Student
ID (PK)
INTEGER
Sport (FK)
INTEGER
Name
VARCHAR(50)
10100Venus Williams
20NULLDemi Moore
Sport
ID (PK)
INTEGER
Name
VARCHAR(50)
100Tennis

SQL:

CREATE TABLE "Sport" (
"ID" integer,
"Name" varchar (50),
PRIMARY KEY ("ID")
);

CREATE TABLE "Student" (
"ID" integer,
"Name" varchar(50),
"Sport" integer,
PRIMARY KEY ("ID"),
FOREIGN KEY("Sport") REFERENCES "Sport"("ID")
);

INSERT INTO "Sport" ("ID", "Name") VALUES (100,'Tennis');
INSERT INTO "Student" ("ID", "Name", "Sport") VALUES (10,'Venus Williams', 100);
INSERT INTO "Student" ("ID", "Name", "Sport") VALUES (20,'Demi Moore', NULL);




File: D009-2tables1primarykey1foreignkey

DirectGraphTC0009

Title: Two tables 1 primary key 1 foreign key

Purpose: Tests two tables with a primary key and a foreign key

Specification reference: #fk-candidate

Review status: unreviewed

Input: D009-2tables1primarykey1foreignkey

Expected result: DirectGraphTC0009

RDF:

@base <http://example.com/base/> .

<Student/ID=10> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
<Student/ID=10> <Student#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=10> <Student#Name> "Venus Williams" .
<Student/ID=10> <Student#Sport> "100"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=10> <Student#ref-Sport> <Sport/ID=100> .
<Student/ID=20> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
<Student/ID=20> <Student#ID> "20"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=20> <Student#Name> "Demi Moore" .
<Sport/ID=100> <Sport#ID> "100"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Sport/ID=100> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Sport> .
<Sport/ID=100> <Sport#Name> "Tennis" .




R2RMLTC0009a

Title: Generation of triples from foreign key relations

Purpose: Test foreign key relationships among logical tables

Specification reference: #foreign-key

Review status: unreviewed

Input: D009-2tables1primarykey1foreignkey

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/resource/student_10><http://xmlns.com/foaf/0.1/name>"Venus Williams"
<http://example.com/resource/student_20><http://xmlns.com/foaf/0.1/name>"Demi Moore"
<http://example.com/resource/sport_100><http://www.w3.org/2000/01/rdf-schema#label>"Tennis"
<http://example.com/resource/student_10><http://example.com/ontology/practises><http://example.com/resource/sport_100>

R2RML mapping: R2RMLTC0009a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/resource/student_{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	foaf:name ;
		rr:objectMap	[ rr:column "\"Name\""; ];
    ];

    rr:predicateObjectMap
    [
      rr:predicate	<http://example.com/ontology/practises> ;
      rr:objectMap	[
           a rr:RefObjectMap ;
           rr:parentTriplesMap <TriplesMap2>;
           rr:joinCondition [
				rr:child "\"Sport\"" ;
				rr:parent "\"ID\"" ;
		  ]
      ];
    ];
    .

<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Sport\"" ];

    rr:subjectMap [ rr:template "http://example.com/resource/sport_{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	rdfs:label ;
		rr:objectMap	[ rr:column "\"Name\""; ];
    ];
	.



R2RMLTC0009b

Title: Generation of triples to multiple graphs

Purpose: Test that results from distinct parts of the mapping can be directed to different target graphs.

Specification reference: #named-graphs

Review status: unreviewed

Input: D009-2tables1primarykey1foreignkey

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/resource/student_10><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/ontology/Student><http://example.com/graph/students>
<http://example.com/resource/student_10><http://xmlns.com/foaf/0.1/name>"Venus Williams"<http://example.com/graph/students>
<http://example.com/resource/student_20><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/ontology/Student><http://example.com/graph/students>
<http://example.com/resource/student_20><http://xmlns.com/foaf/0.1/name>"Demi Moore"<http://example.com/graph/students>
<http://example.com/resource/sport_100><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/ontology/Sport><http://example.com/graph/sports>
<http://example.com/resource/sport_100><http://www.w3.org/2000/01/rdf-schema#label>"Tennis"<http://example.com/graph/sports>
<http://example.com/resource/student_10><http://example.com/ontology/practises><http://example.com/resource/sport_100><http://example.com/graph/practise>
<http://example.com/resource/student_10><http://example.com/ontology/practises><http://example.com/resource/sport_100><http://example.com/graph/students>

R2RML mapping: R2RMLTC0009b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Student\"" ];

    rr:subjectMap
    [
        rr:template	"http://example.com/resource/student_{\"ID\"}";
        rr:class	<http://example.com/ontology/Student>;
        rr:graph	<http://example.com/graph/students> ;
    ];

    rr:predicateObjectMap
    [
      rr:predicate	foaf:name ;
      rr:objectMap	[ rr:column "\"Name\""; ];
      rr:graph		<http://example.com/graph/students> ;
    ];

    rr:predicateObjectMap
    [
      rr:predicate	<http://example.com/ontology/practises> ;
      rr:objectMap	[
           a rr:RefObjectMap ;
           rr:parentTriplesMap <TriplesMap2>;
           rr:joinCondition [
				rr:child "\"Sport\"" ;
				rr:parent "\"ID\"" ;
		   ]
      ];
      rr:graph	<http://example.com/graph/practise> ;
    ];
    .

<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Sport\"" ];

    rr:subjectMap
    [
        rr:template "http://example.com/resource/sport_{\"ID\"}";
        rr:class <http://example.com/ontology/Sport>;
        rr:graph <http://example.com/graph/sports> ;
    ];

    rr:predicateObjectMap
    [
		rr:predicate	rdfs:label ;
		rr:objectMap	[ rr:column "\"Name\""; ];
    ];
	.



R2RMLTC0009c

Title: Unnamed column in a logical table

Purpose: Test a logical table with unnamed column.

Specification reference: #dfn-sql-query

Review status: unreviewed

Input: D009-2tables1primarykey1foreignkey

Expected result: mappedc.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/resource/student_Venus%20Williams><http://xmlns.com/foaf/0.1/name>"Venus Williams"
<http://example.com/resource/student_Demi%20Moore><http://xmlns.com/foaf/0.1/name>"Demi Moore"

R2RML mapping: R2RMLTC0009c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@base <http://example.com/base/> .

<TriplesMap1>
   a rr:TriplesMap;

   rr:logicalTable [ rr:sqlQuery """
        SELECT "Name", COUNT("Sport")
        FROM "Student"
        GROUP BY "Name"
        """ ];

    rr:subjectMap [ rr:template "http://example.com/resource/student_{\"Name\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate	foaf:name ;
      rr:objectMap	[ rr:column "\"Name\""; ];
    ];
  .




R2RMLTC0009d

Title: Named column in logical table

Purpose: Test a logical table named column.

Specification reference: #dfn-sql-query

Review status: unreviewed

Input: D009-2tables1primarykey1foreignkey

Expected result: mappedd.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/resource/student_Venus%20Williams><http://xmlns.com/foaf/0.1/name>"Venus Williams"
<http://example.com/resource/student_Venus%20Williams><http://example.com/numSport>"1"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/resource/student_Demi%20Moore><http://xmlns.com/foaf/0.1/name>"Demi Moore"
<http://example.com/resource/student_Demi%20Moore><http://example.com/numSport>"0"^^<http://www.w3.org/2001/XMLSchema#integer>

R2RML mapping: R2RMLTC0009d

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@base <http://example.com/base/> .

<TriplesMap1>
   a rr:TriplesMap;

   rr:logicalTable [ rr:sqlQuery """
        SELECT "Name", COUNT("Sport") as SPORTCOUNT
        FROM "Student"
        GROUP BY "Name"
        """ ];

    rr:subjectMap [ rr:template "http://example.com/resource/student_{\"Name\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate	foaf:name ;
      rr:objectMap	[ rr:column "\"Name\""; ];
    ];

   rr:predicateObjectMap
    [
		rr:predicate	ex:numSport ;
		rr:objectMap	[ rr:column "SPORTCOUNT"; ];
    ];
  .




D010-1table1primarykey3colums3rows

Title: One table, a primary key, three columns, three rows

Graphical representation:

Country Info
Country Code (PK)
INTEGER
Name
VARCHAR(100)
ISO 3166
VARCHAR(10)
1Bolivia, Plurinational State ofBO
2IrelandIE
3Saint Martin (French part)MF

SQL:

CREATE TABLE "Country Info" (
  "Country Code" INTEGER PRIMARY KEY,
  "Name" VARCHAR(100),
  "ISO 3166" VARCHAR(10)
);
INSERT INTO "Country Info" ("Country Code", "Name", "ISO 3166") VALUES (1, 'Bolivia, Plurinational State of', 'BO');
INSERT INTO "Country Info" ("Country Code", "Name", "ISO 3166") VALUES (2, 'Ireland', 'IE');
INSERT INTO "Country Info" ("Country Code", "Name", "ISO 3166") VALUES (3, 'Saint Martin (French part)', 'MF');



File: D010-1table1primarykey3colums3rows

DirectGraphTC0010

Title: Generation of direct graph for table names with spaces

Purpose: Tests the generation of the direct graph for table names with spaces

Specification reference: #lead-ex

Review status: unreviewed

Input: D010-1table1primarykey3colums3rows

Expected result: DirectGraphTC0010

RDF:

@base <http://example.com/base/> .

<Country%20Info/Country%20Code=1> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Country%20Info> .
<Country%20Info/Country%20Code=1> <Country%20Info#Country%20Code> "1"^^<http://www.w3.org/2001/XMLSchema#integer>  .
<Country%20Info/Country%20Code=1> <Country%20Info#Name> "Bolivia, Plurinational State of"  .
<Country%20Info/Country%20Code=1> <Country%20Info#ISO%203166> "BO"  .
<Country%20Info/Country%20Code=2> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Country%20Info> .
<Country%20Info/Country%20Code=2> <Country%20Info#Country%20Code> "2"^^<http://www.w3.org/2001/XMLSchema#integer>  .
<Country%20Info/Country%20Code=2> <Country%20Info#Name> "Ireland"  .
<Country%20Info/Country%20Code=2> <Country%20Info#ISO%203166> "IE"  .
<Country%20Info/Country%20Code=3> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Country%20Info> .
<Country%20Info/Country%20Code=3> <Country%20Info#Country%20Code> "3"^^<http://www.w3.org/2001/XMLSchema#integer>  .
<Country%20Info/Country%20Code=3> <Country%20Info#Name> "Saint Martin (French part)"  .
<Country%20Info/Country%20Code=3> <Country%20Info#ISO%203166> "MF"  .



R2RMLTC0010a

Title: Template with table column with special chars

Purpose: Tests a template with blank space in column value

Specification reference: #dfn-template-valued-term-map

Review status: unreviewed

Input: D010-1table1primarykey3colums3rows

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/1><http://example.com/name>"Bolivia, Plurinational State of"
<http://example.com/2><http://example.com/name>"Ireland"
<http://example.com/3><http://example.com/name>"Saint Martin (French part)"

R2RML mapping: R2RMLTC0010a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Country Info\""; ] ;

	rr:subjectMap [ rr:template "http://example.com/{\"Country Code\"}" ];

	rr:predicateObjectMap
	[
		rr:predicate		ex:name ;
		rr:objectMap		[ rr:column "\"Name\"" ]
 	]
 	.



R2RMLTC0010b

Title: Template with table columns with special chars

Purpose: Tests a template with special chars in column value

Specification reference: #dfn-template-valued-term-map

Review status: unreviewed

Input: D010-1table1primarykey3colums3rows

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/1/Bolivia%2C%20Plurinational%20State%20of><http://example.com/name>"Bolivia, Plurinational State of"
<http://example.com/2/Ireland><http://example.com/name>"Ireland"
<http://example.com/3/Saint%20Martin%20(French%20part)><http://example.com/name>"Saint Martin (French part)"

R2RML mapping: R2RMLTC0010b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Country Info\""; ] ;

	rr:subjectMap [ rr:template "http://example.com/{\"Country Code\"}/{\"Name\"}" ];

	rr:predicateObjectMap
	[
		rr:predicate	ex:name ;
		rr:objectMap    [ rr:column "\"Name\"" ]
    ]
    .



R2RMLTC0010c

Title: Template with table columns with special chars and backslashes

Purpose: Tests a template with special chars in column value and backslash escapes in string templates

Specification reference: #dfn-template-valued-term-map

Review status: unreviewed

Input: D010-1table1primarykey3colums3rows

Expected result: mappedc.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/1/Bolivia%2C%20Plurinational%20State%20of><http://example.com/code>"{{{ BO }}}"
<http://example.com/2/Ireland><http://example.com/code>"{{{ IE }}}"
<http://example.com/3/Saint%20Martin%20(French%20part)><http://example.com/code>"{{{ MF }}}"

R2RML mapping: R2RMLTC0010c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Country Info\""; ] ;

	rr:subjectMap [ rr:template "http://example.com/{\"Country Code\"}/{\"Name\"}" ];

	rr:predicateObjectMap
	[
		rr:predicate	ex:code ;
		rr:objectMap    [ rr:template "\\{\\{\\{ {\"ISO 3166\"} \\}\\}\\}"; rr:termType rr:Literal; ]
	]
    .



D011-M2MRelations

Title: Database with many to many relations

Graphical representation:

Student
ID (PK)
INTEGER
FirstName
VARCHAR(50)
LastName
VARCHAR(50)
10VenusWilliams
11FernandoAlonso
12DavidVilla
Student_Sport
ID_Student (PFK)
INTEGER
ID_Sport (PFK)
INTEGER
10110
11111
11112
12111
Sport
ID (PK)
INTEGER
Description
VARCHAR(50)
110Tennis
111Football
112Formula1

SQL:

CREATE TABLE "Student" (
"ID" integer PRIMARY KEY,
"FirstName" varchar(50),
"LastName" varchar(50)
);
CREATE TABLE "Sport" (
"ID" integer PRIMARY KEY,
"Description" varchar(50)
);
CREATE TABLE "Student_Sport" (
"ID_Student" integer,
"ID_Sport" integer,
PRIMARY KEY ("ID_Student","ID_Sport"),
FOREIGN KEY ("ID_Student") REFERENCES "Student"("ID"),
FOREIGN KEY ("ID_Sport") REFERENCES "Sport"("ID")
);

INSERT INTO "Student" ("ID","FirstName","LastName") VALUES (10,'Venus', 'Williams');
INSERT INTO "Student" ("ID","FirstName","LastName") VALUES (11,'Fernando', 'Alonso');
INSERT INTO "Student" ("ID","FirstName","LastName") VALUES (12,'David', 'Villa');

INSERT INTO "Sport" ("ID", "Description") VALUES (110,'Tennis');
INSERT INTO "Sport" ("ID", "Description") VALUES (111,'Football');
INSERT INTO "Sport" ("ID", "Description") VALUES (112,'Formula1');

INSERT INTO "Student_Sport" ("ID_Student", "ID_Sport") VALUES (10,110);
INSERT INTO "Student_Sport" ("ID_Student", "ID_Sport") VALUES (11,111);
INSERT INTO "Student_Sport" ("ID_Student", "ID_Sport") VALUES (11,112);
INSERT INTO "Student_Sport" ("ID_Student", "ID_Sport") VALUES (12,111);



File: D011-M2MRelations

DirectGraphTC0011

Title: Many to Many relations

Purpose: Tests the generation of triples from tables M to M relations

Specification reference: #lead-ex

Review status: unreviewed

Input: D011-M2MRelations

Expected result: DirectGraphTC0011

RDF:

@base <http://example.com/base/> .

<Student/ID=10> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
<Student/ID=10> <Student#FirstName> "Venus".
<Student/ID=10> <Student#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=10> <Student#LastName> "Williams" .
<Student/ID=11> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
<Student/ID=11> <Student#FirstName> "Fernando".
<Student/ID=11> <Student#ID> "11"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=11> <Student#LastName> "Alonso" .
<Student/ID=12> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
<Student/ID=12> <Student#FirstName> "David".
<Student/ID=12> <Student#ID> "12"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student/ID=12> <Student#LastName> "Villa" .
<Student_Sport/ID_Student=10;ID_Sport=110> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student_Sport> .
<Student_Sport/ID_Student=10;ID_Sport=110> <Student_Sport#ID_Student> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=10;ID_Sport=110> <Student_Sport#ref-ID_Student> <Student/ID=10> .
<Student_Sport/ID_Student=10;ID_Sport=110> <Student_Sport#ID_Sport> "110"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=10;ID_Sport=110> <Student_Sport#ref-ID_Sport> <Sport/ID=110> .
<Student_Sport/ID_Student=11;ID_Sport=111> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student_Sport> .
<Student_Sport/ID_Student=11;ID_Sport=111> <Student_Sport#ID_Student> "11"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=11;ID_Sport=111> <Student_Sport#ref-ID_Student> <Student/ID=11> .
<Student_Sport/ID_Student=11;ID_Sport=111> <Student_Sport#ID_Sport> "111"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=11;ID_Sport=111> <Student_Sport#ref-ID_Sport> <Sport/ID=111> .
<Student_Sport/ID_Student=11;ID_Sport=112> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student_Sport> .
<Student_Sport/ID_Student=11;ID_Sport=112> <Student_Sport#ID_Student> "11"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=11;ID_Sport=112> <Student_Sport#ref-ID_Student> <Student/ID=11> .
<Student_Sport/ID_Student=11;ID_Sport=112> <Student_Sport#ID_Sport> "112"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=11;ID_Sport=112> <Student_Sport#ref-ID_Sport> <Sport/ID=112> .
<Student_Sport/ID_Student=12;ID_Sport=111> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student_Sport> .
<Student_Sport/ID_Student=12;ID_Sport=111> <Student_Sport#ID_Student> "12"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=12;ID_Sport=111> <Student_Sport#ref-ID_Student> <Student/ID=12> .
<Student_Sport/ID_Student=12;ID_Sport=111> <Student_Sport#ID_Sport> "111"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Student_Sport/ID_Student=12;ID_Sport=111> <Student_Sport#ref-ID_Sport> <Sport/ID=111> .
<Sport/ID=110> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type>  <Sport> .
<Sport/ID=110> <Sport#ID> "110"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Sport/ID=110> <Sport#Description> "Tennis" .
<Sport/ID=111>  <http://www.w3.org/1999/02/22-rdf-syntax-ns#type>  <Sport> .
<Sport/ID=111> <Sport#ID> "111"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Sport/ID=111> <Sport#Description> "Football" .
<Sport/ID=112>  <http://www.w3.org/1999/02/22-rdf-syntax-ns#type>  <Sport> .
<Sport/ID=112>  <Sport#ID> "112"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Sport/ID=112>  <Sport#Description> "Formula1" .




R2RMLTC0011a

Title: M to M relation, by using a SQL query

Purpose: Tests, M to M relations, by using a SQL query

Specification reference: #r2rml-views

Review status: unreviewed

Input: D011-M2MRelations

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/110/Tennis><http://example.com/description>"Tennis"
<http://example.com/110/Tennis><http://example.com/id>"110"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/10/Venus;Williams><http://example.com/plays><http://example.com/110/Tennis>
<http://example.com/10/Venus;Williams><http://example.com/lastName>"Williams"
<http://example.com/10/Venus;Williams><http://example.com/firstName>"Venus"
<http://example.com/10/Venus;Williams><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/111/Football><http://example.com/description>"Football"
<http://example.com/111/Football><http://example.com/id>"111"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/12/David;Villa><http://example.com/plays><http://example.com/111/Football>
<http://example.com/12/David;Villa><http://example.com/lastName>"Villa"
<http://example.com/12/David;Villa><http://example.com/firstName>"David"
<http://example.com/12/David;Villa><http://example.com/id>"12"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/112/Formula1><http://example.com/description>"Formula1"
<http://example.com/112/Formula1><http://example.com/id>"112"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/11/Fernando;Alonso><http://example.com/lastName>"Alonso"
<http://example.com/11/Fernando;Alonso><http://example.com/firstName>"Fernando"
<http://example.com/11/Fernando;Alonso><http://example.com/id>"11"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/11/Fernando;Alonso><http://example.com/plays><http://example.com/111/Football>
<http://example.com/11/Fernando;Alonso><http://example.com/plays><http://example.com/112/Formula1>

R2RML mapping: R2RMLTC0011a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:sqlQuery """
       SELECT "Student"."ID" as ID,
              "Student"."FirstName" as FirstName,
              "Student"."LastName" as LastName,
              "Sport"."Description" as Description,
              "Sport"."ID" as Sport_ID
       FROM "Student","Sport","Student_Sport"
       WHERE "Student"."ID" = "Student_Sport"."ID_Student"
       AND "Sport"."ID" = "Student_Sport"."ID_Sport";
       """; ];

    rr:subjectMap [ rr:template "http://example.com/{ID}/{FirstName};{LastName}" ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:id ;
      rr:objectMap	[ rr:column "ID"; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:firstName ;
      rr:objectMap	[ rr:column "FirstName" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:lastName ;
      rr:objectMap	[ rr:column "LastName" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:plays ;
      rr:objectMap	[ rr:template "http://example.com/{Sport_ID}/{Description}" ]
    ]
    .

<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Sport\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"ID\"}/{\"Description\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:id ;
      rr:objectMap	[ rr:column "\"ID\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:description ;
      rr:objectMap	[ rr:column "\"Description\"" ]
    ]
    .



R2RMLTC0011b

Title: M to M relation, by using an additional Triples Map

Purpose: Tests, M to M relations, by using an additional Triples Map

Specification reference: #physical-tables

Review status: unreviewed

Input: D011-M2MRelations

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/student/10><http://example.com/lastName>"Williams"
<http://example.com/student/10><http://example.com/firstName>"Venus"
<http://example.com/student/12><http://example.com/lastName>"Villa"
<http://example.com/student/12><http://example.com/firstName>"David"
<http://example.com/student/11><http://example.com/lastName>"Alonso"
<http://example.com/student/11><http://example.com/firstName>"Fernando"
<http://example.com/sport/110><http://example.com/description>"Tennis"
<http://example.com/sport/110><http://example.com/id>"110"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/sport/111><http://example.com/description>"Football"
<http://example.com/sport/111><http://example.com/id>"111"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/sport/112><http://example.com/description>"Formula1"
<http://example.com/sport/112><http://example.com/id>"112"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/student/10><http://example.com/plays><http://example.com/sport/110>
<http://example.com/student/12><http://example.com/plays><http://example.com/sport/111>
<http://example.com/student/11><http://example.com/plays><http://example.com/sport/112>
<http://example.com/student/11><http://example.com/plays><http://example.com/sport/111>

R2RML mapping: R2RMLTC0011b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
	a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\""; ] ;

    rr:subjectMap [ rr:template "http://example.com/student/{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	ex:firstName ;
		rr:objectMap	[ rr:column "\"FirstName\"" ]
    ];

    rr:predicateObjectMap
    [
		rr:predicate	ex:lastName ;
		rr:objectMap	[ rr:column "\"LastName\"" ]
    ]
	.

<TriplesMap2>
	a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Sport\""; ] ;

    rr:subjectMap [ rr:template "http://example.com/sport/{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap	[ rr:column "\"ID\""; ]
    ];

    rr:predicateObjectMap
    [
		rr:predicate	ex:description ;
		rr:objectMap	[ rr:column "\"Description\"" ]
    ]
	.

<LinkMap_1_2>
	a rr:TriplesMap;

   rr:logicalTable [ rr:tableName "\"Student_Sport\"" ];

   rr:subjectMap [ rr:template "http://example.com/student/{\"ID_Student\"}" ];

   rr:predicateObjectMap [
		rr:predicate	ex:plays ;
		rr:objectMap	[ rr:template "http://example.com/sport/{\"ID_Sport\"}" ];
   ].





D012-2tables2duplicates0nulls

Title: Two tables, two duplicate records, zero nulls, no primary key

Graphical representation:

IOUs
fname
VARCHAR(20)
lname
VARCHAR(20)
amount
DOUBLE
BobSmith30.0E0
SueJones20.0E0
BobSmith30.0E0
Lives
fname
VARCHAR(20)
lname
VARCHAR(20)
city
VARCHAR(20)
BobSmithLondon
SueJonesMadrid
BobSmithLondon

SQL:

CREATE TABLE "IOUs" (
      "fname" VARCHAR(20),
      "lname" VARCHAR(20),
      "amount" FLOAT);
INSERT INTO "IOUs" ("fname", "lname", "amount") VALUES ('Bob', 'Smith', 30);
INSERT INTO "IOUs" ("fname", "lname", "amount") VALUES ('Sue', 'Jones', 20);
INSERT INTO "IOUs" ("fname", "lname", "amount") VALUES ('Bob', 'Smith', 30);
CREATE TABLE "Lives" (
      "fname" VARCHAR(20),
      "lname" VARCHAR(20),
      "city" VARCHAR(20));
INSERT INTO "Lives" ("fname", "lname", "city") VALUES ('Bob', 'Smith', 'London');
INSERT INTO "Lives" ("fname", "lname", "city") VALUES ('Sue', 'Jones', 'Madrid');
INSERT INTO "Lives" ("fname", "lname", "city") VALUES ('Bob', 'Smith', 'London');



File: D012-2tables2duplicates0nulls

DirectGraphTC0012

Title: Generation of direct graph from a database without primary keys

Purpose: Test the generation of direct graph from a database without primary keys, by creating subject BlankNodes

Specification reference: #no-pk

Review status: unreviewed

Input: D012-2tables2duplicates0nulls

Expected result: DirectGraphTC0012

RDF:

@base <http://example.com/base/> .

_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <IOUs> .
_:a <IOUs#fname> "Bob" .
_:a <IOUs#lname> "Smith" .
_:a <IOUs#amount> "3.0E1"^^<http://www.w3.org/2001/XMLSchema#double> .
_:b <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <IOUs> .
_:b <IOUs#fname> "Sue" .
_:b <IOUs#lname> "Jones" .
_:b <IOUs#amount> "2.0E1"^^<http://www.w3.org/2001/XMLSchema#double> .
_:c <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <IOUs> .
_:c <IOUs#fname> "Bob" .
_:c <IOUs#lname> "Smith" .
_:c <IOUs#amount> "3.0E1"^^<http://www.w3.org/2001/XMLSchema#double> .
_:d <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Lives> .
_:d <Lives#fname> "Bob" .
_:d <Lives#lname> "Smith" .
_:d <Lives#city> "London" .
_:e <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Lives> .
_:e <Lives#fname> "Sue" .
_:e <Lives#lname> "Jones" .
_:e <Lives#city> "Madrid" .
_:f <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Lives> .
_:f <Lives#fname> "Bob" .
_:f <Lives#lname> "Smith" .
_:f <Lives#city> "London" .



R2RMLTC0012a

Title: Duplicate tuples generate same blank node

Purpose: Tests that blank nodes with same identifier and in the same graph but generated by different logical rows are considered equivalent.

Specification reference: #blank-nodes

Review status: unreviewed

Input: D012-2tables2duplicates0nulls

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
_:BobSmith30<http://example.com/amount>"3.0E1"^^<http://www.w3.org/2001/XMLSchema#double>
_:BobSmith30<http://xmlns.com/foaf/0.1/name>"Bob Smith"
_:SueJones20<http://example.com/amount>"2.0E1"^^<http://www.w3.org/2001/XMLSchema#double>
_:SueJones20<http://xmlns.com/foaf/0.1/name>"Sue Jones"

R2RML mapping: R2RMLTC0012a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"IOUs\"" ];

    rr:subjectMap [ rr:template "{\"fname\"}_{\"lname\"}_{\"amount\"}"; rr:termType rr:BlankNode; ];

    rr:predicateObjectMap
    [
      rr:predicate	foaf:name ;
      rr:objectMap	[
            rr:template "{\"fname\"} {\"lname\"}";
            rr:termType rr:Literal ;
      ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:amount ;
      rr:objectMap    [
            rr:column "\"amount\"";
      ]
    ];
	.



R2RMLTC0012b

Title: Duplicate tuples generate same blank node

Purpose: Tests that blank nodes with same identifier and in the same graph but generated by different logical rows are considered equivalent.

Specification reference: #blank-nodes

Review status: unreviewed

Input: D012-2tables2duplicates0nulls

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
_:BobSmith<http://example.com/city>"London"
_:BobSmith<http://xmlns.com/foaf/0.1/name>"Bob Smith"
_:SueJones<http://example.com/city>"Madrid"
_:SueJones<http://xmlns.com/foaf/0.1/name>"Sue Jones"

R2RML mapping: R2RMLTC0012b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"IOUs\"" ];

    rr:subjectMap [
            rr:template "{\"fname\"}_{\"lname\"}";
            rr:termType rr:BlankNode ;
      ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap    [
            rr:template "{\"fname\"} {\"lname\"}";
            rr:termType rr:Literal ;
      ]
    ];
    .
<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Lives\"" ];

    rr:subjectMap [
            rr:template "{\"fname\"}_{\"lname\"}";
            rr:termType rr:BlankNode;
      ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:city ;
      rr:objectMap	[ rr:column "\"city\""; ]
    ];
	.



R2RMLTC0012c

Title: TriplesMap without subjectMap

Purpose: Tests a R2RML with missing information, TriplesMap without subjectMap.

Specification reference: #dfn-template-valued-term-map

Review status: unreviewed

Input: D012-2tables2duplicates0nulls

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0012c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"IOUs\"" ];

    rr:predicateObjectMap
    [
      rr:predicate	foaf:name ;
      rr:objectMap	[
            rr:template "{\"fname\"} {\"lname\"}";
            rr:termType rr:Literal ;
      ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate	ex:amount ;
      rr:objectMap	[ rr:column "\"amount\""; ]
    ];
	.



R2RMLTC0012d

Title: TriplesMap with two subjectMap

Purpose: Tests a R2RML with wrong information, TriplesMap with two subjectMap.

Specification reference: #dfn-template-valued-term-map

Review status: unreviewed

Input: D012-2tables2duplicates0nulls

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0012d

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"IOUs\"" ];

    rr:subjectMap [
            rr:template "{\"fname\"}_{\"lname\"}_{\"amount\"}";
      ];

    rr:subjectMap [
            rr:template "{\"amount\"}_{\"fname\"}_{\"lname\"}";
      ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:amount ;
      rr:objectMap		[ rr:column "\"amount\""; ]
    ];
	.



R2RMLTC0012e

Title: Default mapping

Purpose: Tests the generation of a default mapping for tables without a primary key.

Specification reference: #default-mappings

Review status: unreviewed

Input: D012-2tables2duplicates0nulls

Expected result: mappede.nq

RDF:

SubjectPredicateObjectGraph
_:BobSmith30<http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/base/IOUs>
_:BobSmith30<http://example.com/base/IOUs#fname>"Bob"
_:BobSmith30<http://example.com/base/IOUs#lname>"Smith"
_:BobSmith30<http://example.com/base/IOUs#amount>"3.0E1"^^<http://www.w3.org/2001/XMLSchema#double>
_:SueJones20<http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/base/IOUs>
_:SueJones20<http://example.com/base/IOUs#fname>"Sue"
_:SueJones20<http://example.com/base/IOUs#lname>"Jones"
_:SueJones20<http://example.com/base/IOUs#amount>"2.0E1"^^<http://www.w3.org/2001/XMLSchema#double>
_:BobSmithLondon<http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/base/Lives>
_:BobSmithLondon<http://example.com/base/IOUs#fname>"Bob"
_:BobSmithLondon<http://example.com/base/IOUs#lname>"Smith"
_:BobSmithLondon<http://example.com/base/IOUs#city>"London"
_:SueJonesMadrid<http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/base/Lives>
_:SueJonesMadrid<http://example.com/base/IOUs#fname>"Sue"
_:SueJonesMadrid<http://example.com/base/IOUs#lname>"Jones"
_:SueJonesMadrid<http://example.com/base/IOUs#city>"Madrid"

R2RML mapping: R2RMLTC0012e

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"IOUs\"" ];

    rr:subjectMap [ rr:template "{\"fname\"}_{\"lname\"}_{\"amount\"}"; rr:termType rr:BlankNode; ];

    rr:predicateObjectMap [
    	rr:predicate rdf:type;
    	rr:object <IOUs>;
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#fname> ;
      rr:objectMap		[ rr:column "\"fname\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#lname> ;
      rr:objectMap		[ rr:column "\"lname\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#amount> ;
      rr:objectMap		[ rr:column "\"amount\""; ]
    ];
	.

<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName  "\"Lives\"" ];

    rr:subjectMap [ rr:template "{\"fname\"}_{\"lname\"}_{\"city\"}"; rr:termType rr:BlankNode; ];

    rr:predicateObjectMap [
    	rr:predicate rdf:type;
    	rr:object <Lives>;
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#fname> ;
      rr:objectMap		[ rr:column "\"fname\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#lname> ;
      rr:objectMap		[ rr:column "\"lname\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		<IOUs#city> ;
      rr:objectMap		[ rr:column "\"city\""; ]
    ];
	.



D013-1table1primarykey3columns2rows1nullvalue

Title: One table, one primary key, three columns, two rows, a null value

Graphical representation:

Person
ID (PK)
INTEGER
Name
VARCHAR(50)
DateOfBirth
VARCHAR(50)
1AliceNULL
2BobSeptember, 2010

SQL:

CREATE TABLE "Person" (
"ID" integer,
"Name" varchar(50),
"DateOfBirth" varchar(50),
PRIMARY KEY ("ID")
);
INSERT INTO "Person" ("ID", "Name", "DateOfBirth") VALUES (1,'Alice', NULL);
INSERT INTO "Person" ("ID", "Name", "DateOfBirth") VALUES (2,'Bob', 'September, 2010');



File: D013-1table1primarykey3columns2rows1nullvalue

DirectGraphTC0013

Title: Generation of a direct graph from a table with NULL values

Purpose: Tests the generation of a Direct Graph from a table with NULL values

Specification reference: #lead-ex

Review status: unreviewed

Input: D013-1table1primarykey3columns2rows1nullvalue

Expected result: DirectGraphTC0013

RDF:

@base <http://example.com/base/> .

<Person/ID=1> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Person> .
<Person/ID=1> <Person#ID> "1"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Person/ID=1> <Person#Name> "Alice" .
<Person/ID=2> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Person> .
<Person/ID=2> <Person#ID> "2"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Person/ID=2> <Person#Name> "Bob" .
<Person/ID=2> <Person#DateOfBirth> "September, 2010" .



R2RMLTC0013a

Title: Generation of empty triples from referenced columns that have null values

Purpose: Tests the generation of empty triples from referenced columns that have null values

Specification reference: #dfn-template-valued-term-map

Review status: unreviewed

Input: D013-1table1primarykey3columns2rows1nullvalue

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Person/2/Bob/September%2C%202010><http://example.com/BirthDay>"September, 2010"

R2RML mapping: R2RMLTC0013a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
     a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Person\"" ];

    rr:subjectMap [ rr:template "http://example.com/Person/{\"ID\"}/{\"Name\"}/{\"DateOfBirth\"}";  ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:BirthDay ;
      rr:objectMap		[ rr:column "\"DateOfBirth\"" ]
    ]
    .



D014-3tables1primarykey1foreignkey

Title: 3 tables, one primary key, one foreign key

Graphical representation:

EMP
empno (PK)
INTEGER
deptno (FK)
INTEGER
ename
VARCHAR(100)
job
VARCHAR(30)
etype
VARCHAR(30)
736910SMITHCLERKPART_TIME
LIKES
id
INTEGER
likeType
VARCHAR(30)
likedObj
VARCHAR(100)
7369PlayingSoccer
7369WatchingBasketball
DEPT
deptno
INTEGER
dname
VARCHAR(30)
loc
VARCHAR(100)
10APPSERVERNEW YORK

SQL:

CREATE TABLE "DEPT" (
      "deptno" INTEGER UNIQUE,
      "dname" VARCHAR(30),
      "loc" VARCHAR(100));
INSERT INTO "DEPT" ("deptno", "dname", "loc") VALUES (10, 'APPSERVER', 'NEW YORK');

CREATE TABLE "EMP" (
      "empno" INTEGER PRIMARY KEY,
      "ename" VARCHAR(100),
      "job" VARCHAR(30),
	  "deptno" INTEGER REFERENCES "DEPT" ("deptno"),
	  "etype" VARCHAR(30));
INSERT INTO "EMP" ("empno", "ename", "job", "deptno", "etype" ) VALUES (7369, 'SMITH', 'CLERK', 10, 'PART_TIME');

CREATE TABLE "LIKES" (
      "id" INTEGER,
      "likeType" VARCHAR(30),
      "likedObj" VARCHAR(100));
INSERT INTO "LIKES" ("id", "likeType", "likedObj") VALUES (7369, 'Playing', 'Soccer');
INSERT INTO "LIKES" ("id", "likeType", "likedObj") VALUES (7369, 'Watching', 'Basketball');



File: D014-3tables1primarykey1foreignkey

DirectGraphTC0014

Title: Generation of direct graph from a database with primary key referencing candidate key

Purpose: Test the generation of direct graph from a database with primary key referencing candidate key

Specification reference: #lead-ex

Review status: unreviewed

Input: D014-3tables1primarykey1foreignkey

Expected result: DirectGraphTC0014

RDF:

@base <http://example.com/base/> .

<EMP/empno=7369> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <EMP> .
<EMP/empno=7369> <EMP#empno> "7369"^^<http://www.w3.org/2001/XMLSchema#integer>  .
<EMP/empno=7369> <EMP#deptno> "10"^^<http://www.w3.org/2001/XMLSchema#integer>  .
<EMP/empno=7369> <EMP#ref-deptno> _:c  .
<EMP/empno=7369> <EMP#ename> "SMITH" .
<EMP/empno=7369> <EMP#job> "CLERK" .
<EMP/empno=7369> <EMP#etype> "PART_TIME" .
_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <LIKES> .
_:a <LIKES#id> "7369"^^<http://www.w3.org/2001/XMLSchema#integer>  .
_:a <LIKES#likeType> "Playing" .
_:a <LIKES#likedObj> "Soccer" .
_:b <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <LIKES> .
_:b <LIKES#id> "7369"^^<http://www.w3.org/2001/XMLSchema#integer>  .
_:b <LIKES#likeType> "Watching" .
_:b <LIKES#likedObj> "Basketball" .
_:c <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <DEPT> .
_:c <DEPT#deptno> "10"^^<http://www.w3.org/2001/XMLSchema#integer>  .
_:c <DEPT#dname> "APPSERVER" .
_:c <DEPT#loc> "NEW YORK" .





R2RMLTC0014a

Title: Subjectmap with rr:inverseExpression

Purpose: Tests a rr:subjectMap with rr:inverseExpression

Specification reference: #inverse

Review status: unreviewed

Input: D014-3tables1primarykey1foreignkey

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
_:Department10<http://example.com/dept#location>"NEW YORK"

R2RML mapping: R2RMLTC0014a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix dept: <http://example.com/dept#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;
    rr:logicalTable [ rr:sqlQuery """
       SELECT ('Department' || "deptno") AS "deptId"
            , "deptno"
            , "dname"
            , "loc"
       FROM "DEPT"
       """ ];

    rr:subjectMap [ rr:column "\"deptId\""; rr:termType rr:BlankNode;
                    rr:inverseExpression "{\"deptno\"} = substr({\"deptId\"},length('Department')+1)"];

    rr:predicateObjectMap
    [
      rr:predicate	dept:location ;
      rr:objectMap	[ rr:column "\"loc\"" ]
    ];

.



R2RMLTC0014b

Title: Triplesmaps with rr:inverseExpression and rr:joinCondition

Purpose: Test two triplesmaps, one with a rr:inverseExpression and the other with a rr:joinCondition for foerign key relations

Specification reference: #dfn-join-condition

Review status: unreviewed

Input: D014-3tables1primarykey1foreignkey

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/emp/7369><http://example.com/emp#jobtype><http://example.com/emp/job/CLERK>
<http://example.com/emp/7369><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/emp/job/CLERK>
<http://example.com/emp/7369><http://example.com/emp#emptype><http://example.com/emp/etype/PART_TIME>
<http://example.com/emp/7369><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/emp/etype/PART_TIME>
<http://example.com/emp/7369><http://example.com/emp#empno>"7369"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/emp/7369><http://example.com/emp#name>"SMITH"
<http://example.com/emp/7369><http://example.com/emp#job>"CLERK"
<http://example.com/emp/7369><http://example.com/emp#deptNum>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/emp/7369><http://example.com/emp#etype>"PART_TIME"
<http://example.com/emp/7369><http://example.com/emp#c_ref_deptno>_:Department10
_:Department10<http://example.com/dept#deptno>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
_:Department10<http://example.com/dept#name>"APPSERVER"
_:Department10<http://example.com/dept#location>"NEW YORK"
_:Department10<http://example.com/dept#COMPANY>"EXAMPLE Corporation"

R2RML mapping: R2RMLTC0014b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/ns#> .
@prefix emp: <http://example.com/emp#> .
@prefix dept: <http://example.com/dept#> .
@prefix likes: <http://example.com/likes#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;
    rr:logicalTable [ rr:sqlQuery """
       SELECT ('Department' || "deptno") AS deptId
            , "deptno"
            , "dname"
            , "loc"
       FROM "DEPT"
       """ ];

    rr:subjectMap [ rr:column "deptId"; rr:termType rr:BlankNode;
                    rr:inverseExpression "{\"deptno\"} = substr({deptId},length('Department')+1)" ];

    rr:predicateObjectMap
    [
      rr:predicate		dept:deptno ;
      rr:objectMap    [ rr:column "\"deptno\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		dept:name ;
      rr:objectMap    [ rr:column "\"dname\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		dept:location ;
      rr:objectMap    [ rr:column "\"loc\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		dept:COMPANY ;
      rr:object			"EXAMPLE Corporation"
    ]
.

<TriplesMap2>
    a rr:TriplesMap;
    rr:logicalTable [ rr:sqlQuery """
       SELECT ('http://example.com/emp/' || "empno") AS empURI
            , "empno"
            , "ename"
            , ('http://example.com/emp/job/'|| "job") AS jobTypeURI
            , "job"
            , "deptno"
            , ('http://example.com/emp/etype/'|| "etype") AS empTypeURI
            , "etype"
            , ('http://example.com/graph/'|| "job" || '/' || "etype") AS graphURI
       FROM "EMP"
       """ ];

    rr:subjectMap [ rr:column "empURI"; ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:jobtype ;
      rr:objectMap    [ rr:column "jobTypeURI"; rr:termType rr:IRI; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		rdf:type ;
      rr:objectMap    [ rr:column "jobTypeURI"; rr:termType rr:IRI; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:emptype ;
      rr:objectMap    [ rr:column "empTypeURI"; rr:termType rr:IRI; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		rdf:type ;
      rr:objectMap    [ rr:column "empTypeURI"; rr:termType rr:IRI; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:empno ;
      rr:objectMap    [ rr:column "\"empno\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:name ;
      rr:objectMap    [ rr:column "\"ename\"" ];
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:job ;
      rr:objectMap    [ rr:column "\"job\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:deptNum ;
      rr:objectMap    [ rr:column "\"deptno\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:etype ;
      rr:objectMap    [ rr:column "\"etype\"" ]
    ];

    rr:predicateObjectMap [
      rr:predicate		emp:c_ref_deptno ;
      rr:objectMap    [
        a rr:RefObjectMap ;
        rr:parentTriplesMap <TriplesMap1>;
        rr:joinCondition [
          rr:child "\"deptno\"";
          rr:parent "\"deptno\"";
        ];
      ];
    ]
    .



R2RMLTC0014c

Title: Triplesmaps with rr:inverseExpression, rr:joinCondition, and referencing object maps

Purpose: Triplesmaps with rr:inverseExpression, rr:joinCondition, and referencing object maps

Specification reference: #foreign-key

Review status: unreviewed

Input: D014-3tables1primarykey1foreignkey

Expected result: mappedc.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/emp/7369><http://example.com/emp#jobtype><http://example.com/emp/job/CLERK>
<http://example.com/emp/7369><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/emp/job/CLERK>
<http://example.com/emp/7369><http://example.com/emp#emptype><http://example.com/emp/etype/PART_TIME>
<http://example.com/emp/7369><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://example.com/emp/etype/PART_TIME>
<http://example.com/emp/7369><http://example.com/emp#empno>"7369"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/emp/7369><http://example.com/emp#job>"CLERK"
<http://example.com/emp/7369><http://example.com/emp#deptNum>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/emp/7369><http://example.com/emp#etype>"PART_TIME"
<http://example.com/emp/7369><http://example.com/emp#c_ref_deptno>_:Department10
<http://example.com/emp/7369><http://example.com/emp#name>"SMITH"
_:Department10<http://example.com/dept#deptno>"10"^^<http://www.w3.org/2001/XMLSchema#positiveInteger>
_:Department10<http://example.com/dept#name>"APPSERVER"
_:Department10<http://example.com/dept#location>"NEW YORK"
_:Department10<http://example.com/dept#COMPANY>"EXAMPLE Corporation"

R2RML mapping: R2RMLTC0014c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/ns#> .
@prefix emp: <http://example.com/emp#> .
@prefix dept: <http://example.com/dept#> .
@prefix likes: <http://example.com/likes#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;
    rr:logicalTable [ rr:sqlQuery """
       Select ('Department' || "deptno") AS deptId
            , "deptno"
            , "dname"
            , "loc"
         from "DEPT"
       """ ];

    rr:subjectMap [ rr:column "deptId"; rr:termType rr:BlankNode;
                    rr:inverseExpression "{\"deptno\"} = substr({deptId},length('Department')+1)"];

    rr:predicateObjectMap
    [
      rr:predicate		dept:deptno ;
      rr:objectMap    [ rr:column "\"deptno\""; rr:datatype xsd:positiveInteger ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		dept:name ;
      rr:objectMap    [ rr:column "\"dname\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		dept:location ;
      rr:objectMap    [ rr:column "\"loc\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		dept:COMPANY ;
      rr:objectMap		[ rr:constant "EXAMPLE Corporation"; ]
    ]
.


<jobtypeObjectMap>
    a rr:ObjectMap;
    rr:template "http://example.com/emp/job/{\"job\"}"
    .

<emptypeObjectMap>
    a rr:ObjectMap;
    rr:template "http://example.com/emp/etype/{\"etype\"}"
    .

<TriplesMap2>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"EMP\"" ];

    rr:subjectMap [ rr:template "http://example.com/emp/{\"empno\"}"; ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:jobtype ;
      rr:objectMap    <jobtypeObjectMap>
    ];

    rr:predicateObjectMap
    [
      rr:predicate		rdf:type ;
      rr:objectMap    <jobtypeObjectMap>
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:emptype ;
      rr:objectMap    <emptypeObjectMap>
    ];

    rr:predicateObjectMap
    [
      rr:predicate		rdf:type ;
      rr:objectMap    <emptypeObjectMap>
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:empno ;
      rr:objectMap    [ rr:column "\"empno\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:name ;
      rr:objectMap    [ rr:column "\"ename\"" ];
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:job ;
      rr:objectMap    [ rr:column "\"job\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:deptNum ;
      rr:objectMap    [ rr:column "\"deptno\"" ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		emp:etype ;
      rr:objectMap    [ rr:column "\"etype\"" ]
    ];

    rr:predicateObjectMap [
      rr:predicate		emp:c_ref_deptno ;
      rr:objectMap    [
      	a rr:RefObjectMap ;
        rr:parentTriplesMap <TriplesMap1>;
        rr:joinCondition [
          rr:child "\"deptno\"";
          rr:parent "\"deptno\"";
        ];
      ];
    ]
    .



R2RMLTC0014d

Title: three tables, one primary key, one foreign key

Purpose: Test the translation of database type codes to IRIs

Specification reference: #example-translationtable

Review status: unreviewed

Input: D014-3tables1primarykey1foreignkey

Expected result: mappedd.nq

RDF:

SubjectPredicateObjectGraph
<http://data.example.com/employee/7369><http://example.com/ns#role><http://data.example.com/roles/general-office>

R2RML mapping: R2RMLTC0014d

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/ns#> .
@prefix emp: <http://example.com/emp#> .
@prefix dept: <http://example.com/dept#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap4>
	a rr:TriplesMap;
    rr:logicalTable [ rr:sqlQuery """

        SELECT "EMP".*, (CASE "job"
            WHEN 'CLERK' THEN 'general-office'
            WHEN 'NIGHTGUARD' THEN 'security'
            WHEN 'ENGINEER' THEN 'engineering'
        END) AS ROLE FROM "EMP"

        """ ];
    rr:subjectMap [
        rr:template "http://data.example.com/employee/{\"empno\"}";
    ];
    rr:predicateObjectMap [
        rr:predicate ex:role;
        rr:objectMap [ rr:template "http://data.example.com/roles/{ROLE}" ];
    ].




D015-1table3columns1composityeprimarykey3rows2languages

Title: One table, three columns, one composite primary key, three rows, two languages

Graphical representation:

Country
Code (PK)
VARCHAR(2)
Lan (PK)
VARCHAR(10)
Name
VARCHAR(100)
BOENBolivia, Plurinational State of
BOESEstado Plurinacional de Bolivia
IEENIreland
IEESIrlanda

SQL:

CREATE TABLE "Country" (
  "Code" VARCHAR(2),
  "Name" VARCHAR(100),
  "Lan" VARCHAR(10),
  PRIMARY KEY ("Code","Lan")
);
INSERT INTO "Country" ("Code", "Name", "Lan") VALUES ('BO', 'Bolivia, Plurinational State of', 'EN');
INSERT INTO "Country" ("Code", "Name", "Lan") VALUES ('BO', 'Estado Plurinacional de Bolivia', 'ES');
INSERT INTO "Country" ("Code", "Name", "Lan") VALUES ('IE', 'Ireland', 'EN');
INSERT INTO "Country" ("Code", "Name", "Lan") VALUES ('IE', 'Irlanda', 'ES');




File: D015-1table3columns1composityeprimarykey3rows2languages

DirectGraphTC0015

Title: Generation of direct graph from multi-column primary keys

Purpose: Tests the generation of direct graph from multi-column primary keys

Specification reference: #multi-key

Review status: unreviewed

Input: D015-1table3columns1composityeprimarykey3rows2languages

Expected result: DirectGraphTC0015

RDF:

@base <http://example.com/base/> .

<Country/Code=BO;Lan=EN> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Country> .
<Country/Code=BO;Lan=EN> <Country#Code> "BO" .
<Country/Code=BO;Lan=EN> <Country#Lan> "EN" .
<Country/Code=BO;Lan=EN> <Country#Name> "Bolivia, Plurinational State of" .
<Country/Code=BO;Lan=ES> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Country> .
<Country/Code=BO;Lan=ES> <Country#Code> "BO" .
<Country/Code=BO;Lan=ES> <Country#Lan> "ES" .
<Country/Code=BO;Lan=ES> <Country#Name> "Estado Plurinacional de Bolivia" .
<Country/Code=IE;Lan=EN> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Country> .
<Country/Code=IE;Lan=EN> <Country#Code> "IE" .
<Country/Code=IE;Lan=EN> <Country#Lan> "EN" .
<Country/Code=IE;Lan=EN> <Country#Name> "Ireland" .
<Country/Code=IE;Lan=ES> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Country> .
<Country/Code=IE;Lan=ES> <Country#Code> "IE" .
<Country/Code=IE;Lan=ES> <Country#Lan> "ES" .
<Country/Code=IE;Lan=ES> <Country#Name> "Irlanda" .



R2RMLTC0015a

Title: Generation of language tags from a table with language information

Purpose: Generation of language tags from a table with language information

Specification reference: #language-tags

Review status: unreviewed

Input: D015-1table3columns1composityeprimarykey3rows2languages

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/BO><http://www.w3.org/2000/01/rdf-schema#label>"Bolivia, Plurinational State of"@en
<http://example.com/BO><http://www.w3.org/2000/01/rdf-schema#label>"Estado Plurinacional de Bolivia"@es
<http://example.com/IE><http://www.w3.org/2000/01/rdf-schema#label>"Ireland"@en
<http://example.com/IE><http://www.w3.org/2000/01/rdf-schema#label>"Irlanda"@es

R2RML mapping: R2RMLTC0015a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [  rr:sqlQuery """
						SELECT "Code", "Name", "Lan"
						FROM "Country"
						WHERE "Lan" = 'EN';
                       """ ] ;

    rr:subjectMap [ rr:template "http://example.com/{\"Code\"}" ];

    rr:predicateObjectMap
    [
      rr:predicate	rdfs:label;
      rr:objectMap	[ rr:column "\"Name\""; rr:language "en" ]
    ]
    .

<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [  rr:sqlQuery """
                       SELECT "Code", "Name", "Lan"
                       FROM "Country"
					   WHERE "Lan" = 'ES';
                       """ ] ;

    rr:subjectMap [ rr:template "http://example.com/{\"Code\"}" ];

    rr:predicateObjectMap
    [
      rr:predicate rdfs:label;
      rr:objectMap    [ rr:column "\"Name\""; rr:language "es" ]
    ]
    .



R2RMLTC0015b

Title: Generation of language tags from a table with language information, and a term map with invalid rr:language value

Purpose: Tests a term map with an invalid rr:language value, which is an error

Specification reference: #language-tags

Review status: unreviewed

Input: D015-1table3columns1composityeprimarykey3rows2languages

Expected result: non-conforming R2RML mapping

R2RML mapping: R2RMLTC0015b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [  rr:sqlQuery """
                       SELECT "Code", "Name", "Lan"
                       FROM "Country"
					   WHERE "Lan" = 'EN';
                       """ ] ;

    rr:subjectMap [ rr:template "http://example.com/{\"Code\"}" ];

    rr:predicateObjectMap
    [
      rr:predicate		rdfs:label;
      rr:objectMap		[ rr:column "\"Name\""; rr:language "english" ]
    ]
    .

<TriplesMap2>
    a rr:TriplesMap;

	rr:logicalTable [  rr:sqlQuery """
                       SELECT "Code", "Name", "Lan"
                       FROM "Country"
					   WHERE "Lan" = 'ES';
                       """ ] ;

    rr:subjectMap [ rr:template "http://example.com/{\"Code\"}" ];

    rr:predicateObjectMap
    [
      rr:predicate		rdfs:label;
      rr:objectMap		[ rr:column "\"Name\""; rr:language "spanish" ]
    ]
    .



D016-1table1primarykey10columns3rowsSQLdatatypes

Title: One table, one primary key, ten columns, three rows with sql datatypes

Graphical representation:

Patient
ID (PK)
INTEGER
FirstName
VARCHAR(50)
LastName
VARCHAR(50)
Sex
VARCHAR(6)
Weight
DOUBLE
Height
DOUBLE
BirthDate
DATE
EntranceDate
TIMESTAMP
PaidInAdvance
BOOLEAN
VARBINARY
10MonicaGellerfemale80.25E01.65E01981-10-102009-10-10 12:12:22.000000FALSE[Binary Data]
11RachelGreenfemale70.22E01.7E01982-11-122008-11-12 09:45:44.000000TRUE[Binary Data]
12ChandlerBingmale90.31E01.76E01978-04-062007-03-12 02:13:14.000000TRUE[Binary Data]

SQL:

CREATE TABLE "Patient" (
"ID" INTEGER,
"FirstName" VARCHAR(50),
"LastName" VARCHAR(50),
"Sex" VARCHAR(6),
"Weight" REAL,
"Height" FLOAT,
"BirthDate" DATE,
"EntranceDate" TIMESTAMP,
"PaidInAdvance" BOOLEAN,
"Photo" VARBINARY(200),
PRIMARY KEY ("ID")
);

INSERT INTO "Patient" ("ID", "FirstName","LastName","Sex","Weight","Height","BirthDate","EntranceDate","PaidInAdvance","Photo")
VALUES (10,'Monica','Geller','female',80.25,1.65,'1981-10-10','2009-10-10 12:12:22',FALSE,
X'89504E470D0A1A0A0000000D49484452000000050000000508060000008D6F26E50000001C4944415408D763F9FFFEBFC37F062005C3201284D031F18258CD04000EF535CBD18E0E1F0000000049454E44AE426082');

INSERT INTO "Patient" ("ID", "FirstName","LastName","Sex","Weight","Height","BirthDate","EntranceDate","PaidInAdvance","Photo")
VALUES (11,'Rachel','Green','female',70.22,1.70,'1982-11-12','2008-11-12 09:45:44',TRUE,
X'89504E470D0A1A0A0000000D49484452000000050000000508060000008D6F26E50000001C4944415408D763F9FFFF3FC37F062005C3201284D031F18258CD04000EF535CBD18E0E1F0000000049454E44AE426082');

INSERT INTO "Patient" ("ID", "FirstName","LastName","Sex","Weight","Height","BirthDate","EntranceDate","PaidInAdvance","Photo")
VALUES (12,'Chandler','Bing','male',90.31,1.76,'1978-04-06','2007-03-12 02:13:14',TRUE,
X'89504E470D0A1A0A0000000D49484452000000050000000508060000008D6F26E50000001C4944415408D763F9FFFEBFC37F062005C3201284D031F18258CD04000EF535CBD18E0E1F0000000049454E44AE426082');



File: D016-1table1primarykey10columns3rowsSQLdatatypes

DirectGraphTC0016

Title: Generation of direct graph from a database with sql datatypes

Purpose: Tests the generation of direct graph from a database with sql datatypes

Specification reference: #lead-ex

Review status: unreviewed

Input: D016-1table1primarykey10columns3rowsSQLdatatypes

Expected result: DirectGraphTC0016

RDF:

@base <http://example.com/base/> .

<Patient/ID=10> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Patient> .
<Patient/ID=10> <Patient#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Patient/ID=10> <Patient#FirstName> "Monica" .
<Patient/ID=10> <Patient#LastName> "Geller" .
<Patient/ID=10> <Patient#Sex> "female" .
<Patient/ID=10> <Patient#Weight> "8.025E1"^^<http://www.w3.org/2001/XMLSchema#double> .
<Patient/ID=10> <Patient#Height> "1.65E0"^^<http://www.w3.org/2001/XMLSchema#double> .
<Patient/ID=10> <Patient#BirthDate> "1981-10-10"^^<http://www.w3.org/2001/XMLSchema#date> .
<Patient/ID=10> <Patient#EntranceDate> "2009-10-10T12:12:22"^^<http://www.w3.org/2001/XMLSchema#dateTime> .
<Patient/ID=10> <Patient#PaidInAdvance> "false"^^<http://www.w3.org/2001/XMLSchema#boolean> .
<Patient/ID=10> <Patient#Photo> "89504E470D0A1A0A0000000D49484452000000050000000508060000008D6F26E50000001C4944415408D763F9FFFEBFC37F062005C3201284D031F18258CD04000EF535CBD18E0E1F0000000049454E44AE426082"^^<http://www.w3.org/2001/XMLSchema#hexBinary> .
<Patient/ID=11> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Patient> .
<Patient/ID=11> <Patient#ID> "11"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Patient/ID=11> <Patient#FirstName> "Rachel" .
<Patient/ID=11> <Patient#LastName> "Green" .
<Patient/ID=11> <Patient#Sex> "female" .
<Patient/ID=11> <Patient#Weight> "7.022E1"^^<http://www.w3.org/2001/XMLSchema#double> .
<Patient/ID=11> <Patient#Height> "1.7E0"^^<http://www.w3.org/2001/XMLSchema#double> .
<Patient/ID=11> <Patient#BirthDate> "1982-11-12"^^<http://www.w3.org/2001/XMLSchema#date> .
<Patient/ID=11> <Patient#EntranceDate> "2008-11-12T09:45:44"^^<http://www.w3.org/2001/XMLSchema#dateTime> .
<Patient/ID=11> <Patient#PaidInAdvance> "true"^^<http://www.w3.org/2001/XMLSchema#boolean> .
<Patient/ID=11> <Patient#Photo> "89504E470D0A1A0A0000000D49484452000000050000000508060000008D6F26E50000001C4944415408D763F9FFFF3FC37F062005C3201284D031F18258CD04000EF535CBD18E0E1F0000000049454E44AE426082"^^<http://www.w3.org/2001/XMLSchema#hexBinary> .
<Patient/ID=12> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Patient> .
<Patient/ID=12> <Patient#ID> "12"^^<http://www.w3.org/2001/XMLSchema#integer> .
<Patient/ID=12> <Patient#FirstName> "Chandler" .
<Patient/ID=12> <Patient#LastName> "Bing" .
<Patient/ID=12> <Patient#Sex> "male" .
<Patient/ID=12> <Patient#Weight> "9.031E1"^^<http://www.w3.org/2001/XMLSchema#double> .
<Patient/ID=12> <Patient#Height> "1.76E0"^^<http://www.w3.org/2001/XMLSchema#double> .
<Patient/ID=12> <Patient#BirthDate> "1978-04-06"^^<http://www.w3.org/2001/XMLSchema#date> .
<Patient/ID=12> <Patient#EntranceDate> "2007-03-12T02:13:14"^^<http://www.w3.org/2001/XMLSchema#dateTime> .
<Patient/ID=12> <Patient#PaidInAdvance> "true"^^<http://www.w3.org/2001/XMLSchema#boolean> .
<Patient/ID=12> <Patient#Photo> "89504E470D0A1A0A0000000D49484452000000050000000508060000008D6F26E50000001C4944415408D763F9FFFEBFC37F062005C3201284D031F18258CD04000EF535CBD18E0E1F0000000049454E44AE426082"^^<http://www.w3.org/2001/XMLSchema#hexBinary> .



R2RMLTC0016a

Title: Table with datatypes: string and integer

Purpose: Tests the rr:termtype and datatype conversions: string and integer

Specification reference: #datatype-conversions

Review status: unreviewed

Input: D016-1table1primarykey10columns3rowsSQLdatatypes

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Patient/10><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient/10><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/Patient/10><http://example.com/firstName>"Monica"
<http://example.com/Patient/10><http://example.com/lastName>"Geller"
<http://example.com/Patient/10><http://example.com/gender>"female"
<http://example.com/Patient/11><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient/11><http://example.com/id>"11"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/Patient/11><http://example.com/firstName>"Rachel"
<http://example.com/Patient/11><http://example.com/lastName>"Green"
<http://example.com/Patient/11><http://example.com/gender>"female"
<http://example.com/Patient/12><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient/12><http://example.com/id>"12"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/Patient/12><http://example.com/firstName>"Chandler"
<http://example.com/Patient/12><http://example.com/lastName>"Bing"
<http://example.com/Patient/12><http://example.com/gender>"male"

R2RML mapping: R2RMLTC0016a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Patient\"" ];

    rr:subjectMap [ rr:template "http://example.com/Patient/{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
		rr:predicate	ex:id ;
		rr:objectMap    [ rr:column "\"ID\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:firstName;
      rr:objectMap		[ rr:column "\"FirstName\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:lastName;
      rr:objectMap		[ rr:column "\"LastName\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:gender;
      rr:objectMap		[ rr:column "\"Sex\""; ]
    ];

    .



R2RMLTC0016b

Title: Table with datatypes: real and float

Purpose: Tests the rr:termtype and datatype conversions: real and float

Specification reference: #datatype-conversions

Review status: unreviewed

Input: D016-1table1primarykey10columns3rowsSQLdatatypes

Expected result: mappedb.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Patient10><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient10><http://example.com/weight>"8.025E1"^^<http://www.w3.org/2001/XMLSchema#double>
<http://example.com/Patient10><http://example.com/height>"1.65E0"^^<http://www.w3.org/2001/XMLSchema#double>
<http://example.com/Patient11><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient11><http://example.com/weight>"7.022E1"^^<http://www.w3.org/2001/XMLSchema#double>
<http://example.com/Patient11><http://example.com/height>"1.7E0"^^<http://www.w3.org/2001/XMLSchema#double>
<http://example.com/Patient12><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient12><http://example.com/weight>"9.031E1"^^<http://www.w3.org/2001/XMLSchema#double>
<http://example.com/Patient12><http://example.com/height>"1.76E0"^^<http://www.w3.org/2001/XMLSchema#double>

R2RML mapping: R2RMLTC0016b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Patient\"" ];

    rr:subjectMap [ rr:template "http://example.com/Patient{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate rdf:type;
		rr:object foaf:Person;
	];

    rr:predicateObjectMap
    [
      rr:predicate ex:weight;
      rr:objectMap    [ rr:column "\"Weight\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate ex:height;
      rr:objectMap    [ rr:column "\"Height\""; ]
    ];

    .



R2RMLTC0016c

Title: Table with datatypes: date and timestamp

Purpose: Tests the rr:termtype and datatype conversions: date and timestamp

Specification reference: #datatype-conversions

Review status: unreviewed

Input: D016-1table1primarykey10columns3rowsSQLdatatypes

Expected result: mappedc.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Patient10><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient10><http://example.com/birthdate>"1981-10-10"^^<http://www.w3.org/2001/XMLSchema#date>
<http://example.com/Patient10><http://example.com/entrancedate>"2009-10-10T12:12:22"^^<http://www.w3.org/2001/XMLSchema#dateTime>
<http://example.com/Patient11><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient11><http://example.com/birthdate>"1982-11-12"^^<http://www.w3.org/2001/XMLSchema#date>
<http://example.com/Patient11><http://example.com/entrancedate>"2008-11-12T09:45:44"^^<http://www.w3.org/2001/XMLSchema#dateTime>
<http://example.com/Patient12><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient12><http://example.com/birthdate>"1978-04-06"^^<http://www.w3.org/2001/XMLSchema#date>
<http://example.com/Patient12><http://example.com/entrancedate>"2007-03-12T02:13:14"^^<http://www.w3.org/2001/XMLSchema#dateTime>

R2RML mapping: R2RMLTC0016c

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Patient\"" ];

    rr:subjectMap [ rr:template "http://example.com/Patient{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
      rr:predicate		ex:birthdate;
      rr:objectMap		[ rr:column "\"BirthDate\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:entrancedate;
      rr:objectMap		[ rr:column "\"EntranceDate\""; ]
    ];

    .



R2RMLTC0016d

Title: Table with datatypes, boolean conversions

Purpose: Tests the rr:termtype and datatype conversions: boolean

Specification reference: #datatype-conversions

Review status: unreviewed

Input: D016-1table1primarykey10columns3rowsSQLdatatypes

Expected result: mappedd.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Patient10><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient10><http://example.com/paid>"false"^^<http://www.w3.org/2001/XMLSchema#boolean>
<http://example.com/Patient11><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient11><http://example.com/paid>"true"^^<http://www.w3.org/2001/XMLSchema#boolean>
<http://example.com/Patient12><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient12><http://example.com/paid>"true"^^<http://www.w3.org/2001/XMLSchema#boolean>

R2RML mapping: R2RMLTC0016d

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Patient\"" ];

    rr:subjectMap [ rr:template "http://example.com/Patient{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
      rr:predicate		ex:paid;
      rr:objectMap		[ rr:column "\"PaidInAdvance\"";  ]
    ];

    .



R2RMLTC0016e

Title: Table with datatypes, binary column

Purpose: Tests the rr:termtype and datatype conversions: binary

Specification reference: #datatype-conversions

Review status: unreviewed

Input: D016-1table1primarykey10columns3rowsSQLdatatypes

Expected result: mappede.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/Patient10><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient11><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/Patient12><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>

R2RML mapping: R2RMLTC0016e

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .


<TriplesMap1>
    a rr:TriplesMap;

	rr:logicalTable [ rr:tableName "\"Patient\"" ];

    rr:subjectMap [ rr:template "http://example.com/Patient{\"ID\"}"; ];

    rr:predicateObjectMap
    [
		rr:predicate	rdf:type;
		rr:object		foaf:Person;
	];

    rr:predicateObjectMap
    [
      rr:predicate	ex:photo;
    ];

    .



D017-I18NnoSpecialChars

Title: I18N No Special Chars

Graphical representation:

成分
植物名 (FK)
VARCHAR(10)
使用部 (FK)
VARCHAR(10)

VARCHAR(10)
しそしそのとまと
植物
名 (PK)
VARCHAR(10)
使用部 (PK)
VARCHAR(10)
条件
VARCHAR(10)
しそ新鮮な

SQL:

CREATE TABLE "植物" (
  "名" VARCHAR(10),
  "使用部" VARCHAR(10),
  "条件" VARCHAR(10),
  PRIMARY KEY ("名", "使用部")
);
INSERT INTO "植物" ("名", "使用部", "条件") VALUES ('しそ', '葉', '新鮮な');

CREATE TABLE "成分" (
  "皿"  VARCHAR(10),
  "植物名" VARCHAR(10),
  "使用部" VARCHAR(10),
  FOREIGN KEY ("植物名", "使用部") REFERENCES "植物"("名", "使用部")
);
INSERT INTO "成分" ("皿", "植物名", "使用部") VALUES ('しそのとまと', 'しそ', '葉');



File: D017-I18NnoSpecialChars

DirectGraphTC0017

Title: I18N No Special Chars

Purpose: Test de generation of a direct graph from a I18N No Special Chars database

Specification reference: #no-pk

Review status: unreviewed

Input: D017-I18NnoSpecialChars

Expected result: DirectGraphTC0017

RDF:

@base <http://example.com/base/> .

<植物/名=しそ;使用部=葉> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <植物> .
<植物/名=しそ;使用部=葉> <植物#使用部> "葉" .
<植物/名=しそ;使用部=葉> <植物#名>  "しそ" .
<植物/名=しそ;使用部=葉> <植物#条件> "新鮮な" .
_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <成分> .
_:a <成分#使用部> "葉" .
_:a <成分#植物名> "しそ" .
_:a <成分#ref-植物名;使用部> <植物/名=しそ;使用部=葉> .
_:a <成分#皿> "しそのとまと" .



D018-1table1primarykey2columns3rows

Title: One table, one primary key, two columns, three rows

Graphical representation:

Student
ID
INTEGER
Name
CHARACTER(15)
10Venus
20Fernando
30David

SQL:

CREATE TABLE "Student" (
"ID" INTEGER,
"Name" CHAR(15)
);
INSERT INTO "Student" ("ID","Name") VALUES (10,'Venus');
INSERT INTO "Student" ("ID","Name") VALUES (20,'Fernando');
INSERT INTO "Student" ("ID","Name") VALUES (30,'David');



File: D018-1table1primarykey2columns3rows

DirectGraphTC0018

Title: Generation of triples by using CHAR datatype column

Purpose: Generation of triples by using CHAR datatype column, resulting RDF literal is space-padded.

Specification reference: #lead-ex

Review status: unreviewed

Input: D018-1table1primarykey2columns3rows

Expected result: DirectGraphTC0018

RDF:

@base <http://example.com/base/> .

_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
_:a <Student#ID> "10"^^<http://www.w3.org/2001/XMLSchema#integer> .
_:a <Student#Name> "Venus          " .
_:b <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
_:b <Student#ID> "20"^^<http://www.w3.org/2001/XMLSchema#integer> .
_:b <Student#Name> "Fernando       " .
_:c <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Student> .
_:c <Student#ID> "30"^^<http://www.w3.org/2001/XMLSchema#integer> .
_:c <Student#Name> "David          " .



R2RMLTC0018a

Title: Generation of triples by using CHAR datatype column

Purpose: Generation of triples by using CHAR datatype column, resulting RDF literal is space-padded.

Specification reference: #from-template

Review status: unreviewed

Input: D018-1table1primarykey2columns3rows

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/10><http://xmlns.com/foaf/0.1/name>"Venus          "
<http://example.com/10><http://example.com/id>"10"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/10><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/20><http://xmlns.com/foaf/0.1/name>"Fernando       "
<http://example.com/20><http://example.com/id>"20"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/20><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/30><http://xmlns.com/foaf/0.1/name>"David          "
<http://example.com/30><http://example.com/id>"30"^^<http://www.w3.org/2001/XMLSchema#integer>
<http://example.com/30><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>

R2RML mapping: R2RMLTC0018a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;

    rr:logicalTable [ rr:tableName "\"Student\"" ];

    rr:subjectMap [ rr:template "http://example.com/{\"ID\"}";
                    rr:class foaf:Person ];

    rr:predicateObjectMap
    [
      rr:predicate		ex:id ;
      rr:objectMap		[ rr:column "\"ID\""; ]
    ];

    rr:predicateObjectMap
    [
      rr:predicate		foaf:name ;
      rr:objectMap		[ rr:column "\"Name\"" ]
    ]
    .



D019-1table1primarykey3columns3rows

Title: One table, one primary key, three columns, three rows

Graphical representation:

Employee
ID
INTEGER
FirstName
VARCHAR(50)
LastName
VARCHAR(50)
10http://example.com/ns#JhonSmith
20CarlosMendoza
30Juan DanielCrespo

SQL:

CREATE TABLE "Employee" (
"ID" INTEGER,
"FirstName" VARCHAR(50),
"LastName" VARCHAR(50)
);
INSERT INTO "Employee" ("ID","FirstName","LastName") VALUES (10,'http://example.com/ns#Jhon','Smith');
INSERT INTO "Employee" ("ID","FirstName","LastName") VALUES (20,'Carlos','Mendoza');
INSERT INTO "Employee" ("ID","FirstName","LastName") VALUES (30,'Juan Daniel','Crespo');



File: D019-1table1primarykey3columns3rows

R2RMLTC0019a

Title: Generation of triples by using IRI value in columns

Purpose: Test the generation of triples by using IRI value in columns

Specification reference: #from-column

Review status: unreviewed

Input: D019-1table1primarykey3columns3rows

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/ns#Jhon><http://xmlns.com/foaf/0.1/name>"http://example.com/ns#Jhon"
<http://example.com/base/Carlos><http://xmlns.com/foaf/0.1/name>"Carlos"

R2RML mapping: R2RMLTC0019a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;
 	rr:logicalTable [
                     rr:sqlQuery """
                       SELECT "ID", "FirstName", "LastName"
                       FROM "Employee"
                       WHERE "ID" < 30
                       """
                       ];

	rr:subjectMap [ rr:column "\"FirstName\"" ];
	rr:predicateObjectMap
    [
      rr:predicate		foaf:name;
      rr:objectMap		[ rr:column "\"FirstName\"" ];
    ];
.



R2RMLTC0019b

Title: Generation of triples by using IRI value in columns, with data error

Purpose: Test the generation of triples by using IRI value in columns, conforming R2RML mapping with data error (and no result)

Specification reference: #from-column

Review status: unreviewed

Input: D019-1table1primarykey3columns3rows

Expected result: Conforming R2RML mapping with data error

R2RML mapping: R2RMLTC0019b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;
    rr:logicalTable [ rr:tableName "\"Employee\"" ];
	rr:subjectMap [ rr:column "\"FirstName\"" ];
	rr:predicateObjectMap
    [
      rr:predicate	foaf:name;
      rr:objectMap	[ rr:column "\"FirstName\"" ];
    ];
.



D020-1table1column5rows

Title: One table, one column, five rows

Graphical representation:

Student
Name
VARCHAR(50)
http://company.com/Alice
Bob
Bob/Charles
path/../Danny
Emily Smith

SQL:

CREATE TABLE "Student" (
"Name" VARCHAR(50)
);

INSERT INTO "Student" ("Name") VALUES ('http://company.com/Alice');
INSERT INTO "Student" ("Name") VALUES ('Bob');
INSERT INTO "Student" ("Name") VALUES ('Bob/Charles');
INSERT INTO "Student" ("Name") VALUES ('path/../Danny');
INSERT INTO "Student" ("Name") VALUES ('Emily Smith');



File: D020-1table1column5rows

R2RMLTC0020a

Title: Generation of triples by using IRI value in columns

Purpose: Test the generation of triples by using IRI value in columns

Specification reference: #from-template

Review status: unreviewed

Input: D020-1table1column5rows

Expected result: mappeda.nq

RDF:

SubjectPredicateObjectGraph
<http://example.com/base/http%3A%2F%2Fcompany.com%2FAlice><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/base/Bob><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/base/Bob%2FCharles><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/base/path%2F..%2FDanny><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>
<http://example.com/base/Emily%20Smith><http://www.w3.org/1999/02/22-rdf-syntax-ns#type><http://xmlns.com/foaf/0.1/Person>

R2RML mapping: R2RMLTC0020a

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;
 	rr:logicalTable [ rr:tableName "\"Student\""; ];

    rr:subjectMap [ rr:template "{\"Name\"}"; rr:termType rr:IRI; ];

    rr:predicateObjectMap
    [
    	rr:predicate	rdf:type;
    	rr:object		foaf:Person;
    ];
.



R2RMLTC0020b

Title: Generation of triples by using IRI value in columns, with data errors

Purpose: Test the generation of triples by using IRI value in columns, conforming R2RML mapping with data error (and no result)

Specification reference: #from-column

Review status: unreviewed

Input: D020-1table1column5rows

Expected result: Conforming R2RML mapping with data error

R2RML mapping: R2RMLTC0020b

RDF:

@prefix rr: <http://www.w3.org/ns/r2rml#> .
@prefix foaf: <http://xmlns.com/foaf/0.1/> .
@prefix ex: <http://example.com/> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@base <http://example.com/base/> .

<TriplesMap1>
    a rr:TriplesMap;
 	rr:logicalTable [ rr:tableName "\"Student\""; ];

    rr:subjectMap [ rr:column "\"Name\""; rr:termType rr:IRI; ];

    rr:predicateObjectMap
    [
    	rr:predicate	rdf:type;
    	rr:object		foaf:Person;
    ];
.



D021-2tables2primarykeys1foreignkeyReferencesAllNulls

Title: Two tables, two primary keys, a foreign key, references all nulls

Graphical representation:

Source
ID (PK)
INTEGER
attrA (FK)
CHARACTER(5)
attrB (FK)
CHARACTER(5)
1100K2A21K2A11
1101K2A22NULL
1102NULLNULL
Target
PK (PK)
INTEGER
key1attr1
CHARACTER(5)
key1attr2
CHARACTER(5)
key2attr1
CHARACTER(5)
key2attr2
CHARACTER(5)
1010K1A11K1A21K2A11K2A21
1011K1A12K1A22NULLK2A22
1012K1A13K1A23NULLNULL

SQL:

CREATE TABLE "Target" (
	"PK" INT,
	PRIMARY KEY("PK"),
	"key1attr1" CHAR(5),
	"key1attr2" CHAR(5),
	UNIQUE ("key1attr1", "key1attr2"),
	"key2attr1" CHAR(5),
	"key2attr2" CHAR(5),
	UNIQUE ("key2attr2", "key2attr1")
);

CREATE TABLE "Source" (
	"ID" INT,
	PRIMARY KEY("ID"),
	"attrA" CHAR(5),
	"attrB" CHAR(5),
	FOREIGN KEY ("attrA", "attrB") REFERENCES "Target"("key2attr2", "key2attr1")
);

INSERT INTO "Target" ("PK", "key1attr1", "key1attr2", "key2attr1", "key2attr2")
              VALUES (1010, 'K1A11'    , 'K1A21'    , 'K2A11'    , 'K2A21'    );
INSERT INTO "Target" ("PK", "key1attr1", "key1attr2", "key2attr1", "key2attr2")
              VALUES (1011, 'K1A12'    , 'K1A22'    , NULL       , 'K2A22'    );
INSERT INTO "Target" ("PK", "key1attr1", "key1attr2", "key2attr1", "key2attr2")
              VALUES (1012, 'K1A13'    , 'K1A23'    , NULL       , NULL       );

INSERT INTO "Source" ("ID", "attrA", "attrB")
              VALUES (1100, 'K2A21', 'K2A11');
INSERT INTO "Source" ("ID", "attrA", "attrB")
              VALUES (1101, 'K2A22', NULL   );
INSERT INTO "Source" ("ID", "attrA", "attrB")
              VALUES (1102, NULL   , NULL   );




File: D021-2tables2primarykeys1foreignkeyReferencesAllNulls

DirectGraphTC0021

Title: Generation of triples for two tables, two primary keys, a foreign key, references all nulls

Purpose: Generation of triples two tables, two primary keys, a foreign key, references all nulls

Specification reference: #lead-ex

Review status: unreviewed

Input: D021-2tables2primarykeys1foreignkeyReferencesAllNulls

Expected result: DirectGraphTC0021

RDF:

@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<Target/PK=1010> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Target> .
<Target/PK=1010> <Target#PK> 1010 .
<Target/PK=1010> <Target#key1attr1> "K1A11" .
<Target/PK=1010> <Target#key1attr2> "K1A21" .
<Target/PK=1010> <Target#key2attr1> "K2A11" .
<Target/PK=1010> <Target#key2attr2> "K2A21" .

<Target/PK=1011> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Target> .
<Target/PK=1011> <Target#PK> 1011 .
<Target/PK=1011> <Target#key1attr1> "K1A12" .
<Target/PK=1011> <Target#key1attr2> "K1A22" .
<Target/PK=1011> <Target#key2attr2> "K2A22" .

<Target/PK=1012> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Target> .
<Target/PK=1012> <Target#PK> 1012 .
<Target/PK=1012> <Target#key1attr1> "K1A13" .
<Target/PK=1012> <Target#key1attr2> "K1A23" .

<Source/ID=1100> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Source> .
<Source/ID=1100> <Source#ID> 1100 .
<Source/ID=1100> <Source#attrA> "K2A21" .
<Source/ID=1100> <Source#attrB> "K2A11" .
<Source/ID=1100> <Source#ref-attrA;attrB> <Target/PK=1010> .

<Source/ID=1101> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Source> .
<Source/ID=1101> <Source#ID> 1101 .
<Source/ID=1101> <Source#attrA> "K2A22" .

<Source/ID=1102> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Source> .
<Source/ID=1102> <Source#ID> 1102 .




D022-2tables1primarykey1foreignkeyReferencesNoPrimaryKey

Title: Two tables, a primary key, a foreign key, references no primary keys

Graphical representation:

Source
ID (PK)
INTEGER
attrA (FK)
CHARACTER(4)
attrB (FK)
CHARACTER(4)
1100K2A2K2A1
Target
litattr1
INTEGER
key1attr1
CHARACTER(4)
key1attr2
CHARACTER(4)
key2attr1
CHARACTER(4)
key2attr2
CHARACTER(4)
1010K1A1K1A2K2A1K2A2

SQL:

CREATE TABLE "Target" (
	"litattr1" INT,
	-- PRIMARY KEY("PK"),
	"key1attr1" CHAR(4),
	"key1attr2" CHAR(4),
	UNIQUE ("key1attr1", "key1attr2"),
	"key2attr1" CHAR(4),
	"key2attr2" CHAR(4),
	UNIQUE ("key2attr2", "key2attr1")
);

CREATE TABLE "Source" (
	"ID" INT,
	PRIMARY KEY("ID"),
	"attrA" CHAR(4),
	"attrB" CHAR(4),
	FOREIGN KEY ("attrA", "attrB") REFERENCES "Target"("key2attr2", "key2attr1")
);

INSERT INTO "Target" ("litattr1", "key1attr1", "key1attr2", "key2attr1", "key2attr2")
              VALUES (1010      , 'K1A1'     , 'K1A2'     , 'K2A1'     , 'K2A2');

INSERT INTO "Source" ("ID", "attrA", "attrB")
              VALUES (1100, 'K2A2' , 'K2A1' );



File: D022-2tables1primarykey1foreignkeyReferencesNoPrimaryKey

DirectGraphTC0022

Title: Generation of triples from two tables, a primary key, a foreign key, references no primary keys

Purpose: Generation of triples from two tables, a primary key, a foreign key, references no primary keys

Specification reference: #lead-ex

Review status: unreviewed

Input: D022-2tables1primarykey1foreignkeyReferencesNoPrimaryKey

Expected result: DirectGraphTC0022

RDF:

@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

_:a <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Target> .
_:a <Target#litattr1> 1010 .
_:a <Target#key1attr1> "K1A1" .
_:a <Target#key1attr2> "K1A2" .
_:a <Target#key2attr1> "K2A1" .
_:a <Target#key2attr2> "K2A2" .

<Source/ID=1100> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Source> .
<Source/ID=1100> <Source#ID> 1100 .
<Source/ID=1100> <Source#attrA> "K2A2" .
<Source/ID=1100> <Source#attrB> "K2A1" .
<Source/ID=1100> <Source#ref-attrA;attrB> _:a .




D023-2tables2primarykeys2foreignkeysReferencesToNon-primarykeys

Title: Two tables, two primary keys, two foreign keys, references to a key other than primary key

Graphical representation:

Source
ID (PK)
INTEGER
attrA (FK)
CHARACTER(4)
attrB (FK)
CHARACTER(4)
1100K2A2K2A1
Target
PK (PK)
INTEGER
key1attr1
CHARACTER(4)
key1attr2
CHARACTER(4)
key2attr1
CHARACTER(4)
key2attr2
CHARACTER(4)
1010K1A1K1A2K2A1K2A2

SQL:

CREATE TABLE "Target" (
	"PK" INT,
	PRIMARY KEY("PK"),
	"key1attr1" CHAR(4),
	"key1attr2" CHAR(4),
	UNIQUE ("key1attr1", "key1attr2"),
	"key2attr1" CHAR(4),
	"key2attr2" CHAR(4),
	UNIQUE ("key2attr2", "key2attr1")
);

CREATE TABLE "Source" (
	"ID" INT,
	PRIMARY KEY("ID"),
	"attrA" CHAR(4),
	"attrB" CHAR(4),
	FOREIGN KEY ("attrA", "attrB") REFERENCES "Target"("key2attr2", "key2attr1")
);

INSERT INTO "Target" ("PK", "key1attr1", "key1attr2", "key2attr1", "key2attr2")
              VALUES (1010, 'K1A1'     , 'K1A2'     , 'K2A1'     , 'K2A2'     );

INSERT INTO "Source" ("ID", "attrA", "attrB")
              VALUES (1100, 'K2A2' , 'K2A1' );



File: D023-2tables2primarykeys2foreignkeysReferencesToNon-primarykeys

DirectGraphTC0023

Title: Generation of triples for two tables, two primary keys, two foreign keys, references to a key other than primary key

Purpose: Generation of triples from two tables, two primary keys, two foreign keys, references to a key other than primary key

Specification reference: #lead-ex

Review status: unreviewed

Input: D023-2tables2primarykeys2foreignkeysReferencesToNon-primarykeys

Expected result: DirectGraphTC0023

RDF:

@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<Target/PK=1010> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Target> .
<Target/PK=1010> <Target#PK> 1010 .
<Target/PK=1010> <Target#key1attr1> "K1A1" .
<Target/PK=1010> <Target#key1attr2> "K1A2" .
<Target/PK=1010> <Target#key2attr1> "K2A1" .
<Target/PK=1010> <Target#key2attr2> "K2A2" .

<Source/ID=1100> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Source> .
<Source/ID=1100> <Source#ID> 1100 .
<Source/ID=1100> <Source#attrA> "K2A2" .
<Source/ID=1100> <Source#attrB> "K2A1" .
<Source/ID=1100> <Source#ref-attrA;attrB> <Target/PK=1010> .




D024-2tables2primarykeys1foreignkeyToARowWithSomeNulls

Title: Two tables, two primary keys, a foreign key to a row with some NULLs in the key.

Graphical representation:

Source
ID (PK)
INTEGER
attrA (FK)
CHARACTER(5)
attrB (FK)
CHARACTER(5)
1100K2A21K2A11
1101K2A22NULL
Target
PK (PK)
INTEGER
key1attr1
CHARACTER(5)
key1attr2
CHARACTER(5)
key2attr1
CHARACTER(5)
key2attr2
CHARACTER(5)
1010K1A11K1A21K2A11K2A21
1011K1A12K1A22NULLK2A22

SQL:

CREATE TABLE "Target" (
	"PK" INT,
	PRIMARY KEY("PK"),
	"key1attr1" CHAR(5),
	"key1attr2" CHAR(5),
	UNIQUE ("key1attr1", "key1attr2"),
	"key2attr1" CHAR(5),
	"key2attr2" CHAR(5),
	UNIQUE ("key2attr2", "key2attr1")
);

CREATE TABLE "Source" (
	"ID" INT,
	PRIMARY KEY("ID"),
	"attrA" CHAR(5),
	"attrB" CHAR(5),
	FOREIGN KEY ("attrA", "attrB") REFERENCES "Target"("key2attr2", "key2attr1")
);

INSERT INTO "Target" ("PK", "key1attr1", "key1attr2", "key2attr1", "key2attr2")
              VALUES (1010, 'K1A11'    , 'K1A21'    , 'K2A11'    , 'K2A21'    );
INSERT INTO "Target" ("PK", "key1attr1", "key1attr2", "key2attr1", "key2attr2")
              VALUES (1011, 'K1A12'    , 'K1A22'    , NULL       , 'K2A22'    );

INSERT INTO "Source" ("ID", "attrA", "attrB")
              VALUES (1100, 'K2A21', 'K2A11');
INSERT INTO "Source" ("ID", "attrA", "attrB")
              VALUES (1101, 'K2A22', NULL   );




File: D024-2tables2primarykeys1foreignkeyToARowWithSomeNulls

DirectGraphTC0024

Title: Generation of triples from two tables, two primary keys, a foreign key to a row with some NULLs in the key.

Purpose: Generation of triples from two tables, two primary keys, a foreign key to a row with some NULLs in the key.

Specification reference: #lead-ex

Review status: unreviewed

Input: D024-2tables2primarykeys1foreignkeyToARowWithSomeNulls

Expected result: DirectGraphTC0024

RDF:

@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<Target/PK=1010> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Target> .
<Target/PK=1010> <Target#PK> 1010 .
<Target/PK=1010> <Target#key1attr1> "K1A11" .
<Target/PK=1010> <Target#key1attr2> "K1A21" .
<Target/PK=1010> <Target#key2attr1> "K2A11" .
<Target/PK=1010> <Target#key2attr2> "K2A21" .

<Target/PK=1011> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Target> .
<Target/PK=1011> <Target#PK> 1011 .
<Target/PK=1011> <Target#key1attr1> "K1A12" .
<Target/PK=1011> <Target#key1attr2> "K1A22" .
<Target/PK=1011> <Target#key2attr2> "K2A22" .

<Source/ID=1100> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Source> .
<Source/ID=1100> <Source#ID> 1100 .
<Source/ID=1100> <Source#attrA> "K2A21" .
<Source/ID=1100> <Source#attrB> "K2A11" .
<Source/ID=1100> <Source#ref-attrA;attrB> <Target/PK=1010> .

<Source/ID=1101> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Source> .
<Source/ID=1101> <Source#ID> 1101 .
<Source/ID=1101> <Source#attrA> "K2A22" .




D025-3tables3primarykeys3foreignkeys

Title: Three tables, three primary keys, three foreign keys

Graphical representation:

Projects
deptName (FK)
VARCHAR(50)
deptCity (FK)
VARCHAR(50)
lead (FK)
INTEGER
name
VARCHAR(50)
accountingCambridge8pencil survey
accountingCambridge8eraser survey
Addresses
ID (PK)
INTEGER
city
VARCHAR(10)
state
CHARACTER(2)
18CambridgeMA
TaskAssignments
worker (PFK)
INTEGER
project (PFK)
VARCHAR(50)
deptName (FK)
VARCHAR(50)
deptCity (FK)
VARCHAR(50)
deptName (FK)
VARCHAR(50)
deptCity (FK)
VARCHAR(50)
7pencil surveyaccountingCambridgeaccountingCambridge
Department
ID (PK)
INTEGER
manager (FK)
INTEGER
name
VARCHAR(50)
city
VARCHAR(50)
238accountingCambridge
People
ID (PK)
INTEGER
addr (FK)
INTEGER
deptName (FK)
VARCHAR(50)
deptCity (FK)
VARCHAR(50)
fname
VARCHAR(10)
718accountingCambridgeBob
8NULLNULLNULLSue

SQL:

CREATE TABLE "Addresses" (
	"ID" INT,
	PRIMARY KEY("ID"),
	"city" VARCHAR(10),
	"state" CHAR(2)
);

CREATE TABLE "Department" (
	"ID" INT,
	PRIMARY KEY("ID"),
	"name" VARCHAR(50),
	"city" VARCHAR(50),
	UNIQUE ("name", "city"),
	"manager" INT
);

CREATE TABLE "People" (
	"ID" INT,
	PRIMARY KEY("ID"),
	"fname" VARCHAR(10),
	"addr" INT,
	FOREIGN KEY ("addr") REFERENCES "Addresses"("ID"),
	"deptName" VARCHAR(50),
	"deptCity" VARCHAR(50)
);

ALTER TABLE "Department" ADD FOREIGN KEY("manager") REFERENCES "People"("ID");
ALTER TABLE "People" ADD FOREIGN KEY("deptName", "deptCity") REFERENCES "Department"("name", "city");

INSERT INTO "Addresses" ("ID", "city",      "state")
                 VALUES (18,   'Cambridge', 'MA');

INSERT INTO "People" ("ID", "fname", "addr", "deptName", "deptCity" )
              VALUES (8,    'Sue',   NULL,   NULL,       NULL);

INSERT INTO "Department" ("ID", "name",       "city",      "manager")
                  VALUES (23,   'accounting', 'Cambridge', 8);

INSERT INTO "People" ("ID", "fname", "addr", "deptName",   "deptCity" )
              VALUES (7,    'Bob',   18,     'accounting', 'Cambridge');

CREATE TABLE "Projects" (
	"lead" INT,
	"name" VARCHAR(50),
	UNIQUE ("lead", "name"),
	"deptName" VARCHAR(50),
	"deptCity" VARCHAR(50),
	UNIQUE ("name", "deptName", "deptCity"),
	FOREIGN KEY ("deptName", "deptCity") REFERENCES "Department"("name", "city")
);
CREATE TABLE "TaskAssignments" (
	"worker" INT,
	"project" VARCHAR(50),
	PRIMARY KEY ("worker", "project"),
	"deptName" VARCHAR(50),
	"deptCity" VARCHAR(50),
	FOREIGN KEY ("project", "deptName", "deptCity") REFERENCES "Projects"("name", "deptName", "deptCity"),
	FOREIGN KEY ("deptName", "deptCity") REFERENCES "Department"("name", "city")
);

ALTER TABLE "Projects" ADD FOREIGN KEY("lead") REFERENCES "People"("ID");
ALTER TABLE "TaskAssignments" ADD FOREIGN KEY("worker") REFERENCES "People"("ID");

INSERT INTO  "Projects" ("lead", "name",          "deptName",   "deptCity" )
                 VALUES (8,      'pencil survey', 'accounting', 'Cambridge');
INSERT INTO  "Projects" ("lead", "name",          "deptName",   "deptCity" )
                 VALUES (8,      'eraser survey', 'accounting', 'Cambridge');
INSERT INTO "TaskAssignments" ("worker", "project",       "deptName",   "deptCity" )
                       VALUES (7,        'pencil survey', 'accounting', 'Cambridge');



File: D025-3tables3primarykeys3foreignkeys

DirectGraphTC0025

Title: Generation of triples from three tables, three primary keys, three foreign keys

Purpose: Generation of triples from three tables, three primary keys, three foreign keys

Specification reference: #lead-ex

Review status: unreviewed

Input: D025-3tables3primarykeys3foreignkeys

Expected result: DirectGraphTC0025

RDF:

@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
@base <http://example.com/base/> .

<People/ID=7> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <People> .
<People/ID=7> <People#ID> 7 .
<People/ID=7> <People#fname> "Bob" .
<People/ID=7> <People#addr> 18 .
<People/ID=7> <People#ref-addr> <Addresses/ID=18> .
<People/ID=7> <People#deptName> "accounting" .
<People/ID=7> <People#deptCity> "Cambridge" .
<People/ID=7> <People#ref-deptName;deptCity> <Department/ID=23> .
<People/ID=8> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <People> .
<People/ID=8> <People#ID> 8 .
<People/ID=8> <People#fname> "Sue" .

<Addresses/ID=18> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Addresses> .
<Addresses/ID=18> <Addresses#ID> 18 .
<Addresses/ID=18> <Addresses#city> "Cambridge" .
<Addresses/ID=18> <Addresses#state> "MA" .

<Department/ID=23> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Department> .
<Department/ID=23> <Department#ID> 23 .
<Department/ID=23> <Department#name> "accounting" .
<Department/ID=23> <Department#city> "Cambridge" .
<Department/ID=23> <Department#manager> 8; .
<Department/ID=23> <Department#ref-manager> <People/ID=8> .

_:c <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Projects> .
_:c <Projects#lead> 8 .
_:c <Projects#ref-lead> <People/ID=8> .
_:c <Projects#name> "pencil survey" .
_:c <Projects#deptName> "accounting" .
_:c <Projects#deptCity> "Cambridge" .
_:c <Projects#ref-deptName;deptCity> <Department/ID=23> .

_:d <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <Projects> .
_:d <Projects#lead> 8 .
_:d <Projects#ref-lead> <People/ID=8> .
_:d <Projects#name> "eraser survey" .
_:d <Projects#deptName> "accounting" .
_:d <Projects#deptCity> "Cambridge" .
_:d <Projects#ref-deptName;deptCity> <Department/ID=23> .

<TaskAssignments/worker=7;project=pencil%20survey> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <TaskAssignments> .
<TaskAssignments/worker=7;project=pencil%20survey> <TaskAssignments#worker> 7 .
<TaskAssignments/worker=7;project=pencil%20survey> <TaskAssignments#ref-worker> <People/ID=7> .
<TaskAssignments/worker=7;project=pencil%20survey> <TaskAssignments#project> "pencil survey" .
<TaskAssignments/worker=7;project=pencil%20survey> <TaskAssignments#deptName> "accounting" .
<TaskAssignments/worker=7;project=pencil%20survey> <TaskAssignments#deptCity> "Cambridge" .
<TaskAssignments/worker=7;project=pencil%20survey> <TaskAssignments#ref-deptName;deptCity> <Department/ID=23> .
<TaskAssignments/worker=7;project=pencil%20survey> <TaskAssignments#ref-project;deptName;deptCity> _:c .



5 Acknowledgements

The Editors would like to give special thanks to the following contributors: Richard Cyganiak, Freddy Priyatna, Nuno Lopes, Juan Sequeda, Eric Prud'hommeaux, Toby Inkster, Ivan Mikhailov, and Alexander de León who provided useful comments to the Test Cases.
